Panasonic DMC-LF1W User Manual

Basic Owner’s Manual

Digital Camera

Model No. DMC-LF1

Please read these instructions carefully before using this product, and
save this manual for future use.

More detailed instructions on the operation of this camera
are contained in “Owner’s Manual for advanced features
(PDF format)” in the supplied CD-ROM. Install it on your PC
to read it.

Register online at www.panasonic.com/register (U.S. customers only)

For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,
contact us via the web at: http://www.panasonic.com/contactinfo

P

VQT5A15

M0513KZ0

Dear Customer,

Date of Purchase Dealer Phone No.

Dealer Purchased From Model No.

Dealer Address Serial No.

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable
products on the market today. Used properly, we’re sure it will bring
you and your family years of enjoyment. Please take time to fill in
the information below. The serial number is on the tag located on the
underside of your camera. Be sure to retain this manual as your
convenient camera information source.

Please note that the actual controls and components, menu items, etc.
of your Digital Camera may look somewhat different from those shown
in the illustrations in this Owner’s Manual.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or broadcast
material for purposes other than your own private use may infringe copyright
laws. Even for the purpose of private use, recording of certain material may
be restricted.

A lithium ion battery that is recyclable powers
the product you have purchased. Please call
1-800-8-BATTERY for information on how to recycle
this battery.

2 VQT5A15 (ENG)

Information for Your Safety

The socket outlet shall be installed near the equipment and shall be
easily accessible.

■

Product identification marking

Product Location

Digital camera Bottom

WARNING:

To reduce the risk of fire, electric shock or product damage,

• Do not expose this unit to rain, moisture, dripping or

splashing.

• Use only the recommended accessories.

• Do not remove covers.

• Do not repair this unit by yourself. Refer servicing to

qualified service personnel.

■

About the AC adaptor (supplied)

CAUTION!
To reduce the risk of fire, electric shock or product damage,

• Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

AC adaptor

This AC adaptor operates on AC between 110V and 240V.
But

• In the U.S.A. and Canada, the AC adaptor must be connected to
a 120V AC power supply only.

• When connecting to an AC supply outside of the U.S.A. or
Canada, use a plug adaptor to suit the AC outlet configuration.

(ENG) VQT5A15 3

■

About the battery pack

CAUTION

Battery pack (Lithium ion battery pack)

• Use the specified unit to recharge the battery pack.

• Do not use the battery pack with equipment other than the specified unit.

• Do not get dirt, sand, liquids, or other foreign matter on the terminals.

• Do not touch the plug terminals (+ and −) with metal objects.

• Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or
clothes, wash it off thoroughly with water.
If any electrolyte should come into contact with your eyes, never
rub the eyes. Rinse eyes thoroughly with water, and then consult a
doctor.

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace
only with the type recommended by the manufacturer.

• When disposing the batteries, please contact your local
authorities or dealer and ask for the correct method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a
long period of time with doors and windows closed.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above
60 °C (140 °F) or incinerate.

DMC-LF1

4 VQT5A15 (ENG)

FCC Note:

This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, follow the attached
installation instructions and use only shielded interface cables with
ferrite core when connecting to computer or peripheral devices.

Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
this equipment.

Declaration of Conformity

Trade Name: Panasonic
Model No.: DMC-LF1

Responsible Party: Panasonic Corporation of North America

Support Contact: Panasonic Consumer Marketing Company of North America

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

One Panasonic Way, Secaucus, NJ 07094

1-800-211-PANA (7262)

(ENG) VQT5A15 5

■

Cautions for Use

• Do not use any other USB connection cables except the supplied one or a
genuine Panasonic USB connection cable (DMW-USBC1: optional).

• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

Keep this unit as far away as possible from electromagnetic equipment
(such as microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this
unit may be disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.

• Electromagnetic wave radiation generated by microprocessors may adversely
affect this unit, disturbing the pictures and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn
this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded
pictures and/or sound may be adversely affected.

6 VQT5A15 (ENG)

Certification and Compliance

See Camera for the certification and compliance mark specific to
that device.

