Infrared Wireless Microphone System
Infrared Wireless Microphone System
Product Introduction
Product Introduction
Confidential, Internal Use Only
Product lineup
Microphone
(pendant-style)
WX-LT310E
Receivers
Infrared sensor
WX-LS100E
Microphone
(handheld)
WX-LT100E
Infrared sensor
coupler
WX-LC10E
Charger Stand
WX-LZ10E
Battery
Charger
WX-LZ110/G
WX-LR100E/A
WX-LR100E/B
Confidential, Internal Use Only
Key Features
+ High Sound Quality for Speech Use
+ Hands-Free Operation
+ Remote Volume Controls on the Pendant Microphone
+ Light Weight Handheld Microphone
+ Accommodates Four(4)-Microphone Simultaneously
+ Microphone Aux input Allows Local Playback
from External Sources
+ Smart Circuitry for Batteries
Exclusive Panasonic features
Lightweight and easy-to-use handheld microphone
The emitter designed to prevent
problems
The infrared emitter is located right under the
microphone. By relocating the emitter from
the grip, sound interruption by inadvertently
blocking the emitter by the hand holding the
grip is prevented.
The lightweight design eliminates
fatigue from long time use.
The microphone weighs approximately
190 g including two rechargeable batteries.
It weighs approximately 170 g with alkaline
OthersWX-LT100E
Emitter
Grip
Emitter
Panasonic: Approx 190 g
(rechargeable batteries included)
Grip
batteries. The weight is drastically reduced as
compared to that other manufacturers. The
design eliminates fatigue from long time use.
Confidential, Internal Use Only
Exclusive Panasonic features
Innovative hands-free pendant-style microphone
Easy to wear
The innovative device worn around the neck.
It can be easily worn over clothes without pockets.
The cordless design prevents
wire damages
The microphone, emitter and main unit are
Integrated into one unit. The cloggy cord of the
conventional clip-type microphone is gone,
eliminating the risk of being caught or wire damages.
The volume is controlled
on the microphone
The pendant-type microphone is equipped
with volume control buttons. The volume of the
microphones worn by the user and other person
can be controlled. (The two channels of the same
receiver are controlled.)
WX-LT310E
OWN/ OTHER
Switch
*Future use
Volume control
buttons
Confidential, Internal Use Only
Exclusive Panasonic features
Using the microphone in a more flexible way
The four channels are supported by
a single microphone
The PLL frequency conversion system is
adopted in the infrared microphone for
the first time.
The single microphone with a selector
switch to four channels allows using the
microphone in a more flexible way.
The microphone has a line
input terminal
The microphone is equipped with a line
input terminal.Audio data from laptop
PCs and other devices can be easily
Channel selector switch
Handheld Pendant-style
Line input terminal
3.5mm phone jack
reproduced via the infrared microphone
thus providing effective presentation.
(The microphone is turned OFF while the
line input is used.)
Handheld Pendant-style
Confidential, Internal Use Only
Exclusive Panasonic features
Using the microphone in a more flexible way
Commercially available rechargeable
batteries can be used
Basically, rechargeable batteries are used.
The commercially-available, easy-to-obtain
Panasonic size AA rechargeable batteries
can also be used. They are recharged while
installed in the main unit. The dual power
supply system supports size AA dry
batteries in an emergency.
The energy-saving scheme allows up
to approx. Six(6) hours.
Both rechargeable and dry batteries provide
the long battery life.
The user will enjoy carefree use of the
microphone in a prolonged meeting.
Commercially available
Panasonic nickel hydrogen
rechargeable battery
Battery type Rechargeable
battery
Operating
time
Approx
6 hours
Confidential, Internal Use Only
Charger Stand
Dry battery
(Alkaline)
Approx.
5 hours
Exclusive Panasonic features
Battery over discharging protection
Panasonic infrared microphone will be automatically power off to protect
Ni-Hydrogen batteries from over discharging for long time usage.
Using Nickel- Hydrogen Battery
3.0V
BATTERY VOLTAGE
2.5V
2.0V
1.5V
1.0V
0.5V
0.0V
Panasonic
1
Warning
Power Off
Battery Indicator : GREEN
( 6.75H, 230mA )
OPERATING TIME [H]
2.25V
2.10V
Panasonic
No cut off
OFF
20mA
67892345
10uA (Curent Cut)
OFF
10
Confidential, Internal Use Only
Exclusive Panasonic features
Easy to install
The dome infrared sensor covers
360 horizontal degrees.
A single infrared sensor covers a wide area with 360 horizontal degrees.
An area of a standard size can be covered by a single sensor.
The cable length alignment process in setting up multiple sensors is unnecessary and
the installation is facilitated.
WX-LS100E
360 degree
Others
Confidential, Internal Use Only
Infrared Wireless Microphone
System Examples
Confidential, Internal Use Only
System Example (1)
Two(2)-Microphone / Small Scale
WX-LT310E x1
(Set to 1ch)
WX-LS100E
(Set to 1ch/2ch)
WX-LT100E x1
(Set to 2ch)
To amplifier
WX-LR100E/A (1ch/2ch)
Confidential, Internal Use Only
Installation Example: Small Scale
W)8m x D)8m x H)3m
PLAN
IR Sensor
System Block
System Example (2)
Two(2)-Microphone / Medium Scale
WX-LT310E x1
(Set to 1ch)
WX-LS100E x2
(Set to 1ch/2ch)
WX-LC10E
(2-sensor configuration)
WX-LT100E x1
(Set to 2ch)
To amplifier
WX-LR100E/A (1ch/2ch)
Confidential, Internal Use Only
15m
Installation Example: Medium Scale
W)8m x D)15m x H)3m
PLAN
System Block
IR Sensor
IR Sensor
8m
All the value is APPROX.
System Example (3)
Two(2)-Microphone / Large Scale
WX-LT310E x1
(Set to 1ch)
WX-LS100E x4 (Set to 1ch/2ch)
WX-LC10E (Maximum
WX-LT100E x1
(Set to 2ch)
4-sensor configuration)
To amplifier
WX-LR100E/A (1ch/2ch)
Confidential, Internal Use Only
PLAN
Installation example: Large Scale
W)15m x D)25m x H)4m
(1)
IR Sensor
x2
(3) (4)
IR Sensor
(5) (6)
x2
(2)
SW = Mono
All the value is APPROX.
System Example (4)
Four(4)-Microphone / Small Scale
An infrared sensor is required
for each receiver
Set to 1ch/2ch
WX-LT310E x1
WX-LT100E x1
Set to 3ch/4ch
WX-LT100E x2
WX-LS100E
(Set to 1ch/2ch)
To auxiliary input
WX-LR100E/A
(1ch/2ch)
WX-LS100E
(Set to 3ch/4ch)
To amplifier
WX-LR100E/B
(3ch/4ch)
Confidential, Internal Use Only
System Example (5)
Four(4)-Microphone / Medium Scale
An infrared sensor is required for
each receiver
Set to 1ch/2ch
WX-LT310E x1
WX-LT100E x1
Set to 3ch/4ch
WX-LT100E x2
WX-LS100E x2
(Set to 1ch/2ch)
WX-LR100/A
(1ch/2ch)
WX-LS100 x2
(Set to 3ch/4ch)
To auxiliary input
WX-LR100/B
To amplifier
(3ch/4ch)
Confidential, Internal Use Only
For Best Results
RemarksSubject
Small to Medium ScaleOperation Range
Maximum Microphones
per System
Classroom/ Meeting room
Up to Four(4) Microphones
Approx, 6 hours operation Operation time
Excellent for speech useSound quality
*Indoor use onlyApplication
