Peg-Perego P3 User Manual [en, es, fr]

U.S.A./CANADA/AUSTRALIA
Instructions for use EN
Instrucciones de uso ES Notice dʼemploi FR
Pliko Lite
FINA0601I62
WARNING:
AVOID SERIOUS INJURY FROM FALLING OR SLIDING OUT. ALWAYS USE COMPLETE 5 POINT SEAT BELT.
21
A
3
OK
click
4
A
B
C
click
5 6
B
A
C
7 8
9
11
10
12
13
14
A
B
15
17
16
1
2
3
3
2
1
18
1
2
2019
21
3
22
23
24
A
A
B
2625
27 28
29
30
GM
Ganciomatic
System
GM
Ganciomatic
System
GM
Ganciomatic
A
B
System
31 32 Pliko P3+Primo Viaggio
33 Accessory
45 Accessory
34 Accessory
35 Accessory 36 Accessory
15
Pliko Lite
16
18
17
1
3
4
5
6
2
20
19
10
7
8
9
11
12
13
14
Pliko Lite
1 ARPI0398L65NGR• 2 IRTR0007GR 3 SPST5846DGR SPST5846SGR 4 SPST5352GR 5 ASPI0043DN ASPI0043SN 6 SAPI5375JNGR• 7 ARPI0277NGR 8 SPST4023N 9 SAPI5753GRN 10 SPST5468N 11 MMRP0718 12 SAPI5368JNGR 13 SAPI5365NGR 14 ARPI0359L31NUK 15 ARPI0358N 16 BCAPLI• 17 BSAPLI• 18 BRSPPL• 19 ERSHPC• 20 MUCI5P16•
EN• Spare parts available in different colours to be specified
when ordering.
ES• Repuestos disponibles en otros colores que se especificarán
en el pedido.
FR• Pièces de rechange disponibles en plusieurs couleurs à
spécifier dans la demande.
EN•ENGLISH
• IMPORTANT: read the instructions carefully before using the stroller. Save the instructions for future reference.
• PEG PEREGO reserves the right to make any necessary changes or improvements to the products shown at any time without notice.
CUSTOMER SERVICE
If parts of the model are accidentally lost or damaged, use only original Peg Perego spare parts. Contact the Peg Perego Customer Service for all repair work, replacements, information about products, and sale of original spare parts and accessories, at the following:
USA: tel.: 800.671.1701 fax: 260.471.6332 Call us toll free: 1.800.671.1701
on the inside of the handle, in line with the raised surface.
9• Slide the clamp in the drink-holder until
it clicks.
Do not put hot drinks in the drink-holder,
nor items weighing more than 1 kg (2.2 lbs).
HOOD
The hood comes with a zipper, for attaching the zip-on rain canopy or mosquito netting (see Accessories Line).
10• To mount the hood, push the fittings
down until they click, as shown in the figure.
11• As shown in the figure, button the hood
inside the armrest and the backrest of the stroller.
12• To stretch out the hood, push the
coupling downward. The hood can be reclined by following the inclination of the backrest.
13• To remove the hood, you must unbutton
it from the stroller, loosen the couplings and raise the tabs of the fasteners, pushing towards the inside of the stroller.
CANADA: tel.: 905.839.3371 fax: 905.839.9542 Call us toll free: 1.800.661.5050
www.pegperego.com
INSTRUCTIONS FOR USE
OPENING 1• Before opening the stroller remove the
two protective caps from the hooks as shown in the figure. Otherwise, the stroller will not open correctly.
2• To open the stroller, pull up the two
levers on the handles and
3• at the same time, lift the stroller, which
will open automatically. To make sure that the stroller has been set up correctly, check the two side hooks (see figure).
ASSEMBLYING THE STROLLER 4• To mount the front wheels, lower Lever
A and slip the wheels onto the axle, as shown in the figure. Press until the wheels click into place.
5• To mount the rear wheels, slip the wheels
onto the axle, as shown in the figure. Press until the wheels click into place.
6• To mount the basket, slide the slots onto
the front hooks A and the rear hooks B
and C. 7• The figure shows the mounted basket. 8• The drink-holder can be attached to the
left or the right handle of the stroller,
using the two bands.
To attach the drink-holder to the handle,
widen the band, keeping the shaped side
BRAKE 14• To apply the brakes, push down with
one foot the bars on the rear wheels, as shown in the figure. To release the brakes, draw the bar up. Always set the brakes on the stroller when it is not in motion.
SAFETY BELT 15• A: Make sure that the brace is properly
inserted by pushing as shown in the figure. B: Fasten the belt as shown in the figure.
