Panasonic NV-SD450EU User Manual
Specifications and Main Features
- Model: NV-SD450EU
- AC Supply:110~ 240, 50 to 60Hz
- Power Rating: 18 watts
- Two Rotating Heas- Helical Scan System: Video Recording System
- Heads Rating: 4
- Tape Speed: SP: 23.39 mm/sec - LP: 11.7mm per sec
- Tape Format: VHS
- Time: 240 minutes with NV-E240- SP, 480 minutes with NV-E240- LP
- TV Systemss: SECAM: 625 lines, 50 fields, carrying PAL color signal; EIA: 525 lines, 60 fields, carries NTSC color signal.
- Input Level: 1.0 Vp-p(Phono)
- Output Level: 1.0 Vp-p (Phono)
- RF Modulation: PAL B.G.H.I.D/SECAM
- Audio Input Level: -10 dBV (Phono)
- Microphone Input: -70 dBV
- Audio Output Level: -6 dBV (Phono)
- Track: 1 track (normal mono)Audio
- Lines: More than 240 lines Horizontal Resolution;
- Ratio: More than 43 dB video: More than 43 dB audio.
- Audio Frequency: 80Hz- 10kHz;
- Temperature: 5 degree Celsius- 40 degree Celsius.
- Humidity: 35%- 80%
- Weight: 4.6 kg
- Dimensions:430 mm (W) x 91 mm (H) x 312 mm (D)
- Accessories: 1x RF coaxial cable
Rewote this text keeping every technical detail intact:
- 1 x Remote control
- 2 x "AA" batteries
- 1 x Power cord
Frequently Asked Questions
- How about tapes for NV-SD450EU?
A: The device works well if VHS format tapes are used.
- How many video heads are there on the NV-SD450EU?
A: The NV-SD450EU has four video heads.
- Is it possible to record in various formats?
A: Yes, both the SP and LP recording speeds are available on this device.
- How long could a single television recording last?
A: It is possible to record up to 240 minutes in SP mode and 480 minutes in LP mode using NV-E240 tapes.
- Will this device work with other forms of TV?
A: Pal and NTSC formats are both supported by the device.
- I don't know what to do in case the device is not turning on.
A: First, you should connect the power cord correctly and then check whether the device can be turned on.
- Is there any recorded time?
A: Yes, the timer is set to allow recordings of up to 8 programs every month.
- Q: What to do if the image quality is poor?
A: It is necessary to check the position of the tape and video heads, clean the video heads, and align the tracking.
