Mini HiFi System

FW390C

Important notes for users in the U.K. Mains plug

FrançaisEnglish

This apparatus is fitted with an approved 13 Amp plug. To change a fuse in this type of plug proceed as follows:

1 Remove fuse cover and fuse.

Español

2 Fix new fuse which should be a BS1362 5 Amp, A.S.T.A. or BSI approved type. 3 Refit the fuse cover.

If the fitted plug is not suitable for your socket outlets, it should be cut off and an

Deutsch ∂ППЛУИО¿PortuguêsSuomiDanskSvenskaItalianoNederlands

appropriate plug fitted in its place. If the mains plug contains a fuse, this should have a value of 5 Amp. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5 Amp.

Note: The severed plug must be disposed of to avoid a possible shock hazard should it be inserted into a 13 Amp socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured with the following code: blue = neutral (N), brown = live (L). As these colours may not correspond with the colour markings identifying the terminals in your plug, proceed as follows:

• Connect the blue wire to the terminal marked N or coloured black.

• Connect the brown wire to the terminal marked L or coloured red.

• Do not connect either wire to the earth terminal in the plug, marked E (or e) or coloured green (or green and yellow).

Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead - not simply over the two wires.

Recording and playback of material may require consent. See Copyright Act 1956 and The Performer’s Protection Acts 1958 to 1972.

Italia

DICHIARAZIONE DI CONFORMITA’

Si dichiara che l’apparecchio FW390C Philips risponde alle prescrizioni dell’art. 2 comma 1 del D.M. 28 Agosto 1995 n. 548.

Fatto a Eindhoven , il 30/1/1999

Philips Consumer Electronics

5616 JB Eindhoven, The Netherlands

Philips, Glaslaan 2

Norge

Typeskilt finnes på apparatens underside.

Observer:

Den innebygde netdelen er derfor ikke frakoplet nettet så lenge apparatet er tilsluttet nettkontakten.

For å redusere faren for brann eller elektrisk støt, skal apparatet ikke utsettes for regn eller fuktighet.

Nettbryteren er sekundert innkoplet.

INDEX

CLASS 1

LASER PRODUCT

English .....................................4

Français .................................25

Español ..................................45

Deutsch..................................65

Nederlands............................85

Italiano.................................105

Svenska ...............................125

Dansk ...................................145

Suomi ...................................165

Português ............................183

∂ППЛУИО¿

............................ 203

EnglishFrançais

Español

NederlandsItalianoSvenskaDanskSuomiPortuguês∂ППЛУИО¿ Deutsch

English

CONTENTS GENERAL INFORMATION SAFETY INFORMATION

General Information ..........................5

Safety Information .............................5

Preparation ................................... 6 - 7

Controls .........................................8 - 9

Operating The System ............ 10 - 11

CD ...............................................12 - 14

Tuner .......................................... 14 - 16

Tape............................................ 16 - 17

Aux .....................................................17

Recording.................................. 18 - 19

Clock ..................................................19

Timer .......................................... 19 - 20

Maintenance ....................................20

Specifications ..................................21

Troubleshooting............................... 22

General Information

• The type plate (which contains the serial number) is located at the rear of the system.

• Recording is permissible if copyright or other rights of third parties are not infringed.

• This product complies with the radio interference requirements of the European Community.

Environmental Information

All unnecessary packaging material has been omitted. We have done our utmost to make the packaging easily separable into three mono-materials: cardboard (box), polystyrene foam (buffer) and polythene (bags, protective foam sheet).

Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Accessories

– Remote control – Batteries (2 x AA size) for remote control – AM loop antenna – FM wire antenna – AC power cord

(Supplied)

Safety Information

• Before operating the system, check that the operating voltage indicated on the typeplate (or the voltage indication beside the voltage selector) of your system is identical with the voltage of your local power supply. If not, please consult your dealer. The type plate is located at the rear of your system.

• When the system is switched on, do not move it around.

• Place the system on a solid base (e.g. a cabinet).

• Place the system in a location with adequate ventilation to prevent internal heat build-up in your system.

• Do not expose the system to excessive moisture, rain, sand or heat sources.

• Under no circumstances should you repair the system yourself, as this will invalidate the warranty!

• If the system is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lens of the CD unit inside the system. Should this occur, the CD player will not operate normally. Leave the power on for about one hour with no disc in the system until normal playback is possible.

• Electrostatic discharge may cause unexpected problems. See whether these problems disappear if you unplug the AC power cord and plug it in again after a few seconds.

• To disconnect the system from the power supply completely, remove the AC power plug from the wall socket.

English

PREPARATION

English

Rear Connections

SUBWOOFER

OUT

FRONT

FM AERIAL

75Ω

– –

AM AERIAL

MAINS

AUX IN

STANDBY ON

MIN MAX

CUT OFF FREQUENCY

HIGH POWER SUBWOOFER

60Hz 150Hz

AUDIO OUT

PREPARATION

A AM Loop Antenna

Connection

Connect the supplied loop antenna to the AM AERIAL terminal. Place the AM loop antenna far away from the system and adjust its position for the best reception.

B FM Wire Antenna

Connection

Connect the supplied FM wire antenna to the FM 75 Ω terminal. Adjust the position of the FM antenna for the best reception.

Outdoor Antenna

For better FM stereo reception connect an outdoor FM antenna to the FM AERIAL 75 Ω terminal using a 75 Ω coaxial wire.

C Speaker Connections

• Connect the right speaker to Front terminal R, with the red wire to + and the black wire to -.

• Connect the left speaker to Front terminal L, with the red wire to + and the black wire to -.

• Clip the stripped portion of the speaker wire as shown.

12 mm

unlock lock

D Connecting other

equipment to your system

You can connect the audio left and right OUT terminals of a TV, VCR, Laser Disc or DVD player to the AUX IN terminals at the rear of the system.

E Subwoofer Out Connection

You can connect either an optional active subwoofer or an optional wireless active subwoofer to the SUBWOOFER OUT terminal. The wireless system uses a radio frequency transmitter. The subwoofer reproduces just the low bass effect (e.g. explosions, the rumble of the spaceships, etc.). Be sure to follow the instructions supplied with the subwoofer unit.

