Panasonic KX-PW601DW, KX-PW601DL User Manual

Facsimile

Quick Reference Guide

Model No.

Table of Contents

Finding the controls ……………………………………………………………2
Installations and connections …………………………………………………4
Setting the date and time ………………………………………………………7
Setting your facsimile telephone number ……………………………………7
Setting your logo…………………………………………………………………8
Character input and command key table ……………………………………9
Automatic dialing on the main unit……………………………………………10
Automatic dialing on the portable handset …………………………………12
Intercom between the main unit and portable handset ……………………14
Sending faxes …………………………………………………………………15
Receiving faxes ………………………………………………………………16
Operating the built-in answering device ……………………………………18
Individual e-mail services ……………………………………………………19
Specifications…………………………………………………………Back cover

Thank you for purchasing a Panasonic facsimile.

●

This guide explains some basic features and operations, but not all of them.
For further details, see the Japanese operating instructions.

●

This product is designed for use in Japan.
Panasonic cannot provide service for this product if used outside Japan.

●

Any details given in this guide are subject to change without notice.

KX-PW601DL

KX-PW601DL
KX-PW601DW

2

Finding the controls

Main unit (control panel)

1

4

5

2

3

6

7

8

9

10111213141516

17

E-Mail indicator
E-Mail button
Pause button
Speed Dialer button
Hold button
Intercom button
Auto Answer button & indicator

—light on: answering device activated.
—light off: used as a regular telephone.
Replay button plays back recorded
messages.

Record button records telephone calls.
Stop button
Copy button starts copying.
Mute button
Start/Fax button starts faxing.
Speakerphone button & indicator
Tone button switches to tone dialing.

Microphone
Function button initiates programming.
Volume/Redial/Phonebook/
Addressbook key

To adjust the volume.
To change Hiragana into Kanji.

To redial the phone numbers in
the redial list. The last 10 phone
numbers dialed are stored in
memory.

To use the phonebook and the
addressbook.

Multi-operation buttons refer to the
function displayed on the display panel.

Liquid crystal display

17

16

15

14

13

12

11

10

9

8

765

432

1

3

Finding the controls

Portable handset



●



For call waiting service
users.

●



To use the one-touch dial.

●



To use the speakerphone.

LCD (with back light)

Earpiece

Microphone

Do not cover the
microphone while
talking.



●



Displays battery strength, telephone
numbers etc.

1

Portable handset number



●



To adjust the volume.

●



To change Hiragana into
Kanji.

●



To redial the phone
numbers in the redial
list. The last 10 phone
numbers dialed are
stored in memory.

●



To use the phonebook.



How to use key

機能

子機

1

圏外

留守

1

3

2

4

5



Function menu that is
controlled by or .

5

4

Battery strength

2

Indicates which directions the

key can be tilted.

up and down

left

3

Out of range
(Walk closer to the main unit.)

Note:



●



If you use the portable handset near a microwave oven which is being used, noise may be heard from
the earpiece or the speaker. Move away from the microwave oven and closer to the main unit.





How to use buttons

and buttons refer to the function
displayed on the bottom of the display.
They function differently depending on
the mode.

Sharp button

Dial buttons



Tone button



●



To switch to Tone dialing mode.



●



To make/answer calls.

●



To page the main unit or
another portable handset.

●



To clear letters/numbers.

●



To end a call.

●



To end or exit from editing or
other operations.

●



To put a call on hold.

●



To start a search in the
Number Display log.
(For caller ID display service
users.)

●



To adjust the receiver tone
quality.

4

Installations and connections

Installing the ink film

2 Insert the ink film.

1 Open the control panel and the back cover.

Do not
be slacken.

押す

Click

Click

開く

Open the control

panel until it locks.

3 If the ink film is slack, tighten it by winding the “T”

shaped gear.

4 Close the back cover and the control panel until they

lock.

●

When the unit runs out of ink film, the following
message will be displayed.

Install a new ink film.

・

As of June 2003.・Tax not included.

ﾌｨﾙﾑかﾞ

なくなりました

U23

品番

：KXｰ

FAN142

ﾌｨﾙﾑかﾞ

なくなりました

U23

交換

してくたﾞさい

Replacement ink film:

KX-FAN142 (35 m) ¥1250

Open the back cover

until it locks.

