Panasonic TH-42PW5, TH-37PW5 User Manual

®

PLASMA DISPLAY

Progressive Wide Plasma Display

Operating Instructions

+

L
O
V

—

T

U
P
N
I

Y
B
D

N
A

/

T
S

-

R

R

N

E

O

W

R
E

O
P

W
O
P

G

TH-37PW5

Model No.

TH-42PW5

For assistance, please call : 1-888-VIEW-PTV(843-9788)

or send e-mail to : [e-mail]

or visit us at www.panasonic.com (U.S.A)

For assistance, please call : 787-750-4300

or visit us at www.panasonic.com (Puerto Rico)

For assistance, please call : 1-800-561-5505

or visit us at www.panasonic.ca (Canada)

Before connecting, operating or adjusting this product, please read these instructions completely . Please keep this manual
for future reference.

English

TQBC0396

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: To reduce the risk of electric shock, do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualified service personnel.

The lightning flash with
arrow-head within a triangle
is intended to tell the user
that parts inside the product
are a risk of electric shock to
persons.

WARNING: To prevent damage which may result in fire or shock hazard, do not expose this apparatus to rain

or moisture.
Do not place containers with water (flower vase, cups, cosmetics, etc.) above the set.
(including on shelves above, etc.)

WARNING: 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to

qualified service personnel.

2) Do not remove the grounding pin on the power plug. This apparatus is equipped with a three pin
grounding-type power plug. This plug will only fit a grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet, contact an electrician.
Do not defeat the purpose of the grounding plug.

The exclamation point within
a triangle is intended to tell
the user that important
operating and servicing
instructions are in the papers
with the appliance.

2

Important Safety Instructions

1) Read these instructions.
All the safety and operating instructions should be read before the appliance is operated.

2) Keep these instructions.
The safety and operating instructions should be retained for future reference.

3) Heed all warnings.
All warnings on the appliance and in the operating instructions should be adhered to.

4) Follow all instructions.
All operating and use instructions should be followed.

5) Do not use this apparatus near water.
For example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and
the like.

6) Clean only with dry cloth.
Do not use liquid cleaners or aerosol cleaners. Use a dry cloth for cleaning.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Slots and Openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to
protect it from overheating. The openings should never be blocked by placing the product on a bed, sofa, rug, or other
similar surface.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)
that produce heat.
This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer’s instructions have been adhered to.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.

11) Only use attachments / accessories specified by the Manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid
injury from tip-over.
Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination
to overturn.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.
This will prevent damage to the product due to lightning and power-line surges.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.

3

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment
from your new Plasma Display.
To obtain maximum benefit fr om your set, please r ead these Instr uctions before making any adjustments,
and retain them for future reference.
Retain your purchase receipt also, and note down the model number and serial number of your set in
the space provided on the rear cover of these instructions.

For assistance, please call : 1-888-VIEW-PTV(843-9788)

or send e-mail to : [e-mail]

or visit us at www.panasonic.com (U.S.A)

For assistance, please call : 787-750-4300

or visit us at www.panasonic.com (Puerto Rico)

For assistance, please call : 1-800-561-5505

or visit us at www.panasonic.ca (Canada)

Table of Contents

Important Safety Instructions ...................................... 3

FCC STATEMENT .......................................................... 5

Safety Precautions........................................................ 6

Accessories ...................................................................8

Accessories Supplied................................................... 8

Optional Accessories ................................................... 8

Remote Control Batteries............................................. 9

Basic Controls............................................................. 10

Connections ................................................................ 11

Speakers connection ................................................. 12

AV Input Terminals connection................................... 12

COMPONENT/RGB Input connection ....................... 13

PC Input Terminals connection .................................. 15

SERIAL Terminals connection.................................... 17

Power ON/OFF and Input Signal Selection............... 18

AC cord connection.................................................... 18

Power ON/OFF .......................................................... 18

Select the Input Signal ............................................... 19

Selecting the ON-Screen Menu Language ................ 19

On-Screen Menu Display from Remote Control....... 20

ASPECT Controls........................................................ 22

Adjusting PICTURE POSITION/SIZE ......................... 24

SOUND Adjustment .................................................... 26

MUTE......................................................................... 26

SURROUND Controls ................................................. 27

PICTURE Adjustments................................................ 28

SCREENSAVER (For preventing after-images) ........ 30

NEGATIVE / SCROLL Selection................................ 30

ON / OFF Selection.................................................... 30

SIDE BAR ADJUST ................................................... 31

SET UP for Input Signals............................................ 32

COMPONENT/RGB IN SELECT ............................... 32

3D Y/C FILTER – For NTSC Video images ............... 32

COLOR SYSTEM / Panasonic AUTO........................ 33

3:2 PULLDOWN......................................................... 33

SYNC ......................................................................... 34

H-FREQ. (kHz)/V-FREQ. (Hz) ................................... 34

Troubleshooting.......................................................... 35

Specifications.............................................................. 38

4

FCC STATEMENT

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

FCC CAUTION:
To assure continued compliance and possible undesirable interference, the provided ferrite cores must be
used when connecting this plasma display to video equipment; and maintain at least 40cm spacing to other
peripheral devices. Refer to instructions on pages 15, and 17. Any changes or modifications not expressly
approved by Matsushita Electric Corporation of America could cause harmful interference and would void the
user’s authority to operate this device.

FCC Declaration of Conformity

Responsible Party: Matsushita Electric Corporation of America

One Panasonic Way, Secaucus, NJ 07094

Contact Source: Panasonic Consumer Electronics Company

1-888-843-9788
email: [e-mail]

Attach the ferrite core:

The ferrite cores provided as a supplied accessory must be used when connecting this Plasma Display to video
equipment. (see page 15, 17)

CANADIAN NOTICE:

This Class B digital apparatus complies with Canadian ICES-003.

Note:

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent after­image to remain on the High Definition Plasma Display.
Examples of still pictures include logos, video games, computer images, teletext and images displayed in
4:3 mode.

Trademark Credits

VGA is a trademark of International Business Machines Corporation.

•

Macintosh is a registered trademark of Apple Computer, USA.

