System Setup Guide
Home Network System
HUB
Model No. KX-HNB600
Thank you for purchasing a Panasonic product.
This document explains how to configure the hub and access it using a mobile
device. These steps must be followed before you can use the system.
For details about how to use the system, refer to the User’s Guide (page 15).
Please read this document before using the unit and save it for future reference.
For assistance, visit our Web site: www.panasonic.com/support
for customers in the U.S.A. or Puerto Rico.
Please register your product: www.panasonic.com/prodreg
Printed in China
Introduction
Accessory information ..................................3
Important Information
About this system .........................................6
For your safety .............................................6
Important safety instructions ........................7
Security cautions ..........................................7
For best performance ...................................8
Other information .........................................8
Setup
Part names and functions ..........................10
LED indicator ..............................................10
Connections ...............................................10
Wi-Fi® settings ...........................................11
Registering another mobile device .............13
Registering other devices to the hub ..........13
Appendix
Wireless communication range (DECT) .....15
Accessing the User’s Guide .......................15
Wall mounting ............................................16
Specifications .............................................18
Open source software notice .....................18
Software information ..................................18
FCC and other information .........................19
Customer services .....................................21
Warranty (For United States and Puerto
Rico) ...........................................................22
2
Table of Contents
Accessory information
Supplied accessories
No. Accessory item/Part number Quantity
A AC adaptor/PNLV2360Z 1
B Telephone line cord/PQJA10075Z 1
C Wall mounting adaptor/PNKL1049Z1 1
A B C
Additional accessories
microSD card (not supplied)
A commercially-available microSD card must be inserted into the hub in order to record images
from cameras. The following types of microSD cards are supported.
R microSD / SDHC card: Up to 32 GB
Note:
R Please contact your nearest Panasonic dealer for sales information (page 21).
Accessory item Model number
T-adaptor KX-J66
Other information
R Design and specifications are subject to change without notice.
R The illustrations in these instructions may vary slightly from the actual product.
Trademarks
R microSDHC Logo is a trademark of SD-3C, LLC.
R iPhone and iPad are registered trademarks of Apple Inc.
R iPad mini is a trademark of Apple Inc.
R Android is a trademark of Google Inc.
R Wi-Fi is a registered trademark of the Wi-Fi Alliance.
R All other trademarks identified herein are the property of their respective owners.
Notice
R The hub supports microSD and microSDHC memory cards. In this document, the term
“microSD card” is used as a generic term for any of the supported cards.
For assistance, please visit www.panasonic.com/support
3
Introduction
Expanding the Panasonic Home Network System
The Panasonic Home Network System lets you create a powerful wireless network of cameras,
sensors, and smart plugs in your home, and control them all with an easy-to-use mobile app.
Compatible devices are explained below. For information about the Home Network app, refer to
the User’s Guide (page 15).
The maximum number of devices for each device type is listed below.
Digital Cordless Handset (KX-HNH100: 6 max.)
*1
R Makes and receives calls using your home landline
R Can be used to change the system’s security mode
R Displays system status
R Receives notification when the sensors are triggered
Indoor Camera (KX-HNC200: 4 max.*2)
R Full-color camera and built-in microphone for live monitoring
and recording
R Built-in visual sensor, audio sensor, and temperature sensor
can be used to trigger other actions (camera recording, turning
on a light, etc.)
R Built-in microphone and speaker for two-way communication
Outdoor Camera (KX-HNC600: 4 max.*2)
R Full-color camera with built-in microphone for live monitoring
and recording
R Built-in visual sensor and infrared sensor can be used to trigger
other actions (camera recording, turning on a light, etc.)
R Built-in microphone and speaker for two-way communication
R Splash proof design for permanent, outdoor installation
Window/Door Sensor (KX-HNS101: 50 max.*3)
R Detects when the corresponding window or door is opened
R Can be used to trigger other events (camera recording, turning
on a light, etc.)
Motion Sensor (KX-HNS102: 50 max.*3)
R Detects motion in the surrounding area
R Can be used to trigger other events (camera recording, turning
on a light, etc.)
4
For assistance, please visit www.panasonic.com/support
Introduction
Smart Plug (KX-HNA101: 50 max.*3)
R Can be turned on and off using the handset or Home Network
app or when triggered by a sensor
R Built-in overcurrent detection for added peace of mind
R Power consumption is logged for your reference
*1 Optional handsets may be a different color from that of the handset supplied as part of a
pre-configured kit.
*2 A total of 4 cameras (including indoor cameras and outdoor cameras) can be registered to
the hub.
*3 A total of 50 sensors (including motion sensors and window/door sensors) and smart plugs
can be registered to the hub.
Mobile devices
Your mobile devices: 8 max.
You can expand the system by installing the Home Network
app on your mobile devices (smartphones, tablets, etc.) and
registering your mobile devices to the hub.
See page 11 for more information about the Home Network
app.
Note:
R You must configure the hub’s Wi-Fi settings before you can
use the app.
For assistance, please visit www.panasonic.com/support
5
Introduction
About this system
This system is an auxiliary system; it is not
designed to provide complete protection from
property loss. Panasonic will not be held
responsible in the event that property loss
occurs while this system is in operation.
For your safety
To prevent severe injury and loss of life/
property, read this section carefully before
using the product to ensure proper and safe
operation of your product.
WARNING
Power connection
R Use only the power source marked on the
product.
R Do not overload power outlets and
extension cords. This can result in the risk
of fire or electric shock.
R Completely insert the AC adaptor/power
plug into the power outlet. Failure to do so
may cause electric shock and/or excessive
heat resulting in a fire.
R Regularly remove any dust, etc. from the
AC adaptor/power plug by pulling it from
the power outlet, then wiping with a dry
cloth. Accumulated dust may cause an
insulation defect from moisture, etc.
resulting in a fire.
R Unplug the product from power outlets if it
emits smoke, an abnormal smell, or makes
an unusual noise. These conditions can
cause fire or electric shock. Confirm that
smoke has stopped emitting and contact us
at www.panasonic.com/contactinfo
R Unplug from power outlets and never touch
the inside of the product if its casing has
been broken open. Danger of electric shock
exists.
R Never touch the plug with wet hands.
Danger of electric shock exists.
R Do not connect non-specified devices.
Installation
R To prevent the risk of fire or electrical
shock, do not expose the product to rain or
any type of moisture.
R Do not place or use this product near
automatically controlled devices such as
automatic doors and fire alarms. Radio
waves emitted from this product may cause
such devices to malfunction resulting in an
accident.
R Do not allow the AC adaptor or telephone
line cord to be excessively pulled, bent or
placed under heavy objects.
R Keep small parts, such as microSD cards,
out of the reach of children. There is a risk
of swallowing. In the event they are
swallowed, seek medical advice
immediately.
