Oster FPSTSMPL1 User Guide

For product questions:

Oster Consumer Service

USA : 1.800.334.0759

Canada : 1.800.667.8623

www.oster.com

Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions,

Boca Raton, Florida 33431.

SPR-062013-289P

Para preguntas sobre los productos llame:

Oster Consumer Service

EE.UU. : 1.800.334.0759

Canadá : 1.800.667.8623

www.oster.com

Jarden Consumer Solutions, Boca Raton, Florida 33431.

Printed in China Impreso en China

Planetary

Stand Mixer Batidora

Planetaria

FPSTSMPL1

Visit us at www.oster.com P.N. 116170 Rev A

Important SafeguardS

When using electrical appliances, basic safety precautions should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USE

1 . To protect against risk of electrical shock, do not put mixer in water or other liquid.

This may cause personal injury or damage to the product.

2. Close supervision is necessary when mixer is used by or near children or incapacitated persons.

3. Unplug from outlet while not in use, before putting on or taking off parts, and before cleaning.

4. Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas and other utensils away from beaters during operation to reduce the risk of injury to persons and/or damage to the mixer.

5. To disconnect, turn off all controls and remove plug from outlet.

6. Do not operate mixer with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. If the mixer becomes damaged please contact Consumer Services for assistance.

7. Do not use extension cord.

8. The use of attachments not recommended or sold by Jarden Consumer Solutions may cause fire, electrical shock or injury.

9. Do not use outdoors or for commercial purposes.

10. Do not let cord hang over edge of table or countertop or touch hot surfaces, including the stove.

1 1. Remove beaters from mixer before washing.

12. Do not place mixer or bowls on or near a hot gas or electric burner, in a heated oven (microwave, convention, convection, etc.), or on any other heated surface.

13. Do not use mixer for other than intended use.

14. Do not leave mixer unattended while it is operating.

15. Mixer has an internal safety to prevent overheating. If the mixer shuts down because of overheating, reset the speed control dial to OFF and unplug unit from wall. Wait 1 minute and plug back in. If unit still does not start, wait 30 minutes to allow unit to cool completely before turning back on.

16. Any servicing, other than cleaning and user maintenance shall be performed by an authorized service representative.

17. When mixing liquids, especially hot liquid, use a tall container or make small quantities at a time to reduce spillage.

18. Don’t Abuse Cord. Never carry the mixer by the cord or yank it to disconnect from an outlet; instead, grasp the plug and pull to disconnect.

19. THIS UNIT IS FOR HOUSEHOLD USE ONLY.

SAVE THESE INSTRUCTIONS

For Products Purchased in the u.s. and canada only

To reduce the risk of electrical shock, this appliance is equipped with a 3-prong plug. If you are unable to insert the plug into the outlet, contact a qualified electrician to replace the obsolete outlet. Do not attempt to defeat the safety purpose of the 3-prong plug by modifying it in any way. Also, do not pull, twist or otherwise abuse the power cord; instead, grasp the plug and pull to remove from the outlet.

NOTE: The motor of your Mixer is protected by a heat cured insulation. This is a standard process. Due to the heat curing of the insulation, you may experience an odor and possibly a slight wisp of smoke from your mixer’s motor. This effect will disappear after the first few uses.

CONTACT CUSTOMER SERVICE AT 800-334-0759 IN THE U.S. OR 800-667-8623

IN CANADA OR VISIT WWW.OSTER.COM

DO NOT RETURN THIS PRODUCT TO PLACE OF PURCHASE

QUESTIONS?

table of ContentS

Important Safeguards 2 Welcome 4 Features 4 Accessories 5 Preparing for Use Installing Your Attachments 7 Splash Guard 8 Helpful Hints 8 Speed Control Guide 9 Care and Maintenance 9 Recipes 10 Warranty 13

WelCome

Congratulations on your purchase of an Oster® Planetary Stand Mixer. We’re delighted you chose us to work with you in the kitchen and assure that you’ll be pleased with your new Stand Mixer. Once you get started, you’ll ﬁnd you can’t do without this versatile kitchen tool. We've equipped you with all the must-have attachments to whip up dough for cookies and breads, handmade marshmallows and meringues, and your favorite mashed potatoes side-dish. The possibilities are endless when using your new Oster

Stand Mixer. Let's get mixing!

featureS

Attachment Shaft

Beater

Splash Guard

Stainless Steel Bowl

Mixer Head

Speed

Control

Knob

Tilt Release

Button

Bowl Locking Plate

gettIng to KnoW Your aCCeSSorIeS

flat beater

for normal to heavY mIxtureS

cakes, biscuits, creamed frostings, quick breads, candies, meat loaf, cookies, mashed potatoes, pie pastry

dough hooK

for mIxIng and KneadIng

yeast, doughs: breads, coee cakes

preparIng the Stand mIxer for uSe

WIre WhISK

for mIxtureS that need aIr InCorporated

eggs, sponge cakes, egg whites, angel food cakes, heavy cream, mayonnaise

SplaSh guard

for preventIng SplaSh out and addIng IngredIentS WhIle mIxIng

Before preparing the mixer for use, be sure the speed control dial is in the OFF position and the electric cord is unplugged.

