ORU - Excursion Ford Super Duty Multiple Shock Hoops
Bill of Materials, P/N 70020
Part # Qty. Description
70020-1
70020-2
70020-3
70020-HP
1
1
2
1
driver side shock hoop
passenger side shock hoop
lower shock mounting plate
hardware pkg. contaning:
(12) 1/2" x 1-1/2" bolt
(4)1/2" x 7" bolts
(14)1/2" lock nuts
(30) 1/2" flat washers
(2)1/2" tab nuts
(2)1/2" ID x 1-1/2" long steel sleeves
Grade 8 nut torque specifications
STANDARD METRIC
5
/16" nuts
3
/8" nuts
7
/16" nuts
1
/2" nuts
9
/16" nuts
5
/8" nuts
ORU (Off Road Unlimited), extends a lifetime warranty on their products to the original purchaser. The warranty covers defects in material and
workmanship. This warranty does not apply to wear items such as brakes, steering components, u-joints, etc., or to products sold by, but not
manufactured by ORU. Application of this warranty is subject to inspection of the product by ORU and at their sole discretion. ORU is not
responsible for shipping charges incurred to submit product for inspection, or its return if the warranty is declined. This warranty does not cover
parts that have been modified, applied outside of the intended application, or subjected to abuse. This warranty applies solely to the ORU product
and does not extend to any incidental damage(s) or incurred cost(s). No other warranties/guarantees are expressed or implied. All warranty claims
must be accompanied by the original receipt, or reasonable facsimile. To apply for warranty consideration, contact the ORU customer service
20 ft. lbs. M6
35 ft. lbs.
60 ft. lbs.
90 ft. lbs.
160 ft. lbs.
175 ft. lbs.
WARRANTY POLICY
department at 818-563-1208.
offroadunlimited.com
M8
M10
M12
M14
M16
page 1
9 ft. lbs.
23 ft. lbs.
45 ft. lbs.
75 ft. lbs.
120 ft. lbs.
165 ft. lbs.
ORU - Early Ford Super Duty Multiple Shock Hoops
P/N 70020
INSTALLATION NOTES:
• Inspect the contents of the kit and read the entire instructions before proceeding.
• We recommend this installation be performed by a qualified technician.
• Torque all hardware to factory specifications.
• We recommend using red Loctite on all bolts.
1) Block rear wheels and raise front of vehicle. Support with jack stands. Remove front wheels.
2) Remove both front shocks and upper mounts.
3) Using a floor jack, support the passenger side front spring. Remove the u-bolt nuts and lower
shock mounting plate. Install the new lower shock mounting plate and tighten the u-bolts to
specifications.
4) Place the driver side shock hoop (the one with the angle-cut mounting plate) against the frame
and align the lower rear center mounting plate hole with the lower rear mounting hole from
the factory upper shock mount. Install one 1/2" bolt with washers and nut. Using the plate as a
guide, drill the remaining 3 holes out to 1/2" (see photo 1).
5) Using the hoop as a guide, drill the mounting leg holes to 1/2" and secure with 1/2" hardware.
The front leg will require the use of the 1/2" tab nut (see photo 2).
6) Tighten all hardware to specifications.
7) Install shock absorbers. Use flat washers and spacer on lower mounts (see diagram 1).
8) Repeat steps on opposite side of vehicle.
9) Re-install wheels, re-check all bolts, tighten to specifications.
offroadunlimited.com
page 2
ORU - Early Ford Super Duty Multiple Shock Hoops
P/N 70020
photo 1 photo 2
HEAVY WASHER
LOCK NUT
FACTORY MOUNT
SHOCK SHOCK
STEEL SPACER
offroadunlimited.com
page 3
HEAVY WASHER
7" BOLT
