Oster CKSTDFZM37 User Manual

3.7 L Immersion Deep Fryer Freidora de Inmersión de 3.7 L
User Manual / Manual de Instrucciones
For product questions:
Sunbeam Consumer Service USA : 1.800.334.0759 Canada : 1.800.667.8623 www.oster.com
© 2016 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All rights reserved. Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.
Para preguntas sobre los productos llame:
Sunbeam Consumer Service EE.UU.: 1.800.334.0759 Canadá: 1.800.667.8623 www.oster.com
© 2016 Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions. Todos los derechos reservados. Distribuido por Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions, Boca Raton, Florida 33431.
Safety
Seguridad
How to use
Cómo usar
Cleaning
Cuidado y Limpieza
Recipes
Recetas
Warranty
Garantía
P.N. 188604 Printed in China Impreso en China CKSTDFZM37-SS1_16ESM1 GCDS-QST45756-JC
CKSTDFZM37-SS1_16ESM1.indd 1-2 5/13/16 14:08
www.oster.com
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed, including the following:
READ AND SAVE THESE INSTRUCTIONS
1. Read all instructions before using.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against risk of fire, electric shock, and personal injury do not
immerse control panel assembly, cord or plugs in water or other liquids.
4. Close supervision is necessary when Deep Fryer is used near children.
Children should not use this appliance.
5. Unplug from outlet when not in use, before putting on or taking off
parts and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning appliance.
6. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or has been dropped or damaged in any manner. Contact Customer Service (see warranty) to return for examination, repair, or electrical or mechanical adjustment.
7. The use of accessory attachments not recommended by the
manufacturer may result in injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or countertop, or touch hot
surfaces including the stove.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving fryer containing hot oil.
Always use oven mitts or hot pads.
12. Always attach plug to appliance first, then plug AC cord into the wall
outlet. To disconnect, turn control to OFF, then remove AC cord from wall outlet.
13. Do not use appliance for other than intended use.
14. Periodically check the handle for looseness. If loose, retighten the
screws using a Phillips screwdriver. CAUTION: Over tightening can result in stripping of screws or cracking of handle.
15. Use only Model #MI-10/15 magnetic cord set with this product. The use
of any other magnetic cord set may cause fire, electric shock, or injury.
16. Be sure handles are properly assembled to basket and locked in place before use. See detailed assembly instructions on page 5.
17. Do not use without oil.
18. Do not use an extension cord.
SAVE THESE INSTRUCTIONS
This appliance is for HOUSEHOLD USE ONLY. This Deep Fryer is equipped with a unique Power Cord System, which
includes a detachable magnetic cord designed to separate from the unit when certain amounts of force are applied.
A short power supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord.
No user-serviceable parts inside. Do not attempt to service this product.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to t into a polarized outlet only one way. If the
plug does not t fully into the outlet, reverse the plug. If it still
does not t, contact a qualied electrician. Do not attempt
to modify the plug in any way. If the plug ts loosely into
the AC outlet or if the AC outlet feels warm do not use
that outlet.
Welcome
Congratulations on your purchase of a Oster® Deep Fryer! Before using your Oster® Deep Fryer for the first time, remove all packaging
materials from the exterior and interior of the fryer. Make sure the fryer is unplugged. Clean the frying basket, lid and oil reservoir. Dry all parts thoroughly. See the Care and Cleaning section for details.
CAUTION: DO NOT IMMERSE THE CORD OR FRYER UNIT IN WATER OR ANY OTHER LIQUID!
2 3
CKSTDFZM37-SS1_16ESM1.indd 3-4 5/13/16 14:08
www.oster.com
www.oster.com
KNOW YOUR DEEP FRYER
BASKET HANDLE ASSEMBLY
Lid
Handle
Frying Basket
Housing
Filter Cover
Control Panel
Reset Button
Heating Elements
Oil Reservoir
PREPARING YOUR FRYER FOR USE
Prior to first use, remove all packaging materials from the exterior and interior of the fryer. Make sure the fryer is unplugged. Wash the Frying Basket and removable Oil Reservoir in hot soapy water. Gently wipe the Heating Element with a damp cloth. Dry all parts thoroughly. See the Care and Cleaning section for details.
CAUTION: Do not immerse cord, plugs or control panel assembly in water.
INSTRUCTIONS
1. Remove Handle and Frying Basket from inside the deep fryer.
2. Notice the eyelets on the interior side of the basket.
3. Squeeze the handle prongs in the middle.
4. Release the prongs into the eyelets on the interior side of the basket.
5. Press firmly down on the handle to lock in place.
TIPS FOR DEEP FRYING
• Fill the unit with oil between the maximum and minimum capacity lines only.
• Do not over fill the basket. To achieve quality results deep frying food needs to be surrounded by oil. Too much food causes the oil temperature to drop, resulting in “soggy” food. Food should be no higher than the top of the basket.
• Be sure that all ice crystals are removed from the food and food is completely dry. Excessive water and ice can cause the oil to splatter and/ or overflow.
• Coated foods (bread crumbs, batters, etc.) are best for deep frying. The coating acts as a protective layer keeping food moist on the inside and crisp on the outside.
• For best results, defrost frozen foods for 20 minutes prior to frying.
• Fry foods at the correct temperature for best results. This will prevent burning and give you even colored, crispy food.
• Prepackaged frozen, cooked chicken, may cook faster than uncooked food.
• For even cooking, shake basket half way through cooking time.
HOW TO USE YOUR DEEP FRYER
CAUTION: Never turn on the fryer with an empty Oil Reservoir. Always use
your fryer on a flat, heat resistant surface.
• Attach magnetic end of cord assembly directly to the fryer (See Figure
1). This should be done prior to plugging the cord into the wall outlet.
4 5
CKSTDFZM37-SS1_16ESM1.indd 5-6 5/13/16 14:08
www.oster.com
www.oster.com
The magnetic end of the cord is designed to only go on one way. Be sure the side stating "THIS SIDE UP" is facing up.