Operating safeguards
R Unplug the product from power outlets
before cleaning. Do not use liquid or
aerosol cleaners.
R Do not disassemble the product.
R Do not spill liquids (detergents, cleansers,
etc.) onto the telephone line cord plug, or
allow it to become wet at all. This may
cause a fire. If the telephone line cord plug
becomes wet, immediately pull it from the
telephone wall jack, and do not use.
R Never put metal objects inside the product.
If metal objects enter the product, turn off
the circuit breaker and contact an
authorized service center.
Medical
R Consult the manufacturer of any personal
medical devices, such as pacemakers or
hearing aids, to determine if they are
adequately shielded from external RF
(radio frequency) energy. DECT features
operate between 1.92 GHz and 1.93 GHz
with a peak transmission power of 115 mW.
Wi-Fi features operate between 2.412 GHz
and 2.462 GHz with a peak transmission
power of 100 mW.
R Do not use the product in health care
facilities if any regulations posted in the
area instruct you not to do so. Hospitals or
health care facilities may be using
6
For assistance, please visit www.panasonic.com/support
Important Information
equipment that could be sensitive to
external RF energy.
CAUTION
Installation and location
R Never install wiring during a lightning storm.
R Never install telephone line jacks in wet
locations unless the jack is specifically
designed for wet locations.
R Never touch uninsulated telephone wires or
terminals unless the telephone line has
been disconnected at the network interface.
R Use caution when installing or modifying
telephone lines.
R The AC adaptor is used as the main
disconnect device. Ensure that the AC
outlet is installed near the product and is
easily accessible.
R This product is unable to make calls when:
– there is a power failure.
– when the cordless handset or mobile
device’s batteries need recharging or
have failed.
Important safety instructions
When using your product, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
1. Do not use this product near water for
example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet
basement or near a swimming pool.
2. Avoid using a telephone (other than a
cordless type) during an electrical storm.
There may be a remote risk of electric
shock from lightning.
3. Do not use the telephone to report a gas
leak in the vicinity of the leak.
4. Use only the power cord indicated in this
document.
SAVE THESE INSTRUCTIONS
Security cautions
Take appropriate measures to avoid the
following security breaches when using this
product.
– Leaks of private information
– Unauthorized use of this product
– Unauthorized interference or suspension of
the use of this product
Take the following measures to avoid security
breaches:
R Configure the wireless router that connects
your mobile device to this product to use
encryption for all wireless communication.
R You may be vulnerable to security
breaches if the unit is used with the login
password, disarm code, or PIN code, or
other settings at their defaults values.
Configure your own values for these
settings.
R Do not use passwords that could be easily
guessed by a third party. If you keep a
record of your passwords, protect that
record. Change passwords regularly.
R If you lose your mobile device, change the
password used to access this product.
R If you enable the product’s auto login
feature, enable the screen lock or similar
security feature on your mobile device.
R Take care when performing important
security related operations such as deleting
MAC address, unit IDs, etc.
R To prevent disclosure of personal
information, enable the screen lock or
similar security feature on your mobile
device.
R When submitting the product for repair,
make a note of any important information
stored in the product, as this information
may be erased or changed as part of the
repair process.
R Before handing the product over to a third
party for repair or other purposes, perform
a factory data reset to erase any data
stored in the product and remove the
microSD card. Use only trusted repair
services authorized by Panasonic.
R Before disposing of the product, perform a
factory data reset to erase any data stored
For assistance, please visit www.panasonic.com/support
7
Important Information
in the product. Remove and erase the
microSD card.
R If your mobile device will no longer be used
with the product, delete your mobile
device’s registration from the product and
delete the corresponding app from your
mobile device.
R If this product experiences a power outage,
its date and time setting may become
incorrect. In this case, the date and time
setting will be automatically corrected when
your mobile device and this product are
connected to the same wireless network.
Additionally, note the following.
R Multiple hubs cannot be used on the same
network.
R Only one mobile device can access this
product while away from home. If a second
mobile device connects to this product
while away from home, the first mobile
device is disconnected.
R Communications may be interrupted
depending on network conditions and
wireless signal quality.
R This product may be used in ways that
violate the privacy or publicity rights of
others. You are responsible for the ways in
which this product is used.
For best performance
Hub location/avoiding noise
The hub and other compatible Panasonic
devices use radio waves to communicate with
each other.
R For maximum coverage and noise-free
communications, place your hub:
– at a convenient, high, and central
location with no obstructions between
the devices and hub in an indoor
environment.
– away from electronic appliances such as
TVs, radios, personal computers,
wireless devices, or other phones.
– facing away from radio frequency
transmitters, such as external antennas
of mobile phone cell stations. (Avoid
putting the hub on a bay window or near
a window.)
R Coverage and voice quality depends on the
local environmental conditions.
R If the reception for a hub location is not
satisfactory, move the hub to another
location for better reception.
Environment
R Keep the product away from electrical noise
generating devices, such as fluorescent
lamps and motors.
R The product should be kept free from
excessive smoke, dust, high temperature,
and vibration.
R The product should not be exposed to
direct sunlight.
R Do not place heavy objects on top of the
product.
R When you leave the product unused for a
long period of time, unplug the product from
the power outlet.
R The product should be kept away from heat
sources such as heaters, kitchen stoves,
etc. It should not be placed in rooms where
the temperature is less than 0 °C (32 °F) or
greater than 40 °C (104 °F). Damp
basements should also be avoided.
R The maximum communication range may
be shortened when the product is used in
the following places: Near obstacles such
as hills, tunnels, underground, near metal
objects such as wire fences, etc.
R Operating the product near electrical
appliances may cause interference. Move
away from the electrical appliances.
Other information
Routine care
R Wipe the outer surface of the product with a
soft moist cloth.
R Do not use benzine, thinner, or any
abrasive powder.
Protecting your recordings
R Do not remove the microSD card or
disconnect the hub’s AC adaptor while
8
For assistance, please visit www.panasonic.com/support
Important Information
reading or writing data to the microSD card.
Data on the card could become corrupted.
R If a microSD card malfunctions or is
exposed to electromagnetic waves or static
electricity, data on the card could become
corrupted or erased. Therefore we
recommend backing up important data to a
computer or other device.
Notice for product disposal, transfer,
or return
R This product can store your private/
confidential information. To protect your
privacy/confidentiality, we recommend that
you erase information such as phonebook
or caller list entries from the memory before
you dispose of, transfer, or return the
product.
Notice
For assistance, please visit www.panasonic.com/support
9
Important Information
Part names and functions
C
B
A
D E
G H I
F
Speaker
LED indicator
DC jack
LINE jack
MWi-Fi SETUPN
Used when performing initial setup.
microSD card slot
Used when inserting a microSD card.
Remove the label when inserting.