Note: – Availability of wireless transmitter and

its peripherals are subjected to the approval of local authorities. Please check with respective local safety or approving authority.

F AC Power Supply

After all other connections have been made, connect the AC power cord to the system and to the wall outlet.

Inserting batteries into the Remote Control

• Insert the batteries (Type R06 or AA) into the remote control as shown in the battery compartment.

• To avoid damage from possible battery leakage, remove dead batteries or batteries that will not be used for a long time. For replacement, use type R06 or AA batteries.

English

CONTROLS

English

! 0

9 8

7 8

2 1

6 5

4 3

∞

OPTIMAL

DSC DBB

TECHNO

DIGITAL SOUND CONTROL

STANDBY.ON

DUBBING

RECORD A. REPLAY

NORM•FAST

DISC

REC

STEREO

JAZZ

REPEAT

SHUFFLE

TIMER

PROGRAM

ROCK

NEWS

REPLAY

DBB

I S

HSD MW

PMLW

FW 318C

CD TUNER TAPE AUX

• 2 •

TUNING

BAND

▲

STOP•CLEAR

TAPE 1 • 2

DEMO

PAUSE

PLAY

▲▲▲

DISC CHANGE

MAX

VIDEO

▲

PRESET

PREV NEXT

OPEN • CLOSE

RDS NEWS!

CLOCK TIMER

▲

PROGRAM

CHANGER

INCREDIBLE SURROUND

# $

% ^

& *

(

DBB

)

CD DIRECT

PAUSE

VOLUME

TUNERTAPE 1/2CD

MUTEAUXINC. SURR.

DSC

•

3 )

≥

OPENOPEN

™

SHUFFLE

REPEAT PROGRAM

≤

TAPE 1 TAPE 2

CONTROLS

Controls on the system and remote control

1 STANDBY-ON

– to switch the system on or to standby

mode.

– to store radio stations automatically

by pressing and holding for 5 seconds.

2 SOURCE : to select the following.

CD / (CD 1•2•3)

– to select CD mode. When CD in stop

mode; to select the disc tray 1, 2 or 3.

TUNER / (BAND)

– to select Tuner mode. When in tuner

mode; to select the waveband: FM, MW or LW.

TAPE / (TAPE 1• 2)

– to select Tape mode. When tape in

stop mode; to select either tape deck 1 or 2.

AUX / (VIDEO)

– to select sound from an external

source (e.g. TV, Laser Disc, DVD or VCR player).

3 MODE SELECTION

SEARCH à á (TUNING à á)

for CD............ to search backward/

forward.

for TUNER .....to tune to a lower or

higher radio frequency.

for TAPE .......to rewind or fast

forward on tape deck 2 only.

STOP•CLEAR Ç (DEMO)

for CD............ to stop CD playback or

for TUNER .....to stop programming.

for TAPE ........ to stop playback or

DEMO ...........to start or stop

PLAY É / PAUSEÅ

for CD............ to start or interrupt

for TAPE ........ to start playback.

PREV í / NEXT ë (PRESET 4 3)

for CD............ to skip to the beginning

for TUNER .....to select a preset

4 AUTO REPLAY

clear a program.

recording. demonstration mode

(on the system only)

playback.

of the current or previous/next track.

station in memory.

(available in tape

deck 2 only)

– to select playback mode either in

continuous AUTO PLAY or ONCE only.

5 RECORD

– to start recording on tape deck 2 only.

6 DUBBING

– to dub a tape in normal or fast speed.

7 DIGITAL SOUND CONTROL (DSC)

– to select the desired sound effect :

OPTIMAL, JAZZ, ROCK or TECHNO.

8 DIGITAL SOUND CONTROL

DISPLAY PANEL

– to view the selected DSC display.

9 DYNAMIC BASS BOOST (DBB)

– to switch on bass boost to enhance

bass response or to switch off bass boost.

0 DISPLAY

– to view the current setting of the

system.

! CD CAROUSEL TRAY @ CD DIRECT PLAY (DISC 1 / DISC 2 /

DISC 3)

– to select a CD tray for playback.

# OPEN•CLOSE

– to open or close the CD carousel tray.

$ DISC CHANGE

– to change CD(s).

% CLOCK/TIMER

– to view clock, set clock or timer.

^ RDS

– to select RDS data.

& NEWS!

– to hear news at a preset time

automatically.

* PROGRAM

– to program CD tracks in CD mode or

preset radio stations in tuner mode.

( INCREDIBLE SURROUND

– to switch on or off the surround sound

effect.

) VOLUME

– to adjust the volume level.

¡ n

– to connect headphones.

™ OPEN

– to open tape deck 2.

£ TAPE DECK 2 ≤ TAPE DECK 1 ∞ OPEN

– to open tape deck 1.

§ REPEAT

– to repeat a CD track.

≥ SHUFFLE

– to play all the available discs and their

tracks in random order.

• MUTE

– to switch off the sound temporarily.

ª B

– to switch the system to standby mode.

Notes for remote control: – First select the source you wish to

control by pressing one of the source select keys on the remote control (e.g. CD, TUNER, TAPE 1/2 or AUX).

– Then select the desired function

(PLAY, NEXT, etc.).

English

OPERATING THE SYSTEM

English

OPTIMAL

JAZZ

DBB

DSC

TECHNO

DIGITAL SOUND CONTROL

STANDBY.ON

DUBBING

RECORD A. REPLAY

RECORD REPLAY

NORM•FAST

NORMA•HIGH

REPEAT

SHUFFLE

PROGRAM

ROCK

TIMER

FW 318C

CD TUNER TAPE AUX

1 • 2 • 3 BAND

▲▲▲

▲

TUNING

Important: Before you begin operating the system, complete the preparation procedures.

Demonstration mode

The system has a demonstration mode that shows the various features offered by the system.

When the system is switched on for the first time, the demonstration mode will start automatically.

Note: – During the demonstration, if you press

any source (or standby-on) button, the system will switch to the respective mode (or standby).

– When the system is switched to standby

mode, the demonstration will resume five seconds later.

STEREO REPLAY

Notes : – When EASY SET is used, all previously

stored radio stations will be erased.

