Operating Instructions

INTERCHANGEABLE LENS

FOR DIGITAL CAMERA

Thank you for purchasing Panasonic product.

Please read these instructions carefully before using this product, and save this manual for future use.

This lens can be attached to a 35 mm digital camera that complies with the Leica Camera AG L-Mount standard and that is equipped with a full-frame image sensor.

0 L-Mount is a trademark or registered trademark of Leica Camera AG.

0 Other names, company names, product names mentioned in this document are trademarks or registered trademarks of the companies concerned.

Contents
Information for Your Safety....................................	18
Precautions............................................................	19
Supplied Accessories.............................................	20
Names and Functions of Components...................	21
Attaching the Lens .................................................	22
Switching AF/MF....................................................	23
Cautions for Use ....................................................	24
Troubleshooting .....................................................	24
Specifications.........................................................	25
Limited Warranty (ONLY FOR U.S.A.)...................	26
Limited Warranty (ONLY FOR CANADA)..............	28

English

DVQX1747 17

Information for Your Safety

Keepthe unit asfar awayaspossiblefromelectromagnetic equipment (such as microwave ovens, TVs, video games, radio transmitters, high-voltage lines etc.).

0Do not use the camera near cell phones because doing so may result in noise adversely affecting the pictures and sound.

0If the camera is adversely affected by electromagnetic equipment and stops functioning properly, turn the camera off and remove the battery and/or the connected AC adaptor. Then reinsert the battery and/or reconnect the AC adaptor and turn the camera on.

THE FOLLOWING APPLIES ONLY IN THE U.S.A. FCC Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

18 DVQX1747

0 Reorient or relocate the receiving antenna.

0 Increase the separation between the equipment and receiver.

0 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 0 Consult the dealer or an experienced radio/TV technician for help.

Any unauthorized changes or modifications to this equipment would void the user’s authority to operate this device.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Supplier’s Declaration of Conformity

Trade Name:				Panasonic
Model No.:				S-X50
Responsible Party:				Panasonic Corporation of North America
				Two Riverfront Plaza, Newark, NJ
				07102-5490
Support Contact:				http://shop.panasonic.com/support

THE FOLLOWING APPLIES ONLY IN CANADA.

CAN ICES-3(B)/NMB-3(B)

-If you see this symbol-

Disposal of Old Equipment

Only for European Union and countries with recycling systems

This symbol on the products, packaging,

and/or accompanying documents means

that used electrical and electronic products must not be mixed with general household waste.

For proper treatment, recovery and recycling of old products, please take them to

applicable collection points in accordance with your national legislation.

By disposing of them correctly, you will help to save valuable resources and prevent any potential negative effects on human health and the environment.

For more information about collection and recycling, please contact your local authority.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.

Precautions

∫ Lens care

0 Do not subject to strong vibration, shock, or pressure. These may cause malfunction or damage.

– Don’t press hard on the lens.	English
0 Take care not to drop or bump the lens when carrying it.
– When carrying the digital camera with the lens
attached, hold both the lens and the digital camera to
carry them.

–Take care not to drop or bump the bag in which you have put the lens.

0When there is dirt (water, oil, and fingerprints, etc.) on the surface of the lens, the images may be affected. Lightly wipe the surface of the lens with a soft, dry cloth before and after recording.

0When the lens is not in use, be sure to attach the lens cap and lens rear cap to prevent dust and other particles from accumulating on or entering the lens.

0To protect the lens contact

points (A), do not do the following. These may cause malfunction.

– Touch the lens contact points.

– Allow the lens contact points to become dirty.

–Place the lens with its mount surface facing down.

DVQX1747 19

∫ Dust and splash resistant

0 The dust and splash resistant of the camera will not prevent the entry of dust or water droplets completely. Take the following precautions to provide satisfactory dust and splash resistant performance. If the lens is not working properly, consult the dealer or your nearest Service Center.

–Attach to a digital camera that is dust and splash resistant.

–When attaching or removing the lens, be careful so that foreign objects such as sand, dust, and water droplets do not adhere to or enter the lens mount rubber, contact points, digital camera and lens.

–If the lens is exposed to water droplets or other liquids, wipe them off with a soft, dry cloth.

0 To improve the dust and splash resistant performance of the lens, a lens mount rubber is used in the mount.

–The lens mount rubber will leave scuff marks on the digital camera mount, but this does not impact performance.

–For information on changing the lens mount rubber, contact your nearest Service Center.

20 DVQX1747

∫ Condensation (when the lens is fogged up)

0 Condensation occurs when the ambient temperature or humidity changes. Please be careful, as it may cause lens stains, mold and malfunction.

0 If condensation occurs, turn off the digital camera and leave it for approx. 2 hours. The fog will disappear naturally when the temperature of the digital camera becomes close to the ambient temperature.

0 The appearance and specifications of products described in this document may differ from the actual products you have purchased due to later enhancements.

Supplied Accessories

Product numbers correct as of January 2019. These may be subject to change.