M HANDSET/LOCATORN
Used when registering a handset. You
can also press this button to locate a
misplaced handset.
M CAMERAN
Used when registering a camera.
M OTHER DEVICEN
Used when registering a sensor or smart
plug.
LED indicator
You can use the LED indicator to confirm the
hub’s status.
Indicator Status
Off No power, or LED
indicator is turned
off
*1
Indicator Status
Green, lit Normal operation,
connected to
wireless router
*1
Green, blinking Registration mode
Alternating:
Green, blinking
Yellow, blinking
Hub is starting up
(cannot be used
yet)
*2
Red, lit Security system is
armed
Red, blinking quickly Security system was
triggered
Yellow, lit Initial setup required
Yellow, blinking Initial setup in
progress, mobile
device connected
Yellow, blinking
quickly
Initial setup is
starting
*1 You can configure the hub so that its LED
indicator does not light during normal
operation. For more information, refer to
the User’s Guide (page 15).
*2 It may take some time for the hub to finish
starting up.
Connections
Insert the AC adaptor plug firmly into the
DC jack.
Secure the AC adaptor cord by wrapping
it around the hook.
Connect the AC adaptor to the power
outlet.
Insert the telephone line cord into the
LINE jack and a single-line telephone jack
(RJ11C) until you hear a click.
DSL/ADSL service users only: Connect
your DSL/ADSL filter (not supplied).
Outdoor Camera (KX-HNC600) or
Indoor Camera (KX-HNC200) users
only: Remove the label covering the card
slot and then insert the microSD card (not
supplied) into the slot with the notched
corner (
1
) facing upwards (2) until it
clicks into place.
10
For assistance, please visit www.panasonic.com/support
Setup
Note:
R Use only the supplied Panasonic AC
adaptor PNLV236.
R A microSD card (not supplied) is required to
record images from cameras. Refer to the
information about the available microSD
card (page 3).
R To remove the microSD card, push in the
microSD card and then remove it.
4
5
4
3
2
1
6
1
2
Note about power connections
AC adaptor connection
R The AC adaptor must remain connected at
all times. (It is normal for the adaptor to feel
warm during use.)
R The AC adaptor should be connected to a
vertically oriented or floor-mounted AC
outlet. Do not connect the AC adaptor to a
ceiling-mounted AC outlet, as the weight of
the adaptor may cause it to become
disconnected.
Power failure
R The hub will not work during a power failure.
R The hub’s telephone features will not work
during a power failure. We recommend
connecting a corded-type telephone that
does not use an AC adaptor to your
telephone line. You can connect the
telephone to the same telephone line jack
as the hub by using a Panasonic T-adaptor
(page 3).
Wi-Fi® settings
After you have connected your hub, here is
what you will need to do in order to access the
system from your mobile device. Each
procedure is explained in this chapter.
1 Download
Download the [Home Network] app to
your mobile device.
2 Initial setup
Use the [Home Network] app to
configure the hub to connect to your
wireless router, and then register your
mobile device to the hub.
Downloading the [Home
Network] app
Download information is available at the web
page listed below.
www.panasonic.net/pcc/support/tel/
homenetwork/
For assistance, please visit www.panasonic.com/support
11
Setup
Compatible mobile devices
iPhone® 4 or later, iPad®, or iPad mini™ (iOS
6.0 or later) or an Android™ device (Android
4.0 or later)
Note:
R The [Home Network] app may not function
properly depending on the system
environment, such as the model of your
mobile device, peripherals connected to
your mobile device, and the apps installed
on your mobile device.
Initial setup
Confirm the following before you begin.
– Make sure you have installed the [Home
Network] app on your mobile device
– Make sure your mobile device can connect
to the Internet
– Make sure the hub and your wireless router
are turned on and the hub’s LED indicator
is lit in yellow
– Make sure you know the network name
(SSID) and password assigned to your
wireless router
Initial setup for iPhone, iPad
1 Start the [Home Network] app.
2 Tap [Set up the Hub].
3 When prompted, press MWi-Fi SETUPN
on the hub.
R The LED indicator blinks in yellow.
4 Change your mobile device’s Wi-Fi
setting temporarily so that it connects to
the hub directly.
R Open your mobile device’s [Settings]
app, tap [Wi-Fi], select “KX-HNB600”,
enter “00000000” as the password,
and then tap [Join].
R If more than 1 item named
“KX-HNB600” is displayed, wait
approx. 10 minutes and perform this
procedure from the beginning.
5 Start the [Home Network] app again.
6 If necessary, enter the password required
to connect to your wireless router and
then tap [Next].
R The hub and your mobile device
connect to your wireless router.
R If prompted, follow the on-screen
instructions and connect your mobile
device to your wireless router, start the
app again, and then tap [Add Mobile
Device].
7 When prompted, press MWi-Fi SETUPN
on the hub.
R Your mobile device will be registered
to the hub.
8 When prompted, follow the on-screen
instructions and set the password used to
log in to the hub while away from home.
9 Follow the on-screen instructions to finish
setting up the hub.
R The app’s home screen is displayed
when initial setup is complete.
Initial setup for Android devices
1 Start the [Home Network] app.
2 Tap [Set up the Hub].
3 When prompted, press MWi-Fi SETUPN
on the hub.
R The LED indicator blinks in yellow.
R The app temporarily changes your
mobile device’s Wi-Fi setting so that it
connects to the hub directly.
4 If necessary, enter the password required
to connect to your wireless router and
then tap [Next].
R The hub and your mobile device
connect to your wireless router.
5 When prompted, press MWi-Fi SETUPN
on the hub.
R Your mobile device will be registered
to the hub.
6 When prompted, follow the on-screen
instructions and set the password used to
log in to the hub while away from home.
R The app’s home screen is displayed
when initial setup is complete.
12
For assistance, please visit www.panasonic.com/support
Setup
Information about Wi-Fi
communication
The hub uses Wi-Fi to communicate with your
wireless router. Refer to the following
information when planning where to place the
hub.
Do not use the hub in the following areas or
locations. Malfunction or interference to radio
communication may result.
R Indoor areas that have certain types of
radio or mobile communications equipment
R Locations near microwave ovens or
Bluetooth devices
R Indoor areas where antitheft devices or
2.4 GHz frequency devices such as POS
systems are used
Do not place the hub in areas where the
following materials or objects are located
between the hub and the wireless router.
These materials and objects may interfere
with wireless communication or cause
wireless transmission speed to become slower.
R Metallic doors or shutters
R Walls containing aluminum-sheet insulation
R Walls made of concrete, stone, brick, or tin
R Multiple walls
R Steel shelving
R Fireproof glass
Registering another mobile device
After you have used your mobile device to
perform the initial setup procedure, you can
add other mobile devices to the system.