16• To unfasten the belt, press on the buckle
sides and pull out the waist strap.
ADJUSTING THE FOOTBOARD 17• The footboard can be adjusted to
three different positions. To lower the footboard, pull the two small levers downward while lowering. To lift the footboard, pull it up until it clicks into place.
ADJUSTING THE BACKREST 18• The backrest can be lowered to three
different positions. To lower the backrest, pull the two adjustment levers towards you. To raise it, pull the backrest upwards.
SWIVELLING WHEELS 19• To make the front wheels swivel, push
down as shown in the figure. To fix the wheels, pull up the lever.
CLOSING Before closing the stroller, loosen the
braces if the hood is attached, and raise
the backrest if it is lowered. 20• The stroller can be closed with one hand:
pull first one lever up and then the other
until it releases. 21• Grip the central handle and pull it upward
until it closes, as shown in the figure. 22• Verify the correct closing of the stroller
from the safety hook. The folded stroller
can stand upright.
TRANSPORT 23• The stroller can easily be carried (lock the
swivelling front wheels) by gripping the
central handle, as shown in the figure. 24• You can also use the side handle to carry
it, as shown in the figure.
REMOVABLE LINING 25• To remove the lining from the stroller,
slip the leg divider off the safety belt
from under the seat. Loosen the fabric
sack buttons from the seat, and slip the
sack off the hooks on the footboard. 26• Slip the safety belt buckles off the back of
the backrest, and remove the straps from
the two shoulder fasteners. 27• The shoulder fasteners are attached to
each other. To remove them, slip them
out through the openings in the fabric
sack, as shown in the figure. 28• Loosen the buttons on the side of the
fabric sack, as shown in the figure. 29• Loosen the safety belt on one side only,
as shown in the figure, holding your
finger under the nut. Slip the loosened
safety belt off the stroller through the
opening in the fabric sack, as shown in
the figure.
To remount the fabric sack on the
stroller, follow the directions given above
in the reverse order, making sure to
fasten the safety belt properly.
GANCIOMATIC SYSTEM
The Ganciomatic System is the swift, practical system that allows one to fasten to the stroller, with Ganciomatic fasteners, the car seat Primo Viaggio, which can be bought separately and is also equipped with Ganciomatic System. Primo Viaggio can be detached from its base (which stays in the car) and attached to the Ganciomatic fasteners of the stroller to transport your child without disturbing him/her.
PLIKO LITE + PRIMO VIAGGIO
32• To fasten the car seat to the stroller:
- set the brake on the stroller;
- remove the hood from the stroller;
- completely lower the backrest on the stroller;
- lift the footboard on the stroller to the highest position;
- raise the Ganciomatic hooks on the stroller;
- turn the child car seat towards the backrest on the stroller, lining up the front hooks on the car seat with the hooks on the stroller. Push the car seat downwards until it clicks into place.
See the userʼs manual for instructions on how to detach the car seat from the stroller.
ACCESSORY LINE
33• Diaper-Changing Bag: Satchel with pad
for changing babyʼs diaper. Attaches to the stroller.
34• Rain Canopy: Rain canopy zips onto the
hood. Mosquito Netting: Mosquito netting zips
35•
onto the hood.
36• Travel Bag: Practical duffle bag for
transporting the stroller by plane.
CLEANING & MAINTENANCE
Your product requires only minimal maintenance. Cleaning and maintenance operations must be performed only by adults.
• Be sure to keep all moving parts clean,
lubricating them with light oil if necessary.
• Dry off metal parts to prevent rusting.
• Regularly clean the plastic parts with a
damp cloth. Do not use solvents or similar products.
• Brush the fabric parts to remove dust.
• Remove any dust and sand from the wheels.
• Protect the product against smog, water,
rain and snow. Continued and extended exposure to sunlight can change the colours of many materials.
• Store the product in a dry area.
• To wash the sack, follow the instructions
below.
STROLLER GANCIOMATIC HOOKS
30• To raise the Ganciomatic hooks on the
stroller, pull the sack up at the corners of the seat and turn the two hooks upwards until they click into place.
31• To lower the Ganciomatic hooks on the
stroller, pull the little lever outwards and turn the hooks upwards at the same time, as shown in the figure.
