Mechanical Parts List
Panasonic Broadcast
MODEL: AJ-SPD850P/E/MC
CONTENTS
CASING ASSEMBLY.......................................................................................................................MPL-1
LOWER FRONT ASSEMBLY..........................................................................................................MPL-3
UPPER FRONT ASSEMBLY...........................................................................................................MPL-5
REAR JACK / POWER SUPPLY ASSEMBLY.................................................................................MPL-7
FRAME ASSEMBLY ........................................................................................................................MPL-9
PACKING ASSEMBLY.....................................................................................................................MPL-11
CABLE LIST.....................................................................................................................................MPL-13
CASING ASSEMBLY
12
105
105
E9
1-4
E10
E11
E13
1-1
1-3
16
1-2
103
E15
1-4
E6
1-1
1-3
18
103
4
103
1
8
3
6
6
E8
6
15
6
11
18
13
1-2
E7
102
19
104
102
E5
E2
10
E1
E4
101
9
19
101
106
101
E22
9
7
101
9
E3
13
E12
17
14
104
6
2
106
3
105
15
6
6
105
5
MPL-1
s
s
CASING ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPc
1 VYP9057 TOP PANEL ASS'Y 1
1-1 VMX2510 SPACER 2
1-2 VHD0775 SCREW 2
1-3 VMX2582 WASHER 2
1-4 VMT1563 SOFT HIGH SHIELD GASKET 2
2 VKU0546 BOTTOM PLATE 1
3 VGM1699 SIDE PANEL 2
4 VML2903 AC CORD HOOK 1
5 VGF0816 INSULATION SHEET 1
6 VMT1569 SOFT HIGH SHIELD GASKET 10
7 VJF1518 FLAT CABLE CRIP 1
8 VXA7868 P.C.B. CONTROL PANEL U 1
9 VMS4925 POST 4
10 VSC5676 CARD EARTH ANGLE 1
11 VSC5636 WIRE LOD SHIELD ANGLE 1
12 VMP8286 AC CABLE COVER 1
13 VLP0123 FERRITE CORE 2 J0KG00000001
14 VJF1443 CLAMPER 2
15 VMT1572 SOFT HIGH SHIELD GASKET 2
16 VJF1413 CLAMPER 1
17 VLP0388 EMC CLAMP RILTER 1 J0KG00000014
18 VMT1656 GASKET 3
19 VMT1657 GASKET 2
101 XYN3+K6 SCREW 8
102 XSB3+4 SCREW 4
103 XTV3+6FFR SCREW 4
104 XTV3+6F SCREW 16
105 XSB4+8FC SCREW 8
106 XYE3+EF6 SCREW 6
E1 VEP86339B SPD CPU P.C.BOARD 1
E2 VEP80C96A SPD CPU SUB P.C.BOARD 1
E3 VEP83638C SPD MSC P.C.BOARD 1
E4 VEP80C93A CARD IF1 P.C.BOARD 1
E5 VEP80C93B CARD IF2 P.C.BOARD 1
E6 VEP80C92A SPD MOTHER P.C.BOARD 1
E7 VEP84383D AUDIO P.C.BOARD 1
E8 VEP84384C A PROC P.C.BOARD 1
E9 VEP83594B V IN P.C.BOARD 1
E10 VEP83597G V OUT P.C.BOARD 1
E11 VEP86326L SYSCON P.C.BOARD 1
E12 VEP80C87A MOTHER P.C.BOARD 1
E13 VEP83639A REC IF P.C.BOARD 1
E15 VEP81222A AC IN POWER P.C.BOARD 1
E22 VEP80C97A USB CON P.C.BOARD 1
Remarks Ref.No. Part No. Part Name & DescriptionPc
Remarks
MPL-2
LOWER FRONT ASSEMBLY
31
24
32
27
110
27-1
E20
13
28
2
8
E17
12
23 22
111
3
102
101
7
2
