PANASONIC DMCFP1, DMCFP2 User Manual

Operating Instructions

for advanced features

Digital Camera

Model No. DMC-FP2

DMC-FP1

Before connecting, operating or adjusting this product,

please read the instructions completely.

VQT2M98-1

Quick start guide

The battery is not charged when the camera is shipped. Charge the battery and set the clock before use.

When you do not use the card (optional), you can record or play back pictures on the built-in memory (→11).

Do not touch the lens.

Charge the battery

Insert the battery and the card

Open the lens cover

Lens cover

Playback button

[MODE] button

2 VQT2M98

button

[MENU/SET]

Select the desired Recording Mode

■

To use settings automatically selected by the camera

Press the button.

■

To select the Recording Mode manually

Press the [MODE] button. Press ▲▼ to select the Recording Mode, and

then press [MENU/SET].

Press the shutter button and take pictures

Press halfway

(press lightly to focus)

■

To play back the pictures

Press the Playback button. Select the picture you want to

view.

Press fully

(press the button all the

way to record)

Previous Next

Contents

Before use

Before use .............................................. 5

Read first .......................................................5

To prevent damage, malfunctions, and faults

.....5

Standard Accessories ........................... 6

Names of parts....................................... 7

Cursor button ................................................7

Preparations

Charging the battery .............................8

Guidelines for number of recordable pictures

and recording time ........................................9

Inserting and removing the card

(optional)/the battery ........................... 10

Picture save destination

(cards and built-in memory) ........................11

Remaining battery and memory capacity .... 11

Setting the Clock ................................. 12

Setting the menu .................................14

Menu type ...................................................15

Using Quick menu .......................................16

Using the [SETUP] menu ................. 17

[CLOCK SET]/ [WORLD TIME] [TRAVEL DATE]/ [BEEP]

[VOLUME]..............................................17

[LCD MODE]/ [DISPLAY SIZE]/

[FOCUS ICON] ......................................18

[AUTO POWER OFF]

[AUTO REVIEW] ....................................19

[RESET]/ [USB MODE] .....................20

[VIDEO OUT]/ [TV ASPECT]

[VERSION DISP.]/ [FORMAT] ...........21

[LANGUAGE]/ [DEMO MODE] .........22

Basics

Sequence of Recording ......................23

Convenient ways to turn the power on ........24

Taking pictures with automatic settings [INTELLIGENT AUTO] Mode

Taking pictures with your own settings [NORMAL PICTURE] Mode

Align focus for desired composition ............28

Direction detection function .........................28

Taking pictures with zoom .................. 29

Enlarging further [DIGITAL ZOOM] .......30

Viewing your pictures [NORMAL PLAY] ...

Deleting pictures .................................32

To delete multiple (up to 50) or all pictures

................25

.................. 27

...32

VQT2M98 3

Contents (Continued)

Application (Record)

Changing recording information

display .................................................. 33

Taking pictures with the self-timer .... 34

Taking pictures with flash ................... 35

Taking close-up pictures .................... 37

Taking pictures at even closer range

[MACRO ZOOM].....................................38

Taking pictures with exposure

compensation ...................................... 39

Taking pictures according to the scene [SCENE MODE]

[PORTRAIT]/ [SOFT SKIN]/

[TRANSFORM] ......................................41

[SELF PORTRAIT]/ [SCENERY]

[SPORTS]/ [NIGHT PORTRAIT] .......42

[NIGHT SCENERY]/ [FOOD]/

[PARTY]/ [CANDLE LIGHT] ..............43

[BABY]/ [PET]/ [SUNSET] ............44

[HIGH SENS.]/ [HI-SPEED BURST]

[FLASH BURST]/ [STARRY SKY] .....46

[FIREWORKS]/ [BEACH]/ [SNOW]/ [AERIAL PHOTO]/ [FILM GRAIN]

[PHOTO FRAME] .................................. 47

Registering commonly used scenes [MY SCENE MODE]

Taking motion pictures

[MOTION PICTURE] Mode ............. 49

[REC QUALITY] .....................................50

Useful features for travel .................... 51

[TRAVEL DATE] ..................................... 51

[WORLD TIME] ......................................52

Using the [REC] menu ......................... 53

[PICTURE SIZE] .................................... 53

[SENSITIVITY] ......................................54

[WHITE BALANCE] ...............................55

[AF MODE] ............................................56

[BURST]/ [DIGITAL ZOOM] ..............57

[COLOR MODE]/ [STABILIZER] ......58

[AF ASSIST LAMP]/ [RED-EYE REMOVAL]/ [CLOCK SET]

Entering Text ........................................ 60

.................. 40

..45

.......................... 48

...59

Application (View)

