Page 1
MP3-CD
Mini Hi-Fi System
FW-
M355
FW-
M355
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM1
1
3139 115 21421
Page 2
Important notes for users in the
U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1 Remove fuse cover and fuse.
2 Fix new fuse which should be a BS1362 5 Amp,
A.S.T.A. or BSI approved type.
3 Refit the fuse cover.
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board
should not be greater than 5 Amp.
Note: The severed plug must be disposed of to
avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N),
brown = live (L).
¶ As these colour s may not correspond with the
colour markings identifying the terminals in
your plug, proceed as follows:
– Connect the blue wire to the terminal
marked N or coloured black.
– Connect the brown wire to the terminal
marked L or coloured red.
– Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Italia
DICHIARAZIONE DI CONFORMITA’
Si dichiara che l’apparecchio FW-M355 Philips
risponde alle prescrizioni dell’ar t. 2 comma 1 del
D.M. 28 Agosto 1995 n. 548.
Fatto a Eindhoven
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven, The Netherlands
Norge
Typeskilt finnes på apparatens underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller elektrisk
støt, skal apparatet ikke utsettes for regn eller
fuktighet.
CAUTION
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous
radiation exposure or other unsafe
operation.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
2
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM2
3139 115 21421
Page 3
MP3-CD
FW-
MINI HIFI SYSTEM
CD/CD-R/CD-RW COMPATIBLE
DC
3
CHANGER
™
1
2
3
4
5
6
7
8
9
0
!
@
#
STANDBY-ON
ECO POWER
CD
OPEN
CLOSE
CHANGE
/
DISC
T
N
O
C
D
N
U
O
S
L
A
PLAYBACK
DIGITAL SOUND DISPLAY
L
A
M
I
T
P
O
DSC
T
E
C
H
N
O
L
O
R
T
I
G
I
D
J
A
Z
Z
K
C
O
R
BAND
TUNER TAPE AUX
MP3-CD
D
Y
N
A
M
SEARCH•TUNING SEARCH•TUNING PLAY• PAUSE
I
C
B
ALBUM-
A
S
S
B
O
O
S
TITLE-
T
PREV/
CD 1
TAPE 1 • 2 VIDEO
CD 2
MP3-CD
▲
STOP•CLEAR / DEMO STOP
A.REPLAYRDS NEWS RECORD
CD 3
ALBUM+
TITLE+
PRESET▲NEXT/PRESET
DIMCLOCK•TIMERPROG
MASTER VOLUME
PLAY / REC
¡
)
(
*
&
^
%
$
3
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM3
3
3139 115 21421
Page 4
DK
Advarsel: Usynlig laserstråling ved åbning
når sikkerhedsafbrydere er ude af funktion.
Undgå utsættelse for stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen fra
nettet. Den indbyggede netdel er derfor
tilsluttet til lysnettet så længe netstikket
sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på annat
sätt än i denna bruksanvisning specificerats,
kan användaren utsättas för osynlig
laserstrålning, som överskrider gränsen för
laserklass 1.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är därför
ansluten till elnätet så länge stickproppen
sitter i vägguttaget.
SF
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen muulla
kuin tässä käyttöohjeessa mainitulla tavalla
saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei
saa olla alttiina tippu-ja roiskevedelle.
Huom. Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu verkkoosa on kytkettynä sähköverkkoon aina
silloin, kun pistoke on pistorasiassa.
4
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM4
3139 115 21421
Page 5
Index
English ------------------------------------------------ 6
Français -------------------------------------------- 31
Español --------------------------------------------- 56
Deutsch --------------------------------------------- 81
Nederlands -------------------------------------- 106
Italiano -------------------------------------------- 131
English
Français
Español
DeutschNederlandsItalianoSvenskaDanskSuomi
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM5
Svenska ------------------------------------------- 156
Dansk --------------------------------------------- 181
Suomi --------------------------------------------- 206
Português ---------------------------------------- 231
Português
∂ППЛУИО¿ ----------------------------------------- 256
∂ППЛУИО¿
5
3139 115 21341
Page 6
Contents
English
General Information
Supplied accessories ............................................ 7
Acknowledgement ............................................... 7
Environmental information ................................ 7
Safety information ................................................ 7
Preparations
Rear connections ............................................. 8–9
Optional connection ........................................... 9
Inserting batteries into the remote control ... 9
Controls
Controls on the system and remote
control ........................................................... 10–11
Basic Functions
Plug and Play ........................................................ 12
Demonstration mode ........................................ 13
Switching the system on ................................... 13
Switching the system to standby mode ........ 13
Switching the system to Eco Power
standby mode ...................................................... 13
Dim mode ............................................................ 13
Volume control ................................................... 14
Sound control ..................................................... 14
Power
Antennas connection
Speakers connection
Connecting other equipment to your system
Digital Sound Control (DSC)
Dynamic Bass Boost (DBB)
Radio Reception
Tuning to radio stations .................................... 19
Storing preset radio stations .................... 19–20
Automatic preset programming
Manual preset programming
Tuning to preset radio stations ....................... 20
Erasing a preset radio station .......................... 20
RDS ................................................................ 20–21
Setting the RDS clock
NEWS ................................................................... 21
Tape Operation/Recording
Loading tape ........................................................ 22
Playing tapes ........................................................ 23
Rewinding/Fast forwarding ............................... 23
General information on recording ................. 23
Preparation for recording ................................ 24
One touch recording......................................... 24
CD Synchronised start recording .................. 24
Dubbing tapes ..................................................... 24
Clock/Timer
View clock ............................................................ 25
Clock setting ....................................................... 25
Timer setting ................................................ 25–26
Deactivating the timer
Activating the timer
Sleep timer setting ............................................. 26
External Sources
Listening to external sources .......................... 27
CD/MP3-CD Operations
Discs for playback .............................................. 15
About MP3 disc ........................................... 15–16
Loading discs ....................................................... 16
Playing discs ......................................................... 16
Replacing discs during playback ...................... 16
Selecting a desired track/passage .................... 17
Selecting a desired Album/Title
(MP3 disc only) ................................................... 17
Repeat play .......................................................... 17
Programming the disc tracks .................... 17–18
Erasing the programme ..................................... 18
6
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM6
Maintenance.............................................. 27
Specifications ........................................... 28
Troubleshooting ............................. 29–30
3139 115 21422
Page 7
General Information
This product complies with the radio
interference requirements of the European
Community.
Supplied accessories
– 2 speaker boxes
– remote control
– batteries (two AA size) for remote control
– AM loop antenna
– FM wire antenna
Acknowledgement
Energy Star
As an ENERGY STAR
Partner, Philips has
determined that this product
meets the ENERGY STARR guidelines for energy
efficiency.
R
Environmental information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialised company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Safety information
● Before operating the system, check that the
operating voltage indicated on the typeplate (or
the voltage indication beside the voltage
selector) of your system is identical with the
voltage of your local power supply. If not, please
consult your dealer.
