Safety & Troubleshooting

Safety and Troubleshooting Information

Safety Precautions and Maintenance • FAQs • Troubleshooting • Regulatory Information • Other Related Information

Safety precautions and maintenance

WARNING: Use of controls, adjustments or procedures other than those specified in this documentation may result in exposure to shock, electrical hazards and/or mechanical hazards.

Read and follow these instructions when connecting and using your computer monitor:

Operation:

● Keep the monitor out of direct sunlight and away from stoves or any other heat source.

● Remove any object that could fall into ventilation holes or prevent proper cooling of the

monitor’s electronics.

● Do not block the ventilation holes on the cabinet.

● When positioning the monitor, make sure the power plug and outlet are easily accessible.

● If turning off the monitor by detaching the power cable or DC power cord, wait for 6 seconds

before attaching the power cable or DC power cord for normal operation.

● Please use approved power cord provided by Philips all the time. If your power cord is

missing, please contact with your local service center. (Please refer to Customer Care Consumer Information Center)

● Do not subject the LCD monitor to severe vibration or high impact conditions during

operation.

● Do not knock or drop the monitor during operation or transportation.

Maintenance:

● To protect your display from possible damage, do not put excessive pressure on the LCD

panel. When moving your monitor, grasp the frame to lift; do not lift the monitor by placing your hand or fingers on the LCD panel.

● Unplug the monitor if you are not going to use it for an extensive period of time.

● Unplug the monitor if you need to clean it with a slightly damp cloth. The screen may be

wiped with a dry cloth when the power is off. However, never use organic solvent, such as, alcohol, or ammonia-based liquids to clean your monitor.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAFETY.HTM (1 of 2)2005-07-09 9:05:38 AM

Safety & Troubleshooting

● To avoid the risk of shock or permanent damage to the set, do not expose the monitor to

dust, rain, water, or excessive moisture environment.

● If your monitor gets wet, wipe it with dry cloth as soon as possible.

● If foreign substance or water gets in your monitor, please turn the power off immediately and

disconnect the power cord. Then, remove the foreign substance or water, and send it to the maintenance center.

● Do not store or use the LCD monitor in locations exposed to heat, direct sunlight or extreme

cold.

● In order to maintain the best performance of your monitor and use it for a longer ligetime,

please use the monitor in a location that falls within the following temperature and humidity ranges.

❍ Temperature: 5-40°C 41-104°F ❍ Humidity: 20-80% RH

Service:

● The casing cover should be opened only by qualified service personnel.

● If there is any need for any document for repair or integration, please contact with your local

service center. (please refer to the chapter of "Consumer Information Center")

● For transportation information, please refer to "Physical Specifications".

● Do not leave your monitor in a car/trunk under direct sun light.

Consult a service technician if the monitor does not operate normally, or you are not sure what procedure to take when the operating instructions given in this manual have been followed.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAFETY.HTM (2 of 2)2005-07-09 9:05:38 AM

About This Manual

About This Guide • Notational Descriptions

About This Guide

This electronic user's guide is intended for anyone who uses the Philips LCD Monitor TV. It describes the features, setup, operation and other important information.

It includes the following sections:

● Safety and Troubleshooting Information provides tips and solutions for common problems as

well as other related information you may need.

● About This Electronic User's Manual gives an overview of information included, along with

notation icon descriptions and other documentation for your reference.

● Product Information gives an overview of the monitor's features as well as the technical

specifications for this monitor.

● Installing Your Monitor describes the initial setup process and gives an overview of how to

use the monitor.

● On-Screen Display provides information on adjusting the settings on your monitor.

● Remote Control provides information on adjusting the settings for your TV function.

● Customer Care and Warranty contains a list of worldwide Philips Consumer Information

Centres along with help desk phone numbers and information on the warranty applicable to your product.

● Download and Print Option transfers this entire manual to your hard drive for easy reference.

RETURN TO TOP OF THE PAGE

Notational Descriptions

The following subsections describe notational conventions used in this document.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/ABOUT/ABOUT.HTM (1 of 2)2005-07-09 9:05:40 AM

About This Manual

Notes, Cautions and Warnings

Throughout this guide blocks of text may be accompanied by an icon and printed in bold or italic type. These blocks contain notes, cautions or warnings. They are used as follows:

NOTE: This icon indicates important information and tips that help you make better use of your computer system.

CAUTION: This icon indicates information that tells you how to avoid either potential damage to hardware or loss of data.

WARNING: This icon indicates the potential for bodily harm and tells you how to avoid the problem.

Some warnings may appear in alternate formats and may not be accompanied by an icon. In such cases, the specific presentation of the warning is mandated by the relevant regulatory authority.

RETURN TO TOP OF THE PAGE

All rights reserved. Reproduction, copying, use, modification, hiring, renting, public performance, transmission and/or broadcasting in whole or in part is prohibited without written consent of Philips Electronics N.V.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/ABOUT/ABOUT.HTM (2 of 2)2005-07-09 9:05:40 AM

Product Information

Product Features • Technical Specifications • Resolution & Preset Modes • Philips Pixel Defect Policy • Automatic Power Saving • Physical Specification • Pin Assignment • Product Views

Product Features

BDL4221V

● Less management effort for maximum productivity

❍ Multiple displays form a daisy chain to show uniform ❍ Monitor is network controllable for remote management ❍ Input connectors: CVBS, S-video, SCART, YPbPr.

● Better front of screen experience

❍ Montion adaptive deinterlacing for razor sharp images ❍ 3D comb filter separates color for a razor-sharp image ❍ WXGA, wide format 1366 x 768 resolution for sharper display ❍ Adaptive brightness intensifier technology ❍ Ready to display SDTV, EDTV, and HDTV formats

● Great convenience

❍ Zoom function to enable tiled matrix application ❍ Support hight-bandwidth digital content protection decryption ❍ Split screen for dual video/PC display ❍ Picture in picture for public display

*RF(TV input) is only available for 420WN6QS.

RETURN TO TOP OF THE PAGE

Technical Specifications*

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (1 of 9)2005-07-09 9:05:46 AM

Product Information

LCD PANEL

• Type TFT LCD

• Screen size 42"

• Pixel Pitch 0.227 x 0.681 mm

• LCD Panel type

1366 x 768 pixels R.G.B. vertical stripe Hard coating surface, anti-glare polarizer

• Effective viewing area 930.25 x 523.01 mm

• Display Colors 8 bits interface (16.7M colors)

PC SCANNING

• Vertical refresh rate 47Hz-63Hz

• Horizontal frequency 45kHz-50kHz

PC VIDEO

• Video dot rate < 85 MHz

• Input impedance

- Video

75 ohm

- Sync

2.2K ohm

• Input signal levels 0.7 Vpp

• Sync input signal

Separate sync

• Sync polarities Positive and negative

• Input Frequency

WXGA Hsync 48 kHz, Vsync 60 Hz (N.I.) SVGA Hsync 38 kHz, Vsync 60 Hz (N.I.) VGA/DVI-D Hsync 31 kHz, Vsync 60 Hz (N.I.)

• Video interface

D-sub, S-Video, TV-RF, SCART composite, components video, and DVI-D

AUDIO

• Input level for PC/SVHS/SCART 500 mV nominal

• Loudspeaker 10W Stereo Audio (200Hz~10kHz, 8 ohm, 10% THD)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (2 of 9)2005-07-09 9:05:46 AM

Product Information

OPTICAL CHARACTERISTICS

• Contrast ratio 1100:1 (with DCR on)

• Brightness

500 cd/m

(typ.)

• Peak contrast angle 6 o'clock

• White Chromaticity

x: 0.283 y: 0.297 (at 9300°K) x: 0.313 y: 0.329 (at 6500°K) x: 0.328 y: 0.344 (at 5700°K)

• Viewing Angle (C/R >5)

Upper >89° (typ.) Lower >89° (typ.) Left >89° (typ.) Right >89° (typ.)

• Response time (G to G) 8 ms(typ.) 12 ms(max.)

sRGB

sRGB is a standard for ensuring correct exchange of colors between different devices (e.g. digital cameras, monitors, printers, scanners, etc.)

Using a standard unified color space, sRGB will help represent pictures taken by an sRGB compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors are calibrated and you can rely on the correctness of the colors shown on your screen.

Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to a predefined setting as well as the color gamut. Therefore it is important to select the sRGB setting in the monitor's OSD.

To do so, at PC mode, open the OSD by pressing the MENU button of your monitor. Use the down button to go to COLOR SETTINGS and press MENU again. Then move the down button to go to NORMAL COLOR and press MENU again.

* This data is subject to change without notice.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (3 of 9)2005-07-09 9:05:46 AM

Product Information

Resolution & Preset Modes

• Recommended 1366 x 768 at 60Hz

10 factory preset modes:

Resolution Mode H. freq (kHz) V. freq (Hz)

640x350 VGA-1 31.469 70.086 640x480 VGA VESA 60 31.469 59.940 640x480 VGA VESA 75 37.500 75.000 720x400 IBM VGA 3H 31.468 70.087 800x600 SVGA VESA 56 35.156 56.250 800x600 SVGA VESA 60 37.879 60.317

800x600 SVGA VESA 75 46.875 75.000 1280x1024 XGA VESA 60 48.363 60.004 1280x1024 XGA VESA 75 60.023 75.029

1280x768 GTF 60 47.700 60.000 1280x768 Wincomm 45.113 56.260 1360x768 VESA 47.700 60.000

Video

720x480 480i 15.734 59.940

720x576 576i 15.625 50.000

720x480 480p 31.470 60.000

720x576 576p 31.250 50.000

1280x720 720p 28.200 50.000

1280x720 720p 33.750 60.000 1920x1080 1080i 37.500 50.000 1920x1080 1080i 45.000 60.000

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (4 of 9)2005-07-09 9:05:46 AM

Product Information

RETURN TO TOP OF THE PAGE

Automatic Power Saving

If you have VESA DPMS compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will then 'wake up' automatically. The following table shows the power consumption and signaling of this automatic power saving feature:

Power Management Definition

VESA Mode Video H-sync V-sync Power Used LED color

Active On Yes Yes 100 W (typ.) Blue

Sleep Off No No < 5 W Amber

Switch Off Off - - < 3 W Off

RETURN TO TOP OF THE PAGE

Physical Specifications

• Dimension (WxHxD) *

1272mm x 680mm x 300mm (incl. Pedestal, Speakers) 1052mm x 644mm x 150mm (w/o Pedestal, Speakers)

• Weight 35 kg (incl. Pedestal, Speakers)

• Power supply 100 — 240VAC, 60 — 50Hz

• Power consumption

PC Mode: 140 W (typ.) TV Mode: 220 W (typ.)

• Temperature (operating) 5° C to 35° C

• Relative humidity 20% to 80%

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (5 of 9)2005-07-09 9:05:46 AM

Product Information

• System MTBF

50K hrs (excluding CCFL 40Khrs)

* This data is subject to change without notice.

RETURN TO TOP OF THE PAGE

Pin Assignment

1. The digital only connector (DVI-D) contains 24 signal contacts organized in three rows of eight contacts. Signal pin assignments are listed in the following table:

No.

Signal Assignment

No.

Signal Assignment

Pin No.

Signal Assignment

T.M.D.S. Data2-

T.M.D.S. Data1- 17 T.M.D.S. Data0-

T.M.D.S. Data2+

T.M.D.S. Data1+ 18 T.M.D.S. Data0+

T.M.D.S. Data2/4 Shield

T.M.D.S. Data1/3 Shield

T.M.D.S. Data0/5 Shield

No connect

No connect 20 No connect

No connect

No connect 21 No connect

DDC Clock

+5V Power 22

T.M.D.S. Clock Shield

DDC Data

Hot Plug Detect 23 T.M.D.S. Clock+

No connect 16 Ground (for +5V) 24 T.M.D.S. Clock-

2. The 15-pin D-sub connector (male) of the signal cable:

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (6 of 9)2005-07-09 9:05:46 AM

Product Information

No.

Assignment

No.

Assignment

Red video input

DDC +5V

Green video input

Cable detect

Blue video input

Identical output, connected to pin 10

Ground

Serial data line (SDA)

H. Sync / H+V

Red video ground

V. Sync

Green video ground

Data clock line (SCL)

Blue video ground

3. RS232 Connector

D-sub 9-pin male connector for communication with plasma engine or PC.

Pin No.