1
112
101
111
105
101
25
108
110
23
10
9
22
30
29
104
26
11
19
107
103
106
15
21
101
33
104
109
20
17
33
6
19
4
14
5
16
18
E19
103
MPL-3
s
s
LOWER FRONT ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPc
1 VKU0595 BACK COVER 1
2 VGU9664 VR KNOB 5
3 VMP8075 LCD PROTECTION ANGLE 1
4 VGM2096 SUB CONTROL SUPPORT ANGLE 1
5 VGM2097 SUB CONTROL ANGLE 1
6 VGU7178 VR KNOB 4
7 VGU9663 SLIDE KNOB 2
8 VGH4776 SLIDE KNOB SHEET 2
9 VGU9614 SEARCH DIAL RUBBER 1
10 VGU9613 SEARCH DIAL KNOB 1
11 VGF0802 SEARCH DIAL COVER 1
12 VGU5582 SWITCH KNOB 1
13 VGF0687 SLIDE SW SHEET 1
14 VKF3958 SUB CONTROL DOOR 1
15 VGU7179 SLIDE SW KNOB 7
16 VQL0F68 SLIDE SW SEAL 7
17 VGM2117 SUB CONTROL ANGLE 1
18 VMS6012 SHAFT 1
19 VMB2978 LEAF SPRING 2
20 VMC1241 EARTH PLATE 1
21 VMP8356 EARTH PLATE SUB 1
22 VGQ3176 PUSH BUTTON 10
23 VMB3942 KEY SW COIL SPRING 10
24 VYP8989 FRONT PANEL (2)U (LOWER) 1
25 VGU9666 PUSH BUTTON 10
26 VSP1120 SEARCH DIAL 1
27 VEK0G84 LCD U 1
27-1 KBCUGS100VM BACK LIGHT U 1
28 VMZ3475 INSULATION SHEET 1
29 VMP8168 PANEL ANGLE 1
30 VMP8169 FIX ANGLE 1
31 VSC5654 PANEL EARTH SHEET 1
32 VMP8288 SHEET MOUNT ANGLE 1
33 VMT1648 VR CAP 4
101 XTN4+10GFJ SCREW 16
102 XTV3+8GFJ SCREW 1
103 XSS26+6FJK SCREW 2
104 XSB3+6FJK SCREW 2
105 XSB3+8FJK SCREW 3
106 XQN14+C4FJ SCREW 4
107 XSN26+3FJ SCREW 2
108 XSN2+8FJ SCREW 1
109 XSN2+3FJ SCREW 1
110 XSB26+5FJ SCREW 4
111 XSB3+8FJK SCREW 4
112 XSB3+4 SCREW 4
E17 VEP86340A FRONT MAIN P.C.BOARD 1
E19 VEP80C89A FRONT POCKET P.C.BOARD 1
E20 VEP26257C MONITOR P.C.BOARD 1
Remarks Ref.No. Part No. Part Name & DescriptionPc
Remarks
MPL-4
UPPER FRONT ASSEMBLY
107
108
108
6
7
105
5
101
E18
E23
101
106
101
5-1
5-6
5-3
5-4
103
5-2
102
5-4
103
1
8
5-7
3
4
102
104
101
2
9
102
104
5-5
MPL-5
s
s
UPPER FRONT ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPc
1 VEK0G98 USB CN 1
2 VMP8072 ACCESSORY ANGLE 1
3 VGU9663 SLIDE KNOB 4
4 VGH4776 SLIDE KNOB SHEET 4
5 VYP8985 FRONT PANEL (1)U 1
5-1 VKF3919 BLINDER PANEL 5
5-2 VMB3912 BLINDER BADGE 5
5-3 VKF3920 USB LID 1
5-4 VMD5135 BLINDER CONTROL 2
5-5 VGP6077 DVD COVER 1
5-6 VMA0S87 FRONT SUPPORT ANGLE A 1
5-7 VMA0S88 FRONT SUPPORT ANGLE B 1
6 VMP8073 LID ACCESSORY ANGLE 1
7 VGF1005 BLINDER PANEL 1
8 VMT1638 P.C.B. SUPPORT BLOCK 1
9 VMC1955 EARTH SHEET MOUNT ANGLE A 1
101 XTV3+6GR SCREW 7
102 XTB3+6GFN SCREW 4
103 XTN2+8G SCREW 4
104 XTB2+6G SCREW 2
105 XTV3+6FFZ SCREW 1
106 XTV2+5F SCREW 2
107 XTV3+6F SCREW 2
108 XSB3+8FCS SCREW 4
E18 VEP80C90A FRONT UPPER P.C.BOARD 1
E23 VEP80C91B SD CARD P.C.BOARD 1
Remarks Ref.No. Part No. Part Name & DescriptionPc
Remarks
MPL-6
REAR JACK / POWER SUPPLY ASSEMBLY
IMPORTANT SAFETY NOTICE:
Components identified with the mark have the special characteristics for safety.
When replacing any of these components, use only the same type.