Before following this procedure, make sure
you have completed the Initial Setup
procedure.
1 Using the mobile device that you want to
register, download the [Home Network]
app and then start the app.
2 Tap [Add Mobile Device].
3 When prompted, press MWi-Fi SETUPN
on the hub.
R Your mobile device will be registered
to the hub.
4 When prompted, follow the on-screen
instructions and enter the password used
to log in to the hub while away from home.
R The app’s home screen is displayed.
Registering other devices to the hub
This procedure is not required for devices
that were included as part of a bundle.
Before you can use cameras, sensors, and
smart plugs, they must be registered to the
hub.
If you purchased devices separately (i.e., not
as part of a bundle), you must register each
device to the hub.
You can register each device by using the
registration buttons or the [Home Network]
app.
For assistance, please visit www.panasonic.com/support
13
Setup
Using registration buttons
1 Hub:
Press and hold the registration button
until the LED indicator blinks in green.
R Press and hold the appropriate
registration button (page 10) according
to the device you want to register.
M HANDSET/LOCATORN: For
handsets
M CAMERAN: For cameras
M OTHER DEVICEN: For sensors
and smart plugs
2 Handset:
Place the handset on the charger.
Devices other than handset:
Press and hold the device’s registration
button until the device’s LED indicator
blinks in green.
R When registration is complete, the hub
sounds one long beep.
Note:
R If registration fails, the hub sounds several
short beeps.
Using the app
1 Start the [Home Network] app.
2 From the [Home Network] app home
screen, tap [Settings].
3 Tap [Device Registration].
4 Tap [Registration].
5 Select the type of device that you want to
register.
6 Handset:
Place the handset on the charger.
Devices other than handset:
Press and hold the registration button on
the device you want to register until the
device’s LED indicator blinks in green.
R When registration is complete, the hub
sounds one long beep.
7 When prompted, configure the device
name and location as desired, and then
tap [OK].
Note:
R If registration fails, the hub sounds several
short beeps.
14
For assistance, please visit www.panasonic.com/support
Setup
Wireless communication range (DECT)
The wireless communication range of each
device in the system from the hub is
approximately 50 m (160 feet) indoors and
approximately 300 m (1,000 feet) outdoors.
Wireless communication may be unreliable
when the following obstacles are located
between the hub and other system devices.
R Metal doors or screens
R Walls containing aluminum-sheet insulation
R Walls made of concrete or corrugated iron
R Double-pane glass windows
R Multiple walls
R When using each device on separate floors
or in different buildings
Note:
R Outdoor camera, indoor camera, smart
plug:
A device’s LED indicator will blink quickly in
red if it is out of range of the hub. In this
case, confirm all connections, including
those of the hub.
R Window/door sensor, motion sensor:
You can check the sensor’s communication
status by pressing M N. If the LED
indicator is lit in green or red, the sensor is
communicating properly with the hub. If the
LED indicator blinks in red, it is out of range
of the hub.
Accessing the User’s Guide
The User’s Guide is a collection of online
documentation that helps you get the most out
of the [Home Network] app.
1 iPhone/iPad
Tap
in the app’s home screen.
Android devices
Tap or press your mobile device’s
menu button in the app’s home screen.
2 Tap [User’s Guide].
Note:
R You can also access the User’s Guide at
the web page listed below.
www.panasonic.net/pcc/support/tel/
homenetwork/manual/
For assistance, please visit www.panasonic.com/support
15
Appendix
Wall mounting
You can use the included wall mounting
adaptor to wall mount the hub if desired.
Note:
R Make sure that the wall and the fixing
method are strong enough to support the
weight of the unit.
1 Connect the AC adaptor and the
telephone line cord to the hub.
R Secure the AC adaptor cord by
wrapping it around the hook.
2 Slide the wall mounting adaptor up until it
clicks into place.
R Make sure the “UP” mark on the wall
mounting adaptor faces upwards.
R Align and insert the tabs (
1
) of the
wall mounting adaptor to the grooves
(2) of the hub.
UP
1
2
U
P
UP
16
For assistance, please visit www.panasonic.com/support
Appendix
3 Mount the hub on a wall then slide down
to secure in place.
R Pass the AC adaptor cord and the
telephone line cord through the groove
(
1
) in the wall mounting adaptor.
Wrap up the telephone line cord as
shown to prevent the cord from being
pinched.
R This product is compliant with the
following wall phone plate sizes (2
types).
2
83 mm (3 1/4 inches)
3
102 mm (4 inches)
R Fit the slots of the hub onto the
corresponding wall phone plate tabs
for (4) and (5) respectively.
5
2
3
4
5
4
1
Removing the wall mounting adaptor
While pushing the release levers (A) away
from the center of the wall mounting adaptor,
slide the adaptor down (B).
AA
B
For assistance, please visit www.panasonic.com/support
17
Appendix
Specifications
R Standards
DECT:
DECT 6.0 (Digital Enhanced Cordless
Telecommunications 6.0)
Wi-Fi:
IEEE 802.11 b/g/n
R Frequency range
DECT:
1.92 GHz – 1.93 GHz
Wi-Fi:
2.412 GHz – 2.462 GHz (channels 1 – 11)
R RF transmission power
DECT:
115 mW (max.)
Wi-Fi:
100 mW (peak transmission power)
R Encryption
WPA2-PSK (TKIP/AES), WPA-PSK (TKIP/
AES), WEP (128/64 bit)
R Simplified configuration
WPS (PBC)
R Power source
120 V AC, 60 Hz
R Power consumption
Standby: Approx. 3.5 W
Maximum: Approx. 4.0 W
R Operating conditions
0 °C – 40 °C (32 °F – 104 °F)
20% – 80% relative air humidity (dry)
R Alert tone volume
High alert level: approx. 90 dB
Low alert level: approx. 73 dB
(measured approx. 10 cm (3 15/16 inches)
in front of the center of the unit)
R Dimensions
Approx. 42 mm ´ 130 mm ´ 130 mm (1
21/32 inches ´ 5 1/8 inches ´ 5 1/8 inches)
R Mass (weight)
Approx. 220 g (0.49 lb)
Open source software notice
R Parts of this product use open source
software supplied based on the relevant
conditions of the Free Software
Foundation’s GPL and/or LGPL and other
conditions. Please read all licence
information and copyright notices related to
the open source software used by this
product. This information is available at the
following web page:
www.panasonic.net/pcc/support/tel/
homenetwork/
At least three (3) years from delivery of this
product, Panasonic System Networks Co.,
Ltd. will give to any third party who contacts
us at the contact information provided
below, for a charge of no more than the
cost of physically distributing source code,
a complete machine-readable copy of the
corresponding source code and the
copyright notices covered under the GPL
and the LGPL. Please note that software
licensed under the GPL and the LGPL is
not under warranty.
www.panasonic.net/pcc/support/tel/
homenetwork/
Software information
R The End User License Agreement (EULA)
for the Home Network app is available at
the following web page:
www.panasonic.net/pcc/support/tel/
homenetwork/
18
For assistance, please visit www.panasonic.com/support
Appendix
FCC and other information
This equipment complies with Part 68 of the
FCC rules and the requirements adopted by
the ACTA. On the bottom of this equipment is
a label that contains, among other information,
a product identifier in the format
US:ACJ----------.