Viewing as list (Multi Playback/Calendar Playback) .. 61

Watching motion pictures ..................62

Different playback methods

(Playback Mode) .................................. 63

[SLIDE SHOW] ......................................64

[CATEGORY PLAY]/

[FAVORITE PLAY] .................................66

Using the [PLAYBACK] menu ............ 67

[CALENDAR]/ [TEXT STAMP] ..........67

[RESIZE] ................................................68

[CROPPING]..........................................69

[ROTATE DISP.]/ [FAVORITE] ...........70

[PRINT SET] .......................................... 71

[PROTECT]............................................72

[COPY]...................................................73

Connecting with other devices

Using with your PC .............................. 74

Printing ................................................. 76

Printing multiple pictures ............................. 77

Print with date and text ................................77

Making print settings on camera .................78

Viewing on TV screen .........................79

Others

List of LCD monitor displays .............. 80

In recording .................................................80

In playback .................................................. 81

Message displays ................................ 82

Q&A Troubleshooting ........................ 84

Usage cautions and notes .................. 90

Recording picture/time capacity ........ 92

4 VQT2M98

Before use

Read first

■

Fully peel off the strip of tape from the lens cover before using the camera.

Strip of tape

■

Do a test shot first!

Check first to see if you can take pictures and record sounds successfully.

■

We will not compensate for failed/ lost recording or for direct/indirect damage.

Panasonic will not provide compensation even if damage is caused by faults with camera or card.

■

Certain pictures cannot be played back.

• Pictures edited on a computer.

• Pictures taken or edited on a different camera. (Pictures taken or edited on this camera may also not be able to be played back on other cameras.)

■

Software on the CD-ROM supplied.

The following actions are prohibited:

• Making duplicates (copying) for sale or rent.

• Copying onto networks.

To prevent damage,

malfunctions, and faults

■

Avoid shocks, vibration, and pressure.

• Avoid exposing the camera to strong vibration or shock; e.g. dropping or hitting the camera, or sitting down with the camera in your pocket. (Attach hand strap to avoid dropping camera. Hanging any items other than the supplied hand strap from the camera can apply pressure against it.)

• Do not press the lens or the LCD monitor.

■

Do not get the camera wet or insert foreign objects. This camera is not waterproof.

• Do not expose the camera to water, rain, or seawater. (If camera gets wet, wipe with a soft, dry cloth. Wring cloth thoroughly first if wet with seawater, etc.)

• Avoid exposing lens and socket to dust or sand, and do not allow liquids to leak into gaps around buttons.

• When opening and closing the lens cover, make sure that liquid or foreign objects such as sand do not enter.

■

Avoid condensation caused by sudden changes in temperature and humidity.

• When moving between places of different temperature or humidity, place camera into a plastic bag and allow to adjust to conditions before use.

• If the lens clouds up, switch off the power and leave for about two hours to allow camera to adjust to conditions.

• If the LCD monitor clouds up, wipe with a soft, dry cloth.

LCD monitor characteristics

Extremely high precision technology is employed to produce the LCD monitor screen. However there may be some dark or bright spots (red, blue or green) on the screen. This is not a malfunction. The LCD monitor screen has more than 99.99% effective pixels with a mere 0.01% of the pixels inactive or always lit. The spots will not be recorded on pictures on the builtin memory or a card.

VQT2M98 5

Before use (Continued)

To prevent damage,

malfunctions, and faults

■

Lens

• Do not leave the lens exposed to direct sunlight.

■

When using a tripod or unipod

• Do not apply excessive force or tighten screws when they are crooked. (This may damage the camera, screw hole, or label.)

• Ensure that the tripod is stable. (Refer to the tripod instructions.)

■

When transporting

Switch off power. (To prevent the camera from being turned on accidentally, make sure not to open the lens cover when putting the camera away or removing it from the case.)

Please also refer to ‘Usage cautions and notes’ (→90).

Standard Accessories

Check that all the accessories are included before using the camera.

The accessories and their shape

●

will differ depending on the country or area where the camera was purchased. For details on the accessories, refer to Basic Operating Instructions. Battery Pack is indicated as battery

●

pack or battery in the text. Battery Charger is indicated as

●

battery charger or charger in the text. Please dispose of all packaging

●

appropriately.

■

Optional accessories

• Cards are optional. You can record or play back pictures on the built-in memory when you are not using a card.

• If any accessories are lost, customers in the USA and Puerto Rico should contact Panasonic’s parts department at 1-800-833-9626 and customers in Canada should contact 1-800-99-LUMIX (1-800-995-8649) for further information about obtaining replacement parts.

The following do not indicate mechanical problems.

• The camera rattles when shaken. (This is the sound of the lens moving.)

• The camera clicks when turned on or off, or when switched between recording and playback. (This is also the sound of the lens moving.)

• You feel vibration when zooming in or out. (This is from the lens moving.)

• The lens makes a noise when you are recording. (This is the sound of iris adjustment in response to changes in ambient light.) At this time, pictures displayed on the LCD monitor change rapidly, but the recording is not affected.

