Basic Operating Instructions
Digital Camera
Model No. DMC-ZS7
Before connecting, operating or adjusting
this product, please read the instructions
Please also refer to Operating Instructions (PDF
format) recorded on the CD-ROM containing the
Operating Instructions (supplied).
You can learn about advanced operation methods and check the
Troubleshooting.
For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,
contact us via the web at: http://www.panasonic.com/contactinfo
completely.
P
VQT2L60-1
M0210KZ1020
Dear Customer,
Thank you for choosing Panasonic!
You have purchased one of the most sophisticated and reliable products
on the market today. Used properly, we’re sure it will bring you and your
family years of enjoyment. Please take the time to fill in the information
below.
The serial number is on the tag located on the underside of your Camera.
Be sure to retain this manual as your convenient Camera information
source. Please note that the actual controls and components, menu
items, etc. of your Digital Camera may look somewhat different from
those shown in the illustrations in these Operating Instructions.
Carefully observe copyright laws.
• Recording of pre-recorded tapes or discs or other published or
broadcast material for purposes other than your own private use may
infringe copyright laws. Even for the purpose of private use, recording
of certain material may be restricted.
Model No. Serial No.
A lithium ion battery that is recyclable powers
the product you have purchased. Please call
1-800-8-BATTERY for information on how to recycle
this battery.
Information for Your Safety
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE
EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.
2 VQT2L60 (ENG) (ENG) VQT2L60 3
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT
DAMAGE,
•
DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING
OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
• USE ONLY THE RECOMMENDED ACCESSORIES.
• DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO
USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Product Identification Marking is located on the bottom of units.
■
About the battery pack
CAUTION
Battery pack (Lithium ion battery pack)
• Use the specified unit to recharge the battery pack.
• Do not use the battery pack with equipment other than the specified unit.
• Do not get dirt, sand, liquids, or other foreign matter on the terminals.
• Do not touch the plug terminals (+ and −) with metal objects.
• Do not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes,
wash it off thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub
the eyes. Rinse eyes thoroughly with water, and then consult a doctor.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in an automobile exposed to direct
sunlight for a long period of time with doors and windows closed.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 °C
(140 °F) or incinerate.
FCC Note:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, follow the attached
installation instructions and use only shielded interface
cables with ferrite core when connecting to computer or
peripheral devices.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
this equipment.
Declaration of Conformity
Trade Name: Panasonic
Model No.: DMC-ZS7
Responsible party: Panasonic Corporation of
Support Contact: Panasonic Consumer
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
North America
One Panasonic Way,
Secaucus, NJ 07094
Electronics Company
1-800-211-PANA (7262)
DMC-ZS7
4 VQT2L60 (ENG) (ENG) VQT2L60 5
■
About the battery charger
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILTIN CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE
UNIT IS WELL VENTILATED. TO PREVENT RISK OF ELECTRIC
SHOCK OR FIRE HAZARD DUE TO OVERHEATING, ENSURE
THAT CURTAINS AND ANY OTHER MATERIALS DO NOT
OBSTRUCT THE VENTILATION VENTS.
Battery charger
This battery charger operates on AC between 110 V and 240 V.
But
• In the U.S.A. and Canada, the battery charger must be connected to
a 120 V AC power supply only.
• When connecting to an AC supply outside of the U.S.A. or Canada,
use a plug adaptor to suit the AC outlet configuration.
■
Cautions for Use
• Do not use any other AV cables except the supplied one.
• Do not use any other USB connection cables except the supplied one.
• Do not use any other cables except a genuine Panasonic HDMI mini cable (RPCDHM15/RP-CDHM30; optional).
Keep the camera as far away as possible from electromagnetic equipment
(such as microwave ovens, TVs, video games etc.).
• If you use the camera on top of or near a TV, the pictures and sound on the
camera may be disrupted by electromagnetic wave radiation.
• Do not use the camera near cell phones because doing so may result in noise
adversely affecting the pictures and sound.
• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely
affect the camera, disturbing the pictures and sound.
• If the camera is adversely affected by electromagnetic equipment and stops
functioning properly, turn the camera off and remove the battery or disconnect
AC adaptor (DMW-AC5PP; optional). Then reinsert the battery or reconnect AC
adaptor and turn the camera on.
Do not use the camera near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures
and sound may be adversely affected.