If requested, this number must be provided to
the telephone company.
R Registration No.............(found on the
bottom of the unit)
R Ringer Equivalence No. (REN).......0.1B
A plug and jack used to connect this
equipment to the premises wiring and
telephone network must comply with the
applicable FCC Part 68 rules and
requirements adopted by the ACTA. A
compliant telephone cord and modular plug is
provided with the product. It is designed to be
connected to a compatible modular jack that is
also compliant.
The REN is used to determine the number of
devices that may be connected to a telephone
line. Excessive RENs on a telephone line may
result in the devices not ringing in response to
an incoming call. In most but not all areas, the
sum of RENs should not exceed five (5.0). To
be certain of the number of devices that may
be connected to a line, as determined by the
total RENs, contact the local telephone
company. For products approved after July
23, 2001, the REN for the product is part of
the product identifier that has the format
US:AAAEQ##TXXXX. The digits represented
by ## are the REN without a decimal point
(e.g., 03 is a REN of 0.3).
If this equipment causes harm to the
telephone network, the telephone company
will notify you in advance that temporary
discontinuance of service may be required.
But if advance notice isn’t practical, the
telephone company will notify the customer as
soon as possible. Also, you will be advised of
your right to file a complaint with the FCC if
you believe it is necessary.
The telephone company may make changes
in its facilities, equipment, operations or
procedures that could affect the operation of
the equipment. If this happens the telephone
company will provide advance notice in order
for you to make necessary modifications to
maintain uninterrupted service.
If trouble is experienced with this equipment,
for repair or warranty information, please
contact a Factory Service Center or other
Authorized Servicer. If the equipment is
causing harm to the telephone network, the
telephone company may request that you
disconnect the equipment until the problem is
resolved.
Connection to party line service is subject to
state tariffs. Contact the state public utility
commission, public service commission or
corporation commission for information.
If your home has specially wired alarm
equipment connected to the telephone line,
ensure the installation of this equipment does
not disable your alarm equipment. If you have
questions about what will disable alarm
equipment, consult your telephone company
or a qualified installer.
This equipment is hearing aid compatible as
defined by the FCC in 47 CFR Section 68.316.
When you hold the phone to your ear, noise
might be heard in your Hearing Aid. Some
Hearing Aids are not adequately shielded from
external RF (radio frequency) energy. If noise
occurs, use an optional headset accessory or
the speakerphone option (if applicable) when
using this phone. Consult with your audiologist
or Hearing Aid manufacturer about the
availability of Hearing Aids which provide
adequate shielding to RF energy commonly
emitted by digital devices.
WHEN PROGRAMMING EMERGENCY
NUMBERS AND(OR) MAKING TEST CALLS
TO EMERGENCY NUMBERS:
1. Remain on the line and briefly explain to
the dispatcher the reason for the call.
For assistance, please visit www.panasonic.com/support
19
Appendix
2. Perform such activities in the off-peak
hours, such as early morning or late
evenings.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
Privacy of communications may not be
ensured when using this phone.
CAUTION:
Any changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate this device.
NOTE:
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/
TV technician for help.
Some cordless telephones operate at
frequencies that may cause interference to
nearby TVs and VCRs. To minimize or
prevent such interference, the base of the
cordless telephone should not be placed near
or on top of a TV or VCR. If interference is
experienced, move the cordless telephone
further away from the TV or VCR. This will
often reduce or eliminate interference.
FCC RF Exposure Warning:
R This product complies with FCC radiation
exposure limits set forth for an uncontrolled
environment.
R To comply with FCC RF exposure
requirements, the hub must be installed
and operated 20 cm (8 inches) or more
between the product and all person’s body.
R This product may not be collocated or
operated in conjunction with any other
antenna or transmitter.
R For body-worn operation, the handset must
be used only with a non-metallic accessory.
Use of other accessories may not ensure
compliance with FCC RF exposure
requirements.
Notice:
R FCC ID can be found on the bottom of the
unit.
20
For assistance, please visit www.panasonic.com/support
Appendix
Customer services
Customer Services Directory (United States and Puerto Rico)
Obtain Product Information and Operating Assistance; locate your nearest
Dealer or Service Center; purchase Parts and Accessories; or make Customer
Service and Literature requests by visiting our Web Site at:
www.panasonic.com/support
or, contact us via the web at:
www.panasonic.com/contactinfo
For hearing or speech impaired TTY users, TTY: 1-877-833-8855
For hearing or speech impaired TTY users, TTY: 1-866-605-1277
Purchase Parts, Accessories and Owner’s Manual online for all
Panasonic Products by visiting our Web Site at:
www.pstc.panasonic.com
or, send your request by E-mail to:
npcparts@us.panasonic.com
You may also contact us directly at:
1-800-237-9080 (Fax Only)
(Monday - Friday 9 am to 9 pm, EST.)
Panasonic National Parts Center
20421 84th Avenue S., Kent, WA 98032
(We accept Visa, MasterCard, Discover Card, American Express.)
Accessory Purchases (United States and Puerto Rico)
You may also contact us directly at: 1-800-211-PANA (1-800-211-7262),
Monday - Friday 9 am to 9 pm; Saturday - Sunday 10 am to 7 pm, EST.
For assistance, please visit www.panasonic.com/support
21
Appendix
Warranty (For United States and Puerto Rico)
Limited Warranty Coverage
Labor
One (1) Year
Parts
One (1) Year
Online Repair Request
To submit a new repair request and for quick repair status visit our Web Site at
www.panasonic.com/repair
PROOF OF PURCHASE.
Panasonic Home Network System Products
Limited Warranty
Mail-In Service--Online
If your product does not work properly because of a defect in materials or workmanship,
Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length
of the period indicated on the chart below, which starts with the date of original purchase
(“Limited Warranty period”), at its option either (a) repair your product with new or
refurbished parts, or (b) replace it with a new or a refurbished equivalent value product, or
(c) refund your purchase price. The decision to repair, replace or refund will be made by
the warrantor.
During the “Labor” Limited Warranty period there will be no charge for labor. During the
“Parts” Limited Warranty period, there will be no charge for parts. You must mail-in your
product prepaid during the Limited Warranty period. This Limited Warranty excludes both
parts and labor for batteries, antennas, and cosmetic parts (cabinet). This Limited
Warranty only applies to products purchased and serviced in the United States or Puerto
Rico. This Limited Warranty is extended only to the original purchaser and only covers
products purchased as new.
