INTRODUCTION

Thank you for selecting the Oregon ScientiﬁcTM Tap On

Pro Heart Rate Monitor (SE188) watch as your sports

ﬁtness product of choice. This device includes the following

features:

• Heart rate monitor with cordless transmission between watch and chest belt.

• Digital coding system to reduce environmental interference.

• Heart rate monitoring system when you go above or below your upper and lower heart rate limit.

• Visual or sound alert for heart rate thresholds during training.

• Memory stores heart rate ﬁgures during exercise.

• SMART TRAINING PROGRAM enables you to complete exercise cycles effectively.

• Tap on lens to conveniently view exercise data.

• Calorie consumption and percent fat burn display during and after exercise.

• Exercise proﬁle - to calculate your personal heart rate limit for training.

• User proﬁle - to calculate your ﬁtness index and body mass index (BMI).

• Stopwatch.

• 99 lap memory storage showing average heart rate and maximum heart rate.

• Dual alarms with a choice of daily, weekday or weekend settings.

• Mounting bracket, chest belt and carrying case included.

• Watch - up to 50 metres water resistant.

• Chest belt - splash proof.

IMPORTANT The use of the SE188 watch is for sport

purposes only and it is not meant to replace any medical device.

KEY FEATURES

WATCH

1. MEM / LAP / - : Display training records; decrease

setting value; mark a lap.

2. MODE: Switch to another display.

3. ST / SP / +: Start / stop timer; increase setting value. 4

/ : Turn on backlight for 3 seconds; lock / unlock

the keypad.

5. SET: Enter Setting Mode; select another setting option;

display different information during training; reset timer / stopwatch.

LCD DISPLAY

1. Area 1

2. Area 2

3. Area 3

Area 1

1. TIMER: Smart Training Program is shown or running.

2. TTL: Total exercise time is displayed.

4. LAP: Shows current lap time or memory lap time.

5. SPLIT: Shows and calculates split time.

6. WARM: Warm-up timer is shown or running.

7. STW: Stopwatch is shown or running.

9. REST: Recovery timer is shown or running.

: Keypad lock is enabled.

: Keypad tone is disabled.

Area 2

1. MM:DD or DD: MM and day of the week; stopwatch time.

4. kcal: Calorie unit.

Area 3

1. Time - HH:MM.

2. AM/PM: Appears when the 12-hour clock / alarm is

3. AVG: Average heart rate is displayed.

4. MAX: Maximum heart rate is displayed.

/ : Alarm 1 and 2; waves show when alarm is

activated.

: Cursor highlights the selected alarm in Alarm

Mode.

: Light Mode is enabled.

: Tap on lens is enabled.

being used.

: Heart rate is above or below limit; sound alert is

activated.

6. : Flashes when receiving heart rate signal.

7. kglbs: Body weight unit.

8. % FAT: Percentage of fat burn.

9. CM Yr: Height unit; year of user’s birth.

10. LAP: Take lap; lap number.

11. MEM: Stopwatch or timer memory is shown.

12.

: Battery status.

GETTING STARTED

UNPACKING THE WATCH

When you unpack your watch, make sure to keep all the packing materials in a safe place, in case you need to later transport or return the product for servicing.

In this box, you will ﬁnd:

• Watch

• Heart rate chest belt

• Mounting bracket

• Carry case

• 2 x CR2032 lithium batteries - already installed

TURNING ON THE WATCH (FIRST-TIME USE ONLY)

Press any key for 2 seconds to activate the LCD display.

SETTING THE KEYPAD TONE / LIGHT MODE / TAP ON LENS

You can set the watch to have the:

• Keypad “Beep” tone ON or OFF.

• Light Mode ON or OFF - see “Activating the Backlight” section.

• Tap On Lens ON or OFF- see “Tap On Lens” section.

To set these features:

1. Press MODE to navigate to the Real-Time Clock Mode.

2. Press SET repeatedly until you reach the feature you

wish to change.

3. Press ST / SP / + or MEM / LAP / - to change the

setting.