6 VQT2M98

Names of parts

Cursor button

Hand strap eyelet

Zoom lever (→29)

Shutter button (→25, 49)

Flash (→35)

Lens (→6)

Self-timer indicator (→34)/ AF Assist Lamp

Lens cover (→23)

button(→25)

LCD monitor (→33, 80)

[MODE] button (→27)

Cursor button

[DISPLAY] button

(→33)

[Q.MENU] (→16)/Delete button (→32)

[AV OUT/DIGITAL] socket

(→74, 76, 79)

[DC IN] socket (→74, 76)

• Always use a genuine Panasonic AC adaptor (optional).

(→59)

Release lever (→10)

Tripod receptacle

Card/Battery door

(→10)

Microphone(→49)

Power button (→24)

Playback button (

→31

Speaker (→17, 62)

We recommend

①

using the supplied hand strap to avoid dropping the camera.

②

If you attach a hand strap other

●

than the one supplied, it may become impossible to open the lid of the [AV OUT/DIGITAL] socket or [DC IN] socket.

)

[MENU/SET]

(menu display/set/finish) (→14)

Left cursor button (◄)

• Self-timer (→34)

Down cursor button (▼)

• Macro mode (→37)

In this manual, the button that is used is shaded or indicated by▲▼◄►.

●

The illustrations and screens in this manual may differ from the actual product. This

●

manual uses the screens from DMC-FP1 as examples in its explanations.

Up cursor button (▲)

• Exposure compensation (→39)

Right cursor button (►)

• Flash (→35)

VQT2M98 7

Charging the battery

■

About batteries that you can use with this unit

It has been found that counterfeit battery packs which look very similar to the genuine products are made available to purchase in some markets. Some of these battery packs are not adequately protected with internal protection to meet the requirements of appropriate safety standards. There is a possibility that these battery packs may lead to fire or explosion. Please be advised that we are not liable for any accident or failure occurring as a result of use of a counterfeit battery pack. To ensure that safe products are used we recommend that a genuine Panasonic battery pack is used.

• Use the dedicated charger and battery.

• The camera has a function for distinguishing batteries which can be used

safely. The dedicated battery supports this function. The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used). Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.

Insert the battery terminals and attach the battery to the charger

Ensure [LUMIX] faces outwards.

Connect the charger to the electrical outlet

Plug-in type

●

Battery (model- specific)

Charger (model - specific)

Detach the battery after charging is completed

8 VQT2M98

Inlet type

●

• The AC

cable does not fit entirely into the AC input terminal. A gap will remain.

Charging light ([CHARGE])

On: Charging in progress

(approx. 110 min. if fully depleted)

Off: Charging complete

If light is flashing:

• Charging may take longer than normal if battery temperature is too high or too low (charging may not be completed).

• Battery/charger connector is dirty. Clean with a dry cloth.

Always charge before first use! (not sold pre-charged)

Guidelines for number of recordable pictures and recording time

Figures may be reduced if flash, zoom, or [LCD MODE] are used frequently; or in colder climates.

Number of recordable pictures

Recording time Approx. 150 min

Recording conditions by CIPA standard

●

• CIPA is an abbreviation of [Camera & Imaging Products Association].

• [NORMAL PICTURE] Mode.

• Temperature: (23°C (73.4 °F))/Humidity: 50% when LCD monitor is on.

• Using a Panasonic SD Memory Card (32 MB).

• Using the supplied battery.

• Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabilizer function is set to [AUTO].)

Number reduced if intervals are longer – e.g. to approx. one quarter (75 pictures) for 2-minute intervals under the above conditions.

Playback time Approx. 260 min

The number of recordable pictures or available recording time may vary slightly according to battery and usage conditions.

The time required for charging varies depending on conditions of battery usage. Charging takes

●

longer at high or low temperatures and when the battery has not been used in some time. Battery will be warm during charging and for some time thereafter.

●

Battery will run out if not used for long periods of time, even after being charged.

●

Charge the battery with the charger indoors (10 °C - 35 °C (50 °F - 95 °F)).

●

Do not leave any metal items (such as clips) near the contact areas of the power plug.

●

Otherwise, a fire and/or electric shocks may be caused by short-circuiting or resulting heat generated. Frequently charging battery is not recommended.

●

(Frequently charging battery reduces maximum usage time and can cause battery to expand.) Do not disassemble or modify the charger.

●

If available battery power is significantly reduced, battery is reaching end of lifespan. Please

●

purchase a new battery. The battery charger is in the standby condition when the AC power is supplied.

●

The primary circuit is always “live” as long as the battery charger is connected to an electrical outlet. When charging:

●

• Remove any dirt on connectors of charger and battery with dry cloth.

• Keep at least 1 m (3.28 feet) away from AM radio (may cause radio interference).

• Noises may be emitted from inside of charger, but this is not a fault.

• Remove charger from wall socket after charging (up to 0.1 W consumed if left in place).

Do not use a damaged or dented battery (especially connectors), e.g. by dropping (can cause

●

faults).