● Place the system on a flat, hard and stable
surface.
● Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
● Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
● The lens may cloud over when the system is
suddenly moved from cold to warm
surroundings, making it impossible to play a disc.
Leave the system in the warm environment until
the moisture evaporates.
● The mechanical par ts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
● When the system is switched to Standby
mode, it is still consuming some power.
To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.
English
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM7
7
3139 115 21422
Page 8
Preparations
AM ANTENNA
English
AM loop
antenna
AM
ANTENNA
speaker
(right)
B
FM
ANTENNA
AUX/CDR
SPEAKERS 6Ω
AC power cord
Rear connections
The type plate is located at the rear of the
system.
For users in the U.K.: please follow the
instructions on page 2.
A Power
Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
WARNING!
– For optimal performance, use only the
original power cable.
– Never make or change any connections
with the power switched on.
LR
SUBWOOFER
OUT
+
R
C
—
—
L
+
FM wire antenna
speaker
(left)
A
B Antennas Connection
Connect the supplied AM loop antenna and FM
antenna to the respective terminals. Adjust the
position of the antenna for optimal reception.
AM Antenna
To avoid overheating of the system, a safety
circuit has been built in. Therefore, your
system may switch to Standby mode
automatically under extreme conditions. If
this happens, let the system cool down
before reusing it (not available for all versions).
8
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM8
● Position the antenna as far as possible from a TV,
VCR or other radiation source.
3139 115 21422
Page 9
Preparations
FM Antenna
● For better FM stereo reception, connect an
outdoor FM antenna to the FM ANTENNA
terminal.
C Speakers Connection
Front Speakers
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "R" and left speaker to
"L", coloured (marked) wire to "+" and black
(unmarked) wire to "-".
1
● Fully inser t the stripped portion of the speaker
wire into the terminal as shown.
Notes:
– For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
2
Optional connection
The optional equipment and connecting cords
are not supplied. Refer to the operating
instructions of the connected equipment for
details.
Connecting other equipment to your
system
Use a cinch cable to connect AUX/CDR to the
analogue audio out terminals of an external
equipment (TV, VCR, Laser Disc player, DVD
player or CD Recorder).
Note:
– If you are connecting equipment with a mono
output (a single audio out terminal), connect it to
the AUX/CDR left terminal. Alternatively, you can
use a “single to double” cinch cable (the output
sound still remain mono).
Inserting batteries into the
remote control
Insert two batteries type R06 or AA into the
remote control with the correct polarity as
indicated by the "+" and "-" symbols inside
the battery compar tment.
CAUTION!
– Remove batteries if they are exhausted
or will not be used for a long time.
– Do not use old and new or different
types of batteries in combination.
– Batteries contain chemical substances, so
they should be disposed off properly.
English
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM9
9
3139 115 21422
Page 10
Controls (main system’s illustrations on page 3)
Controls on the system and
remote control
1 STANDBY ON y
– to switch the system on or to standby mode.
2 ECO POWER
– to switch the system on or to Eco Power
standby mode.
3 DIGITAL SOUND DISPLAY
– the active DSC will be lighted.
4 TUNER (BAND)
– to select waveband : FM or MW.
TAPE (TAPE 1•2)
– to select tape deck 1 or 2.
AUX (VIDEO)
– to select the input for an additional appliance.
5 CD 1 / CD 2 / CD 3 (CD 1/2/3)
– to select disc tray 1, 2 or 3.
6 OPEN/CLOSE
– to open or close the disc tray.
7 DISC CHANGE
– to change disc(s).
8 DIGITAL SOUND CONTROL (DSC)
– to activate the jog control for DSC selection.
9 Jog control
– to select the desired sound effect for the
selected sound feature.
DSC ..................JAZZ, ROCK, TECHNO or
OPTIMAL.
DBB ..................DBB 1, DBB 2, DBB 3 or
DBB OFF.
0 DYNAMIC BASS BOOST (DBB)
– to activate the jog control for DBB selection.
! Mode Selection
PLAY•PAUSE ÉÅ
for CD/MP3-CD…to start or interrupt playback.
for Tape ............... to start playback.
for Plug & Play…(on the system only) to initiate
and start plug & play mode.
SEARCH•TUNING à (ALBUM -)
SEARCH•TUNING á (ALBUM +)
for MP3-CD ..... to select previous/next album.
for CD .................to search backward/forward.
for Tuner ............. to tune to a lower or higher
radio frequency.
for Tape ............... to rewind or fast forward.
for Clock ............ (on the system only) to set the
hour.
STOP•CLEAR / DEMO STOP Ç
for CD/MP3-CD…to stop playback or to clear a
programme.
for Tuner ............. (on the system only) to stop
programming or to erase a
selected preset.
for Tape ............... to stop playback or recording.
for Demo ........... (on the system only) to activate/
deactivate the demonstration.
for Clock ............ (on the system only) to exit clock
setting or cancel timer.
for Plug & Play…(on the system only) to exit plug
& play mode.
PREV í / PRESET 4 (TITLE -)
NEXT ë / PRESET3 (TITLE +)
for MP3-CD ..... to select previous/next title.
for CD .................to skip to the beginning of the
current, previous, or next track.
for Tuner ............. to select a preset radio station.
for Clock ............ (on the system only) to set the
minute.
@ RDS
– to select RDS information.
NEWS
– to hear News automatically.
# Tape deck 1
$ Tape deck 2
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM10
Page 11
DBB DSC
ÅÉ
1
3
2
4
6
5
7
9
8
VOLUME
á
à
DIM
ë
í
Ç
0
2
TAPE 1/2
MUTE
CD 1/2/3
AUX
TUNER
SLEEPPROG
REPEAT
TITLE
ALBUM
DISPLAY DISPLAY
£
ª
5
4
^
)
!
9
!
≤
∞
§
*
9
)
•
≥
% Tape deck operation
A. REPLAY
– to select continuous playback in either AUTO
REPLAY or ONCE mode only.
RECORD
– to start recording on tape deck 2.
^ PROG
for CD/MP3-CD…to programme disc tracks.
for Tuner ............. to programme preset radio
for Clock ............ to select 12- or 24-hour clock
stations.
mode.
& CLOCK•TIMER
– to view the clock, set the clock or set the timer.
* DIM
– to select different brightness for the display
screen : DIM 1, DIM 2, DIM 3 or DIM OFF.
( n
– to connect headphones.
) MASTER VOLUME (VOLUME +/-)
– to increase or decrease the volume.
¡ Display screen
– to view the current status of the system.
™ Disc tray
£ MUTE
– to interrupt or resume sound reproduction.
≤ DISPLAY (ALBUM)
– to display the album of MP3 disc.
∞ DISPLAY (TITLE)
– to display the title (track) of MP3 disc.
§ REPEAT
– to playback track/disc/programme repeatedly.
