ExSite® Enhanced 2 Explosionproof Fixed Compact Camera System
Product Specification, camera solutions
ExSite®Enhanced 2
Explosionproof Fixed Compact Camera System
Product Features
l
Up to 3200 x 1800 Resolution Wide Dynamic
Range (WDR)
l
Multi-Stream H.264 and H.265 IP Video with
Smart Compression
l
Rated to Operate from -40 °C to +65 °C or +70
°C (-40 °F to 149 °F or 158 °F), with ambient
convection
l
AISI 316L Stainless Steel Electro Polished
Construction
l
Standard IP Ethernet Connection
l
Full Suite of Built-In Analytics
l
Onvif Profiles S, G, and T Conformant
l
Certifications: FCC Part 15, CE, cULus, ICES-003, RCM, BIS
l
Hazardous Location Certifications: IECEx, ATEX, INMETRO, EAC Ex, cULus, UKEx, KCs
Camera System
ExSite® Enhanced 2 Series is purpose-built to monitor operations and control processes in hazardous
locations with risks of explosion due to the presence of flammable liquids, gases or dust. Rugged outdoor
cameras available in fixed, fixed compact, and PTZ, it meets stringent explosion proof and dust-ignition
proof requirements while complying with international standards (IECEx, ATEX, INMETRO, EAC Ex,
cULus, UKEx, KCs).
It provides to operators crisp and clear evidence with zoom, with true WDR, and low light capabilities for
challenging lighting conditions common to hazardous areas. The ExSite® Enhanced 2 Series is built to
survive in the harshest conditions, rated IP69 it protects from water, high wind, high and low
temperatures with an operating range of -40°to +65°C or +70°C. It is also resistant to corrosive
elements.
ExSite® Enhanced 2 Series cameras are easy to install and adaptable to most operational needs.
ExSite® Enhanced 2 Series cameras support a range of input power options. ExSite® Enhanced 2
Series cameras also come standard with sun shrouds, capturing desired video regardless of the
weather.
The ExSite® Enhanced 2 Series provides industry-leading image quality using a Full HD 1080p camera
producing up to 60 images per second. The camera’s image defog capability increases video quality in
poor visibility conditions and 3D noise filtering is available.
Video
ExSite® Enhanced 2 Series cameras provide flexible streaming options. The primary stream can be
compressed with efficient H.265, H.264 High or Main profiles, or MJPEG formats. It can be configured to
C5057S-B | 02/23
1
ExSite® Enhanced 2 Explosionproof Fixed Compact Camera System
Product Specification, camera solutions
a variety of frame rates and variable bit rates to optimize image quality with bandwidth and storage
efficiency. Smart Compression is available on both H.264 and H.265, minimizing storage and bandwidth
utilization.
Open and Integrated
ExSite® Enhanced 2 Series cameras seamlessly connect to Pelco video management systems such as
VideoXpert®. ExSite® Enhanced 2 Series cameras integrate with major third-party systems through the
ONVIF Profile S, Profile G, and Profile T standards.
Standard Web Interface
Pelco cameras use a standard Web browser interface for easy remote setup and administration.
Controls are optimized for convenient one-step camera configuration for features including color,
exposure, flicker control, backlight compensation, and streaming.
Pelco Analytics
ExSite® Enhanced 2 Series cameras feature Pelco’s most advanced analytics technology.
Basic Analytics
ExSite® Enhanced 2 Series cameras feature basic video analytics including Simple Motion Detection
and Camera Sabotage.
Simple Motion Detection: These algorithms allow the camera to record or send an alarm when there is
motion detected in a selected zone or with the entire scene.
Camera Sabotage: An alarm is triggered if the lens is obstructed or when the camera is repositioned.
Pelco Smart Analytics
Pelco Smart Analytics uses object detection AI technologies delivering improved accuracy in both
perimeter protection and in crowded, indoor environments. Added processing power enables the
tracking and classification of over 50 objects. Objects are classified even when they remain stationary.
Pelco Smart Analytics go beyond people and vehicles to include car, truck, bus, motorcycle, and bicycle
classification. Ten different object behaviors can be recognized to create events integrated with many
VMS systems.