– The last preset radio station or the first

available RDS station will appear on the display when EASY SET is completed.

– If RDS station does not transmit RDS

time within 90 seconds, the program will exit automatically and the display will show “

NO RDS TIME

”.

Switching the system ON

• Press STANDBY•ON

only)

, CD, TUNER, TAPE or AUX.

You can also switch on the system by pressing any one of the CD DIRECT PLAY buttons.

(on the system

Switching the system to standby mode

• Press STANDBY•ON again.

™ The system will switch to standby

mode.

REC

DBB

NEWS

DEMO

STOP•CLEAR

I S

HSD MW

PMLW

TAPE 1 • 2

PAUSE

PLAY

MAX

MASTER VOLUME

VIDEO

▲

PRESET

PREV NEXT

RDS NEWS!

CLOCK TIMER

▲

PROGRAM

INCREDIBLE SURROUND

MIC LEVEL

Easy Set

EASY SET allows you to store all available radio stations in a particular band (FM, MW or LW) automatically.

1 Press and hold STANDBY•ON

system only)

system is in standby or demonstration mode.

™ "EASY SET" will be displayed and

for 5 seconds; when the

followed by "TUNER".

(on the

™ EASY SET will start with the last

active band.

To stop the demonstration mode

• Press and hold STOP•CLEAR Ç

the system only)

for

five seconds

the system is in demonstration mode.

™ The demonstration will stop. ™ The system will switch to standby

mode.

Note: – Even though the AC power cord is

removed from and reconnected to the wall socket, the demonstration will remain off until it is switched on again.

To start the demonstration mode

• Press and hold STOP•CLEAR Ç

the system only)

for

five seconds

the system is in standby mode. ™ The demonstration will begin.

(on

when

(on

when

™ All available radio stations with

sufficient signal strength will be stored or until 40 presets are filled.

2 The system will search once again for

the first available RDS station and to set the RDS time automatically.

• When searching RDS station; ™ “SEARCH RDS STATION” will

be displayed. If no RDS station is available, the program will exit automatically and "NO RDS STATION" will be displayed.

™ After a station is found, “EASY

SET” will be displayed and followed

by “TIME”.

• When searching RDS time; ™ “SEARCH RDS TIME” will be

displayed.

™ When RDS time is read, “RDS

TIME” will be displayed. The

current time is displayed for 2 seconds and will be stored automatically.

OPERATING THE SYSTEM

Selecting the Source

• Press the respective source selection button: CD, TUNER, TAPE or AUX. ™ The display indicates the selected

source.

Note: – For an external source, make sure that

you have connected the audio left and right OUT terminals of the external equipment (TV, VCR, Laser Disc or DVD player) to the AUX IN terminals.

Sound Control

Volume Adjustment

Adjust VOLUME to increase or decrease the sound level.

For Personal Listening

Connect the headphones plug to the n socket at the front of the system. The speakers will be muted.

Digital Sound Control (DSC)

The DSC feature enables you to enjoy special sound effects that have preset equalizer settings, providing the best music reproduction.

• Press DIGITAL SOUND CONTROL (DSC) to select OPTIMAL, JAZZ, ROCK or TECHNO. ™ The Digital Sound Control display

panel will light up respectively.

™ “OPTIMAL, JAZZ, ROCK or

TECHNO” will be displayed.

Automatic DSC-DBB selection

The best setting for the DBB is automatically generated for the respective DSC selection. You can manually select the DBB setting that best suits your listening environment.

DSC Selection

Optimal

Jazz

Rock

Techno

DBB On/Off

On Off Off Off

Dynamic Bass Boost (DBB)

The DBB mode enhances the bass response.

• Press DBB to switch on bass response.

™ The DBB button lights up. ™ “DBB ON” will be displayed.

DBB DBB

DBB OFF

DBB

To switch off DBB

• Press DBB again.

™ The DBB button light is switched off. ™ “DBB OFF” will be displayed.

Note: – Some CDs or tapes might be recorded in

high modulation. It may cause a distortion at high volume. If this occurs, switch off Incredible Surround, DBB or reduce the volume.

Incredible Surround

Normal stereo sound is determined by the distance between the front speakers. When Incredible Surround is switched on, it magnifies the virtual distance between the front speakers for an incredibly wide, enveloping, stereo effect.

• Press INCREDIBLE SURROUND to switch on. ™ The INCREDIBLE SURROUND button

lights up.

™ “IS” will be displayed.

To switch off Incredible Surround

• Press INCREDIBLE SURROUND again.

™ The INCREDIBLE SURROUND button

light is switched off.

™ “IS OFF” will be displayed.

Mute (only on remote control)

This feature allows you to temporarily switch off the sound of the system without switching off the system when you require a moment of silence.

• Press MUTE on the remote control to switch off the sound. ™ “MUTE” will be displayed.

• Press MUTE again on the remote control or increase the VOLUME level to switch on the sound.

English

OPTIMAL

DSC

TECHNO

DIGITAL SOUND CONTROL

STANDBY.ON

DUBBING

RECORD A. REPLAY

NORM•FAST

DISC 1 DISC 2 DISC 3

JAZZ

DBB

REPEAT

SHUFFLE

PROGRAM

ROCK

CD TUNER TAPE AUX

• 2 •

▲▲▲

▲

TUNING

Warning!

1) This system is designed for conventional CDs. Do not use any accessories like disc stabilizer rings or CD treatment sheets, etc., which may damage the CD mechanism.

2) Do not load more than one disc into each tray.

3) When the CD changer is loaded with CD(s), do not turn over or shake the system. This may jam the changer.

DISC CHANGE

OPEN • CLOSE

Loading the CD Changer

1 Press CD to select CD mode. 2 Press OPEN•CLOSE.

CHANGER

REC

STEREO

DBB

NEWS

REPLAY

TIMER

I S

HSD MW

PMLW

MAX

RDS NEWS!

CLOCK

PROGRAM

TIMER

MASTER VOLUME

INCREDIBLE SURROUND

™ The CD compartment slides out.

3 Load a CD with the printed side up in

the right tray.

• You can load another disc in the left tray.