Contents Standard accessories
Information for Your Safety .......2
Before use
Standard accessories ................7
Names of parts............................8
Cursor button ...................................9
Preparations
Charging battery .......................10
Inserting and removing the card
(optional)/the battery ................12
Picture save destination
(cards and built-in memory) ...........13
Setting the Clock ......................14
About GPS .....................................15
Setting the menu ......................16
This product is licensed under the AVC patent portfolio license for the personal
and noncommercial use of a consumer to (i) encode video in compliance with
the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded
by a consumer engaged in a personal and non-commercial activity and/or was
obtained from a video provider licensed to provide AVC Video. No license is
granted or shall be implied for any other use. Additional information may be
obtained from MPEG LA, LLC.
See http://www.mpegla.com.
Basics
Selecting the [REC] mode ........17
Taking pictures with
automatic settings
[INTELLIGENT AUTO] Mode ....18
AF Tracking ....................................19
Taking motion pictures ............20
Viewing your pictures
[NORMAL PLAY] .......................21
Deleting pictures ......................21
Others
Reading the Operating
Instructions (PDF format) ........22
Specifications ...........................24
Optional accessories ...............27
Digital Camera Accessory
Order Form ................................28
Limited Warranty (ONLY FOR
U.S.A. AND PUERTO RICO) .....29
6 VQT2L60 (ENG) (ENG) VQT2L60 7
Check that all the accessories are included before using the camera. Part
numbers are as of January 2010.
Battery Pack
DMW-BCG10PP
• Charge the battery
before use.
Battery Pack is indicated as
battery pack or battery in the
text.
Battery Charger
DE-A65B
Battery Charger is indicated as
battery charger or charger in
the text.
Battery Carrying
Case
VGQ0E45
• Cards are optional. You can record or play back pictures on the built-in
memory when you are not using a card.
• If any accessories are lost, customers should contact Panasonic’s parts
department at 1 800 833-9626 for further information about obtaining
replacement parts.
• Please dispose of all packaging appropriately.
Hand Strap
VFC4297
USB Connection
Cable
K1HA14AD0003
AV Cable
K1HA14CD0004
CD-ROM
VFF0576
• Software:
Use it to install the
software on your PC.
• Operating
Instructions
Names of parts
Cursor button
Hand strap eyelet
Zoom lever
LCD monitor
[EXPOSURE] button
Status indicator
[DISPLAY] button
Q.MENU/Delete button
Camera ON/OFF switch
Shutter button
Mode dial
Flash
Self-timer indicator/AF Assist Lamp
Lens barrel
Lens
Speaker
GPS antenna
Microphone
REC/PLAY switch
Motion picture
button
Tripod receptacle
• Ensure that the tripod is stable.
Card/Battery door
Release lever
DC coupler cover
Always use a genuine Panasonic AC adaptor (DMW-AC5PP: optional).
●
When using an AC adaptor, ensure that the Panasonic DC coupler
●
(DMW-DCC5; optional) and AC adaptor (DMW-AC5PP; optional) are
used.
8 VQT2L60 (ENG) (ENG) VQT2L60 9
Cursor button
Hand strap eyelet
The illustrations and screens in this manual may differ from the actual
product.
[MENU/SET]
(menu display/set/finish)
Left cursor button (◄)
• Self-timer
Down cursor button (▼)
• Macro Mode
In this manual, the button that is used is shaded or indicated
●
by▲▼◄►.
Up cursor button (▲)
• Exposure
Compensation
Right cursor button (►)
• Flash
We recommend using the
supplied hand strap to avoid
dropping the camera.
HDMI socket
[AV OUT/DIGITAL] socket
We recommend you use a battery with sufficient battery power or the
●
AC adaptor when recording motion pictures.
If while recording motion pictures using the AC adaptor the power
●
supply is cut off due to a power cut or if the AC adaptor is disconnected
etc., the motion picture being recorded will not be recorded.
Charging battery
■
About batteries that you can use with this unit
The battery that can be used with this unit is DMW-BCG10PP.
It has been found that counterfeit battery packs which look very
similar to the genuine products are made available to purchase
in some markets. Some of these battery packs are not adequately
protected with internal protection to meet the requirements of
appropriate safety standards. There is a possibility that these
battery packs may lead to fire or explosion. Please be advised
that we are not liable for any accident or failure occurring as a
result of use of a counterfeit battery pack. To ensure that safe
products are used we recommend that a genuine Panasonic
battery pack is used.