Objects Detected Behavior Events
People Objects in Area Objects Enter Area
Vehicles with
Classification
Object Loitering Objects Leave Area
Objects Crossing Beam Object Stops in Area
Object Appears or Enters Area Direction Violated
Object Not Present in Area
Objects in Area: The event is triggered when the selected object type moves into the region of interest.
Object Loitering: The event is triggered when the selected object type moves into the region of interest
and then stays for an extended amount of time.
C5057S-B | 02/23
2
ExSite® Enhanced 2 Explosionproof Fixed Compact Camera System
Product Specification, camera solutions
Objects Crossing Beam: The event is triggered when the specified number of objects have crossed the
directional beam that is configured over the camera’s field of view. The beam can be unidirectional or
bidirectional.
Object Appears or Enters Area: The event is triggered by each object that enters the region of interest.
This event can be used to count objects.
Object Not Present in Area: The event is triggered when no objects are present in the region of
interest.
Objects Enter Area: The event is triggered when the specified number of objects have entered the
region of interest.
Objects Leave Area: The event is triggered when the specified number of objects have left the region of
interest.
Object Stops in Area: The event is triggered when an object moves into a region of interest and then
stops moving for the specified threshold time.
Direction Violated: The event is triggered when an object moves in the prohibited direction of travel.
Pelco's Smart Compression Technology
Pelco’s Smart Compression Technology lowers bandwidth and storage requirements by up to 70%,
while reducing storage requirements. Our technology allows the user to make informed optimization
between storage savings and image quality.
Pelco’s Smart Compression Technology dynamically analyzes motion occurring within live video in realtime, to intelligently compress the information you don’t need, while retaining details with clear quality in
the areas that are important in the scene. By enabling Dynamic GOP, an added feature of Smart
Compression, the number of I-frames are automatically reduced in scenes with low motion. Based on the
complexity of scenes and motion occurring, such as a store room that has limited entry and exit, up to
70% bandwidth savings can be achieved.
Technical Specifications
Camera/Optics
Item Description
Resolution
Sensor Type
Maximum Resolution (H x
V) and Aspect Ratio
Dynamic Range
WDROff 85 dB
6.0 MP
1/1.8” progressive scan CMOS
(16:9) 3200 × 1800
WDROn
Active Noise Filtering 3DNoise Filtering
Lens
Horizontal Angle of View
C5057S-B | 02/23
Up to 120 dB
F1.8, 4.9-8 mm remote focus and zoom
(16:9) 50°-91°
3
ExSite® Enhanced 2 Explosionproof Fixed Compact Camera System
Product Specification, camera solutions
Item Description
Vertical Angle of View
Light Sensitivity
Iris Control P-Iris, Automatic, Open, Closed
Shutter Range Automatic, Manual (1/7 to 1/8,196 sec)
Day/Night Capabilities Mechanical IR cut filter. Automatic, Manual
Flicker Correction 60 Hz, 50 Hz
White Balance Automatic, Manual
Backlight Compensation Adjustable
(16:9) 29°-51°
Color (33 ms); 0.055 lux
Mono (33 ms); 0.028 lux
Video
Item Description
Frame Rate 25/30 fps @50/60Hz
Video Encoding H.264, H.265
Video Streams Multi-stream H.264, Multi-stream H.265, Motion JPEG
Pelco
Smart Compression, Motion JPEG
Software Features
Item Description
Smart Compression
Technology
On Screen Displays Yes
Privacy Zones Up to 64 zones
Yes, lowers bandwidth and storage requirements by up to 70%.
Network
Item Description
Open API ONVIF compliance version 1.02, 2.00, Profile S, Profile G, and Profile T
(www.onvif.org)
Security Password protection, HTTPS encryption, digest authentication, WS
authentication, user access log, 802.1x port based authentication
Supported Protocols
IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP,
UDP, IGMP, ICMP, DHCP, Zeroconf, ARP, SNMP v2c, SNMP v3
C5057S-B | 02/23
4
