Panasonic PT-CX301U Specification
PEC
S
ILE
F
Product Number :
Product Name :
PT-CX301R
Ultra Short-Throw DLP™Projector
As of June 2013. Specifications and appearance are subject to change without notice.
SFD13M003-1
1/13
S PEC F ILE
Ultra Short-Throw DLP™Projector
Specifications
Main unit
Power supply
Power consumption
DLP™ chip Panel size
Display method
Pixels
Lens
Lamp
Screen size
Colors
Brightness*
Center-to-corner uniformity*
Contrast*
Resolution
Scanning frequency HDMI
Keystone correction range
Installation
Built-in speaker Size
Terminals HDMI IN
2
2
2
RGB
(YCBCR)
YP
BPR
Video/S-Video
Output power
COMPUTER (RGB) 1/2 IN
R, G, B
B (CB), PR (CR)
Y, P
MONITOR (RGB) OUT
R, G, B
Y, P
B (CB), PR (CR) Y: 1.0 Vp-p (including sync signal);
VIDEO IN
S-VIDEO IN
PT-CX301R
100–240 V AC, 3.6–1.5 A, 50/60 Hz
340 W
(0.5 W when
STANDBY MODE
set to NETWORK.)
14.0 mm (0.55 inches) diagonal (4:3 aspect ratio)
DLP™ chip × 1, DLP™ system
786,432 (1,024 × 768) pixels
Fixed (0.44:1 throw ratio), manual focus, F 2.6, f 5.27 mm
280 W UHM lamp × 1
1.52–2.29 m (60– 90 inches) diagonally, 4:3 aspect ratio
Full color (16,777,216 colors)
3,100 lumens (
LAMP POWER: NORMAL
80%
8,000:1 (full on/off, During RGB signal input,
1,024 × 768 pixels (Input signals that exceed this resolution will be
converted to 1,024 × 768 pixels.)
f
H: 15 kHz–100 kHz, fV: 24 Hz–120 Hz,
dot clock: 25 MHz– 162 MHz
H: 15 kHz–100 kHz, fV: 24 Hz–120 Hz, dot clock: 162 MHz or lower
f
525i (480i): f
15.75 kHz; fV60 Hz,
H
625i (576i): fH15.63 kHz; fV50 Hz,
525p (480p): f
625p (576p): f
750 (720)/60p: f
H 31.50 kHz; fV 60 Hz,
31.25 kHz; fV50 Hz,
H
H
45.00 kHz; fV60 Hz,
750 (720)/50p: fH37.50 kHz; fV50 Hz,
1125 (1080)/60i: fH33.75 kHz; fV60 Hz,
1125 (1080)/50i: f
1125 (1080)/24p: f
1125 (1080)/60p: f
1125 (1080)/50p: f
f
H: 15.75/15.63 kHz, fV: 50/60 Hz
H 28.13 kHz; fV 50 Hz
H 27.00 kHz; fV 24 Hz
H 67.50 kHz; fV 60 Hz
H 56.25 kHz; fV 50 Hz
[NTSC/NTSC4.43/PAL/PAL60/PAL-N/PAL-M/SECAM]
Vertical: ±15°
Ceiling/floor, front/rear (Menu setting)
7 x 3 cm (2-3/4 x 1-3/16 inches) (oval-shaped) × 1
10 W (monaural)
HDMI 19-pin × 1, HDCP compatible, Deep color compatible
525p (480p), 625p (576p), 525p (480p), 625p (576p), 750 (720)/60p,
750 (720)/50p, 1125 (1080)/60i, 1125 (1080)/50i, 1125 (1080)/24p,
1125 (1080)/60p, 1125 (1080)/50p
VGA (640 × 480) – WSXGA+(1,680 × 1,050), Audio signal: linear
PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
D-sub HD 15-pin (female) × 2
G: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms;
B, R: 0.7 Vp-p, 75 ohms;
HD/VD, SYNC: high impedance, TTL, positive/negative automatic
Y: 1.0 Vp-p (including sync signal);
P
), PR(CR): 0.7 Vp-p, 75 ohms
B(CB
D-sub
HD 15-pin (female) × 1
(Outputs signals selected from RGB input 1/2.)