• To load the third disc, press the DISC CHANGE button. ™ The CD changer carousel will rotate

until the empty tray is at the right

BAND

DEMO

STOP•CLEAR

TAPE 1 • 2

PAUSE

PLAY

VIDEO

▲

PRESET

PREV NEXT

▲

hand side and is ready for loading.

™ Playback will always start with the

disc in the outer right disc tray.

4 Press OPEN•CLOSE to close the CD

compartment.

Playing a CD

1 Press PLAY É to start playback.

™ The disc tray, track number and

elapsed playing time of the current track appear on the display.

• To interrupt playback, press PAUSE Å. ™ The playing time flashes.

• To resume playback, press PLAY É again.

2 To stop playback, press STOP•CLEAR

Ç.

Note: – All the available discs will play once,

then stop. When the CD has stopped playing, the system will switch to the standby mode after 15 minutes if no button is pressed.

™ The total number of tracks and

You can load up to three discs in the CD changer for continuous playback without interruption.

Discs for playback

This system can play all audio CD, finalized audio CD-Recordable and finalized audio CD-Rewritable format discs.

playing time of the last selected disc appear on the display.

CD Direct Play

You can play a CD directly by pressing the DISC 1, DISC 2 or DISC 3 button. The CD player will stop at the end of playback of the selected disc.

– When the button is lighted, it indicates

that there is a disc loaded in the disc tray.

Disc Change

You can change the outer 2 discs while the third inner disc is at the stop or playing mode.

1 Press DISC CHANGE.

™ The CD compartment slides out.

2 Replace the discs in the left and right

disc trays.

• If you press DISC CHANGE again during playback, the CD will stop playing. ™ The CD carousel tray will rotate until

the inner tray is at the right hand side and is ready for changing.

3 Press OPEN•CLOSE to close the CD

compartment.

Selecting a desired track

Selecting a desired track at the stop mode 1 Press PREV í or NEXT ë until the

desired track appears on the display.

2 Press PLAY É to start playback.

™ The selected track number and

elapsed playing time appear on the display.

Selecting a desired track during playback 1 Press PREV í or NEXT ë until the

desired track appears on the display. ™ The selected track number and

elapsed playing time appear on the display.

• If you press PREV í once it will skip to the beginning of the current track and play the track again.

Searching for a particular passage during playback

• Press and hold à or á until the desired passage is located. ™ The volume will be reduced.

• Play returns to normal when à or á is released.

Programming Tracks

Programming tracks of a loaded CD is possible in the stop mode. The display will indicate the total tracks stored in the program. Up to 40 tracks can be stored in the memory in any order. When 40 tracks are stored and you attempt to store another track, the display will show “PROGRAM FULL”.

1 Load the desired discs in the disc trays. 2 Press PROGRAM to start programming.

™ The PROGRAM flag starts flashing.

3 Press the CD (CD 1•2•3) button to

select the disc.

4 Press PREV í or NEXT ë to select

the desired track.

5 Press PROGRAM to store the track.

• Repeat steps 3 to 5 to store other discs and tracks.

6 Press STOP•CLEAR Ç once to end

programming mode. ™ The total number of tracks

programmed and total playing time appear on the display.

Notes: – If the total playing time is more than

“

99:59

” or if one of the programmed tracks has a number greater than 30, then “

--:--

instead of the total playing time.

– During programming, if no button is

pressed within 20 seconds, the system will exit program mode automatically.

” appears in the display

Playing the program

1 Press PLAY É to start program

playback. ™ “PLAY PROGRAM” appears on the

display.

™ The track number and elapsed

playing time of the current track will appear on the display.

• If you press REPEAT during program playback, the current track will be played repeatedly. ™ The REPEAT and PROGRAM flags will

be displayed.

2 Press STOP•CLEAR Ç to stop

program playback.

Note: – If you press any of the CD DIRECT PLAY

button, the system will play the selected disc or track and the stored program will be ignored temporarily. The PROGRAM flag will also temporarily disappear from the display and then reappear when the playback for the selected disc ends.

Reviewing the program

Reviewing of the program is only possible in the stop mode.

• Press PREV í or NEXT ë repeatedly to review the programmed tracks.

• Press STOP•CLEAR Ç to exit review mode.

Erasing the program (in the stop

mode)

• Press STOP•CLEAR Ç on the system. ™ “PROGRAM CLEARED” will be

displayed.

Note: – The program will be erased when the

system is disconnected from the power supply. If the CD carousel is opened, the tracks belonging to the outer two trays will be erased and the display will show “

CLEARED

Repeat

It will play the current track repeatedly. 1 Press REPEAT during CD playback.

™ “REPEAT TRACK” will be ™ The REPEAT flag appears on the

• The track will now be played repeatedly until you press STOP•CLEAR Ç.

2 Press REPEAT again to resume normal

playback. ™ The REPEAT flag disappears from the

” .

(only on remote control)

displayed. display.

display.

English

CD TUNER

English

Shuffle

(only on remote control)

It will play all the available discs and their tracks in random order. Shuffle may also be used when tracks are programmed.

To shuffle all the discs and tracks 1 Press SHUFFLE.

™ “SHUFFLE” will be displayed. ™ The SHUFFLE flag, the disc and the

track selected at random appear on the display.

• The discs and the tracks will now be played in random order until you press STOP•CLEAR Ç.

• If you press REPEAT during shuffling, the current track will be played repeatedly. ™ The REPEAT and SHUFFLE flags will

be displayed.

2 Press SHUFFLE again to resume normal

playback. ™ The SHUFFLE flag disappears from

the display.

REC

OPTIMAL

DSC

TECHNO

DIGITAL SOUND CONTROL

STANDBY.ON

DUBBING

RECORD A. REPLAY

NORM•FAST

Easy Set

JAZZ

DBB

ROCK

CD TUNER TAPE AUX

• 2 •

▲▲▲

(only in Standby or

STEREO

NEWS

HSD

REPLAY

REPEAT PROGRAM

TUNING

SHUFFLE

TIMER

BAND

▲

DEMO

STOP•CLEAR

Demonstration mode)

EASY SET allows you to store all available radio stations in a particular band (FM, MW or LW) automatically.

1 Press and hold STANDBY•ON

system only)

for 5 seconds; when the

(on the

system is in standby or demonstration mode. ™ "EASY SET" will be displayed and

followed by "TUNER".