•

S-VGA is a registered trademark of the Video Electronics Standard Association.

•

Even if no special notation has been made of company or product trademarks, these trademarks have been fully
respected.

5

Safety Precautions

WARNING

Set up

Do not place the Plasma Display on sloped or unstable surfaces.

The Plasma Display may fall off or tip over.

•

Do not place any objects on top of the Plasma Display.

If water spills onto the Plasma Display or foreign objects get inside it, a short-circuit may occur which could result in fire

•

or electric shock. If any foreign objects get inside the Plasma Display, please consult an Authorized Service Center.

Do not cover the ventilation holes.

Doing so may cause the Plasma Display to overheat, which can cause fire or damage to the Plasma Display.

•

If using the pedestal (optional accessory), leave a space of 3 15/16” (10 cm) or more at the top, left and right, 2 3/8”
cm) or more at the bottom, and 2 3/4” (7 cm) or more at the rear. If using some other setting-up method, leave a
space of 3 15/16” (10 cm) or more at the top, bottom, left and right, and 3/4” (1.9 cm) or more at the rear.

Avoid installing this product near electronic equipment that easily receives electromagnetic waves.

It may cause interference in image, sound, etc. In particular, keep video equipment away from this product.

•

AC Power Supply Cord

The Plasma Display is designed to operate on 120 V AC, 50/60 Hz.

(6

Securely insert the power cord plug as far as it will go.

If the plug is not fully inserted, heat may be generated which could cause fire. If the plug is damaged or the wall socket

•

plate is loose, they should not be used.

Do not handle the power cord plug with wet hands.

Doing so may cause electric shocks.

•

Do not do anything that might damage the power cable. When disconnecting the power cable, hold the plug, not
the cable.

Do not make any modifications, place heavy objects on, place near hot objects, heat, bend, twist or forcefully pull the

•

power cable. Doing so may cause damage to the power cable which can cause fire or electric shock. If damage to the
cable is suspected, have it repaired at an Authorized Service Center.

If the Plasma Display will not be used for a long period of time, unplug the power cord from the wall outlet.

If problems occur during use

If a problem occurs (such as no picture or no sound), or if smoke or an abnormal odor is detected from the Plasma
Display, unplug the power cord immediately.

Continuous use of the Display under these conditions might cause fire or permanent damage to the unit. Have the

•

Display evaluated at an Authorized Service Center. Services to the Display by any unauthorized personnel are strongly
discouraged due to its high voltage dangerous nature.

If water or foreign objects get inside the Plasma Display, if the Plasma Display is dropped, or if the cabinet
becomes damaged, disconnect the power cord plug immediately.

A short may occur, which could cause fire. Contact an Authorized Service Center for any repairs that need to be made.

•

6

Safety Precautions

CAUTION

This Plasma Display is for use only with the following optional accessories. Use with any other type of optional
accessories may cause instability which could result in the possibility of injury.

(All of the following accessories are manufactured by Matsushita Electric Industrial Co., Ltd.)

Speakers ........................................ TY-SP37P5W-K (TH-37PW5)

•

Pedestal (supplied for USA)............TY-ST05-K

•

Wall-hanging bracket (vertical)....... TY-WK37PV3 (TH-37PW5)

•

Wall-hanging bracket (angled) ....... TY-WK42PR1 (TH-42PW5)

•

Always be sure to ask a qualified technician to carry out set-up.

When using the Plasma Display

Do not bring your hands, face or objects close to the ventilation holes of the Plasma Display.

Top of the Plasma Display is usually very hot due to the high temperature of exhaust air being released through the

•

ventilation holes. Burns or personal injuries can happen if any body parts are brought too close. Placing any object
near the top of the display could also result in heat damages to the object as well as to the Display if its ventilation
holes are blocked.

TY -SP42PWD3W , TY -SP42P5W-K (TH-42PW5)

Be sure to disconnect all cables before moving the Plasma Display.

Moving the Display with its cables attached might damage the cables which, in turn, can cause fire or electric shock.

•

Disconnect the power plug from the wall outlet as a safety precaution before carrying out any cleaning.

Electric shocks can result if this is not done.

•

Clean the power cable regularly to prevent it from becoming dusty.

Built-up dust on the power cord plug can increase humidity which might damage the insulation and cause fire. Unplug

•

the cord from the wall outlet and clean it with a dry cloth.

Cleaning and maintenance

The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning
cloth or a soft, lint-free cloth.

If the surface is particularly dirty, soak a soft, lint-free cloth in a weak detergent solution and then wring the cloth to

•

remove excess liquid. Use this cloth to wipe the surface of the display panel, then wipe it evenly with a dry cloth, of the
same type, until the surface is dry.

Do not scratch or hit the surface of the panel with fingernails or other hard objects. Furthermore, avoid contact with

•

volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the surface may be adversely
affected.

If the cabinet becomes dirty, wipe it with a soft, dry cloth.

If the cabinet is particularly dirty , soak the cloth in a weak detergent solution and then wring the cloth dry. Use this cloth

•

to wipe the cabinet, and then wipe it dry with a dry cloth.

Do not allow any detergent to come into direct contact with the surface of the Plasma Display.

•

If water droplets get inside the unit, operating problems may result.
Avoid contact with volatile substances such as insect sprays, solvents and thinner , otherwise the quality of the cabinet

•

surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods in contact
with articles made from rubber or PVC.

Note:

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent after-image to remain
on the Plasma Display.
Examples of still pictures include logos, video games, computer images, teletext and images displayed in 4:3 mode.

7

Accessories

Accessories Supplied

Check that you have the Accessories and items shown

Operating
Instruction book

Warranty

Remote Control
Transmitter
EUR646525

INPUT

SURROUND

VOL

NR


SET UP

SOUND

POS. /SIZE

ASPECT

OFF TIMER

PC

PLASMA DISPLAY

(small size)
J0KF00000018 × 1

Batteries for the Remote
Control Transmitter
(AA(R6) Battery × 2)

Ferrite core
(large size)
J0KG00000054 × 2

AC cord

Fixing bandsFerrite core

Optional Accessories

Speakers

•

TY-SP37P5W-K (TH-37PW5)
TY -SP42PWD3W , TY -SP42P5W-K (TH-42PW5)

Pedestal

•

TY-ST05-K
(supplied for USA)

For assembling

Full instructions are supplied with each of the optional accessories for use with this Plasma Display.