Approx. 300 pictures

∗

By CIPA standard

• Recording once every 30 seconds with full flash every second recording.

• Rotating the zoom lever from Tele to Wide or vice versa in every recording.

• Turning the camera off every 10 recordings and leaving it until the temperature of the battery decreases.

∗

The number of recordable pictures

decreases in Auto Power LCD Mode and Power LCD Mode.

VQT2M98 9

nserting and removing the card (optional)/

the battery

Turn the camera off and slide the release lever to [OPEN] before opening the lid

Release lever

Lever

[OPEN] [LOCK]

Do not touch terminal

Charged battery (check orientation) Card (check orientation: terminals

■

To remove

• To remove battery: • To remove card:

move lever in direction of arrow.

face LCD)

Lever

Completely insert battery and card

• Battery: Insert until the lever locks into place.

• Card: Insert until it clicks.

Close lid

Slide to the [LOCK] position.

press down in center.

Always use genuine Panasonic batteries.

●

If you use other batteries, we cannot guarantee the quality of this

●

product. Remove battery from camera after use.

●

• Store the battery in battery case (supplied).

To remove the card or battery, turn the camera off and wait until

●

the LCD monitor display is completely blank. (Failure to wait may cause the camera to malfunction and may damage the card or recorded data.) Keep the Memory Card out of reach of children to prevent swallowing.

●

The unusable battery should be discarded in accordance with battery recycling laws.

●

Call the RBRC hotline at 1-800-822-8837 for information.

10 VQT2M98

Picture save destination (cards and built-in memory)

Pictures will be saved to a card if one is inserted, or to the built-in memory if not.

■

Built-in memory (approx. 40 MB) Pictures may be copied between cards and the built-in memory (→73).

●

The access time for the built-in memory may be longer than the access time for a card.

●

[QVGA] in [REC QUALITY] can only be available to record motion pictures in the built-in memory.

●

■

Compatible memory cards (optional)

The following SD standard-based cards (Panasonic brand recommended)

Type of Card Capacity Notes

SD memory cards

SDHC memory cards

SDXC memory cards

Please reformat the card with this camera if it has already been formatted with a

●

computer or another device. (→21) If the write-protect switch is set to ‘LOCK’, the card cannot be used to record or delete

●

pictures, and it cannot be formatted. It is recommended that you copy important pictures to your computer (as

●

electromagnetic waves, static electricity, or faults may cause data to be damaged). Latest information:

●

http://panasonic.jp/support/global/cs/dsc/ (This Site is English only.)

8 MB – 2 GB • Can be used with devices compatible with

4 GB – 32 GB

48 GB – 64 GB

the respective formats.

• Before using SDXC memory cards, check that your computer and other devices support this type of card. http://panasonic.net/avc/sdcard/information/SDXC.html

• Cards in capacities not listed at left are not supported.

Switch (LOCK)

Remaining battery and memory capacity

Remaining battery (only when using battery)

(flashes red)

If the battery mark flashes red, recharge or replace battery. (→8)

Displayed when no card is inserted (pictures will be saved to built-in

Pictures remaining (→92)

When in operation

(Card) or (Built-in memory) are illuminated red. This means that an operation is in progress, such as the recording, reading, deleting, or formatting of pictures. Do not turn off the power or remove the battery, card, or AC adaptor (optional) (this may cause damage to or loss of data). Do not subject the camera to vibrations, impact, or static electricity. Should any of these cause camera operation to be terminated, attempt to perform the operation again.

memory)

VQT2M98 11

Setting the Clock

Do not touch the lens.

Lens cover

■

To set local time at travel destination

[WORLD TIME] (→52)

Open the lens cover

The power is turned on. If the language select screen is not displayed, proceed to step

Press [MENU/SET] while the message is displayed

Press ▲▼ to select the language, and press [MENU/SET]

• The [PLEASE SET THE CLOCK] message appears.

Press [MENU/SET]

12 VQT2M98

The Clock is not set when the camera is shipped.

To change time setting

Press ◄► to select the items (year, month, day, hour, minute, display order or time display format), and press ▲▼ to set

Select the

setting

item

Change

the values

and

settings

• To cancel → Press .

• When set to [AM/PM], 0:00 midnight is AM 12:00, and 0:00 noon is PM 12:00.

Select the display order for the day, month, and year ([M/D/Y], [D/M/Y], or [Y/M/D]).

Select either [24HRS] or [AM/ PM] for the time display format.

Press [MENU/SET]

Confirm the setting and press [MENU/SET]

• To return to the previous screen, press .

• Turn on power again and check time display. (Time and date can be displayed by pressing [DISPLAY] several times.)

Select [CLOCK SET] from [SETUP] menu (→17), perform and .

• Clock settings will be saved for approx. 3 months even after battery is removed, provided a fully-charged battery was installed in the camera for 24 hours beforehand.