1 Select [Wi-Fi Setup] in the [Wi-Fi] menu
2 Press

to select [Approved Regulations], and press

[MENU/SET]

Contains FCC ID : VPYLBXN604

This transmitter must not be co-located or operated in conjunction
with any other antenna or transmitter.

This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines in Supplement C to OET65.
This equipment has very low levels of RF energy that are deemed
to comply without testing of specific absorption ratio (SAR).

(ENG) VQT5A15 7

Contents

Information for Your Safety .... 3

Before use ................................ 8

Standard accessories .............9

Names and Functions of

Main Parts ..............................10

Inserting and removing the

battery or SD memory card

(optional) ................................ 12

Charging the battery .............13

Setting the clock .................... 14

Setting the menu ...................15

Taking still pictures ............... 16

Recording motion pictures ... 18

Using the control ring ........... 19

Taking pictures with the composition

determined [Composition Guide]

Viewing your pictures ........... 22

Deleting pictures ...................23

What you can do with the

Wi-Fi function ......................... 24

Reading the Owner’s Manual

(PDF format) ........................... 26

Supplied software .................. 27

Specifications ........................ 29

Digital Camera Accessory System

Digital Camera Accessory Order Form

Limited Warranty

(ONLY FOR U.S.A. AND PUERTO RICO)

... 21

... 32

... 33

... 34

Before use

■

Camera handling

Keep the camera away from excessive vibration, force, or pressure.

●

The camera is not dust resistant, splash resistant, or waterproof.

●

Avoid using the camera in places with excessive dust or sand, or where
water can come into contact with the camera.

■

Condensation (When the lens, the LCD monitor or the viewfinder is fogged up)

Condensation may occur when the camera is exposed to sudden changes of

●

temperature or humidity. Avoid these conditions, which may make the lens,
the LCD monitor or the viewfinder dirty, cause mold, or damage the camera.
If condensation does occur, turn off the camera and wait about two hours before using it.

●

Once the camera adjusts to the surrounding temperature, the fogging will clear naturally.

8 VQT5A15 (ENG)

Standard accessories

Check that all the accessories are supplied before using the camera. Part
numbers are as of May 2013. These may be subject to change.

Battery pack

DMW-BCN10PP

• Charge the battery
before use.

Battery pack is indicated as
battery pack or battery in the text.

AC adaptor

VSK0768

Hand strap

VFC4297

• SD Memory Card, SDHC Memory Card and SDXC Memory Card are
indicated as card in the text.

• Cards are optional. You can record or play back pictures on the built-in
memory when you are not using a card.

• For information about optional accessories, refer to the “Digital Camera
Accessory System”.

• If any accessories are lost, customers should contact Panasonic’s parts
department at 1-800-833-9626 for further information about obtaining
replacement parts.

• Please dispose of all packaging appropriately.

• Keep small parts in a safe place out of the reach of children.

• The illustrations and screens in this manual may differ from the actual product.

USB connection cable

K1HY08YY0034

CD-ROM

• Software:
Use it to install the
software on your
PC.

CD-ROM

VFF1214

• Owner’s Manual for
advanced features

(ENG) VQT5A15 9

Names and Functions of Main Parts

12 3 4 5

11
12
13

14

15
16
17
18
19
20

21 22 23 25 26

31 32 33 34

10 VQT5A15 (ENG)

24

7
8
9

10

27
28

6

29

30

1 Camera [ON/OFF] button
2 Shutter button
3 Mode dial
4 Microphones
5 [Wi-Fi] antenna
6 Diopter adjustment dial
7 Strap eyelet
8 Control ring
9 NFC antenna

10 Lens barrel

11 Zoom lever
12 Flash
13 Self-timer indicator/

AF Assist Lamp
14 Lens
15 Viewfinder
16 LCD monitor
17 [LVF] button

• Use this to switch display
between viewfinder and LCD
monitor.

18 [Wi-Fi] button
19 Charging lamp/

Wi-Fi connection lamp
20 [Fn] button
21 Playback button
22 Control dial

23 Cursor button

• In this manual, the button that
is to be used is indicated by

.
24 [MENU/SET] button
25 [DISP.] button
26

[Q.MENU/

] / [ ] button
27 Motion picture button
28 Strap eyelet

• We recommend using the
supplied hand strap to avoid
dropping the camera.