Wall-hanging bracket

•

(vertical)
TY-WK37PV3 (TH-37PW5)

Wall-hanging bracket

•

(angled)
TY-WK42PR1 (TH-42PW5)

8

Remote Control Batteries

Requires two AA batteries.

1. Turn the transmitter face down.

Press and slide off the battery
cover.

2. Install the batteries as shown in the
battery compartment. (Polarity + or
– must match the markings in the
compartment.)

3. Replace the cover and slide in
reverse until the lock snaps.

Two "AA" size

Helpful Hint:

For frequent remote control users, replace old batteries with
Alkaline batteries for longer life.

Precaution on battery use

Incorrect installation can cause battery leakage and corrosion that will damage the remote control transmitter.

Observe the following precautions:

1. Batteries should always be replaced as a pair. Always use new batteries when replacing the old set.

2. Do not combine a used battery with a new one.

3. Do not mix battery types (example: “Zinc Carbon” with “Alkaline”).

4. Do not attempt to charge, short-circuit, disassemble, heat or burn used batteries.

5. Battery replacement is necessary when the remote control acts sporadically or stops operating the Plasma Display.

9

Basic Controls

R - STANDBY

Main POWER

G POWER ON

TH-42PW5

ON/OFF Switch

Remote control
sensor

Power Indicator

The Power Indicator will light.

POWER-OFFIndicator not illuminated

•

(The unit will still consume some power
as long as the power cord is inserted into
the wall outlet.)

.....

STAND-BY

•

POWER-ON.....Green

•

Red

STAND-BY(ON/OFF) button

The Plasma Display must first be plugged into the wall
outlet and turned on at the power switch. (see page 18)
Press this button to turn the Plasma Display ON, from
STAND-BY mode. Press it again to turn the Plasma
Display OFF to STAND-BY mode.

STATUS button

Press the “STATUS” button to display
the current system status.

VIDEO

NORMAL

OFF TIMER 90

1
2

3

1 VIDEO(S VIDEO), COMPONENT/

RGB, PC mode
2 ASPECT mode (see page 22)
3 OFF TIMER
The off timer indicator is displayed only
when the off timer has been set.

N button

(see page 25, 26, 28)

PICTURE button

(see page 28)

PICTURE POS./SIZE button

(see page 24)

PC button

Press the “PC” mode selection
button to select the PC mode.
This button is used to switch
directly to PC mode.

The Plasma Display can be preset to switch to stand-by after a fixed period. The
setting changes to 30 minutes, 60 minutes, 90 minutes and 0 minutes (off timer
cancelled) each time the button is pressed.

When three minutes remain, “OFF TIMER 3” will flash.
The off timer is cancelled if a power interruption occurs.

INPUT

—

VOL

INPUT button
(VIDEO (S VIDEO),
COMPONENT/RGB and
PC Mode Selection)

(see page 19)

C.A.T.S sensor
Plasma C.A.T.S (Contrast Automatic Tracking System)

Plasma C.A.T.S automatically senses the ambient light
conditions and adjusts the brightness and gradation
accordingly,to optimise contrast.
(Effective when Picture mode is set to Auto.)

SURROUND button

(see page 27)

INPUT button
(VIDEO(S VIDEO), COMPONENT/
RGB, PC Mode Selection)

Press to select VIDEO(S VIDEO),
COMPONENT/RGB, PC input signal
modes sequentially. (see page 19)

INPUT

SURROUND

VOL

NR

Sound mute On/Off (see page 26)

VOLUME Adjustment

Press the Volume Up “+” or Down “–
” button to increase or decrease the

sound volume level.

R button (see page 21)

ACTION button

Press to make selections


SOUND

SET UP

POSITION buttons
SET UP button (see page 20)

POS. /SIZE

ASPECT

SOUND button (see page 26)

ASPECT button

Press to adjust the aspect.

PC

OFF TIMER

(see page 22)

OFF TIMER button

+

VOLUME Adjustment

Press the Volume Up “+” or
Down “–” button to increase
or decrease the sound
volume level.

30 60

0

90

10

Connections

SPEAKER
Terminals (R)

– Cable fixing bands

Secure any excess cables with bands, as required.

Pass the attached cable fixing
band through the clip as
shown in the figure.

1

To tighten:

Pull

SPEAKER
Terminals (L)

AC cord connection (see page 18)

To secure cables connected to Terminals, wrap
the cable fixing band around them then pass the
pointed end through the locking block, as shown
in the figure.

While ensuring there is sufficient slack in
cables to minimize stress (especially in the
power cord), firmly bind all cables with the
supplied fixing band.

2

To tighten:

Push
the catch

Pull

RL

A V IN Terminals
(see page 12, 13)

AUDIO

S VIDEOVIDEO

RL

AUDIO

COMPONENT/RGB IN and Audio
IN Terminals (see page 13,14)

AUDIO

HD

VD

COMPONENT/RGB INAV IN

P

B/CB

PR/CR/R

/B Y/G

PC IN

From EXIT monitor Terminal
on Computer (see page 15)

SERIAL

From SERIAL Terminal on
Computer (see page 17)

11

Connections

Speakers connection

When connecting the speakers, be sure to use only the optional accessory
speakers.
Refer to the speaker’s Installation Manual for details on speaker installation.

1

Remove the
tubes from the
ends of the
speaker wires.

Speakers (Optional accessories)

AV Input Terminals connection

Connect the signal source equipment.

2

3

1

2

An S VIDEO VCR connection

(S VIDEO VCR)

2×RCA audio

cables

AUDIO

Audio input to

L/R sockets

Note:

Additional equipment and cables shown are not supplied with this set.