Failure to set the date and time will cause the date/time to be improperly printed when

●

printing pictures at a digital photo center or when using [TEXT STAMP]. Year can be set between 2000 and 2099.

●

After the time has been set, the date can be printed correctly even if the date is not

●

displayed on the camera screen.

VQT2M98 13

Setting the menu

Refer to the procedure example below when operating the [SETUP] menu, [REC] menu and [PLAYBACK] menu.

(Example) Change [LCD MODE] in [SETUP] menu when in [NORMAL PICTURE] Mode.

Do not touch the lens.

Lens cover

Shutter button

■

To reset default settings

[RESET] (→20)

Open the lens cover

The power is turned on.

Select the [NORMAL PICTURE] Mode

Press the [MODE] button. Press ▲▼ to select [NORMAL PICTURE], and then press [MENU/SET].

• To display the [PLAYBACK] menu, press the Playback button to switch to Playback Mode.

Bring up the menu

The background color of the selected item changes.

Select [SETUP] menu

Highlight Select and return

The

background

color

changes.

to menu items

14 VQT2M98

Select the item

Page (Zoom lever can be used to switch to next screen.)

Item

Settings display may vary according to items.

Menu type

Menu items displayed vary according to the mode.

Select the setting

Settings Selected setting

Close menu

[REC] menu (Recording Mode only)

[SETUP] menu

[PLAYBACK] menu (Playback Mode only)

Changing picture preferences (→53 - 59)

• Enables you to specify color, Sensitivity, pixel level, and other settings.

Making the camera more convenient to use (→17 - 22)

• Enables you to specify settings related to usability. Adjust the Clock, change the Beep sounds, and so on.

Using your pictures (→67 - 73)

• Enables you to specify picture protection, cropping, and printing settings for pictures you have taken.

• You can also exit this menu in Recording Mode by pressing the shutter button halfway down.

VQT2M98 15

Setting the menu (Continued)

Using Quick menu

Recording menu items can be called up easily.

In Recording Mode, display the Quick menu

Select item and setting

Press the button until the Quick menu is displayed

Select

Press

(Finished)

Quick menu

Setting

Item

Settings items displayed vary depending on Recording Mode.

●

16 VQT2M98

Using the [SETUP] menu

For details about the setting procedure in the [SETUP] menu. (→14) Make general camera settings such as adjusting the Clock, extending the battery life, and changing the Beep sounds.

[CLOCK SET], [AUTO REVIEW] and [AUTO POWER OFF] are important for Clock setting and battery life. Please check these before use.

Item Settings, notes

[CLOCK SET]

Set the date and time. (→12)

[WORLD TIME]

Set the local time at travel destination. (→52)

[TRAVEL DATE]

Record the number of days elapsed in your travels. (→51)

[BEEP]

Change or mute the beep/shutter sounds.

[VOLUME]

Adjust volume of sound from speakers (7 levels).

Set time, date, and display format.

[DESTINATION]: Set the local time at travel destination.

[HOME]: Set date and time at home area.

[TRAVEL SETUP]

[OFF]/[SET] (Register departure and return dates.)

[LOCATION]

[OFF]/[SET] (Input name of destination.) (→60)

[BEEP LEVEL]

/ / : Mute/Low/High

[BEEP TONE]

/ / : Change beep tone.

[SHUTTER VOL.]

/ / : Mute/Low/High

[SHUTTER TONE]

/ / : Change shutter tone.

0 • • [LEVEL3] • • [LEVEL6]

• Cannot be used to adjust TV speaker volume when connected to TV. (We recommend setting camera volume to 0)

VQT2M98 17

Using the [SETUP] menu (Continued)

For details about the setting procedure in the [SETUP] menu. (→14)

Item Settings, notes

[LCD MODE]

Make LCD monitor easier to see.

[DISPLAY SIZE]

Change the display size of the menu.

[FOCUS ICON]

Change the focus icon.

[OFF]: Normal (cancel setting)

[AUTO POWER LCD]:

The brightness is adjusted automatically depending on how bright it is around the camera.

[POWER LCD]:

Makes screen brighter than normal (for outdoor use).

[HIGH ANGLE]:

Makes screen easier to see when taking pictures from high positions. (becomes harder to see from the front)

• [AUTO POWER LCD] is disabled in the following situations. During Playback Mode or menu screen display, or when connected to computer/printer.

• [POWER LCD] will be deactivated if no operations are performed for 30 seconds while recording. (Brightness can be restored by pressing any button)

• [HIGH ANGLE] will be canceled when power is turned off (including [AUTO POWER OFF]).

• Brightness/color of screen in [LCD MODE] has no effect on pictures recorded.

• Block out sunlight (with hand, etc.) if reflection makes screen difficult to see.

• [AUTO POWER LCD] and [HIGH ANGLE] are not available in Playback Mode.

• Selecting [AUTO POWER LCD] or [POWER LCD] will reduce the number of pictures available and battery life.