• Use the dedicated charger and battery.
• The camera has a function for distinguishing batteries which can
be used safely. The dedicated battery (DMW-BCG10PP) supports
this function. The only batteries suitable for use with this unit
are genuine Panasonic products and batteries manufactured by
other companies and certified by Panasonic. (Batteries which do
not support this function cannot be used). Panasonic cannot in
any way guarantee the quality, performance or safety of batteries
which have been manufactured by other companies and are not
genuine Panasonic products.
• The battery is not charged when the camera is shipped. Charge
the battery and set the Clock before use.
• Charge the battery with the charger indoors (10 °C - 35 °C (50 °F -
95 °F)).
Insert the battery terminals and attach
the battery to the charger
Ensure [LUMIX] faces outwards.
1
2
10 VQT2L60 (ENG) (ENG) VQT2L60 11
Connect the charger to the electrical outlet
Charging light ([CHARGE])
On: Charging in progress (approx. 130
min. if fully depleted)
Off: Charging complete
Detach the battery after charging is completed
■
Guidelines for number of recordable pictures and
recording time
Number of recordable
pictures
Recording time Approx. 150 min
Playback time Approx. 300 min
Recording conditions by CIPA standard
• CIPA is an abbreviation of [Camera & Imaging Products Association].
• [PROGRAM AE] Mode.
• [GPS SETTING] is set to [OFF].
• Temperature: 23 °C (73.4 °F)/Humidity: 50% when LCD monitor is on.
• Using a Panasonic SD Memory Card (32 MB).
• Using the supplied battery.
• Starting recording 30 seconds after the camera is turned on. (When the
Optical Image Stabilizer function is set to [AUTO].)
• Recording once every 30 seconds with full flash every second
recording.
• Rotating the zoom lever from Tele to Wide or vice versa in every
recording.
• Turning the camera off every 10 recordings and leaving it until the
temperature of the battery decreases.
∗
The number of recordable pictures decreases when [LCD MODE] is used.
Approx. 300 pictures
∗
Inserting and removing the card
(optional)/the battery
Set the camera ON/OFF switch
to OFF and slide the release
lever (
) to [OPEN] before
A
opening the lid
Completely insert battery and
[OPEN] [LOCK]
card
• Battery: Push in until the lever is locked.
• Memory card: Push in until it clicks.
Do not touch terminal.
B
Check orientation.
C
Close lid
Slide to the [LOCK] position.
■
To remove
• To remove battery:
move lever in direction of arrow.
Lever
Always use genuine Panasonic batteries (DMW-BCG10PP).
●
If you use other batteries, we cannot guarantee the quality of this
●
product.
The card may be damaged if it is not fully inserted.
●
• To remove card:
press down in center.
A
B
C
12 VQT2L60 (ENG) (ENG) VQT2L60 13
Picture save destination (cards and built-in memory)
■
Built-in memory (approx. 15 MB)
The built-in memory can be used as a temporary storage device when the
●
card being used becomes full.
The access time for the built-in memory may be longer than the access time
●
for a card.
■
Compatible memory cards (optional)
The following SD standard-based cards
(Panasonic brand recommended)
Type of Card Capacity Notes
SD memory
cards
SDHC memory
cards
SDXC memory
cards
If the write-protect switch is set to ‘LOCK’, the card cannot be used to
●
record or delete pictures, and it cannot be formatted.
Latest information:
●
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
8 MB – 2 GB
4 GB – 32 GB
48 GB – 64 GB
• Can be used with devices
compatible with the
respective formats.
• Before using SDXC memory
cards, check that your
computer and other devices
support this type of card.
http://panasonic.net/avc/
sdcard/information/SDXC.
html
• Cards in capacities not listed
at left are not supported.
Switch (LOCK)
Keep the Memory Card out of reach of children to prevent swallowing.
●
Setting the Clock
About GPS
The Clock is not set when the camera is shipped.
Turn on the power (
Press [MENU/SET] (
)
A
) while
B
the message is displayed
Press ◄► to select the items
(year, month, day, hour, minute,
display order or time display
format), and press ▲▼ to set
• To cancel → Press .
Press [MENU/SET]
Confirm the setting and press
[MENU/SET]
• T
o return to the previous screen, press .
A
B
14 VQT2L60 (ENG) (ENG) VQT2L60 15
About GPS
Press ▲▼ to select [YES] and press [MENU/SET]
if automatically correcting time of day
• To manually set date and time →select [NO].