Press here.

Find the “T” shaped gear (blue).

Ink film

Blue core

Insert the “T”
shaped gear
(blue) into the
left slot of the
main unit.

Insert the white core into the slots.

Insert the blue
core into the
right slot of the
main unit.

1

Click

To close the back cover, press here.

Close the control panel until it locks.

3

1

2

1

2

2

3

5

Installations and connections

Installing recording paper

(A4

size)

3 Install the recording paper cover on the recording

paper tray by sliding it down from the top.

Recording
paper tray

Tab

Slot

Recording
paper cover

Recording
paper tray

Fan the stack of recording paper (A4 size).

Insert the recording paper into the recording
paper tray. (Up to 30 sheets)

Close the paper entrance cover by leaning it
back.

2 Insert the recording paper into the recording paper tray.

Open the paper entrance cover until it locks.

1

1 Install the recording paper tray.

Separate the recording paper cover from the

recording paper tray.

1

Insert the left tab on the recording paper tray into

the left slot of the main unit.

Insert the right tab into the right slot of the main unit.

3

2

2

3

3



Printing

side is on

the back

4

2

Recording
paper cover

Recording
paper tray

6

Connecting the main unit

Installations and connections

3 Charge the battery in the charger for 10 hours.

Plug

Charger

AC adaptor

Power outlet
(AC 100 V)

Connector

Battery

Battery cover

Click

Black

Red

Setting up the portable handset

1

2

●

After your Panasonic battery is fully charged,
it will last up to about 7 hours of conversation.

Power cord

Telephone
line cord

Wall jack

Power outlet
(AC 100V)

3 Connect the power

  cord.

2 Connect the telephone line

  cord (Supplied accessory).

1 Connect the cord and place the handset on the

  main unit.

Click

停

電

用



電

話

機



回

線



（電話回線へ）

Click

Click

After the Power On...

This unit will automatically select the dialing

mode (Tone/Pulse).

充電中

充電完了

●

While charging.

●

Charging completed.

7

Setting the date and time

1Press (Function).

2Press .

3Enter the correct year/month/day.

Example: October 1, 2003

Press .

3Enter your facsimile telephone number, up to 20

digits.

Example: 098 765 43 · ·

4Enter the correct hour/minute in a 24-hour clock entry.

Example: 15:45 (3:45 PM)

Press .

4Press (Set/Register).

決定/登録

5Press (Set/Register).

決定/登録

6Press (Stop).

5Press (Stop).

Setting your facsimile
telephone number

機能登録ﾓｰﾄﾞ

■2

003

年

06月01

日

20：10

Cursor

Example :

2003年10月01

日

■20：

10

■2

003年10月01

日

15：45

■2

003年10月01

日

15：45

登録

しました

10月01日ｱ15：

45

用件録音ｱ13：00

件

Example :

1Press (Function).

機能登録ﾓｰﾄﾞ

2Press .

あなたの

電話番号

?

■■

．．．．．．．．．．．．．．．．

Cursor

あなたの

電話番号

?

09876543

■■

．．．．．．

The   (Space) button replaces

the digit with a space.

あなたの

電話番号

?

■0

9876543．．．．．．

登録

しました

10月01日ｱ15：

45

用件録音ｱ13：00

件

Example :

4. Press to move the cursor to the next space

and press four times.

8

2Press .

3Enter your logo, up to 30 characters, using the dial

keypad.

●

To enter English characters easily, press
(Character input mode) repeatedly and select

“英” (English and sign input mode).

●

For details, see the table on page 9 for instructions.

文字切替

5Press (Stop).

Setting your logo

2. Press six times.

3. Press six times.

5. Press five times.

Example: Micah

1. Press once.

4Press (Set/Register).

決定/登録

1Press (Function).

機能登録ﾓｰﾄﾞ

10

月01日ｱ15：45

用件録音ｱ13：00

件

Example :

M

Cursor

M

i

Mi

c

Mic

a

Mica

h

Micah
>

登録

しました

M

名前(印刷用)

?