RS-232 (EIA-232-A) Function

3 Transmit Data (TD) from DTE to DCE 2 Receive Data (RD) from DCE to DTE 7 Request to Send (RTS) 8 Clear to Send (CTS) 6 DCE Ready (DSR)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (7 of 9)2005-07-09 9:05:46 AM

Product Information

5 Signal Ground (SG) 1 Received Line Signal Detector (DCD) 4 DTE Ready (DTR) 9 Ring Indicator

4. SCART Connector

No.

Signal Pin

No.

Audio right channel output (0.5 Vrms, < 1K ohms)

Audio right channel input (0.5 Vrms, > 10K ohms)

Audio left channel output (0.5 Vrms, < 1K ohms)

4 Audio ground 4 5 Blue signal ground 5

Audio left channel input (0.5 Vrms, > 10K ohms)

7 Blue signal I/O (0.7 Vp-p, 75 ohms) 7

Function switching I/O (L: < 2V, H: > 10V, 10K ohms)

9 Green signal ground 9 10 Intercommunication data line No. 1 10 11 Green signal I/O (0.7 Vp-p, 75 ohms) 11 12 Intercommunication data line No. 2 12

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (8 of 9)2005-07-09 9:05:46 AM

Product Information

13 Red signal ground 13 14 Blanking signal ground 14 15 Red signal I/O (0.7 Vp-p, 75 ohms) 15

Blanking signal I/O (L: < 0.4V, H: >1.0V, 75 ohms)

17 Composite video signal ground 18 18 Blanking signal ground 17

Composite video signal output (1 Vp-p, 75 ohms, sync: negative)

Composite video signal input (1 Vp-p, 75 ohms, sync: negative)

21 Plug shield (common ground) 21

RETURN TO TOP OF THE PAGE

Product Views

Follow the links to see various views of the monitor and its components.

Product Description

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (9 of 9)2005-07-09 9:05:46 AM

Installing your LCD Monitor/TV

Product Description • Connecting to Your PC, TV antenna, DVD/VCR etc. • Getting Started • Optimizing Performance

Product Description

Installing your LCD Monitor/TV

Side View (Left)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/install.htm (1 of 6)2005-07-09 9:05:50 AM

Installing your LCD Monitor/TV

INPUT

Selecting input source

Increase or decrease the channel number or moving up or down to highlight the function in OSD

Increase or decrease the level of audio volume or moving left or right to highlight the sub-menu in the selected function of OSD

Open the OSD or confirm the selected function

DC power switch On/Off

RETURN TO TOP OF THE PAGE

Side View (Right)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/install.htm (2 of 6)2005-07-09 9:05:50 AM

Installing your LCD Monitor/TV

1 Audio input for composite input

Audio (left and right) in put for compo site signal in put.

2 Composite input Composite (CVBS) signal input

3 S-Video input S-Video signal input

4 Earphone output Earphone output

5 TV tuner TV tuner input (available in TV version only)

RETURN TO TOP OF THE PAGE

Rear View

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/install.htm (3 of 6)2005-07-09 9:05:50 AM

Installing your LCD Monitor/TV

AC in

AC power in

2 AC power AC power switch 3 Speakers output

External speakers output

4 D-Sub output

PC analog D-Sub input

5 DVI-D input

PC digital input

6 D-Sub input

PC analog D-Sub input

7 RS232 input

RS232 network connection Input

8 RS232 output

RS232 network connection output for the use of loop through function

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/install.htm (4 of 6)2005-07-09 9:05:50 AM

Installing your LCD Monitor/TV

9 PC audio

PC stereo audio input

10 Audio input for component signal

Audio (left and right) input for component signal input

11 Component input

Component (YP

bPr

) signal input

12 Composite output

Composite (CVBS) output for the use of loop through function

13 Audio output for composite output

Audio (left and right) out put for compo site signal out put.

14 External / EURO-AV

SCART connection (for the use of European model only)

15 Kensington lock

Kensington lock

Optimising Performance

● For best performance, ensure that your display settings are set at 1360x768, 60Hz.

Note: You can check the current display settings by pressing the 'MENU' button

once.

● You can also install the Flat Panel Adjust (FP Adjust) program, a program for getting the best performance

out of your monitor. This is included on this CD. Step-by-step instructions are provided to guide you through the installation process. Click on the link to find out more about this program.

More about FP_setup04.exe

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/install.htm (5 of 6)2005-07-09 9:05:50 AM

On Screen Display

On Screen Display Control • Using Your Remote Control

On Screen Display Controls

An overall view of the On-Screen Display (OSD) structure is shown below. You can use it as a reference for further adjusting your Monitor/TV.

There are two different modes of OSD available for different models:

● PC Mode

● TV Mode

Main menu

There is a slight difference between PC mode and TV mode: Setup selection is available in TV mode only.

Sub-menus

Picture: press to enter sub-menu selections.

PC Mode

TV Mode

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (1 of 22)2005-07-09 9:05:54 AM

On Screen Display

PC mode

Selection How to use

Smart Picture

In PC mode

● Users can press or to toggle between ❍ Normal ❍ Warm ❍ Cool

● Press to next sub-menu selection or to return to

main menu.

Brightness

Adjust image brightness.

● Press or to adjust,

● Press or to adjacent sub menu selections,

● Press to return to main menu.

Contrast

Adjust image sharpness.

● Press or to adjust,

● Press to adjacent sub-menu selections,

● Press to return to main menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (2 of 22)2005-07-09 9:05:54 AM

On Screen Display

Auto Adjust

Automatic fine tuning display geometry and time frequency parameter.

● Press to start,

● A selection of Store? Yes/No will appear.

● Press or to toggle between Yes and No.

● Press to confirm and return to sub-menu.

Manual Adjust

Adjust display geometry and time frequency parameters.

● Phase: Press or to adjust, to confirm and return to

sub-menu.

● Clock: Phase: Press or to adjust, to confirm and

return to sub-menu.

● Horizontal: Phase: Press or to adjust, to confirm

and return to sub-menu.

● Vertical: Phase: Press or to adjust, to confirm and

return to sub-menu.

TV mode

Smart Picture

In TV mode

● Users can press or to toggle between ❍ Personal ❍ Movies ❍ Sports ❍ Weak Signal ❍ Multimedia ❍ Night

● Press to next sub-menu selection, or to return to

main menu.

Brightness

Adjust image brightness. It is adjustable only when Smart Picture is in personal mode.

● Press or to adjust,

● Press or to adjacent sub-menu selections,

● Press to return to main menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (3 of 22)2005-07-09 9:05:54 AM

On Screen Display

Contrast

Adjust image sharpness. It is adjustable only when Smart Picture is in personal mode.

● Press or to adjust,

● Press or to adjacent sub-menu selections,

● Press to return to main menu.

Color

Adjust image color saturation. It is adjustable only when Smart Picture is in personal mode.

● Press or to adjust,

● Press or to adjacent sub-menu selections,

● Press to return to main menu.

Sharpness

Adjust image sharpness. It is adjustable only when Smart Picture is in personal mode.

● Press or to adjust,

● Press or to adjacent sub-menu selections,

● Press to return to main menu.

Tint

Adjust image hue level.

● Press or to adjust,

● Press or to adjacent sub-menu selections,

● Press to return to main menu.

Audio: press

to enter sub-menu selections

PC Mode

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (4 of 22)2005-07-09 9:05:54 AM

On Screen Display

TV Mode

Smart Sound

Preset audio modes.

● Users can press or to toggle between ❍ Personal ❍ News ❍ Music ❍ Theater

● Press to next sub-menu selections

● or to return to main menu.

Settings

Adjust audio setting parameters.

● Users can press or to toggle between ❍ Treble ❍ Bass ❍ Balance

● Press or to adjacent sub-menu selections

● or to return to main menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (5 of 22)2005-07-09 9:05:54 AM

On Screen Display

Virtual Surround Sound

Switch virtual surround effect on or off.

● Users can press or to toggle between ❍ On ❍ Off

● Press or to adjacent sub-menu selections, to

return to main menu.

AVL

Auto Volume Limit, adjust volume level automatically to prevent sudden peak load exceeds design limit.

● Users can press or to toggle between ❍ Yes ❍ No

● Press or to adjacent sub-menu selections, to

return to main menu.

Features: press

to enter sub-menu selections.

PC mode

PIP

Picture in Picture size choices.

● Press to enter PIP sub-menu, and press or to

selection between

❍ Size ❍ Video ❍ Audio ❍ Display

● Press to return from PIP sub-menu to sub-menu, or press

or to return to main menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (6 of 22)2005-07-09 9:05:54 AM

On Screen Display

PIP Sub-menu

Size

PIP window size adjustment.

● Users can use or to toggle between ❍ Small ❍ Medium ❍ Large ❍ PBP ❍ Off

● Press or to return to upper level sub-menu, to next

selection.

Video

Video source of the PIP window.

● Users can use or to toggle between ❍ TV ❍ AV (CVBS) ❍ S-video ❍ EXT (Scart)

● Press or to adjacent sub-menu selections, to

return to upper level sub-menu.

Audio

Audio source of the PIP window.

● Users can use or to toggle between ❍ PC ❍ PIP

● Press or to adjacent sub-menu selections, to

return to upper level sub-menu.

Display

PIP window location selection.

● Users can use or to toggle between ❍ Icon1 (upper right corner of the screen) ❍ Icon2 (lower right corner of the screen) ❍ Icon3 (lower left corner of the screen) ❍ Icon4 (upper left corner of the screen)

● Press or to adjacent sub-menu selections, to

return to upper level sub-menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (7 of 22)2005-07-09 9:05:54 AM

On Screen Display

Source

Choices of video source for main screen.

● Users can use or to toggle between ❍ PC ❍ DVI ❍ HDCP ❍ TV ❍ AV (CVBS) ❍ S-video ❍ EXT (Euro connector, Scart) ❍ HD (YPbPr)

● Press or to adjacent sub-menu selections, to

return to upper level sub-menu.

Zoom

Choices for Zoom function.

● Users can use to enter next level sub-menu and Zoom sub-

menu.

Zoom sub-menu

Zoom Type

● Users can use or to toggle between ❍ Off ❍ 4x4 ❍ 3x3 ❍ 2x2 ❍ 1x1

● Press to confirm and to return to upper level sub-menu.

Zoom ID

This selections is only available when one of zoom types is chosen. When zoom type is off, this selections is unavailable.

● Users can use or to toggle between IDs. For example,

when 4x4 is chosen, the ID selection are

A1 A2 A3 A3 B1 B2 B3 B4 C1 C2 C3 C4 D1 D2 D3 D4

● Press to confirm and to return to Zoom Type and exit to

upper level sub-menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (8 of 22)2005-07-09 9:05:54 AM

On Screen Display

TV mode

Source

Choices of video source for main screen.

● Users can use or to toggle between each signal source,

then press

to confirm your select.

❍ PC ❍ DVI ❍ HDCP ❍ TV ❍ AV (CVBS) ❍ S-Video ❍ Ext (Euro connector, Scart) ❍ HD (YP

bPr

)

● Press or to adjacent sub-menu selections to

return to upper level sub-menu.

Picture Format

Selections of image format.

● Users can use or to toggle between ❍ Automatic ❍ 4:3

❍ Zoom 16:9

❍ Wide screen

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (9 of 22)2005-07-09 9:05:54 AM

On Screen Display

❍ Super wide

● Press or to adjacent sub-menu selections to

return to upper level sub-menu.

Auto Lock

Lock up specific channels to prevent underage viewers to watch improper TV content.

● Users can use to enter next level sub-menu.

● When you select this function for the first time, a sub-menu will

appear and ask you to input access code.You can use number buttons to input a four-digit access code.Then a confirming submenu will appear and ask you to input the same access code once more to confirm.

● After the first time, each time you try to access this function, a sub-

menu will appear to request for a access code.If the code is correct, you can start the setting process of this function.

Note: Please remember that 0711 is a default access code.If

you forget the access code you set or someone else has changed your access code.You can always use 0711 to unlock.

Auto Lock sub-menu

Lock Program

Lock selected channel from underage viewers.

● Press to enter.

● Use to block the current channel, to unlock this channel.

● Use number buttons to select the channel you wish to block of

unlock.

● Then, use to confirm and return to upper level sub-menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (10 of 22)2005-07-09 9:05:54 AM

On Screen Display

Change code

Change program lock access code. Users need to set a four digits access code to enable the Auto Lock function.

● Use to enter code input mode

● Use number buttons to a new four-digit code

● Press to confirm and return to upper level sub menu.

Clear all

Clear all of the locked channels.

● Press or to toggle between ❍ On ❍ Off

● Press to confirm and clear up all locked channel settings.