Audio

OUT

RL

RL

AUDIO

AV IN

Video

OUT

S Video

OUT

S VIDEO

Video input to

S VIDEO

S VIDEOVIDEO

socket

12

S VIDEO 4 pin socket

Luminance earth

Luminance in

Chrominance earth

Chrominance in

××

3

×RCA audio video cables connection

××

(VCR)

Connections

Audio

OUT

RL

Video

OUT

AUDIO-VIDEO

Video input to

RCA socket

3×RCA audio

video cables

Audio input to

L/R sockets

Notes:

(1) S-Video input will override the composite video signal when S-Video lead is connected.
(2) Additional equipment and cables shown are not supplied with this set.

COMPONENT/RGB Input connection

Component signals (Y, PB, PR ) connection

RL

AUDIO

AV IN

S VIDEOVIDEO

(DVD Player)

Y

Y, PB, P

P

B

P

R

L

R

3×RCA
video cables

AUDIO

2×RCA

R

audio cables

Audio input to

L/R sockets

RL

AUDIO

COMPONENT/RGB IN

HD

VD

PR/CR/R

P

B/CB

/B Y/G

Notes:

(1) Change the “COMPONENT/RGB-IN” setting in the “SET UP” menu to “COMPONENT”. (see page 32)
(2) Additional equipment and cables shown are not supplied with this set.

13

Connections

RGB signal (R, G, B, HD, VD) connection

Example of input signal source

HDTV-compatible VCR

RGB camera

Computer

RGB input to
R, G, B, HD, VD sockets

5×BNC
RGB cables

AUDIO

2×RCA audio cables

Audio input to
L/R sockets

BNC-RCA
adaptor plug

RL

AUDIO

P

R/CR

HD

VD

/R

COMPONENT/RGB IN

P

B/CB

/B

Y/G

VD

HD

R

B

G

Notes:

(1) Change the “COMPONENT/RGB-IN” setting in the “SET UP” menu to “RGB”. (see page 32)
(2) Additional equipment, cables and adaptor plugs shown are not supplied with this set.

14

PC Input Terminals connection

COMPUTER

INPUT

—

VOL

+

POWER /

R - STANDBY
G POWER ON

Conversion adapter
(if necessary)

Connect a cable that matches
the audio output terminal on the computer.

Less than

15

3"

/16

(10 cm)

Ferrite core (small size)

(supplied)

Audio

Ferrite core (large size)
(supplied)

D-sub 15p

RGB

PC cable

Less than

15

3"

/16

(10 cm)

Stereo plug

Connections

AUDIO

PC IN

Installing the ferrite core (Small size)

1

2

3

Open

Pull back the tabs
(in two places)

Press the cable
through and close

Installing the ferrite core (Large size)

1

2

3

Open

Pull back the tabs
(in two places)

Press the cable
through and close

Notes:

(1) Computer signals which can be input are those with a horizontal scanning frequency of 15.6 to 110 kHz and vertical

scanning frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200
lines.)

(2) The display resolution is a maximum of 640 × 480 dots when the aspect mode is set to “NORMAL”, and 852 × 480 dots

when the aspect mode is set to “FULL”. If the display resolution exceeds these maximums, it may not be possible to
show fine detail with sufficient clarity.

(3) The PC input terminals are DDC1/2B-compatible. If the computer being connected is not DDC1/2B-compatible, you will

need to make setting changes to the computer at the time of connection.
(4) Some PC models cannot be connected to the set.
(5) There is no need to use an adapter for computers with DOS/V compatible D-sub 15P terminal.
(6) The computer shown in the illustration is for example purposes only.
(7) Additional equipment and cables shown are not supplied with this set.
(8) Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the specified

frequency range.

15

Connections

1

67839

45

10

1514131211

2

16

SERIAL Terminals connection

The SERIAL terminal is used when the Plasma Display is controlled by a computer.

COMPUTER

RS-232C
straight cable

Ferrite core
(large size)
(supplied)

SERIAL

Connections

9876

53214

Pin layout for RS-232C

Installing the ferrite core

(Large size)

D-sub 9p

Notes:

Less than

15

3"

/

16

(10 cm)

Open

(1) Use the RS-232C cable to connect the computer to the Plasma Display.
(2) The computer shown is for example purposes only.
(3) Additional equipment and cables shown are not supplied with this set.

The SERIAL terminal conforms to the RS-232C interface specification, so that the Plasma Display can be controlled by a
computer which is connected to this terminal.
The computer will require software which allows the sending and receiving of control data which satisfies the conditions
given below. Use a computer application such as programming language software. Refer to the documentation for the
computer application for details.

Communication parameters

Signal level

Synchronization method

Baud rate

Parity

Character length

Stop bit

Flow control

RS-232C compliant

Asynchronous

9600 bps

None
8 bits

1 bit

–

Basic format for control data

The transmission of control data from the computer starts
with a STX signal, followed by the command, the
parameters, and lastly an ETX signal in that order. If there
are no parameters, then the parameter signal does not need
to be sent.

STX

Start
(02h)

Colon Parameter(s)

3-character
command (3bytes)

(1 - 5 bytes)

ETX:C2C1 C3 P2P1 P3 P4 P5

End
(03h)

Notes:

(1) If multiple commands are transmitted, be sure to wait

for the response for the first command to come from

this unit before sending the next command.
(2) If an incorrect command is sent by mistake, this unit will

send an “ER401” command back to the computer.

D-sub 9-pin female

Command

Command
PON
POF
AVL

AMT
IIS

(When
Used RCA
Terminal
Board)
DAM

RS-232C Conversion cable

2
3
5

4 • 6

7
8

1 • 9

Parameter
None
None

**

0
1
None
VID
YP1

Power ON
Power OFF
Volume 00 - 63
Audio MUTE OFF
Audio MUTE ON
Input select (toggle)
VIDEO Mode
COMPONENT / RGB mode (processed as

a Y/PB/PR or RGB signals as set by this unit)
RG1
None
NORM
ZOOM
FULL
JUST
SELF

PC mode

Screen mode select (toggle)

NORMAL (4:3)

ZOOM

FULL

JUST

Panasonic AUTO

Details

R X D
T X D

GND

Non use

Shorted

NC

Control details

With the power off, this display responds to PON command only.

17

Power ON/OFF and Input Signal Selection

AC cord connection

Connecting the AC cord plug to the Plasma Display.

