Parallels HELM 4.2.0 Quick installation guide

Parallels® Helm

Parallels Helm 4.2.0 Quick Installation
Guide

REVISION 1.0

Legal and Copyright Notice

ISBN: N/A

Parallels Holdings, Ltd.

c/o Parallels International GmbH

Vordergasse 59

CH-Schaffhausen

Switzerland

Phone: [phone]

Fax: [phone]

© Copyright 2011,

Parallels, Inc.

All rights reserved

Distribution of this work or derivative of this work in any form is prohibited unless prior

written permission is obtained from the copyright holder.

Product and service names mentioned herein are the trademarks of their respective owners.

Contents

Preface 4

Typographical Conventions ........................................................................................................... 4

Feedback ....................................................................................................................................... 5

About Parallels Helm 6

About This Guide 7

What’s New in This Version 8

Windows 2008 R2 support (including R2 SP1) ................................................................... 8

SmarterMail 6.x, 7.x and 8.x support .................................................................................. 8

MySQL ODBC 5.1 driver support ........................................................................................ 8

Improved Helm 3 to Helm 4 migration tool .......................................................................... 8

Licensing Parallels Helm 9

Installing Parallels Helm 10

Upgrading Parallels Helm 12

Uninstalling Parallels Helm 13

Uninstalling Microsoft SQL Server Desktop Engine (Helm) 14

In this chapter:

Typographical Conventions ............................................................................... 4

Feedback .......................................................................................................... 5

Formatting convention

Type of Information

Example

Special Bold

Items you must select,
such as menu options,
command buttons, or
items in a list.

Go to the System tab.
Titles of chapters,
sections, and
subsections.

Read the Basic
Administration chapter.

Italics

Used to emphasize the
importance of a point, to
introduce a term or to
designate a command
line placeholder, which is
to be replaced with a real
name or value.

The system supports the
so called wildcard
character search.

Monospace

The names of
commands, files,
directories, and domain
names.

The license file is located
in the

http://docs/common/
licenses directory.

C HAP T E R 1

Preface

Typographical Conventions

Before you start using this guide, it is important to understand the documentation
conventions used in it.

The following kinds of formatting in the text identify special information.

Preface 5

Preformatted

On-screen computer
output in your command­line sessions; source
code in XML, C++, or
other programming
languages.

# ls –al /files

total 14470

Preformatted
Bold

What you type,
contrasted with on-screen
computer output.

# cd /root/rpms/php

CAPITALS

Names of keys on the
keyboard.

SHIFT, CTRL, ALT

KEY+KEY

Key combinations for
which the user must
press and hold down one
key and then press
another.

CTRL+P, ALT+F4

Feedback

If you have found a mistake in this guide, or if you have suggestions or ideas on how to
improve this guide, please send your feedback using the online form at

http://www.parallels.com/en/support/usersdoc/. Please include in your report the

guide’s title, chapter and section titles, and the fragment of text in which you have found
an error.

Parallels Helm Web Hosting Control System is an extremely powerful hosting

C H A P T E R 2

About Parallels Helm

automation solution for Windows 2003 and Windows 2008 servers. Parallels Helm is
owned by Parallels, a global leader in virtualization and automation software. Web site:

http://www.parallels.com/en/products/helm/

Please take some time to read over this guide. Doing so will help you ensure that you

C H A P T E R 3

About This Guide

install Parallels Helm correctly on your server.

Windows 2008 R2 support (including R2 SP1)

C H A P T E R 4

What’s New in This Version

Note: Microsoft FTP 7.5 is not supported.

SmarterMail 6.x, 7.x and 8.x support

SmarterMail provider is tested to be compatible with the newest SmarterMail software.

Known problem: Max Recipients/Message could not be set in Mail list parameters if
Smarter Mail 6.x, 7.x, 8.x is used

MySQL ODBC 5.1 driver support

ODBC provider extension now supports the newest version of MySQL ODBC driver.

Improved Helm 3 to Helm 4 migration tool

 List of improvements:

 Added migration of WebScheduler tasks.

 Added migration of ODBC records.

 Fixed migration of Secure folders.

