PRODUCT SPECIFICATION
Evolution 12
360° Stainless Steel Camera
The next step in 360° total situational awareness
12MP sensor and no moving parts
12MP high-resolution sensor
• Up to 30 fps at 2.0 MP
• 0.1 lux minimum illumination
• Constant 360° surveillance with no blind spots
• No moving parts, no maintenance and silent operation
• PoE or 12 VDC powered
• 3-years warranty
Advanced features
• Local SD card slot for event recording
• Configurable privacy regions
• Polygonal video motion detection regions
• Local alarm digital input and output
• Audio microphone input
Uniquely suited for demanding environments
• Electropolished marine grade 316 stainless steel
• Withstands high pressure washes and corrosion
• IP66, IP67, IP68, IP69K and NEMA Type 4X & 6P rated for dust
and water protection
• IK10+ rated for vandalism protection
• Certified by NSF to NSF/ANSI Standard 169
• HCV EU marked for HACCP environments
• Surface and pendant mounting options available with matching
stainless steel accessories
Applications
• Food and processing areas
• Industrial and chemical plants
• Vehicle wash stations
• Ports and marine applications
• High end architecture
Model EVO-12-SS2-P
Extensive VMS/NVR platform integration
with Oncam SDK
• Market leading Oncam 3D dewarping software
• Full live and retrospective dewarping available
• Camera features are accessible through VMS platforms
• Simultaneous multiple video streams
• 10x digital zoom capability through client-side dewarping
• H.264 / MJPEG streaming with multiple quality levels
• Optimizes bandwidth and storage utilization
• Intuitive web-based interface for viewing and configuration
• Supported by major VMS / NVR systems
• ONVIF profile S conformant
International Standards
Organization Registered Firm;
ISO 9001 Quality System
C5011S Revised 30.08.19
TECHNICAL SPECIFICATION
General
Model
Lens Field of View 180º Horizontal, 180º Vertical
Image Sensor
Lens 185° / F2.0
Minimum Illumination 0.1 lux = 50 IRE F/2.0
Frame Rate
Video Motion Detection 8 configurable polygonal regions
External Input 1x contact input
External Output 1x contact output
Security Configurable password protection
Advanced Event Management Triggered by motion, external input or HTTP event, result configurable, external output,
FTP/SMTP upload and local recording
Networking TCP/IP, HTTP, DHCP, DNS, NTP, FTP, SMTP and RSTP
Privacy 10 configurable privacy regions
SD Card Built-in SD card slot. Supports cards up to 128 GB capacity. Speed class 10 or higher required.
Audio Connections Audio In through 3.5 mm jack, RTSP using G711 codec or ONVIF S
Audio Input Level Mic input level range is approximately 5 mV to 50 mV
Analog Video Out Test port for production, not available in normal operation
White Balance Range Auto White Balance (Range = approximately 2500 K ~ 8000 K)
EVO-12-SS2-P
12.4 MP, 4072 H x 3046 V pixels
and 1/2.3-inch Sony CMOS Sensor
30 fps for 2MP and ¼ MP resolution
14 fps for 6, and 4 MP resolution
12 fps for 9.6MP resolution
Video
Model
Video Stream 1 Codec H.264 in 9.6 MP, 6 MP, 4 MP, 2 MP
Video Stream 1 Compression Level Multi-levels of compression and frame rate adjustment
Video Stream 1 Pixel Resolution
Video Stream 2 Codec H.264 in ¼ MP
Video Stream 2 Compression Level Multi-levels of compression and frame rate adjustment
Video Stream 2 Pixel Resolution Fisheyes at: ¼ MP (544 x 512)
Video Stream 3 Codec MJPEG at ¼ MP
Video Stream 3 Compression Level Multi-levels of compression and frame rate adjustment
Video Stream 3 Pixel Resolution Fisheyes at: ¼ MP (544 x 512)
* VCam Stream 4, 5, 6, 7 Codec H.264
* VCam Stream 4, 5, 6, 7
Compression Level
* VCam Stream 4, 5, 6, 7
Pixel Resolution
Maximum Frame Rate 30 fps
Image Control
Image Enhancement Electronic WDR 60dB
PTZ Functionality 10x zoom with Oncam 3D client-side dewarping software
VMS / NVR Support Contact Oncam Sales for the supported VMS / NVR list
Web Browser Compatibility Internet Explorer 9, Edge 25, Firefox 23 and Chrome 29 or above. Plug-in required for full functionality
Unicast Up to 20 simultaneous users depending on the resolution settings
Multicast Supported for H.264 main camera stream
Bit Rate Control
* Video Stream 2 and VCams cannot be used simultaneously.
Settings: brightness / contrast / saturation / exposure compensation,
6 MP (2528 x 2376), 4 MP (2080 x 1960),
4x independent onboard dewarped VCams at
compression quality and wall / ceiling / table mount
EVO-12-SS2-P
Fisheyes at: 9.6 MP (3200 x 3000),
2 MP (1472 x 1384)
Multi-levels of compression and
frame rate adjustment
1 MP (1280 x 720), ¼ MP (640 x 480)
Constant Bit Rate Control and
Constant Quality Control