WARNING
• THIS PRODUCT IS DESIGNED FOR
CHILDREN WHOSE MAXIMUM WEIGHT IS 40 POUNDS (18 KG) AND WHOSE MAXIMUM HEIGHT IS 43 INCHES (110 CM). THIS
SHOPPER BASKET IS DESIGNED TO CARRY A MAXIMUM WEIGHT OF 11 POUNDS (5 KG). ANY CUPHOLDER EVENTUALLY PROVIDED WITH THIS UNIT IS DESIGNED TO CARRY A MAXIMUM WEIGHT SPECIFIED ON THE CUPHOLDER ITSELF. ANY POACH OR POCKET PROVIDED WITH THIS UNIT IS DESIGNED TO CARRY A MAXIMUM WEIGHT OF
0.44 POUNDS (0.2 KG).
• FAILURE TO FOLLOW MANUFACTURERʼS SPECIFICATIONS OR USE OF ACCESSORIES OTHER THAN THOSE APPROVED BY THE MANUFACTURER MAY CAUSE THE UNIT TO BECOME UNSTABLE.
• AVOID SERIOUS INJURY FROM FALLING OR SLIDING OUT. ALWAYS USE COMPLETE 5 POINT SEAT BELT.
• NEVER LEAVE YOUR CHILD UNATTENDED.
• ALWAYS USE ALL THE BRAKES WHENEVER PARKED.
• TO AVOID SERIOUS INJURY, WHEN MAKING ADJUSTMENTS ENSURE THE CHILDʼS BODY IS CLEAR OF ALL MOVING PARTS.
• ALL OPERATING AND ASSEMBLY PROCEDURES SHOULD BE PERFORMED BY AN ADULT.
• DO NOT LIFT THE STROLLER BY GRIPPING THE FRONT BAR. THE FRONT BAR IS NOT DESIGNED TO WITHSTAND LOADS.
• ENSURE THAT THE STROLLER IS OPENED CORRECTLY AND LOCKED IN POSITION OF USE.
• CHECK TO MAKE SURE THAT THE CAR SEAT OR THE BABY CARRIAGE IS CORRECTLY FASTENED TO THE STROLLER (WHERE APPLICABLE).
• DO NOT DRIVE THIS PRODUCT AROUND STAIRS OR STEPS; CARE MUST BE TAKEN IF UNIT IS USED ON STAIRS OR ESCALATORS.
• DO NOT USE THE PRODUCT IF IT HAS BROKEN OR MISSING PARTS.
• DO NOT USE NEAR FIRE OR EXPOSED FLAME.
ES•ESPAÑOL
• IMPORTANTE: leer detenidamente las instrucciones antes del uso y conservarlas para poder utilizarlas en el futuro.
• PEG PEREGO podrá modificar los modelos decritos en este prospecto, por razones técnicas o commerciales.
SERVICIO DE ASISTENCIA
Si por casualidad alguna parte del modelo se pierde o se rompe, usar sólo piezas de repuesto originales Peg Perego. Para todo lo que concierne las reparaciones, cambios, informaciones sobre los productos y la venta de repuestos originales y accesorios, contacte con el Servicio de Asistencia Peg-Perego:
USA: tel.: 800.671.1701 fax: 260.471.6332 Call us toll free: 1.800.671.1701
www.pegperego.com
INSTRUCCIONES DE USO
APERTURA 1• Antes de abrir la silla de paseo hay que
quitar los dos tapones de protección de los ganchos como indica la figura pues, si no se quitan, el carro no se abrirá correctamente.
2• Para abrir la silla de paseo hay que tirar
hacia arriba las dos palancas de los mangos y
3• al mismo tiempo levantar la silla de paseo
que se abrirá automáticamente. Para verificar que la silla de paseo esté abierta correctamente, controlar los dos ganchos laterales (véase la figura).
ENSAMBLAJE DE LA SILLA DE PASEO 4• Para montar las ruedas anteriores, bajar
la palanca A e introducir las ruedas como indica la figura hasta oír un clic.
5• Para montar las ruedas posteriores,
introducirlas como indica la figura hasta oír un clic.
6• Para montar la cesta hay que meter las
ranuras en los ganchos delanteros A y en
los ganchos posteriores B y C. 7• La figura muestra la cesta enganchada. 8• El portabebidas, gracias a sus dos
abrazaderas, se puede poner en el asa
derecha o izquierda de la silla de paseo.
Para poner el portabebidas en el asa,
ensanchar la abrazadera, manteniendo el
lado perfilado de la abrazadera dentro del
asa de manera que corresponda con el
realce.
9• Meter la abrazadera en el portabebidas
hasta oír clic.
Se aconseja no poner en el portabebidas
bebidas calientes y que pesen más de 1 Kg (2,2 lbs).
CAPOTA
La capota está dotada de cremallera para aplicar el plástico de lluvia o el mosquitero con cremallera (véase la Línea de Accesorios).