≥ SLEEP
– to activate/deactivate or set the sleep timer.
• Numeric keys (0 – 9)
(numbers consisting more than two figures must be
keyed in within 2 seconds.)
– to direct key in a track number for CD/MP3-CD.
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM11
Controls
ª B
– to switch the system to standby mode.
– to switch the system to Eco Power standby
mode.
Notes for remote control:
– First select the source you wish to control
by pressing one of the source select keys on
the remote control (for example CD1/2/3,
TUNER).
– Then select the desired function (for
exampleÉ,
í
,
ë
).
3139 115 21422
English
11
Page 12
Basic Functions
English
DIGITAL SOUND DISPLAY
STANDBY-ON
ECO POWER
CD
OPEN
CLOSE
CHANGE
/
DISC
L
A
M
I
T
P
O
DSC
T
E
C
H
N
O
L
O
R
T
N
O
C
D
N
U
O
S
L
A
T
I
G
I
D
J
A
Z
Z
K
C
O
R
BAND
TUNER TAPE AUX
MP3-CD
D
Y
N
A
M
SEARCH•TUNING SEARCH•TUNING PLAY• PAUSE
I
C
B
ALBUM-
A
S
S
B
O
O
S
TITLE-
T
PREV/
TAPE 1 • 2VIDEO
C
C
D
1
MP3-CD
▲
STOP• CLEAR / DEMO STOP
A.REPLAYRDS NEWS RECORD
MUTE
CD 1/2/3
1
4
MASTER VOLUME
C
D
D
2
3
ALBUM+
TITLE+
PRESET▲NEXT/PRESET
DIMCLOCK•TIMERPROG
7
à
ALBUM
2
TUNER
AUX
TAPE 1/2
3
2
6
5
8
9
SLEEPPROG
0
VOLUME
ÅÉ
ë
í
Ç
á
DIM
DSCDBB
TITLE
IMPORTANT!
Before operating the system, complete the
preparation procedures.
Plug and Play
Plug and Play allows you to store all available
RDS stations and radio stations automatically.
First time setup/power up
1 When you turn on the main supply, "AUTO
INSTALL - PRESS PLAY" is displayed.
2 PressÉÅ on the system to start installation.
➜ "INSTALL" is displayed, followed by "TUNER"
and "AUTO".
➜ PROG starts flashing.
➜ The system will automatically store the radio
stations with sufficient signal strength, starting
from all RDS stations and followed by FM and
MW bands respectively. Weak RDS stations may
be stored in later presets.
➜ When all the available radio stations are
stored or the memory for 40 presets are used,
the last preset radio station (or the first available
RDS station) will be played.
3 The system will proceed to set the RDS clock if
the first preset is an RDS station.
➜ "INSTALL" is displayed, followed by "TIME"
and "SEARCH RDS TIME".
➜ When RDS time is read, "RDS TIME" is
displayed and the current time will be stored.
➜ If RDS station does not transmit RDS time
within 90 seconds, the programme will exit
automatically and the display will show “NO RDS
TIME”.
● If the first preset is non-RDS station;
➜ The programme will exit automatically.
To reinstall Plug and Play
1 In standby or demonstration mode, press and
holdÉÅ on the system until "AUTO INSTALL
- PRESS PLAY" is displayed.
2 PressÉÅ again to start installation.
➜ All previously stored radio stations will be
replaced.
To exit without storing the Plug and Play
● Press Çon the system.
➜ If you do not complete the Plug and Play
installation, the function will be restarted when
you next turn on the main supply again.
Notes:
– When the power is turned on, the disc tray may
open and close to initialise the system.
– If no stereo frequency is detected during Plug
and Play, "CHECK ANTENNA" will be displayed.
– During Plug and Play, if no button is pressed
within 15 seconds, the system will exit Plug and
Play mode.
12
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM12
3139 115 21422
Page 13
Basic Functions
Demonstration mode
The system has a demonstration mode that
shows the various features offered by the system.
To activate the demonstration
● In standby mode, press and holdÇon the
system until "WELCOME" is displayed.
➜ The demonstration will begin.
To deactivate the demonstration
● Press and holdÇon the system until
"DEMO OFF" is displayed.
➜ The system will switch to standby mode.
Switching the system on
In standby/demonstration mode
● Press STANDBY ON to switch on the last
selected source.
● Press CD 1/2/3, TUNER, TAPE (TAPE 1/2)
or AUX.
● Press OPEN/CLOSE.
➜ The system will switch to CD mode.
In Eco Power standby mode
● Press ECO POWER to switch on the last
selected source.
● Press CD 1/2/3, TUNER, TAPE or AUX on
the remote control.
Switching the system to standby
mode
In demonstration mode
● Press and hold Ç on the system.
Switching the system to Eco
Power standby mode (< 0.5 Watt)
● Press ECO POWER (or press and hold B on
the remote control).
➜ "ECO PWR" is displayed, then the display
screen will go blank.
➜ The low power ECO POWER LED will be
lighted.
Note:
– If you have not deactivated the demonstration, it
will resume five seconds after the system switches
to Eco Power standby or standby mode.
Dim mode
You can select the desired brightness for the
display.
● In any source mode (except standby and Eco
Power standby mode), press DIM repeatedly to
select DIM 1, DIM 2, DIM 3 or DIM OFF display
mode.
➜ DIM is shown, except for DIM OFF mode.
Brightness
DIM
mode
normal
1
half
2
half
3
normal
OFF
Note:
– In standby mode, pressing DIM to select half or
full brightness for clock display.
Spectrum
Analyser
off
on
off
on
English
In any other source mode (except Eco
Power standby mode)
● Press STANDBY ON (or B on the remote
control).
➜ The clock will appear on the display when the
system is in standby mode.
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM13
13
3139 115 21422
Page 14
T
P
DSC
JAZZ
ROCK
TECHNO
OPTIMAL
DBB
off
on (3)
on (3)
on (2)
Basic Functions
English
Volume control
Adjust MASTER VOLUME (or press
VOLUME + or - on the remote control) to
increase or decrease the volume level.
To listen through the
headphones
● Connect the headphones plug to
the n socket at the front of the
system.
➜ The speakers will be muted.
To switch off the volume temporarily
● Press MUTE on the remote control.
➜ Playback will continue without sound and
"MUTE" is displayed.
● To restore the volume, press MUTE again or
increase the volume level.
Sound control
Digital Sound Control (DSC)
The DSC feature enables you to enjoy special
sound effects that have preset equaliser settings,
providing the best music reproduction.
1 Press DSC.
➜ The selected DSC is shown.
2 Adjust the jog control (or press DSC on the
remote control repeatedly) to select : JAZZ,
ROCK, TECHNO or OPTIMAL.
Dynamic Bass Boost (DBB)
There are three DBB settings to enhance the
bass response.
1 Press DBB.
➜ The selected DBB is shown, except for DBB
OFF mode.
