ORU - Traction Bars
Bill of Materials, P/N 79100
Part # Qty. Description
79100-1
79100-2
79100-3
79100-4
79100-5
79100-6
79100-7
79100-8
2
2
2
2
2
2
4
1
traction bar
traction bar slider
axle bracket
frame bracket
dust boot
steel side plates
threaded poly rod end
hardware pkg.
contents:
(6) 9/16” greasable bolts w/washers & lock nuts
(8) 3/8” x 11/4” bolts w/washers & lock nuts
(4) 5/16” x 1“ bolts w/washers & lock nuts
(4) 11/4” jam nuts
(1) small assembly lube
(6) poly flex joint internal assembly components
Grade 8 nut torque specifications
STANDARD METRIC
5
/16" nuts
3
/8" nuts
7
/16" nuts
1
/2" nuts
9
/16" nuts
5
/8" nuts
20 ft. lbs. M6
35 ft. lbs.
60 ft. lbs.
90 ft. lbs.
160 ft. lbs.
175 ft. lbs.
offroadunlimited.com
page 1
M8
M10
M12
M14
M16
9 ft. lbs.
23 ft. lbs.
45 ft. lbs.
75 ft. lbs.
120 ft. lbs.
165 ft. lbs.
ORU - Traction Bars
INSTALLATION NOTES:
• Inspect the contents of the kit and read the entire instructions before proceeding.
• We recommend this installation be performed by a qualified technician.
• Torque all hardware to factory specifications.
• We recommend using red Loctite on all bolts.
• When removing wheels, support vehicle with jack stands.
1) Apply assembly lube and use vise or press to assemble poly flex joint internal components
into six end joints as shown (see photo 1).
2) Install jam nut onto each end. Install threaded ends into bars leaving no more than 1” of
exposed threads (see photo 2).
3) Apply assembly lube, install boot, and insert slider rod into traction bar ends leaving 2” of
exposed slider (see photo 3).
4) Position axle brackets between u-bolts as shown and mark location. Clean axle surface for
welding (see photo 4).
5) Tack weld axle brackets in position and fully weld on inside only (see photo 5).
6) After welds have cooled, set traction bar temporarily in place using both axle bolts (see photo 6).
7) With weight on the vehicle, using a 9/16” bolt for locating, place frame bracket on slider
and adjust threaded axle pivots until the frame bracket rests on frame (see photo 7).
8) Mark and drill the 3/8” & 9/16” holes, bolt frame brackets in place (photo 8 & 9).
9) Install side trim plates. Tighten all hardware to specifications. Lube all greasable bolts and
the 2 fittings for each slider. Note: the slider grease fittings only require a small amount of
grease. Example: 4-5 pumps from a manual grease gun.
offroadunlimited.com
page 2
ORU - Traction Bars
photo 1 photo 2 photo 3
Boot removed in photo for clarity.
photo 4 photo 5 photo 6
2"
photo 7 photo 8 photo 9
WARRANTY POLICY
ORU (Off Road Unlimited), extends a lifetime warranty on their products to the original purchaser. The warranty covers defects in material and
workmanship. This warranty does not apply to wear items such as brakes, steering components, u-joints, etc., or to products sold by, but not
manufactured by ORU. Application of this warranty is subject to inspection of the product by ORU and at their sole discretion. ORU is not
responsible for shipping charges incurred to submit product for inspection, or its return if the warranty is declined. This warranty does not cover
parts that have been modified, applied outside of the intended application, or subjected to abuse. This warranty applies solely to the ORU product
and does not extend to any incidental damage(s) or incurred cost(s). No other warranties/guarantees are expressed or implied. All warranty claims
must be accompanied by the original receipt, or reasonable facsimile. To apply for warranty consideration, contact the ORU customer service
department at 818-563-1208.