[STANDARD]/[LARGE]

/ / / / /

18 VQT2M98

For details about the setting procedure in the [SETUP] menu. (→14)

Item Settings, notes

[AUTO POWER OFF]

The camera turns off automatically after a specified period of inactivity.

[OFF]/[2 MIN.]/[5 MIN.]/[10 MIN.]

• Not used in the following situations. When an AC adaptor (optional) is used, when connected to a computer or printer, during motion picture recording or playback, and during Slide Shows or demos

• Specific periods apply in the following situations. [INTELLIGENT AUTO] Mode: [5 MIN.], and when a Slide Show is paused: [10 MIN.]

[AUTO REVIEW]

Automatically display still pictures immediately after taking them.

[OFF]: No auto review

[1 SEC.]/[2 SEC.]: Automatically display for 1 or 2

seconds.

[HOLD]: Auto review screen remains until a button (other

than the [DISPLAY] button) is pressed

• Fixed to [2 SEC.] in [INTELLIGENT AUTO] Mode.

• Auto review occurs immediately after still pictures taken in [BURST] mode and in the Scene Modes [SELF PORTRAIT], [HI-SPEED BURST], [FLASH BURST], and [PHOTO FRAME], regardless of settings.

• Motion pictures cannot be automatically reviewed.

VQT2M98 19

Using the [SETUP] menu (Continued)

For details about the setting procedure in the [SETUP] menu. (→14)

Item Settings, notes

[RESET]

Reset to the default settings.

[USB MODE]

Select communication method for when connecting camera to a computer or printer with USB connection cable.

[RESET REC. SETTINGS?]

[YES]/[NO]

[RESET SETUP PARAMETERS?]

[YES]/[NO]

• Resetting the setup parameters will also reset the following:

- Age in years/months and names in Scene Modes

[BABY] and [PET]

- [TRAVEL DATE]

- [WORLD TIME]

- [FAVORITE] in [PLAYBACK] menu (set to [OFF])

- [ROTATE DISP.] (set to [ON])

• Folder numbers and clock settings will not be reset.

• Camera movement may be audible as the lens function is reset. This is not a fault.

[SELECT ON CONNECTION]:

Select [PC] or [PictBridge (PTP)] each time you connect to a computer or PictBridge-compatible printer

[PictBridge (PTP)]: Select when connecting to a

PictBridge-compatible printer

[PC]: Select when connecting to a computer

20 VQT2M98

For details about the setting procedure in the [SETUP] menu. (→14)

Item Settings, notes

[VIDEO OUT]

∗

Change the video output

[NTSC]/[PAL]

• Operates when AV cable is connected.

format when connected to a TV, etc. (Playback Mode only).

[TV ASPECT]

Change the aspect ratio

• Operates when AV cable is connected. when connected to a TV, etc. (Playback Mode only).

[VERSION DISP.]

Current version is displayed.

Check the version of the camera firmware.

[FORMAT]

Use when [BUILT-IN MEMORY ERROR] or [MEMORY CARD ERROR] appears, or when formatting the builtin memory or card.

When a card/built-in memory is formatted, the data cannot be restored. Check the content of the card/ built-in memory carefully before

[YES]/[NO]

• This requires a sufficiently charged battery (→8) or AC

adaptor (optional). When formatting the built-in memory, remove the cards. (Only inserted card will be formatted if present; built-in memory will be formatted if no card is inserted.)

• Always format cards with this camera.

• All picture data including protected pictures will be

deleted. (→72)

• Do not turn off power or perform other operations during

formatting.

• Formatting the built-in memory may take several

minutes.

• Consult your nearest Service Center if format cannot be

successfully completed.

formatting.

∗

PAL video out is not available on the version DMC-FP2P/DMC-FP1P sold in the U.S. and the version DMC-FP2PC/DMC-FP1PC sold in Canada.

VQT2M98 21

Using the [SETUP] menu (Continued)

For details about the setting procedure in the [SETUP] menu. (→14)

Item Settings, notes

[LANGUAGE]

Change display language.

[DEMO MODE]

View demonstration of functions.

Set the language displayed on the screen.

[STABILIZER DEMO.]: (Only during recording) Indicates the extent of jitter detected by the camera (Estimate)

Large ← Small → Large

Extent of jitter

Extent of jitter after stabilization

• When the demo screen is displayed, press [MENU/SET] to switch the Optical Image Stabilizer between on and off.

• Cannot be displayed in Playback Mode.

• To stop→ Press [DISPLAY] button.

• Recording and zoom cannot be performed during demo.

[AUTO DEMO]: View introductory Slide Show

[OFF]/[ON]

• To close → Press [MENU/SET]

• If the camera is left switched on while connected to the AC adaptor (optional) and with no card inserted, the demo will automatically begin whenever no operations are performed for approx. 2 minutes.

• [AUTO DEMO] cannot be displayed on external devices such as TVs.