• Remove Frying Basket by pulling the Basket Handle up.
• Make sure the Oil Reservoir is seated in place. Pour cooking oil into Oil Reservoir until it reaches between “MIN” and “MAX” marks inside reservoir. DO NOT OVER OR UNDER FILL.
• Make sure that fryer is OFF and insert plug into 120 volt AC outlet.
• Turn fryer to desired temperature position.
• Turn Timer knob to “ON” position. Power Light will turn on.
• Ready light will turn on when oil is pre-heated. Remove the lid and place Frying Basket onto basket hook inside Oil Reservoir.
• Place food inside Frying Basket (Do not over stack food). Lower Frying Basket into Oil Reservoir. CAUTION: Always replace Lid after immersing food in oil.
• Turn timer knob to desired time.
• After time is up a bell with sound and the power and power light will turn off. Remove the lid and lift Frying Basket and hang basket onto basket hook in Oil Reservoir. To remove excess grease and retain crispness, let food drain in Frying Basket at least 10–20 seconds. Then lift Frying Basket by handle and pour contents onto plate covered with paper towels before serving.
• When finished cooking, make sure fryer is in OFF position.
WARNING: DO NOT USE THE DETACHABLE MAGNETIC CORD SYSTEM TO DISCONNECT THE FRYER. ALWAYS DISCONNECT PLUG FROM WALL OUTLET FIRST TO DISCONNECT FRYER.
Use only Model #MI-10/15 magnetic cord set with this product. The use of any other magnetic cord set may cause fire, electric shock, or injury.
CAUTION: The detachable magnetic cord is only for accidental disconnection and not to be removed during normal operation. If the cord becomes disconnected, the user should immediately unplug the cord set from the wall outlet, then reconnect the magnetic cord to the deep fryer and then to the wall outlet.
Figure 1
TO REMOVE AND REPLACE LID
• Remove Lid by pulling firmly upwards. Reverse the sequence to secure Lid from the vertical position to secure back in place.
NOTE: Always remove Lid before emptying the Oil Reservoir or cleaning. CAUTION: Ensure that Lid is in place prior to operation of unit.
FRYING TIME AND TEMPERATURE
The frying times in this chart are a guide and should be adjusted to suit the different quantities or thickness of food and to suit your own taste.
Preheat time is 7–10 minutes for fryer to reach desired temperature. (Ready light will cycle On/Off during frying as temperature fluctuates due to food load.)
Food Temp. Setting Time (minutes)
Chicken Strips 375°F/190°C 5–8 Chicken Pieces, Bone-In 360°F/180°C 15–20 Fish, Battered 340°F/170°C 8–10 French Fries, Frozen 375°F/190°C 3–5 Fritters 375°F/190°C 2–4 Onion Rings 375°F/190°C 3–5 Shrimp, Breaded 375°F/190°C 2–4
NOTE: Prepackaged frozen cooked chicken may cook faster than above time.
TIPS FOR OIL USE AND STORAGE
• Do not use seasoned or flavored oil such as walnut, olive oil, lard or drippings because they have a low smoke point. Use blended vegetable oil, pure corn oil, sunflower oil, soybean oil or grape seed oil (canola oil) because these oils have a high smoke point. Peanut oil is not recommended because it impacts the flavor greatly.
• Oils should never be mixed when deep frying.
• High heat, water and burnt food particles break down the oil’s smoke point.
6
CKSTDFZM37-SS1_16ESM1.indd 7-8 5/13/16 14:08
www.oster.com
www.oster.com
7
• Replace oil if you notice:
• Excessive smoking at normal temperatures
- Strong oil discoloration
- A rancid smell
- Excessive foaming around the frying food
• Oil darkens with use because the oil and food molecules burn when subjected to high/prolonged heat. The more you use an oil, the more slowly it will pour. Its viscosity changes because of changes to the oil’s molecular structure. When smoke appears on the oils’ surface before the temperature reaches 375°F/190°C, your oil will no longer deep-fry effectively.
• When frying foods with strong flavor and/or aroma like fish or chicken, use the oil only once.
• Filtering the oil with a cooking oil filter or fine-mesh strainer can keep it fresher. Although storing oil in a refrigerator may extend the life of the oil, this should never be done. This process of chilling oil then bringing the oil to room temperature causes excessive splattering during the heat up process.
• Store the covered oil in a cool dark place, for up to three months. Check the oil before using for color, smell, or excessive foaming. Discard the oil if it shows any of these qualities.
Problem Cause Solution
Fryer not operating
Oil spills over Oil reservoir over filled
Food greasy or not crisp
RESETTING THE OVERHEAT PROTECTION BUTTON
Resetting the Overheat Protection Reset Button may be necessary if unit will not turn on at start up (power indicator light illuminated and temperature dial set to selected temperature) or if unit appears to have stopped working during use.
1. Unplug the unit from the wall electrical outlet.
2. Allow the unit to cool down.
3. Check the oil level in your unit. If it is below the minimum level, oil should be added before resetting the unit and resuming cooking cycle.
4. Remove the control box with heater.
5. Using a narrow slotted screwdriver or pen, gently press the recessed reset button on the back of the control box, located on the lower right hand side as indicated by the arrow. (see Figure 2)
8 9
www.oster.com
Figure 2
Unpleasant smell
CARE AND CLEANING
WARNING: Always turn control to OFF then disconnect plug from wall
outlet. Remove cord from appliance.
CAUTION:
• Do not immerse cord sets in water or any liquids
• Do not attempt to defeat the detachable magnetic Cord system by trying to permanently attach cord set to product.
• Do not stick pins or other sharp objects in holes on magnetic cord set.
• Do not use any type of steel wool to clean magnetic contacts.
• Turn unit OFF.