Use

to adjacent upper level sub-menu selections.

Zoom

Choices for Zoom function.

● User can use to enter next level sub-menu, and Zoom sub-

menu.

Zoom sub-menu

Zoom Type

● Users can use or to toggle between ❍ Off ❍ 4x4 ❍ 3x3 ❍ 2x2 ❍ 1x5

● Press to confirm and to return to upper level sub-menu.

Zoom ID

This selection is only available when one of zoom types is chosen.When zoom type is off, this selection is unavailable.

● Users can use or to toggle between IDs.For example,

when 4x4 is chosen, the ID selections are

A1 A2 A3 A3 B1 B2 B3 B4 C1 C2 C3 C4 D1 D2 D3 D4

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (11 of 22)2005-07-09 9:05:54 AM

On Screen Display

● Press to confirm and to return to Zoom Type and exit to

upper level sub-menu.

Install: press to enter sub-menu selections.

Language

Choices of languages in user interfaces.

● Users can use or to toggle between ❍ ENGLISH ❍ ESPAÑOL

❍

❍ DEUTSCH ❍ ITALIANO

❍

● Press to adjacent sub-menu selections or to return

to main menu.

Monitor ID

Assigning a three digits monitor ID to the unit, so it can be identified when using RS232 to control from remote.

● Use to enter, and or to select 1~9 numbers, to

confirm.

DCR

Dynamic Contrast Ratio, technology to boost display contrast ratio.

● Users can use or to toggle between ❍ On ❍ Off

● Press or to adjacent sub-menu selections.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (12 of 22)2005-07-09 9:05:54 AM

On Screen Display

Light Sensor

Turns on or off the light sensor for automatic brightness control.

● Users can use or to toggle between ❍ On ❍ Off

● Press or to adjacent sub-menu selections.

Remote Control

Users need to turn off remote control function when they want to use RS232 protocol to control this unit from afar, so it will remote control commands not to conflict with RS232 commands.

● Users can use or to toggle between ❍ On ❍ Off

● Press or to adjacent sub-menu selections.

Factory Reset

To reset monitor TV's settings back to factory default.

● Users can use or to toggle between ❍ No ❍ Yes

● Press to confirm.

Setup:Setup sub-menu is available in TV modes only. Press

to enter the sub-

menu selections. TV mode (North America model)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (13 of 22)2005-07-09 9:05:54 AM

On Screen Display

Tuner Mode

Choose of tuner signal inputs.

● Users can press or to toggle between ❍ Antenna ❍ Cable ❍ Auto

● Then, press to adjacent sub-menu selections or

to return to main menu.

Auto Program

Scan all existing channels from your tuner input.

● Press to start.

● Press or to adjacent sub-menu selections, to

return to main menu.

Channel Edit

Choices to add or delete channels from available channels.

● Press to enter Channel Edit sub-menu.

● In Channel selection, use or to choose the channel that

you wish to add or delete.

● Then, press to next selection, use or to toggle

between

❍ Activate (add) ❍ Skip (delete)

● Repeat the above two steps to add or delete other channels,or,

press

to confirm and return to upper level sub-menu.

● Press or to adjacent sub-menu selections.

Manual Fine Tune

In case of weak signal situations, manually fine-tune channel signals to get the best display quality.

● Users can use or to fine tune

● Press or to adjacent sub-menu selections, to

return to main menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (14 of 22)2005-07-09 9:05:54 AM

On Screen Display

Rating

Movie or TV broadcasters add rating signal in the TV or movie broadcasted.Users can use this function to set up an automatic program rating and blocking mechanism to prevent underage viewers to watch improper movie or TV contents.

● Press to enter Rating sub-menu.

● Press or to adjacent sub-menu selections.

Rating sub-menu

Block Option

To enable or disable the TV or Movie block function.

● Users can use or to toggle between ❍ On ❍ Off

● Press or to return to upper level sub- menu , to

adjacent sub-menu selections.

Moving Rating

There are seven movie ratings.

● Users can use to enter movie rating sub-menu, and use

or to choose between

❍ G: all ages admitted ❍ PG: Parental guidance suggested ❍ PG13: Parents strongly cautioned ❍ R: Restricted ❍ NC: No children under the age of 17 will be admitted ❍ X: Adults only

(More information will be seen at the end of this section)

● In each rating selection, users can use or to toggle

between

❍ On ❍ Off

Note: If a lower level rating is blocked, then all the upper level rating will be also blocked automatically.For example, if PG is blocked, then all the rest ratings except G will be blocked.

● Then, press to return to upper level sub- menu, or

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (15 of 22)2005-07-09 9:05:54 AM

On Screen Display

to adjacent sub-menu selections.

TV Rating

There are six movie ratings.

● Users can use to enter movie rating sub-menu, and use

or to choose between

1) Y: all children

● Users can use or to toggle between ❍ On ❍ Off

2) Y7: Directed to older children

● Users can use or to toggle between ❍ Block ❍ FV: fantasy violence or comic violence

3) G: General audience

● Users can use or to toggle between ❍ On ❍ Off

4) PG: Parental guidance suggested

● Users can use or to toggle between ❍ Block ❍ V: violence ❍ S: sexual situation ❍ L: strong language ❍ D: suggestive dialogue

to block all programs in this rating or part of the programs with specific contents.

5) 14: Parents strongly cautioned.

● Users can use or to toggle between ❍ Block ❍ V: violence

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (16 of 22)2005-07-09 9:05:54 AM

On Screen Display

❍ S: sexual situation ❍ L: strong language ❍ D: suggestive dialogue

to block all programs in this rating or part of the programs with specific contents.

6) MA: Matured audience only.

● Users can use or to toggle between ❍ Block ❍ V: violence ❍ S: sexual situation ❍ L: strong language ❍ D: suggestive dialogue

to block all programs in this rating or part of the programs with specific contents.

(More information will be seen at the end of this section)

Note: If a lower level rating is blocked, then all the upper level rating will be also blocked automatically. For example, if Y7 is blocked, then all the rest ratings except Y will be blocked.

● Then, press to return to upper level sub- menu, or

to adjacent sub-menu selections.

Closed Caption

Closed caption are captions that are hidden in the video signal, invisible without a special decoder. It allows hearing impaired TV viewers to read ongoing program dialogues or audio effects.

● Users can use to enter Closed Caption sub-menu. Then use

or to choose between

❍ Caption Mode ❍ CC Display

● Press to return to main menu.

Closed Caption sub-menu

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (17 of 22)2005-07-09 9:05:54 AM

On Screen Display

Caption Mode

There are nine caption modes to be selected.

● Users can use or to toggle between ❍ CC1 ❍ CC2 ❍ CC3 ❍ CC4 ❍ TXT1 ❍ TXT2 ❍ TXT3 ❍ TXT4 ❍ CC Mute

● Then, press to confirm and return to upper level sub-menu.

Note: The difference between CC and TXT mode is, CC shows a few lines of dialogues only while TXT (text) use half or entire page to display scrolling text information. CC1 ~CC4 are usually showing same contents in different languages. Text mode likewise.

CC Display

Users can use CC display to turn on/off closed caption which was set earlier.

● Users can use or to toggle between ❍ On ❍ Off

● Then, press to confirm and return to upper level sub-menu.

About Movie Ratings The movie rating system is set up by Motion Picture Association of America.The main reason is to prevent underage viewers to watch improper movie contents.There are six rating levels, namely G, PG, PG-13, R, NC-17, and X.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (18 of 22)2005-07-09 9:05:54 AM

On Screen Display

TV mode (Europe, Asia Pacific models)

Auto Program

Scan all existing channels from your tuner input.

● Press to start.

● Press or to adjacent sub-menu selections, to return

to main menu.

Manual Store

Select a frequency with specific channel.

● Use to enter Manual Store sub-menu, and or to

select between selections.

● Then, to confirm.

Channel Setting

Choose channel setting to channel edit, channel swap, neme edit, and channel sort.

● Use to enter Channel Setting sub-menu, and or to

select between selections.

● Then, to confirm.

System

Select different programs in TV mode.

● Use to enter System sub-menu, and or to select

between selections.

● Then, to confirm.

Manual Store sub-menu

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (19 of 22)2005-07-09 9:05:54 AM

On Screen Display

System

● Users can use or to toggle between ❍ France: scans pan Europe and French TV systems ❍ Western Europe: scans pan Europe TV systems only.

● Press or to adjacent sub-menu selections, to

confirm and return to upper level sub-menu.

Manual Store

Select a frequency with specific channel.

● Use to enter, and use or to adjust frequency.

● Then, press or to adjacent sub-menu selections, to

confirm.

Program Number

Give a channel number to the frequency chose in the above function.

● Use to enter, and use or to select a number.

● Press or to adjacent sub-menu selections, to

confirm.

Fine Tune

Fine tune the channel frequency to get a better display quality.

● Use to enter, and use or to adjust frequency.

● Then, press or to adjacent sub-menu

selections,

to confirm.

Store

● Use to enter storing process.

● A selection of Store? Yes/No will appear.

● Press or to toggle between ❍ Yes ❍ No

● Press to confirm and return to sub-menu.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (20 of 22)2005-07-09 9:05:54 AM

On Screen Display

Channel Edit

Choices to add or delete channels from available channels.

● Press enter Channel Edit sub-menu

● In Channel selection, use or to choose the channel that

you wish to add or delete.

● Then, press to next selection, use or to toggle

between

❍ Activate (add) ❍ Skip (delete)

● Repeat the above two steps to add or delete other channels, or,

● Press to confirm and return to upper level sub-menu

● Press or to adjacent sub-menu selections.

Channel Swap

To swap channel numbers between two channels.So users can put preferred channels at front.

● Users can use to enter Manual Store sub-menu,

● or to select between selections.

● Then, to confirm.

Channel Swap sub-menu

From

Choose a channel number to be swapped from.

● Use or to select channel.

● to confirm and return to upper level sub-menu.

Choose a target channel number to be swapped to.

● Use or to select channel.

● to confirm and return to upper level sub-menu.

Exchange

Execute channel swap.

● Users can use to execute the swapping move.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (21 of 22)2005-07-09 9:05:54 AM

On Screen Display

Name Edit

Modify the channel name from a broadcaster give one to a user preferred one.

● Users can use to enter

● Use or to select channel.

● Press to name input line.

● Use or to select from A to Z, or to adjacent

alphabet.

● Press to confirm and return to upper level sub-menu.

Channel Sort

Sort channel name sequence in alphabetical order, from A to Z. Those channels without a name will be placed at the end of the sequence according to their frequencies, from small to large.

● Users can use to enter.

● Press to start sorting.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/osddesc.htm (22 of 22)2005-07-09 9:05:54 AM

Remote Control

On Screen Display • Using Your Remote Control

Using Your Remote Control

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/tv_control.htm (1 of 5)2005-07-09 9:05:59 AM

Remote Control

AV source:

● To select TV/video source in TV and also PIP window.

● If TV is in Standby mode, press this button to switch to ON.

Mode:

Screen aspect ratio, switching between 4:3, 16: 9, wide screen, and super wide.

Numerical keys:

● For direct access to programs.

● If TV is in Standby mode, press any number will switch the TV to ON

mode.

Previous program:

Jump to previous TV channel you are viewing.

Menu:

To turn on or off the On-screen-display (OSD) menu

● Move the cursor up in OS

● Channel up

● Move the cursor left in OSD

● Adjust volume down

Switching between PC and TV mode.

Closed Caption:

Functions in North America and Asia Pacific models only.

● Move the cursor down in OSD

● Channel down

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/tv_control.htm (2 of 5)2005-07-09 9:05:59 AM

Remote Control

● Move the cursor right in OSD

● Adjust volume up

Confirm the chosen OSD function

Freeze:

Freeze the screen in video mode or PIP.

Status:

Display channel number, video/PC mode, and sound mode information.

Sound select:

● To switch between mono and stereo, or to choose between Dual I

and Dual II for bilingual transmissions.

● For TV sets fitted with NICAM, depends on transmission, you can

switch between NICAM stereo and Mono, or between NICAM Dual I, NICAM Dual II, and Mono.

PIP Size:

Adjusts Picture-in-Picture (PIP) window size between small, medium, large, picture-by-picture (PBP or split screen), and off.

PIP position:

Changing PIP window’s location on the screen between upper right, lower right, lower left, and upper left.

Mute:

Disables audio: To enable audio, press the button again.

Sleep Timer:

Selects a period of time and the unit will switch off automatically.

Standby:

Sets the TV to standby mode temporary.

Smart Sound:

Chooses audio effects between Music, Theater, News, and Personal.