4. Press SET to conﬁrm the setting and move on to the

next one.

ACTIVATING THE BACKLIGHT

When the Light Mode is set to OFF:

• Press to turn on the backlight for 3 seconds. Press any other key whilst the light is on and it will extend the light time by another 3 seconds.

When the Light Mode is set to ON:

• Press any key to turn ON or extend the backlight for 3 seconds.

To help conserve power the Light Mode ON setting will automatically switch to OFF after 2 hours.

NOTE The backlight does not work when the low battery icon is shown and will return to normal once the batteries are replaced.

ACTIVATING THE KEYPAD LOCK

To turn the keypad lock ON or OFF:

• Press and hold for 2 seconds. will appear on the display when the keypad lock is on.

appears when the tap on lens is activated and ﬂashes

when the preset display is shown.

TAP ON LENS

The tap on lens feature gives you easy access to 1 of 6 preset modes:

• Heart rate (HR)

• Stopwatch (STW)

• Smart Training Program (SMART)

• Calorie measurement (CAL)

• Lap timer (LAP)

• Time

To set the tap on lens preset mode:

1. In clock mode, press SET repeatedly until you reach the tap on lens “ON” display.

2. Press and hold SET to enter the preset modes selection.

3. Press ST / SP / + or MEM / LAP / - to select the preset mode.

4. Press SET to conﬁrm.

To use the tap on lens:

Simply tap on the lens and your preset mode will display for 10 seconds before returning to the previous screen.

SWITCHING BETWEEN OPERATION MODES

Press MODE to switch between the 5 operation modes:

• Real-Time Clock

• Alarm Clock

• User Proﬁle / Exercise Proﬁle

• Timer - SMART TRAINING PROGRAM

• Stopwatch The modes are described in the sections that follow.

NOTE You can run the SMART TRAINING PROGRAM or stopwatch in the background as you access other modes. The icon for the mode that is running will ﬂash until you switch back to that mode.

USING THE CLOCK

The real-time clock is the default display for the watch. To set the real-time clock:

1. Press MODE to switch to Real-Time Clock Mode.

2. Press and hold SET until the ﬁrst setting ﬂashes.

3. Press ST / SP / + or MEM / LAP / - to change the setting. Hold to speed through the options. Press SET

to conﬁrm the setting and move on to the next one.

4. Repeat step 3 to change other settings for this mode.

The order of the real-time clock settings is:

• 12 / 24 hour clock format

• Hour

• Minute

• Year

• DD:MM or MM:DD date format

• Month

• Day

To set alarm 1 or alarm 2:

1. Press MODE to navigate to Alarm Clock Mode.

2. Press SET to move the cursor to select alarm 1 or alarm 2 and ST / SP / + or MEM / LAP / - to activate deactivate

3. Press and hold SET to enter the setting mode for the chosen alarm.

the alarm.

NOTE The clock is programmed with a 50-year autocalendar, which means you do not need to reset the days of the week and dates each month.

USING THE ALARM(S)

SETTING THE ALARM(S)

Your watch has 2 alarms that can be set to activate daily (Mon-Sun), on a weekday (Mon-Fri), or on a weekend (Sat / Sun).

4. Press ST / SP / + or MEM / LAP / - to change the setting. Hold to speed through the options. Press SET

to conﬁrm the setting and move on to the next one.

5. Repeat step 4 to change other settings for this mode.

6. The alarm will automatically be activated once you have ﬁnished setting the alarm time.

The order of the alarm clock settings is:

• Select daily, weekday or weekend alarm

• Hour

• Minute

TURNING THE ALARM SOUND OFF

Press any key to turn the alarm sound off. The alarm will automatically reset itself unless you deactivate it.

ACTIVATING / DEACTIVATING THE ALARM

1. Press MODE to navigate to Alarm Clock Mode.

2. Press SET to move to the cursor to select alarm 1 or 2.

3. Press ST / SP / + or MEM / LAP / - to activate

deactivate

the alarm.