10• Para montar la capota, empujar hacia
abajo los acoples hasta oír clic como indica la figura.
11• Abrochar la capota como indica la figura
dentro del brazo y en el respaldo de la silla de paseo.
12• Para tensar la capota, empujar hacia
abajo el compás. La capota puede reclinarse siguiendo la inclinación del respaldo.
13• Para quitar la capota hay que
desabotonarla de la silla de paseo, aflojar los compases y levantar las aletas de los acoples empujando hacia el interior de la silla de paseo.
fijas, actuar en la palanca en sentido contrario.
CIERRE Antes de cerrar la silla de paseo, si está
montada la capota, aflojar los compases y si el respaldo está bajado, levantarlo.
20• La silla de paseo se puede cerrar con una
sola mano: tirar hacia arriba primero una palanca y luego la otra hasta oír clic.
21• Empuñar el mango central y tirar de él
hacia arriba hasta que cierre como indica la figura.
22• Comprobar que la silla de paseo esté
bien cerrada por medio del gancho de seguridad. La silla de paseo cerrada se sostiene sola en pie.
TRANSPORTE 23• La silla de paseo se puede transportar
cómodamente (manteniendo las ruedas delanteras en posición no giratoria) cogiendo el asa central como indica la figura.
24• También se puede transportar gracias al
asa lateral como indica la figura.
FRENO 14• Para frenar la silla de paseo, bajar con el
pie las palancas colocadas en las ruedas posteriores como muestra la figura. Para desbloquear los frenos, actuar en sentido contrario. Cuando la silla de paseo está detenida, siempre hay que dejar accionados los frenos.
CINTURÓN DE SEGURIDAD 15• A: Asegurarse que los tirantes estén
correctamente introducidos, empujando tal y como muestra la figura. B: Enganchar el cinturón actuando como muestra la figura.
16• Para desenganchar el cinturón, pulsar en
los lados de la hebilla y al mismo tiempo tirar hacia fuera, el cinturón.
REGULACIÓN DEL REPOSAPIÉS 17• El reposapiés se puede regular en tres
posiciones. Para bajar el reposapiés, tirar de las dos palanquitas laterales hacia abajo y al mismo tiempo bajarlo. Para subir el reposapiés, subirlo hacia arriba hasta oír clic.
REGULACIÓN DEL RESPALDO 18• El respaldo se puede reclinar en tres
posiciones. Para bajar el respaldo, coger con ambas manos las dos piezas que regulan el respaldo tirando hacia sí. Para levantarlo empujar el respaldo hacia arriba.
RUEDAS GIRATORIAS 19• Para hacer que las ruedas anteriores sean
giratorias, es necesario bajar la palanca como muestra la figura. Para hacerlas
DESENFUNDABLE 25• Para quitar la funda de la silla de paseo
sacar la correa para la entrepierna del cinturón de seguridad por debajo del asiento. Desenganchar los botones de la funda del asiento y sacar la funda de los ganchos del reposapiés.
26• Sacar por detrás del respaldo las hebillas
de los tirantes del cinturón de seguridad y sacar los tirantes de los dos protege­hombros.
27• Para sacar los protege-hombros, al estar
unidos entre ellos, hay que sacarlos por las ranuras de la funda como indica la figura.
28• Desenganchar los botones de la funda
lateralmente como indica la figura. Sacar la funda lateralmente del chasis, tirando hacia arriba los laterales de la funda como indica la figura.
29• Desenroscar la correa (sólo por un lado)
como indica la figura manteniendo el dedo debajo de la tuerca. Sacar la correa precedentemente desenroscada de la silla de paseo por la ranura de la funda como indica la figura.
Para volver a montar la funda en la silla de paseo hacer las mismas operaciones en sentido contrario sin olvidarse de enroscar la correa.
GANCIOMATIC SYSTEM
Ganciomatic System es el sistema práctico y rápido que permite enganchar en la silla de paseo la silla de auto Primo Viaggio, que también está dotada de sistema Ganciomatic y se puede comprar por separado. Primo
Viaggio se desengancha de la base (que queda en el automóvil) y se engancha en la silla de paseo para transportar al niño sin molestarlo.
ACOPLES GANCIOMATIC DE LA SILLA
DE PASEO
30• Para subir los acoples Ganciomatic de
la silla de paseo, levantar el saco en los ángulos del asiento y girar hacia arriba los dos acoples hasta oír clic.
31• Para bajar los acoples Ganciomatic de
la silla de paseo, tirar hacia fuera la palanquita y al mismo tiempo girar hacia abajo los acoples como indica la figura.
