haiser
TM
BLADE
BHS-430
USER MANUAL
The BHS-430 is more than just a Bluetooth
headset. While providing best all day wearing comfort it lets you listen to your favorite
tunes in premium stereo quality, keeping you
connected to the world at all times.
By connecting to your phone or tablet
through Bluetooth instead of cables, this
headset saves you lots of hassle and
supports your active lifestyle wherever you
go.
The BHS-430 employs Nanocoating-Technology to safeguard itself against Sweat and
Moisture.
The BHS-430 complies with the Bluetooth
V4.1 Standard.
2
Plus button
Increase the volume,
Next Track
Minus button
Decrease the volume, Previous Track
Multifunction button
Play/Pause, On/Off,
Answer/Hang up
3
Product Features
1. Lightweight earhook design for best stability while working out.
2. Premium Speakers with strong Bass and
HD Stereo Music.
3. Extra long Playback and Standby time.
4. The easily operable buttons offer fun-
ctions for answering phone calls and
controlling audio playback.
4
Specifications
Bluetooth Specication: Bluetooth 4.1
Battery: Lithium Polymer Battery 3,7V
Standby Time: UP to 200 hours
Talk Time: UP to 7 hours
Music Playback Time: UP to 7 hours
Charging Time: Less Than 2 hours
Operating Temperature: 14°F/-10°C to
140°F/60°C
First Steps
To ensure best battery performance, it is
recommended to charge the headset fully
before first use.
Please open the charge-port-cover with
your fingernail and connect the USB-charging-cable. The LED will turn red to indicate
charging in progress. Once the headset is
fully charged, the LED will turn green.
5
Inserting the Comply™ Premium
Earphone Tip
1. Squeeze down the foam
tip and roll the tip into a
thin, round cylinder.
2. Pull back and up on ear
to open the canal. Gently
insert the entire tip into
the ear.
3. Hold the tip in place until
it expands
6
Installing the Comply Earphone
Replacement Tips
1. Remove the silicone tip
from the earphone.
2. Clean the earphone
nozzle of any debris with
a dry cloth.
3. Insert the earphone
sound port nozzle into
the tip‘s core at an angle.
Then push the rest of
thetip onto the earphone‘s nozzle.
4. Repeat for the other side
7
Note regarding the functions described
in this manual: Not all phones or other
connected Bluetooth devices support every
function. For further information, please refer
to your device’s user manual.
Pairing
Before using the headset for the first time,
you must pair it with another Bluetooth-enabled device (for example a phone). The
headset will automatically enter pairing
mode after you power it on and become
visible to other devices.
1. Put the earphones in your ears and keep
the multifunction button pressed for 3
seconds. You will hear the audio message
“Power On”. While the LED is constantly
green, the headset is in pairing mode.
2. On your phone find the Bluetooth menu
and “search for” or “add” new devices.
Select “BHS-430” from the list and pair it.
3. Once the headset is successfully connected to your phone, you will hear the audio
message “Connected”.
8
Additional Pairing Notes
1. If asked for the Pass/PIN code, please
enter “0000” or “1234”. Newer phones do
not require this.
2. Some phones may ask permission to access the phone contact list. If you receive
this message on your phone, please select
“OK” or “allow access”.
3. The headset will automatically turn off if
not paired within 5 minutes.
Manual Pairing, Pairing with a
second device or Re-Pairing:
1. Press and hold the “+” (plus button) on
the right earpiece for 2 seconds while
the headset is turned on, connected and
neither a call nor music are active. You will
hear the audio message “Disconnected”
(The original connection will be lost while
in pairing mode).
2. Search the Bluetooth menu of your device for “BHS-430” and complete above
regular pairing steps until successfully
connected.
9
Multipoint
This headset is capable of connecting with
2 devices at the same time, enabling you to
use the headset with both devices simultaneously.
A common application, for example, is to
connect your smart phone and your tablet.
You will be able to enjoy media on your
tablet while not missing phone calls from
your phone.
Note: The headset can use the multifunction button functions only for the primary
handset. The second device connected to
the headset will be the primary device where
the button works.
1. Pair the headset with the device which
will NOT be used for calling according to
the instructions on under “Pairing” (Turn
the headset on and select “BHS-430” in
the Bluetooth menu). This device will be
the secondary device.