2 Adjust the jog control (or press DBB on the
remote control repeatedly) to select : DBB 1,
DBB 2, DBB 3 or DBB OFF.
Note:
– Some discs or tapes might be recorded in high
modulation, which causes a distortion at high
volume. If this occurs, switch off DBB or reduce the
volume.
Automatic DSC-DBB selection
The best DBB setting is generated automatically
for each DSC selection. You can manually select
the DBB setting that best suits your listening
environment.
L
O
R
T
N
O
C
D
N
U
O
S
L
A
T
I
G
I
D
ISC
GE
1
14
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM14
D
Y
N
A
M
I
C
B
2
A
S
S
B
O
O
S
T
1
3139 115 21422
Page 15
CD/MP3-CD Operations
MP3-CD
FW-
MINI HIFI SYSTEM
DIGITAL SOUND DISPLAY
STANDBY-ON
ECO POWER
CD
OPEN
CLOSE
CHANGE
/
DISC
L
A
J
A
M
Z
I
Z
T
P
O
DSC
T
E
K
C
C
H
O
N
R
O
L
O
R
T
N
O
C
D
N
U
O
S
L
A
T
I
G
I
D
MP3-CD
D
Y
N
A
M
I
C
B
A
S
S
B
O
O
S
T
TAPE 1 • 2VIDEO
BAND
TUNER TAPE AUX
C
C
C
D
D
2
1
SEARCH•TUNING SEARCH•TUNING PLAY• PAUSE
ALBUM-
MP3-CD
TITLE-
▲
STOP• CLEAR / DEMO STOP
PREV/
A.REPLAYRDS NEWS RECORD
IMPORTANT!
– This system is designed for regular discs.
Therefore, do not use any accessories such
as disc stabiliser rings or disc treatment
sheets, etc., as offered on the market,
because they may jam the changer
mechanism.
– Do not load more than one disc into
each tray.
Discs for playback
This system is able to play :
– All pre-recorded audio CDs
– All finalised audio CDR and audio
CDRW discs
– MP3-CDs (CD-ROMs with MP3 tracks)
MUTE
CD 1/2/3
D
ALBUM+
TITLE+
PRESET▲NEXT/PRESET
3
CD/CD-R/CD-RW COMPATIBLE
MASTER VOLUME
DIMCLOCK•TIMERPROG
DC
3
CHANGER
About MP3 disc
Supported formats
– ISO9660, Joliet, Multisession
– Max. track number plus album is 255
– Max. nested directory is 8 levels
– The max. album number is 32
– The max. MP3 programme track number is 99
– Suppor ted VBR bit-rate
– Supported sampling frequencies for MP3 disc
are: 32 kHz, 44.1 kHz, 48 kHz
– Supported Bit-rates of MP3 disc are: 32, 64,
96, 128, 192, 256 (kbps)
Making your own MP3-CD
1 Rip the music from your own Digital Audio CDs
or download legal MP3 music from the Internet.
2 Record (“burn”) the music on CD-R(W) disc
with your home PC. Make sure to use a
recording speed not faster than indicated on the
CD-R(W) and avoid running other programme
simultaneously on your PC during the recording
process.
TUNER
AUX
TAPE 1/2
1
2
4
5
8
7
VOLUME
SLEEPPROG
0
ÅÉ
ë
í
Ç
DIM
DBB DSC
ALBUM
REPEAT
á
TITLE
à
DISPLAY DISPLAY
2
English
3
6
9
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM15
15
3139 115 21422
Page 16
CD/MP3-CD Operations
English
Sound Quality
Take note that MP3-CD compilations should
best contain only MP3 tracks (*.mp3). To
achieve a good MP3 quality, a bit rate of
128 kbps is recommended.
Loading discs
1 Press OPEN/CLOSE to open the disc tray.
2 Load up to two discs on the individual disc trays.
To load the third disc, press DISC CHANGE.
➜ The disc tray will rotate until the empty tray
is ready for loading.
OPEN•CLOSE
2
CLOCK.TIMER
2
CD TAPE
RECORD
TIMER SET
DUBBING
BAND
SHUFFLE
TIMER
SHUFFLE
1
FMMW
LWSW
2
STEREO
3
PRESET TUNING
CD CHANGER
PROGRAM
RECORD
DBB
FRONT
BACK
HSD
NR
3
DEMO
1
PLAY
MODE
PROGRAM
SET CLOCK
TIMER
AMPM
SIDE
RDS
MODE
CLEAR
Playing discs
a disc is loaded in the disc tray
the current selected disc tray is empty
the current selected disc tray is loaded
or playing
To play all discs on the disc tray
● PressÉÅ .
➜ All the available discs will play once, then stop.
➜ During playback, the selected disc tray, track
number and elapsed playing time of the current
track are displayed.
➜ For MP3 disc, TITLE is shown. For mixed
mode discs, only one mode will be selected for
playback depending on the recording format.
1
VOLUME
To play the selected disc only
● In CD mode, press CD 1, CD 2 or CD 3 on
the system.
➜ The selected disc will play once, then stop.
3 Press OPEN/CLOSE to close the disc tray.
➜ "READING" is displayed. The selected disc
tray, total number of tracks and the playing time
will appear on the display.
➜ For MP3 disc, the name of the first album
and title will be scrolled through the display once
and followed by "AXX TXXX".
Notes:
– Load the discs with the label side facing up.
– For MP3 disc, the disc reading time may exceed
10 seconds due to the large number of songs
compiled into one disc.
To interrupt playback
● PressÉÅ.
➜ The current track time flashes.
● To resume playback, pressÉÅ again.
To stop playback
● Press Ç.
Replacing discs during playback
1 Press DISC CHANGE.
➜ The disc tray will open without interrupting
current playback.
2 To change the inner disc, press DISC
CHANGE again.
➜ "DISC CHANGE" is displayed and the disc
will stop playing.
➜ The disc tray will close to retrieve the inner
disc, then reopen with the inner disc accessible.
16
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM16
3139 115 21422
Page 17
CD/MP3-CD Operations
Selecting a desired track/passage
To search for a particular passage during
playback
1 Press à or á until the desired passage is
located.
2 Press ÉÅ to resume normal playback.
To select a desired track
● Press í or ë repeatedly (or numeric keys
0-9 on the remote control) until the desired
track is displayed.
● If playback is stopped, pressÉÅ to start
playback.
Selecting a desired Album/Title
(MP3 disc only)
To select a desired album
● Press ALBUM -/+ (à or á) repeatedly.
➜ ALB starts flashing and the album’s name will
scroll through the display once.
To select a desired title
● Press TITLE -/+ repeatedly (í / ë or
numeric keys 0-9).
➜ TITLE starts flashing and the title’s name will
scroll through the display once.
Note:
– The album and title will only be displayed once
when selected. To view again, press the respective
DISPLAY button on the remote control.
Repeat play
You can select and change the various play
modes before or during playback.