1	2	3	4
SFC0360	1ZE4SX50Z	1GE1Z276Z	RGE1Z276Z

1 Lens pouch

2 Lens hood

3 Lens cap¢

4Lens rear cap¢

¢Fitted to the lens at the time of purchase.

Names and Functions of	1	Lens surface
Components	2	Focus ring
		Switches between AF (auto focus) and MF (manual
		focus) by sliding the focus ring forwards or
		backwards. (l 23)
4	3	Rotates the focus ring to focus when set to MF.
		Aperture ring
5		Adjusts the aperture value when you set the digital
6		camera to Aperture-Priority AE mode or Manual
		Exposure mode.
		0 If you set the position of the aperture ring to [A],
	4	set the aperture value of the digital camera.
		Contact points
	5	Lens fitting mark
	6	Lens mount rubber
		Note
	0 If the sound of AF operation bothers you during video
	recording, it is recommended to slide the focus ring to
	MF.

English

1 2 3

DVQX1747 21

Attaching the Lens

For information on how to attach the lens, refer to the operating instructions for your digital camera.

0	Attach the lens after turning off the digital camera.
0	Attach the lens after removing
	the lens rear cap.
0	After removing the lens from
	the digital camera, be sure to
	attach the lens cap and lens
	rear cap to prevent dust and
	other particles from
	accumulating on or entering
	the lens.

∫ Attaching the lens hood

Hold the lens hood with your fingers placed as shown in the picture.

0Do not hold the lens hood in a way that twists or bends it.

1Align mark A () on the lens hood with the mark on the tip of the lens.

2Rotate the lens hood in the direction of the arrow to align mark B

() on the lens hood with the mark on the tip of the lens.

0 Attach the lens hood by rotating it until it clicks.

∫Removing the lens hood

While pressing the lens hood button, rotate the lens hood in the direction of the arrow and then remove it.

22 DVQX1747

Note

0 When carrying, the lens hood can be attached in the reverse direction.

1Remove the lens hood.

2Align mark C () on the lens hood with the mark on the tip of the lens.

3Attach the lens hood by rotating it in the direction of the arrow until it clicks.

0It is recommended to remove the lens hood during flash photography as the lens hood can block the light from the flash.

0To prevent dropping of the lens, you should never carry the lens by just holding the lens hood.

∫ Notes on filter use

0 It is possible to attach the lens cap or the lens hood with the filter already attached.

0 If you use two or more filters at the same time, part of a recorded image may darken.

0 It is not possible to attach any items other than filters such as a conversion lens or adaptor to the front of the lens and use it in combination with this lens.

Lens damage may result if such items are attached.

Switching AF/MF

Switch AF/MF by sliding the focus ring A forwards or backwards (focus clutch mechanism).

0 When the digital camera is set to MF, the operation will be MF irrespective of the position of the focus ring.

AF	MF
	English

0	Check the length indication
	B when using MF. Use it as a
	guide for focusing.
0	You can set the amount that
					1.5	2	3		5	13
					0.44	0.6	0.9		1.5	4 mft
	the focus moves with the
	focus ring using menu
	settings in compatible digital
	cameras. Switch the lens to

AF and set the digital camera to MF. Refer to the operating instructions for the digital camera for details.

DVQX1747 23

Cautions for Use

0 Do not spray the lens with insecticides or volatile chemicals.

–If such substances get onto the lens they can damage the exterior case or cause the paint to peel.

0 Do not point the lens at the sun or other strong light sources.

–This may cause the lens to collect an excessive amount of light, resulting in fire and malfunction.

0 Do not use while directly touching the lens at low temperatures for a long period of time.

–In cold places (environments below 0 oC (32 oF), such as ski slopes), prolonged direct contact with the metal parts of the lens may cause skin injury. Use gloves or similar when using the lens for long periods.

0 Use a soft, dry, dust-free cloth to clean the lens.

–Do not use benzine, thinner, alcohol or other similar cleaning agents to clean the lens. Using solvents may damage the lens or cause the paint to peel.

–Do not use a household detergent or a chemically treated cloth.

0 Do not keep products made of rubber, PVC or similar materials in contact with the lens for a long period of time.

0 Do not disassemble or alter this product.

0 When the lens is not going to be used for a prolonged period, we recommend storing with a desiccant (silica gel).

24 DVQX1747

0 Check all the parts before recording when you have not used the lens for a long period of time.

0 Avoid using or storing the lens in any of the following locations as this may cause problems in operation or malfunctioning:

–In direct sunlight or on a beach in summer

–In locations with high temperatures and humidity levels or severe changes in temperature and humidity

–In sandy or dusty locations

–Where there is fire

–Near heaters, air conditioners or humidifiers

–Where water may make the lens wet

–Where there is vibration

–Inside a vehicle

0 Refer also to the operating instructions for the digital camera.

Troubleshooting

A rattling sound, etc. is heard when the digital camera is turned on or off or the lens is shaken.

There is a sound from the lens when taking pictures.

0 This is the sound of the lens moving and aperture operation. It is not a malfunction.

Specifications

The specifications are subject to change for performance enhancement.