Smart Picture:

Choose picture settings between Sports, Movie, Weak signal, Night, Multimedia, and Personal.

The following buttons are using in Teletext mode only, which are available in Europe and some of the Asia Pacific TV systems.

Teletext Enlarge:

Enlarge teletext context to two times larger.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/tv_control.htm (3 of 5)2005-07-09 9:05:59 AM

Remote Control

Teletext Mix:

Teletext background become transparent, content mixes with images.

Teletext On/Off:

Teletext ON or OFF.

Teletext Hold:

Freezes the teletext page.

Main Index:

Press the button to return to the main index.

Teletext Reveal/Conceal:

To view the concealed text information (e.g. question/answer, quiz, etc.) send by the teletext provider. Press the button can toggle between conceal and reveal mode.

These four color buttons allow you to access the item or the page indicated by corresponding color in teletext.

Warning:

If you are going to control the monitor TV via RS232 interface, to avoid conflict, you need to disable the remote control first. You can enter the OSD menu, select Install, remote control to achieve so. After remote control is disabled, you can use buttons on the unit to enter OSD and enable it, or enable remote control via RS232 command.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/OSD/tv_control.htm (4 of 5)2005-07-09 9:05:59 AM

Customer Care and Warranty

Customer Care & Warranty

PLEASE SELECT YOUR COUNTRY/AREA TO REVIEW DETAILS OF YOUR WARRANTY COVERAGE

WESTERN EUROPE: Austria • Belgium • Cyprus • Denmark • France • Germany • Greece •

Finland • Ireland • Italy • Luxembourg • the Netherlands • Norway • Portugal • Sweden • Switzerland • Spain • United Kingdom

EASTERN EUROPE: Czech Republic • Hungary • Poland • Russia • Slovakia • Slovenia •

Turkey

LATIN AMERICA: Antilles • Argentina • Brasil • Chile • Colombia • Mexico • Paraguay •

Peru • Uruguay • Venezuela

NORTH AMERICA: Canada • USA

PACIFIC: Australia • New Zealand

ASIA: Bangladesh • China • Hong Kong • India • Indonesia • Japan • Korea • Malaysia •

Pakistan • Philippines • Singapore • Taiwan • Thailand

AFRICA: Morocco • South Africa

MIDDLE EAST: Dubai • Egypt

file:///D|/My%20Documents/dfu/420WN6/english/warranty/warranty.htm2005-07-09 9:06:01 AM

Download and Print

Installing your LCD monitor driver • Download and Printing Instructions • Installing FPadjust Program

Installing Your LCD monitor driver

System requirements:

●

PC running Windows® 95, Windows® 98, Windows® 2000 , Windows® Me, Windows® XP or later

● Find your driver ".inf/.icm/.cat" at : /PC/drivers/

Read the "Readme.txt" file before installing.

This page provides an option to read the manual in .pdf format. PDF files can be downloaded into your hard disk, then viewed and printed with Acrobat Reader or through your browser.

If you do not have Adobe¨ Acrobat Reader installed, click on the link to install the application.

Adobe® Acrobat Reader for PC / Adobe® Acrobat Reader for Mac.

Download instructions:

To download the file:

1. Click-and-hold your mouse over the icon below. (Win95/98/2000/Me/XP users right-click)

Download

BDL4221V.pdf

2. From the menu that appears, choose 'Save Link As...', 'Save Target As...' or 'Download Link to Disk'.

file:///D|/My%20Documents/dfu/420WN6/english/download/download.htm (1 of 3)2005-07-09 9:06:04 AM

Download and Print

3. Choose where you would like to save the file; click 'Save' (if prompted to save as either 'text' or 'source', choose 'source').

Printing instructions:

To print the manual:

1. With the manual file open, follow your printer's instructions and print the pages you need.

RETURN TO TOP OF THE PAGE

Installing FPadjust Program

The FP Adjust program generates alignment patterns which will help you adjust monitor settings such as CONTRAST, BRIGHTNESS, HORIZONTAL & VERTICAL POSITION, PHASE and CLOCK.

System requirements:

●

PC running Windows® 95, Windows® 98, Windows® 2000, Windows® Me, Windows® XP or later

To install FPadjust Program:

●

Click on the link or icon to install FPadjustment Program.

●

Click-and-hold your mouse over the icon. (Win95/98/2000/Me/XP users right-click)

file:///D|/My%20Documents/dfu/420WN6/english/download/download.htm (2 of 3)2005-07-09 9:06:04 AM

Download and Print

Download

FP_setup04.exe

●

From the menu that appears, choose 'Save Link As...', 'Save Target As...' or 'Download Link to Disk'.

● Choose where you would like to save the file; click 'Save' (if prompted to save as either 'text'

or 'source', choose 'source').

● Exit your browser and install the FPadjust Program.

Read the "FP_Readme04.txt" file before installing.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/download/download.htm (3 of 3)2005-07-09 9:06:04 AM

FAQs (Frequently Asked Questions)

Safety and Troubleshooting • General FAQs • Screen Adjustments • Compatibility with Other Peripherals • LCD Panel Technology • Ergonomics, Ecology and Safety Standards • Troubleshooting • Regulatory Information • Other Related Information

General FAQs

When I install my monitor what should I do if the screen shows 'Cannot display this video

mode'?

A: Recommended video mode for Philips 42": 1360x768 @60Hz.

1. Unplug all cables, then connect your PC to the monitor that you used

previously.

2. In the Windows Start Menu, select Settings/Control Panel. In the Control Panel

Window, select the Display icon. Inside the Display Control Panel, select the 'Settings' tab. Under the setting tab, in box labeled 'desktop area', move the slidebar to 1360x768 pixels (42").

3. Open 'Advanced Properties' and set the Refresh Rate to 60Hz, then click OK.

4. Restart your computer and repeat step 2 and 3 to verify that your PC is set at

1360x768@60Hz (42").

5. Shut down your computer, disconnect your old monitor and reconnect your

Philips LCD monitor.

6. Turn on your monitor and then turn on your PC.

Q: What should I do when screen shows: THIS IS 85HZ OVERSCAN, CHANGE COMPUTER

DISPLAY INPUT TO 1360 x 768 @60HZ?

A: It means the signal input from your PC is 85Hz -- outside the range that the

monitor can display. New Generation LCD intelligent monitor capabilities temporarily override the overscan, providing you with 10 minutes to reset timing to recommended settings.

Here's how:

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (1 of 9)2005-07-09 9:06:10 AM

FAQs (Frequently Asked Questions)

Go to your Windows Start menu. Select Settings, then Control Panel. Select Display. Move to Settings and click on the Advanced button. Under Adaptor, change the refresh rate to 56~75.

You have 10 minutes to complete the operation; if you do not complete within 10 minutes, power off and re-power on monitor to enter changes.

Q: What does 'refresh rate' mean in connection with an LCD monitor?

A: The refresh rate is of much less relevance for LCD monitors. LCD monitors display

a stable, flicker-free image at 60Hz. There is no visible difference between 85Hz and 60Hz.

Q: What are the .inf and .icm files on the CD-ROM? How do I install the drivers (.inf and .

icm)?

A: These are the driver files for your monitor. Follow the instructions in your user

manual to install the drivers. Your computer may ask you for monitor drivers (.inf and . icm files) or a driver disk when you first install your monitor. Follow the instructions to insert the ( companion CD-ROM) included in this package. Monitor drivers (.inf and . icm files) will be installed automatically.

Q: How do I adjust the resolution?

A: Your video card/graphic driver and monitor together determine the available

resolutions. You can select the desired resolution under Windows® Control Panel with the "Display properties"

Q: What if I get lost when I am making monitor adjustments?

A: Simply press the OK button, then select 'Reset' to recall all of the original factory

settings.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (2 of 9)2005-07-09 9:06:10 AM

FAQs (Frequently Asked Questions)

Q: What is the Auto function?

A: The AUTO adjustment key restores the optimal screen position, phase and clock

settings at the press of a single button – without the need to navigate through OSD menus and control keys.

Note: Auto function is available in selected models only.

Q: My Monitor has no power (Power LED does not light up). What should I do?

A: Make sure the AC power cord is connected to the Monitor.

Q: Will the LCD monitor accept an interlaced signal under PC models?

A: No. If an Interlace signal is used, the screen displays both odd and even horizontal

scanning lines at the same time, thus distorting the picture.

Q: What does the Refresh Rate mean for LCD?

A: Unlike CRT display technology, in which the speed of the electron beam is swept

from the top to the bottom of the screen determines flicker, an active matrix display uses an active element (TFT) to control each individual pixel and the refresh rate is therefore not really applicable to LCD technology.

Q: Will the LCD screen be resistant to scratches?

A: A protective coating is applied to the surface of the LCD, which is durable to a

certain extent (approximately up to the hardness of a 2H pencil). In general, it is recommended that the panel surface is not subject to any excessive shocks or scratches. An optional protective cover with greater scratch resistance is also available.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (3 of 9)2005-07-09 9:06:10 AM

FAQs (Frequently Asked Questions)

Q: How should I clean the LCD surface?

A: For normal cleaning, use a clean, soft cloth. For extensive cleaning, please use

isopropyl alcohol. Do not use other solvents such as ethyl alcohol, ethanol, acetone, hexane, etc.

Q: Can the Philips LCD Monitor be mounted on the wall or used as a touch panel?

A: Yes. Philips LCD monitors have this optional feature. The standard VESA mount

holes on the back cover allows the user to mount the Philips monitor on any VESA standard ARM or accessories. Touch panels are being developed for future applications. Check with your Philips sales representative for more information.

RETURN TO TOP OF THE PAGE

Screen Adjustments

What is the FPadjust program on the CD-ROM?

A: The FPadjust program generates alignment patterns that help you adjust monitor

settings such as Contrast, Brightness, Horizontal Position, Vertical Position, Phase and Clock for optimal performance.

Q: When I install my monitor, how do I get the best performance from the monitor?

For best performance, make sure your display settings are set at 1360x768@60Hz for 42". Note: You can check the current display settings by pressing the OSD OK button once. The current display mode is shown in product information in OSD main controls.

2. To install the Flat Panel Adjust (FPadjust) program located on the monitor

setup CD-ROM, open the CD-ROM and double-click the FP_setup04.exe icon. This will install FP Adjust automatically and place a shortcut on your desktop.

3. Run FPadjust by double clicking the shortcut. Follow the instructions step by

step to optimize image performance with your system's video controller.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (4 of 9)2005-07-09 9:06:10 AM

FAQs (Frequently Asked Questions)

Q: How do LCDs compare to CRTs in terms of radiation?

A: Because LCDs do not use an electron gun, they do not generate the same amount

of radiation at the screen surface.

RETURN TO TOP OF THE PAGE

Compatibility with other Peripherals

Can I connect my LCD monitor to any PC, workstation or Mac?

A: Yes. All Philips LCD monitors are fully compatible with standard PCs, Macs and

workstations. You may need a cable adapter to connect the monitor to your Mac system. Please contact your dealer/retailer for more information.

Q: Are Philips LCD monitors Plug-and-Play?

A: Yes, the monitors are Plug-and-Play compatible with Windows® 95, 98, 2000 and

XP.

Q: What is USB (Universal Serial Bus)?

A: Think of USB as a smart plug for PC peripherals. USB automatically determines

resources (like driver software and bus bandwidth) required by peripherals. USB makes necessary resources available without user intervention. There are three main benefits of USB. USB eliminates "case anxiety," the fear of removing the computer case to install circuit board cards -- that often requires adjustment of complicated IRQ settings -- for add-on peripherals. USB does away with "port gridlock." Without USB, PCs are normally limited to one printer, two Com port devices (usually a mouse and modem), one Enhanced Parallel Port add-on (scanner or video camera, for example), and a joystick. More and more peripherals for multimedia computers come on the market every day. With USB, up to 127 devices can run simultaneously on one computer. USB permits "hot plug-in." No need to shut down, plug in, reboot and run

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (5 of 9)2005-07-09 9:06:10 AM

FAQs (Frequently Asked Questions)

set up to install peripherals. No need to go through the reverse process to unplug a device. Bottom line: USB transforms today's "Plug-and-Pray" into true Plug-and-Play!

Please refer to glossary for more information about USB.

Q: What is a USB hub ?

A: A USB hub provides additional connections to the Universal Serial Bus. A hub's

upstream port connects a hub to the host, usually a PC. Multiple downstream ports in a hub allows connection to another hub or device, such as a USB keyboard, camera or printer.