Home Network System Products
microSD card (Included model only) 90 days N/A
When shipping the unit carefully pack in a padded shipping carton, include all
accessories, and send it prepaid. Include a letter detailing the complaint, a return
address and provide a day time phone number where you can be reached. P.O. Boxes
are not acceptable. Keep the tracking number for your records. A copy of valid
registered receipt is required under the 1 year parts and labor Limited Warranty.
For Limited Warranty service for headsets if a headset is included with this
product please follow instructions above.
IF REPAIR IS NEEDED DURING THE LIMITED WARRANTY PERIOD THE
PURCHASER WILL BE REQUIRED TO FURNISH A SALES
RECEIPT/PROOF OF PURCHASE INDICATING DATE OF PURCHASE,
AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL BE
CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH
22
For assistance, please visit www.panasonic.com/support
Appendix
When you ship the product
• Carefully pack your unit, preferably in the original carton.
• Attach a letter, detailing the symptom.
• Send the unit to Panasonic Exchange Center, prepaid and adequately insured.
• Do not send your unit to Panasonic Corporation of North America listed on the back
cover or to executive or regional sales offices. These locations do not repair consumer
products.
Limited Warranty Limits And Exclusions
This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship,
and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty
ALSO DOES NOT COVER damages which occurred in shipment, or failures which are
caused by products not supplied by the warrantor, or failures which result from accidents,
misuse, abuse, neglect, bug infestation, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, introduction of sand,
humidity or liquids, commercial use such as hotel, office, restaurant, or other business or
rental use of the product, or service by anyone other than a Factory Service Center or
other Authorized Servicer, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED
WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR
ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY. (As examples, this
excludes damages for lost time, lost calls or messages, cost of having someone remove or
re-install an installed unit if applicable, travel to and from the servicer. The items listed are
not exclusive, but are for illustration only.) ALL EXPRESS AND IMPLIED WARRANTIES,
INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE
PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, or limitations on how long an implied warranty lasts, so the exclusions may not
apply to you.
This Limited Warranty gives you specific legal rights and you may also have other rights
which vary from state to state. If a problem with this product develops during or after the
Limited Warranty period, you may contact your dealer or Service Center. If the problem is
not handled to your satisfaction, then write to the warrantor’s Consumer Affairs Department
at the addresses listed for the warrantor.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY,
ARE YOUR RESPONSIBILITY.
For assistance, please visit www.panasonic.com/support
23
Appendix
A
B
Check if telephone line cord is connected.
If your product is not working properly. . .
IMPORTANT!
Visit our Web site: www.panasonic.com/support
• FAQ and troubleshooting hints are available.
Use the Home Network app to access the User’s Guide
and refer to the Troubleshooting section.
For your future reference
We recommend keeping a record of the following information to assist with any repair under
warranty.
Serial No. Date of purchase
(found on the bottom of the unit)
Name and address of dealer
Attach your purchase receipt here.
Two Riverfront Plaza, Newark, NJ 07102-5490
© Panasonic System Networks Co., Ltd. 2014
Guía de configuración del sistema
Sistema de red doméstico
HUB
Modelo n° KX-HNB600
Gracias por adquirir un producto Panasonic.
Este documento explica cómo configurar el hub y cómo acceder a él desde un dispositivo
móvil. Se deben seguir estos pasos para poder usar el sistema.
Para obtener detalles sobre cómo usar el sistema, consulte la Guía del usuario (página 9).
Lea este documento antes de usar la unidad, y guárdelo para consultarlo en el futuro.
Para obtener ayuda, visite nuestro sitio web: www.panasonic.com/support
para clientes en los EE. UU. o Puerto Rico (solo en inglés).
Por favor, registre su producto: www.panasonic.com/prodreg
PNQX6695ZA CC0814WK0 (E)
Configuración
Nombres de los componentes y funciones ..........3
Led indicador ........................................................3
Conexiones ..........................................................4
Configuraciones de Wi-Fi® ...................................5
Registro de otro dispositivo móvil ........................7
Registro de otros dispositivos al hub ...................7
Apéndice
Alcance de la comunicación inalámbrica
(DECT) .................................................................9
Acceso a la Guía del usuario ...............................9
Montaje en la pared ...........................................10
2
Tabla de Contenido
Nombres de los componentes y funciones
C
B
A
D E
G H I
F
Altavoz
Led indicador
Clavija de corriente continua
Clavija LINE
MWi-Fi SETUPN
Se usa durante la configuración inicial.
Ranura para tarjeta microSD
Se usa mientras inserta una tarjeta microSD.
Retire la etiqueta cuando la inserte.
M HANDSET/LOCATORN
Se usa al registrar un auricular. También
puede presionar este botón para ubicar un
auricular perdido.
M CAMERAN
Se usar al registrar una cámara.
M OTHER DEVICEN
Se usa al registrar un sensor o un conector
inteligente.
Led indicador
Puede usar el Led indicador para confirmar el
estado del hub.
Indicador Estado
Apagado Sin energía, o el Led
indicador está apagado
*1
Verde, encendido Funcionamiento nor-
mal, conectado al enrutador inalámbrico
*1
Verde, parpadeante Modo de registro
Alterna entre:
Verde, parpadeante
Amarillo, parpadeante
El hub se está iniciando (no se puede usar
aún)
*2
Rojo, encendido Se activó el sistema
de seguridad
Rojo, parpadeo rápido Se activó el sistema
de seguridad
Amarillo, encendido Se debe realizar la con-
figuración inicial
Amarillo, parpadeante Configuración inicial
en progreso, dispositivo móvil conectado
Amarillo, parpadeo rápido
La configuración inicial
está arrancando
*1 Puede configurar el hub de forma tal que el
Led indicador no se encienda durante el
funcionamiento normal. Para obtener más
información, consulte la Guía del usuario
(página 9).
*2 Es posible que el hub tarde un tiempo en
terminar de iniciar.
Para obtener ayuda, visite www.panasonic.com/support
3
Configuración
Conexiones
Inserte el enchufe del adaptador de corriente
firmemente en la clavija de corriente continua.
Asegure el cable del adaptador de corriente
alterna enrollándolo en el gancho.
Conecte el adaptador de corriente a la toma
de corriente.
Inserte el cable de línea telefónica en la clavija
de LINE y la toma telefónica de una sola línea
(RJ11C) hasta que escuche un clic.
Solo para los usuarios de servicio DSL/
ADSL: conecte su filtro DSL/ADSL (no
incluido).