TROUBLE SHOOTING
Not turned ON Not plugged in Outlet not energized Over heat device activated
Too much water in food Food batched too large Food batches too large Oil temperatures too low Using wrong type of oil
Oil not fresh Replace oil
www.oster.com
Turn to ON Insert plug into outlet Check fuses or circuit breaker Unplug unit and allow to
cool. Then follow the instructions in RESETTING THE OVERHEAT PROTECTION BUTTON section Remove excess oil (when cool)
Dry food with towel Use less food in basket Use less food in basket Increase oil temperature Use good vegetable oil (See TIPS FOR OIL USE AND
STORAGE)
CKSTDFZM37-SS1_16ESM1.indd 9-10 5/13/16 14:08
• Unplug from outlet and allow unit to cool completely.
• Remove magnetic cord from the fryer socket.
• Remove the Lid.
• Open the Filter Cover and remove the Filters.
• Remove Frying Basket. Wash the Frying Basket with hot soapy water. Rinse and towel dry carefully.
• Carefully lift Oil Reservoir straight up out of the exterior housing by holding the rim of the bowl. Empty cooking oil and store in an air tight container. See TIPS FOR OIL USE AND STORAGE. Oil Reservoir is dishwasher safe.
WARNING: Do not remove Oil Reservoir until the unit has cooled and is
unplugged.
• The Basket, Lid, Oil Reservoir and Housing are dishwasher safe. Dry all parts thoroughly after cleaning.
• The Control Panel should never be immersed in water or other liquids. Gently clean the outer surface of the Control Panel with a damp cloth containing mild soap solution or plain water.
• Ensure that both the Lid and Oil Reservoir are completely dry after washing and before use.
• Insert Oil Reservoir back into housing.
• Place Basket into Oil Reservoir.
• Put Filters back into Lid and put Cover on.
• Place lid on top.
REPLACING AND CLEANING FILTERS
• Open the Filter Cover, and remove filters.
• Grease Filters may be washed in hot soapy water. Rinse thoroughly and allow to air dry.
• Clean the inside of the cover with a damp soapy sponge. Rinse and dry thoroughly.
• Place clean White Grease Filter on Lid, followed by Black Charcoal Odor Filter, then replace Filter Cover.
RECIPES
APPLE FRITTERS
3 cups all-purpose flour 4 tbsp. cooking oil 2 tsp. baking powder 1 tsp. pure vanilla extract ½ tsp. salt Juice of 1 orange (¹⁄³ cup) 1 cup sugar 1 cup chopped apple 1 large egg, lightly beaten
Preheat oil to 375°F/190°C. Combine flour, baking powder, salt and sugar; set aside. Combine egg, cooking oil and vanilla. Combine dry and liquid ingredients and stir to blend thoroughly. Add orange juice and apple and mix well. Add teaspoon of combined mixture to raised frying basket. Close Lid and lower basket into oil. Fry for about 2 minutes until crisp and brown. Remove basket from oil and drain. Open Lid and place on a plate covered with paper towel to absorb the excess oil. Dust with powdered sugar or a mixture of granulated sugar and cinnamon; serve at once.
BEER BATTER FOR FISH OR CHICKEN
2 large eggs, separated ¼ tsp. ground black pepper 1 tbsp. oil or butter 1¹⁄³ cups all-purpose flour 1 tsp. salt ¾ cup flat beer
Preheat oil to 375°F/190°C. Beat egg yolks with oil/butter, salt and pepper. Alternately add the beer and flour to mixture. Beat ingredients well and refrigerate for 3–12 hours. When you are ready to use mixture, carefully fold in 2 stiffly beaten egg whites. Pat fish or boneless chicken breasts. Coat lightly with flour then dip into beer batter. Place fish or chicken in raised fryer basket. Close Lid and lower basket into oil. Fry fish for 3 minutes or until golden brown. Fry fish chicken 5–8 minutes until brown and fully cooked. Remove basket from oil and drain. Open Lid and place on a plate covered with paper towels to absorb excess oil.
10 11
CKSTDFZM37-SS1_16ESM1.indd 11-12 5/13/16 14:08
www.oster.com
www.oster.com
DEEP FRIED CHICKEN
1 fryer chicken (2½ lbs.), cut up ¼ tsp. salt 1½ cups all-purpose flour 1¼ cups milk 1 tsp. seasoned salt
Preheat oil to 375°F/190°C. Combine flour and seasonings. Dip chicken pieces in flour, then milk, then flour again. Place chicken in raised fryer basket. Close Lid and lower basket into oil. Fry for 20 minutes or until golden brown and done. Remove basket from oil and drain. Open lid and place on a plate covered with paper towels to absorb excess oil. Serve warm.
CHICKEN KIEV
4 whole boneless, skinless chicken breasts 1 stick of butter or margarine 1 tbsp. chopped onion ½ cup all-purpose flour 1 tbsp. chopped parsley 1 large egg, beaten 1¹⁄³ tsp. salt 1 cup fine, dry bread crumbs
Preheat oil to 375°F/190°C. Place chicken breasts between two pieces of plastic wrap. Pound with wooden mallet to flatten to ¼-inch thick. Remove plastic. Combine onion, parsley and salt and sprinkle on chicken. Cut butter into 8 pieces. Place a piece of butter on seasoned chicken toward one end. Roll as jelly roll, starting at end with butter, tucking in sides of meat. Press to seal well. Secure with toothpicks. Dust with flour, dip in beaten egg, then roll in bread crumbs. Chill rolls of chicken thoroughly (at least one hour). Place rolled chicken in a single layer in raised fry basket. Close Lid and lower basket into oil. Cook 5 minutes or until brown. To test for doneness, remove a piece of chicken from the oil. When fork can be inserted with ease, chicken is done. Remove basket from oil and drain. Open lid and place on a plate covered with paper towels to absorb excess oil. Serve warm.