EXERCISE PROFILE

To calculate your minimum and maximum heart rate you

need to set the exercise proﬁle.

Different activities exercise the body in different ways

and help you to achieve a variety of ﬁtness goals. To accommodate this the exercise proﬁle can be set to suit

different exercise activities. For example, if you are running,

your exercise proﬁle settings are likely to differ from those

you would use when undertaking a weight training activity. Also, the time you require to warm-up and complete an

exercise will vary. That is why you can change the warm-up and exercise countdown time to suit you.

To set the exercise proﬁle:

1. Press MODE to navigate to Exercise Proﬁle Mode.

If this screen appears, press SET to navigate to the Exercise

Proﬁle Mode.

2. Press SET to navigate to 1 of the 3 exercise proﬁles.

3. Press and hold SET until the ﬁrst setting ﬂashes.

4. Press ST / SP / + or MEM / LAP / - to change the setting. Hold to speed through the options. Press SET

to conﬁrm the setting and move on to the next one.

5. Repeat step 4 to change other settings for this mode.

The order of the exercise proﬁle settings is:

• Target activity - 0 to 2

• Lower limit heart rate

• Upper limit heart rate

• Heart rate alert - ON / OFF

• Exercise timer - hour

• Exercise timer - minute

• Warm-up timer - set to 5, 10, 15 to activate or 0 mins to deactivate timer

• Rest timer - ON / OFF

NOTE Once you have set your exercise proﬁle your lower and upper heart rate limit will be set automatically. However, you can manually change your upper and lower heart rate limit if the automatic setting does not suit you. If you change the target activity level, your upper / lower and maximum heart rate will automatically be updated.

TARGET ACTIVITY

There are 3 target activity levels:

TARGET ACTIVITY MHR% DESCRIPTION

0 Health

Maintenance

1 Aerobic

Exercise

65-78% This is the lowest

training intensity level. It is good for beginners and those who want to strengthen their cardiovascular systems.

65-85% Increases strength

and endurance. It works within the body’s oxygen intake capability, burns more calories, and can be maintained for a long period of time.

2 Anaerobic

Exercise

78-90% Generates speed

and power. It works at or above the body’s oxygen intake capability, builds muscle,and cannot be maintained for a long period of time.

MAXIMUM / LOWER / UPPER HEART RATE LIMIT

Before you begin any exercise program and to achieve maximum health beneﬁts from your workout, it is important to know your:

• Maximum heart rate (MHR)

• Lower heart rate limit

• Upper heart rate limit

To manually calculate your own heart rate limits, follow the instructions below:

MHR LOWER LIMIT UPPER LIMIT

MHR = 220 - age

MHR x lower target activity %. E.g. Target activity is

0. Lower Limit = MHR x 65%

MHR x upper target activity %. E.g. Target activity is 0. Upper Limit = MHR x 78%

HEART RATE ALERT

You can set the heart rate alert in the exercise proﬁle to the following settings:

ICON DESCRIPTION

Heart rate sound alert is OFF

Heart rate sound alert is ON

• 1 beep means you have gone below your lower zone limit

• 2 beeps means you have gone above your upper zone limit

When the heart rate alert is activated, a ﬂashing down or up arrow will appear on the display to show which heart rate limit you have surpassed.

USER PROFILE

To access the full beneﬁts of the watch, set up your user proﬁle before you exercise. This will automatically generate a ﬁtness index and body mass index (BMI). These calculations along with the calorie and fat % burned will help you track your progress over time.

To set the user proﬁle:

1. Press MODE to navigate to User Proﬁle Mode.

If this screen appears, press SET repeatedly to navigate

to the User Proﬁle Mode.

2. Press and hold SET until the ﬁrst setting ﬂashes.

3. Press ST / SP / + or MEM / LAP / - to change the setting. Hold to speed through the options. Press SET to conﬁrm the setting and move on to the next one.