Power ON/OFF

Connecting the plug to the Wall Outlet

Press the POWER switch on the Plasma Display to turn the
set on : POWER-ON.

INPUT

—

VOL

+

R - STANDBY
G POWER ON

Power Indicator: Green

R - STANDBY
G POWER ON

TH-42PW5

Power Indicator

Remote Control Sensor

When the POWER is turned on for the first
time, the LANGUAGE selection screen is
displayed.

From the second time on, language
selection can be done from the setup
menu. (see page 19)

Select the desired language using the
and

keys and press the ACTION

button.

INPUT

SURROUND

VOL

NR

OSD LANGUAGE

English (UK

Deutsch
Fran ais

Italiano

p

a ol

Es

ENGLISH (US

SELECT

Example: The screen below is displayed for a while after the

Plasma Display is turned on. (setting condition is
an example.)

From the second time on, the screen shown below

)

is displayed for a while (setting condition is an
example).

VIDEO

NORMAL

)

SET

Press the

button on the remote control to turn the

Plasma Display off.

Power Indicator: Red (STAND-BY)

Press the

button on the remote control to turn the

Plasma Display on.

Power Indicator: Green

T o turn the power for the Plasma Display of f, press the
on the Plasma Display, when the Plasma Display is on or in
standby mode.

switch

18

Power ON/OFF and Input Signal Selection

VIDEO COMPONENT PC

Select the Input Signal

INPUT

— VOL +

R - STANDBY
G POWER ON

INPUT

Press the INPUT button to select the input
video signal desired from equipment such as
a VCR which has been connected to the
Plasma Display.

Input signals will change as follows:
For COMPONENT INPUT (see page 32)

INPUT

— VOL +

For RGB INPUT (see page 32)

VIDEO RGB PC

INPUT

SURROUND

VOL

Selecting the On-Screen Menu Language

SET UP

COMPONENT/RGB-IN SELECT

SIGNAL

SCREENSAVER

OSD LANGUAGE

RGB

ENGLISH (US

)

19

On-Screen Menu Display from Remote Control

To PICTURE adjust menu
(see page 28)


NORMALIZE
PICTURE MENU

BRIGHTNESS
COLOR
TINT
SHARPNESS

COLOR TEMP

NORMAL

STANDARD
0
0
0
0
0

NORMAL

Press to select each
menu.

INPUT

SURROUND

VOL

NR

To SOUND adjust menu
(see page 26)

SOUND

NORMALIZE
AUDIO MENU
BASS
TREBLE
BALANCE
SURROUND

NORMAL

STANDARD
0
0
0

ON

T o PICTURE POS./SIZE adjust
menu (see page 24)
During “VIDEO (S VIDEO)” and
“COMPONENT” input signal modes.

PICTURE POS./SIZE

NORMALIZE

H-POS
H-SIZE
V-POS
V-SIZE

NORMAL

During “RGB” and “PC”
input signal modes.

PICTURE POS./SIZE

NORMALIZE

H-POS

H-SIZE
V-POS
V-SIZE
CLOCK PHASE

NORMAL


POS. /SIZE

PC

PLASMA DISPLAY

SOUND

SET UP

ASPECT

OFF TIMER

To SET UP menu (see page 32)

SET UP

COMPONENT/RGB-IN SELECT

SIGNAL

SCREENSAVER

OSD LANGUAGE

SET UP

COMPONENT/RGB-IN SELECT

SIGNAL

SCREENSAVER

OSD LANGUAGE

RGB

ENGLISH (US

RGB

ENGLISH (US

)

)

20

On-Screen Menu Display from Remote Control

To SIGNAL screen for VIDEO (see page 32, 33)

[

VIDEO

ON

AUTO

OFF

NORMAL

[

COMPONENT

OFF

[

RGB

H & V

Press to access “SIGNAL” setup menu.

R

Press the R button to return
to “SET UP” menu.

SIGNAL
3D Y/C FILTER (NTSC

COLOR SYSTEM
3:2 PULLDOWN
Panasonic AUTO (4:3

To SIGNAL screen for COMPONENT (see page 33)

)

)

SIGNAL
3:2 PULLDOWN

To SIGNAL screen for RGB (see page 34)

SIGNAL
SYNC

H

-

FREQ. kHz

-

FREQ. Hz

V

To SIGNAL screen for PC (see page 34)

31.5

60.0

SIGNAL
SYNC

H

-

FREQ. kHz

-

FREQ. Hz

Note:

“SIGNAL” setup menu displays a different setting condition for each input signal. (see page 19)

V

31.5

60.0

H & V

[

PC

]

]

]

]

Press to access “SCREENSAVER”
menu.(see page 30)

R

Press the R button to return
to “SET UP” menu.

To setup SCREENSAVER.

SCREENSAVER
FUNCTION

MODE
SIDE BAR ADJUST

WHITE BAR SCROLL

ON

OFF

21

ASPECT Controls

The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format
picture.

INPUT

SURROUND

VOL

NR


POS. /SIZE

PC

SOUND

SET UP

ASPECT

OFF TIMER

ASPECT

ASPECT button

The aspect mode changes each time the ASPECT button
is pressed.

NORMAL ZOOM FULL

Panasonic AUTO JUST

Notes:

(1) During RGB and PC input signal modes, the mode switches between

“NORMAL”, “ZOOM” and “FULL” only.

(2) For a 525p (480p) signal input during “COMPONENT” input signal

mode, the mode switches between “ZOOM” and “FULL” only.

(3) For a 1,125i (1,080i), 750p (720p) signal input during

“COMPONENT” input signal mode, the mode is set to “FULL” mode,
and switching is not possible.
For a 525i (480i), 625i (575i) signal input during “Component” input
signal mode, “Panasonic Auto” can not be selected.

(4) The aspect mode is memorized separately for each input terminal

(VIDEO, COMPONENT, RGB and PC).

22

PLASMA DISPLAY

ASPECT Controls

Mode

NORMAL

ZOOM

FULL

JUST

4

NORMAL

4

4

4


3

16

ZOOM

3

16

FULL

3

16

JUST

3 9

Explanation

NORMAL will display a 4:3 picture at its standard 4:3
size.