™ EASY SET will start with the last

active band.

™ All available radio stations with

sufficient signal strength will be stored or until 40 presets are filled.

2 The system will search once again for

the first available RDS station and to set the RDS time automatically.

DBB

I S

PMLW

TAPE 1 • 2

PAUSE

PLAY

MAX

MASTER VOLUME

VIDEO

▲

PRESET

PREV NEXT

RDS NEWS!

CLOCK TIMER

▲

PROGRAM

INCREDIBLE SURROUND

• When searching RDS station; ™ “SEARCH RDS STATION” will

be displayed. If no RDS station is available, the program will exit automatically and "NO RDS STATION" will be displayed.

™ After a station is found, “EASY

SET” will be displayed and followed

by “TIME”.

• When searching RDS time; ™ “SEARCH RDS TIME” will be

displayed.

™ When RDS time is read, “RDS

TIME” will be displayed. The

current time is displayed for 2 seconds and will be stored automatically.

Notes : – When EASY SET is used, all previously

stored radio stations will be erased.

– The last preset radio station or the first

available RDS station will appear on the display when EASY SET is completed.

– If RDS station does not transmit RDS

time within 90 seconds, the program will exit automatically and the display will show “

Tuning to radio stations

1 Press TUNER to select TUNER mode.

NO RDS TIME

™ "TUNER" will be displayed.

A few seconds later, the current frequency will be displayed.

2 Press TUNER (BAND) again to select

the desired waveband : FM, MW or LW.

3 Press TUNING à or á for more than

one second, then release. ™ The display will show ‘SEARCH’

until a radio station with sufficient signal strength is found.

• Repeat this procedure until the desired station is reached.

• To tune to a weak station, briefly press TUNING à or á until the display shows the desired frequency and/or when the best reception has been obtained.

”.

TUNER

Storing Preset Stations

You can store up to 40 radio stations in the memory. When a preset radio station is selected, the preset number appears next to the frequency on the display.

Automatic programming 1 Press TUNER. 2 Press TUNER (BAND) again to select

the desired waveband : FM, MW or LW.

3 Press PROGRAM for more than one

second. ™ PROGRAM flag starts flashing and

‘AUTO’ will be displayed.

™ Every available station for the

selected waveband will be stored automatically. The frequency and preset number will be displayed briefly.

™ The system will stop searching when

all the available radio stations are stored or when the memory for 40 preset radio stations is used.

™ The system will remain tuned to the

last stored preset radio station.

• Repeat the above procedure to store other preset radio stations for the other waveband. Remember to select the next available preset number before proceeding. If not, some of the preset radio stations may be erased.

Notes: – You can cancel the automatic

programming by pressing PROGRAM or STOP•CLEAR Ç on the system only.

– If you want to reserve a section of

preset numbers, for example preset numbers 1 to 9, select preset 10 before starting automatic programming: now only the preset numbers 10 to 40 will be programmed.

Manual programming 1 Press TUNER. 2 Press TUNER (BAND) to select the

desired waveband : FM, MW or LW.

3 Press PROGRAM for less than one

second. ™ PROGRAM flag, the frequency and

preset number start flashing.

™ The next available preset number will

be displayed for selection.

4 Press TUNING à or á to tune to the

desired frequency.

• If you wish to store the radio station to another preset number, press PRESET 4 or 3 to select the desired preset number.

5 Press PROGRAM again.

™ PROGRAM flag will stop flashing,

and the radio station will be stored.

• Repeat the above procedure to store other preset radio stations.

Notes: – When 40 radio stations are stored and

you attempt to store another radio station, the display will show "

PROGRAM FULL

”. If you want to change an existing preset number; repeat steps 4 and 5.

– You can cancel manual programming by

pressing STOP•CLEAR Ç on the system only.

– During programming, if no button is

pressed within 20 seconds, the system will exit program mode automatically.

Tuning to Preset Radio Stations

• Press PRESET 4 or 3 to select the desired preset number. ™ The preset number, frequency and

waveband appear on the display

Receiving RDS radio station Ç

RDS (Radio Data System) is a broadcasting service that allows FM stations to send additional information along with the regular FM radio signal. This additional information can contain:

• STATION NAME: The station name is displayed.

• FREQUENCY: The frequency of the station is displayed.

• PROGRAM TYPE: The following program types exist and can be received by your tuner: News, Affairs, Info, Sport, Educate, Drama, Culture, Science, Varied, Pop M, Rock M, M.O.R. (middle of the road music), Light M, Classics, Other M, No type.

• RADIO TEXT (RT): text messages appear in the display.

When you have tuned to a RDS station, the RDS logo (Ç) and the station name will appear on the display:

• The display normally shows the radio station name if available. By repeatedly pressing RDS button you can change the type of display information: ™ The display shows in turn:

STATION NAME ™ FREQUENCY ™ PROGRAM TYPE ™ RADIO TEXT

™ STATION NAME ...

Note: – When you press the RDS button and the

display shows "

NO RDS

", it indicates that either the tuned station is not transmitting RDS signal or it is a non RDS station.

RDS Time

Some RDS station may be transmitting a real time clock at an interval of every minute.

Setting the time with RDS clock 1 Press CLOCK/TIMER.

™ "--:--" or current time appears on

the display.

2 Press CLOCK/TIMER once more to

enter clock setting mode. ™ "00:00" or current time starts

flashing.

3 Press RDS.

™ The message "SEARCH RDS

TIME" will be displayed.

English

TUNER TAPE

English

™ If the station does not transmit RDS

clock, "NO RDS TIME" will be displayed.

™ When the RDS clock is read, "RDS

TIME" will be displayed. The

current clock time is displayed for 2 seconds and will be stored automatically.

News

(only available in Radio Station

with RDS)

You can activate NEWS function in Standby or any source mode except Tuner mode. Once the News PTY (program type) is detected in a RDS station, it will switch to TUNER mode automatically.

To start NEWS function 1 Press NEWS.

• The NEWS flag and "NEWS ON" will be displayed.

• It will search for the first available RDS station in the presets and wait for the News PTY (program type) to be available. During News PTY search : ™ If NEWS activate from Standby or

Demo mode, the display will show "WAITING FOR NEWS".