	INTERCHANGEABLE LENS FOR DIGITAL CAMERA “LUMIX S PRO 50 mm F1.4”
Mount	Leica Camera AG L-Mount	English
Focal length	f=50 mm
Lens construction	13 elements in 11 groups (2 aspherical lenses, 3 ED lenses)
Aperture type	11 diaphragm blades/Circular aperture diaphragm
Maximum aperture	F1.4
Minimum aperture value	F16
Angle of view	47o
Recording range	0.44 m (1.44 feet) to ¶ (from the focus distance reference line)
Maximum image	0.15k
magnification
Image stabilizer	No
Filter diameter	77 mm
Maximum diameter	‰90 mm (3.5q)
Overall length	Approx. 130 mm (5.1q) (from the tip of the lens to the base side of the lens mount)
Mass (Weight)	Approx. 955 g (2.105 lb)
Dust and splash resistant	Yes
Recommended operating	j10 oC to 40 oC (14 oF to 104 oF)
temperature
Permissible relative	10%RH to 80%RH
humidity

DVQX1747 25

Limited Warranty

(ONLY FOR U.S.A.)

Panasonic Products Limited Warranty

Limited Warranty Coverage (For USA Only)

If your product does not work properly because of a defect in materials or workmanship, Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (“warranty period”), at its option either (a) repair your product with new or refurbished parts, (b) replace it with a new or a refurbished equivalent value product, or

(c) refund your purchase price. The decision to repair, replace or refund will be made by the warrantor.

	Product or part name	Parts	Labor
	Interchangeable Lens for	1 Year	1 Year
	Digital Camera
	All included Accessories
	(Except	90 Days	Not
	Non-Rechargeable		Applicable
	Batteries)
	Only Non-Rechargeable	10 Days	Not
	Batteries		Applicable

During the “Labor” warranty period there will be no charge for labor. During the “Parts” warranty period, there will be no charge for parts. This Limited Warranty excludes both parts and labor for non-rechargeable

26 DVQX1747

batteries, antennas, and cosmetic parts (cabinet). This warranty only applies to products purchased and serviced in the United States. This warranty is extended only to the original purchaser of a new product which was not sold “as is”.

Mail-In Service--Online Repair Request

Online Repair Request

To submit a new repair request and for quick repair status visit our Web Site at http://shop.panasonic.com/support.

When shipping the unit, carefully pack, include all supplied accessories listed in the Owner’s Manual, and send it prepaid, adequately insured and packed well in a carton box. When shipping Lithium Ion batteries please visit our Web Site at http://shop.panasonic.com/support as Panasonic is committed to providing the most up to date information. Include a letter detailing the complaint, a return address and provide a daytime phone number where you can be reached. A valid registered receipt is required under the Limited Warranty.

IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE PURCHASER WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF PURCHASE.

Limited Warranty Limits and Exclusions

This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused by products not supplied by the warrantor, or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, misadjustment of consumer controls, improper maintenance, power line surge, lightning damage, modification, introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or other business or rental use of the product, or service by anyone other than a Factory Service Center or other Authorized Servicer, or damage that is attributable to acts of God.

THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY.

(As examples, this excludes damages for lost time, travel to and from the servicer, loss of or damage to media or images, data or other memory or recorded content. The items listed are not exclusive, but for illustration only.)

ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.

	Some states do not allow the exclusion or limitation of
	incidental or consequential damages, or limitations on
	how long an implied warranty lasts, so the exclusions
	may not apply to you.
	This warranty gives you specific legal rights and you may
	also have other rights which vary from state to state. If a	English
	problem with this product develops during or after the
	warranty period, you may contact your dealer or Service
	Center. If the problem is not handled to your satisfaction,
	then write to:
	Consumer Affairs Department
	Panasonic Corporation of North America
	661 Independence Pkwy
	Chesapeake, VA 23320

PARTSANDSERVICE, WHICHARENOT COVEREDBY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY.

DVQX1747 27

Limited Warranty

(ONLY FOR CANADA)

Panasonic Canada Inc.

5770 Ambler Drive, Mississauga, Ontario L4W 2T3

PANASONIC PRODUCT – LIMITED WARRANTY

Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship under normal use and for a period as stated below from the date of original purchase agrees to, at its option either (a) repair your product with new or refurbished parts, (b) replace it with a new or a refurbished equivalent value product, or

(c) refund your purchase price. The decision to repair, replace or refund will be made by Panasonic Canada Inc.

Interchangeable Lens	One (1) year, parts and
for Digital Camera	labour

			This warranty is given only to the original purchaser, or
			the person for whom it was purchased as a gift, of a
			Panasonic brand product mentioned above sold by an
			authorized Panasonic dealer in Canada and purchased
			and used in Canada, which product was not sold “as is”,
	As of July 2015		and which product was delivered to you in new condition
			in the original packaging.

IN ORDER TO BE ELIGIBLE TO RECEIVE WARRANTY

SERVICE HEREUNDER, A PURCHASE RECEIPT OR

OTHER PROOF OF DATE OF ORIGINAL PURCHASE,

SHOWING AMOUNT PAID AND PLACE OF PURCHASE

IS REQUIRED

28 DVQX1747