ZOOM mode magnifies the central section of the picture.

9

FULL will display the picture at its maximum size but
with sight elongation.

9

JUST mode will display a 4:3 picture at its maximum
size but with aspect correction applied to the center of
the screen so that elongation is only apparent at the
left and right edges of the screen. The size of the picture
will depend on the original signal.

416

Panasonic AUTO

39

The display will automatically become enlarged
(depending on the picture source), allowing you to view
the picture at its maximum size.

Note:

Panasonic

AUTO

For an elongated image

4

3

For a 4:3 image

Image is expanded

Changes in accordance
with the Panasonic
AUTO mode setting (see
page 33)

Panasonic AUTO mode is designed to automatically
adjust the aspect ratio to handle a mix of 16:9 and 4:3
program material. Certain 4:3 program material, such
as stock market data screens, may occasionally cause
the image size to change unexpectedly . When viewing
such programs, it is recommended that the ASPECT
be set to NORMAL.

Note:

Do not allow the picture to be displayed in 4:3 mode for an extended period, as this can cause a parmanent after-image to
remain on the Plasma Display Panel.

23

Adjusting PICTURE POSITION/SIZE

24

Adjusting PICTURE POS./SIZE

H-POS

H-SIZE

V-POS

When the Position Left

When the Position Left

When the Position Left

“ ”

button is pressed

”

“

button is pressed

“ ”

button is pressed

When the Position Right

When the Position Right

When the Position Right

“ ”

button is pressed

”

“

button is pressed

“ ”

button is pressed

“ ”

“ ”

button is pressed

or Right

“ ”

button to

When the Position Left

V-SIZE

CLOCK PHASE

(RGB/PC in Mode)

Flickering and distortion can be eliminated by using the Position Left
carry out adjustment.

N

Helpful Hint ( /

While the PICTURE POS./SIZE display is active, if either the N button on the remote control is pressed at any time or the

(ACTION button) is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

“ ”

button is pressed

NORMALIZE

Normalization)

When the Position Right

25

SOUND Adjustment

1
2

BASS

Adjusts low sounds

TREBLE

Adjusts high sounds

BALANCE

Adjusts left and right
volumes

SURROUND (see next page)
Select ON or OFF

SOUND

Press to display the Sound menu.

Select to adjust each item.

Press to select the desired adjustment menu.

Select the desired level by listening to the sound.

SOUND

NORMALIZE
AUDIO MENU

BASS
TREBLE
BALANCE
SURROUND

NORMAL

STANDARD
0
0
0

ON

STANDARD

AUTO

INPUT

SURROUND

VOL

N R



Emits the original sound.

Automatically controls
proper volume level.

SOUND

SET UP

To end adjustments

•

R

Press the R button

Note:

Press the SURROUND button to directly turn the surround effect ON and OFF. (see next page)
BASS, TREBLE and SURROUND settings are memorized separately for each SOUND mode (STANDARD, AUTO).

Helpful Hint ( /

While the “SOUND” menu is displayed, if either the N button on the remote control is pressed at any time or the
(ACTION button) is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

N

NORMALIZE

Normalization)

MUTE

Useful when answering the phone or receiving visitors.

Press this button to mute the sound.
Press again to reactivate sound. Sound is also reactivated when power is turned off or
volume level is changed.

26

SURROUND Controls

INPUT

SURROUND

VOL

NR


POS. /SIZE

PC

SOUND

SET UP

ASPECT

OFF TIMER

SURROUND

SURROUND Button

The benefits of surround sound are enormous. You can be
completely enveloped in sound; just as if you were at a concert
hall or cinema.

The surround setting switches on and off each time the
SURROUND button is pressed.

ON OFF

SURROUND

Note:

The surround settings are memorized separately for each SOUND mode
(ST ANDARD, AUTO).

ON

PLASMA DISPLAY

27

PICTURE Adjustments

1

2


Select to adjust each item.


NORMALIZE
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP

NORMAL

Press to display the PICTURE menu.

Press to select the menu to adjust.

Select the desired level by looking at the picture
behind the menu.

Press the left
modes.

STANDARD

20

0
0
0
0

NORMAL

AUTO

Automatically selects the mode that best suits the
brightness of the environment.

STANDARD

For viewing in standard (evening lighting) environments.
This menu selects the normal levels of BRIGHTNESS
and PICTURE.


NORMALIZE
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP

or right
AUTO STANDARD

CINEMA DYNAMIC

button to switch between

NORMAL

STANDARD

20

0
0
0
0

NORMAL

DYNAMIC

For viewing in brighter environments.
This menu selects higher than normal levels of
BRIGHTNESS and PICTURE.

CINEMA

Ideal for movies.

• Can be selected for VIDEO/COMPONENT.

Note:

If you would like to change the picture and color of the
selected PICTURE menu to something else, adjust
using the items in the PICTURE menu. (see page 29)

Press the left
modes.

Helpful Hint ( /

While the “PICTURE” menu is displayed, if either the N button on the remote control is pressed at any time or the
(ACTION button) is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

N

NORMALIZE

Normalization)

or right

NORMAL COOL WARM

button to switch between

28

PICTURE Adjustments

Item


BRIGHTNESS

COLOR

TINT

(NTSC only)

SHARPNESS

Effect Adjustments

Adjusts the proper picture contrast.

Less More

Adjusts for easier viewing of dark pictures

Darker Brighter

such as night scenes and black hair.
Adjusts color saturation.

Less More

Adjust for natural flesh tones.

Reddish Greenish

Adjusts picture sharpness.

Less More

Notes:

(1)

“COLOR” and “TINT”

settings cannot
be adjusted for “RGB” and “PC” input
signal modes.

(2) You can change the level of each

function (PICTURE, BRIGHTNESS,
COLOR, TINT, SHARPNESS) for each
PICTURE menu.

(3) The setting details for STANDARD,

DYNAMIC and CINEMA respectively
are memorized separately for each
input mode (VIDEO (S VIDEO),
COMPONENT RGB and PC).

(4) The “TINT” setting can be adjusted for

NTSC signal only during “VIDEO
(S VIDEO)” input signal.