™ If NEWS is activated from CD, Tape

or Aux mode, the current source activity will be remain uninterrupted.

™ If no RDS station is found after the

search, the News function will be switched off. The display will show

"NO RDS NEWS" and NEWS flag will disappear from the display.

• When News transmission is detected, the system will switch to Tuner mode. ™ The NEWS flag starts flashing.

• After News has ended, the last selected source mode will be resumed. ™ The NEWS flag will disappear from

the display.

To cancel NEWS function

• Press NEWS again.

™ The NEWS flag disappears and

"NEWS OFF" will be displayed.

Notes: – During NEWS bulletin, you can press

any available source button to cancel NEWS function and execute the relevant source mode.

– The NEWS works only once for each

activation.

– If NEWS is activated from Standby or

Demonstration mode, it switches to Tuner mode and the sound will be muted until News is available.

OPTIMAL

DSC

TECHNO

DIGITAL SOUND CONTROL

STANDBY.ON

DUBBING

RECORD A. REPLAY

NORM•FAST

REC

STEREO

JAZZ

DBB

REPEAT

SHUFFLE

TIMER

PROGRAM

ROCK

CD TUNER TAPE AUX

• 2 •

▲▲▲

▲

TUNING

REPLAY

BAND

DBB

NEWS

DEMO

STOP•CLEAR

I S

HSD MW

PMLW

TAPE 1 • 2

PAUSE

PLAY

MAX

MASTER VOLUME

VIDEO

▲

PRESET

PREV NEXT

RDS NEWS!

CLOCK TIMER

▲

PROGRAM

TAPE 1 TAPE 2

Loading a tape

• Press OPEN.

• The tape deck door opens.

• Load the tape with the open side downward and the full spool to the left.

• Close the tape deck door.

INCREDIBLE SURROUND

OPENOPEN

TAPE AUX

Tape Playback

1 Press TAPE to select TAPE mode.

™ "TAPE 1" or "TAPE 2" will be

displayed.

• Press TAPE again to select either tape deck 1 or tape deck 2.

2 Load the tape into the selected tape

deck.

3 Press PLAY É to start playback.

3a(For Tape Deck 2 only)

Press A. REPLAY to select the different type of play mode

4 Press STOP Ç to end playback.

Note: – When the tape has stopped playing, the

system will switch to the standby mode automatically after 15 minutes if no button is pressed.

Auto Replay

• Press A. REPLAY to select either continuous AUTO REPLAY or ONCE during tape playback. ™ "AUTO REPLAY" or "ONCE" will

be displayed.

(see auto replay)

(only on tape deck 2)

Notes: – This feature is available during tape

playback only.

– When "

AUTO REPLAY

" is selected, the tape will rewind automatically at the end of playback for the selected side. Then it will start playing again. It will replay up to a maximum of 20 times or when you press STOP Ç.

– When "

ONCE

" is selected, the tape will play the selected side once and then stop.

Rewind/Fast Forward

(only on

tape deck 2)

At the stop mode 1 You can rewind or fast forward the tape

by pressing à or á respectively. ™ "OOO" or "PPP" will be displayed

depending on which button is pressed.

™ The tape will stop automatically at

the end of the rewinding or fast forwarding.

2 Press STOPÇ to stop rewind or fast

forward.

During playback

• Press and hold à or á respectively until the desired passage is located. ™ During searching, the sound is

reduced to a low volume.

™ When you release à or á, the

tape continues playing.

Notes: – During rewinding or fast forwarding of a

tape, it is possible to select another source (e.g. CD, TUNER or AUX ).

– Check and tighten slack tape with a

pencil before use. Slack tape may get jammed or may burst in the mechanism.

– C-120 tape is extremely thin and is

easily deformed or damaged. It is not recommended for use in this system.

– Store the tapes at room temperature

and do not put them too close to a magnetic field (for example, a transformer, TV or loudspeaker boxes).

REC

STEREO

DBB

NEWS

HSD

REPLAY

REPEAT PROGRAM

SHUFFLE

TIMER

TUNER TAPE AUX

BAND

I S

TAPE 1 • 2

RDS NEWS

CLOCK

MAX

PROGR

TIMER

MASTER VOLU

VIDEO

Selecting External Equipment

If you have connected the audio out terminals of the external equipment (TV, VCR, Laser Disc or DVD player) to the AUX IN terminals, you can hear the enhanced sound from the system.

• Press AUX to select the external mode. ™ "AUX" will be displayed.

Note: – All the sound control features (e.g. DSC,

DBB, etc.) are available for selection.

English

RECORDING

English

OPTIMAL

DSC

TECHNO

DIGITAL SOUND CONTROL

STANDBY.ON

DUBBING

RECORD A. REPLAY

NORM•FAST

REC

STEREO

JAZZ

DBB

REPEAT

SHUFFLE

PROGRAM

ROCK

TIMER

CD TUNER TAPE AUX

1 • 2 • 3 BAND

▲▲▲

▲

TUNING

REPLAY

DBB

NEWS

DEMO

STOP•CLEAR

I S

HSD MW

PMLW

TAPE 1 • 2

PAUSE

PLAY

MAX

MASTER VOLUME

VIDEO

▲

PRESET

PREV NEXT

RDS NEWS!

CLOCK TIMER

▲

PROGRAM

INCREDIBLE SURROUND

TAPE 1 TAPE 2

Notes: – For recording, use only tape of IEC type I

(normal tape) or IEC type II (Chrome).

– The tape is secured at both ends with

leader tape. At the beginning and end of tape, nothing will be recorded for six to seven seconds.

– The recording level is set automatically,

regardless of the position of VOLUME,

DBB or Incredible Surround.

– To prevent accidental recording, break

out the tab on the left shoulder of the tape side that you want to protect.

– If "

OPENOPEN

CHECK TAPE

protection tab has been broken. Put a

" is displayed, the

piece of clear adhesive tape over the opening. Do not cover the Chrome tape detection hole when covering the tab opening.

One Touch Recording

• For One Touch Recording, as soon as you press RECORD, the current source will be recorded on tape deck 2.