22 VQT2M98

Sequence of Recording

Please set the Clock before recording. (→12)

Lens cover

Power button

[MODE] button

Do not touch the lens.

button

Playback button

[MENU/SET]

Open the lens cover

The power is turned on.

Select the desired Recording Mode and record

■

To use settings automatically selected by the camera

Press the button.

■

To select the Recording Mode manually

Press the [MODE] button. Press ▲▼ to select the Recording Mode, and then press [MENU/SET].

Play back the pictures you took

Press the Playback button. Press ◄► to select a picture.

■

To return to the Recording Mode

Press the Playback button again.

• The camera returns to the previous Recording Mode.

Close the lens cover

The power is turned off.

• The power can also be turned off by pressing the Power button.

■

Recording Mode list

[INTELLIGENT AUTO] Mode Take pictures with automatic settings. (→25)

[NORMAL PICTURE] Mode Take pictures with your own settings. (→27)

[MY SCENE MODE]

[SCENE MODE] Take pictures according to scene. (→40)

[MOTION PICTURE] Mode Take motion pictures. (→49)

Take pictures in commonly used Scene Modes.

(→48)

VQT2M98 23

Sequence of Recording (Continued)

■

Holding the camera

Flash

AF Assist Lamp

Convenient ways to turn the power on

Besides opening the lens cover, you can also turn the power on as follows.

■

To turn the power on in Playback Mode

• If jitter becomes noticeable, use both hands, keep your arms close to your body, and stand with your feet at shoulder width.

• Do not touch the lens.

• Do not block the microphone when recording motion picture. (→7)

• Do not block the flash or the AF Assist Lamp. Do not look at it from close range.

• Try to hold the camera steady when you press the shutter button.

Hold

Pictures on the card or built-in memory are displayed.

■

With the lens cover opened and the power off

The camera will turn on in Recording Mode.

• When the Power button is held with the lens cover closed, a message [PLEASE OPEN THE LENS COVER] is displayed.

24 VQT2M98

Hold

Taking pictures with automatic settings

[INTELLIGENT AUTO] Mode

Recording Mode:

Optimum settings are made automatically from information such as ‘face,’ ‘movement,’ ‘brightness,’ and ‘distance’ just by pointing the camera at the subject, meaning that clear pictures can be taken without the need to make settings manually.

Open the lens cover

The power is turned on.

Select [INTELLIGENT AUTO] Mode

Take pictures

• Press again to return to the previous Recording Mode.

Recording Mode icon (see below)

Press halfway (press lightly to focus)

Shutter button

The type of scene detected is indicated by a

■

Automatic Scene Detection

Camera identifies the scene when pointed at the subject, and makes optimum settings automatically.

[i PORTRAIT]: People are detected

[i SCENERY]: Scenery is detected

[i MACRO]: A close-up shot is detected [i SUNSET]: A sunset is detected Reads subject movement to avoid blurring when scene does not correspond to any of the

above.

If the camera automatically identifies the scene and determines that people appear as subjects in the picture ( or ), Face Detection is activated, and the focus and exposure are adjusted for the recognized faces.

blue icon for two seconds

[i NIGHT PORTRAIT]: People and night scenery are detected

is selected)

[i NIGHT SCENERY]: Night scenery is detected

Press fully (press the button all the way to record)

Focus display

(when focus is aligned: flashing → illuminated)

(Only when

VQT2M98 25

Taking pictures with automatic settings

[INTELLIGENT AUTO] Mode (Continued)

Recording Mode:

■

To use flash

Select either (i Auto) or (Forced flash off).

• When is used, , (Auto/Red-Eye Reduction), (Slow Sync./Red-Eye Reduction) and (Slow Sync.)

are selected automatically according to the subject type and brightness. (For details (→36))

•

and indicate that digital red-eye correction is activated.

• The shutter speed is slower in

In addition to automatic scene detection, [ ] in [SENSITIVITY] and backlight

●

compensation will operate automatically. The following menu items may be set in [INTELLIGENT AUTO] Mode:

●

• ([REC] menu): [PICTURE SIZE]

• ([SETUP] menu [STABILIZER DEMO.]

∗

Items that may be set differ from other Recording Modes.

∗

Other items in the [SETUP] menu will reflect settings made in other Recording

Modes.

According to the following conditions, different scene types may be determined for the

●

same subject: Face contrast, conditions of subject (size, distance, coloring, contrast, movement), zoom ratio, sunset, sunrise, low brightness, jitter If desired scene type is not selected, we recommend manually selecting the appropriate

●

Recording Mode. (Scene Mode: (→40)) Backlight compensation

●

Backlight refers to the light that shines from behind the subject. When this occurs, the subject appears darker, and so backlighting is automatically corrected by increasing the brightness of the entire image. We recommend using a tripod and the self-timer with [i NIGHT SCENERY] and

●

[i NIGHT PORTRAIT]. When jitter is small (e.g. using tripod) with [i NIGHT SCENERY], shutter speed can

●

reach a maximum of 8 seconds. Do not move the camera. The settings for the following functions are fixed:

●

• [AUTO REVIEW]: [2 SEC.] • [AUTO POWER OFF]: [5 MIN.]