＞＿

Cursor

9

Character input and command key table

、、。

、。

“かな”

Hiragana

“英”

English

“カナ”

Katakana

“数”

Numbers

!？/ー

#

‚ ;: ｜

・

’”

（）

[]

｛｝〈〉「」

ワヲン

ー

！？ ( )

あいうえおぁぃぅぇぉ
かきくけこ
さしすせそ
たちつてとっ
なにぬねの
はひふへほ
まみむめも
やゆよゃゅょ
らりるれろ
わをんー！？ ( )

アイウエオァィゥェォ

@

・

ｰ&＄¥%＋=〜^

DEFdef
GHI gh i
JKL j k l
MNOmn o
PQRSpqrs
TUVtuv
WXYZwx yz

カキクケコ
サシスセソ
タチツテトッ
ナニヌネノ
ハヒフヘホ
マミムメモ
ヤユヨャュョ
ラリルレロ

1
2
3
4
5
6
7
8
9

0

ABCabc

、。

Character

Dial key

Used to change the character input mode.

Used to move the cursor to the left and right.

Used to delete a character.

Used to insert a space.

Command keys

(Main unit), (Portable handset)

(Main unit), (Portable handset)

文字切替

(Main unit), (Portable handset)

クリアー

(Main unit), (Portable handset)

●

When entering e-mail address, the small letters are displayed before the capital letters.

●

When entering e-mail address, you can not enter the following symbols: 、。ー

.

「」

●

When entering e-mail address, you can enter only English and Numbers.

●

When entering e-mail message, pressing enables you to begin the new line. ( “ ” is displayed.)

●

The display items of the main unit are somewhat different from those of the portable handset.

Portable

(

handset

)

Main

(

unit

)

Pressing the dial keys will select a character as shown below.

10

Automatic dialing on the main unit

Storing names and telephone
numbers in the phonebook

Making a voice call using the
phonebook

1Press (Phonebook).

1Press (Phonebook).

2Press (Set/Register).

●

“XXX” shows the remaining
station numbers you can
store.

●

You can program up to 150
stations, including 4 pre­programmed stations.

決定/登録

3Enter the name, up to 20 characters (see the table on

page 9 for instructions).

4Press (Set/Register) twice.

決定/登録

5Enter the telephone number, up to 24 digits.

●

To correct a mistake, press (Clear).

クリアー

8Press (Set/Register).

●

To program other items, repeat steps 3 to 8.

決定/登録

9Press (Stop) to exit the program.

2Press (Search button) repeatedly until the

desired name is displayed.

3Lift the handset or press (Speakerphone).

Editing a stored name or number
in the phonebook

3Press (Edit).

4Edit the name (see the table on page 9 for

instructions).

●

If you do not need to edit the name, skip to step 5.

5Press (Set/Register).

決定/登録

8Edit the telephone number.

●

If you do not need to edit the telephone number,
skip to step 9.

9Press (Set/Register).

決定/登録

1Press (Phonebook).
2Press (Search button) repeatedly until the

desired name is displayed.

6Press (Set/Register).

決定/登録

7If necessary, enter the group number (1-9).

6Edit the kana.

●

If you do not need to edit the kana, skip to step 7.

7Press (Set/Register).

決定/登録

10If necessary, enter the correct group number.

11Press (Set/Register).

決定/登録

電話帳空きｱ

×××

件

検索は[ ｱｱ]を押

す

12Press (Stop) to exit the program.

修正

11

Automatic dialing on the main unit

Storing names and telephone
numbers in the speed dialer

Making a voice call using the
speed dialer

1Press (Speed dialer).

3Press (Set/Register).

決定/登録

4Press (Search button) repeatedly until the

desired name is displayed.

3Lift the handset or press (Speakerphone).

5Press (Set/Register).

●

To program other items in other stations, repeat
steps 2 to 5.

決定/登録

6Press (Stop) to exit the program.

Erasing a stored name and
number in the speed dialer

3Press (Erase) and (Yes).

クリアー

2Press the memory station number ( to ).

Example: speed dialer 1

You can store up to 9 names and telephone numbers
which are stored in the phonebook. The dialing buttons

( to ) function as memory stations.

1Press (Speed dialer).

2Press the memory station number ( to ).

1Press (Speed dialer).

2Press the memory station number ( to ).

1.