 Fixed migration of Serv-U FTP accounts.

 Fixed migration of demo accounts.

 Fixed migration of credit card info.

 Fixed duplication of DNS records.

Parallels Helm 4.2 requires a valid license with Upgrade Protection, or, in terms of

C H A P T E R 5

Licensing Parallels Helm

Parallels licensing, a license that provides Software Update Service (SUS) which
entitles you to version upgrade licenses throughout the life of your SUS. About SUS:

http://www.parallels.com/en/support/sus.

Installation. New retail sales for Parallels Helm 4.2 are currently available for unlimited
domains and remote servers and include 1 year SUS. Please go to

http://www.parallels.com/store/helm/buy/ and purchase a Parallels Helm license prior to

the installation which requires a valid license key.

Upgrade. Upgrading from Parallels Helm 4 or 4.1 to Parallels Helm 4.2 requires a new
license.

 If your license does not provide SUS, go to

http://www.parallels.com/store/support/helm/ and reinstate your license.

 If you have a Parallels Helm 4.1 license with SUS, just run a special Parallels Helm

4.1 to Parallels Helm 4.2 Upgrade Tool. See Upgrading Parallels Helm (on page 12)
for details.

To check if your license provides SUS, go to the Parallels Helm members area:

http://www.webhostautomation.com/members.

Important: Parallels SUS is a subscription base service that must be renewed in
advance of its expiration date. In case you pay in advance, the cost of the renewal for
purchase keys will be 25% of the retail cost of the key. Otherwise, if you have not
renewed and decide later to upgrade, you will need to pay 65% of the retail cost of the
key to get it reinstated.

License Verification. Parallels Helm licenses are verified on the Parallels licensing
servers. This means that to initialize the license your server must be connected to the
Internet and have access to a working DNS service. If you receive the message that
the license failed because it is already in use, this means that the license key entered
has already been installed on another machine. You will need to reset your licence.
Details of how to do this can be found here:

http://support.webhostautomation.com/index.php?_a=knowledgebase&_j=questiondetai
ls&_i=148

If the license has been installed on another server, Parallels Helm will stop working on
that server if the license is reassigned.

Important Note: In order to run Parallels Helm, you need to install Microsoft .NET 2.0

C H A P T E R 6

Installing Parallels Helm

Framework (http://www.microsoft.com/downloads/details.aspx?FamilyID=0856eacb-

4362-4b0d-8edd-aab15c5e04f5&displaylang=en). Once downloaded, double click the

executable to install the Framework.

 Download the Parallels Helm installer from here:

http://www.parallels.com/en/products/helm/

 Double-click the install file you downloaded. Read and accept the licence

agreement, then fill in your name and your company name, then enter your licence
key. Your licence key will have been sent to you when you either signed up for a
trial account, or purchased a full licence.

Important: Make a note of the Administrative Password you decide to enter here, as
this is the password you will be using to login to Parallels Helm once the install is
complete.

Once you have entered the password, click Next to continue.

 On the next screen, specify your install choices:

 Helm Control Server with MSDE: Choosing this option will install Parallels Helm with

MSDE (a cut-down version of SQL Server). If you do not have SQL Server on
your machine, this is the option you should choose.

 Helm Control Server: Choosing this option will install just Parallels Helm on your

server, with no database server.

If you have SQL Server installed on your server, you should choose this option
as Parallels Helm can then put your database into SQL Server. Alternatively, if
you installed MSDE already and already have a Parallels Helm database, then
there is no need to install MSDE again, so choose this option and in the next
screen choose the Parallels Helm database you already have set up there.

 Helm Remote Server: If you just want to install the Remote Installer tool to allow

Parallels Helm to manage a remote server, you should choose this option.

 Installation Directory: If you want to install Parallels Helm to a different location to

the default, you can specify it here, or browse to it with the ... button.

 If you chose Helm Control Server with MSDE or Helm Remote Server, installation will now

take place, and you will need no further configuration.

 If you chose Helm Control Server, you will be taken to the Database Information screen:

 In the Server Name field, you will see the server that your Parallels Helm database

is believed to be on. If this is incorrect, you can click the ... button and select the
correct location of the Parallels Helm database.