RETURN TO TOP OF THE PAGE

LCD Panel Technology

What is a Liquid Crystal Display?

A: A Liquid Crystal Display (LCD) is an optical device that is commonly used to

display ASCII characters and images on digital items such as watches, calculators, portable game consoles, etc. LCD is the technology used for displays in notebooks and other small computers. Like light-emitting diode and gas-plasma technologies, LCD allows displays to be much thinner than cathode ray tube (CRT) technology. LCD consumes much less power than LED and gas-displays because it works on the principle of blocking light rather than emitting it.

Q: How are LCDs made?

A: LCDs are created from two glass plates separated from each other at a distance

of a few microns. The plates are filled with liquid crystal and then sealed together. The top plate is colored with an RGB pattern to make the color filter. Polarizers are then glued to both plates. This combination is sometimes called 'glass' or 'cell.' The LCD cell is assembled into a 'module' by adding the backlight, driver electronics and frame.

Q: What is polarization ?

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (6 of 9)2005-07-09 9:06:10 AM

FAQs (Frequently Asked Questions)

A: Polarization is basically directing light to shine in one direction. Light is

electromagnetic waves. Electric and magnetic fields oscillate in a direction perpendicular to the propagation of the light beam. The direction of these fields is called the 'polarization direction'. Normal or non-polarized light has fields in several directions; polarized light has a field in only one direction.

Q: What differentiates passive matrix LCDs from active matrix LCDs?

A: An LCD is made with either a passive matrix or an active matrix display grid. An

active matrix has a transistor located at each pixel intersection, requiring less current to control the luminance of a pixel. For this reason, the current in an active matrix display can be switched on and off more frequently, improving the screen refresh time (your mouse pointer will appear to move more smoothly across the screen, for example). The passive matrix LCD has a grid of conductors with pixels located at each intersection in the grid.

Q: How does a TFT LCD Panel work?

A: On each column and row of the TFT LCD panel, a data source drive and a gate

drive are attached, respectively. The TFT drain of each cell is connected to the electrode. The molecular arrangement of liquid crystal elements differ according to whether it is impressed with voltage or not. It varies the direction of polarized light and the amount of light by letting it through different arrays of liquid crystal elements. When two polarized filters are arranged vertically on a polarized light pole, the light that passes through the upper polarized panel is turned 90 degrees along with the spiral structure of the liquid crystal molecules and goes through the polarized filter at the bottom. When impressed with voltage, liquid crystal molecules are arranged vertically from the original spiral structure and the direction of the light is not turned through 90 degrees. In this case, light that comes through the top polarized panel may not go through the polarized panel at the bottom.

Q: What are the advantages of TFT LCD compared with CRT?

A: In a CRT monitor, a gun shoots electrons and general light by colliding polarized

electrons on fluorescent glass. Therefore, CRT monitors basically operate with an analog RGB signal. A TFT LCD monitor is a device that displays an input image by operating a liquid crystal panel. The TFT has a fundamentally different structure than a CRT: Each cell has an active matrix structure and independent active elements. A TFT LCD has two glass panels and the space between them is filled with liquid

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (7 of 9)2005-07-09 9:06:10 AM

FAQs (Frequently Asked Questions)

crystal. When each cell is connected with electrodes and impressed with voltage, the molecular structure of the liquid crystal is altered and controls the amount of inlet lighting to display images. A TFT LCD has several advantages over a CRT, since it can be very thin and no flickering occurs because it does not use the scanning method.

Q: Why is vertical frequency of 60Hz optimal for an LCD monitor?

A: Unlike a CDT monitor, the TFT LCD panel has a fixed resolution. For example, an

XGA monitor has 1024x3 (R, G, B) x 768 pixels and a higher resolution may not be available without additional software processing. The panel is designed to optimize the display for a 65MHz dot clock, one of the standards for XGA displays. Since the vertical/horizontal frequency for this dot clock is 60Hz/48kHz, the optimum frequency for this monitor is 60Hz.

Q: What kind of wide-angle technology is available? How does it work?

A: The TFT LCD panel is an element that controls/displays the inlet of a backlight

using the dual-refraction of a liquid crystal. Using the property that the projection of inlet light refracts toward the major axis of the liquid element, it controls the direction of inlet light and displays it. Since the refraction ratio of inlet light on liquid crystal varies with the inlet angle of the light, the viewing angle of a TFT is much narrower than that of a CDT. Usually, the viewing angle refers to the point where the contrast ration is 10. Many ways to widen the viewing angle are currently being developed and the most common approach is to use a wide viewing angle film, which widens the viewing angle by varying the refraction ratio. IPS (In Plane Switching) or MVA (Multi Vertical Aligned) is also used to give a wider viewing angle.

Q: Why is there no flicker on an LCD Monitor?

A: Technically speaking, LCDs do flicker, but the cause of the phenomenon is

different from that of a CRT monitor -- and it has no impact of the ease of viewing. Flickering in an LCD monitor relates to usually undetectable luminance caused by the difference between positive and negative voltage. On the other hand, CRT flickering that can irritate the human eye occurs when the on/off action of the fluorescent object becomes visible. Since the reaction speed of liquid crystal in an LCD panel is much slower, this troublesome form of flickering is not present in an LCD display.

Q: Why is an LCD monitor virtually free of Electro Magnetic Interference?

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (8 of 9)2005-07-09 9:06:10 AM

FAQs (Frequently Asked Questions)

A: Unlike a CRT, an LCD monitor does not have key parts that generate Electro

Magnetic Interference, especially magnetic fields. Also, since an LCD display utilizes relatively low power, its power supply is extremely quiet.

RETURN TO TOP OF THE PAGE

Ergonomics, Ecology and Safety Standards

What is the CE mark?

A: The CE (Conformité Européenne) mark is required to be displayed on all regulated

products offered for sale on the European market. This 'CE' mark means that a product complies with the relevant European Directive. A European Directive is a European 'Law' that relates to health, safety, environment and consumer protection, much the same as the U.S. National Electrical Code and UL Standards.

Q: Does the LCD monitor conform to general safety standards?

A: Yes. Philips LCD monitors conform to the guidelines of MPR-II and TCO 99/03

standards for the control of radiation, electromagnetic waves, energy reduction, electrical safety in the work environment and recyclability. The specification page provides detailed data on safety standards.

More information is provided in the Regulatory Information section.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAF_FAQ.HTM (9 of 9)2005-07-09 9:06:10 AM

Troubleshooting

Safety and Troubleshooting • FAQs • Common Problems • TV and Audio Problems • Video Problems • Remote Control Problems • Product Specific Problems • OSD Warning Message

• Regulatory Information • Other Related Information

This page deals with problems that can be corrected by the user. If the problem still persists after you have tried these solutions, contact your nearest Philips dealer.

Common Problems

Symptoms

Having this problem?

Check these items

No Video/ Power LED off

No picture, the LCD Monitor TV is not working

● Check connection integrity at both ends of the

video cable and/or power cord.

● Electric outlet verification

● Ensure AC power at the rear of the monitor

TV is switched on.

No Video/ Power LED on

No picture or no brightness

● Increase brightness and contrast controls.

● Perform the LCD Monitor TV self-test feature

check.

● Check for bent or broken pins in video cable

connector.

Poor Focus Picture is fuzzy,

blurry or ghosting

● Auto adjust image through Menu -> Image

Setting -> Auto Adjust.

● Adjust Phase and Clock controls via OSD.

● Eliminate video extension cables.

● Perform the LCD Monitor TV factory reset (via

Menu -> Factory Reset -> All Settings).

● Lower video resolution or increase font size.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/saf_troub.htm (1 of 7)2005-07-09 9:06:11 AM

Troubleshooting

Shaky/Jittery Video Wavy picture or

fine movement

● Auto adjust image through Menu -> Image

Setting -> Auto Adjust

● Adjust Phase and Clock controls via OSD

● Perform the LCD Monitor TV factory reset (via

Menu -> Factory Reset -> All Settings)

● Check environmental factors

● Relocate and test in other room

Missing Pixels LCD screen has

spots

● Cycle power on-off

● These are pixels that are permanently off and

is a natural defect that occurs in LCD technology

Stuck-on Pixels LCD screen has

bright spots

● Cycle power on-off

● These are pixels that are permanently on and

is a natural defect that occurs in LCD technology

Brightness Problems Picture too dim or

too bright

● Perform the LCD Monitor TV factory reset (via

Menu -> Factory Reset -> All Settings)

● Auto adjust image through Menu -> Image

Setting -> Auto Adjust

● Adjust brightness & contrast controls

Note: When operating in DVI mode, the contrast adjustment is not available.

Geometric Distortion Screen not

centered correctly

● Perform the LCD Monitor TV reset on

"Position Settings Only"

● Auto adjust image through Menu -> Image

Setting -> Auto Adjust

● Adjust the centering controls

● Ensure the LCD Monitor TV is in proper video

mode

Note: When operating in DVI mode, the positioning adjustments are not available.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/saf_troub.htm (2 of 7)2005-07-09 9:06:11 AM

Troubleshooting

Horizontal/Vertical Lines

Screen has one or more lines

● Perform the LCD Monitor TV reset

● Auto adjust image through Menu -> Image

Setting -> Auto Adjust

● Adjust Phase and Clock controls via OSD

● Perform the LCD Monitor TV self-test feature

check and determine if these lines are also in self-test mode

● Check for bent or broken pins in the video

cable connector

Note: When operating in DVI mode, the Pixel Clock and Phase adjustments are not available.

Sync Problems Screen is

scrambled or appears torn

● Perform the LCD Monitor TV reset

● Push Auto Adjust button

● Adjust Phase and Clock controls via OSD

● Perform the LCD Monitor TV self-test feature

check to determine if scrambled screen appears in self-test mode

● Check for bent or broken pins

● Boot up in the "safe mode"

LCD Scratched Screen has

scratches or smudges

● Turn the LCD Monitor TV off and clean the

screen

Safety Related Issues

Visible signs of smoke or sparks

● Do not perform any troubleshooting steps

● The LCD Monitor TV needs to be replaced

Intermittent Problems The LCD Monitor

TV malfunctions on & off

● Ensure the LCD Monitor TV is in proper video

mode

● Ensure video cable connection between

computer and the LCD monitor TV is secured

● Perform the LCD Monitor TV factory reset (via

Menu -> Factory Reset -> All Settings)

● Perform the LCD Monitor TV self-test feature

check to determine if the intermittent problem occurs in self-test mode

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/saf_troub.htm (3 of 7)2005-07-09 9:06:11 AM

Troubleshooting

TV and Audio Problems

Poor TV signal reception

Abnormal picture seen from the screen

● The proximity of mountains or high buildings

may be responsible for ghost pictures, echoing or shadows. In this case, try manually adjusting your pictures: see 'fine tuning' or adjust the direction of the outside aerial. For Asia users in non-NTSC area: Does your antenna enable you to receive broadcasts in this frequency range (UHF or VHF band)? In the event of difficult reception (snowy pictures) switch the NR on the PICTURE menu to ON.

No TV picture

No picture when TV input was selected

● Have you connected the aerial socket

properly? Have you chosen the right system? Poorly connected SCART cables or aerial sockets are often the cause of picture or sound problems (sometimes the connectors can become half disconnected if the LCD Monitor TV set is moved or turned). Check all connections.

No sound

No sound output when a program with sound was playing

● Ensure that the audio cables are firmly

connected to both the audio input connectors on your the LCD Monitor TV and audio output connectors on your PC or Video player.

● If on certain TV channels you receive a

picture but no sound, this means that you do not have the correct TV system. Modify the SYSTEM setting.

Video Problems

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/saf_troub.htm (4 of 7)2005-07-09 9:06:11 AM

Troubleshooting

No Video

No signal indicator is displayed.

● Check Video Input Selection ❍ Composite: Yellow colored RCA jack ❍ S-Video: Typically a round 4 pin jack ❍ Component: Typically 3 RCA jacks of

Green, Red and Blue.

● Make sure you did not plug the video cable to

video output port behind the LCD monitor TV.

Low Quality DVD playback

Picture not crisp and some color distortion

● Check DVD connection ❍ Composite gives good picture ❍ S-Video gives better picture ❍ Component gives best picture

No sound

See video but no audio

● Check if the LCD Monitor TV volume is turn

off of muted.

● Connect the audio cable securely.

● Audio cable is connected incorrectly.

● Verify that the audio source is selected

correctly in the OSD.

Remote Control Problems

Remote control does not work properly

No response from the LCD Monitor TV when remote is pressed

● Point the remote control directly at the remote

sensor on the LCD Monitor TV.