登録

されていません

Memory station number

12

Automatic dialing on the portable handset

1Press (one-touch).

Storing telephone number in the
one-touch dial

Making a voice call using the
one-touch dial

2When the other party answers, start talking.

2Enter the telephone number, up to 24 digits.

●

To correct a mistake, press (Clear).

Editing a stored number in the
one-touch dial

1Press (one-touch).

●

The unit will start dialing.

2Press (one-touch).

1Press (Function).

4Press (Register).

登録

3Edit the telephone number, up to 24 digits.

Erasing a stored number in the
one-touch dial

2Press (one-touch).

1Press (Function).

3Press and hold (Erase) until the telephone

number has been erased.

3Press (Register).

登録

4Press (Register).

登録

ﾜﾝﾀｯﾁ登録

0009876543

..

ﾜﾝﾀｯﾁ
登録されて
いません

機能

機能

13

Storing names and telephone
numbers in the phonebook

Making a voice call using the
phonebook

1Press (Phonebook).

3Enter the name, up to 20 characters (see the table on

page 9 for instructions).

4Press (Register) twice.

登録

3Press (Talk) or press

(Speakerphone).

5Enter the telephone number, up to 24 digits.

●

To correct a mistake, press (Clear).

8Press (Register).

●

To program other items, repeat steps 3 to 8.

登録

9Press (Off) to exit the program.

2Press (Search button) repeatedly until the

desired name is displayed.

1Press (Phonebook).

2Press (Register).

●

“XXX” shows the remaining
station numbers you can
store.

●

You can program up to 150
stations, including 4 pre­programmed stations.

登録

Automatic dialing on the portable handset

検索は

[ ｱｱ]を押す

ｱｱｱｱｱｱｱｱｱ

名前

?

空き

AAA

×××

件

6Press (Register).

登録

7If necessary, enter the group number (1-9).

Editing a stored name or number
in the phonebook

3Press (Edit).

修正

4Edit the name (see the table on page 9 for

instructions).

●

If you do not need to edit the name, skip to step 5.

5Press (Register).

登録

8Edit the telephone number.

●

If you do not need to edit the telephone number,
skip to step 9.

9Press (Register).

登録

1Press (Phonebook).

2Press (Search button) repeatedly until the

desired name is displayed.

6Edit the kana.

●

If you do not need to edit the kana, skip to step 7.

7Press (Register).

登録

10If necessary, enter the correct group number.

11Press (Register).

登録

12Press (Off) to exit the program.

14

Intercom between the main unit and portable handset

An intercom is available between the main unit and portable handset.
A 2-way intercom is available between 2 portable handsets.
(For KX-PW601DL users: An optional handset is needed when using this feature.)

Using the main unit: Using the portable handset:

2Start talking.

●

You can switch to the
speakerphone by pressing

(Speakerphone).

1■ For single portable handset users

1

Lift the handset.

2

Press (Intercom).

■ For multiple portable handset users

1

Lift the handset.

2

Press (Intercom).

3

Press the portable handset number ( to )

which you want to call.

3Replace the handset to end the intercom call.

2Start talking.

●

You can switch to the
speakerphone by pressing

(Speakerphone).

1■ For single portable handset users

Press (Intercom).

■ For multiple portable handset users

Press (Intercom), then press .

3Press (Off) to end the intercom call.

Intercom between portable handsets:

Press (Intercom), then press the portable

handset number ( to ) which you want to

call.

番号

?

子機1呼出中

内線番号

0123[12

....]を押す

子機1内線通話中

内線通話中

ｱｱｱｱｱｱｱｱｱ

15

Sending faxes

1Open the document cover, and adjust the width of the

document guides to the size of the document.

2Insert the document (up to 5 pages) FACE DOWN

until a single beep is heard.

3If necessary, press (Resolution) repeatedly to

select the desired setting (see below).

画質

FACE DOWN

Document

Document
guide

Document cover

Document

4Dial the fax number.

5Press (Fax).

●

The unit will start fax transmission.

FACE DOWN

Document

Document
guide

Document cover

Sending a fax manually Sending a fax using automatic

dialing

1Insert the document (up to 5 pages) FACE DOWN

until a single beep is heard.