QUICK DOUGHNUTS
Refrigerated can of biscuits ½ cup sugar 2 tbsp. ground cinnamon
Preheat oil to 375°F/190°C. Take each biscuit and flatten slightly with palm of hand. With finger, punch holes in center of each biscuit to shape into doughnuts. Place into raised frying basket. Close Lid and lower basket into oil. Fry for 2 minutes turning once. Remove basket from oil and drain. Open Lid and place on a plate covered with paper towels to absorb excess oil. Dip doughnut in mixture of cinnamon and sugar. Serve warm.
NOTES
12 13
CKSTDFZM37-SS1_16ESM1.indd 13-14 5/13/16 14:08
www.oster.com
www.oster.com
1 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of one year from the date of purchase, this product will be free from defec ts in material and workman ship. JCS, at its option , will repai r or replace this product or any component of the product found to be defective during the warranty period. Replacement will be made with a new or remanufactured p roduct or component. If the product is no longer available, replacement may be made with a similar product of equal or greater value. This is your exclusive warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty. This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service centers, or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and conditions of this warranty. This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on JCS’s Liability?
JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or statutory warranty or condition. Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for a particular purpose is limited in duration to the duration of the above warranty. JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise. JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract, fundamental or otherwise, or for any claim brought against purchaser by any other party. Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from province to province, state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A. If you have any question regarding this warranty or would like to obtain warranty service,
please call 1-800-334-0759 and a convenient service center address will be provided to you.
In Canada If you have any question regarding this warranty or would like to obtain warranty service,
please call 1-800-667-8623 and a convenient service center address will be provided to you. In the U.S.A., this warranty is oered by Sunbeam Products, Inc doing business as Jarden
Consumer Solutions located in Boca Raton, Florida 33431. In Canada, this warranty is oered by Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer S olutions, located at 20B Hereford Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection with this product, please write our Consumer Service Department.
PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
14 15
CKSTDFZM37-SS1_16ESM1.indd 15-16 5/13/16 14:08
www.oster.com
www.oster.com
PRECAUCIONES IMPORTANTES
Cuando use algún aparato eléctrico siempre deben seguirse precauciones básicas de seguridad incluyendo las siguientes:
LEA Y GUARDE ESTAS INSTRUCCIONES
1. Lea todas las instrucciones antes de usar.
2. No toque las superficies calientes. Use las manijas o las perillas.
3. Para protegerse contra incendios, descargas eléctricas y lesiones personales no sumerja el panel de control, los cables o enchufes en agua ni en ningún otro líquido.
4. Es necesario tener supervisión adulta cercana cuando se utilice la Freidora cerca de los niños. Los niños no deben utilizar este artefacto.
5. Desenchufe del tomacorriente cuando no esté en uso, antes de reubicarlo o sacarle piezas y antes de limpiarlo. Permita que se enfríe antes de ponerle o quitarle piezas, y antes de la limpieza del artefacto.
6. No opere ningún artefacto con un cable o enchufe dañados, ni después de un mal funcionamiento del artefacto, o si se ha caído o se ha dañado de alguna manera. Contacte Servicio a Clientes (vea la garantía) para devolverlo para su examen, reparación, o ajuste mecánico o eléctrico.
7. El uso de aditamentos o accesorios no recomendados por el fabricante puede causar lesiones personales.
8. No lo use a la intemperie.
9. No deje que el cable cuelgue sobre el borde de la mesa o del mostrador o que toque superficies calientes incluyendo la estufa.
10. No coloque el artefacto sobre o cerca de una hornilla caliente de gas o eléctrica, ni dentro de un horno caliente.
11. Debe tenerse extrema precaución al manipular o trasladar la freidora con aceite caliente. Use siempre guantes o agarraderas.
12. Siempre conecte el cable al artefacto primero, luego enchúfelo en el tomacorriente. Para desconectar, lleve el control a la posición OFF, después desenchúfela.
13. No use el artefacto para otros fines que no sea el concebido.
14. Periódicamente revise para asegurarse que la manigueta no se afloje. Si la manigueta se ha aflojado, asegure utilizando un desatornillador de estrella (Philips). PRECAUCION: No apriete demasiado para asegurarse de que los tornillos no se amellen.
15. Use sólo el cable magnético del Modelo # MI-10/15 con este producto. El uso de cualquier
16 17
www.oster.com
otro cable magnético puede provocar incendios, descargas eléctricas o lesiones.
16. Asegúrese que las agarraderas estén colocadas correctamente en la cesta y se bloqueen en su lugar antes de utlizar. Consulte las instrucciones detalladas de montaje en la página 19.
17. No utilice sin aceite.
18. No utilice un cable de extensión.
GUARDE ESTAS INSTRUCCIONES
Esta Unidad Es Sólo para Uso Doméstico. Esta freidora está equipada con un exclusivo Sistema de Cable Eléctrico, que incluye un cable magnético desprendible diseñado para separarse de la unidad cuando se aplica mucha fuerza. Se ha provisto un cable eléctrico corto a fin de disminuir el riesgo de que haya tropiezos o se enrede con un cable más largo. No se tiene adentro ninguna parte que el propio usuario pudiera utilizar para repararlo; por tanto no intente repararlo usted mismo.
ENCHUFE POLARIZADO
Este artefacto cuenta con una clavija polarizada (una hojilla es mas ancha que la otra). Como medida de seguridad para reducir el riesgo de descarga eléctrica, esta clavija entra sólo de
una manera en un enchufe polarizado. Si la clavija no encaja en el enchufe, simplemente colóquela al revés. Si aún así no encaja,
contacte a un electricista calicado. De ninguna manera
intente modicar esta medida de seguridad o modicar el
enchufe. Si el enchufe queda ojo en el tomacorriente o el
tomacorriente se recalienta no utilice ese tomacorriente.
Bienvenidos
¡Felicitaciones en su compra de un Freidora Oster®. Antes de usar su Freidora Oster® por primera vez, remueva todos los materiales del empaque tanto del interior como del exterior de su freidora. Asegúrese que su freidora esté desenchufada. Limpiar la Cesta para Freír, Tapa, Recipiente de Aceite, Cuerpo de la Freidora y la Trampa de Condensación (todas las partes se pueden lavar en el lava vajillas). Pase un paño húmedo al Elemento Calefactor de Zona Fría. Seque completamente todas las piezas. Vea la sección Cuidado y Limpieza para obtener más detalles.