PLIKO LITE + PRIMO VIAGGIO
32• Para enganchar la silla de auto a la silla
de paseo hay que:
- frenar la silla de paseo;
- quitar la capota de la silla de paseo;
- bajar completamente el respaldo de la silla de paseo;
- levantar el reposapiés de la silla de paseo en la posición más alta;
- levantar los acoples Ganciomatic de la silla de paseo;
- poner la silla de auto hacia el respaldo de la silla de paseo de manera que correspondan los ganchos delanteros de la silla con los acoples de la silla de paseo; luego empujar la silla hacia abajo hasta oír clic.
Para desenganchar la silla de auto de la silla de paseo consultar el manual de instrucciones.
LÍNEA DE ACCESORIOS
33• Bolso con cambiador: bolso con
colchoneta para cambiar al bebé, que se puede enganchar a la silla de paseo.
34• Plástico de lluvia: plástico de lluvia con
cremallera que se puede aplicar a la capota mediante la cremallera
35• Mosquitero: mosquitero con cremallera,
que se puede aplicar a la capota mediante la cremallera
36• Bolso de viaje: práctico bolso para llevar
la silla de paseo en el avión.
LIMPIEZA & MANTENIMIENTO
Su producto necesita un mínimo mantenimiento. Las operaciones delimpieza y mantenimiento tiene que ser efectuadas sólo por adultos.
• Se aconseja mantener limpias las partes en
movimiento y si hiciera falta, lubricarlas con aceite ligero.
• Secar las partes de metal del producto para
evitar que se oxiden.
• Limpiar periódicamente las partes de
plástico con un paño húmedo, no usar
disolventes ni otros productos parecidos.
• Cepillar las partes de tejido para quitar el polvo.
• Mantener limpias las ruedas quitando polvo y arena.
• Proteger el producto contra los agentes atmosféricos, agua, lluvia o nieve; la exposición continua y prolongada al sol puede causar cambios de color en muchos materiales.
• Conservar el producto en un sitio seco.
• Para lavar el saco, seguir las instrucciones siguientes.
CUIDADO
• ESTE PRODUCTO HA SIDO DISEÑADO PARA NIÑOS CON UN PESO MÁXIMO DE 18 KG Y UNA ALTURA MÁXIMA DE 110 CM. LA CESTILLA HA SIDO REALIZADA PARA SOPORTAR UN PESO MÁXIMO DE 5 KG. LOS POSIBLES PORTABEBIDAS QUE VAN CON ESTE PRODUCTO ESTÁN CONCEBIDOS PARA SOPORTAR EL PESO MÁXIMO ESPECIFICADO EN EL PORTABEBIDAS EN CUESTIÓN. CUALQUIER BOLSA ENTREGADA JUNTO AL PRODUCTO ESTÁ REALIZADA PARA SOPORTAR UN PESO MÁXIMO DE 0,2 KG.
• SI NO SE RESPETAN LAS INDICACIONES ESPECIFICADAS O SI SE USAN ACCESORIOS DIFERENTES DE LOS HOMOLOGADOS POR EL FABRICANTE, EL PRODUCTO PUEDE SER INESTABLE.
• PARA EVITAR LESIONES GRAVES POR CAÍDAS O SI ESCAPA EL NIÑO DE LA SILLA DE PASEO, USAR SIEMPRE UN CINTURÓN DE SEGURIDAD DE 5 PUNTOS COMPLETO.
• NO DEJAR NUNCA AL NIÑO SIN VIGILANCIA.
• USAR SIEMPRE TODOS LOS DISPOSITIVOS DE BLOQUEO CADA VEZ QUE LA SILLA DE PASEO NO ESTÉ EN MOVIMIENTO.
• PARA EVITAR LESIONES GRAVES, ASEGURARSE DE QUE EL NIÑO NO PUEDA MOVERSE PELIGROSAMENTE
MIENTRAS SE REGULA EL PRODUCTO.
• TODAS LAS OPERACIONES DE ENSAMBLAJE DEBE REALIZARLAS SOLO UN ADULTO.
• NO LEVANTAR LA SILLA DE PASEO COGIÉNDOLA POR LA BARRA FRONTAL. LA BARRA FRONTAL NO HA SIDO CONCEBIDA PARA SOPORTAR PESOS.
• ASEGURARSE DE QUE LA SILLA DE PASEO ESTÉ ABIERTA CORRECTAMENTE Y BLOQUEADA EN LA POSICIÓN CORRECTA PARA SU UTILIZACIÓN.