● Replace both batteries with new ones.

● Make sure the remote control is not disabled

(for disable/enable the remote control, please refer to the section of Remote Control).

Product Specific Problems

Screen image is too small

Image is centered on screen, but does not fill entire viewing area

● Perform the LCD Monitor TV factory reset (via

Menu -> Factory Reset -> All Settings).

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/saf_troub.htm (5 of 7)2005-07-09 9:06:11 AM

Troubleshooting

Cannot adjust the LCD Monitor TV with the buttons at the side of the unit

OSD does not appear on the screen

● Turn the LCD Monitor TV off and unplug the

power cord and then plug back and power on.

For further assistance, refer to the Consumer Information Centers list and contact your local Philips distributor.

RETURN TO TOP OF THE PAGE

OSD Warning Messages

A warning message may appear on the screen indicating the LCD Monitor TV current status.

When user sees this warning message, it means that the LCD Monitor TV is in adjustment process.

A warning message may appear on the screen indicating that the LCD Monitor TV is out of sync range.

See Specifications for the Horizontal and Vertical frequency ranges addressable by this the LCD Monitor TV. Recommended mode is 1360 x 768 @ 60Hz.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/saf_troub.htm (6 of 7)2005-07-09 9:06:11 AM

Troubleshooting

This message means that there is no video input signal.

The LCD Monitor TV is in a power saving mode (in PC mode).

The main OSD menu is unlocked.

The main OSD menu is locked.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/saf_troub.htm (7 of 7)2005-07-09 9:06:11 AM

Regulatory Information

CE Declaration of Conformity • Display Power Management Signaling • Federal Communications Commission (FCC) Notice (U.S. Only) • Commission Federale de la Communication (FCC Declaration) • EN 55022 Compliance (Czech Republic Only) • VCCI Class 2 Notice (Japan Only) • MIC Notice (South Korea Only) • Polish Center for Testing and Certification Notice • North Europe (Nordic Countries) Information • BSMI Notice (Taiwan Only) • Ergonomie Hinweis (nur Deutschland)

• Philips End-of-Life Disposal • Information for UK only • Waste Electrical and Electronic Equipment-

WEEE

Safety and Troubleshooting • Troubleshooting • Other Related Information • Frequently Asked Questions (FAQs)

CE Declaration of Conformity

Philips Consumer Electronics declare under our responsibility that the product is in conformity with the following standards

- EN60950-1:2001 (Safety requirement of Information Technology Equipment)

- EN55022:1998 (Radio Disturbance requirement of Information Technology Equipment)

- EN55024:1998 (Immunity requirement of Information Technology Equipment)

- EN61000-3-2:2000 (Limits for Harmonic Current Emission)

- EN61000-3-3:1995 (Limitation of Voltage Fluctuation and Flicker)

- EN55013:1990+A12+A13+A14 (Radio Disturbance requirement of Sound and Television Receivers and associated)

- EN55020:1994+A12 (Immunity requirement of Sound and Television Receivers and associated)

- IEC Guide 112:2000 ( Guide on the Safety of Multimedia Equipment) following provisions of directives applicable

- 73/23/EEC (Low Voltage Directive)

- 89/336/EEC (EMC Directive)

- 93/68/EEC (Amendment of EMC and Low Voltage Directive) and is produced by a manufacturing organization on ISO9000 level.

The product also comply with the following standards

- ISO9241-3, ISO9241-7, ISO9241-8 (Ergonomic requirement for Visual Display)

- ISO13406-2 (Ergonomic requirement for Flat panels)

- GS EK1-2000 (GS specification)

- prEN50279:1998 (Low Frequency Electric and Magnetic fields for Visual Display)

- MPR-II (MPR:1990:8/1990:10 Low Frequency Electric and Magnetic fields)

- TCO99, TCO03 (Requirement for Environment Labelling of Ergonomics, Energy, Ecology and Emission, TCO: Swedish Confederation of Professional Employees) for TCO versions

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (1 of 11)2005-07-09 9:06:12 AM

Regulatory Information

RETURN TO TOP OF THE PAGE

Display Power Management Signaling

BDL4221V

This monitor is equipped with a function for saving energy which supports the VESA Display Power Management Signaling (DPMS) standard. This means that the monitor must be connected to a computer which supports VESA DPMS to fulfill the requirements in the NUTEK specification 803299/94. Time settings are adjusted from the system unit by software.

NUTEK VESA State LED Indicator Power Consumption Normal operation ON Blue 100 W (typical) Power Saving

Alternative 2 One step

OFF(Sleep) Amber < 5 W

Switch OFF OFF < 3 W

We recommend you switch off the monitor when it is not in use for quite a long time.

RETURN TO TOP OF THE PAGE

Federal Communications Commission (FCC) Notice (U.S. Only)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (2 of 11)2005-07-09 9:06:12 AM

Regulatory Information

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and receiver.

● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Use only RF shielded cable that was supplied with the monitor when connecting this monitor to a computer device.

To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain or excessive moisture.

THIS CLASS B DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-CAUSING EQUIPMENT REGULATIONS.

RETURN TO TOP OF THE PAGE

Commission Federale de la Communication (FCC Declaration)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (3 of 11)2005-07-09 9:06:12 AM

Regulatory Information

Cet équipement a été testé et déclaré conforme auxlimites des appareils numériques de class B,aux termes de l'article 15 Des règles de la FCC. Ces limites sont conçues de façon à fourir une protection raisonnable contre les interférences nuisibles dans le cadre d'une installation résidentielle. CET appareil produit, utilise et peut émettre des hyperfréquences qui, si l'appareil n'est pas installé et utilisé selon les consignes données, peuvent causer des interférences nuisibles aux communications radio. Cependant, rien ne peut garantir l'absence d'interférences dans le cadre d'une installation particulière. Si cet appareil est la cause d'interférences nuisibles pour la réception des signaux de radio ou de télévision, ce qui peut être décelé en fermant l'équipement, puis en le remettant en fonction, l'utilisateur pourrait essayer de corriger la situation en prenant les mesures suivantes:

● Réorienter ou déplacer l'antenne de réception.

● Augmenter la distance entre l'équipement et le récepteur.

● Brancher l'équipement sur un autre circuit que celui utilisé par le récepteur.

● Demander l'aide du marchand ou d'un technicien chevronné en radio/télévision.

Toutes modifications n'ayant pas reçu l'approbation des services compétents en matière de conformité est susceptible d'interdire à l'utilisateur l'usage du présent équipement.

N'utiliser que des câbles RF armés pour les connections avec des ordinateurs ou périphériques.

CET APPAREIL NUMERIQUE DE LA CLASSE B RESPECTE TOUTES LES EXIGENCES DU REGLEMENT SUR LE MATERIEL BROUILLEUR DU CANADA.

RETURN TO TOP OF THE PAGE

EN 55022 Compliance (Czech Republic Only)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (4 of 11)2005-07-09 9:06:12 AM

Regulatory Information

RETURN TO TOP OF THE PAGE

VCCI Notice (Japan Only)

This is a Class B product based on the standard of the Voluntary Control Council for Interference (VCCI) for Information technology equipment. If this equipment is used near a radio or television receiver in a domestic environment, it may cause radio Interference. Install and use the equipment according to the instruction manual.

Class B ITE

RETURN TO TOP OF THE PAGE

MIC Notice (South Korea Only)

Class B Device

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (5 of 11)2005-07-09 9:06:12 AM

Regulatory Information

Please note that this device has been approved for non-business purposes and may be used in any environment, including residential areas.

RETURN TO TOP OF THE PAGE

Polish Center for Testing and Certification Notice

The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, monitor, printer, and so on) should have the same power supply source.

The phasing conductor of the room's electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value no larger than 16 amperes (A).

To completely switch off the equipment, the power supply cable must be removed from the power supply socket, which should be located near the equipment and easily accessible.

A protection mark "B" confirms that the equipment is in compliance with the protection usage requirements of standards PN-93/T-42107 and PN-89/E-06251.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (6 of 11)2005-07-09 9:06:12 AM

Regulatory Information

RETURN TO TOP OF THE PAGE

North Europe (Nordic Countries) Information

Placering/Ventilation

VARNING:

FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS.

Placering/Ventilation

ADVARSEL:

SØRG VED PLACERINGEN FOR, AT NETLEDNINGENS STIK OG STIKKONTAKT ER NEMT TILGÆNGELIGE.

Paikka/Ilmankierto

VAROITUS:

SIJOITA LAITE SITEN, ETTÄ VERKKOJOHTO VOIDAAN TARVITTAESSA HELPOSTI IRROTTAA PISTORASIASTA.

Plassering/Ventilasjon

ADVARSEL:

NÅR DETTE UTSTYRET PLASSERES, MÅ DU PASSE PÅ AT KONTAKTENE FOR STØMTILFØRSEL ER LETTE Å NÅ.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (7 of 11)2005-07-09 9:06:12 AM

Regulatory Information

RETURN TO TOP OF THE PAGE

BSMI Notice (Taiwan Only)

RETURN TO TOP OF THE PAGE

Ergonomie Hinweis (nur Deutschland)

Damit Ihr Monitor immer den in der Zulassung geforderten Werten entspricht, ist darauf zu achten, daß

1. Reparaturen nur durch Fachpersonal durchgeführt werden.

2. nur original-Ersatzteile verwendet werden.

3. bei Ersatz der Bildröhre nur eine bauartgleiche eingebaut wird.

Aus ergonomischen Gründen wird empfohlen, die Grundfarben Blau und Rot nicht auf dunklem Untergrund zu verwenden (schlechte Lesbarkeit und erhöhte Augenbelastung bei zu geringem Zeichenkontrast wären die Folge).

Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 beträgt 70dB (A) oder weniger.

ACHTUNG: BEIM AUFSTELLEN DIESES GERÄTES DARAUF ACHTEN, DAß NETZSTECKER UND NETZKABELANSCHLUß LEICHT ZUGÄNGLICH SIND.

RETURN TO TOP OF THE PAGE

End-of-Life Disposal

Your new monitor contains materials that can be recycled and reused. Specialized companies can recycle

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (8 of 11)2005-07-09 9:06:12 AM

Regulatory Information

your product to increase the amount of reusable materials and to minimize the amount to be disposed of.

Please find out about the local regulations on how to dispose of your old monitor from your local Philips dealer.

(For customers in Canada and U.S.A.)

This product may contain lead and/or mercury. Dispose of in accordance to local-state and federal regulations. For additional information on recycling contact www.eia.org (Consumer Education Initiative)

RETURN TO TOP OF THE PAGE

Information for UK only

WARNING - THIS APPLIANCE MUST BE EARTHED.

Important:

This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows:

1. Remove fuse cover and fuse.

2. Fit new fuse which should be a BS 1362 5A,A. S.T.A. or BSI approved type.

3. Refit the fuse cover.

If the fitted plug is not suitable for your socket outlets, it should be cut off and an appropriate 3pin plug fitted in its place.

If the mains plug contains a fuse, this should have a value of 5A. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5A.

Note: The severed plug must be destroyed to avoid a possible shock hazard should it be inserted into a 13A socket elsewhere.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (9 of 11)2005-07-09 9:06:12 AM

Regulatory Information

How to connect a plug

The wires in the mains lead are coloured in accordance with the following code:

BLUE - "NEUTRAL" ("N")

BROWN - "LIVE" ("L")

GREEN & YELLOW - "EARTH" ("E")

1. The GREEN AND YELLOW wire must be connected to the terminal in the plug which is marked with the letter "E" or by the Earth symbol

or coloured GREEN or GREEN AND

YELLOW.

2. The BLUE wire must be connected to the terminal which is marked with the letter "N" or coloured BLACK.

3. The BROWN wire must be connected to the terminal which marked with the letter "L" or coloured RED.

Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead - not simply over the three wires.

RETURN TO TOP OF THE PAGE

Waste Electrical and Electronic Equipment-WEEE

Attention users in European Union private households

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (10 of 11)2005-07-09 9:06:12 AM

Regulatory Information

This marking on the product or on its packaging illustrates that, under European Directive 2002/96/EG governing used electrical and electronic appliances, this product may not be disposed of with normal household waste. You are responsible for disposal of this equipment through a designated waste electrical and electronic equipment collection. To determine the locations for dropping off such waste electrical and electronic, contact your local government office, the waste disposal organization that serves your household or the store at which you purchased the product.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/REGS/REGULAT.HTM (11 of 11)2005-07-09 9:06:12 AM

Other Related Information

Safety and Troubleshooting • FAQs • Troubleshooting • Regulatory Information • Information for Users in the U. S. • Information for Users Outside the U.S

Information for Users in the U. S.