G: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms;
B, R: 0.7 Vp-p, 75 ohms;
HD/VD, SYNC: high impedance, TTL, positive
P
), PR(CR): 0.7 Vp-p, 75 ohms
B(CB
Pin jack × 1, 1.0 Vp-p, 75 ohms
Mini DIN 4-pin × 1, Y: 1.0 Vp-p; C: 0.286 Vp-p, 75 ohms
set to
ECO
,*16.0 W when
)
LAMP POWER: NORMAL)
STANDBY MODE
As of June 2013
SFD13M003-1
2/13
S PEC F ILE
Ultra Short-Throw DLP™Projector
COMPUTER 1 AUDIO IN
COMPUTER 2 AUDIO IN
VIDEO/S-VIDEO AUDIO IN
AUDIO OUT
SERIAL IN
LAN
MiniUSB
Power cord length
Cabinet materials
Dimensions (W ×H×D)
Weight
Operation noise
Operating temperature
Operating humidity
Remote control unit
Power supply
Operation range*
Dimensions (W × H × D)
Weight
4
PT-CX301R
M3 (L, R) × 1, 0.5 Vrms
M3 (L, R) × 1, 0.5 Vrms
Pin jack × 2 (L/R × 1), 0.5 Vrms
M3 (L, R) × 1 (monitor out: 0– 2.0 Vrms, variable)
D-sub 9-pin (female) × 1, for external control (RS-232C compliant)
RJ-45 × 1, for network connection, 100Base-TX/10Base-T, compliant
with PJLink™
MiniUSB x 1 (For interactive function)
3.0 m (9 ft 10 in)
Molded plastic (PC)
357 mm × 250 mm*
(14-1/16 × 9-27/32*3 × 14-7/16 inches)
Approximately 7.8 kg (17 lbs)
LAMP POWER: NORMAL), 33 dB (LAMP POWER: ECO)
37 dB (
5–40 °C (41–104 °F) up to 750 m (2,500 ft) above sea level,
5–35 °C (41–95 °F) between 750 m and 1,500 m (2,500 ft and
5,000 ft) above sea level.
5–30 °C (41–86 °F) between 1,500 m and 3,000 m (5,000 ft and
10,000 ft) above sea level.
20%–80% (no condensation)
3 V DC (Lithium coin cell battery × 1)
Approximately 8 m (26.3 ft) when operated from directly in front of the
signal receptor
41 × 87 × 7 mm (1-5/8 × 3-7/16 × 9/32 inches)
Approx. 23 g (0.8 oz) (including Lithium coin cell battery)
3
× 367 mm
Supplied accessories
Optional accessories
Ceiling mount bracket
Bracket assembly
Wall mount bracket
Replacement lamp unit
Interactive Pen
Interactive Pointer
Power cord (× 1) (× 2 for PT-CX301REA)
Power code cover (x 1)
Power code holder (x 1)
Wireless remote control unit (× 1)
Lithium coin cell battery for remote control (× 1)
Computer cable (1.8 m) (x 1)
Interactive Pen (x 2)
AAA type battery (x 4)
USB cable (5.0 m) (x 1)
Software CD-ROM (Interactive function manual, LightPenⅢ) (x 1)
ET-PKV100H (for high ceilings)
ET-PKV100S (for low ceilings)
ET-PKC200B
ET-PKC200W
ET-LAC300
ET-PEN100
ET-PNT100
Weights and dimensions shown are approximate. Specifications subject to change without notice.
1 When the standby mode is set to eco, network functions such as LAN Standby On and MONITOR OUT/AUDIO OUT terminals do not work.
*
2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*
3 With legs at shortest position.
*
4 Operation range differs depending on environments.
*
As of June 2013
SFD13M003-1
3/13
S PEC F ILE
Ultra Short-Throw DLP™Projector
Dimensions
45
(1-25/32)
367
(14-7/16)
PT-CX301R
unit : mm (inch)
NOTE: This illustration is not drawn to scale.
335
(13-3/16)
Terminals
13567842
187
250
(27/32)
231
(9-3/32)
357
(14-1/16)
91011121314
19
(3/4)
(7-3/8)
134
(5-9/32)
17
(21/32)
1 MiniUSB
2 HDMI input
3 Monitor output
4 LAN connector
5 Computer 1 input
6 Audio input for computer 1
7 S-Video input
8 Audio input for S-Video
9 Serial input
10 Computer 2 input
11 Audio input for computer 2
12 Video input
13 Audio input for video
14 Audio output
As of June 2013
SFD13M003-1
4/13