29 [HDMI] socket
30 [AV OUT/DIGITAL] socket

• This socket is also used when
charging the battery.

31 Tripod mount

• Do not attach to a tripod with
a 5.5 mm (0.22 inch) or longer
screw. Doing so may damage
this unit.

32 Speaker
33 Card/Battery door
34 Release lever

(ENG) VQT5A15 11

Inserting and removing the battery or SD memory card (optional)

Make sure that the camera is turned off.

Slide the release lever ( ) to the
[OPEN] position and open the card/
battery door

Insert the battery and card, making sure
that their orientation is correct

• Battery: Insert the battery all the way firmly and
check that it is locked by lever (

• Card: Insert the card all the way firmly until it

clicks. Do not touch the terminals on the
back of the card.

Close the door

Slide the release lever to the [LOCK] position.

■

To remove

• To remove battery:

Move lever in direction of
arrow.

Lever

Always use genuine Panasonic batteries (DMW-BCN10PP).

●

If you use other batteries, we cannot guarantee the quality of this product.

●

Keep the Memory Card out of reach of children to prevent swallowing.

●

We recommend using a Panasonic card.

●

).

• To remove card:
Push the card until it clicks, then pull
the card out.

Press Pull out

12 VQT5A15 (ENG)

Charging the battery

• The battery that can be used with this unit is DMW-BCN10PP.

• The battery is not charged when the camera is shipped. Charge the

battery before use.

• Charge the battery with the AC adaptor (supplied) indoors (10 °C to

30 °C (50 °F to 86 °F)).

Make sure that the camera is turned off.

Insert the battery to this unit, and then connect this unit to
the AC adaptor (supplied) ( ) or a PC ( )

To the electrical outlet
USB connection cable (supplied)

■

Charging lamp ( )

On: Charging in progress (Red)
Off: Charging stops (Charging time: Approx. 160 min)

When using the AC adaptor (supplied), observe the following points as improper
connections may cause malfunctions.

Do not use any other USB connection cables except the supplied one or a

●

genuine Panasonic USB connection cable (DMW-USBC1: optional).
Do not use any other AC adaptors except the supplied one.

●

Do not use the AC adaptor (supplied) or the USB connection cable (supplied)

●

with other devices.

(ENG) VQT5A15 13

Setting the clock

The clock is not set when the camera is shipped.
Disconnect the unit from the AC adaptor (supplied).

Press the Camera [ON/OFF] button ( )

Press [MENU/SET] ( )

Press to select the items (year, month,
day, hour, minute, display order or time
display format), and press to set

• To cancel → Press [Q.MENU/ ] button.

Press [MENU/SET] to set

Confirm the setting and press [MENU/SET]

• To return to the previous screen, press [Q.MENU/ ] button.

■

Changing time settings

Select [Clock Set] from [Rec] or [Setup] menu, perform
Please see the next page on how to set the menu.

and .

14 VQT5A15 (ENG)

Setting the menu

Refer to the following procedures to operate the menus.

Example: Setting [AF Mode] from

to in the [Program AE] Mode

Press [MENU/SET] to display the menu

Switching to the [Rec] menu

Use cursor button to select [Rec] and press
[MENU/SET]

• Items can also be selected by turning the
control dial.

Press to select [AF Mode] and then
press [MENU/SET]

• Depending on the item, its setting may not
appear or it may be displayed in a different
way.

Press to select and then press
[MENU/SET] to set

Press [Q.MENU/ ] button several
times to close the menu

• In recording mode, the menu screen can
also be exited by pressing the shutter button
halfway.

(ENG) VQT5A15 15

Taking still pictures

Press the Camera [ON/OFF] button ( )

Set to the desired recording mode

Align the mode dial correctly to the mode that you
want to use.

Use the zoom lever ( ) to adjust the range of the picture to
be captured

Capture a wider area

(wide-angle)

Press the shutter button ( ) halfway to focus

Press the shutter button ( ) fully to take the picture

Enlarge the subject
(telephoto)

16 VQT5A15 (ENG)

■

Recording mode

Take pictures with automatic settings.

Take pictures with automatic shutter speed and aperture value
settings.

Determine aperture, then record pictures.