For units set at 115 V :

Use a UL Listed Cord Set consisting of a minimum 18 AWG, Type SVT or SJT three conductor cord a maximum of 15-feet long and a parallel blade, grounding type attachment plug rated 15 A, 125 V.

For units set at 230 V:

Use a UL Listed Cord Set consisting of a minimum 18 AWG, Type SVT or SJT three conductor cord a maximum of 15-feet long and a tandem blade, grounding type attachment plug rated 15 A, 250 V.

Information for Users outside the U.S.

For units set at 230 V:

Use a Cord Set consisting of a minimum 18 AWG cord and grounding type attachment plug rated 15 A, 250 V. The Cord Set should have the appropriate safety approvals for the country in which the equipment will be installed and / or be marked HAR.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/saf_other.htm2005-07-09 9:06:12 AM

Philips Pixel Defect Policy

Product Features • Technical Specifications • Resolution and Preset Modes • Automatic Power Saving • Physical Specification • Pin Assignment • Product Views

Philips' LCD Panel Pixel Defect Policy

Philips strives to deliver the highest quality products. We use some of the industry's most advanced manufacturing processes and practise stringent quality control. However, pixel or sub pixel defects on the TFT LCD panels used in flat panel monitors are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but Philips guarantees that any monitor with an unacceptable number of defects will be repaired or replaced under warranty. This notice explains the different types of pixel defects and defines acceptable defect levels for each type. In order to qualify for repair or replacement under warranty, the number of pixel defects on a TFT LCD panel must exceed these acceptable levels. For example, no more than 0.0004% of the sub pixels on a 15" XGA monitor may be defective. Furthermore, Philips sets even higher quality standards for certain types or combinations of pixel defects that are more noticeable than others. This policy is valid worldwide.

Pixels and Sub pixels

A pixel, or picture element, is composed of three sub pixels in the primary colors of red, green and blue. Many pixels together form an image. When all sub pixels of a pixel are lit, the three colored subpixels together appear as a single white pixel. When all are dark, the three colored sub pixels together appear as a single black pixel. Other combinations of lit and dark sub pixels appear as single pixels of other colors.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/PIXEL.HTM (1 of 4)2005-07-09 9:06:18 AM

Philips Pixel Defect Policy

Types of Pixel Defects

Pixel and sub pixel defects appear on the screen in different ways. There are two categories of pixel defects and several types of sub pixel defects within each category.

Bright Dot Defects Bright dot defects appear as pixels or sub pixels that are always lit or 'on'. That

is, a bright dot is a sub-pixel that stands out on the screen when the monitor displays a dark pattern. There are the types of bright dot defects:

One lit red, green or blue sub pixel

Two adjacent lit sub pixels:

- Red + Blue = Purple

- Red + Green = Yellow

- Green + Blue = Cyan (Light Blue)

Three adjacent lit sub pixels (one white pixel)

A red or blue bright dot must be more than 50 percent brighter than neighboring dots while a green bright dot is 30 percent brighter than neighboring dots.

Black Dot Defects Black dot defects appear as pixels or sub pixels that are always dark or 'off'. That

is, a dark dot is a sub-pixel that stands out on the screen when the monitor displays a light pattern. These are the types of black dot defects:

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/PIXEL.HTM (2 of 4)2005-07-09 9:06:18 AM

Philips Pixel Defect Policy

One dark sub pixel Two or three adjacent dark sub pixels

Proximity of Pixel Defects

Because pixel and sub pixels defects of the same type that are near to one another may be more noticeable, Philips also specifies tolerances for the proximity of pixel defects.

Pixel Defect Tolerances

In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT LCD panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.

BRIGHT DOT DEFECTS ACCEPTABLE LEVEL

MODEL

BDL4221V

1 lit sub pixel 0 2 adjacent lit sub pixels 0 3 adjacent lit sub pixels (one white pixel) 0 75% ~ 50% of Dot 0 50% ~ Less Dot (Weak Dot) Max 7 Distance between two bright dot defects* N/A Total bright dot defects of all types 0

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/PIXEL.HTM (3 of 4)2005-07-09 9:06:18 AM

Philips Pixel Defect Policy

Tiny bright dots less then 50% R/B, 30% G Max 4

* Bright Dot is defined as dots (sub-pixels) which appeared brightly in the screen when the LCM displayed with whole pattern & Bright Dot's brightess is defined over 50% of the brightness against around. (but, Green bright dot is over 30% of brightness against around)

* Here in Tiny Bright Dot is defined as "for Red and Blue" the bright area should be no longer than 1/2 sub-pixel and for green the bright area should be no larger than 1/3 sub-pixel.

BLACK DOT DEFECTS ACCEPTABLE LEVEL

MODEL

BDL4221V

1 dark sub pixel 5 or fewer 2 adjacent dark sub pixels 1 or fewer 3 adjacent dark sub pixels 0 Distance between two black dot defects* 15 mm or more Total black dot defects of all types 5 or fewer

TOTAL DOT DEFECTS ACCEPTABLE LEVEL

MODEL

BDL4221V

Total bright or black dot defects of all types 5 or fewer

Note:

* 1 or 2 adjacent sub pixel defects = 1 dot defect

All Philips monitors are ISO13406-2 Compliant

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/PIXEL.HTM (4 of 4)2005-07-09 9:06:18 AM

Connecting to Your PC, TV Antenna, DVD/VCR etc.

Product Description • Accessory Pack • Connecting to Your PC, TV Antenna, DVD/VCR etc. • Getting Started • Optimizing Performance

Accessory Pack

Unpack all the parts

Power cable Remote control & batteries

DVI-D cable VGA signal cable

E-DFU pack

Accessories below are available for TV model only

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/CONNECT.HTM (1 of 8)2005-07-09 9:06:30 AM

Connecting to Your PC, TV Antenna, DVD/VCR etc.

Base

Screw pack

2x10 W Detachable Speakers

RETURN TO TOP OF THE PAGE

Setting up and connecting your monitor/TV

CAUTION: Ensure that the power to the monitor/TV is switched off before the

installation.

- Connecting the monitor/TV

● Connect the cables to the rear of your monitor/TV according to the numbers:

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/CONNECT.HTM (2 of 8)2005-07-09 9:06:30 AM

Connecting to Your PC, TV Antenna, DVD/VCR etc.

TV model

RETURN TO TOP OF THE PAGE

- Connect to PC

● Connect the cables to the back of your computer by following step 1~5.

● If your monitor displays the computer image the installation has been completed successfully.

● If installation was not successful, see the Troubleshooting section.

● For installation of the monitor driver for Microsoft Windows®, see the Monitor Driver Installation section

(Getting Started).

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/CONNECT.HTM (3 of 8)2005-07-09 9:06:30 AM

Connecting to Your PC, TV Antenna, DVD/VCR etc.

RETURN TO TOP OF THE PAGE

- Connect to DVD/VCD/VCR

Connect to DVD/VCR/VCD through S-VIDEO

● Connect to DVD/VCR/VCD through S-VIDEO

● Connect to DVD/VCR /VCD through SCART (for Europe only)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/CONNECT.HTM (4 of 8)2005-07-09 9:06:30 AM

Connecting to Your PC, TV Antenna, DVD/VCR etc.

● Connect to DVD/VCR /VCD through composite video (CVBS)

● Connect to DVD/VCR /VCD through component video (YPbPr)

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/CONNECT.HTM (5 of 8)2005-07-09 9:06:30 AM

Connecting to Your PC, TV Antenna, DVD/VCR etc.

RETURN TO TOP OF THE PAGE

Connecting to Cable TV

Antenna

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/CONNECT.HTM (6 of 8)2005-07-09 9:06:30 AM

Connecting to Your PC, TV Antenna, DVD/VCR etc.

Progressive video and HDTV connections for digital high-definition picture

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/CONNECT.HTM (7 of 8)2005-07-09 9:06:30 AM

Connecting to Your PC, TV Antenna, DVD/VCR etc.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/CONNECT.HTM (8 of 8)2005-07-09 9:06:30 AM

Getting Started

Product Description • Connecting to Your PC, TV Antenna, DVD/VCR etc.• Driver Installation • Optimizing Performance

Driver Installation Use the information file ( .inf) for Windows® 95/98/2000/Me/XP or later

The built-in VESA DDC2B feature in Philips Monitors supports Plug & Play requirements for Windows® 95/98/2000/Me/XP. This information file ( .inf) should be installed in order that your Philips monitor can be enabled from the 'Monitor' dialog box in Windows® 95/98/2000/Me/XP and the Plug & Play application can be activated. The installation procedure based on Windows® '95 OEM Release 2 , 98 , Me, XP and 2000 is specified as follows.

For Windows® 95

1. Start Windows® '95

2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'.

3. Double click on the 'Display' Icon.

4. Select the 'Settings' tab then click on 'Advanced...'.

5. Select the 'Monitor' button, point to 'Change...' then click on 'Have Disk...'.

6. Click on the 'Browse...' button, select the appropriate drive F: ( CD-ROM Drive) then click

on the 'OK' button.

7. Click on the 'OK' button then select your monitor model and click on the 'OK'.

8. Click on the 'Close' button.

For Windows® 98

1. Start Windows® 98

2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'.

3. Double click on the 'Display' Icon.

4. Select the 'Settings' tab then click on 'Advanced...'.

5. Select the 'Monitor' button, point to 'Change...' then click on 'Next'

6. Select 'Display a list of all the drivers in a specific location, so you can choose the driver

you want.' then click on 'Next' and then click on 'Have Disk...'.

7. Click on the 'Browse...' button, select the appropriate drive F: ( CD-ROM Drive) then click

on the 'OK' button.

8. Click on the 'OK' button then select your monitor model and click on the 'Next' button.

9. Click on the 'Finish' button then the 'Close' button.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/gt_start.htm (1 of 3)2005-07-09 9:06:30 AM

Getting Started

For Windows® Me

1. Start Windows® Me

2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'.

3. Double click on the 'Display' Icon.

4. Select the 'Settings' tab then click on 'Advanced...'.

5. Select 'Monitor' button, then click on 'Change...' button.

6. Select 'Specify the location of the driver(Advanced)' and click on the 'Next' button.

7. Select 'Display a list of all the drivers in a specific location, so you can choose the driver

you want', then click on 'Next' and then click on 'Have Disk...'.

8. Click on 'Browse...' button, select the appropriate drive F: ( CD-ROM Drive) then click on

the 'OK' button.

9. Click on the 'OK' button, select your monitor model and click on the 'Next' button.

10. Click on 'Finish' button then the 'Close' button.

For Windows® 2000

1. Start Windows® 2000

2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'.

3. Double click on the 'Display' Icon.

4. Select the 'Settings' tab then click on 'Advanced...'.

5. Select 'Monitor'

- If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation.

- If the 'Properties' button is active. Click on 'Properties' button. Please follow the steps given below.

6. Click on 'Driver' and then click on 'Update Driver...' then click on the 'Next' button.

7. Select 'Display a list of the known drivers for this device so that I can choose a specific

driver', then click on 'Next' and then click on 'Have disk...'.

8. Click on 'Browse...' button then select the appropriate drive F: ( CD-ROM Drive).

9. Click on the 'Open' button, then click on the 'OK' button.

10. Select your monitor model and click on the 'Next' button.

11. Click on the 'Finish' button then the 'Close' button.

If you can see the 'Digital Signature Not Found' window, click on the 'Yes' button.

For Windows® XP

1. Start Windows® XP

2. Click on the 'Start' button and then click on 'Control Panel'.

3. Select and click on the category 'Printers and Other Hardware'

4. Click on the 'Display' Icon.

5. Select the 'Settings' tab then click on the 'Advanced' button.

6. Select 'Monitor' tab

- If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/gt_start.htm (2 of 3)2005-07-09 9:06:30 AM

Getting Started

- If the 'Properties' button is active, click on 'Properties' button. Please follow the steps below.

7. Click on the 'Driver' tab and then click on 'Update Driver...' button.

8. Select the 'Install from a list or specific location [advanced]' radio button and then click on

the 'Next' button.

9. Select the 'Don't Search. I will choose the driver to install' radio button. Then click on the

'Next' button.

10. Click on the 'Have disk...' button, then click on the 'Browse...' button and then select the

appropriate drive F: (CD-ROM Drive).

11. Click on the 'Open' button, then click the 'OK' button.

12. Select your monitor model and click on the 'Next' button.

- If you can see the 'has not passed Windows® Logo testing to verify its compatibility with Windows® XP' message please click on the 'Continue Anyway' button.