To select the resolution

Select the desired resolution according to the type of document, by pressing (Resolution).

(Standard) for printed or typewritten originals with normal-sized characters.

(Fine) for originals with minute printing.

(Photo) for originals containing photographs.

画質=写真

画質

=小さい

画質=ふつう

画質

Using the speed dialer

Using the phonebook

1Insert the document (up to 5 pages) FACE DOWN

until a single beep is heard.

3Press (Search button) repeatedly until the

desired name is displayed.

2Press (Phonebook).

4Press (Fax).

●

The unit will start fax transmission.

3Press (Fax).

●

The unit will start fax transmission.

2Press (Speed dialer), then press the memory

station number ( to ).

16

Receiving faxes

Receiving a fax manually
(AUTO ANSWER off)

2When:

– document reception is required,
– a fax calling tone (slow beep) is heard, or
– no sound is heard,

press

(Fax), then replace the handset.

●

The unit will start fax reception.

Using the main unit:

1When you hear a ring, lift the handset to answer the

call.

Using the portable handset:

1When you hear a ring, lift the portable handset from

the charger to answer the call.

●

If the portable handset is not set on the charger,

press

(Talk).

2When:

–document reception is required,
–a fax calling tone (slow beep) is heard, or
–no sound is heard,

press

(Fax reception) until a single beep is

heard.

●

The main unit will start fax reception.

ファクス

17

Receiving faxes

2When receiving a call, the unit will receive a fax

document or record a voice message automatically
depending on the caller’s request.

light on

Receiving a fax automatically
(AUTO ANSWER on)

1If the (Auto answer) light is off, turn it on by

pressing .

Recording your own greeting
message

You can record your own greeting message. When
receiving a call, it will be played to callers instead of the
pre-recorded Japanese greeting message.

3Press (Set/Register).

決定/登録

5Press (Set/Register) and speak your greeting

message, up to 16 seconds, to the handset.

決定/登録

6Press (Stop) and replace the handset.

●

Your greeting message will be played back
automatically.

1Press (Function).
2Press .

4Lift the handset.

Erasing your own greeting message

2Press .

1Press (Function).

3Press (Set/Register).

決定/登録

4Press .

●

The pre-recorded Japanese greeting message will
be played when you receive a call.

自作応答録音

自作応答消去

18

Operating the built-in answering device

2When receiving a call, a greeting message will be

played and the unit will record a voice message.

●

To record your own greeting message, see page 17.

light on/flash

Activating the answering device

1Turn the (Auto answer) light on by pressing .

Listening to recorded messages

When new messages are recorded, the (Auto
answer) light will flash.

Press to listen to recorded messages.

After the messages are played back, the following will be
displayed.

■

To erase the messages, push .

■

To save the messages, push

.

Listening to all of the recorded
messages

Press (Replay/Record).

After the messages are played back, the following will be
displayed.

■

To erase the messages, push .

■

To save the messages, push

.

Erasing a specific message

Press (Erase) while listening to the message you

want to erase, then press .

用件消去

Erasing all of the recorded messages

1Press (Erase).

用件消去

Operating the answering device
from a remote location

Preparation: Programming the remote operation ID

1. Press (Function).

2.

Press .

3. Enter any 4-digit number (remote operation ID) except
or #.

4. Press (Set/Register).

5. Press (Stop).

決定/登録

Operation: Listening to a recorded message from a

remote location

Turn the (Auto answer) light on before you go out.
Remote operations are available only from a touch tone
telephone.

1. Call your unit.

2. Enter the remote operation ID during the greeting

message.

3. Press or wait 4 seconds.

●

Only the new recorded messages will be played
back.

●

To listen to all the recorded messages, press
after the new messages have been played back.

4

2

Example :

light on/flash

2Press .

再生

した

用件を消去

する=ｱｱ

しない

=#

再生

した

用件を消去

する=ｱｱ

しない

=#

すへ

ﾞて消去

しますか

?

はい=ｱｱ

いいえ

=#

暗証番号

=■1234

AAAAAAAAAAA

[4桁]

19

Individual e-mail services

Using the e-mail services

Panasonic Communications Co., Ltd. (hereafter called
“PCC”) offers individual information services, such as
e-mail.
Your fax machine with e-mail features will enable you to
send an e-mail to another party’s personal computer (PC)
or another e-mail fax machine anywhere in the world
through the Internet. Also, you will be able to receive an
e-mail from them.

