Philips 20HF8432 User Manual

Philips professional flat TV with Crystal Clear III

20"

LCD

20HF8432

System Prepared Flat TV

Specially designed for in-room entertainment

Stylish compact design. Equiped with advanced hotel mode and compatible with the future proof, optional, Smartcard Xpress expansion unit allowing third party interactive solutions.

Advanced hotel features and future proof

• Wireless SmartLoader for fast cloning

• Welcome message on screen display

• Volume limitation

• Front Controls Locking

• Switch On Channel Programming

• Security Menu Access

• Built-in FM radio

Interactive System Prepared, Future Proof

• SmartCard Xpress Box compatible for interactive systems

• Additional integrated power supply

• Serial Xpress™ Control interface

• Future proof by software upgradability

Breathtaking natural pictures

• Crystal Clear III for natural images with enhanced quality

Professional flat TV with Crystal Clear III

20HF8432/11

20" LCD

Specifications Product highlights

Picture/Display

• Aspect ratio: 4:3

• Brightness: 450 cd/m²

• Contrast ratio (typical): 350:1

• Diagonal screen size: 20 inch / 51 cm

• Picture enhancement: Crystal Clear III, Progressive Scan, Active Control, Digital Noise Reduction, Dynamic Contrast, Sharpness Adjustment, 3D Combfilter

• Screen enhancement: Anti-Reflection coated screen

• Viewing angle (H / V): 176 / 176 degree

• Response time (typical): 25 ms

• Panel resolution: 640 x 480p

• Display screen type: LCD VGA Active Matrix TFT

Sound

• Sound System: Stereo, Virtual Dolby Surround, Mono

• Output power (RMS): 2 x 5W

• Music Power: 20 W

Convenience

• Ease of Installation: Automatic Channel Install(ACI), Automatic Tuning System (ATS), Autostore, Fine Tuning, PLL Digital Tuning

• Ease of Use: Menu Control, On Screen Display, Smart Picture Control, Smart Sound Control, Top Controls

• Remote control type: RC2887

• Teletext: 10 page Smart Text

• Remote control: Zappa

• Clock: Sleep Timer

• VESA Mount: 100 x 100 mm

• Child Protection: Child Lock

• Remote Control: TV

Tuner/Reception/Transmission

• Tuner bands: Hyperband, S-Channel, UHF, VHF, FM

• TV system: NTSC

• Aerial Input: 75 ohm coaxial (IEC75)

• Tuner Display: PLL

• Video Playback: NTSC, PAL, SECAM

Connectivity

• Other connections: FM Antenna, D-Sub in (PC)

• AV 1: Audio L/R in, CVBS in, YPbPr

• Connectivity Enhancements: RJ12 connector, RJ45 connector

Power

• Mains power: AC 90V - 240V 50/60 Hz

• Ambient temperature: 5 °C to 40 °C

Dimensions

• Product weight: 8.8 kg

Accessories

• Included Accessories: Power cord, Remote Control, RF antenna cable, User Manual

•

Wireless SmartLoader

Provides the ability to copy easy and wireless all programmming settings from one TV set into other TV sets in less then a minute. The feature ensures uniformity between TV sets and significantly reduces installation time and costs.

Welcome message

A welcome greeting is displayed each time the TV set is switched on.

Volume limitation

This feature predefines the volume range with which the TV set is allowed to operate, preventing excessive volume adjustments and avoiding disturbance of next door guests.

Front Controls Locking

Prevents unauthorised access to TV functions

Switch On Channel Programming

Perfect for in-house advertising or information channels as it allows to show a predefined channel when the TV is turned on.

Security Menu Access

Provides conditional access to installation and configuration settings via a special code or master remote control

Built-in FM radio

The integrated FM radio offers guests additional comfort without the extra investment in radio receivers.

SmartCard Xpress Box

The optional SmartCard Xpress Box can be mounted at th e r ear side o f t he TV set an d allows t hi rd party de coders and application cards to interface with the TV adding new functionality to the TV. The TV can also be connected to external decoders and set-top boxes of all major interactive system providers, through the Serial Xpress Control Interface (supporting UART and RS232 protocols) and the SmartPlug Control interface.

Add. integrated power supply

The additional integrated power supply avoids the need for a separate power supply for an interactive system. In case of stand-alone use, the additional power supply can be switched off to save energy.

Serial Xpress™ Control

The Serial Xpress™ Control interface is compatible with all major premium entertainment services. The protocols enables the TV connection with external decoders, set-top boxes and PC based solutions. Support UART and RS232 protocols.

Upgradable software

The upgradable software architecture ensures that the TV is future proof and compatible with new technologies and developments, securing your investment.

Crystal Clear III

Crystal Clear III combines a whole range of enhancements to provide a better picture. They include a 2D Comb filter, Dynamic contrast, Blue stretch and Green enhancement so that you always get the most natural looking colors.

LCD VGA display, 640 x 480p

This VGA display with state-of-the-art LCD screen technology has an enhanced resolution of 640 x 480p.

Issue date 2008-06-16

Version: 2.0.5

12 NC: 8670 000 22965 EAN: 87 10895 90409 4

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com

2D Combfilter

The 2D comb filter separates chrominance (color) from luminance (brightness) information in the video signal for independent processing to improve picture resolution and minimize distortion.