13. Click on the 'Finish' button then the 'Close' button.

14. Click on the 'OK' button and then the 'OK' button again to close the Display_Properties

dialog box.

If your Windows® 95/98/2000/Me/XP version is different or you need more detailed installation information, please refer to Windows® 95/98/2000/Me/XP user's manual.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/INSTALL/gt_start.htm (3 of 3)2005-07-09 9:06:30 AM

Your Philips F1rst Choice Warranty

Thank you for purchasing this Philips monitor.

All Philips monitors are designed and manufactured to high standards and deliver high-quality performance, ease of use and ease of installation. Should you encounter any difficulties while installing or using this product, please contact the Philips helpdesk directly to benefit from your Philips F1rst Choice Warranty. This three-year service warranty entitles you to a swap model on-site if your monitor turns out to be faulty or defective. Philips aims at a swap within 48 hours of your call being received.

What is covered?

The Philips F1rst Choice Warranty applies within Andorra, Austria, Belgium, Cyprus, Denmark, France, Germany, Greece, Finland, Ireland, Italy, Liechtenstein, Luxembourg, Monaco, the Netherlands, Norway, Portugal, Sweden, Switzerland, Spain and the United Kingdom and only for monitors originally designed, manufactured, approved and/or authorized for usage within these countries.

Warranty coverage begins as from the day you buy your monitor. For three years thereafter, your monitor will be swapped by at least an equivalent monitor in case of defects provided for under the warranty coverage.

The swap monitor remains yours and Philips keeps the defective/original monitor. For the swap monitor the warranty period remains equal to that of your original monitor, being 36 months as from the purchase date of your original monitor.

What is excluded?

The Philips F1rst Choice Warranty applies provided the product is handled properly for its intended use, in accordance with its operating instructions and upon presentation of the original invoice or cash receipt, indicating the date of purchase, dealer's name and model and production number of the product.

The Philips F1rst Choice Warranty may not apply if:

● The documents have been altered in any way or made illegible;

● The model or production number on the product has been altered, deleted, removed or

made illegible;

● Repairs or product modifications and alterations have been executed by unauthorized

service organizations or persons;

file:///D|/My%20Documents/dfu/420WN6/english/warranty/war_1st.htm (1 of 3)2005-07-09 9:06:36 AM

Your Philips F1rst Choice Warranty

● Damage is caused by accidents including but not limited to lightning, water or fire, misuse or

neglect;

● Reception problems caused by signal conditions or cable or antenna systems outside the

unit;

● Defects caused by abuse or misuse of the monitor;

● Product requires modification or adaptation to enable it to comply with local or national

technical standards, which apply in countries for which the product was not originally designed, manufactured, approved and/or authorized. Therefore always check whether a product can be used in a specific country.

● Note that products that are not originally designed, manufactured, approved and/or

authorized for usage within the Philips F1rst Choice countries, do not apply to the Philips F1rst Choice Warranty. In these cases the Philips global warranty terms are valid.

Just a click away

In case of any problems, we advise you to read the operating instructions carefully or go to the www.

philips.com/support website for additional support.

Just a phone call away

In order to avoid unnecessary inconvenience, we advise you to read the operating instructions carefully or go to the www.philips.com/support website for additional support before contacting the

Philips helpdesk.

To solve your problem quickly, please prepare the following details before contacting the Philips helpdesk:

● Philips type number

● Philips serial number

● Purchase date (copy of purchase may be required)

● PC environment Processor: ❍ 286/386/486/Pentium Pro/Internal memory ❍ Operating system (Windows, DOS, OS/2, MAC) ❍ Fax/Modem/Internet program?

● Other cards installed

Having the following information available will also help speed up the process:

● Your proof of purchase indicating: date of purchase, dealer name, model and product serial

number.

● The full address to which the faulty monitor has to be collected and the swap model should

be delivered.

Philips' customer help desks are located worldwide. Click here to access the F1rst Choice Contact

file:///D|/My%20Documents/dfu/420WN6/english/warranty/war_1st.htm (2 of 3)2005-07-09 9:06:36 AM

Your Philips F1rst Choice Warranty

Information.

Or you can reach us via:

Website: http://www.philips.com/support

file:///D|/My%20Documents/dfu/420WN6/english/warranty/war_1st.htm (3 of 3)2005-07-09 9:06:36 AM

International Guarantee

Your International Guarantee

Dear Customer,

Thank you for purchasing this Philips product which has been designed and manufactured to the highest quality standards.

If, unfortunately, something should go wrong with this product Philips guarantees free of charge labor and replacement parts irrespective of the country where it is repaired during a period of 12 months from date of purchase. This international Philips guarantee complements the existing national guarantee obligations to you of dealers and Philips in the country of purchase and does not affect your statutory rights as a customer.

The Philips guarantee applies provided the product is handled properly for its intended use, in accordance with its operating instructions and upon presentation of the original invoice or cash receipt, indicating the date of purchase, dealer's name and model and production number of the product.

The Philips guarantee may not apply if:

● the documents have been altered in any way or made illegible;

● the model or production number on the product has been altered, deleted, removed or made

illegible;

● repairs or product modifications and alterations have been executed by unauthorized service

organizations or persons;

● damage is caused by accidents including but not limited to lightning, water or fire, misuse or

neglect.

Please note that the product is not defective under this guarantee in the case where modifications become necessary in order for the product to comply with local or national technical standards which apply in countries for which the product was not originally designed and/or manufactured. Therefore always check whether a product can be used in a specific country.

In case your Philips product is not working correctly or is defective, please contact your Philips dealer. In the event you require service whilst in another country a dealer address can be given to you by the Philips Consumer Help Desk in that country, the telephone and fax number of which can be found in the relevant part of this booklet.

In order to avoid unnecessary inconvenience, we advise you to read the operating instructions carefully before contacting your dealer. If you have questions which your dealer cannot answer or any related question please contact the Philips Consumer Information Centers or via:

Website: http://www.philips.com

file:///D|/My%20Documents/dfu/420WN6/english/warranty/war_intl.htm (1 of 2)2005-07-09 9:06:37 AM

United States Guarantee

PHILIPS LIMITED WARRANTY

One (1) Year Labor and Parts Repair

PHILIPS CONSUMER ELECTRONICS warrants this

product against defect in material or workmanship, subject to any conditions set forth as follows:

PROOF OF PURCHASE:

You must have proof of the date of purchase to receive warranted repair on the product. A sales receipt or other document showing the product and the date that your purchased the products as well as the authorized retailer included, is considered such proof.

COVERAGE:

(If this product is determined to be defective) LABOR: For a period of one (1) year from the date of purchase,

Philips will repair or replace the product, at its option, at no charge, or pay the labor charges to any Philips authorized repair facility. After the period of one (1) year, Philips will no longer be responsible for charges incurred.

PARTS: For a period of one (1) year from the date of purchase, Philips will supply, at no charge, new or rebuilt replacement parts in exchange for defective parts, through a Philips authorized service center.

Note: If Philips is unable to provide service in your area, receipt of the paid service can be submitted for consideration of adjustment or full reimbursement at Philips discretion.

EXCLUDED FROM WARRANTY COVERAGE

Your warranty does not cover:

• Labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation or repair of antenna systems outside of the product.

• Product repair and/or part replacement because of improper installation, connections to improper voltage supply, abuse, neglect, misuse, accident, unauthorized repair or other cause not within the control of Philips.

• A product that requires modification or adaptation to enable it to operate in any country other than the country for which it was designed, manufactured, approved and/or authorized, or repair of products damaged by these modifications.

• Damage occurring to product during shipping when improperly packaged or cost associated with packaging.

• Product lost in shipment and no signature verification of receipt can be provided.

• Products sold AS IS or RENEWED.

CARRY-IN / SHIP-IN WARRANTY

For Carry-In warranty repair, take the product to a Philips authorized service center for repair. When the product has been repaired, you must pick up the unit at the center. For Ship-In warranty repair, ship the product to a Philips authorized service center for repair in its original carton and packing material. If you do not have the original carton or packing material, have your product professionally packed for shipping. Ship product via a traceable carrier. When it is necessary for you to ship the product to Philips for repair, you will pay the shipping cost for shipment to Philips. Philips will pay the shipping costs when returning the product to you.

TO OBTAIN WARRANTY SERVICE IN THE U.S.A., PUERTO RICO, OR U.S. VIRGIN ISLANDS…

Contact Philips Customer Care Center at:

1-888-PHILIPS (1-888-744-5477)

TO OBTAIN WARRANTY SERVICE IN CANADA…

1-800-661-6162 (French Speaking) 1-888-PHILIPS (1-888-744-5477) - (English or Spanish

Speaking) REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS

WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some states do not allow the exclusions or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. In addition, if you enter into a service contract agreement with the PHILIPS partnership within ninety (90) days of the date of sale, the limitation on how long an implied warranty lasts does not apply.

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

Philips, P.O. Box 671539, Marietta, GA. 30006-0026

(Warranty: 4835 710 27175

)

file:///D|/My%20Documents/dfu/420WN6/english/warranty/war_usa.htm (1 of 2)2005-07-09 9:06:37 AM

F1rst Choice Contact Information

Country Telephone number Tariff Austria 0820 901115

 0.20

Belgium 070 253 010

 0.17 Cyprus 800 92256 Free of Charge Denmark 3525 8761 Local call tariff Finland 09 2290 1908 Local call tariff France 08 9165 0006

 0.23 Germany 0180 5 007 532

 0.12 Greece 00800 3122 1223 Local call tariff Ireland 01 601 1161 Local call tariff Italy 199 404 042

 0.25 Luxembourg 26 84 30 00 Local call tariff The Netherlands 0900 0400 063

 0.20 Norway 2270 8250 Local call tariff Portugal 2 1359 1440 Local call tariff Spain 902 888 785

 0.15 Sweden 08 632 0016 Local call tariff Switzerland 02 2310 2116 Local call tariff United Kingdom 0207 949 0069 Local call tariff

file:///D|/My%20Documents/dfu/420WN6/english/warranty/warfirst.htm2005-07-09 9:06:44 AM

Consumer Information Centers

Antilles • Argentina • Australia • Bangladesh • Brasil • Canada • Chile • China • Colombia • Belarus • Bulgaria • Croatia • Czech Republic • Estonia • Dubai • Hong Kong • Hungary • India • Indonesia • Korea • Latvia • Lithuania • Malaysia • Mexico • Morocco • New Zealand

• Pakistan • Paraguay • Peru • Philippines • Poland • Romania • Russia • Serbia &

Montenegro • Singapore • Slovakia • Slovenia • South Africa • Taiwan • Thailand • Turkey • Ukraine • Uruguay • Venezuela

Eastern Europe

BELARUS

Technical Center of JV IBA M. Bogdanovich str. 155 BY - 220040 Minsk Tel: +375 17 217 33 86

BULGARIA

LAN Service 140, Mimi Balkanska Str. Office center Translog 1540 Sofia, Bulgaria Tel: +359 2 960 2360 www.lan-service.bg

CZECH REPUBLIC

Xpectrum Lužná 591/4 CZ - 160 00 Praha 6 Tel: 800 100 697 Email:info@xpectrum.cz www.xpectrum.cz

file:///D|/My%20Documents/dfu/420WN6/english/warranty/warcic.htm (1 of 11)2005-07-09 9:06:49 AM

Consumer Information Centers

CROATIA

Renoprom d.o.o. Mlinska 5, Strmec HR - 41430 Samobor Tel: +385 1 333 0974

ESTONIA

FUJITSU SERVICES OU Akadeemia tee 21G EE-12618 Tallinn Tel: +372 6519900 www.ee.invia.fujitsu.com

HUNGARY

Serware Szerviz Vizimolnár u. 2-4 HU - 1031 Budapest Tel: +36 1 2426331 Email: inbox@serware.hu www.serware.hu

LATVIA

ServiceNet LV Jelgavas iela 36 LV - 1055 Riga, Tel: +371 7460399 Email: serviss@servicenet.lv

LITHUANIA

ServiceNet LT Gaiziunu G. 3 LT - 3009 KAUNAS Tel: +370 7400088 Email: servisas@servicenet.lt www.servicenet.lt

file:///D|/My%20Documents/dfu/420WN6/english/warranty/warcic.htm (2 of 11)2005-07-09 9:06:49 AM

Philips 42PM8822/10, BDL4221M/00, 42PM8822 - annexe 2, BDL4221M, BDL4221V User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