1 Press REPEAT on the remote control
repeatedly to select :
➜ "TRACK" – to repeat playback of the current
track.
➜ "DISC" – to repeat playback of the current
disc.
➜ "PROGRAM" – to repeat playback of the
programmed tracks.
2 To resume normal playback, press REPEAT
until "REPEAT OFF" is displayed.
➜ REP is shown, except for REPEAT OFF mode.
Notes:
– During programme play mode, it is not possible
to repeat playback the current disc (Repeat Disc
mode).
– Pressing theÇ button will cancel all repeat
modes.
Programming the disc tracks
Programming tracks is possible when playback is
stopped. Up to 99 tracks can be stored in the
memory in any order.
1 Load the desired discs on the disc tray (refer to
“Loading discs”).
2 Press CD 1/2/3 to select a disc.
3 Press PROG to star t programming.
➜ PROG starts flashing.
4 Press í or ë repeatedly (or numeric keys
0-9 on the remote control) to select the desired
track.
● For MP3 disc, press ALBUM -/+ and
TITLE -/+ to select the desired album and
title for programming.
English
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM17
17
3139 115 21422
Page 18
CD/MP3-CD Operations
English
5 Press PROG to store the track.
● Repeat steps 3–5 to store other discs and
tracks.
6 To end programming, press Ç once.
➜
PROG stays and the programme mode
remains active.
➜ The total number of tracks programmed and
the total playing time are displayed.
➜ For MP3 disc, total playing time will not be
shown.
7 To start programme play, pressÉÅ.
➜ "PLAY PROGRAM" is displayed.
Erasing the programme
● Press Ç once when playback is stopped or
twice during playback.
➜ PROG disappears and "PROGRAM CLEARED"
is displayed.
Note:
– The programme will be erased when the system
is disconnected from the power supply or when the
disc tray is opened.
Notes:
– It is not possible to create a programme with
MP3 tracks from multiple CDs, or combined with
normal audio tracks.
– If the total playing time is more than "99:59"
then "--:--" is displayed instead of the total
playing time.
– If you attempt to programme more than 99
tracks, "FULL" is displayed.
– During programming, if no button is pressed
within 20 seconds, the system will exit the
programme mode automatically.
To review the programme
● Stop playback and pressí or ë repeatedly.
● To exit review mode, press Ç.
For Recording, please refer to “Tape
Operation/Recording”.
18
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM18
3139 115 21422
Page 19
STANDBY-ON
ECO POWER
CD
OPEN
CLOSE
CHANGE
T
N
O
C
D
N
/
U
O
S
L
A
DISC
DIGITAL SOUND DISPLAY
L
A
M
I
T
P
O
DSC
T
E
C
H
N
O
L
O
R
T
I
G
I
D
J
A
Z
Z
K
C
O
R
BAND
TUNER TAP E AU X
MP3-CD
D
Y
N
A
M
SEARCH•TUNING SEARCH •TUNING PLAY• PAUSE
I
C
B
ALBUM-
A
S
S
B
O
O
S
TITLE-
T
PREV/
C
D
1
TAPE 1 • 2 VIDEO
C
D
2
MP3-CD
▲
STOP• CLEAR / DEMO STOP
A.REPLAYRDS NEWS RECORD
Radio Reception
MUTE
CD 1/2/3
1
MASTER VOLUME
C
D
3
ALBUM+
TITLE+
PRESET▲NEXT/PRESET
DIMCLOCK•TIMERPROG
4
7
à
TUNER
AUX
2
5
8
0
VOLUME
ÅÉ
í
Ç
DIM
DBB DSC
ë
2
TAPE 1/2
3
6
9
SLEEPPROG
á
English
Tuning to radio stations
1 Press TUNER to select TUNER mode.
➜ "TUNER" is displayed. A few seconds later, the
current radio frequency will appear on the
display.
➜ If an FM station is received in stereo, is
displayed.
2 Press TUNER again to select the desired
waveband : FM or MW.
3 Press and hold à or á until the frequency
indication starts to change, then release.
➜ The display will show "SEARCH" until a radio
station with sufficient signal strength is found.
4 Repeat step 3 if necessar y until you find the
desired radio station.
● To tune to a weak station, press à or á briefly
and repeatedly until optimal reception found.
Storing preset radio stations
You can store up to 40 preset radio stations in
the memory.
Automatic Preset Programming
● Plug and Play setting (refer to “Basic Functions -
Plug and Play”).
OR
1 Press TUNER to select TUNER mode.
To begin automatic preset from a desired
preset number
● Press í or ë to select the desired preset
number.
➜ If a radio station has been stored in one of
the presets, it will not be stored again under
another preset number.
2 Press and hold PROG until "AUTO" is displayed.
➜ PROG starts flashing.
➜ The system will automatically store the radio
stations with sufficient signal strength, starting
from all RDS stations and followed by FM and
MW bands respectively. Weak RDS stations may
be stored in later presets.
➜ When all the available radio stations are
stored or the memory for 40 presets are used,
the last preset radio station (or the first available
RDS station) will be played.
To stop storing the automatic preset
● Press PROG or Ç on the system.
Note:
– If no preset number is selected, automatic preset
will begin from preset (1) and all your former
presets will be overridden.
pg 001-030/M355/22-Eng 4/17/02, 10:36 AM19
19
3139 115 21422
Page 20
Radio Reception
English
Manual Preset Programming
1 Tune to your desired radio station (refer to
“Tuning to radio stations”).
2 Press PROG.
➜ PROG starts flashing.
➜ The next available preset number is displayed
for selection.
To store the radio station to another
preset number
● Press í or ë to select the desired preset
number.
3 Press PROG again to store the radio station.
➜ PROG disappears.
● Repeat steps 1–3 to store other radio stations.
To exit manual preset mode
● Press Ç on the system.
Notes:
– If you attempt to store more than 40 preset
radio stations, "FULL" is displayed.
– During programming, if no key is pressed within
20 seconds, the system will exit the programme
mode automatically.
Tuning to preset radio stations
● Once you’ve programmed the radio stations,
press í or ë to select the desired preset
number.
➜ The preset number, radio frequency, and
waveband are displayed.
Erasing a preset radio station
1 Press í or ë to select the preset radio station
to be erased.
2 Press and hold Çon the system until
“PRESET DELETED” is displayed.
➜ The deleted radio frequency remains on the
display.
➜ The preset numbers of all other preset radio
stations in the band with higher numbers are
also decreased by one.
● Repeat steps 1–2 to erase other preset radio
stations.
For Recording, please refer to “Tape
Operation/Recording”.
RDS
RDS (Radio Data System) is a broadcasting
service that allows FM stations to send additional
information along with the regular FM radio
signal. This additional information can contain:
Station name: The radio station name is
displayed.
Programme type: The following programme
types exist and can be received by your tuner:
News, Affairs, Info, Sport, Educate, Drama,
Culture, Science, Varied, Pop M, Rock M, M.O.R.