To access the Internet using your fax machine,

●

you need a credit card (VISA, JCB or MASTER as of
June 2003) and

●

have to subscribe to individual information services
offered by PCC beforehand.

The application fee including call charges will be charged
to your Credit Card.

Important:

●

If your fax machine is connected to a home telephone
system or a private branch exchange (PBX) system,
these services are not available.

Application fee and call charges

PCC information
services

Registration fee

¥500

Information
Service fee

Call charge
included

¥20/minute

(8 am-11 pm)

¥18.5/minute

(11 pm-8 am)

●

As of June 2003.

●

Tax not included.

The following services are available with your fax
machine. The information service fee including the call
charge will be applied.

●

E-mail reception and printing (page 21)

●

Text e-mail sending (page 21)

●

Fax e-mail sending (page 22)

●

Storing e-mail addresses in the addressbook
(free of charge) (page 23)

●

Others

Note:

●

PCC plans to add new information services and the
information service fee is subject to change.
PCC will announce them by e-mail to its customers.

●

For the PC user to view your fax e-mail sent from your
fax machine, the following PC software will be required.
–E-mail software that can read the MIME format
–TIFF viewer software

PCC information services

()

有効期限

？

■

. ./..(月/年)

20

Individual e-mail services

Subscribing to PCC information
services

●

Please save the address and ID code for
future reference.

11After approx. 5 minutes, the unit will ring, and a data

communication will start automatically between your
unit and PCC.

●

If you answer this call, hang up and wait for a
while until the communication is completed.

10Press (Set/Register).

●

The unit will start fax transmission.

決定/登録

／／／／／／／／／／／／／／   「ユーザー登録完了」案内   ／／／／／／／／／／／／／／
 
 こちらはパナソニックコミュニケーションズ株式会社です。
 
 このたびは、「おたっくす情報サービス」にお申し込みいただきましてありがとうございます。
 おたっくすEメールのご利用が可能になりましたので、お知らせいたします。


  あなたの電話番号  ： ○○○○○○△△△△



◆あなたの
   Ｅメールアドレス ： p××××△△△△＠ｆｅｍ．ｄｉｏｎ．ｎｅ．ｊｐ


◆あなたの
   セキュリティＩＤ  ： □□□□

  ＥメールアドレスとセキュリティＩＤは、新サービスの提供時や引越しに伴う電話番号の
  変更連絡等に必要になりますので、取扱説明書裏表紙の「おたっくすEメールお客様メモ」
  欄に必ず記入しておいてください。




Your e-mail address

Your security ID code

1Fill in the included application form.

パナソニックコミュニケーションズ株式会社 行


｢おたっくすＥメール｣のご利用には｢おたっくす情報サービス｣への加入登録が必要です。

フリガナ

サイン

連絡先電話番号
（勤務先など）

申込者
ご氏名

ご住所

ご利用クレジットカード（□（チェックボックス）を塗りつぶしてください）

■VISA □JCB □MASTER 

都道
府県

お申し込み

電話番号

（NTT契約番号)



お申し込み年月日：西暦

PHS、携帯電話、ﾎﾟｹｯﾄﾍﾞﾙなどの番号は登録できません。

年 月 日

• おたっくす情報サービスのご利用条件は「おたっくす情報サービス契約約款」によります。

お申し込みにあたっては、本約款の内容をよくお読みいただき、同内容にご同意のうえ、お申し込みください。

• 本サービスのご利用には、登録料・情報料（通話料を含みます）がかかります。

• 本サービスのお申し込みにあたっては、ご利用料金を引き落とすためのクレジットカードが必要です。

（ご利用可能なクレジットカード：VISA、JCB、MASTER 2002年8月現在）

・

下記の太枠内に必要事項をご記入ください。

•太枠内をかい書にてご記入ください。 • ご記入にあたっては、濃い鉛筆をご使用願います。

おたっくす情報サービス

(おたっくすEメール)ご利用申込書

この面を裏向きにして、

矢印の方向へ入れてください。

Eメール

【お申し込み前に必ずお読みください】

申し込み
のしかた



・

ご利用可能なクレジットカード（VISA,JCB,MASTER）をご準備ください。

「おたっくす情報サービス」

の利用申し込みをします。

・

裏面の申し込みのしかたに従って、ファクス送信してください。

Your
signature

Date of application

The telephone no.
you wish to
subscribe to PCC

Your telephone no.
for contact

Your name

Your
address

Check your credit card type

FACE DOWN

2Press (Function), then press (E-mail).