1 Load a blank tape in tape deck 2. 2 Press RECORD to start recording.

™ REC flag starts flashing.

3 Press STOP Ç to stop recording.

Note: – When you press RECORD at TAPE mode,

“

SELECT OTHER SOURCE

displayed. One Touch Recording is not

” will be

Dubbing tapes

(from tape deck 1 to

tape deck 2)

1 Press TAPE to select tape deck 2 . 2 Load the prerecorded tape into tape

deck 1 and a blank tape into tape deck

2. ™ Make sure that the tape in tape deck

1 has its full spool to the left.

3 Press DUBBING

speed dubbing or

seconds

once

for normal

twice within 2

for high speed dubbing.

™ "NORMAL" (normal speed) or

"FAST" (high speed) will be displayed and then followed by "DUBBING".

™ HSD flag appears on the display for

high speed dubbing.

• Dubbing will start immediately. ™ REC flag starts flashing.

4 Press STOP Ç to stop dubbing.

Notes: – At the end of side A, flip the tapes to

side B and repeat the procedure.

– Dubbing of tapes is only possible from

tape deck 1 to tape deck 2.

– To ensure good dubbing, use tapes of

the same length.

– During high speed dubbing in Tape

mode, the sound is reduced to a low volume.

– You can switch to other source while

dubbing.

possible at TAPE mode.

RECORDING CLOCK TIMER

CD Synchro Start Recording

1 Load a blank tape into tape deck 2 and a

disc into the disc tray.

2 Press CD to select CD mode .

™ You can program the tracks in the

order you want them to be recorded (see Programming Tracks). If not, the tracks are recorded according to the selected disc.

3 Press RECORD to start recording.

™ REC flag starts flashing.

• CD will start playback automatically.

4 Press STOP Ç to stop recording.

Recording from other sources

(only on tape deck 2)

1 Load a blank tape into tape deck 2. 2 Press CD, TUNER or AUX.

• Start playback of the selected source. 3 Press RECORD â to start recording.

™ REC flag starts flashing.

4 Press STOP Ç to stop recording.

Note: – During recording, it is not possible to

listen to another sound source.

REC

TUNING

REPEAT PROGRAM

STEREO

NEWS

HSD

REPLAY

SHUFFLE

TIMER

▲

DEMO

STOP•CLEAR

OPTIMAL

DSC

TECHNO

DIGITAL SOUND CONTROL

STANDBY.ON

DUBBING

RECORD A. REPLAY

NORM•FAST

JAZZ

DBB

ROCK

CD TUNER TAPE AUX

1 • 2 • 3 BAND

▲▲▲

View Clock

You can view the clock (if it is set) at standby or any source mode. It will be displayed for about 7 seconds.

• Press CLOCK/TIMER briefly. ™ “10:25” (the current time) will be

displayed.

™ “--:--” will be displayed if the

clock is not set.

Clock Setting

The clock is set in 24-hour mode, e.g. “00:00“ or “23:59“. Before setting the clock, you must be in the View Clock mode.

1 Press CLOCK/TIMER to select clock

mode. ™ “00:00” or the current time starts

flashing.

™ “à , á , í , ë, Ç” light up.

DBB

I S

PMLW

TAPE 1 • 2

PAUSE

PLAY

MAX

MASTER VOLUME

VIDEO

▲

PRESET

PREV NEXT

RDS NEWS!

CLOCK TIMER

▲

PROGRAM

INCREDIBLE SURROUND

2 Set the hour with à or á. 3 Set the minute with í or ë. 4 Press CLOCK/TIMER again to store the

setting. ™ The clock starts running.

• To exit without storing the setting, press Ç.

Notes: – During clock setting, if no button is

pressed within 90 seconds, the system will exit clock setting mode automatically.

– When a power interruption occurs, the

clock setting is erased.

– To set the time with RDS clock, see

"Receiving RDS Radio Station" under TUNER section.

Timer Setting

• The system can switch on to CD, TUNER or TAPE 1 mode automatically at a preset time. It can serve as an alarm to wake you up. After half an hour from the preset time, the system will return to the standby mode if no button is pressed.

• Before setting the timer, make sure the

clock is set correctly.

• The timer will always be switched on once it is set.

• The volume of the timer will be at the last setting before the set is switched to standby mode.

1 Press and hold CLOCK/TIMER for more

than 2 seconds to select timer mode. ™ “ON 00:00” or the last set timer

starts flashing. The TIMER flag flashes.

™ The last selected source is lighted

while other available sources are flashing.

™ “à , á , í , ë, Ç” light up.

2 Press CD, TUNER or TAPE to select the

desired source.

3 Press à or á to set the hour for the

timer to start.

4 Press í or ë to set the minute for

the timer to start.

English

TIMER MAINTENANCE

English

5 Press CLOCK/TIMER to store the start

time.

™ The TIMER is now set. ™ The TIMER flag remains on the

display.

• To exit without storing the setting, press Ç.

• At the preset time, the TIMER will be activated. ™ The selected source will be played.

Notes: – During timer setting, if no button is

pressed within 90 seconds, the system will exit timer setting mode automatically.

– If the source selected is TUNER, the last

tuned frequency will be switched on.

– If the source selected is CD, playback

will begin with the first track of the last selected disc. If the CD trays are empty, the TUNER will be selected instead.

– If the source selected is TAPE 1, and if

the preset time is reached during high speed dubbing, the TUNER source will be selected instead.

To cancel the TIMER 1 Press CLOCK/TIMER for more than 2

seconds.

2 Press Å to cancel the timer.

™ “CANCEL” will be displayed. ™ The TIMER flag disappears from the

display.

To start the TIMER again

(for the same

time)

1 Press CLOCK/TIMER for more than 2

seconds.

2 Press CLOCK/TIMER again to store the

start time and the selected source.

Maintenance

Cleaning the Cabinet

• Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives.

Cleaning Discs

• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center out.

• Do not use solvents such as benzine, thinner, commercially available cleaners, or antistatic spray intended for analog records.

Cleaning the CD lens

• After prolonged usage, dirt or dust may accumulate at the CD lens. To ensure good playback quality, clean the CD lens with Philips CD Lens Cleaner or any commercially available. Follow the instructions supplied with the Lens Cleaner.