Note:

In PICTURE, there is nor a noticeable change even when contrast is increased with a bright picture or reduced with a dark
picture.

29

SCREENSAVER (For preventing after-images)

1

2

3

30

SIDE BAR ADJUST

OFF DARK MID BRIGHT

SCREENSAVER

1

2

Do not display a picture in 4:3 mode for an extended period, as
this can cause an after-image to remain on the side bars on either
side of the display field.
To prevent the appearance of such an after-image, change the
brightness of the side bars.

To display the SCREENSAVER screen.
(Refer to the previous page, operation guide steps 1 and 2)

Press to select the
SIDE BAR ADJUST.

Press to select
OFF, DARK, MID, BRIGHT.

side bars

Screen Display

after-images

SCREENSAVER
FUNCTION

MODE
SIDE BAR ADJUST

4:3

WHITE BAR SCROLL

ON

MID

R

3

Notes:

• Setting the side bar to BRIGHT mode for an extended period may result in occurence of after-images.

• The side bars may flash (alternate black/white) depending on the picture being shown on the screen. In such
an occurrence, use the Cinema mode.

Press to exit from SCREENSAVER.

31

SET UP for Input Signals

COMPONENT/RGB IN SELECT

Select to match the signals from the source connected to the COMPONENT/RGB input terminals.
Y, PB, PR signals
R, G, B, HD, VD signals

“COMPONENT”

“RGB”

1

SET UP

Press to display the SET UP menu screen.

INPUT

SURROUND

VOL

NR


SOUND

SET UP

2

Press to select the “COMPONENT/RGB IN
SELECT”.

Press to select the desired mode.

SET UP

COMPONENT/RGB-IN SELECT

SCREENSAVER

OSD LANGUAGE

COMPONENT RGB

POS. /SIZE

ASPECT

R

Press to exit from adjust mode.

SIGNAL

RGB

ENGLISH (US

)

3D Y/C FIL TER – For NTSC Video images

Select “SIGNAL” from the “SET UP” menu during VIDEO (S VIDEO) input signal mode.
(“SIGNAL [VIDEO]” menu is displayed.)

Press to select the “3D Y/C FILTER (NTSC)”.

Press to set ON/OFF.

R

Press to exit from adjust mode.

Note:

When on, this setting only affects NTSC input signals.

SET UP

COMPONENT/RGB-IN SELECT

SIGNAL

SCREENSAVER

OSD LANGUAGE

Press

SIGNAL
3D Y/C FILTER (NTSC

COLOR SYSTEM
3:2 PULLDOWN
Panasonic AUTO (4:3

(ACTION) button

)

ENGLISH (US

)

RGB

[

VIDEO

ON

AUTO

OFF

NORMAL

)

]

32

SET UP for Input Signals

COLOR SYSTEM / Panasonic AUTO

Select SIGNAL from the “SET UP” menu during VIDEO (S VIDEO) input signal mode.
(“SIGNAL [VIDEO]” menu is displayed.)

SET UP

Mode

Color system

Panasonic
AUTO (4:3)

Press to select the “COLOR SYSTEM” or
“Panasonic AUTO”.

Press to select each function.

If the image becomes unstable:

With the system set on Auto, under conditions of
low level or noisy input signals the image may in
rare cases become unstable. Should this occur,
set the system to match the format of the input
signal.

COMPONENT/RGB-IN SELECT

SIGNAL

SCREENSAVER

OSD LANGUAGE

Press

SIGNAL
3D Y/C FILTER (NTSC

COLOR SYSTEM
3:2 PULLDOWN
Panasonic AUTO (4:3

(ACTION) button

)

ENGLISH (US

)

RGB

[

VIDEO

ON

AUTO

OFF

NORMAL

Function
Set the color system to match the input signal. If set to “AUTO”, the color system is
determined creTf24.e7lly.TJET175.44 483.6 m172.28 483.6 lSBT10 0 0 10 9618083 07.76 Tm0 TwcSet theNORMTj/F7 1 Tf0.333 0 TD-0[(he)Tview 3)mage msnpu annstchang crrmat ofwhen nasonic

)

]

33

SET UP for Input Signals

SYNC

Select SIGNAL from the “SET UP” menu during RGB or PC input signal mode.

Press to adjust.

R

Press to exit from adjust mode.

Setting RGB sync signal

Confirm that the input is set to RGB INPUT (this setting is valid only for RGB INPUT).

H & V:
ON G: Uses a synchronized signal on the Video G signal, which is input

ON VIDEO: The composite video signal input from the VIDEO input terminal is

The H and V sync signals are input from the HD/VD connector.
from the G connector.
used by dividing the sync signals.

SET UP

COMPONENT/RGB-IN SELECT

SIGNAL

OSD LANGUAGE

Press

SIGNAL
SYNC

SIGNAL
SYNC

SYNC

SYNC

SYNC

SCREENSAVER

(ACTION) button

H

-

FREQ. kHz

-

FREQ. Hz

V

H

-

FREQ. kHz

-

FREQ. Hz

V

31.5

60.0

31.5

60.0

RGB

ENGLISH (US

H & V

H & V

H & V

ON G

ON VIDEO

)

[

RGB

[

PC

]

]

Setting PC sync signal

Confirm that the input is set to PC INPUT (this setting is valid only for PC INPUT).

H & V: The H and V sync signals are input from the HD/VD connector.
ON G: Uses a synchronized signal on the Video G signal, which is input from

the G connector.

H-FREQ (kHz)/V-FREQ (Hz)

Displays the H (Horizontal)/V (Vertical) frequencies.

This display is valid only for RGB input and PC input.
Display range:

Horizontal 15.6 - 110 kHz
Vertical 48 - 120 Hz

34

SYNC

SYNC

H-FREQ. kHz
V

-

FREQ. Hz

31.5

60.0

H & V

ON G

Troubleshooting

Before you call for service, determine the symptoms and make a few simple checks as shown below.


Interference

Normal Picture

No Picture

No Picture

Symptoms

Sound

Noisy Sound

No Sound

No Sound

Normal Sound

Checks

Electrical Appliances
Cars/Motorcycles
Fluorescent light

Volume
(Check whether the mute function has been
activated on the remote control.)