9Insert the application form FACE DOWN.

3Press (Set/Register).

決定/登録

6Enter your credit card number again, then press

(Set/Register).

決定/登録

5Press (Set/Register).

決定/登録

8Press (Set/Register).

決定/登録

4 Enter your 16-digit credit card number.

●

To correct a mistake, press (Clear).

クリアー

7 Enter the valid date of your credit card.

12When the communication is completed, a user

registration form will be printed.

13Press (E-mail).

14Press (Set/Register).

●

An information service guide will be printed.

決定/登録

Month Year

ｸﾚｼﾞｯﾄｶｰﾄﾞNo.

？

■

. ...-....-....-.

確認

のためｱもう

一度

■

. ...-....-....-.

21

Individual e-mail services

1Press (E-mail).

2Press (Search button) repeatedly until the

following is displayed.

Sending a text e-mail from the
main unit

3Press (Set/Register).

決定/登録

5Press (Set/Register).

決定/登録

6Enter the title of your e-mail, up to 32 characters (see

the table on page 9 for instructions).

●

You can enter the title of the last e-mail you sent

by pressing (Redial).

9Press (Set/Register).

決定/登録

7Press (Set/Register).

決定/登録

8Enter your e-mail message, up to 200 characters

(see the table on page 9 for instructions).

●

You can enter the message of the last e-mail you

sent by pressing (Redial).

4Enter the desired e-mail address (see the table on

page 9 for instructions), then press
(Set/Register).

●

You can enter the address of the last e-mail you

sent by pressing (Redial).

●

You can select the desired address using the
addressbook.

1. Press (Addressbook).

2. Press (Search button) repeatedly until the

desired name is displayed.

3. Press (Set/Register).

To store an address, see page 23.

決定/登録

Receiving and printing an e-mail

2Press (Set/Register).

●

If there is an e-mail you have not viewed yet, the
unit will print the received e-mail.

●

If there is no e-mail, the following will be displayed.

決定/登録

1Press (E-mail).

The file formats recognized by your fax machine are:

●

JPEG

●

~. doc

●

TIFF

●

~. xls

●

BMP

●

~. ppt

●

TXT

●

~. pdf

(as of June 2003)

未受信Eﾒｰﾙあﾙ

0

件

文字Eﾒｰﾙ送 信

決定/登録

22

1Open the document cover, and adjust the width of the

document guides to the size of the document.

2Insert the document (up to 5 pages) FACE DOWN

until a single beep is heard.

3If necessary, press (Resolution) repeatedly to

select the desired setting (see page 15).

画質

FACE DOWN

Adjust the

document

guides

Document cover

5Enter the desired e-mail address (see the table on

page 9 for instructions), then press
(Set/Register).

●

You can enter the address of the last e-mail you

sent by pressing (Redial).

●

You can select the desired address using the
addressbook.

1. Press (Addressbook).

2. Press (Search button) repeatedly until the

desired name is displayed.

3. Press (Set/Register).

To store an address, see page 23.

決定/登録

Sending a fax e-mail

4Press (E-mail), then press (Set/Register).

決定/登録

6Press (Set/Register).

決定/登録

Individual e-mail services

7Enter the title of your fax e-mail, up to 32 characters

(see the table on page 9 for instructions).

●

You can enter the title of the last e-mail you sent

by pressing (Redial).

8Press (Set/Register).

決定/登録

決定/登録

23

Individual e-mail services

6Enter the e-mail address, up to 60 characters (see the

table on page 9 for instructions).

Storing names and e-mail
addresses in the addressbook

3Press (Set/Register) twice.

決定/登録

1Press (Function), then press (E-mail).

2Press (Search button) repeatedly until the

following is displayed.