2. Pair the headset with the primary device
according to the instructions under “manual pairing” (press and hold “+” button
for 2 seconds). This device will be the
primary device where all functions for the
multifunction button work by default.
3. Once you paired and connected the
primary device, go back to the secondary
10
device and connect the headset again
through the device’s Bluetooth menu.
You will hear the voice confirmation
“Connected”.
Additionally you can use the manual
pairing method when you already have 2
devices connected to the headset and like
to connect the headset to a third, different
device instead.
Of course you can reconnect one of the 2
previously connected devices again through
its Bluetooth menu to use Multipoint functions again.
Auto Reconnect
1. If you turn the headset off, it will be
disconnected from your phone. It will
automatically attempt to reconnect once
turned back on and in range.
2. A secondary device must be reconnected
through the Bluetooth-menu by selecting
“BHS-430”.
11
Out Of Range
1. If headset and phone are separated by
more than 10 meters (33 feet), they will
disconnect. The headset will alert you by
playing the link loss tones.
2. In case headset and phone do not automatically reconnect once back in range,
briefly press the multifunction button on
the right earphone to manually reconnect.
You can also use manual reconnect to
abort pairing mode and connect to the
last connected device.
3. While you are in multi connection mode,
a device which goes out of range, will lose
connection. The headset will notify you
by playing the link loss tones. The headset
will not try to reconnect to the lost device.
4. In case you intentionally switched off the
Bluetooth function on a single connected
device and hear the “Disconnected” message, you can immediately go to the Bluetooth menu of your other device (phone
or tablet) to connect the headset by using
the regular pairing steps described earlier.
The headset will become visible to other
devices as soon as all connections are
dropped or it’s forced to pairing mode by
pressing and holding the “+” button for 2
seconds while connected and not using.
12
ON / OFF-Function
Keep the multifunction button on the right
earphone pressed for 3 seconds to turn on
the headset. You will hear the audio message
“Power On”. To turn off the headset, press
and hold the middle button on the right
earphone for 3 seconds until you hear the
“Power Off” message.
In case you move out of range from your
headset or turn off Bluetooth on your phone,
the headset will turn off automatically after
5 minutes.
13
Charging the Headset
Just open the charging port cover on the
left earphone marked with a USB symbol
and plug in the USB charger cable. You
can either choose to use a dedicated wall
charger with USB ports (like a mobile phone
charger), your computers USB ports or basically any powered USB port. Once you start
charging the indicator-LED will be constantly
red. After the charge is complete, the LED
will change to a constant green.
Answering Calls
As soon as you have an incoming phone call,
the headset will notify you by ringtone and
read the phone number of the caller to you.
To answer, briefly press the multifunction
button on the right earphone or answer the
call on your phone. The call will be transferred to your headset if not set differently in
your phone.
14
Refusing Calls
To refuse a call, double press the multifunction button and the call will be rejected. You
will hear a confirmation tone.
Ending Calls
To end a call, press the multifunction button
briefly or end the call through your phone.
15
Volume Control
By briefly pressing “+” (plus button) you
can increase the volume and by pressing “-”
(minus button) you can decrease it. When
volume reaches maximum or minimum, you
will hear a warning tone. Warning: Listening
to music on a high volume over a longer
period of time may damage your hearing
ability.
Voice Dialing
Double press the multifunction button to
activate your phone’s Voice-Dial function
and say the name of the person you want to
call. Please be sure to have an audio sample
stored in your phone before using this
feature. Also it is necessary that your phone
supports this feature and that it is turned on.
Please refer to your phones user manual for
further information.
Play / Pause
During media playback you can press the
multifunction button briefly to start, pause
or resume playback. It is also possible to use
your phone’s media player to control this
function.
16
Next / Previous Track
During media playback you can skip between tracks by double pressing the “+” (plus
button) for “Next Track” or double pressing
“-” (minus button) for “Previous Track”.
Fast Forward / Rewind
During media playback you can fast forward
by pressing and holding the “+” (plus
button). When you arrive at your desired
position, release the button and normal
playback will resume.
To rewind a track, use the “-” (minus button)
in the same way. It is necessary for your
media player to support this feature.
