ENGLISH Before operating the unit, read these operating instructions thoroughly and keep them for future reference.

Manufactured by:

Panasonic HA Air-Conditioning (M) Sdn. Bhd.

Lot 2, Persiaran Tengku Ampuan, Section 21, Shah Alam Industrial Site, 40300 Shah Alam, Selangor, Malaysia.

Thank you for purchasing Panasonic Air Conditioner

During Installation

During Operation

During Installation

During Operation

■ Definition

To prevent personal injury, injury to others, or property damage, please observe the following.

Incorrect operation due to failure to follow instructions may cause harm or damage, the seriousness of which is classiﬁ ed as below:

Warning

This sign warns of death

or serious injury.

Caution

This sign warns of injury

or damage to property.

The instructions to be followed are classiﬁ ed by the following symbols:

SAFETY PRECAUTIONS

Warning

During Installation

• Do not install, remove and reinstall the unit by yourself; improper installation will cause leakage, electric shock or ﬁ re. Please consult an authorized dealer or specialist for the installation work.

• This equipment must be earthed and installed with ELCB. It may cause electrical shock or ﬁ re in case of malfunction

During Operation

• Do not share the same power outlet with other equipment.

• Do not modify power cords.

• Do not use extension cords.

• Do not operate with wet hands.

• Do not insert your ﬁ ngers or other objects into the indoor or outdoor unit.

• Do not attempt to repair the unit by yourself.

• Do not use rechargeable (Ni-Cd) batteries.

• Do not allow infants and small children to play with the remote control to prevent them from accidentally swallowing the batteries.

• Use the speciﬁ ed supply cord.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualiﬁ ed persons in order to avoid a hazard.

• Remove the batteries if the unit is not going to be used for a long period of time.

• New batteries of the same type must be inserted following the polarity stated to prevent malfunction of the remote control.

• In case of emergency or abnormal conditions (burning, unusual odour, etc), turn off the power supply.

Caution

This symbol denotes

an action that is

PROHIBITED.

These symbols denote

actions that are

COMPULSORY.

During Installation

• Ensure that the drainage pipe is connected properly. Otherwise, leakage may occur.

• Do not install the unit in a potentially explosive atmosphere.

During Operation

• Do not wash the unit with water, benzene, thinner or scouring powder.

• Do not use for other purposes such as preservation of food.

• Do not use any combustible equipment in front of the airﬂ ow outlet.

• Do not sit or place anything on the indoor or outdoor unit.

• Do not expose directly to cold air for a long period.

• Aerate the room regularly.

• After long periods of use, make sure the installation rack is not damaged.

• Switch off the power supply before cleaning or servicing.

• Turn off the power supply if the unit is not used for a long period of time.

• This air conditioner is equipped with a built-in surge protective device. However, in order to further protect your air conditioner from being damaged by abnormally strong lightning activity, you may want to disconnect it from the power supply. Do not touch the air conditioner during lightning, it may cause electric shock.