When [PLEASE SET THE HOME AREA] is
displayed, press [MENU/SET]
Press ◄► to set your home
area and press [MENU/SET]
The current time and home area are set.
• [GPS SETTING] turns [ON].
• Turn on the power again and check time
display.
■
To change time setting
Select [CLOCK SET] from the [REC] or [SETUP] menu, perform and
.
When GPS is used, the camera performs the following functions:
• Records location name information and the latitude and longitude
for the positioned location on the recorded pictures.
• Corrects automatically to the current time.
■
The GPS function can be used even when the camera’s
power is off.
When [GPS SETTING] is [ON], the GPS function works to check
your current position periodically even if the camera’s power is OFF.
• When turning off the camera’s power in an airplane, hospital or
other restricted area, set [GPS SETTING] to or [OFF].
• When [GPS SETTING] is [ON], power will drain from the battery
even if the camera’s power is OFF.
Setting the menu
Refer to the following procedures to operate menus such as the [SETUP]
menu, [REC] menu, [TRAVEL MODE] menu and [PLAYBACK] menu.
Example: Setting [GPS SETTING] from [OFF] to [ON] in the
[PROGRAM AE] Mode
Press [MENU/SET] to display the menu
Switching to the [TRAVEL MODE] menu
1 Press ◄.
2 Press ▼ to select the [TRAVEL MODE]
menu icon [
3 Press ►.
• Select a menu item next and set it.
].
Press ▲▼ to select [GPS
SETTING] and then press ►
• Depending on the item, its setting may not
appear or it may be displayed in a different
way.
Press ▲▼ to select [ON] and
then press [MENU/SET] to set
Press [MENU/SET] to close the
menu
16 VQT2L60 (ENG) (ENG) VQT2L60 17
Selecting the [REC] mode
Turn on the power (
)
A
A
Slide the [REC/PLAY] switch
(
) to
B
Switching the mode by rotating
the mode dial(
[INTELLIGENT AUTO] Mode
Take pictures with automatic settings.
[PROGRAM AE] Mode
The subjects are recorded using your own settings.
[APERTURE-PRIORITY] Mode
The shutter speed is automatically determined by the aperture value you
set.
[SHUTTER-PRIORITY] Mode
The aperture value is automatically determined by the shutter speed you
set.
[MANUAL EXPOSURE] Mode
The exposure is adjusted by the aperture value and the shutter speed which
are manually adjusted.
[CUSTOM] Mode
Use this mode to take pictures with previously registered setting.
[MY SCN MODE]
Take pictures in frequently-used Scene Modes.
[SCENE MODE]
Take pictures according to scene.
[CLIPBOARD] Mode
Take pictures as memos.
)
C
BC
Taking pictures with automatic settings
Optimum settings are made automatically from information such as ‘face,’
‘movement,’ ‘brightness,’ and ‘distance’ just by pointing the camera at
the subject, meaning that clear pictures can be taken without the need to
make settings manually.
Turn on the power (
)
A
Slide the [REC/PLAY] switch
(
) to
B
Set the mode dial (
) to
C
Shutter button
A
BC
Take pictures
Press halfway
(press lightly and focus)
• If jitter becomes noticeable, use both hands, keep your arms close
to your body, and stand with your feet at shoulder width.
• Focus display (
(In focus: lit / Not in focus: flashing)
• The AF area (E) is displayed around
the subject’s face by the Face Detection
function. In other cases, it is displayed at
the point on the subject which is in focus.
D
Press fully
(press the button all the way to record)
)
D
E
18 VQT2L60 (ENG) (ENG) VQT2L60 19
[INTELLIGENT AUTO] Mode
Recording Mode:
■
Automatic Scene Detection
Camera identifies scene when pointed at subject, and makes optimum
settings automatically. The type of scene detected is indicated by a blue
icon for two seconds.
Recognizes people [i PORTRAIT]
Recognizes babies [i BABY] (When babies (under 3 years) that are
registered with the Face Recognition function are recognized)
Recognizes landscapes [i SCENERY]
Recognizes night scenes and people in them [i NIGHT PORTRAIT]
(Only when
Recognizes night scenes [i NIGHT SCENERY]
Recognizes close-ups [i MACRO]
Recognizes sunsets [i SUNSET]
Reads subject movement to avoid blurring when scene does not
correspond to any of the above.
is selected)
If the camera automatically identifies the scene and determines that people
appear as subjects in the picture ( or ), Face Detection is activated,
and the focus and exposure are adjusted for the recognized faces.