PRECAUCIÓN: ¡NO SUMERJA EL CABLES, EL ELEMENTO CONECTOR DE POTENCIA O PANEL DE CONTROL EN AGUA O EN NINGUN OTRO TIPO DE LIQUIDO!
www.oster.com
CKSTDFZM37-SS1_16ESM1.indd 17-18 5/13/16 14:08
CONOZCA SU FREIDORA
INSTRUCCIONES DE ENSAMBLADO
Tapa
Cubierta del Filtro
Mango
Canasta de la freidora
Depósito de Aceite
Cavidad
Panel de Control
Botón de reinicio
Elementos térmicos
PREPARANDO EL USO DE SU FREIDORA
Antes de su primer uso, remueva todo material de embalaje del interior y exterior de su freidora. Asegúrese de que la freidora esté desenchufada. Lave la Canasta de la Freidora y el Depósito removible de Aceite en agua caliente jabonosa. Limpie suavemente los Elementos Térmicos con una tela húmeda. Seque todas las partes completamente. Vea la sección Cuidado y Limpieza para obtener más detalles.
PRECAUCIÓN: No sumerja el cordón, los enchufes o el panel de control en agua.
DEL MANGO DE LA CANASTA
1. Remueva el mango y la canasta freidora del interior de la Freidora.
2. Fíjese en los agujeros en la parte interior de la canasta.
3. Apriete los dientes del mango por el medio.
4. Libere los dientes dentro de los agujeros en la parte interior de la canasta.
5. Presione el mango firmemente hacia abajo para asegurar en su lugar.
CONSEJOS PARA FREÍR
• Llene la unidad con aceite solamente entre las líneas de capacidad de máximo y mínimo.
• No llene la canasta en exceso. Para obtener resultados de buena calidad, la comida que va a freír debe estar rodeada de aceite. Demasiada comida causa que la temperatura del aceite baje, lo cual resulta en comida empapada de aceite. La comida no debe pasar mas arriba de la parte superior de la canasta.
• Asegúrese de que todos los cristales de hielo hayan sido removidos de la comida y que la comida este completamente seca. El exceso de agua y de hielo pueden causar que el aceite salpique o se rebalse.
• Comidas recubiertas (con migas de pan, arrebozadas, etc.) son las que quedan mejor para freír. La capa recubierta actúa como una capa protectora, manteniendo la comida jugosa por dentro y crujiente por fuera.
• Para mejores resultados, deshiele la comida 20 minutos antes de freír.
• Fría las comidas a la temperatura correcta para obtener mejores resultados. Esto evitará que su comida se queme y permitirá que tenga un color parejo y que esté crujiente.
• El pollo precocido, empacado y congelado, puede cocinarse mejor que la comida no cocida.
• Para un cocido parejo, sacuda la canasta a la mitad del tiempo de cocción.
CÓMO UTILIZAR SU FREIDORA
PRECAUCIÓN: Nunca encienda la freidora con el depósito para aceite vacío.
Siempre utilice su freidora sobre un a superficie plana y resistente al calor.
18 19
CKSTDFZM37-SS1_16ESM1.indd 19-20 5/13/16 14:08
www.oster.com
www.oster.com
• Conecte el extremo magnético del cable directamente a la freidora (Ver Figura 1). Esto debe hacerse antes de conectar el cable al tomacorriente. El extremo magnético del cable está diseñado para entrar de una sola manera. Asegúrese de que el lado que dice "THIS SIDE UP" quede hacia arriba.
• Remueva la canasta de la Freidora jalando el mango de la canasta hacia arriba.
• Asegúrese de que el depósito de aceite esté posado en su lugar. Vierta aceite de cocina en el depósito de aceite hasta que quede entre las marcas de MIN y MAX dentro del depósito. No llene en exceso o de menos.
• Asegúrese de que la freidora esté Apagada (OFF) e introduzca el enchufe en un tomacorriente AC de 120 voltios.
• Gire la freidora a la posición deseada de temperatura.
• Gire el botón del Marcador de Tiempo a la posición de Encendido (ON). La luz indicadora de corriente se encenderá.
• La luz de Listo se encenderá cuando el aceite esté precalentado. Retire la tapa y coloque la canasta freidora en el gancho para la canasta dentro del depósito de aceite.
• Coloque la comida dentro de la canasta freidora (no ponga la comida en demasiadas capas). Baje la canasta freidora en el depósito de aceite. PRECAUCIÓN: Siempre coloque la tapa después de sumergir la comida en aceite.
• Gire el Marcador de tiempo al tiempo deseado.
• Una vez que el tiempo haya transcurrido se oirá una campana y la corriente y la luz de corriente se apagarán. Retire la tapa y levante la canasta freidora y cuelgue la canasta del gancho para canasta en el depósito de aceite. Para remover el exceso de grasa y mantener la comida crujiente, deje que la comida drene en la canasta freidora por lo menos de 10 a 20 segundos. Luego levante la canasta freidora por el mango y vierta el contenido en un plato que esté previamente cubierto con papel toalla antes de servir.
• Cuando haya terminado de cocinar, asegúrese de que la Freidora esté en la posición de apagado (OFF).
ADVERTENCIA: NO USE EL SISTEMA DE CABLE MAGNÉTICO DESPRENDIBLE PARA DESCONECTAR LA FREIDORA. DESCONECTE SIEMPRE EL ENCHUFE DE LA PARED PARA DESCONECTAR LA FREIDORA.
20 21
www.oster.com
Figura 1
Use el cordón magnético Modelo #MI-10/15 con este producto. El uso de cualquier otro cordón magnético podría causar fuego, choque eléctrico o lesión.
