USER MANUAL
ZONE
BHS-630
|2
CONGRATULATIONS!
As the proud new owner of the
BHS-630 Bluetooth headset, you’re
about to experience a massive upgrade in the way you listen to music.
In addition to the wireless convenience of Bluetooth and the customizable
comfort of our extendable headband,
the BHS-630 features an incredible
and unique sound experience you will
never want to miss again.
Electronic user guide can be found at:
phaiser.com/manuals.
Enjoy your headset! We hope it’ll help
you #LiveLoud!
3|
THANKS FOR PURCHASING
PHAISER PRODUCTS!
We’re so happy to have you on board,
we’d like to invite you to
Join The Phaiser VIP Club!
Become a member of an exclusive
club for new and existing customers
with access to amazing benefits such
as:
- Get 10% O Your Next Order
- Free Velvet Earpads
- Early Access To New Products
- Free Monthly Giveaways
- 24 Month Manufacturer’s Warranty
- Lifetime Sweatproof Warranty
Go to phaiser.com/extra to join!
|4
PRODUCT FEATURES
1. Foldable for easy storage.
2. Premium Speakers with strong Bass
and HD Stereo Music.
3. Extra long Playback and Standby
time.
4. Easily operable buttons for answe ring phone calls and controlling
audio playback.
SPECIFICATIONS
Bluetooth Specification: 4.2
Battery: Lithium Polymer Battery 3.7V
Standby Time: UP to 450 hours
Talk Time: UP to 11 hours
Music Playback Time: UP to 15 hours
Charging Time: Less than 2 hours
Operating Temperature: 14°F/-10°C to
140°F/60°C
5|
1 Power Button
2 Plus Button
3 Minus Button
4 AUX Socket
5 Microphone
6 Indicator LED
7 Micro-USB Charging Port
1
3
2
5
7
4 6
|6
FIRST STEPS
To ensure best battery performance, it
is recommended to charge the headset fully before first use.
To do so, connect the USB charging
cable to the charging port at the
bottom of the left speaker.
CHARGING THE HEADSET
Just plug in the micro USB charging cable at the bottom of the left
speaker. You can choose to either use
a dedicated wall charger with a USB
port (like a mobile phone charger),
your computer‘s USB port or basically
any powered USB port. Once you
start charging the indicator-LED on
the control unit will be constantly red.
After charge is completed, the LED
will turn blue.
7|
Note regarding the functions described in this manual: Not all phones
or other connected Bluetooth devices
support every function. For further
information, please refer to your device’s user manual.
PAIRING
Before using the headset for the first
time, you must pair it with another
Bluetooth-enabled device (for example a phone). The headset will automatically enter pairing mode after you
power it on and become visible to
other devices.
1. Put the headphones on your head
and press and hold the power
button. You will hear the audio
message “Power On”. While the
LED indicator is constantly blue, the
headset is in pairing mode.
2. On your phone, find the Bluetooth
menu and “search for” or “add” new
|8
devices. Select “BHS-630” from the
list and pair it.
3. Once the headset is successfully
connected to your phone, you will
hear the audio message “Connected”.
ADDITIONAL PAIRING NOTES
1. If asked for the Pass/PIN code,
please enter “0000”. Newer phones
don‘t require this.
2. The headset will automatically turn
o if not paired within 5 minutes.
MANUAL PAIRING, PAIRING
WITH A SECOND DEVICE OR
RE-PAIRING
1.
Simultaneously press and hold the
Power and Minus buttons for 3
seconds while the headset is turned
on. You will hear the audio message
“Disconnected” (The original con nection will be lost while in pairing
mode).
9|
2. Search the Bluetooth menu of your
device for “BHS-630” and complete
above regular pairing steps until
successfully connected.
3. To delete all pairings from the head set, press and hold the Plus,
Minus and Power buttons for 10
seconds until you hear the low tone
confirmation.
MULTIPOINT
This headset is capable of connecting
with 2 devices at the same time, enabling you to use the headset with both
devices simultaneously.
A common application, for example, is
to connect your phone and your tablet-pc. You will be able to enjoy media
on your tablet-pc while not missing
phone calls from your phone.
1. Pair the headset with the first de vice according to the instructions
under “Pairing” (Turn the headset
|10
on and select “BHS-630” in the
Bluetooth menu). This device will be
the secondary device.
2. Pair the headset with the primary
device according to the instructions
under “manual pairing” (press and
hold Power and Minus for 3
seconds). This device will be the
primary device where all functions
for the multifunction („power“)
button work by default.
3. Once you paired and connected
the primary device, go back to the
secondary device and connect the
headset again through the device’s
Bluetooth menu. You will hear the
voice confirmation “Connected”.
Additionally, you can use the manual
pairing method when you already
have 2 devices connected to the
headset and like to connect the headset to a third, dierent device instead.