Equalizer Settings
In case you want to change the way the
headset reproduces music from your device,
press and hold “+” and “-“ at the same time
until you hear a beep. This will change the
equalizer setting. There are 3 equalizer
settings available: “Normal” (default), “Bass”
and “Treble”. Try them out to find the most
suitable one for your preferred music style.
17
Battery Status Notification
Every time you turn the headset on, you will
hear the battery status notification. There are
3 battery levels reported:
“Battery High”: 100% to 66% battery life
“Battery Medium”: 66% to 33% battery life
“Battery Low”: 33% to 0% battery life
While the headset is already turned on, you
can trigger the battery status notification
manually by briefly pressing “+” and “-” at
the same time.
The headset will start to report “Battery
Low” automatically, once the battery life
reaches 5 to 10 minutes before automatic
shutdown.
On iOS and some newer Android devices,
you will be able to see the battery level of
the headset in the upper right corner near
the Bluetooth-symbol.
18
Three Way Calling
To answer a second call coming in on either
of your connected devices without hanging
up the first call (putting the first caller on
hold), briefly press the multifunction button
while the second call is ringing.
To answer a second call and hang up the
active call, double press the multifunction
button while the second call is ringing.
To reject a second call, press and hold the
multifunction button for 1 second while the
call is ringing.
To switch between active and held call, putting the active call on hold, press and hold
the multifunction button for 1 second.
To hang up the active call, briefly press the
multifunction button.
Microphone Mute and Unmute
While on a call, press and hold the “-” button
for 2 seconds, until you hear the notification
tone, to mute the microphone. To unmute
the microphone, repeat this procedure.
19
Troubleshooting the headset
Issue: The headset does not work
Solution: Please make sure the headset is
turned on and charged.
Issue: Phone disconnects with headset
Solution: Make sure the phone supports the
Bluetooth Hands-Free Profile and is in range.
Issue: Headset does not work properly with
the phone
Solution: Pair phone and headset again,
make sure headset is in range (no obstacles
like other electronic devices or walls).
20
Avoiding Problems
- Please turn the headset off before putting
it into your bag or pocket to avoid accidental calls.
- Do not clean the headset with solvents or
abrasives.
- Do not expose the headset to extreme
temperature (not outside 14°F/-10°C to
140°F/60°C).
- Do not expose the headset to fire, the
battery may explode.
- Do not attempt to open the headset.
- Do not put heavy objects on your
headset.
- Avoid moisture and dust.
- Do not use the headset while swimming
or showering.
- For safe storage, please keep the headset
in a dry place.
- If stored longer than 1 month, please
recharge the battery before use.
21
Additional Information
Radio Frequency Exposure
This headset is a radio transmitter and receiver. It communicates with Bluetooth equipped devices by receiving and transmitting
radio frequency (RF) electromagnetic fields
(microwaves) in the frequency range 2.4 to
2.4835 Ghz. The output power of the head-
set is only 0,001 watt (low). The headset is
designed to comply with the RF exposure
guidelines and limits set by national and
international authorities and health agencies.
Potentially Explosive Atmosphere
If you enter a potentially explosive atmosphere, please make sure you turn off your
headset. Such areas are rare and in most
cases, but not always, clearly marked. It is
unlikely but possible that your device could
generate a spark and cause an explosion or
fire resulting in serious injury or death.
Avoiding Hearing Damage
Serious and permanent hearing damage and
even loss of hearing may occur if you use
your headset continuously at high volume.
Please be sure to set the volume to a safe
level. Using high volume continuously may
22
feel normal after some time but it can still
damage your hearing ability. In case you
experience ringing or muffed speech, do not
continue listening and have your hearing
checked. The higher the volume the sooner
your hearing may be affected. Hearing experts suggest that you protect your hearing.
It is better to use the headset only for a limited time at high volume. It is not suggested
to turn up the volume in noisy surroundings
to block out the noise. In case you cannot
hear people talking to you anymore, please
turn down the volume.
Please refer to earlier pages of this manual
on how to adjust the volume.
Headset Safety Information
In some areas it is illegal and generally it is
not recommended to use the headset for
listening to music while operating a vehicle.
You should be careful and attentive while
driving. Do not continue using the headset if
you find it distracts you while operating any
kind of vehicle or during any other activity
requiring your full attention.
23
BLADE
BHS-430
FCC ID: WTDG18
24
Loading...