4. Repeat step 3 to change other settings for this mode.

The order of the user proﬁle settings is:

• Sex

• Year of birth

• Month of birth

• Day of birth

• Weight unit - lbs or kg

• Weight

• Height unit - ft or cm

• Height

• Activity level - 0-2

Once you complete your user proﬁle, a ﬁtness index and body mass index is automatically calculated and displayed for you. Refer to the “About the Fitness / Body Mass Index” section for further information.

NOTE You can display and adjust your user proﬁle at any time.

NOTE You must set up your user proﬁle to use the calorie count and fat burn features.

ACTIVITY LEVEL

The activity level is based on your own self-assessment of the amount of exercise you regularly perform.

ACTIVITY LEVEL

0 Low - You do not usually participate

1 Medium - You are engaged in modest

DESCRIPTION

in programmed recreation sports or exercise.

physical activity (such as golﬁng, horseback riding, table tennis, callisthenics, bowling, weight lifting or gymnastics) 2-3 times a week, totalling 1 hour per week.

ABOUT THE FITNESS / BODY MASS INDEX

FITNESS INDEX

Your watch will generate a ﬁtness index based on your aerobic ﬁtness. This index is dependent and limited by the body’s ability to deliver oxygen to the working muscles in training. It is often measured by maximum oxygen uptake (VO2 Max), which is deﬁned as the highest amount of oxygen that can be utilized when exercising at an increasingly demanding level. The lungs, heart, blood, circulatory system, and working muscles are all factors to determine VO2 Max. The unit of VO2 Max is ml/kg min.

The higher the index, the ﬁtter you are. See the tables below for a rough guide to what your ﬁtness index means:

egA

RIAF

EGAREVA

DOOG

2 High - You actively and regularly

participate in heavy physical exercise (such as running, jogging, swimming, cycling, or skipping rope) or engage in vigorous aerobic exercise (such as tennis, basketball or handball).

Fitness index

egA

RIAF

Fitness index

EGAREVA

BODY MASS INDEX

Your body mass index is a measurement of the relative percentages of fat and muscle mass in the human body.

HEALTH INDICATION

Underweight

Recommended

BMI RANGE

Less than

20.0

20.0 to

25.0

DESCRIPTION

Your body weight is currently lower than average. Work toward healthy, regular food intake and exercise routine to build up your health to recommended levels.

Your health is at the recommended level. Maintain a balanced diet and exercise to keep your current level of health.

Overweight 25.1 to

29.9

DOOG

Obese

NOTE BMI should not be used as a guideline for health risks for the following groups:

GROUP REASON

Children and teenagers BMI ranges are only based

Athletes and body builders

Pregnant or nursing women

People over the age of 65

30.0 or greater

Your body weight may be above normal. Increase your exercise and work out a diet plan to lower your risk for serious illness.

At this level, you may be at risk for heart disease, high blood pressure, and other illnesses. Consult with your doctor to develop a proper

health and ﬁtness plan.

on adult heights.

BMI does not differentiate between fat and muscle, thus making it inaccurate for persons with high muscle volumes.

This group generates naturally high fat reserves as part of the pregnancy.

Fat reserves naturally tend to be higher with older persons.

NOTE The above BMI information is based on an average Caucasian physique.

VIEW FITNESS / BODY MASS INDEX

Press MODE to navigate to the User Proﬁle Mode. Then, press MEM / LAP / - to display your ﬁtness and body mass index.

NOTE If you have not completed your user proﬁle, these will not display and “- -” will show on the display.

WEARING THE CHEST BELT AND WATCH

CHEST BELT

The heart rate chest belt is used to count your heartbeat and transmit the data to the watch. To wear the chest belt:

1. Wet the conductive pads on the underside of the chest

belt with a few drops of water or a conductive gel to ensure solid contact.

2. Strap the heart rate chest belt across your chest. To ensure an accurate heart rate signal, adjust the strap until the belt sits snugly below your pectoral muscles.

TIPS

• The position of the chest belt affects its performance. Move the chest belt along the strap so that it falls above

your heart.

• Avoid areas with dense chest hair.

