Pelco TXB-IP-P User Manual

INSTALLATION

TXB-IP Spectra® IV IP Communication Module

C3443M-B (7/09)

Regulatory Notices

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

RADIO AND TELEVISION INTERFERENCE

This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However there is no guarantee that the interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

• Consult the dealer or an experienced radio/TV technician for help.

You may also find helpful the following booklet, prepared by the FCC: “How to Identify and Resolve
Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Office,
Washington D.C. 20402.

Changes and modifications not expressly approved by the manufacturer or registrant of this equipment can
void your authority to operate this equipment under Federal Communications Commission’s rules.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

LEGAL NOTICE

SOME PELCO EQUIPMENT CONTAINS, AND THE SOFTWARE ENABLES, AUDIO/VISUAL AND RECORDING
CAPABILITIES, THE IMPROPER USE OF WHICH MAY SUBJECT YOU TO CIVIL AND CRIMINAL PENALTIES.
APPLICABLE LAWS REGARDING THE USE OF SUCH CAPABILITIES VARY BETWEEN JURISDICTIONS AND
MAY REQUIRE, AMONG OTHER THINGS, EXPRESS WRITTEN CONSENT FROM RECORDED SUBJECTS.
YOU ARE SOLELY RESPONSIBLE FOR INSURING STRICT COMPLIANCE WITH SUCH LAWS AND FOR
STRICT ADHERENCE TO ANY/ALL RIGHTS OF PRIVACY AND PERSONALTY. USE OF THIS EQUIPMENT
AND/OR SOFTWARE FOR ILLEGAL SURVEILLANCE OR MONITORING SHALL BE DEEMED UNAUTHORIZED
USE IN VIOLATION OF THE END USER SOFTWARE AGREEMENT AND RESULT IN THE IMMEDIATE
TERMINATION OF YOUR LICENSE RIGHTS THEREUNDER.

OPEN SOURCE SOFTWARE NOTICE

This product includes certain open source or other software originated from third parties that is subject to
the GNU General Public License (GPL), GNU Library/Lesser General Public License (LGPL) and different
and/or additional copyright licenses, disclaimers and notices.

The exact terms of GPL, LGPL and some other licenses are provided to you with this product. Please refer
to the exact terms of the GPL and LGPL at www.fsf.org (Free Software Foundation) and
www.opensource.org (Open Source Initiative) regarding your rights under said license. You may obtain a
complete corresponding machine-readable copy of the source code of such software under the GPL or
LGPL by sending your request to [e-mail] and the subject line should read Source Code
Request. You will then receive a link in the e-mail for you to download the source code.

This offer is valid for a period of three (3) years from the date of the distribution of this product by Pelco.

2 C3443M-B (7/09)

Description

The TXB-IP allows Spectra® IV and Spectra IV SE dome systems to transfer live video and data over an
Internet protocol (IP) network. The IP module provides MJPEG and MPEG-4 compression for use with most
standard Web browsers. Once installed, the Spectra IV dome system retains all of the standard Spectra
features, while adding IP connectivity.

NOTE: The TXB-IP module is only compatible with Spectra IV dome systems that use version 1.07 or
newer software. Dome systems with software older than version 1.07 do not have the capability to
operate over an IP network.

MODELS

TXB-IP-F Spectra IV IP communication module for in-ceiling back boxes

TXB-IP-P Spectra IV IP communication module for pendant back boxes

Figure 1. TXB-IP-F

Figure 2. TXB-IP-P

C3443M-B (7/09) 3

Installation

PARTS LIST

Qty Description

1TXB-IP module
2 MAC address label
1 Resource Disk
1 TXB-IP Installation manual
1 Spectra IV IP Operation/Configuration manual
1 Device Utility Operation/Configuration manual

To access the back box PCB, use the following steps:

1. Turn off power to the dome system.

2. Remove the lower dome.

3. Remove the dome drive by pressing in the blue and red tabs on the sides of the dome drive. Gently
rock the dome drive to release the blue tab first, and then release the red tab.

4. Open the hinged door to the box. Push the tab lock towards the back box wall of the unit and open
the door (refer to Figure 3).

Figure 3. Spectra IV Back Box Interconnect Door

4 C3443M-B (7/09)

INSTALLING THE TXB-IP

+-

Figure 4. Installing the TXB-IP

ì

Shorting Plug

î

16-Pin Connector

ï

Heat Sink Standoff

ñ

Captive Screw

ó

Standoff

r

Video UTP Cable

To install the TXB-IP into the back box, use the following steps (refer to Figure 4):

WARNING: The TXB-IP-F is intended for use only with in-ceiling back boxes. The TXB-IP-P is
intended for use only with pendant back boxes. If a TXB-IP-F is installed in a pendant back box, the
unit will overheat and you will void the warranty. If a TXB-IP-P is installed in an in-ceiling back box,
the unit will be damaged and you will void the warranty. Refer to Figure 1 and Figure 2 on page 3.

1. Ensure that you are installing the correct model TXB-IP into the appropriate in-ceiling or pendant
model back box.

2. If you plan to use the audio functions, install your audio UTP cables into the audio line-in and
line-out connectors on the TXB-IP.