PRECAUCION: El cable magnético desprendible es sólo para una desconexión accidental y no debe ser desconectado durante el funcionamiento normal. Si el cable se desconecta, el usuario debe desconectar inmediatamente el cable del enchufe de la pared y a continuación, volver a conectar el cable magnético a la freidora y luego al tomacorriente.
PARA REMOVER Y REEMPLAZAR LA TAPA
• Retire la tapa jalando firmemente hacia arriba. Reverse la secuencia para asegurar la tapa en la posición vertical para asegurarla de vuelta en su lugar.
NOTA: Siempre remueva la Tapa antes de vaciar el Depósito de Aceite o antes de limpiar.
PRECAUCIÓN: Asegúrese de que la Tapa esté en su lugar antes de operar la unidad.
TIEMPOS PARA FREÍR Y TEMPERATURA
Los tiempos para freír en este cuadro son una guía y deben ser ajustados de acuerdo a las diferentes cantidades o grosores de los alimentos y de acuerdo a su propio gusto.
El tiempo de precalentamiento para que la freidora alcance la temperatura deseada es de 7–10 minutos. (Al empezar a freírse, la Luz indicadora de Listo va a moverse On/Off mientrás la temperatura fluctúa debido a que se están metiendo los alimentos.)
Alimento Graduación Temp. Tiempo (minutos)
Tiras de Pollo 375°F/190°C 5–8 Piezas de Pollo, con Hueso 360°F/180°C 15–20 Pescado, Recubierto 340°F/170°C 8–10 Papas Fritas, Congeladas 375°F/190°C 3–5 Buñuelos 375°F/190°C 2–4 Aros de Cebollas 375°F/190°C 3–5 Langostinos, empanados 375°F/190°C 2–4
www.oster.com
CKSTDFZM37-SS1_16ESM1.indd 21-22 5/13/16 14:08
NOTA: Pollos cocinados, congelados y preempacados se cocinan más rápidamente que los tiempos anteriores indicados.
REINICIO DEL BOTÓN DE PROTECCIÓN
CONSEJOS PARA EL USO Y ALMACENAJE DEL ACEITE
• No use aceites con sazones o saborizados tales como aceite de nueces, aceite de oliva, manteca o grasa debido a que tienen un punto de humeado bajo. Utilice aceite vegetal, aceite puro de maíz, aceite de girasol, aceite de soya o aceite de canola debido a que estos aceites tienen un punto de humeado alto. No se recomienda aceite de maní/ cacahuate debido a que afecta el sabor tremendamente.
• Nunca mezcle aceites cuando fría.
• El calor alto, el agua y las partículas de comida quemada cortan el punto de humeado del aceite.
• Reemplace el aceite si usted nota:
• Humo excesivo a temperaturas normales
- Pronunciado descoloramiento del aceite
- Olor rancio
- Exceso de espuma alrededor de la comida frita
• El aceite se oscurece con el uso debido a que las moléculas del aceite y la comida se queman cuando son sujetas a altas y prolongadas temperaturas. Cuanto más use el aceite, más despacio se rociará. La viscosidad del aceite cambia debido al cambio en la estructura molecular del aceite. Cuando el humo aparece en la superficie del aceite antes de que la temperatura alance los 375ºF/190ºC, su aceite ya no freirá efectivamente.
• Cuando fría comidas que tengan un sabor o aroma fuertes como pescado o pollo, use el aceite sólo una vez.
• Filtrar el aceite con un filtro para aceite de cocina o un colador fino puede mantener el aceite más fresco. Aunque guardar el aceite en la refrigeradora podría extender la vida del aceite no le recomendamos que lo haga. Este proceso de enfriar el aceite para después llevarlo a temperatura ambiente causa un salpicado excesivo durante el proceso de calentamiento.
• Guarde el aceite cubierto en un lugar frío y oscuro por no más de tres meses. Revise el cambio en el color u olor, o espuma excesiva en el aceite antes de usar. Deseche el aceite si muestra alguna de estas características.
POR SOBRECALENTAMIENTO
Puede ser necesario que tenga que fijar el botón de protección de sobrecalentamiento, si la unidad no opera al inicio (la luz indicadora de corriente estará iluminada y el disco de la temperatura fijado a la temperatura seleccionada) o si la operación de la unidad parece haberse detenido durante el uso.
1. Desenchufe la unidad del tomacorriente de la pared.
2. Deje que la unidad enfríe.
3. Cheque el nivel de aceite en su unidad. Si está por debajo del nivel mínimo, añada aceite antes de volver a fijar la unidad y empezar el ciclo de cocido.
4. Remueva la caja de control con el elemento calentador.
5. Usando un desarmador delgado o lapicero, presione suavemente el botón de reinicializar en la parte trasera de la caja de control, localizado en la parte inferior derecha como se indica con la flecha (Vea la Figura 2).
SOLUCIÓN DE PROBLEMAS
Problema Causa Solución
La Freidora no está funcionando
No se encendió (ON) No enchufado en
tomacorriente con electricidad
Aparato de sobrecalentamiento activado
Figura 2
Prender (ON) Enchufar en tomacorriente Revisar fusibles o circuitos
eléctricos e interruptores Desenchufe la unidad y deje
enfriar. Luego siga las instrucciones de la sección de REINICIO DEL BOTÓN DE PROTECCIÓN POR SOBRECALENTAMIENTO
22 23
CKSTDFZM37-SS1_16ESM1.indd 23-24 5/13/16 14:08
www.oster.com
www.oster.com
Aceite salpicando
Alimento grasoso o no crocante
Olor desagradable
Recipiente con exceso de aceite
Mucha agua dentro del alimento
Comida en lotes demasiado grandes Trozos de alimentos muy largos
Temperatura del aceite muy baja
Usando tipo de aceite inadecuado
Aceite no fresco Reemplazar el aceite
Remover exceso de aceite (cuando esté frío)
Secar el alimento con toalla de papel
Use menos comida en la canasta Poner menos alimento en la Cesta
Incrementar la temperatura del aceite
Usar buen aceite vegetal (vea CONSEJOS PARA EL USO Y ALMACENAJE DEL ACEITE)
CUIDADO Y LIMPIEZA
ADVERTENCIA: Siempre gire el control a Apagado (OFF) y luego desconecte
el enchufe del tomacorriente de pared. Retire el cordón del aparato.