(middle of the road music), Light M, Classics,
Other M, No type.
Radio text (RT): text messages appear on the
display.
20
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM20
To receive RDS Radio Stations
● Tuned to a radio station from FM band.
➜ If the radio station is transmitting RDS signal,
the RDS logo (RDS) and the radio station name
will appear on the display.
3139 115 21422
Page 21
Radio Reception
To Check the RDS information
● Press RDS repeatedly to scroll through the
following information (if available) :
STATION NAME ™ PROGRAMME TYPE ™
RADIO TEXT ™ TUNED FREQUENCY ™
STATION NAME ....
Notes:
– If the tuned radio station does not transmit RDS
signal or is a non RDS station, "NO RDS" is
displayed.
– If the RDS text message is not available at the
RDS station, "NO RDS TEXT" is displayed.
Setting the RDS clock
Some RDS radio station may be transmitting a
real clock time at an interval of ever y minute. It
is possible to set the clock by using a time signal
which is broadcast together with the RDS signal.
1 Press CLOCK•TIMER twice.
2 Press RDS.
➜ "SEARCH RDS TIME" is displayed.
➜ When RDS time is read, "RDS TIME" is
displayed and the current time will be stored.
➜ If the RDS radio station does not transmit
RDS time within 90 seconds, "NO RDS TIME" is
displayed.
Note:
– Some RDS radio station may be transmitting a
real time clock at a minute interval. The accuracy
of the transmitted time depends on the
transmitting RDS radio station.
NEWS (only available in RDS radio station)
Once the News PTY (Programme Type) is
detected in a RDS radio station, it will switch to
TUNER mode automatically.
IMPORTANT!
You can activate NEWS function in standby,
demonstration or any source mode except
Tuner and Eco Power standby mode.
To activate NEWS function
1 Press NEWS until "NEWS" is displayed.
➜ NEWS is shown.
➜ It will scan the radio stations stored in the
first 5 preset and wait for the News Programme
Type data to be available in any of these RDS
radio stations.
➜ While searching NEWS in progress, the
current source activity will remain uninterrupted.
2 When NEWS transmission is detected, the
system will switch to Tuner mode automatically.
➜ NEWS starts flashing.
Notes:
– You have to exit Tuner mode before selecting
NEWS function.
– Before you activate the NEWS feature, ensure
that the first five presets have RDS stations.
– The NEWS works only once for each activation.
– The NEWS will not start if a recording is in
progress.
– If no RDS station is detected, "NO RDS NEWS"
is displayed.
To cancel NEWS function
● Press NEWS again or press TUNER to select
tuner mode.
● During news bulletin, press any other available
source keys to execute the relevant source mode.
English
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM21
21
3139 115 21422
Page 22
Tape Operation / Recording
English
DIGITAL SOUND DISPLAY
STANDBY-ON
ECO POWER
CD
OPEN
CLOSE
CHANGE
/
DISC
L
O
R
T
N
O
C
D
N
U
O
S
L
A
T
I
G
I
D
PLAYBACK
L
A
J
A
M
Z
I
Z
T
P
O
DSC
T
E
K
C
C
H
O
N
R
O
MP3-CD
D
Y
N
A
M
I
C
B
A
S
S
B
O
O
S
T
TAPE 1 • 2 VIDEO
BAND
TUNER TAPE
CD 1CD 2CD
SEARCH•TUNING SEARCH•TUNING PLAY• PAUSE
ALBUM-
MP3-CD
TITLE-
▲
STOP•CLEAR / DEMO STOP
PREV/
A.REPLAYRDS NEWS RECORD
AUX
3
ALBUM+
TITLE+
PRESET▲NEXT/PRESET
DIMCLOCK•TIMERPROG
MASTER VOLUME
PLAY / REC
MUTE
TUNER
AUX
CD 1/2/3
1
2
4
5
8
7
0
VOLUME
ÅÉ
í
Ç
à
DIM
DBB DSC
ALBUM
REPEAT
DISPLAY DISPLAY
ë
TITLE
2
TAPE 1/2
3
6
9
SLEEPPROG
á
IMPORTANT!
– Before playing a tape, check and tighten
slack tape with a pencil. Slack tape may get
jammed or may burst in the mechanism.
– C-120 tape is extremely thin and is easily
deformed or damaged. It is not
recommended for use in this system.
– Store the tapes at room temperature and
do not put them too close to a magnetic
field (for example, a transformer, TV or
speaker).
22
Loading tape
1 Press on the tape deck to open the tape deck
door.
2 Load the tape with the open side downward and
full spool to the left.
3 Close the tape deck door.
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM22
3139 115 21422
Page 23
Tape Operation / Recording
Playing tapes
To playback a selected tape deck
1 Press TAPE repeatedly to select tape deck 1 or
2.
2 PressÉÅ.
To stop playback
● Press Ç.
To select automatic replay or one time
playback
● Press A. REPLAY repeatedly to select the
different playback modes.
➜ "AUTO REPLAY" ( ) or "ONCE" ( )
is displayed.
AUTO REPLAY …the tape will rewind
automatically at the end of
playback and replay again. It will
replay up to a maximum of 20
times.
ONCE .............. the tape will playback the
selected side once and then stop.
Rewinding / Fast forwarding
1 Stop playback, press à or á.
➜ The tape will stop automatically at the end of
rewinding or fast forwarding.
2 Press Ç to stop rewinding or fast forwarding.
Note:
– During rewinding or fast forwarding of a tape, it
is also possible to select another source (CD or
TUNER, for example).
General information on
recording
● For recording, use only tape of IEC type I
(normal tape).
● The recording level is set automatically,
regardless of the position of the Volume, DBB,
DSC and so forth.
● The tape is secured at both ends with leader
tape. At the beginning and end
of the tape, nothing will be
recorded for six to seven
seconds.
● To prevent accidental recording,
break out the tab on the left
shoulder of the tape side you
want to protect.
● If “CHECK TAPE” is displayed, the protection
tab has been broken. Put a piece of clear
adhesive tape over the opening.
IMPORTANT!
– Recording is permissible if copyright or
other rights of third parties are not
infringed upon.
– Recording is possible only on tape deck 2.
English
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM23
23
3139 115 21422
Page 24
Tape Operation / Recording
English
Preparation for recording
1 Press TAPE to select tape deck 2.
2 Load a recordable tape into tape deck 2 with full
spool to the left.
3 Prepare the source to be recorded.
CD – load the disc(s).
TUNER – tune to the desired radio station.
TAPE – load the prerecorded tape into tape
deck 1 with the full spool to the left.
AUX – connect external equipment.
When recording is in progress
➜ REC starts flashing.
● It is not possible to listen to another source,
except tape dubbing.
● It is not possible to activate the timer function
during recording or tape dubbing.
One touch recording
1 Press CD 1/2/3, TUNER or AUX to select the
source.