Determine shutter speed, then record pictures.

Determine aperture and shutter speed, then record pictures.

Record pictures using pre-registered settings.

Record panorama pictures.
Take pictures using Scene modes.

Take pictures by selecting your preferred picture effect.

■

Holding the camera

Flash AF Assist Lamp

Hand strap

To avoid camera shake, hold it with both hands keeping your arms close to

●

your body while standing with your feet slightly apart.
Do not touch the lens.

●

Do not block the flash or the lamp. Do not look at it from close range.

●

(ENG) VQT5A15 17

Recording motion pictures

You can record motion pictures with audio (stereo). Zoom can also be used
during recording.

Press the motion picture button ( ) to start
recording

Do not block the microphones ( ) when recording

●

motion pictures.
Immediately release the motion picture button after

●

pressing it.

Press the motion picture button ( ) again to
end recording

About recording time

●

• You can continuously record a motion picture in [MP4] for up to 29 minutes
59 seconds or approx. 4 GB. (Since recording in [MP4] with [FHD] creates
larger files, the recording time for such motion pictures will be shorter than
29 minutes 59 seconds.)

• If [Rec Quality] of [AVCHD] motion pictures is set to [FHD], you can
continuously record a motion picture for up to 29 minutes 59 seconds.

If the surrounding temperature is high, or a motion picture is recorded

●

continuously,
through to protect the camera.

You can record a motion picture to the built-in memory only in [MP4] using the

●

[VGA] setting.

is displayed and recording may be stopped halfway

18 VQT5A15 (ENG)

Using the control ring

Using the control ring allows you to perform frequently used operations and
settings such as Step zoom and ISO Sensitivity directly.

Turn the control ring ( )

• You can also perform operations with the
control dial. (Some operations may differ under
certain recording conditions such as [Manual
Exposure] mode.)

(when in [Intelligent Auto]

))

Mode (

Items that can be set by the control ring vary depending on recording modes.
Following are the pre-assigned settings.

Step zoom

ISO Sensitivity

Aperture adjustment

Shutter speed adjustment

Aperture adjustment

You can adjust the shutter speed with the control dial on the
back.

Picture effects change

(ENG) VQT5A15 19

Using the control ring

Using Quick menu

Using the Quick menu, you can change camera settings with the control ring.

Press [Q.MENU/ ] button ( )

Press to select menu items

Turn the control ring to change the setting

• You can also change settings with the control dial.

Press [MENU/SET] ( )

20 VQT5A15 (ENG)

Taking pictures with the composition determined [Composition Guide]

By using the viewfinder or LCD monitor to consider the placement of your
subject (the composition), you can take more impressive still pictures.

Press [Fn] button ( )

• [Fn Button Set] is set to [Composition
Guide] at the time of purchase. If another
function has been set, select [Composition
Guide] from the [Setup] menu.

Press to select the guideline to display and press
[MENU/SET]

• To turn off guideline display, select [OFF].

• If the guideline allows horizontal flipping, use

■

Guidelines (Examples)

[Rule of Thirds Offset] [Diagonal lines] [Tunnel]

[Radiation] [S-shape]

to flip.

(ENG) VQT5A15 21

Viewing your pictures

When a card is in the camera, pictures are played back from the card, and
without a card, pictures are played back from the built-in memory.

Press the Playback button ( )

• By holding down the Playback button while
the camera is off, you can turn the camera
on in Playback Mode.

Press to select a picture to be displayed

• When the buttons are held down, the pictures can be scrolled quickly
forward or backward.

• Pictures can also be selected with the control dial.

Folder/File number

22 VQT5A15 (ENG)

Picture number/Total
pictures

Viewing motion pictures

Select a picture with the motion picture icon, and press

Motion picture icon

(differs depending on

the recording mode

and picture quality

■

Operations during motion picture playback

: Pause/play
: Stop
: Fast rewind (2 steps)/Single-frame rewind (while paused)

: Fast forward (2 steps)/Single-frame forward (while paused)
[MENU/SET]: Capturing still pictures from motion pictures (while paused)
Control dial: Fast rewind/Fast forward (same as
Zoom lever: Volume adjustment

setting)

Motion picture
recording time

)

Deleting pictures

Pictures will be deleted from the card if the card is inserted, or from the built-in
memory if the card is not inserted. (Deleted pictures cannot be recovered.)