• In dry, cold climates, it may take several minutes for the chest belt to function steadily. This is normal and should improve with several minutes of exercise.

• To maintain the best performance of your chest belt, please handle it with care according to the following:

• Do not wrap the chest belt in a wet towel nor with other wet materials.

• Do not store the chest belt in a hot (about 50°C) and humid (about 90%) environment.

• Do not place or wash the chest belt under running water, instead clean it with a wet cloth.

• Do not place the conductive rubber face down on a metal table or surface.

• Properly dry the chest belt immediately after use.

NOTE If the watch is kept idle without receiving a heart rate signal for 5 minutes, the Heart Rate Mode will quit and return to Clock Mode.

WATCH You can wear the receiver watch on your wrist or strap it to

a bike or exercise machine, as shown below.

TRANSMISSION SIGNAL

The heart rate chest belt and watch have a maximum transmission range of about 62.5 centimetres (25 inches). They are equipped with the latest digital coding system to reduce signal interference from the environment, as well as analog technology. For more accurate readings use the digital transmission signal. You should only switch to the analog transmission signal if the situation in point 2 occurs (see below). Your watch will advise you which system it is using and the signal status by displaying the following icons:

NOTE Whenever the watch is searching for the chest belt signal (manual or automatic search), make sure that the chest belt is no further than 10 cm (4 inches) from the watch.

ICON DESCRIPTION

Outside heart is

ﬂashing

Inside heart is

ﬂashing

Heart is ﬂashing

NOTE To switch from digital to analog or analog to digital system, press the chest belt button for more than 4 seconds and then force a signal search.

IMPORTANT If the heart icon does not appear on the

display or is not ﬂashing because no signal has been found,

force a signal search. See “Signal Search” section on how to do this.

In the event that you experience a weak signal or your signal is disrupted by interference in the environment, follow the instructions below to identify and resolve the situation.

1. The signal is weak - the watch heart rate monitor will only show “0”:

• Shorten the distance between the heart rate chest

belt and watch.

• Re-adjust the position of the heart rate chest

belt.

• Check the conductive pads are moist enough to

ensure solid contact.

Searching for a signal

A signal has been found and the digital system is being used

A signal has been found and the analog system is being used

No signal has been found

• Check the batteries. If they are low or exhausted, the transmission range may be shortened.

• Force a signal search (see “Signal Search” section).

2. The gym equipment does not seem to work with your chest belt and the digital icon

• Most gym equipment is compatible with the analog system button for more than 4 seconds to change from digital to analog. Then force a signal search (see “Signal Search” section).

3. Interference from another person’s heart rate monitor

- their heart rate readings appear on your watch, or the heart rate monitor shows “0”:

• Press the chest belt button to get the watch to receive your chest belt signal. Do not press and hold the chest belt button, as it will change the transmission signal from digital to analog.

4. The signal is jammed - the heart rate reading on your watch is ﬂashing:

• There is too much interference in the environment for your heart rate monitor to function. Move to an area where the heart rate reading stops ﬂashing.

. Press and hold the chest belt

is displayed:

WARNING Signal interference in the environment can be caused by electromagnetic disturbances. These may occur near high voltage power lines, trafﬁc lights, overhead lines of electric railways, electric bus lines or trams, televisions, car motors, bike computers, some motor driven exercise equipment, cellular phones or when you walk through electric security gates. Under interference, the heart rate reading may become unstable and inaccurate.

SIGNAL SEARCH

To force a signal search:

1. Press MODE to navigate to the SMART TRAINING

PROGRAM or Stopwatch Mode.

2. Press and hold MODE for 2 seconds. The signal-

searching icon with the outside ﬂashing will appear to conﬁrm a signal search is taking place. Whenever the watch is searching for the chest belt signal make sure that the chest belt is no further than 10 cm (4 inches) from the watch.

The signal search will take approximately 10 seconds. If after 10 seconds the heart icon is not ﬂashing, then your signal search has been unsuccessful and you need to force another signal search.