AF Tracking
Even if a subject, where the focus was locked (AF Lock) moves, the
camera can continue to keep it in focus.
Press▲
AF Tracking icon
A
AF Tracking frame
B
• Press ▲ again to cancel.
A
B
Align the AF Tracking frame with the subject, and
then press ▼ to lock
• The optimum scene is detected for the subject where the focus
was locked (AF Lock).
• AF Lock successful: Yellow
• AF Lock failed: Red (flash)
• Press ▲ to cancel.
Taking motion pictures
Recording Mode:
Enables motion pictures to be recorded with (stereo) audio. (Recording
with muted sound is not possible.) Zoom can also be used during
recording.
Slide the [REC/PLAY] switch to
Set the mode dial to any except
Start recording
Press
Remaining recording
time (approx.)
End recording
Press
Immediately release the motion picture button after pressing it all the
●
way.
When there is no space left to store the motion picture, recording
●
automatically ends.
AVCHD Lite motion pictures can be recorded continuously for up to
●
13 hours, 3 minutes and 20 seconds. Also, a maximum of approx. 2 GB
of continuous motion picture can be recorded in Motion JPEG format.
(Even if there is more than 2 GB of available space on the card, the
available recording time will be calculated for a maximum of 2 GB.)
Elapsed recording time
20 VQT2L60 (ENG) (ENG) VQT2L60 21
Viewing your pictures [NORMAL PLAY]
Playback Mode:
Slide the [REC/PLAY] switch
(
) to
A
Press ◄► to select the picture
To play back a motion picture, select an image with ◄ or ►, and then
●
press ▲ to start playback.
Deleting pictures
Playback Mode:
Deleted pictures cannot be recovered.
Press (
displayed picture
Press ◄ to select [YES] and
then press [MENU/SET] (
) to delete
A
)
B
A
B
A
Reading the Operating Instructions
(PDF format)
• You have practised the basic operations introduced in these operating
instructions and want to progress to advanced operations.
• You want to check the Troubleshooting.
In these kinds of situations refer to Operating Instructions (PDF format)
recorded on the CD-ROM containing the Operating Instructions
(supplied).
■
For Windows
Turn the PC on and insert the CD-ROM containing
the Operating Instructions (supplied)
Click the [Operating Instructions]
Select the desired language and then click
[Operating Instructions] to install
B
A
A
To return to the install menu.
See next page.
B
Double click the ‘Operating Instructions’ shortcut
icon on the desktop
22 VQT2L60 (ENG) (ENG) VQT2L60 23
■
When the Operating Instructions (PDF format) will not open
You will need Adobe Acrobat Reader 5.0 or later or Adobe Reader 7.0
or later to browse or print the Operating Instructions (PDF format).
Insert the CD-ROM containing the Operating Instructions (supplied),
click B and then follow the messages on the screen to install.
Compatible OS: Windows 2000 SP4/Windows XP SP2 or SP3/
Windows Vista SP1 or SP2/Windows 7
• You can download and install a version of Adobe Reader that you can
use with your OS from the following Web Site.
http://get.adobe.com/reader/otherversions
■
To uninstall the Operating Instructions (PDF format)
Delete the PDF file from the ‘Program Files\Panasonic\Lumix\’ folder.
• When the contents in the Program Files folder cannot be displayed,
click the [Show the contents of this folder] to display them.
■
For Macintosh
Turn the PC on and insert the CD-ROM containing
the Operating Instructions (supplied)
Open the ‘Manual’ folder in the CD-ROM and then
copy the PDF file with the desired language inside
the folder
Double click the PDF file to open it
Specifications
Digital Camera: Information for your safety
Power Source DC 5.1 V
Power
Consumption
Camera effective
pixels
Image sensor 1/2.33” CCD, total pixel number 14,500,000 pixels
Lens Optical 12 x zoom
Digital Zoom Max. 4 x
Extended Optical
Zoom
Focus range
P/A/S/M 50 cm (1.64 feet) (Wide)/
Macro/
Intelligent
Auto/
Clipboard/
Motion picture
Scene Mode There may be difference in above settings.