Not plugged into AC outlet
Not switched on
PICTURE and BRIGHTNESS/Volume setting
(Check by pressing the power switch or
stand-by button on the remote control.)

If a signal with a non-applicable color system
format, or frequency is input, only the input
terminal indication is displayed.

No Color

Plasma Display panel

Symptoms

Some parts of the screen do not
light up.

After-images appear

Color controls set at minimum level.
(see page 28, 29)
Color system (see page 33)

Normal Sound

Check

The plasma display panel is manufactured using an extremely high level of precision
technology , however, sometimes some parts of the screen may be missing picture
elements or have luminous spots. This is not a malfunction.

Do not allow a still picture to be displayed for an extended period, as this can
cause a permanent after-image to remain on the Plasma Display.
Examples of still pictures include logos, video games, computer images, teletext
and images displayed in 4:3 mode.

Note:

The permanent after-image on the Plasma Display resulting from fixed image use
is not an operating defect and as such is not covered by the Warranty.
This product is not designed to display fixed images for extended periods of time.

35

36

37

Specifications

Power Source
Power Consumption

Maximum
Stand-by condition
Power off condition

Plasma Display panel

Contrast Ratio

Screen size

Operating condition

Temperature
Humidity

Applicable signals

Color System

Scanning format

PC signals

Connection terminals

AV

COMPONENT/RGB

PC

SERIAL

SPEAKERS (6 Ω)

818 mm (W) × 461 mm (H) × 939 mm (diagonal)

408,960 (852 (W) × 480 (H)) [2,556 × 480 dots]

NTSC, PAL, PAL60, SECAM, Modified NTSC
525i (480i), 625i (575i), 525p (480p), 625p (575p), 750p (720p), 1,125/60i, 50i, 24p,
24sF (1,080/60i, 50i, 24p, 24sF) ·············· SMPTE 274M
VGA display
VGA
SVGA, XGA, SXGA, UXGA ··············(compressed)
Horizontal scanning frequency 15.6 - 110 kHz
Vertical scanning frequency 48 - 120 Hz

Video IN (RCA)
S VIDEO IN (MINI DIN 4PIN)
AUDIO IN (RCA PIN JACK × 2)
Y/G (RCA)

PB/B (RCA)
PR/R (RCA)
HD (RCA)
VD (RCA)
AUDIO IN (RCA PIN JACK × 2)
(HIGH-DENSITY D-SUB 15PIN)

AUDIO IN (M3 JACK)
EXTERNAL CONTROL TERMINAL (D-SUB 9PIN)

TH-37PW5 TH-42PW5

120 V AC, 50/60 Hz

325 W 395 W

2.3 W 2.3 W

0.8 W 0.8 W

Drive method AC type Drive method AC type

37-inch, 16:9 aspect ratio 42-inch, 16:9 aspect ratio

3000:1

920 mm (W) × 518 mm (H) × 1056 mm (diagonal)

No. of pixels No. of pixels

408,960 (852 (W) × 480 (H)) [2,556 × 480 dots]

34 °F - 104 °F (0 °C - 40 °C)

20 % - 80 %

1.0 Vp-p (75-ohm)
Y: 1 Vp-p (75-ohm), C: 0.286 Vp-p (75-ohm)

0.5 Vrms (high impedance)

1.0 Vp-p/composite (75-ohm)

0.7 Vp-p/non-composite (75-ohm)

0.7 Vp-p (75-ohm)

0.7 Vp-p (75-ohm)

1.0 - 5.0 Vp-p (high impedance)

1.0 - 5.0 Vp-p (high impedance)

0.5 Vrms (high impedance)
R,G,B/0.7 Vp-p (75-ohm)
HD, VD/1.0 - 5.0 Vp-p (high impedance)

0.5 Vrms (high impedance)
RS-232C COMPATIBLE

16W [8 W + 8 W] (10 % THD)

38

Accessories Supplied

Remote Control Transmitter

Batteries

Ferrite core

Fixing bands

Optional Supplied

Specifications

TH-37PW5 TH-42PW5

EUR646525

2 × AA Size

1 × J0KF00000018, 2 × J0KG00000054

(TMME203 or TMME 187) × 2

Speakers

Pedestal(supplied for USA)

Wall-hanging bracket (vertical)
Wall-hanging bracket (angled)

Dimensions

××

× H

××

××

× D)

××

(W

Mass (Weight)

TY-SP37P5W-K

TY -SP42PWD3W, TY-SP42P5W-K

TY-ST05-K

TY-WK37PV3 TY-WK42PV1

TY-WK42PR1

36.2” (920 mm) × 21.7” (550 mm) × 3.5” (89 mm) 40.2” (1,020 mm) × 24” (610 mm) × 3.5” (89 mm)

3.5"

(89 mm)

24" (610 mm)

36.2" (920 mm)

—

VOL

+

INPUT

POWER /

R - STANDBY
G POWER ON

3.5"

(89 mm)

21.7" (550 mm)

40.2" (1,020 mm)

INPUT

—

VOL

+

POWER /

R - STANDBY
G POWER ON

approx. 53.9 lbs (main unit only) approx. 62.7 lbs (main unit only)
approx. 63.1 lbs (with speakers) approx. 72.0 lbs (with speakers)

Note:

Design and specifications are subject to change without notice. Weight and dimensions shown are approximate.

39

Customer’s Record

The model number and serial number of this product can be found on its rear panel. You should note this
serial number in the space provided below and retain this book, plus your purchase receipt, as a permanent
record of your purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes.

Model Number Serial Number

Panasonic Consumer Electronics
Company, Division of Matsushita
Electric Corporation of America

One Panasonic Way Secaucus
New Jersey 07094

Panasonic Sales Company,
Division of Matsushita Electric of
Puerto Rico Inc. (“PSC”)

Ave. 65 de Infanteria, Km 9.5
San Gabriel Industrial Park,
Carolina, Puerto Rico 00985

Panasonic Canada Inc.

5770 Ambler Drive
Mississauga, Ontario
L4W 2T3

Printed in Japan

MBS0702S0