See the table in the “Transmission Signal” section for more signal status information.

ABOUT THE SMART TRAINING PROGRAM

The SMART TRAINING PROGRAM enables you to complete exercise cycles effectively. It will guide you through from a 5-minute warm up (default setting), to the end of your exercise program. In addition to monitoring your heart rate

and alerting you whenever you fall out of the range for the selected training zone, the Program allows you to check the calories consumed and the percentage of fat burned.

USING THE SMART TRAINING PROGRAM

The SMART TRAINING PROGRAM monitors your exercise

performance once you have entered your user proﬁle and exercise proﬁle.

NOTE You cannot use the SMART TRAINING PROGRAM if you are running the stopwatch.

To enter the SMART TRAINING PROGRAM:

1. Press MODE to navigate to Timer Mode.

2. Press and hold SET. Press ST / SP / + or MEM / LAP

/ - to select 1 of the 3 exercise proﬁles. Press SET to conﬁrm and enter the SMART TRAINING PROGRAM.

timer, press ST / SP / +.

4. To bypass a countdown timer and move onto the next

one, press and hold ST / SP / +.

5. To reset the timer, press and hold SET. The order of the Timer Mode is:

• Warm-up time

- The warm-up will not display if it has been

set to “0” in the exercise proﬁle.

• Exercise time -The exercise time is set in the exercise proﬁle.

• Rest time

- The rest time is automatically set to 3 mins

and cannot be changed. When the timer

reaches “0”, the recovery heart rate will appear.

- The rest time will not display if it has been set to

“OFF” in the exercise proﬁle.

VIEW DATA WHILE SMART TRAINING PROGRAM IS RUNNING

During warm-up, exercise or rest time countdown, press SET to view and toggle between the following screen displays:

• Remaining warm-up / exercise / rest time with current

heart rate

3. To start or stop the warm-up, exercise or rest countdown

• Current calorie and fat burn level

• Clock with current heart rate

VIEW SMART TRAINING PROGRAM MEMORY RECORDS

When the SMART TRAINING PROGRAM has been completed, press MEM / LAP / - to view the “total time / maximum heart rate” record, then press SET to view the following records:

• Recovery heart rate / average heart rate

• Total calorie and fat burn level

• In zone time: Time spent without exceeding your upper or lower heart rate limit

• Above zone time: Time spent exceeding your upper heart rate limit

• Below zone time: Time spent exceeding your lower heart rate limit

NOTE You cannot use the stopwatch if you are running the SMART TRAINING PROGRAM.

RECOVERY HEART RATE

Your recovery heart is a good indication of cardiovascular ﬁtness. The faster your heart rate recovers after exercise, the better shape you are in. The watch uses a time-based recovery method, which checks your recovery heart rate 3 minutes after exercise.

Compare your recovery heart rate between exercise sessions to track the effect your exercise is having.

STOPWATCH

The stopwatch function is particularly beneﬁcial to use when you are unsure how long your activity will take, or when you

want to measure the time it takes to complete a task and your performance over that time. You can also take lap and split time readings when using the stopwatch function.

To get the most out of your stopwatch function complete

your user and exercise proﬁle. If you have not completed the user proﬁle you will be unable to use the calorie and fat burn function.

Press MODE to navigate to Stopwatch Mode. You can now perform the following functions:

TASK INSTRUCTION

Start stopwatch Press ST / SP / + Pause / resume

stopwatch Reset Press and hold SET Save lap

Select exercise

proﬁle for stopwatch

NOTE The stopwatch begins measurement in min:

sec:1/100 sec. After 59 minutes pass, the display will change to hrs:min:sec.

Press ST / SP / +

Press MEM / LAP / - while the stopwatch is running

NOTE Up to 99 laps / 99 hrs,

59 mins total can be stored in

the memory Reset the stopwatch. Press

and hold SET

VIEW DATA WHILE STOPWATCH / LAP IS RUNNING

While the stopwatch or lap functions are being used, press SET to view and toggle between the following screen displays:

• Total time / split time and current heart rate

• Lap time and current heart rate (if enabled)

• Current calorie and fat burn level

• Clock with current heart rate If the battery is low when taking a lap, this screen will appear

and no more laps will be saved.