2 Star t playback of the selected source.
3 Press RECORD to star t recording.
To stop recording
● Press Ç on the system.
Note:
– One Touch Recording is not possible in TAPE
mode, "SELECT SOURCE" will be displayed.
To select another track during recording
1 PressÉÅ to interrupt recording.
2 Pressí or ë to select the desired track.
3 PressÉÅ again to resume recording.
To stop recording
● Press Ç.
➜ Recording and disc playback will stop
simultaneously.
Dubbing tapes
1 Press TAPE to select tape mode.
2 Load the prerecorded tape in tape deck 1.
● You can set the tape to the desired passage
where recording will start.
3 Press RECORD.
➜ Playing and recording will start simultaneously.
➜ "DUB" is displayed.
● Dubbing of tapes is possible on one side of the
tape only. To continue recording on the reverse
side, at the end of side A, flip the tape to side B
and repeat the procedure.
To stop dubbing
● Press Ç.
Notes:
– Dubbing of tapes is possible only from tape
deck 1 to tape deck 2.
– To ensure good dubbing, use tapes of the same
length.
CD Synchronised start recording
1 Press CD 1/2/3 to select the disc.
● Press í or ë to select the desired track to
start recording.
● You can programme the tracks in the order you
want them to be recorded (refer to “CD/MP3CD Operations - Programming the disc tracks”).
2 Press RECORD to star t recording.
➜ The disc will start playback automatically.
24
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM24
3139 115 21422
Page 25
STANDBY-ON
ECO POWER
CD
OPEN
CLOSE
CHANGE
T
N
O
C
D
N
/
U
O
S
L
A
DISC
DIGITAL SOUND DISPLAY
L
A
M
I
T
P
O
DSC
T
E
C
H
N
O
L
O
R
T
I
G
I
D
J
A
Z
Z
C
O
R
K
D
Y
N
A
O
S
T
BAND
TUNER TAPE
MP3-CD
C
D
M
SEARCH•TUNING SEARCH•TUNING PLAY• PAUSE
I
C
B
ALBUM-
A
S
S
B
O
TITLE-
PREV/
1
▲
STOP•CLEAR / DEMO STOP
A.REPLAYRDS NEWS RECORD
TAPE 1 • 2 VIDEO
AUX
C
C
D
D
2
ALBUM+
MP3-CD
TITLE+
PRESET▲NEXT/PRESET
Clock/Timer
MUTE
CD 1/2/3
MASTER VOLUME
3
DIMCLOCK•TIMERPROG
1
4
7
à
TUNER
AUX
2
5
8
0
VOLUME
ÅÉ
í
Ç
DIM
DBB DSC
ë
2
TAPE 1/2
3
6
9
SLEEPPROG
á
English
IMPORTANT!
When in Eco Power standby mode, it is not
possible to operate the clock or timer
function.
View clock
The clock (if it is set) will be shown in standby
mode.
To view the clock in any source mode
(CD or TUNER for example)
● Press CLOCK•TIMER.
➜ The clock is displayed for a few seconds.
➜ If the clock has not been set, "--:--" is
displayed.
Clock setting
The clock can be set in either 12-hour or
24-hour mode ("12:00 AM" or "00:00", for
example)
1 In standby or view clock mode, press
CLOCK•TIMER once. In other source mode,
press CLOCK•TIMER twice.
2 Press PROG repeatedly to select clock mode.
➜ "12:00 AM" or "00:00" starts flashing.
3 Press à or á on the system repeatedly to set
the hour.
4 Press í or ë on the system repeatedly to set
the minute.
5 Press CLOCK•TIMER again to store the
setting.
➜ The clock starts working.
To exit without storing the setting
● Press Çon the system.
Notes:
– The clock setting will be cancelled when the
power cord is disconnected or if a power failure
occurs.
– During clock setting, if no button is pressed
within 90 seconds, the system will exit clock setting
mode automatically.
– To set the clock automatically through the time
information in the RDS signal, refer to "Radio
Reception - Setting the RDS clock".
Timer setting
The system can switch on to CD, TUNER, or
TAPE mode automatically at a preset time,
serving as an alarm to wake you up.
IMPORTANT!
– Before setting the timer, ensure that the
clock is set correctly.
– The timer will always be switched on
after it has been set.
– The timer will not start if a recording is in
progress.
– The volume of the timer will increase
gradually from the minimum level to the
last tuned volume level.
1 Press and hold CLOCK•TIMER for more than
two seconds to select timer mode.
➜ "12:00 AM" or "00:00" or the last timer
setting starts flashing.
➜ starts flashing.
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM25
25
3139 115 21422
Page 26
Clock/Timer
English
2 Press CD 1/2/3, TUNER or TAPE to select
the desired source.
➜ “CD1 [or 2, 3] XX:XX" indicates the CD
mode is selected.
➜ “TU XX:XX” indicates the Tuner mode is
selected.
➜ “TA1 [or 2] XX:XX” indicates the Tape
mode is selected.
● Before setting timer, make sure the music source
has been prepared.
CD 1/2/3 – Load the disc(s).
TUNER – tune to the desired radio station.
TAPE – load the prerecorded tape into tape
deck.
3 Press à or á on the system repeatedly to set
the hour for the timer to start.
4 Press í or ë on the system repeatedly to set
the minute for the timer to start.
5 Press CLOCK•TIMER to store the timer.
➜ "TIMER ON" is displayed, followed by the set
timer "XX:XX" and the selected source.
➜ remains on the display.
● At the preset time, the selected sound source
will play.
To exit without storing the setting
● Press Çon the system.
Notes:
– When the preset time is reached and the
selected disc tray is empty, the next available disc
will be selected. If all the disc trays are not
available, Tuner will be selected automatically.
– During timer setting, if no button is pressed
within 90 seconds, the system will exit timer setting
mode automatically.
Deactivating the timer
1 Press and hold CLOCK•TIMER for more than
two seconds.
2 Press Ç on the system to cancel the timer.
➜ "CANCEL" is displayed and the disappear s.
Activating the timer (for the same preset
time and source)
1 Press and hold CLOCK•TIMER for more than
two seconds.
2 Press CLOCK•TIMER again to store.
➜ The last set timer information is displayed for
a few seconds and is shown.
Sleep timer setting
The sleep timer enables the system to switch to
standby mode automatically at a preset time.
1 Press SLEEP on the remote control repeatedly
to select a preset time.
➜ The selections are as follows (time in
minutes):
15 ™ 30 ™ 45 ™ 60 ™ 90 ™ 120 ™
OFF ™ 15 …
➜ "SLEEP XX" or "OFF" is displayed. "XX" is the
time in minutes.
2 When you reach the desired length of time, stop
pressing the SLEEP button.
➜ is shown, except for "OFF" mode.
➜ The sleep timer is now set. Before the system
switches to standby mode, a countdown of 10
seconds is displayed.