Of course, you can reconnect one of
the 2 previously connected devices
11|
again through its Bluetooth menu to
use Multipoint functions again.
AUTO RECONNECT
1. If you turn the headset o, it will be
disconnected from your phone. It
will automatically attempt to recon nect once turned back on and in
range.
2. A secondary device may need to be
reconnected through the Bluetooth menu by selecting “BHS-630”.
OUT OF RANGE
1. If headset and phone are separated
by more than 10 meters (33 feet),
they will disconnect.
2. In case the headset and phone do
not automatically reconnect once
back in range, briefly press the
Power button to manually re connect. You can also use manual
|12
reconnect to abort pairing mode
and connect to the last connected
device.
3. While you are in multi connection
mode, a device which goes out of
range, will lose connection. The
headset will keep trying to connect
to the lost device for 5 minutes.
4. In case you intentionally switched
o the Bluetooth function on a
single connected device and hear
the “Disconnected” message, you
can immediately go to the Blue tooth menu of your other device
(phone or tablet) to connect the
headset by using the regular pairing
steps described earlier. The headset
will become visible to other devices
as soon as all connections are drop ped or it’s forced to pairing mode
by pressing and holding the Power
and Minus buttons at the same time
for 3 seconds.
13|
ON / OFF-FUNCTION
Hold the Power button for 2 seconds
to turn the headset on. You will hear
the audio message “Power On”. You
will see the indicator LED turn blue for
a short time, then turn o if automatically reconnected to your phone or
stay blue while in pairing mode.
To turn o the headset, hold the Power button for 2 seconds. You will hear
the “Power O” message. The indicator LED will turn red and then shut
o.
If you leave your earbuds powered
on without a device being connected,
they will automatically power down
after 5 minutes.
|14
ANSWERING CALLS
As soon as you have an incoming
phone call, the headset will notify
you by ringtone and read the phone
number of the caller to you.
To answer, briefly push the Power
button or answer the call on your
phone. The call will be transferred to
your headset if not set dierently in
your phone.
REFUSING CALLS
To refuse a call, double press the call
button and the call will be rejected.
You will hear a confirmation tone.
ENDING CALLS
To end a call, press the call button
briefly or end the call through your
phone.
15|
LAST NUMBER REDIAL
To redial the last number you called,
triple click the call button and the
phone will start dialling.
VOLUME CONTROL
By pressing Plus you can increase the
volume and by pressing Minus you
can decrease it. To adjust the volume
quicker, the buttons can be pressed in
quick succession.
Note regarding volume control
Warning: Listening to music on a high
volume over a longer period of time
may damage your hearing ability.
|16
VOICE ASSISTANT AND
VOICE DIALING
Double press the Power button to
activate your phone’s Voice Assistant
function such as Siri or Google Now.
It‘s necessary that your phone supports this feature and that it‘s turned
on. Please refer to your phones user
manual for further information.
PLAY / PAUSE
During media playback you can press
the Power button button briefly to
start, pause or resume playback. It
is also possible to use your phone’s
media player to control this function.
Sometimes, it‘s necessary to manually
start a music player app before the
headset controls start working.
17|
NEXT / PREVIOUS TRACK
During media playback you can skip
between tracks by holding Plus for the
next track or Minus for the previous
track.
EQUALIZER SETTINGS
In order to change the way the
headset reproduces music from your
device, press and hold the Plus and
Minus buttons at the same time until
you hear a short interruption in playback. This will change the equalizer
setting. There are 3 equalizer settings
available: “Normal” (default), “Bass”
and “Treble”. Try them out to find the
most suitable one for your preferred
music style.
|18
BATTERY STATUS
NOTIFICATION
Every time you turn the headset
on, you will hear the battery status
notification. There are 3 battery levels
reported:
High: 100% to 60% battery life
Medium: 59% to 30% battery life
High-low beep: 29% to 0% battery life
While the headset is turned on, you
can trigger the battery status notification manually by briefly pressing the
Plus and Minus buttons at the same
time.
The headset will start to report low
battery level automatically 5 to 10
minutes before automatic shutdown.
On iOS and some Android devices,
you will be able to see the battery
level of the headset in the status bar
of your smartphone.
19|
USING THE CHARGING CASE
The headphones can also be charged
using the (optionally) included headphones charger. To do so, connect the
headphones to the charger using the
included USB cable and press the big
silver button on the charger to turn
it on.
A blue light indicates that the charger
is turned on. If no headphones are
connected, the charger will turn o after 20s. If the charger doesn‘t turn on
it is empty and needs to be recharged.
To recharge the charger, simply
connect it to your mobile phone‘s
|20
charger. While it is charging, the LED
indicator will flash red. As soon as it
is charged, it will constantly light red.
Charging the charger will take about
3h, depending on the USB power
output.
Only applies to models which include
the Charging Case.