PRECAUCIÓN:
• No sumerja el conjunto de cables en agua o cualquier otro líquido.
• No mantenga conectado permanentemente el sistema removible de cable magnético de potencia al producto.
• No clave pinzas u objetos afilados dentro de los huecos del conjunto de cables magnéticos.
• No use ningún tipo de esponjas de alambre para limpiar los contactos magnéticos.
• Apague la unidad.
• Desenchufe del tomacorriente y permita que la unidad se enfríe completamente.
• Remueva el cordón magnético de Liberado Seguro del enchufe de la Freidora.
• Remueva la Tapa.
• Abra la cubierta del Filtro y remueva el filtro.
• Retire la Cesta de Freir. Lave la Cesta de Freir. con agua caliente jabonosa. Enjuague y seque cuidadosamente.
• Levante con cuidado el Depósito de Aceite hacia arriba y fuera de la freidora agarrándolo por el borde del recipiente. Saque el aceite y guárdelo en un envase hermético. Vea CONSEJOS PARA EL USO Y ALMACENAJE DEL ACEITE. El Depósito del Aceite es apto para el lavaplatos.
ADVERTENCIA: No remueva el Depósito de Aceite hasta que la unidad
se haya enfriado y esté apagada.
• La canasta, tapa , depósito de aceite y cubierta pueden lavarse en el lavaplatos. Seque todas las partes minuciosamente después de lavar.
• Nunca sumerja en agua u otro líquido el panel de control. Limpie suavemente el exterior del panel de control con una tela húmeda que contenga unas solución de jabón suave o solamente agua.
• Asegúrese de que ambos, la Tapa y el Depósito de Aceite, estén completamente secos luego de lavar y antes de usar.
• Introduzca el Depósito de Aceite de vuelta en la cavidad.
• Coloque la Canasta en el Depósito de Aceite.
• Coloque los filtros de vuelta en la Tapa y coloque la cubierta.
• Coloque la tapa en la parte superior.
REEMPLAZANDO Y LIMPIANDO LOS FILTROS
• Abra la cubierta del filtro y remueva los filtros.
• Los filtros para grasa pueden lavarse con agua caliente jabonosa. Enjuague minuciosamente y deje secar al aire.
• Limpie el interior de la cubierta con una esponja húmeda y jabón. Enjuague y seque completamente.
• Coloque el Filtro de Grasa Blanco en la Tapa, seguido por el Filtro Negro para el Olor de Carbón y luego coloque de vuelta la Cubierta del Filtro.
24 25
CKSTDFZM37-SS1_16ESM1.indd 25-26 5/13/16 14:08
www.oster.com
www.oster.com
RECETAS
BUÑUELOS DE MANZANA
3 tazas de harina para todo uso 4 cdas. de aceite para freir 2 cditas. de polvo de hornear 1 cdita. de extracto de vainilla ½ cdita. de sal Jugo de Naranja (¹⁄³ de taza) 1 taza de azúcar 1 taza de trocitos de manzana 1 huevo, ligeramente batido
Precalentar el aceite a 375ºF. Combine la harina, polvo de hornear, sal y azúcar, ponga aparte. Combine el huevo, aceite y la vainilla. Mezcle muy bien los ingredientes secos y líquidos. Agregue el jugo de naranja y la manzana y mezcle nuevamente. Con una cucharadita vaya echando la mezcla dentro del aceite caliente (la Cesta ya debe estar bajada dentro del aceite). Fría alrededor de 2 minutos o hasta que estén crocantes y bastante dorados. Remueva de la grasa y escurra. Espolvoree con azúcar en polvo o con una mezcla de azúcar granulada y canela; sirva inmediatamente.
MEZCLA PARA PESCADO O POLLO A BASE DE CERVEZA
2 huevos, separados ¼ cdita. pimienta negra molida 1 cda. de aceite o mantequilla 1¹⁄³ taza de harina para todo uso 1 cdita. de sal ¾ taza de cerveza
Precalentar el aceite a 375ºF. Bata las yemas de huevo con aceite/ mantequilla, sal y pimienta. Agregue alternadamente la cerveza y la harina a la mezcla. Bata bien los ingredientes y refrigérelas de 3 a 12 horas. Cuando usted esté lista para usar la mezcla, cuidadosamente agregue con movimientos envolventes las 2 claras de huevo batidas a punto de nieve. Aplaste un poco el pescado o las pechugas de pollo sin huesos. Cubra ligeramente con harina y después con la mezcla de cerveza. Coloque el pescado en el aceite caliente (la Cesta ya debe estar bajada dentro del aceite) y fría por 3 minutos o hasta que estén dorados. Fría el pollo de 5 a 8 minutos o hasta que esté dorado y completamente cocido.
POLLO FRTIO EN INMERSIÓN
1 Pollo para freir (2 ½ lbs.), cortado en trozos ¼ cditas de sal 1½ tazas de harina para todo uso 1¼ de taza de leche 1 cdita. de sal sazonada
Precalentar el aceite a 375ºF. Combine la harina y los aderezos secos. Pase las piezas de pollo por harina, luego leche y harina nuevamente. Fría por 20 min. o hasta que se doren y estén cocidos.