E16
108
102
108
106
105
8
9
3
2
6
101
5
104
101
103
104
4
7
103
10-2
105
107
109
105
1
109
E21
10
10-4
E14
10-3
10-1
110
110
MPL-7
s
s
REAR JACK / POWER SUPPLY ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPc
1 VMP8089 OPTION PANEL 1
2 VJH1245 JACK PANEL 1
3 VHN0063 NYLON NUT 2
4 VMP5032 OPTION PANEL 1
5 VMP7303 XLR HOLDER ANGLE 1
6 VMX0835 SPACER 2
7 VMP7304 BLANK PANEL 1
8 VJF1157 HARNESS 1
9 VRF0190 FAN MOTOR 1 L6FALEFH0007
10 VEK0G78 POWER U 1
10-1 VSC5223 POWER CASE (LOWER) 1
10-2 VSC5640 SIDE (R) SHIELD PLATE 1
10-3 VMZ3472 INSULATION SHEET 1
10-4 VMZ3148 POWER BARRIER B 1
101 XSN26+6FZ SCREW 12
102 XSN4+35FC SCREW 2
103 XTN26+6FFZ SCREW 9
104 XTV3+10GFZ SCREW 7
105 XTV3+6FFZ SCREW 3
106 XYE4+EF8 SCREW 1
107 XSB2+5FZ SCREW 4
108 XTV3+6F SCREW 6
109 XTV3+6FFR SCREW 4
110 XYN3+F8 SCREW 4
E14 VEP81235A POWER 2 P.C.BOARD 1
E16 VEP80C40E AV JACK P.C.BOARD 1
E21 VEP80C98A NETWORK CON P.C.BOARD 1
Remarks Ref.No. Part No. Part Name & DescriptionPc
Remarks
MPL-8
FRAME ASSEMBLY
103
21
103
102
12
15
103
101
23
7
102
103
10
104
103
102
18
103
8
13
11
4
103
105
17
24
20
2
25
19 14
22
7
103
105
10
16
1
5
103
3
103
7
10
104
103
7
103
6
10
104
103
9
12
102
102
101
102
103
MPL-9
104
103
s
s
FRAME ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPc
1 VMP8080 CENTER SUB FRAME 1
2 VMP8087 P.C.B. SUPPORT ANGLE 1
3 VGQ8115 P.C.B. GUIDE RAIL A 1
4 VGQ4011 P.C.BOARD GUIDE RAIL A 1
5 VMP6802 REAR FRAME 1
6 VMP6020 BOTTOM FRAME 1
7 VJF0384 CLAMPER 6
8 VMP6832 SIDE FRAME (L) 1
9 VMP6833 SIDE FRAME (R) 1
10 VKA0117 PLASTIC FOOT 4
11 VJF1259 EDGE HOLDER 1
12 VMP6248 RACK MOUNT 2
13 VYQ3276 ROTATING JOINT L 1
14 VYQ3277 ROTATING JOINT R 1
15 VHD5013 SCREW 2
16 VXA7867 P.C.B. SUPPORT BASE PLATE 1
17 VMP8228 EARTH BASE ANGLE 1
18 VMT1658 GASKET 1
19 VMP8077 FRONT FRAME 1
20 VXA7875 CENTER FRAME U 1
21 VXA7876 GUIDE RAIL MOUNT ANGLE A 1
22 VXA7877 GUIDE RAIL MOUNT ANGLE B 1
23 VES0941 POWER SW U 1
24 VMP8081 P.C.B. CONTROL PLATE 1
25 VMT1607 P.C.B. CONTROL RUBBER 3
101 XYN3+C6 SCREW 6
102 XTV4+6F SCREW 12
103 XTV3+6F SCREW 33
104 XYNV3+K12S SCREW 4
105 XSB3+4 SCREW 3
Remarks Ref.No. Part No. Part Name & DescriptionPc
Remarks
MPL-10
PACKING ASSEMBLY
IMPORTANT SAFETY NOTICE:
Components identified with the mark have the special characteristics for safety.
When replacing any of these components, use only the same type.
1
10
2
9
4
7
3
8
11
5
6
12
13
11
14
14
14
14
14
14
14
14
MPL-12
s
s
PACKING ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPc
1 VJA0488 POWER CODE 1 K2CG3CH00001 FOR AJ-SPD850P
1 VJA0746 POWER CODE 1 FOR AJ-SPD850E
1 K2CK3DH00015 POWER CODE 1 FOR AJ-SPD850MC
2 VJA0738 AC CODE 1 FOR AJ-SPD850E
3 VYQ3230 OPERATING INSTRUCTIONS 1 CD-R
4 VQT0L03 OPERATING INSTRUCTIONS 1 FOR AJ-SPD850P
4 VQT0L05 OPERATING INSTRUCTIONS 1 FOR AJ-SPD850E
4 VQT0L06 OPERATING INSTRUCTIONS 1 FOR AJ-SPD850MC
5 VPF0277 POLYETHYLENE BAG 1
6 VPN4303 CUSHION LR 1
7 VPN4606 CUSHION 1
8 VPN4304 CUSHION LL 1
9 VPN4302 CUSHION UL 1
10 VPN4305 ACCESSORY PAD 1
11 VPF0149 HANDLE COVER 2
12 VPG0Z49 PACKING CASE 1 FOR AJ-SPD850P
12 VPG0Z51 PACKING CASE 1 FOR AJ-SPD850E
12 VPG0Z54 PACKING CASE 1 FOR AJ-SPD850MC
13 VPG8654 PACKING CASE (OUT) 1 FOR AJ-SPD850MC
14 VPN1791 CORNER PAD 8 FOR AJ-SPD850MC
Remarks Ref.No. Part No. Part Name & DescriptionPc
Remarks
MPL-12
s
s
CABLE LIST
Ref.No. Part No. Part Name & DescriptionPc
1 VWJ10AW180M0 FLEX. CABLE 1
2 VEE0Z70 M FRM1 1
3 VEE0Z71 M FRM2 1
4 VEE0Z74 C SUB LAN1 1
5 VEE0Z75 C SUB LAN2 1
6 VEE0Z73 ATA POWER 1
7 VEE0Z78 ATA1 1
8 VEE0U47 POWER CABLE 1
9 VEE0Z77 SD CARD2 1
10 VWJ20SW130L0 FLEX. CABLE 1
11 VWJ1488 MONITOR FLEX. 1
12 VEE1A38 USB CABLE 1
Remarks Ref.No. Part No. Part Name & DescriptionPc
Remarks
MPL-14