Press [ ] button ( ) to delete the
displayed picture

Press to select [Yes] and then
press [MENU/SET] ( )

(ENG) VQT5A15 23

What you can do with the Wi-Fi function

For details about Wi-Fi connections, please read “Wi-Fi connection guide”.

■

Using a smartphone as a camera remote control

By installing the “Panasonic Image App” on your smartphone, you can operate
the camera remotely and use the smartphone to record and play back.

• By using the NFC function, you can hold your smartphone close to the
camera and easily make a Wi-Fi connection without making troublesome
Wi-Fi settings.

■

Using WEB services

Through LUMIX CLUB, you can send still pictures and motion pictures to
social networking services, etc. By selecting the setting to automatically
transfer still pictures and motion pictures to [Cloud Sync. Service], you
can receive the transferred still pictures and motion pictures on a PC or a
smartphone.

WEB services

LUMIX CLUB

Wireless access point

Cloud synchronization
services

24 VQT5A15 (ENG)

■

Transferring pictures automatically [Smart Transfer]

During battery charging, recorded pictures are transferred automatically to
PC, AV equipment and cloud folders.

■

Sending pictures to Wi-Fi compatible equipment

You can select pictures on your camera and transfer them to a TV, printer, AV
equipment, PC, etc.
Also, during recording, you can transfer still pictures as they are recorded
(except for transferring to a printer).

■

Panasonic Image App

The “Panasonic Image App” is an application provided by Panasonic.
For details, refer to “Wi-Fi connection guide”.

■

LUMIX CLUB

If you register this unit to the “LUMIX CLUB”, you can synchronize images
between the devices you are using, or transfer these images to WEB
services.
For details, refer to the “LUMIX CLUB” site.
http://lumixclub.panasonic.net/eng/c/

(ENG) VQT5A15 25

Reading the Owner’s Manual (PDF format)

More detailed instructions on the operation of this camera are contained in
“Owner’s Manual for advanced features (PDF format)” in the supplied CD-ROM.
Install it on your PC to read it.

■

For Windows

Turn the PC on and insert the CD-ROM containing the
Owner’s Manual (supplied)

Select the desired language and
then click [Owner’s Manual] to
install

Double-click the “Owner’s Manual”
shortcut icon on the desktop

■

When the Owner’s Manual (PDF format) will not open

You will need Adobe Acrobat Reader 5.0 or later, or Adobe Reader 7.0 or later
to browse or print the Owner’s Manual (PDF format).

• You can download and install a version of Adobe Reader that you can use
with your OS from the following website.
http://get.adobe.com/reader/otherversions/

26 VQT5A15 (ENG)

Supplied software

The supplied CD-ROM contains the following software.
Install the software on your computer to use.

PHOTOfunSTUDIO

9.2 AE

SILKYPIX
Developer Studio

LoiLoScope
(30-day full-trial
version)

For details about operating environment and usage, please read “Owner’s
Manual for advanced features” (PDF format) or the manuals for each software.

PHOTOfunSTUDIO / LoiLoScope are not compatible with Mac.

●

Pictures can be captured to a PC, and can be viewed,
organized, printed, etc. Also, still pictures can be
corrected and motion pictures can be edited.

• Compatible OS: Windows 8 / 7 / Vista / XP

This software develops and edits RAW file pictures.
Edited pictures can be saved in a file format such as
JPEG or TIFF that can be displayed on a PC, etc.
For details on how to use the SILKYPIX Developer
Studio, refer to the “Help” or the Ichikawa Soft
Laboratory’s support website:
http://www.isl.co.jp/SILKYPIX/english/p/support/

• Compatible OS: Windows 8 / 7 / Vista / XP
Mac OS X v10.4 / v10.5 / v10.6 /
v10.7 / v10.8

You can edit motion pictures easily. This will only install a
shortcut to the trial version download site.
For details about using LoiLoScope, please download
and see the manual from the following site.
http://loilo.tv/product/20/

• Compatible OS: Windows 8 / 7 / Vista / XP

(ENG) VQT5A15 27

Supplied software

Installing supplied software

Preparations:

• Check your PC’s specifications and operating environment for each software.