• ASEGURARSE DE QUE LA SILLA DE AUTO O EL COCHECITO ESTÉN ENGANCHADOS CORRECTAMENTE A LA SILLA DE PASEO.
• NO USAR LA SILLA DE PASEO CERCA DE ESCALERAS O ESCALONES; PRESTAR ATENCIÓN CUANDO SE UTILIZA EN ESCALERAS O ESCALERAS MECÁNICAS.
• NO UTILIZAR EL PRODUCTO SI PRESENTA PARTES DAÑADAS O SI FALTA ALGUNA PARTE.
• NO USAR EN PRESENCIA DE LLAMAS O FUENTES DE CALOR.
FR•FRANÇAIS
• AVERTISSEMENT: lire attentivement les instructions avant dʼutiliser le produit et les conserver pour toute référence ultérieure.
• Pour des raisons techniques et commerciales, PEG PEREGO pourra apporter à tout moment des modifications aux modèles décrits dans ce manuel.
SERVICE DʼASSISTANCE
En cas de perte ou dommage fortuit de pièces du modèle, utilisez exclusivement les pièces de rechange originales Peg Perego. Pour les éventuelles réparations, substitutions, informations sur les produits, la vente de pièces de rechange originales et dʼaccessoires, contactez le Service dʼassistance Peg-Perego:
CANADA: tel.: 905.839.3371 fax: 905.839.9542 Call us toll free: 1.800.661.5050
www.pegperego.com
NOTICE DʼEMPLOI
OUVERTURE 1• Avant dʼouvrir la poussette, retirer
les deux bouchons de protection des crochets, comme indiqué sur la figure, ou la poussette ne pourra être ouverte correctement.
2• Pour ouvrir la poussette, tirez
simultanément les deux crochets des poignées vers le haut et,
3• en même temps, soulevez la poussette
et elle s'ouvrira automatiquement. Appuyez avec une main au fond de la poussette afin de vérifier que l'ouverture soit correcte. Pour vous assurer que la poussette est ouverte correctement, contrôlez les deux crochets latéraux (voir figure).
ASSEMBLAGE DE LA POUSSETTE 4• Pour monter les roues avant, abaissez le
levier A et insérez la roue jusquʼau déclic, comme sur la figure.
5• Pour monter les roues arrière, insérez la
roue jusquʼau déclic, comme sur la figure.
6• Pour fixer le panier, enfilez les crochets
avant A et les crochets arrières B et C sur
les ergots prévus à cet effet. 7• Panier installé. 8• Le porte-biberon est applicable à la
poignée gauche ou droite de la poussette,
grâce aux deux attaches.
Pour monter le porte-boissons sur
le poignée, élargir le petit collier en
positionnant son côté au profil particulier à lʼintérieur de la poignée.
9• Enfilez le porte-biberon sur le collier
jusqu'au CLIC. Il est déconseillé de mettre un biberon ou une bouteille contenant une boisson chaude et pesant plus d'1 kg dans le porte-biberon.
CAPOTE
La capote est munie dʼune fermeture éclair pour monter la bâche ou la moustiquaire avec fermeture éclair (voir Ligne Accessoires).
10• Pour fixer la capote, enfoncez les
attaches sur les tubes de la poussette jusqu'à entendre le CLIC comme indiqué sur le schéma correspondant.
11• Pressionnez l'arrière de la capote au
dossier de la poussette et sur la partie intérieure des accoudoirs.
12• Pour tendre la capote, poussez les petits
leviers vers le bas. La capote peut être réglée en fonction de l'inclinaison du dossier.
13• Pour retirer la capote, la déboutonner de
la poussette, détendre les petit leviers et relever les ailettes des fixations en poussant vers lʼintérieur de la poussette.
FREINS 14• Pour actionner le frein de la poussette,
abaissez avec le pied la barre située sur les roues arrières comme indiqué sur le schéma. Pour débloquer les freins, relevez la barre. A lʼarrêt, toujours actionner les freins de la poussette.
CEINTURES DE SECURITE 15• A: Assurez-vous que la bretelle soit
correctement insérée en vérifiant comme indiqué sur le schéma correspondant. B: Accrochez la ceinture comme indiqué sur le schéma.
16• Pour détacher la ceinture, appuyez de
chaque côté de la boucle et tirez pour que les deux parties se désolidarisent.
REGLAGE DU REPOSE-PIEDS 17• Le repose-pieds est réglable en trois
positions. Pour la position la plus basse, actionnez les deux petites manettes situées de chaque côté du repose-pieds et celui-ci s'abaissera. Pour le mettre en position haute, soulevez le repose-pieds jusqu'au déclic.
indiqué sur le dessin correspondant. Pour les mettre en position fixe, relevez le levier.