NOTES:

• To take full advantage of the UTP distance and noise immunity benefits, you must use a 600-

ohm impedance matching transformer (refer to Figure 5 on page 7).

• A stable power supply is required for optimal audio performance.

C3443M-B (7/09) 5

s

UTP Connector

t

Audio Connectors

u

Video Coaxial Cable

~í

Ethernet Cable

~â

RJ-45 Coupler

Figure 5. Audio Connections

ì

Microphone

î

Amplifier

ï

600-Ohm Impedance Matching TransformersAmplifier

ñ

Line-In Audio UTP Cable

3. Install the video unsheilded twisted pair (UTP) cable into the UTP connector:

a. For ease of installation, remove the video UTP cable from the TXB-IP.

b. Plug the exposed wires of the video UTP cable into the UTP connector on the back box circuit

board. Insert the blue wire into the positive terminal, and then insert the gray wire into the
negative terminal.

c. Plug the video UTP cable back into the TXB-IP.

4. Remove the shorting plug from the 16-pin connector located on the back box circuit board.

6 C3443M-B (7/09)

ó

Line-Out Audio UTP Cable

r

600-Ohm Impedance Matching Transformer

t

Speaker

5. Insert the TXB-IP module into the 16-pin connector located on the back box circuit board. Secure the
module to the standoff on the circuit board using the captive screw on the TXB-IP module.

6. Plug your network Ethernet cable into the RJ-45 coupler to connect the Spectra IV dome system to
your existing network.

WARNING: An electrical short in the back box may occur if the metal BNC connector on the video
coaxial cable is not completely covered by the protective boot.

7. If you plan to view video using both analog and IP connections, connect the video coaxial cable from
the back box circuit board to the coaxial cable coming in from the outside. Make sure that the BNC
connector is completely covered by the protective boot.

If you plan to only view video using the IP connection, make sure that the BNC connector is completely
covered by the protective boot and is out of the way of the back box door.

8. Before closing the interconnect door, ensure that no wires are between the top of the heat sink
standoff and the back box. Both the video coaxial cable and the Ethernet cable need to be routed
carefully to ensure clearance for the heat sink standoff. Refer to Figure 6.

9. Close the interconnect door. Snap the tab lock into place.

Figure 6. Routing the Cables

ì

RJ-45 Coupler

î

Ethernet Cable

ï

Video Coaxial Cable

C3443M-B (7/09) 7

INSTALLING THE DOME DRIVE

NOTE: For complete installation instructions, refer to the installation manual supplied with the Spectra IV

back box.

1. If you plan to view video using both analog and IP connections, set the DIP switches on the top of
the Spectra IV dome drive. For DIP switch settings, refer to the labels located on the top of the dome
drive, or refer to Switch Settings in the Installation/Operation manual shipped with the dome drive.
If you plan to only view video using the IP connection, you do not need to set the DIP switches.

2. Install the dome drive (refer to Figure 7). Line up the blue and red tabs with the blue and red labels.
When pushing the tabs in, insert the red tab first, and then the blue tab. Continue pushing on the
ends of the tabs until both tabs click into place.

Figure 7. Spectra IV Dome Drive Installation

3. Install the lower dome.

4. Apply power to the system.

8 C3443M-B (7/09)

Troubleshooting

If the following instructions fail to solve your problem, contact Pelco Product Support at 1-800-289-9100
(USA and Canada) or [phone] (international) for assistance. Be sure to have the serial number
available when calling.

Do not try to repair the unit yourself. Leave maintenance and repairs to qualified technical personnel.

Symptom Possible Cause Suggested Solution

No video is displayed. Power is not connected. Check the power connector.

Spectra IV information (model,
firmware, Pelco P and D
protocol addresses, and
communication settings) does
not appear after the
configuration cycle.

The unit does not respond to
commands.

The displayed video is
scrambled.

The audio signal is weak. You are not using the correct

There is an echo when audio is
received.

Video cable is not connected. Check the video connector.
Video UTP cable is not

connected.
TXB-IP module is not inserted

properly.

The unit cannot complete its
configuration cycle.

Make sure your switches are
set to the proper settings.

Video UTP wires are incorrectly
installed.

type of transformer.

The wiring distance connecting
the audio equipment may be
too long.

The gain is not properly
adjusted.

The speaker volume is too high. Lower the speaker volume.
The microphone and the

speaker are too close together.

Your call station does not have
built-in echo cancellation.

Check the UTP connector.

Reinstall the TXB-IP module.
Make sure the pins on the
module are inserted correctly.
Refer to Troubleshooting in the
Installation/Operation manual
shipped with the Spectra IV
dome drive.

Check all DIP switch settings
on the dome drive.

Verify that the video UTP cable
is wired correctly to the UTP
connector on the back box
circuit board. The blue wire
should be connected to the
positive terminal, and the gray
wire should be connected to
the negative terminal. Refer to
Figure 4 on page 5.
Be sure you are using a 600­ohm impedance matching
transformer

Test the equipment using a
shorter wiring distance.

If you are using an external
amplifier and it has an
adjustable gain, increase the
gain until the signal is
acceptable.