Shutter system Electronic shutter + Mechanical shutter
Burst recording
Burst speed 2.3 pictures/second
Number of
recordable
pictures
When recording: 1.3 W
When playing back: 0.6 W
12,100,000 pixels
Primary color filter
f=4.1 mm to 49.2 mm (35 mm film camera
equivalent: 25 mm to 300 mm)/
F3.3 to F4.9
Max. 23.4 x
2 m (6.56 feet) (Tele) to
3 cm (0.10 feet) (Wide)/1 m (3.28 feet) (Tele) to
(5 × to 8 × is 2 m (6.56 feet) to ∞)
Max. 5 pictures (Standard), max. 3 pictures (Fine)
∞
∞
24 VQT2L60 (ENG) (ENG) VQT2L60 25
Hi-speed burst
Burst speed Approx. 10 pictures/second (Speed priority)
Number of
recordable
pictures
Shutter speed 60 to 1/2000 th
Exposure (AE) Program AE (P)/Aperture-priority AE (A)/
Metering mode Multiple/Center weighted/Spot
LCD monitor 3.0” TFT LCD (Approx. 460,800 dots)
Flash Flash range: (ISO AUTO) Approx. 60 cm (1.97 feet)
Microphone Stereo
Speaker Monaural
Recording media Built-in Memory (Approx. 15 MB)/SD Memory Card/
Recording file
format
Still Picture JPEG (based on Design rule for Camera File
Still pictures
with audio
Motion
pictures
Approx. 6 pictures/second (Image priority)
Approx. 15 pictures (When using the built-in
memory, immediately after formatting)
Max. 100 pictures (When using a card, it may differ
depending on the type of card and the recording
conditions)
[STARRY SKY] Mode: 15 seconds, 30 seconds,
60 seconds
Shutter-priority AE (S)/Manual exposure (M)
Exposure Compensation
(1/3 EV Step, -2 EV to +2 EV)
(field of view ratio about 100 %)
to 5.3 m (17.4 feet) (Wide)
SDHC Memory Card/SDXC Memory Card
system, based on Exif 2.21 standard)/DPOF
corresponding
JPEG (based on Design rule for Camera File
system, based on Exif 2.21 standard) + QuickTime
AVCHD Lite/
QuickTime Motion JPEG
(motion pictures with audio)
Specifications (Continued) Optional accessories
Interface Digital: USB 2.0 (High Speed)
Terminal HDMI: HDMI mini cable (type C)
Dimensions
Mass With card and battery: Approx. 218
Operating
temperature
Operating
humidity
GPS Reception frequency: 1575.42 MHz (C/A code)
Language select [ENGLISH]/[ESPAÑOL]
Battery charger
(Panasonic DE-A65B): Information for your safety
Input 110 V to 240 V 50/60Hz, 0.2 A
Output 4.2 V
Equipment mobility: Movable
Battery Pack (lithium-ion)
(Panasonic DMW-BCG10PP): Information for your safety
Voltage/capacity 3.6 V/895 mAh
Analog video/audio: NTSC Composit,
Audio line output (stereo)
AV OUT/DIGITAL: Dedicated jack (14 pin)
Approx. 103.3 mm (W) x 59.6 mm (H) x 32.6 mm (D)
[4.07” (W) x 2.35” (H) x 1.28” (D)]
(excluding the projection part)
(0.480 lb)
Excluding card and battery: Approx. 196 (0.432 lb)
0 °C to 40 °C (32 °F to 104 °F)
10 % to 80 %
Geographical coordinate system: WGS84
0.65 A (Battery charging)
26 VQT2L60 (ENG) (ENG) VQT2L60 27
Product name: Battery Pack
Product no.: DMW-BCG10PP
Performance identical to
●
supplied battery pack.
Recommended for taking on
●
holiday, etc.
Product name:
HDMI mini cable
Product no.:
RP-CDHM15/RP-CDHM30
Product name: AC adaptor
Product no.: DMW-AC5PP
Purchase the AC adaptor and DC
coupler as a set. They cannot be
used individually with this camera.