21|
MICROPHONE MUTE
AND UNMUTE
While on a call, press and hold the
Minus button for 1 second until you
hear the notification tone to mute the
microphone. Repeat to unmute.
TROUBLESHOOTING
THE HEADSET
Issue: Headset does not work
Solution: Please make sure the head-
set is turned on and charged.
Issue: Phone disconnects from
headset
Solution: Make sure the phone
supports the Bluetooth Hands-Free
Profile and is in range.
Issue: Headset does not work properly
with the phone
Solution: Pair phone and headset
again, make sure headset is in range
(no obstacles like other electronic
devices or walls).
|22
Issue: Battery lasts shorter than
expected
Solution: Turn down the volume. High
volume will drain the battery faster
than lower volume.
AVOIDING PROBLEMS
- Turn the headset o before putting
it into a bag or pocket to avoid acc dental calls.
- Do not clean the headset with
solvents or abrasives.
- Do not expose the headset to extre me temperature (not outside 14°F/ 10°C to 140°F/60°C).
- Do not expose the headset to fire,
the battery may explode.
- Do not attempt to open the headset.
- Do not put heavy objects on your
headset.
- For safe storage, keep the headset
in a dry place.
23|
- Avoid moisture and dust.
- Do not use the headset while swim ming or showering.
- If stored longer than 1 month, please
recharge the battery before use.
To safeguard against potential problems, make sure you’ve registered
your 2-year manufacturer and lifetime
sweatproof warranties at phaiser.com/
extra.
|24
ADDITIONAL INFORMATION
Radio Frequency Exposure
This headset is a radio transmitter and
receiver. It communicates with Bluetooth equipped devices by receiving
and transmitting radio frequency (RF)
electromagnetic fields (microwaves)
in the frequency range 2.4 to 2.4835
Ghz. The output power of the headset
is only 0,001 watt (low). The headset
is designed to comply with the RF
exposure guidelines and limits set by
national and international authorities
and health agencies.
Potentially Explosive Atmosphere
If you enter a potentially explosive
atmosphere, please make sure you
turn o your headset. Such areas are
rare and in most cases, but not always,
clearly marked. It is unlikely but possible that your device could generate
a spark and cause an explosion or fire
resulting in serious injury or death.
25|
Avoiding Hearing Damage
Serious and permanent hearing damage and even loss of hearing may occur
if you use your headset continuously
at high volume. Please be sure to set
the volume to a safe level. Using high
volume continuously may feel normal
after some time but it can still damage your hearing ability. In case you
experience ringing or mued speech,
do not continue listening and have
your hearing checked. The higher the
volume the sooner your hearing may
be aected. Hearing experts suggest
that you protect your hearing. It is
better to use the headset only for a
limited time at high volume. It is not
suggested to turn up the volume in
noisy surroundings to block out the
noise. In case you cannot hear people
talking to you anymore, please turn
down the volume.
Please refer to earlier pages of this
manual on how to adjust the volume.
|26
SAFETY INFORMATION
In some areas it is illegal and generally
it is not recommended to use the
headset for listening to music while
operating a vehicle. You should be
careful and attentive while driving. Do
not continue using the headset if you
find it distracts you while operating
any kind of vehicle or during any other
activity requiring your full attention.
27|
CAUTION
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to part
15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not
installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
causes harmful interference to radio
or television reception, which can be
determined by turning the equipment
o and on, the user is encouraged to
try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving
antenna.
|28
- Increase the separation between
the equipment and receiver.
- Connect the equipment into an
outlet on a circuit dierent from that
to which the receiver is connected.
- Consult the dealer or an experien
ced radio/TV technician for help.
This device complies with part 15 of
the FCC rules. Operation is subject to
the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
Any Changes or modifications not
expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment.
29|
RF EXPOSURE
The equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This device
should be installed and operated with
minimum distance 0mm between the
radiator & your body.
|30
Before you go…
Love Free Stu?
Become a Phaiser VIP to get exclusive
benefits such as:
- 10% O Your Next Order
- Free Velvet Earpads
- Early Access To New Products
- Free Monthly Giveaways
- 24 Month Manufacturer’s Warranty
- Lifetime Sweatproof Warranty
It’s fast. It’s free.
Go to phaiser.com/extra now to get
your extras!
31|
Thank you for being a part of the
Phaiser family! We hope you enjoy
your BHS-630.
If there is anything we can be of
assistance with, feel free to drop us
a line to the email below:
support@phaiser.com
FCC ID: 2AGY3BHS630
© 2018 Phaiser
Phaiser LLC, 909 Silber RD APT 59,
Houston, TX 77024-3636, United States
© 2018 Liquipel
Liquipel is a registered trademark of Liquipel IP LLC
© 2018 Hearing Components
Comply is a registered trademark of Hearing Components
Made in China
www.phaiser.com
V1.0
ZONE
BHS-630
Customer Service
support@phaiser.com
Loading...