FERMETURE Avant de fermer la poussette, si la capote
est montée, desserrer les petits leviers, et relever le dossier sʼil est abaissé.
20• Vous pouvez fermer la poussette dʼune
seule main: tirez dʼabord vers le haut lʼune des deux poignées puis lʼautre, jusquʼà entendre le déclic.
21• Saisissez la poignée centrale et
tirez énergiquement pour fermer complètement la poussette.
22• Vérifiez que la poussette soit bien fermée
et que le crochet de sécurité soit bien enclenché. La poussette fermée tient debout toute seule.
TRANSPORT 23• Il est très facile de transporter la Pliko
grâce à la poignée centrale.
24• La poignée latérale, très pratique pour
les petits parcours, vous permettra de transporter la poussette aisément.
RETIRER LA HOUSSE 25• Pour retirer la housse de la poussette,
enlever la sangle dʼentrejambe par le dessous de lʼassise. Déboutonner le revêtement de lʼassise et lʼenlever des crochets du repose-pieds.
26• Enlever de lʼarrière du dossier les boucles
des bretelles de la ceinture de sécurité et enlever les bretelles des deux épaulières.
27• Les épaulières sont attachées lʼune à
lʼautre. Pour enlever les épaulières, les faire glisser par les fentes de la housse, comme sur la figure.
28• Déboutonner la housse sur les côtés,
comme sur la figure. Enlever la housse du siège en commençant par tirer vers le haut les côtés de la housse, comme sur la figure.
29• Dévisser la ceinture (seulement dʼun
côté), comme sur la figure, en bloquant lʼécrou avec un doigt. Enlever la ceinture dévissée au préalable par la fente de la housse, comme sur la figure.
Pour remonter la housse à la poussette, répéter les mêmes opérations mais dans le sens inverse, en prenant soin de revisser la ceinture.
REGLAGE DU DOSSIER 18• Le dossier peut être incliné en trois
positions. Pour abaisser le dossier, se saisir des deux éléments de réglage du dossier et les tirer vers soi. Pour le relever, pousser le dossier vers le haut.
ROUES PIVOTANTES 19• Pour mettre les roues avant en position
pivotante, baissez le levier comme
SYSTEME GANCIOMATIC
Grâce à ses fixations spéciales, le Système Ganciomatic, pratique et rapide, permet de monter sur la poussette le siège auto Primo Viaggio (vendu séparément), lui aussi muni du Système Ganciomatic. Primo Viaggio peut être détaché de sa base (qui reste dans la voiture) et accroché à la poussette pour transporter le bébé sans le déranger.
FIXATIONS GANCIOMATIC DE LA
POUSSETTE
30• Pour soulever les fixations Ganciomatic
de la poussette, relever le sac au niveau des angles de lʼassise et faire pivoter les deux fixations vers le haut jusquʼau déclic.
31• Pour abaisser les fixations Ganciomatic
de la poussette, tirer le petit levier vers lʼextérieur et, dans le même temps, faire pivoter les fixations vers le bas comme sur la figure.
PLIKO LITE + PRIMO VIAGGIO 32• Pour monter le siège auto sur la
poussette, il faut:
- bloquer la poussette;
- retirer la capote de la poussette;
- abaisser complètement le dossier de la poussette;
- relever le repose-pieds de la poussette jusquʼà la position la plus haute;
- soulever les fixations Ganciomatic de la poussette;
- positionner le siège auto tourné vers le dossier en faisant correspondre les crochets antérieurs du siège auto aux fixations de la poussette; encastrer ensuite le siège auto en appuyant vers le bas.
Pour démonter le siège auto de la poussette, se reporter au manuel dʼinstructions correspondant.
LIGNE ACCESSOIRES
33• Sac à langer: Sac muni dʼun petit matelas
pour changer bébé, qui peut être monté sur la poussette.
34• Bâche: Bâche avec fermeture-Eclair
adaptable à la capote munie de fermeture-Eclair
35• Moustiquaire: Moustiquaire avec
fermeture-Eclair adaptable à la capote munie de fermeture-Eclair.
36• Sac de voyage: Sac pratique pour le
transport en avion de la poussette.
NETTOYAGE ET ENTRETIEN
Votre produit nécessite un minimum dʼentretien. Les opérations de nettoyage et dʼentretien doivent être effectuées uniquement par des adultes.
• Il est recommandé de maintenir toutes les
parties mobiles propres et, au besoin, de les lubrifier avec une huile légère.