Cleaning the Heads and the Tape Paths

• To ensure good recording and playback quality, clean the heads, the capstan(s), and pressure roller(s) after every 50 hours of tape operation.

• Use a cotton swab slightly moistened with cleaning fluid or alcohol.

• You can also clean the heads by playing a cleaning tape through once.

Demagnetizing the heads

• Use a demagnetizing tape available at your dealer.

SPECIFICATIONS

Specifications

AMPLIFIER

Output power

(1)

RMS

(6 Ω, 1 kHz, 10% THD).................... 2 x 25 W

Music Power .................................................... 2 x 50 W

Signal-to-noise ratio..................................... ≥ 65 dBA (IEC)

Frequency response..................................... 50 – 15,000 Hz

Input sensitivity

Aux In.................................................................... 700 mV

Output

Speakers

(Left/Right) ..............................................

Headphones..............................................32 Ω – 1000 Ω

Subwoofer ................................................................ 1.5 V

(1) ± 1 dB

CD PLAYER

Number of programmable tracks .....................................40

Frequency range ........................................... 20 – 20000 Hz

Signal-to-noise ratio..............................................≥ 80 dBA

Channel separation ..................................... ≥ 60 dB (1 kHz)

Total harmonic distortion ..................................... < 0.003%

TUNER

FM wave range........................................... 87.5 – 108 MHz

MW wave range.......................................... 531 – 1602 kHz

LW wave range..............................................153 – 279 kHz

Number of presets............................................................ 40

Antenna

FM ....................................................................75 Ω wire

AM............................................................... Loop antenna

≥ 6 Ω

TAPE DECK

Frequency range

Chrome tape (type II) ...................... 80 – 14,000 Hz (8 dB)

Normal tape (type I) ....................... 80 – 12,500 Hz (8 dB)

Signal-to-noise ratio

Chrome tape (type II) ..........................................≥ 52 dBA

Normal tape (type I) ...........................................≥ 48 dBA

Wow and flutter ................................................≤ 0.4% DIN

SPEAKERS

System .................................2 way; double port bass reflex

Impedance ..................................................................... 6 Ω

Woofer......................................................................1 x 5.5"

Tweeter.....................................................................1 x 2.5"

Dimensions (w x h x d) ...................... 210 x 310 x 240 (mm)

Weight ............................................................... 2.3 kg each

GENERAL INFORMATION

Material/finish ..................................................Polystyrene

AC Power ..............................................220 – 230 V / 50 Hz

Power Consumption

Dimensions (w x h x d) ...................... 265 x 310 x 330 (mm)

Weight

(Front Left/Right)

Active...................................................................... 44 W

Standby ...............................................................≤ 15 W

(without speakers) .........................................

5.2 kg

Subject to modification

English

TROUBLESHOOTING

English

Warning! Under no circumstances you should try to repair the set yourself as this will invalidate the guarantee. Do not open the set as there is a risk of electric shock.

• If a fault occurs, check the points listed

below before taking the system for repair.

• Should any problems persist after you

have made these checks, consult your nearest dealer or service center.

CD Player Operation

“NO DISC” is displayed.

• The disc is inserted upside down.

™

Place CD with printed side up.

• Moisture condensation at the lens.

™

Wait until lens has adjusted to normal

room temperature.

• There is no disc in the CD tray.

™

Insert a CD.

• The CD is dirty, badly scratched or

warped.

™

Clean or replace the CD.

• The CD lens is dirty or dusty

™

See section under Maintenance.

“DISC NOT FINALIZED” is displayed.

• The CD-RW or CD-R disc is not properly

recorded for the use of a standard CD

player.

™

Read the instruction booklet of your CD-

Rewritable or CD-Recorder on how to

finalize a recording.

• The CD is badly scratched or dirty.

™

Replace or clean CD.

Radio Reception

Poor radio reception

• The signal strength is too weak.

™

Adjust the antenna.

• The TV or VCR is too close to the stereo system.

™

Separate the stereo system from the TV or VCR.

™

Connect an external antenna for better reception.

Tape Deck Operation

“RECORDING ACTIVE” is displayed.

• A recording is in progress.

™

Stop the recording or wait until it is finished.

“TAPE DUBBING ONLY” is displayed.

• Tape dubbing is only possible in tape mode.

™

Switch source to tape mode.

Recording or playback cannot be made or there is a decrease in audio level.

• Dirty tape heads, capstans or pressure rollers.

™

See section on tape deck maintenance.

• Magnetic build-up in the record/ playback head.

™

Use demagnetizing tape.

General

System does not react when any button is pressed.

• Electrostatic discharge.

™

Press STANDBY-ON to switch the system off. Remove the AC power plug from the wall outlet, then reconnect and switch on the system again.

No or poor sound.

• Volume is not turned up.

™

Adjust VOLUME.

• The system is muted.

™

Press MUTE to switch on the sound.

• The headphones are connected.

™

Disconnect the headphones.

• Speakers are not connected or are connected wrongly.

™

Check that the speakers are connected correctly.

™

Make sure that the stripped speaker wire is clamped.

Reversed left and right sound.

• Speakers are connected wrongly.

™

Check the speaker connections and location.

Lack of bass sound or apparently imprecise physical location of musical instruments.

• Speakers are connected wrongly.

™

Check the speaker connection for proper phasing, red/black wires to red/ black terminals.

Remote control has no effect on the system.

• The distance to the system is too large.

™

Reduce the distance.

• Batteries are inserted incorrectly.

™

Insert the batteries with their polarities (+/– signs) as indicated..

• Batteries are exhausted.

™

Replace the batteries.

• Wrong source is selected.

™

Select the source (CD, TUNER, etc.) before pressing the function button, (PLAY, PREV/NEXT, etc.).

Timer not working.

• Timer is not switched on.

™

Press CLOCK/TIMER to switch on the timer.

• Dubbing/recording is in progress.

™

Stop dubbing/recording.

System displays features automatically; buttons flash continuously.

• Demonstration mode is switched on.

™

Press and holdÇ for 5 seconds to switch off the demonstration.

Philips FW390C/34, FW390C/22, FW390C/19 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