 If you are using SQL Server on a different machine than Parallels Helm to host

the database, then you will need to provide SQL User Authentication details (the
SA username and password), in order to connect to this remote machine.

Installing Parallels Helm 11

Once you have chosen your database location, click Next to complete the
installation.

 Open the Parallels Helm Control Panel (an icon should be on the desktop). The

admin login for this is set to:

 Account Name: admin

 Login Name: admin

 Login Password: the password you chose at the beginning of the install.

Warning: Do NOT install old Parallels Helm updates on top of new ones. Doing so
could corrupt your entire database, and may mean you having to drop that database
and all data and recreating it from scratch.

If you have errors, contact your support provider. Do not overwrite new updates with
older versions!

 To upgrade Parallels Helm 4.1.x to Parallels Helm 4.2.x:

C H A P T E R 7

Upgrading Parallels Helm

 The upgrade to Parallels Helm 4.2.x requires a valid license with Upgrade

Protection, or, in terms of Parallels licensing, a license that provides Software
Update Service (SUS) which entitles you to version upgrade licenses throughout the

life of your SUS. About SUS: http://www.parallels.com/en/support/sus.

You can validate your license by going to the Parallels Helm member area:

http://www.webhostautomation.com/members.

If you have a license without SUS, go to

http://www.parallels.com/store/support/helm/ and reinstate your license. Otherwise,

you will not be able to upgrade to Parallels Helm 4.2.x.

 Download the Parallels Helm 4.1.x to 4.2.x Upgrade Tool from the following

location:

http://helm.download.webhostautomation.net/Helm41To42UpgradeTool.exe

 Run the tool and follow its instructions.

 To upgrade Parallels Helm 4.0.x to Parallels Helm 4.2.x:

 Upgrade Parallels Helm 4.0.x to Parallels Helm 4.1.2

 Upgrade Parallels Helm 4.1.2 to Parallels Helm 4.2.x

 To upgrade Parallels Helm 4.0.x to Parallels Helm 4.1.2:

 The upgrade to Parallels Helm 4.1.2 requires a valid license with Upgrade

Protection, or, in terms of Parallels licensing, a license that provides Software
Update Service (SUS) which entitles you to version upgrade licenses throughout the

life of your SUS. About SUS: http://www.parallels.com/en/support/sus.

You can validate your license by going to the Parallels Helm member area:

http://www.webhostautomation.com/members.

If you have a license without SUS, go to

http://www.parallels.com/store/support/helm/ and reinstate your license. Otherwise,

you will not be able to upgrade to Parallels Helm 4.1.2.

 Download the Parallels Helm 4 to 4.1.2 Upgrade Tool from the following location:

http://helm.download.webhostautomation.net/Helm4To41UpgradeTool.exe

 Run the tool and follow its instructions.

 To uninstall Parallels Helm:

C H A P T E R 8

Uninstalling Parallels Helm

 Go to Start > Programs > Parallels > Parallels Helm 4 > Uninstall Helm

 Click Next and confirm the uninstallation. Parallels Helm will be uninstalled.

Important Note: Parallels Helm will not remove any domains, databases or other
settings that you have set up since using the control panel. These will continue to run
correctly without Parallels Helm installed.

If you have installed Microsoft SQL Server Desktop Engine (MSDE) as the Parallels

C H A P T E R 9

Uninstalling Microsoft SQL Server Desktop Engine (Helm)

Helm database server, this can be uninstalled by removing Microsoft SQL Server Desktop
Engine (HELM) from Add or Remove Programs, which can be found in the Windows Control

Panel.

 To uninstall Microsoft SQL Server Desktop Engine for Parallels Helm:

 To access the Windows Control panel click the Start menu and click Control Panel.

The control panel can also be located by double clicking My Computer on the desktop
and selecting Control Panel from the drop down menu in the address bar.

 In the Control Panel double click Add or Remove Programs and highlight the Microsoft

SQL Server Desktop Engine (Helm) program by clicking on it.

 Click Remove and confirm the uninstall by clicking Yes when prompted. MSDE will be

removed, and the uninstallation process is now complete.