Product name:
Marine Case
Product no.:
DMW-MCTZ10
Product name:
DC coupler
Produce no.:
DMW-DCC5
Product name:
SDXC Memory Card
Product no.:
48 GB: RP-SDW48GU1K
64 GB: RP-SDW64GU1K
Product name:
SDHC Memory Card
Product no.:
4 GB: RP-SDW04GU1K
4 GB: RP-SDP04GU1K
4 GB: RP-SDR04GU1A
Product numbers are correct as of January 2010. These may be
●
8 GB: RP-SDW08GU1K
8 GB: RP-SDP08GU1K
8 GB: RP-SDR08GU1A
16 GB: RP-SDW16GU1K
16 GB: RP-SDP16GU1K
32 GB: RP-SDW32GU1K
Product name: SD Memory Card
Product no.:
2 GB: RP-SDP02GU1K
2 GB: RP-SDR02GU1A
subject to change.
Accessories and/or model numbers may vary between countries.
●
Consult your local dealer.
Digital Camera Accessory Order Form
Limited Warranty
(ONLY FOR U.S.A. AND PUERTO RICO)
Limited Warranty for P_eng.fm 11 ページ ２００９年１１月２６日 木曜日 午後５時０分
Please photocopy this form when placing an order.
1. Digital Camera Model #
2. Items Ordered
Accessory # Description Price Each Quantity Total Price
3.Method of payment (check one)
Check of Money Order enclosed (NO C.O.D.SHIPMENTS)
VISA Credit Card #
MasterCard Expiration Date
Discover Customer Signature
(Please do not send cash)
4. Shipping information (UPS delivery requires complete street address)
Ship To:
Mr.
Mrs.
Ms.
First Last
Street Address
City
TO OBTAIN ANY OF OUR DIGITAL CAMERA ACCESSORIES YOU CAN DO ANY OF
CALL PANASONIC’S ACCESSORY ORDER LINE AT 1-800-332-5368
MAIL THIS ORDER TO: PANASONIC SERVICE AND TECHNOLOGY COMPANY
Make Check or Money Order to: PANASONIC ACCESSORIES
VISIT YOUR LOCAL PANASONIC DEALER
[6 AM-6 PM M-F, PACIFIC TIME]
ACCESSORY ORDER OFFICE
20421 84th Avenue South Kent, WA. 98032
Your State & Local Sales Tax
Shipping & Handling 6.95
State Zip
THE FOLLOWING:
OR
OR
Subtotal
Total Enclosed
Phone#:
Day ( )
Night ( )
28 VQT2L60 (ENG) (ENG) VQT2L60 29
Limited Warranty
Limited Warranty
(ONLY FOR U.S.A. AND PUERTO RICO)
Limited Warranty for P_eng.fm 11 ページ ２００９年１１月２６日 木曜日 午後５時０分
(ONLY FOR U.S.A. AND PUERTO RICO)
Panasonic Consumer Electronics Company,
Division of Panasonic Corporation of North America
One Panasonic Way, Secaucus, New Jersey 07094
Limited Warranty Coverage (For USA and Puerto Rico Only)
If your product does not work properly because of a defect in materials or
workmanship, Panasonic Consumer Electronics Company (referred to as “the
warrantor”) will, for the length of the period indicated on the chart below, which
starts with the date of original purchase (“warranty period”), at its option either (a)
repair your product with new or refurbished parts, (b) replace it with a new or a
refurbished equivalent value product, or (c) refund your purchase price. The
decision to repair, replace or refund will be made by the warrantor.
Digital Still Camera 1 year 1 year
CCD 6 months 90 days
SD Memory Cards, Rechargeable
Battery Pack (defective exchange)
During the “Labor” warranty period there will be no charge for labor. During the
“Parts” warranty period, there will be no charge for parts. This Limited Warranty
excludes both parts and labor for non-rechargeable batteries, antennas, and
cosmetic parts (cabinet). This warranty only applies to products purchased and
serviced in the United States or Puerto Rico. This warranty is extended only to the
original purchaser of a new product which was not sold “as is”.
Panasonic Digital Still Camera Products
Limited Warranty
Product or Part Name Parts Labor
90 days Not Applicable
Limited Warranty for P_eng.fm 12 ページ ２００９年１１月２６日 木曜日 午後５時０分
Limited Warranty for P_eng.fm 13 ページ ２００９年１１月２６日 木曜日 午後５時０分
Mail-In Service
For assistance in the U.S.A. and Puerto Rico in obtaining repairs, please ship the
product prepaid to:
Panasonic Exchange Center
4900 George McVay Drive
Suite B
McAllen, TX 78503
panacare
When shipping the unit, carefully pack, include all accessories, and send it
prepaid, adequately insured and preferably in the original carton. If Lithium Ion
batteries are shipped by air the package must be labeled “Contains Lithium Ion
Battery (No lithium metal)”. Damaged batteries are prohibited from shipment by
US Mail. Batteries must be securely packed in a manner to prevent
short-circuiting and a package cannot contain more than 3 Lithium Ion batteries.