• [WHITE BALANCE]: [AWB] • [STABILIZER]: [AUTO]

• [AF MODE]: (Face Detection)

∗

(9-area-focusing) when face cannot be recognized

The following functions cannot be used:

●

[EXPOSURE], [DIGITAL ZOOM]

∗

): [CLOCK SET], [WORLD TIME], [BEEP]

∗

, [BURST], [COLOR MODE]

∗

• [AF ASSIST LAMP]: [ON]

and .

∗

, [LANGUAGE],

26 VQT2M98

Taking pictures with your own settings

[NORMAL PICTURE] Mode

Recording Mode:

Using the [REC] menu to change settings and set up your own recording environment.

Shutter button

■

To use zoom

(→29)

■

To use flash

(→35)

■

To adjust picture brightness

(→39)

■

To take close-up pictures

(→37)

■

To adjust coloring

(→55)

Open the lens cover

The power is turned on.

Display the screen for Recording Mode selection

Select [NORMAL PICTURE] Mode

Take a picture

Press halfway

(press lightly to focus)

Focus display

(when focus is aligned: flashing → illuminated)

Press fully

(press the button all

the way to record)

AF area (aligns focus with subject; when complete: red → green)

If a warning is displayed about jitter, use

●

[STABILIZER], a tripod, or [SELFTIMER]. If aperture value or shutter speed is displayed in red,

●

correct exposure has not been achieved. Use flash or change [SENSITIVITY] settings.

Jitter alert display

Aperture value Shutter speed

VQT2M98 27

Taking pictures with your own settings

[NORMAL PICTURE] Mode (Continued)

Recording Mode:

Align focus for desired composition

Useful when subject is not in center of picture.

First adjust focus according to subject

Align the AF

area with the

subject

Hold down

halfway

AF area

Return to desired composition

Press fully

AF area

The focus display flashes and beep sounds when focus is not aligned.

●

Use the focus range displayed in red as a reference. Even if the focus display is lit, the camera may be unable to bring the subject into focus if it is out of range. AF area is displayed larger in dark conditions or when using Digital

●

Zoom. Most displays are temporarily cleared from screen when the shutter

●

button is pressed halfway.

Subjects/environments which may

●

make focusing difficult:

•

Fast-moving or extremely bright objects, or objects with no color contrast.

• Taking pictures through glass or near objects emitting light. In the dark, or with significant jitter.

•

When too close to object or when taking pictures of both distant and close objects together in the same picture.

We recommend using the ‘Face

●

Detection’ function when taking pictures of people (→56).

Focus range

Direction detection function

Still pictures taken with the camera held vertically are automatically played back vertically. (Only when [ROTATE DISP.] is set to [ON])

Still pictures taken with the lens surface facing directly up or down and still pictures

●

taken on other cameras may not be rotated. Additionally, still pictures taken while holding the camera upside down are not rotated automatically. Motion pictures are not displayed vertically.

●

28 VQT2M98

Taking pictures with zoom

Recording Mode:

‘Optical Zoom’ offers 4 x magnification. At a lower recording pixel level, ‘Extended Optical Zoom’ can be used to zoom up to 8.4 x (DMC-FP2) or 7.8 x (DMC-FP1). For zooming in even closer, ‘Digital Zoom’ is available.

Zoom In/Out

Capture a wider area (wide-angle)

W side (wide-angle): 1 x

Adjust the focus after adjusting the zoom.

●

Enlarge the subject (telephoto)

T side (telephoto): up to 4 x

Zoom bar

Focus range

Zoom ratio (approx.)

Optical Zoom and Extended Optical Zoom (EZ)

Automatically switches to ‘Optical Zoom’ when using maximum Picture Size (→53), and to ‘Extended Optical Zoom’ (for further zooming) otherwise. (EZ is short for ‘Extended Optical Zoom’.)

• Optical Zoom • Extended Optical Zoom

Zoom bar

Maximum zoom ratios by picture size

●

DMC-FP2 Optical Zoom Extended Optical Zoom

[PICTURE SIZE] 14 M - 10.5 M

Max. enlargement 4 x 4.7 x 6.8 x 8.4 x

DMC-FP1 Optical Zoom Extended Optical Zoom

[PICTURE SIZE] 12 M - 9 M

Max. enlargement 4 x 4.9 x 6.3 x 7.8 x

10 M

8 M

( displayed)

5 M 3 M or less

Extended Optical Zoom system

●

When the recording pixel level is set to [3 M ] (corresponding to 3 million pixels), 3 million pixels of the available pixel level in the center of the CCD are used in recording, enabling higher magnification. The enlargement ratio displayed in the bar on screen is an estimate.

●

VQT2M98 29

+ 65 hidden pages