Solo usuarios de Cámara exterior
(KX-HNC600) o Cámara interior
(KX-HNC200): retire la etiqueta que cubre la
ranura de la tarjeta y luego inserte la tarjeta
microSD (no se incluye) con la esquina
dentada (1) hacia arriba en la ranura (2)
hasta que escuche un clic.
Nota:
R Use solo el adaptador de corriente alterna
Panasonic PNLV236 que se suministra.
R Se necesita una tarjeta microSD (no incluida)
para grabar imágenes de cámaras.
R Para extraer la tarjeta microSD, presiónela hacia
dentro primero y luego extráigala.
4
5
4
3
2
1
6
1
2
Nota acerca de las conexiones de
alimentación
Adaptador de corriente alterna
R El adaptador de corriente debe permanecer
conectado en todo momento (es normal que el
adaptador se caliente durante su uso).
R El adaptador de corriente debe estar conectado
a un enchufe de corriente orientado
verticalmente o en una toma de corriente alterna
colocada en el piso. No conecte el adaptador de
corriente alterna a una toma de corriente
montada en el techo, ya que el peso del
adaptador puede hacer que se desconecte.
4
Para obtener ayuda, visite www.panasonic.com/support
Configuración
Falla en el suministro eléctrico
R El hub no funciona durante las fallas del
suministro eléctrico.
R Las funciones telefónicas del hub no trabajarán
durante un corte de energía. Recomendamos
que conecte un teléfono con cable que no utilice
un adaptador de CA a su línea telefónica. Puede
conectar el teléfono a la misma toma de la línea
telefónica que el hub utilizando un adaptador T
Panasonic.
Configuraciones de Wi-Fi
®
Después de conectar el hub, necesitará lo siguiente
para acceder al sistema desde su dispositivo móvil.
En este capítulo se explica cada procedimiento.
1 Descarga
Descargue la aplicación [Red doméstico] a
su dispositivo móvil.
2 Configuración inicial
Use la aplicación [Red doméstico] para
configurar el hub y que se conecte al
enrutador inalámbrico; a continuación, registre
el dispositivo móvil en el hub.
Cómo descargar la aplicación [Red
doméstico]
La información de descarga está disponible en la
siguiente página web.
www.panasonic.net/pcc/support/tel/
homenetwork/
Dispositivos móviles compatibles
iPhone® 4 o posterior, iPad®, o iPad mini™ (iOS
6.0 o posterior) o un dispositivo
Android™ (Android 4.0 o posterior)
Nota:
R Es posible que la aplicación [Red doméstico]
no funcione correctamente dependiendo del
entorno del sistema, como el modelo de su
dispositivo móvil, los periféricos conectados al
mismo y las aplicaciones instaladas en él.
Configuración inicial
Confirme lo siguiente antes de comenzar.
– Asegúrese de haber instalado la aplicación [Red
doméstico] en su dispositivo móvil
– Asegúrese de que su dispositivo móvil pueda
conectarse a Internet
– Asegúrese de que el hub y su enrutador
inalámbrico estén encendidos y que el Led
indicador del hub esté encendido en amarillo
– Asegúrese de conocer el nombre de la red
(SSID) y la clave que se asignó al enrutador
inalámbrico
Configuración inicial para iPhone, iPad
1 Inicie la aplicación [Red doméstico].
2 Toque [Configurar el Hub].
3 Cuando se le solicite, oprima MWi-Fi SETUPN
en el hub.
R El Led indicador parpadea en amarillo.
4 Cambie la configuración de Wi-Fi de su
dispositivo móvil temporalmente para que se
conecte de forma directa al hub.
R Abra la aplicación [Configuración] en su
dispositivo móvil, toque [Wi-Fi], seleccione
“KX-HNB600”, introduzca “00000000”
como clave y luego toque [Conectar].
R Si aparece más de 1 elemento llamado
“KX-HNB600”, espere aprox. 10 minutos y
realice este procedimiento desde el inicio.
5 Inicie de nuevo la aplicación [Red doméstico].
6 Si es necesario, introduzca la clave necesaria
para conectarse al enrutador inalámbrico y, a
continuación, presione [Sig.].
R El hub y su dispositivo móvil se conectan a
su enrutador inalámbrico.
R Si se le solicita, siga las instrucciones en la
pantalla y conecte su dispositivo móvil a su
enrutador inalámbrico, reinicie la aplicación
y luego toque [Añadir dispositivo móvil].
7 Cuando se le solicite, oprima MWi-Fi SETUPN
en el hub.
R Se registrará el dispositivo móvil en el hub.
Para obtener ayuda, visite www.panasonic.com/support
5
Configuración
8 Cuando se le solicite, siga las instrucciones en
la pantalla y establezca la clave usada para
acceder al hub.
9 Siga las instrucciones en pantalla para
terminar de configurar el hub.
R Aparecerá la pantalla de inicio de la
aplicación una vez completada la
configuración inicial.
Configuración inicial para dispositivos
Android
1 Inicie la aplicación [Red doméstico].
2 Toque [Configurar el Hub].
3 Cuando se le solicite, oprima MWi-Fi SETUPN
en el hub.
R El Led indicador parpadea en amarillo.
R La aplicación cambia temporalmente la
configuración Wi-Fi de su dispositivo móvil
para que se conecte de forma directa al
hub.
4 Si es necesario, introduzca la clave necesaria
para conectarse al enrutador inalámbrico y, a
continuación, presione [Sig.].
R El hub y su dispositivo móvil se conectan a
su enrutador inalámbrico.
5 Cuando se le solicite, oprima MWi-Fi SETUPN
en el hub.
R Se registrará el dispositivo móvil en el hub.
6 Cuando se le solicite, siga las instrucciones en
la pantalla y establezca la clave usada para
acceder al hub.
R Aparecerá la pantalla de inicio de la
aplicación una vez completada la
configuración inicial.
Información acerca de la
comunicación Wi-Fi
El hub usa Wi-Fi para comunicarse con su
enrutador inalámbrico. Consulte la siguiente
información cuando piense en dónde colocar el hub.
No coloque el hub en las siguientes áreas o
ubicaciones. Es posible que existan fallas o
interferencias en la comunicación por radio.
R Interiores donde haya equipos con cierto tipo de
comunicación por radio o móvil
R Ubicaciones cerca de hornos microondas o
dispositivos Bluetooth
R Interiores donde haya dispositivos antirrobos o
dispositivos en frecuencias de 2.4 GHz como los
sistemas POS
No coloque un hub en áreas donde se encuentren
los siguientes materiales u objetos entre el hub y el
enrutador inalámbrico. Dichos materiales y objetos
pueden interferir con la comunicación inalámbrica o
pueden provocar que la velocidad de transmisión
se reduzca.