• Essuyer les parties métalliques du produit
pour prévenir la formation de rouille.
• Nettoyer régulièrement les parties en
plastique avec un chiffon humide, ne pas utiliser de solvants ou dʼautres produits du même type.
• Brosser les parties en tissu pour les
dépoussiérer.
• Éliminer les dépôts de poussière et de sable des roues.
• Protéger le produit contre les agents atmosphériques, lʼeau, la pluie ou la neige; lʼexposition continue et prolongée au soleil pourrait altérer les couleurs de nombreux matériaux.
• Conserver le produit dans un endroit sec.
• Pour le lavage du sac, suivre les instructions ci-après.
AVERTISSEMENT
• CE PRODUIT A ETE CONÇU POUR DES ENFANTS DONT LE POIDS NʼEXCEDE PAS 18 KG (40 LIVRES) ET LA TAILLE NE DEPASSE PAS 110 CM (43 POUCES). LE PANIER A ETE CONÇU POUR SUPPORTER DES CHARGES MAXIMALES DE 5 KG (11 LIVRES). LE PORTE­BOISSONS EVENTUELLEMENT FOURNI AVEC LE PRODUIT A ETE CONÇU POUR SUPPORTER DES CHARGES INDIQUEES SUR LE PORTE-BOISSONS LUI-MEME. LES POCHETTES OU SACS FOURNIS AVEC CE PRODUIT ONT ETE CONÇUS POUR SUPPORTER DES CHARGES MAXIMALES DE 0,2 KG (0,44 LIVRES).
• LE DEFAUT DʼOBSERVATION DES SPECIFICATIONS DU FABRICANT OU LʼEMPLOI DʼACCESSOIRES NON APPROUVES PAR LE FABRICANT PEUT AFFECTER LA STABILITE DU PRODUIT.
• POUR ÉVITER DE GRAVES BLESSURES SUITE À LA CHUTE OU AU GLISSEMENT DE LʼENFANT DU PRODUIT, TOUJOURS UTILISER UNE CEINTURE DE SÉCURITÉ À 5 POINTS COMPLÈTE.
• NE JAMAIS LAISSER LʼENFANT SANS SURVEILLANCE.
• TOUJOURS ACTIONNER LES FREINS LORSQUE LE PRODUIT EST A LʼARRET.
• POUR ÉVITER DE GRAVES BLESSURES LORS DU RÉGLAGE DU PRODUIT, SʼASSURER QUE LES MEMBRES DE LʼENFANT NE SONT
PAS EN CONTACT AVEC DES PIÈCES EN MOUVEMENT.
• LʼENSEMBLE DES PROCÉDURES DE MONTAGE ET DʼUTILISATION DOIT ÊTRE EFFECTUÉ PAR UN ADULTE
• NE PAS SOULEVER LA POUSSETTE PAR LA BARRE FRONTALE. ELLE NʼA PAS ÉTÉ CONÇUE POUR SUPPORTER DES CHARGES.
• SʼASSURER QUE LA POUSSETTE EST CORRECTEMENT OUVERTE EST BLOQUÉE DANS LA POSITION CONVENANT À SON UTILISATION.
• CONTRÔLER QUE LE SIÈGE ENFANT OU LE LANDAU EST CORRECTEMENT ACCROCHÉ À LA POUSSETTE.
• NE PAS UTILISER CE PRODUIT À PROXIMITÉ DE MARCHES OU DʼESCALIERS; PRÊTER ATTENTION À LA MANIPULATION DU PRODUIT DANS DES ESCALIERS OU DES ESCALATORS.
• NE PAS UTILISER LE PRODUIT SI DES PIÈCES SONT MANQUANTES OU CASSÉES.
• NE PAS UTILISER PRÈS DU FEU OU DʼUNE FLAMME DIRECTE.
Pliko Lite
PEG PEREGO S.p.A.
VIA DE GASPERI 50 20043 ARCORE MI ITALIA
tel. 0039•039•60881 fax 0039•039•615869-616454
Servizio Post Vendita - After Sale:
tel. 0039•039•6088213 fax: 0039•039•3309992
PEG PEREGO U.S.A. Inc.
3625 INDEPENDENCE DRIVE FORT WAYNE INDIANA 46808
phone 260•482•8191 fax 260•484•2940
Call us toll free 1•800•671•1701
PEG PEREGO CANADA Inc.
585 GRANITE COURT PICKERING ONTARIO CANADA L1W3K1
phone 905•839•3371 fax 905•839•9542
Call us toll free 1•800•661•5050
www.pegperego.com
28-02-06
Loading...