• Before inserting the CD-ROM (supplied), close all running applications.

■

Windows

Insert the CD-ROM with the supplied software

• The installation menu runs.

Click [Recommended Installation]

• Continue the installation procedure following the instructions displayed on
the screen.

■

Mac (SILKYPIX Developer Studio)

Insert the CD-ROM with the supplied software

Double-click the recognized disc to open

Double-click the [SILKYPIX] folder to open

Double-click an icon in the folder

• Continue the installation procedure following the instructions displayed on
the screen.

28 VQT5A15 (ENG)

Specifications

Digital Camera: Information for your safety

Power Source DC 5 V

Power
Consumption

Camera effective
pixels

Image sensor 1/1.7″ MOS sensor,

Lens Optical 7.1x zoom

Image Stabilizer Optical method

Focus range

Normal 50 cm (1.6 feet) (Max. Wide) /

Macro /
iA mode /
Motion picture /
MF

Scene Mode The focus ranges listed above may vary depending on

Shutter system Electronic shutter + Mechanical shutter
Shutter speed 250 seconds to 1/4000th of a second

Minimum
Illumination

1.7 W (When recording with LCD Monitor)

1.1 W (When playing back with LCD Monitor)
12,100,000 pixels

total pixel number 12,800,000 pixels
Primary color filter

f=6.0 mm to 42.8 mm
(35 mm film camera equivalent: 28 mm to 200 mm) /
F2.0 (Max. Wide) to F5.9 (Max. Tele)

80 cm (2.6 feet) (Max. Tele) to
3 cm (0.098 feet) (Max. Wide) /

80 cm (2.6 feet) (Max. Tele) to

the selected Scene Mode.

[Starry Sky] Mode:
15 seconds, 30 seconds, 60 seconds

Approx. 6 lx (when i-Low light is used, the shutter
speed is 1/30th of a second)

(ENG) VQT5A15 29

Specifications

Exposure (AE) Program AE (P) / Aperture-priority AE (A) /

Metering Mode [Multi Metering] / [Center Weighted] / [Spot]
LCD monitor 3.0″ TFT LCD (3:2) (Approx. 921,600 dots)
Viewfinder Color LCD Viewfinder (Approx. 200,000 dots)

Microphones Stereo
Speaker Monaural
Recording media Built-in Memory (Approx. 87 MB)

Recording file
format

Still picture RAW / JPEG (based on Design rule for Camera File

Motion pictures AVCHD / MP4

Audio compression
format

Interface

Digital USB 2.0 (High Speed)
Analog video NTSC Composite
Audio Audio line output (Monaural)

Terminal HDMI: MicroHDMI TypeD

Dimensions Approx. 102.5 mm (W) x 62.1 mm (H) x 27.9 mm (D)

Shutter-priority AE (S) / Manual exposure (M)

(with diopter adjustment -4 to +4 diopter)

SD Memory Card / SDHC Memory Card /
SDXC Memory Card

system, based on Exif 2.3 standard /
DPOF corresponding) / MPO

®

AVCHD: Dolby
MP4: AAC (2 ch)

AV OUT/DIGITAL: Dedicated jack (8 pin)

[4.0″ (W) x 2.4″ (H) x 1.1″ (D)]
(excluding the projection part)

Digital (2 ch)

30 VQT5A15 (ENG)

Mass (Weight) With card and battery: Approx. 192 (0.42 lb)

Excluding card and battery: Approx. 170

Operating

0 °C to 40 °C (32 °F to 104 °F)

temperature
Operating humidity 10%RH to 80%RH
Language select [ENGLISH] / [ESPAÑOL]

Wi-Fi

Compliance
standard

Frequency range
used

IEEE 802.11b/g/n
(standard wireless LAN protocol)

2412 MHz to 2462 MHz (1ch to 11ch)

(central frequency)
Encryption method Wi-Fi compliant WPA™ / WPA2™
Access method Infrastructure mode

NFC

Compliance

ISO / IEC 18092 NFC-F (Passive Mode)

standard

AC adaptor
(Panasonic VSK0768): Information for your safety

Input ~ 110 V to 240 V, 50/60 Hz, 0.2 A

Output

5 V, 800 mA

Battery pack (lithium-ion)
(Panasonic DMW-BCN10PP): Information for your safety

Voltage / capacity 3.7 V / 950 mAh

Specifications are subject to change without notice.