Be sure to wash bowls and attachments before initial use.

preparIng the Stand mIxer for uSe

raISIng and loWerIng

the mIxIng head

To tilt mixer head, push Tilt Release button (Figure A) and slowly lift mixer head until it locks in the upright position. (Figure B)

To lower mixer head, grab head, push Tilt Release button and gently lower mixer head, ensuring it locks in downward position. A "click" sound will indicate the mixer head has locked securely into position. (Figure C)

operatIng Speed Control Knob:

The speed control dial is used for turning the mixer ON and OFF and for selecting its 12 mixing speeds.

Rotate the speed control dial in a CLOCKWISE direction to increase mixing speed, and in a COUNTERCLOCKWISE direction to decrease mixing speed.

Rotate the speed control dial until the indicator is aligned with the indicator line for the desired speed. (Figure D)

Figure A

Figure B

NOTE: Always begin mixing at the lowest possible

speed setting, then gradually move to desired higher speed to avoid splashing ingredients out of bowl.

DO NOT OPERATE WITHOUT ATTACHMENTS AND SEE NEXT SECTION "INSTALLING YOUR ATTACHMENTS" TO BEGIN.

Figure C

Figure D

InStallIng Your attaChmentS

to attaCh boWl

1. Rotate Control Knob to OFF position to turn unit off.

2. Unplug Stand Mixer.

3. Press Tilt Release button and tilt mixer head back.

4. Place bowl on bowl locking plate.

5. Turn bowl gently in a clockwise direction so that bowl handles are perpendicular to base.

6. Plug into a grounded 3 prong outlet.

to remove boWl

1. Rotate Control Knob to OFF position to turn unit off.

2. Unplug Stand Mixer.

3. Press Tilt Release button and tilt mixer head back.

4. Turn bowl counterclockwise and lift off locking plate.

to InStall attaChmentS

1. Rotate Control Knob to OFF position to turn unit off.

2. Unplug Stand Mixer.

3. Press Tilt Release button and tilt mixer head back.

4. Align the key positions of the beater shaft and attachment, push upward.

5. Twist counterclockwise so that pin aligns with attachment notch and clicks into position.

6. Plug into a grounded 3 prong outlet.

(ﬁgure A):

(ﬁgure B):

(ﬁgure C):

Figure A

Figure B

NOTE: Align the key positions of the beater shaft

and attachment.

to remove attaChmentS

1. Rotate Control Knob to OFF position to turn unit off.

2. Unplug Stand Mixer.

3. Tilt mixer head back.

4. Press attachment upward as far as possible and turn clockwise.

5. Pull attachment from beater shaft.

NOTE: It is recommended to scrape food off attachment

with a spatula/scraper before removing.

(ﬁgure D):

Figure C

Figure D

hoW to uSe the SplaSh guard

to attaCh SplaSh guard

1. Rotate Control Knob to OFF position to turn unit off.

2. Unplug Stand Mixer.

3. After bowl and attachment are in place, lock mixer head into the downward position.

4. From the front of the mixer, slide the Splash Guard over the bowl until centered and chute is to the right. The inner rim of the Splash Guard should ﬁt against the inside edge of the bowl.

NOTE: Splash Guard should ﬁt loosely on bowl for easy

assembly. Be sure to hold lid in place while pouring.

(ﬁgure A):

to uSe SplaSh guard:

1. For best results, rotate Splash Guard so the mixer head ﬁts into

the opening of the Splash Guard. The pouring chute will be just to the right of the attachment hub as you face the mixer.

2. While securing Splash Guard with one hand, pour the ingredients into the bowl through the pouring chute.

to remove SplaSh guard

1. Rotate Control Knob to OFF position to turn unit off.

2. Unplug Stand Mixer.

3. Lift the front of the Splash Guard clear of the bowl rim and pull forward.

(ﬁgure B):

Figure A

Figure B

helpful hIntS

• When mixing liquids, especially hot liquid, make small quantities at a time to reduce spillage.

• Ingredients should be added to the mixing bowl in the order they are speciﬁed in the recipe.

• Use the mixing speed that is recommended in the recipe. Use the speed control dial of the mixer to help you ﬁnd the correct speed to use.

• Use mixing times as speciﬁed in recipes. BE CAREFUL NOT TO OVERMIX. Overmixing can cause the mixture to become very tough.

• Should an object, such as a spatula, fall into the bowl while the mixer is operating, turn the mixer OFF immediately, then remove the object.

• For easier clean-up remove attachments and rinse immediately with warm water.

• Mixer is designed to operate in orbital pattern; periodic scraping of bowl sides may be required during mixing. Turn OFF before scraping.