POLLO A LA KIEV
4 pechugas enteras de pollo deshuesadas y sin piel 1 barrita de mantequilla o margarina 1 cda. de cebolla picadita ½ taza de harina 1 cda. de perejil picadito 1 huevo, batido 1¹⁄³ cdita de sal 1 taza de pan rallado fino
Precalentar el aceite a 375ºF. Coloque las pechugas de pollo entre dos pedazos de papel de envoltura de plástico. Golpéelas con un mazo de madera para aplanarlas hasta ¼ de pulgada de grosor. Quite el plástico. Combine cebolla, perejil y sal y espolvoree sobre el pollo. Corte la mantequilla en 8 trozos. Coloque cada trozo de mantequilla sobre un extremo de pechuga sazonada. Enrolle como si fuera un rollo de mermelada, comenzando por el extremo con mantequilla, metiendo los bordes de la carne. Apriete bien para sellar. Asegúrelos con palillos de dientes. Espolvoree con harina, remoje en el huevo batido, después ruédelo sobre el pan rallado. Refrigere los rollitos de pollo (por lo menos 1 hora). Colóquelos en una camada dentro de la cesta de freír. Baje la cesta y cocine por 5 minutos o hasta que doren. Para probar si están listos, remueva del aceite un pedazo de pollo. Cuando el tenedor entra con suavidad, el pollo ya está listo.
ROSQUIL LAS RÁPIDAS
Lata de galletas refrigeradas ½ taza de azúcar 2 cdas. de canela molida
Precalentar el aceite a 375ºF. Agarre cada galleta y aplástela suavemente con la palma de la mano. Con el dedo, oprímale un hueco en el centro de cada galleta para obtener la forma de rosquillas. Fría 2 minutos, volteándolas una vez. Remuévalas del aceite y séquelas con papel toalla. Espolvoree con una mezcla de azúcar y canela. Sirva caliente.
26 27
CKSTDFZM37-SS1_16ESM1.indd 27-28 5/13/16 14:08
www.oster.com
www.oster.com
NOTAS NOTAS
28 29
CKSTDFZM37-SS1_16ESM1.indd 29-30 5/13/16 14:08
www.oster.com
www.oster.com
Garantía Limitada de 1 Año
Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions, o en Canadá, Sunbeam Corporation (Canada) Limited operando bajo el nombre de Jarden Consumer Solutions, (en forma conjunta, “JCS”), garantiza que por un período de un año a partir de la fecha de compra, este producto estará libre de defectos de materiales y mano de obra. JCS, a su elección, reparará o reemplazará este producto o cualquier componente del mismo que presente defectos durante el período de garantía. El reemplazo se realizará por un producto o componente nuevo o reparado. Si el producto ya no estuviera disponible, se lo reemplazará por un producto similar de valor igual o superior. Ésta es su garantía exclusiva. No intente reparar o ajustar ninguna función eléctrica o mecánica de este producto. Al hacerlo elimínará ésta garantía.
La garantía es válida para el comprador minorista original a partir de la fecha de compra inicial y la misma no es transferible. Conserve el recibo de compra original. Para solicitar servicio en garantía se requiere presentar un recibo de compra. Los agentes y centros de servicio de JCS o las tiendas minoristas que venden productos de JCS no tienen derecho a alterar, modicar ni cambiar de ningún otro modo los términos y las condiciones de esta garantía.
Esta garantía no cubre el desgaste normal de las piezas ni los daños que se produzcan como resultado de uso negligente o mal uso del producto, uso de voltaje incorrecto o corriente inapropiada, uso contrario a las instrucciones operativas, y desarme, reparación o alteración por parte de un tercero ajeno a JCS o a un Centro de Servicio autorizado por JCS. Asimismo, la garantía no cubre actos fortuitos tales como incendios, inundaciones, huracanes y tornados
¿Cuál es el límite de responsabilidad de JCS?
JCS no será responsable de daños incidentales o emergentes causados por el incumplimiento de alguna garantía o condición expresa, implícita o legal.
Excepto en la medida en que lo prohíba la ley aplicable, cualquier garantía o condición implícita de comerciabilidad o aptitud para un n determinado se limita, en cuanto a su duración, al plazo de la garantía antes mencionada.
JCS queda exenta de toda otra garantías, condiciones o manifestaciones, expresa, implícita, legal o de cualquier otra naturaleza.
JCS no será responsable de ningún tipo de daño que resulte de la compra, uso o mal uso del producto, o por la imposibilidad de usar el producto, incluidos los daños incidentales, especiales, emergentes o similares, o la pérdida de ganancias, ni de ningún incumplimiento contractual, sea de una obligación esencial o de otra naturaleza, ni de ningún reclamo iniciado contra el comprador por un tercero.
Algunas provincias, estados o jurisdicciones no permiten la exclusión o limitación de los daños incidentales o emergentes ni las limitaciones a la duración de las garantías implícitas, de modo que
es posible que la exclusión o las limitaciones antes mencionadas no se apliquen en su caso. Esta garantía le otorga derechos legales especícos y es posible que usted tenga otros derechos que
varían de un estado, provincia o jurisdicción a otro.
Cómo solicitar el servicio en garantía
En los Estados Unidos Si tiene alguna pregunta sobre esta garantía o desea recibir servicio de garantía, llame al
1-800-334-0759 y podrá obtener la dirección del centro de servicio que le resulte más conveniente. En Canadá Si tiene alguna pregunta sobre esta garantía o desea recibir servicio de garantía, llame al
1-800-667-8623 y podrá obtener la dirección del centro de servicio que le resulte más conveniente. En los Estados Unidos, esta garantía es ofrecida por Sunbeam Products, Inc. operando bajo el
nombre de Jarden Consumer Solutions, Boca Ratón, Florida 33431. En Canadá, esta garantía es ofrecida por Sunbeam Corporation (Canada) Limited operando bajo el nombre de Jarden Consumer Solutions, 20 B Hereford Street, Brampton, Ontario L6Y 0M1. Si usted tiene otro problema o reclamo en conexión con este producto, por favor escriba al Depar tamento de Servicio al Consumidor.
POR FAVOR NO DEVUELVA ESTE PRODUCTO A NINGUNA DE ESTAS DIRECCIONES NI AL LUGAR DE COMPRA.
30 31
CKSTDFZM37-SS1_16ESM1.indd 31-32 5/13/16 14:08
www.oster.com
www.oster.com
Loading...