(0.37 lb)

(ENG) VQT5A15 31

Digital Camera Accessory System

Description Accessory#

Battery pack DMW-BCN10
USB connection cable DMW-USBC1
AV cable DMW-AVC1

Product numbers are correct as of May 2013. These may be subject to

●

change.
Accessories and/or model numbers may vary between countries.

●

Consult your local dealer.

32 VQT5A15 (ENG)

Digital Camera Accessory Order Form

Please photocopy this form when placing an order.

1. Digital Camera Model #

2. Items Ordered
Accessory # Description Price Each Quantity Total Price

Shipping & Handling $6.95

Your State & Local Sales Tax

3. Method of payment (check one)

American Express
VISA Credit Card #
MasterCard Expiration Date
Discover Customer Signature

(Please do not send cash)

4. Shipping information (UPS delivery requires complete street address)

Ship To:
Mr.
Mrs.
Ms.

First Last Phone#:

Street Address Night

City State Zip

TO OBTAIN ANY OF OUR DIGITAL CAMERA ACCESSORIES YOU CAN DO ANY OF

VISIT YOUR LOCAL PANASONIC DEALER

CALL PANASONIC’S ACCESSORY ORDER LINE AT 1-800-332-5368

MAIL THIS ORDER TO: PANASONIC NATIONAL PARTS CENTER

THE FOLLOWING:

OR

[6 AM-6 PM M-F, PACIFIC TIME]

20421 84th Ave S., Kent, WA 98032

OR

Subtotal

Total

( )

Day

( )

(ENG) VQT5A15 33

Limited Warranty (ONLY FOR U.S.A. AND PUERTO RICO)

Panasonic Consumer Marketing Company of North America,
Division of Panasonic Corporation of North America

One Panasonic Way, Secaucus, New Jersey 07094

Panasonic Products Limited Warranty

Limited Warranty Coverage (For USA and Puerto Rico Only)

If your product does not work properly because of a defect in materials or
workmanship, Panasonic Consumer Marketing Company of North America
(referred to as “the warrantor”) will, for the length of the period indicated on the
chart below, which starts with the date of original purchase (“warranty period”),
at its option either (a) repair your product with new or refurbished parts, (b)
replace it with a new or a refurbished equivalent value product, or (c) refund
your purchase price. The decision to repair, replace or refund will be made by
the warrantor.

Product or Part Name Parts Labor

Digital Camera 1 Year 1 Year
All included Accessories

(Except Non-Rechargeable Batteries)
Only Non-Rechargeable Batteries 10 Days Not Applicable

During the “Labor” warranty period there will be no charge for labor. During the
“Parts” warranty period, there will be no charge for parts. This Limited Warranty
excludes both parts and labor for non-rechargeable batteries, antennas, and
cosmetic parts (cabinet). This warranty only applies to products purchased and
serviced in the United States or Puerto Rico. This warranty is extended only to
the original purchaser of a new product which was not sold “as is”.

90 Days Not Applicable

34 VQT5A15 (ENG)

Mail-In Service

For assistance in the U.S.A. and Puerto Rico in obtaining repairs, please ship
the product prepaid to:

Panasonic Exchange Center
4900 George McVay Drive
Suite B
McAllen, TX 78503
[e-mail]

Online Repair Request

To submit a new repair request and for quick repair status visit our Web Site at
www.panasonic.com/repair.

When shipping the unit, carefully pack, include all supplied accessories listed in
the Owner’s Manual, and send it prepaid, adequately insured and packed well in
a carton box. When shipping Lithium Ion batteries please visit our Web Site at
www.panasonic.com/BatteryHandling as Panasonic is committed to providing
the most up to date information. Include a letter detailing the complaint, a return
address and provide a daytime phone number where you can be reached. A
valid registered receipt is required under the Limited Warranty.

IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE
PURCHASER WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF
OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID AND
PLACE OF PURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR
OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF PURCHASE.