If your call station does not
have built-in echo cancellation,
move the microphone and
speaker farther apart.

Use a call station with built-in
echo cancellation.

C3443M-B (7/09) 9

REVISION HISTORY

Manual # Date Comments

C3443M 5/08 Original version.
C3443M-A 10/08 Added audio line-in information per CN21948.
C3443M-B 7/09 Added full-duplex audio information.

Pelco, the Pelco logo, Camclosure, Digital Sent ry, Endura, Esprit, ExSite, Genex, Intelli-M, Legacy, and Spectra are registered tradem arks of Pelco, Inc.
Spectra III is a trademark of Pelco, Inc.
DLP is a registered trademark of Texas Instruments Incorporated.
All product names and services identified t hroughout this document are trademarks or registered trademarks of their respective companies.
The absence of a trademark or registered trad emark from this document does not constitute a waiver of intellectual property rights.
© Copyright 2009, Pelco, Inc. All rights reserve d.

10 C3443M-B (7/09)

PRODUCT WARRANTY AND RETURN INFORMATION

WARRANTY

Pelco will repair or replace, without charge, an y merchandise proved defective in material or workmanship for a period of one year after the date of
shipment.

Exceptions to this warranty are as noted below:

• Five years:
– Fiber optic products
– TW3 000 Series unshielded twisted pair (UTP) transmission products
– CC370 1H-2, CC3701H-2X, CC3751H-2, CC3651H-2X, MC3651H-2, and MC3651H-2X camera models

• Three years:
– Pe lco-branded fixed camera models (CCC1390H Series, C10DN Series, C10CH Series, IP3701H Series, and IX Series)
– EH150 0 Series enclosures

®

– Spectra

IV products (including Spectra IV IP)

– Cam closure
– DX Se ries digital video recorders, DVR5100 Series digital video recorders, Digital Sentry

– En dura
– Ge nex® Series products (multiplexers, server, and keyboard)
– PMCL200/300/400 Series LCD monitors

• Two years:
– S tandard varifocal, fixed focal, and motorized zoom lenses.
– DF5/DF8 Series fixed dom e products
– Lega cy® Series integrated positioning systems
– Spectra III™, Spectra Mini, Spectra Mini IP, Esprit®, ExSite®, and PS20 scanners, including when u sed in continuous motion applications.
– Espr it Ti and TI2500 Series thermal imaging products
– Espr it and WW5700 Series window wiper (excluding wiper blades).
– CM 6700/CM6800/CM9700 Series matrix
– Di gital Light Processing (DLP®) displays (except lamp and color wheel). The lamp and color wheel will be covered for a period of 90 days.

– Inte lli-M

•One year:
– Video cassette record ers (VCRs), except video heads. Video heads will be covered for a period of six months.

• Six months:
– Al l pan and tilts, scanners, or preset lenses used in continuous motion applicatio ns (preset scan, tour, and auto scan modes).

Pelco will warrant all replacement parts and repairs for 90 days from the date of Pelco shipment. All goods requiring warranty repair shall be sent
freight prepaid to a Pelco designated locatio n. Repairs made necessary by reason of misuse, alteration, normal wear, or accident are no t covered under
this warranty.

Pelco assumes no risk and shall be subject to no li ability for damages or loss resulting from the specific use or application made of the Products.
Pelco’s liability for any claim, whether based on breach of contract, negligence, infringement of any rights of any party or product liability, relating to
the Products shall not exceed the price paid by the Dealer to Pelco for such Products. In no event will Pelco be liable for any special, incidental, or
consequential damages (including loss of use, loss of profit, and claims of third parties) however caused, whether by the negligence of Pelco or
otherwise.

The above warranty provides the Dealer with spe cific legal rights. The Dealer may also have additional right s, which are subject to variation from state
to state.

If a warranty repair is required, the Dealer must contact Pelco at [phone] or [phone] to obtain a Repair Authorization n umber (RA), and
provide the following information:

1. Model and serial number

2. Date of shipment, P.O. number, sales order number, or Pelco invoice number

3. Details of the defect or problem

If there is a dispute regarding the warranty of a product that does not fall un der the warranty conditions stated above, please include a written
explanation with the product wh en returned.

Method of return shipment shall be the same or equal to the method by which the item was received by Pelco.

RETURNS

To expedite parts returned for repair or credit, please call Pelco at [phone] or [phone] to obtain an authorization number (CA number if
returned for credit, and RA number if returned for repair) and designated return location.

All merchandise returned for credit may be subject to a 20 percent restocking and refurbishing charge.

Goods returned for repair or credit should be clearly identified with the assigned CA or RA number and freight should be prepaid

®

Series (IS, ICS, IP) integrated camera systems

recorders, and NVR300 Series network video r ecorders

®

Series distributed network-based video pro ducts

The air filter is not covered under warranty.

®

eIDC controllers

®

Series hardware products, DVX Series digital vide o

12-23-08

www.pelco.com

Pelco, Inc. Worldwide Headquarters 3500 Pelco Way Clovis, California 93612 USA

USA & Canada Tel [phone] Fax [phone]

International Tel [phone] Fax [phone]