4Enter the name, up to 20 characters (see the table on

page 9 for instructions).

7Press (Set/Register).

●

To program other items, repeat steps 4 to 7.

決定/登録

Editing a stored name or e-mail
address in the addressbook

7Press (Set/Register).

決定/登録

5Press (Edit).

修正

3Press (Set/Register).

決定/登録

1Press (Function), then press (E-mail).

2Press (Search button) repeatedly until the

following is displayed.

10Edit the e-mail address (see the table on page 9 for

instructions).

●

If you do not need to edit the e-mail address, skip
to step 11.

12Press (Stop) to exit the program.

4Press (Search button) repeatedly until the

desired name is displayed.

5Press (Set/Register) twice.

決定/登録

11Press (Set/Register).

決定/登録

6Edit the name (see the table on page 9 for

instructions).

●

If you do not need to edit the name, skip to step 7.

8Press (Stop) to exit the program.

ｱﾄﾞﾚｽ帳

ｱﾄﾞﾚｽ帳

9Press (Set/Register).

決定/登録

8Edit the kana.

●

If you do not need to edit the kana, skip to step 9.

KX-PW601DL
KX-PW601DW

Main unit

PFQX1934ZA FK0603KM0

Specifications

© Panasonic Communications Co., Ltd. 2003

Main unit

Applicable line Public Switched Telephone Network (Tone/Pulse), F-Net, NCC Lines

320 Ω (*2)
G3 compatible
A4-A5 (Max.216 mm in width, Max. 600 mm in length)
208 mm (A4)
202 mm (A4 size plain paper)
Approx. 15 s/page (Original mode) (*3)
9,600 / 7,200 / 4,800 / 2,400 bps; Automatic fallback
64-level
Horizontal : 8 pels/mm

Vertical : 7.7 lines/mm (Fine/Photo), 3.85 lines/mm (Standard)
Contact image sensor
Thermal transfer printing on plain paper

Modified Huffman (MH), Original mode

A4: 210 mm x 297 mm (Plain paper)

Greeting message: Digital recording system (up to 16 sec)

Pre-recording greeting message

ICM Recording: Digital recording system (Approx. 18 min. in total) (*4)

Max. Approx. 46 pages (Only receiving fax etc.) (*5)
Max. Approx. 18 min. (Only Recording message) (*4)

DC resistance
Compatibility
Document size
Effective scanning size
Effective printing size
Transmission time
Modem speed
Halftone level

Scanning density

Scanner type
Printer type
Data compression

system
Recording paper size

Answering device

Memory capacity

*1 When copying a 100% black document.
*2 If you can not make a call due to DC resistance, consult your dealer.
*3 Transmission speed is based on an A4-size document of 700 characters sent in standard resolution at 9,600 bps.

The actual transmission speed depends upon the contents of the page, resolution, telephone line conditions and

capability of the other party’s machine.
*4 If there is a silent pause, the total recording time will be longer.
*5 The memory capacity is based on an A4-size document of 700 characters.

Power supply

Power
consumption

Dimensions
(H x W x D)

Mass
(Weight)

AC 100 V (50 Hz/60 Hz)

Ni-MH battery

(Part no. KX-FAN50)

DC 3.6 V, 600 mAh

Approx. 161

X 47 X 39 mm

Approx. 140 g
(battery installed)

AC adaptor
(Part no. PFAP1009)
AC 100 V (50 Hz/60 Hz)
DC 7.5 V, 100 mA

• Charging:
Approx. 1.5 W

• Stand by:
Approx. 0.6 W

Approx. 64

X 80 X 90 mm

Approx. 80 g

Transmission: Approx. 16 W
Reception: Approx. 22 W
Copy: Approx. 20 W
Stand by: Approx. 1.2 W
(When the F-net service is not in use.)
Maximum(*1): Approx. 130 W

Approx. 140

X 331 X 237 mm

(without projections)

Approx. 365 X 331 X 268 mm

(recording paper tray installed,

without projections)
Approx. 3.4 kg
(10 m ink film installed)

Main unit Portable handset Battery charger

Operating
environment

5 °C – 35 °C, 45 % – 85 % RH (Relative Humidity)

KX-PW601DL
KX-PW601DW

2.4 GHzFrequency