Limited Warranty Limits And Exclusions

This warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic
damage. The warranty ALSO DOES NOT COVER damages which occurred
in shipment, or failures which are caused by products not supplied by the
warrantor, or failures which result from accidents, misuse, abuse, neglect,
mishandling, misapplication, alteration, faulty installation, set-up adjustments,
misadjustment of consumer controls, improper maintenance, power line surge,
lightning damage, modification, introduction of sand, humidity or liquids,
commercial use such as hotel, office, restaurant, or other business or rental
use of the product, or service by anyone other than a Factory Service Center or
other Authorized Servicer, or damage that is attributable to acts of God.

(ENG) VQT5A15 35

THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING
OUT OF ANY BREACH OF THIS WARRANTY.

(As examples, this excludes damages for lost time, travel to and from the
servicer, loss of or damage to media or images, data or other memory or
recorded content. The items listed are not exclusive, but for illustration only.)

ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY
OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED
WARRANTY.

Some states do not allow the exclusion or limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts, so
the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other rights
which vary from state to state. If a problem with this product develops during
or after the warranty period, you may contact your dealer or Service Center.
If the problem is not handled to your satisfaction, then write to the warrantor’s
Consumer Affairs Department at the addresses listed for the warrantor.

PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.

36 VQT5A15 (ENG)

Customer Services Directory (United States and Puerto Rico)

Obtain Product Information and Operating Assistance; locate your
nearest Dealer or Service Center; purchase Parts and Accessories; or
make Customer Service and Literature requests by visiting our Web
Site at:
http://www.panasonic.com/help
or, contact us via the web at:
http://www.panasonic.com/contactinfo

You may also contact us directly at:
1-800-211-PANA (7262)
Monday-Friday 9am-9pm, Saturday-Sunday 10am-7pm EST

For hearing or speech impaired TTY users, TTY: 1-877-833-8855

Accessory Purchases (United States and Puerto Rico)

Purchase Parts, Accessories and Instruction Books online for all Panasonic
Products by visiting our Web Site at:
http://www.pstc.panasonic.com
Or, send your request by E-mail to:
[e-mail]
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday-Friday 9am-9pm EST)
Panasonic National Parts Center
20421 84th Ave S., Kent, WA 98032
(We accept Visa, MasterCard, Discover Card, American Express)

For hearing or speech impaired TTY users, TTY: 1-866-605-1277

As of October 2012

(ENG) VQT5A15 37

• SDXC Logo is a trademark of SD-3C, LLC.

• HDMI, the HDMI Logo, and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.

• HDAVI Control™ is a trademark of Panasonic Corporation.

• “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation
and Sony Corporation.

• Manufactured under license from Dolby Laboratories. Dolby and the double-D
symbol are trademarks of Dolby Laboratories.

• Windows and Windows Vista are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries.

• Mac and Mac OS are trademarks of Apple Inc., registered in the U.S. and
other countries.

• QuickTime and the QuickTime logo are trademarks or registered trademarks
of Apple Inc., used under license therefrom.

• App Store is a service mark of Apple Inc.

• The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.

• The Wi-Fi Protected Setup Mark is a mark of the Wi-Fi Alliance.

• “Wi-Fi”, “Wi-Fi Protected Setup”, “Wi-Fi Direct”, “WPA” and “WPA2” are marks
or registered marks of the Wi-Fi Alliance.

• DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks,
or certification marks of the Digital Living Network Alliance.

• This product uses “DynaFont” from DynaComware Corporation. DynaFont is a
registered trademark of DynaComware Taiwan Inc.

• Other names, company names, and product names mentioned in these
instructions are trademarks or registered trademarks of the companies
concerned.

38 VQT5A15 (ENG)

-If you see this symbol-

Information on Disposal in other Countries outside
the European Union

This symbol is only valid in the European Union. If you
wish to discard this product, please contact your local
authorities or dealer and ask for the correct method of
disposal.

Panasonic Consumer Marketing Company of North America,
Division of Panasonic Corporation of North America

One Panasonic Way, Secaucus, NJ 07094
© Panasonic Corporation 2013

Printed in Japan
