ORU 70030-F User Manual

ORU- Dana 60 Axle Crossover Steering System

Bill of Materials, P/N 70030-E&F

Part# Qty. Description
70030-E Kit (92-94 Ford F-350, 6-12" lift, Dana 60 w/"slider type" caliper mount):

70031-B 1 Pitman arm
60032 1 Upper tie rod
60033 1 Lower tie rod
60034L 1 LH jam nut
60034R 1 RH jam nut
60036-EC 1 Knuckle (slider mount)
60038-C 1 28" drag link
90004 1 Anti-seize

70030-F Kit, (95-97 Ford F-350, 6-12" lift, Dana 60, w/"bolt-on" type caliper mount):

70031-B 1 Pitman arm
60032 1 Upper tie rod
60033 1 Lower tie rod
60034L 1 LH jam nut
60034R 1 RH jam nut
60036-FC 1 Knuckle (bolt-on mount)
60038-C 1 28" drag link
90004 1 Anti-seize

Grade 8 nut torque specifications
5/16" nuts 20 ft. lbs. M6 nuts 9 ft. lbs.
3/8" nuts 35 ft. lbs. M8 nuts 23 ft. lbs.
7/16" nuts 60 ft. lbs. M10 nuts 45 ft. lbs.
1/2" nuts 75 ft. lbs. M12 nuts 75 ft. lbs.
9/16" nuts 160 ft. lbs. M14 nuts 120 ft. lbs.
5/8" nuts 175 ft. lbs. M16 nuts 165 ft. lbs.

offroadunlimited.com

page 1