"SLEEP 10" ™ "SLEEP 9".... ™ "SLEEP 1"
™ "SLEEP"
To check the remaining length of time
after sleep timer is activated
● Press SLEEP once.
To change the preset sleep timer
● Press SLEEP again while the remaining sleep
timer is shown.
➜ The display will show the next sleep timer
options.
To deactivate the sleep timer
● Press SLEEP repeatedly until "OFF" is displayed,
or press the STANDBY ON button.
26
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM26
3139 115 21422
Page 27
External Sources
D
C CB
B
A
DIGITAL SOUND DISPLAY
L
A
J
A
M
Z
I
Z
T
P
O
DSC
T
E
K
C
C
H
O
N
R
O
TUNER TAPE
L
MP3-CD
BAND
CD 1
TAPE 1 • 2 VIDEO
CD 2
AUX
CD 3
Listening to external sources
1 Connect the audio out terminals of the external
equipment (TV, VCR, Laser Disc player, DVD
player or CD Recorder) to the AUX/CDR IN
terminals of your system.
2 Press AUX to select external equipment.
➜ "AUX" is displayed.
Cleaning the Cabinet
● Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning Discs
● When a disc becomes dir ty,
clean it with a cleaning cloth.
Wipe the disc from the centre
out.
● Do not use solvents such as
benzene, thinner, commercially
available cleaners, or antistatic spray intended for
analogue records.
Notes:
– All the sound control features (DSC or DBB, for
example) are available for selection.
– Refer to the operating instructions for the
connected equipment for details.
For Recording, please refer to “Tape
Operation/Recording”.
Maintenance
Cleaning the Heads and the Tape Paths
● To ensure good recording and playback quality,
clean the heads A, the capstan(s) B, and
pressure roller(s) C after every 50 hours of
tape operation.
● Use a cotton swab slightly moistened with
cleaning fluid or alcohol.
● You can also clean the heads by playing a
cleaning tape once.
English
Cleaning the disc lens
● After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
Demagnetising the heads
● Use a demagnetising tape available at your
dealer.
cleaner. Follow the instructions supplied with
cleaner.
27
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM27
3139 115 21422
Page 28
Specifications
English
AMPLIFIER
Output power ..................................... 2 x 80 W MPO
................................................................... 2 x 40 W RMS
Signal-to-noise ratio .......................... ≥ 67 dBA (IEC)
Frequency response .......................... 50 – 15000 Hz
Input sensitivity
AUX/CDR In .......................................... 500 mV / 1V
Output
Speakers ....................................................................≥ 6 Ω
Headphones ...................................... 32 Ω – 1000 Ω
(1) (6 Ω, 1 kHz, 10% THD)
CD/MP3-CD PLAYER
Number of programmable tracks ......................... 99
Frequency range .................................. 20 – 20000 Hz
Signal-to-noise ratio ....................................... ≥ 80 dBA
Channel separation ..........................≥ 60 dB (1 kHz)
Total harmonic distortion ........................... < 0.003%
MPEG 1 Layer 3 (MP3-CD) .......... MPEG AUDIO
MP3-CD bit rate ....................................... 32-256 kbps
Sampling frequencies ....................... 32, 44.1, 48 kHz
TUNER
FM wave range ...................................87.5 – 108 MHz
MW wave range ................................ 531 – 1602 kHz
Number of presets ........................................................ 40
Antenna
FM ..................................................................... 75 Ω wire
AM ............................................................ Loop antenna
(1)
(128 kbps advised)
SPEAKERS
System .................................... double port bass reflex
Impedance ........................................................................ 6 Ω
Woofer ........................................... 1 x 5 1/4" full range
Dimensions (w x h x d) . 210 x 310 x 235 (mm)
Weight\ .............................................................. 3.1 kg each
GENERAL INFORMATION
Material .............................................................. Polystyrene
AC Power ..................................... 220 – 230 V / 50 Hz
Power Consumption
Active ......................................................................... 80 W
Standby ................................................................. < 15 W
Eco Power Standby........................................ ≤ 0.5 W
Dimensions (w x h x d) .... 265x 310x 365 (mm)
Weight (without speakers)................................. 6.4 kg
Specifications and external appearance are
subject to change without notice.
TAPE DECK
Frequency response
Normal tape (type I) ...... 80 – 12500 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) ................................ ≥ 48 dBA
Wow and flutter ......................................... ≤ 0.4% DIN
28
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM28
3139 115 21422
Page 29
Troubleshooting
WARNING
Under no circumstances should you try to repair the system yourself, as this will invalidate the
warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If you
are unable to solve a problem by following these hints, consult your dealer or service centre.
Problem Solution
CD OPERATION
“UNREADABLE DISC” is displayed. – Check if the disc is inser ted upside down.
– Wait until the moisture condensation at the lens
has cleared.
– Replace or clean the disc, see “Maintenance”.
– Use a finalised CD-RW or a correct MP3-CD
format disc.
“NO DISC” is displayed. – Inser t a disc.
RADIO RECEPTION
Radio reception is poor. – If the signal is too weak, adjust the antenna or
connect an external antenna for better reception.
– Increase the distance between the Mini HiFi
System and your TV or VCR.
TAPE OPERATION/RECORDING
Recording or playback cannot be made. – Clean deck par ts, see “Maintenance”.
– Use only NORMAL (IEC I) tape.
– Apply a piece of adhesive tape over the missing
tab space.
The tape deck door cannot open. – Remove and reconnect the AC power plug and
switch on the system again.
English
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM29
29
3139 115 21422
Page 30
Troubleshooting
English
GENERAL
The system does not react when – Remove and reconnect the AC power plug and
buttons are pressed. switch on the system again.
Sound cannot be heard or is of poor – Adjust the volume.
quality. – Disconnect the headphones.
The left and right sound outputs are – Check the speaker connections and location.
reversed.
The remote control does not function – Select the source (CD 1/2/3 or TUNER, for
properly. example) before pressing the function button
The timer is not working. – Set the clock correctly.
Not all lighted buttons are showing light. – Press DIM to select DIM OFF display mode.
The Clock/Timer setting is erased. – Power has been interrupted or the power cord
The system displays features – Press and hold Çon the system to switch off
automatically. the demonstration.
– Check that the speaker s are connected correctly.
– Check if the stripped speaker wire is clamped.
– Make sure the MP3-CD was recorded within
32-256 kbps bit rate with sampling frequencies
at 48 kHz, 44.1 kHz or 32 kHz.
(É,í,ë).
– Reduce the distance between the remote
control and the system.
– Inser t the batteries with their polarities
(+/– signs) aligned as indicated.
– Replace the batteries.
– Point the remote control directly towards the IR
sensor .
– Press and hold CLOCK•TIMER to switch on the
timer.
– If recording or tape dubbing is in progress, stop
recording.
has been disconnected. Reset the clock/timer.
30
pg 001-030/M355/22-Eng 4/17/02, 10:37 AM30
3139 115 21422
Loading...