Include a letter detailing the complaint, a return address and provide a daytime
phone number where you can be reached. A valid registered receipt is required
under the Limited Warranty.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE
PURCHASER WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF
OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID AND
PLACE OF PURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR
OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF PURCHASE.
Limited Warranty Limits And Exclusions
This warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic
damage. The warranty ALSO DOES NOT COVER damages which occurred in
shipment, or failures which are caused by products not supplied by the warrantor,
or failures which result from accidents, misuse, abuse, neglect, mishandling,
misapplication, alteration, faulty installation, set-up adjustments, misadjustment of
consumer controls, improper maintenance, power line surge, lightning damage,
modification, introduction of sand, humidity or liquids, commercial use such as
hotel, office, restaurant, or other business or rental use of the product, or service
by anyone other than a Factory Service Center or other Authorized Servicer, or
damage that is attributable to acts of God.
@us.panasonic.com
30 VQT2L60 (ENG) (ENG) VQT2L60 31
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
Limited Warranty for P_eng.fm 13 ページ ２００９年１１月２６日 木曜日 午後５時０分
“LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING
OUT OF ANY BREACH OF THIS WARRANTY.
(As examples, this excludes damages for lost time, travel to and from the servicer,
loss of or damage to media or images, data or other memory or recorded content.
The items listed are not exclusive, but for illustration only.)
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY
OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED
WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, or limitations on how long an implied warranty lasts, so the exclusions
may not apply to you.
This warranty gives you specific legal rights and you may also have other rights
which vary from state to state. If a problem with this product develops during or
after the warranty period, you may contact your dealer or Service Center. If the
problem is not handled to your satisfaction, then write to the warrantor's
Consumer Affairs Department at the addresses listed for the warrantor.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
Limited Warranty for P_eng.fm 14 ページ ２００９年１１月２６日 木曜日 午後５時０分
Customer Services Directory (United States and Puerto Rico)
Obtain Product Information and Operating Assistance; locate your nearest
Dealer or Service Center; purchase Parts and Accessories; or make
Customer Service and Literature requests by visiting our Web Site at:
http://www.panasonic.com/help
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at:
1-800-211-PANA (7262)
Monday-Friday 9am-9pm, Saturday-Sunday 10am-7pm EST
For hearing or speech impaired TTY users, TTY: 1-877-833-8855
Accessory Purchases (United States and Puerto Rico)
Purchase Parts, Accessories and Instruction Books online for all Panasonic
Products by visiting our Web Site at:
http://www.pstc.panasonic.com
Or, send your request by E-mail to:
npcparts@us.panasonic.com
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday-Friday 9am-9pm EST)
Panasonic Service and Technology Company
20421 84th Avenue South, Kent, WA 98032
(We accept Visa, MasterCard, Discover Card, American Express, and Personal
Checks)
For hearing or speech impaired TTY users, TTY: 1-866-605-1277
As of November 2009
32 VQT2L60 (ENG)
-If you see this symbol-
Information on Disposal in other Countries outside
the European Union
This symbol is only valid in the European Union. If you
wish to discard this product, please contact your local
authorities or dealer and ask for the correct method of
disposal.
• HDMI, the HDMI Logo, and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC
in the United States and other countries.
• HDAVI Control™ is a trademark of Panasonic
Corporation.
• VIERA Link™ is a trademark of Panasonic
Corporation.
• EZ Sync™ is a trademark of Panasonic
Corporation.
•
“AVCHD”, “AVCHD Lite” and “AVCHD”,
“AVCHD Lite” logo are trademarks of
Panasonic Corporation and Sony Corporation.
• Manufactured under license from Dolby
Laboratories.
Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
• SDXC Logo is a trademark of SD-3C, LLC.
• QuickTime and the QuickTime logo are
trademarks or registered trademarks of Apple
Inc., used under license therefrom.
• Other names, company names, and product
names printed in these instructions are
trademarks or registered trademarks of the
companies concerned.
Panasonic Consumer Electronics Company,
Division of Panasonic Corporation of North America
One Panasonic Way, Secaucus, NJ 07094
© Panasonic Corporation 2010
Printed in Japan
Loading...