R Puertas metálicas
R Paredes que contengan aislamiento de aluminio
R Paredes de hormigón, piedra, ladrillo o estaño
R Varias paredes
R Repisas de acero
R Vidrio a prueba de incendios
6
Para obtener ayuda, visite www.panasonic.com/support
Configuración
Registro de otro dispositivo móvil
Una vez que haya usado su dispositivo móvil para
realizar el procedimiento de configuración inicial,
puede agregar otros dispositivos móviles al
sistema. Antes de continuar con este
procedimiento, asegúrese de haber completado el
procedimiento de configuración inicial.
1 Desde el dispositivo móvil que desea registrar,
descargue la aplicación [Red doméstico] y
luego iníciela.
2 Toque [Añadir dispositivo móvil].
3 Cuando se le solicite, oprima MWi-Fi SETUPN
en el hub.
R Se registrará el dispositivo móvil en el hub.
4 Cuando se le solicite, siga las instrucciones en
la pantalla e introduzca la clave usada para
acceder al hub.
R Aparecerá la pantalla de inicio de la
aplicación.
Registro de otros dispositivos al hub
Este procedimiento no es necesario para unidades que son parte de un paquete.
Antes de poder usar cámaras, sensores y
conectores inteligentes, se deben registrar en el
hub.
Si compró los dispositivos por separado (es decir,
no como parte de un paquete), debe registrar cada
dispositivo en el hub.
Puede registrar cada unidad mediante los botones
de registro o la aplicación [Red doméstico].
Uso de los botones de registro
1 Hub:
Oprima y mantenga oprimido el botón de
registro hasta que el Led indicador parpadee
en verde.
R Oprima y mantenga oprimido el botón de
registro correspondiente (página 3) en
función del dispositivo que desea registrar.
M HANDSET/LOCATORN: Para
auriculares
M CAMERAN: Para cámaras
M OTHER DEVICEN: Para sensores o
conectores inteligentes
2 Auricular:
Coloque el auricular en el cargador.
Dispositivos que no sean auriculares:
Oprima y mantenga oprimido el botón de
registro del dispositivo hasta que el Led
indicador parpadee en verde.
R Cuando se ha completado el registro, el
hub emitirá un pitido largo.
Nota:
R Si el registro falla, el hub emitirá varios pitidos
cortos.
Para obtener ayuda, visite www.panasonic.com/support
7
Configuración
Uso de la aplicación
1 Inicie la aplicación [Red doméstico].
2 Desde la pantalla de inicio de la aplicación
[Red doméstico], toque [Configuración].
3 Toque [Registro de dispositivos].
4 Toque [Registro].
5 Seleccione el tipo de dispositivo que desea
registrar.
6 Auricular:
Coloque el auricular en el cargador.
Dispositivos que no sean auriculares:
Oprima y mantenga oprimido el botón de
registro del dispositivo que desea registrar
hasta que el Led indicador parpadee en verde.
R Cuando se ha completado el registro, el
hub emitirá un pitido largo.
7 Cuando se solicite, configure el nombre de la
unidad y su ubicación según lo desee, y luego
toque [Aceptar].
Nota:
R Si el registro falla, el hub emitirá varios pitidos
cortos.
8
Para obtener ayuda, visite www.panasonic.com/support
Configuración
Alcance de la comunicación inalámbrica (DECT)
El alcance de la comunicación inalámbrica de cada
dispositivo en el sistema del hub es de
aproximadamente 50 m (160 pies) en interiores y
de aproximadamente 300 m (1,000 pies) en el
exterior. Es posible que la comunicación
inalámbrica no sea tan confiable cuando se
encuentran los obstáculos siguientes entre el hub y
otros dispositivos del sistema.
R Puertas o pantallas metálicas
R Paredes que contengan aislamiento de aluminio
R Paredes de hormigón o hierro corrugado
R Ventanas de vidrio doble
R Varias paredes
R Cuando los dispositivos están en pisos o
edificios diferentes
Nota:
R Cámara exterior, cámara interior, enchufe
inteligente:
Un Led indicador parpadea rápidamente en rojo,
si está fuera del alcance del hub. En este caso,
confirme todas las conexiones, incluso las del
hub.
R Sensor para ventana/puerta, sensor de
movimiento:
Puede verificar el estado de la comunicación del
sensor presionando M N. Si el Led indicador
está iluminado en verde o rojo, el sensor se está
comunicando de forma adecuada con el hub. Si
el Led indicador parpadea en rojo, se encuentra
fuera de alcance del hub.
Acceso a la Guía del usuario
La Guía del usuario es una colección de
documentación en línea que lo ayuda a aprovechar
al máximo la aplicación [Red doméstico].
1
iPhone/iPad
Toque en la pantalla de inicio de la
aplicación.
Dispositivos Android
Toque u oprima el botón menú de su
dispositivo en la pantalla de inicio de la
aplicación.
2 Toque [Guía del usuario].
Nota:
R También puede acceder a la Guía del usuario
mediante la página web a continuación.
www.panasonic.net/pcc/support/tel/
homenetwork/manual/
Para obtener ayuda, visite www.panasonic.com/support
9
Apéndice
Montaje en la pared
Puede usar el adaptador de instalación en pared
incluido para instalar el hub de dicha forma si lo
desea.
Nota:
R Asegúrese de que la pared y el método de
colocación sean lo suficientemente resistentes
para soportar el peso de la unidad.
1 Conecte el adaptador de corriente y el cable
de línea telefónica al hub.
R Asegure el cable del adaptador de
corriente alterna enrollándolo en el gancho.
2 Deslice el adaptador de instalación en pared
hasta que encaje y haga clic.
R Asegúrese de que la marca “UP” en el
adaptador de instalación en pared mire
hacia arriba.
R Alinee e inserte las pestañas (1) del
adaptador de instalación en pared en las
ranuras (2) del hub.
UP
1
2
U
P
UP
10
Para obtener ayuda, visite www.panasonic.com/support
Apéndice
3 Monte el hub en la pared y deslícelo para
asegurarlo en su sitio.
R Pase el cable del adaptador de corriente y
el de la línea telefónica por la ranura (1)
en el adaptador de instalación en pared.
Enrolle el cable de línea telefónica como se
muestra para evitar que se quede pillado.
R Este producto es compatible con los
siguientes tamaños de placas de los
teléfonos (tipos 2).
2
83 mm (3 1/4 pulgadas)
3
102 mm (4 pulgadas)
R Ajuste las ranuras del hub en las pestañas
correspondientes de la placa del teléfono
(4) y (5) respectivamente.
5
2
3
4
5
4
1
Extracción del adaptador de instalación
en pared
Mientras aleja las palancas de desbloqueo (A) del
adaptador de instalación en pared, deslice el
adaptador hacia abajo (B).
AA
B
Para obtener ayuda, visite www.panasonic.com/support
11
Apéndice
12
Notas
Loading...