VIEW STOPWATCH OR LAP MEMORY RECORDS

To view stopwatch records:

1. The stopwatch must be stopped (press ST / SP / +).

2. Press MEM / LAP / -, then press SET.

The stopwatch records will appear in the following order:

• Total time / maximum heart rate

• Total time / average heart rate

• Calories / fat burn total

• In zone time: Time spent without exceeding your upper

or lower heart rate limit

• Above zone time: Time spent exceeding your upper

heart rate limit

• Below zone time: Time spent exceeding your lower

heart rate limit

To view lap records:

1. The stopwatch must be stopped (press ST / SP / +).

2. Press MEM / LAP / -, then press ST / SP / + or MEM / LAP / - to select lap.

3. Press SET to view lap record.

The lap records will appear in the following order:

• Lap time / maximum heart rate

• Split time / average heart rate

• Calorie and fat burn total - per lap

• In zone time - per lap: Time spent without exceeding

your upper or lower heart rate limit

• Above zone time - per lap: Time spent exceeding your

upper heart rate limit

• Below zone time - per lap: Time spent exceeding your

lower heart rate limit

To replace the watch battery:

1. Undo the screws and remove the back plate.

2. Using a thin blunt instrument, hook the release catch and lift the clip.

3. Replace the old battery and then the battery clip.

4. Replace the back plate and screws.

BATTERIES

The SE188 uses two CR2032 lithium batteries, one for the watch and another for the heart rate chest belt. Both are already installed. See the table below for battery warnings.

LOW BATTERY ICON DESCRIPTION

The batteries typically last one year.

The battery is too low to run the backlight

The chest belt battery is nearly too low to send a signal to the watch

To replace the chest belt battery:

1. Using a coin, twist the battery door counter-clockwise until it clicks out of place.

2. Replace the old battery and close the battery door by

twisting it clockwise until it is ﬁrmly in place.

IMPORTANT

• Remember to set the proﬁles after every battery replacement or reset.

TRAINING INFORMATION

HOW THE HEART RATE MONITOR HELPS YOU

A heart rate monitor is the most important tool in cardiovascular health and an ideal training partner. It enables you to see and monitor results. This helps you assess your past performance, maximise your work out and adapt your future exercise program to achieve your desired goals in a safer and more effective way.

When you exercise, the chest belt picks up your heartbeat and sends it to the watch. Now you can view your heart rate and start monitoring your performance based on your heart rate readings. As you get ﬁtter, your heart will need to do less work and the speed of your heart rate will decrease. The reason for this is as follows:

• Your heart pumps blood to your lungs to obtain oxygen. Then, the oxygen rich blood will travel to your muscles. The oxygen is used as fuel and the blood leaves the muscles and returns to the lungs to begin the process again. As you get ﬁt, your heart is able to pump more blood with every beat. As a result, your heart doesn’t have to beat as often to get the necessary oxygen to your muscles.

TRAINING TIPS

To gain the maximum beneﬁt from your training program, and to ensure that you exercise safely, please observe the following guidelines:

• Start with a well-deﬁned training goal, such as to lose weight, keep ﬁt, improve health or compete in a sporting event.

• Select a training activity you enjoy, and vary your training activities to exercise different muscle groups.

• Start slowly, and then gradually step up your work out as you become ﬁtter. Exercise regularly. To maintain a healthy cardio-vascular system, 20-30 minutes three times a week is recommended.

• Always allow at least ﬁve minutes before and after exercising for warm-up and cool-down.

• Measure your pulse after training. Then repeat the procedure again after three minutes. If it does not return to its normal resting rate, you may have trained

too hard.

• Always check with your doctor before starting a vigorous training program.

AQUATIC AND OUTDOOR ACTIVITIES

The watch is water-resistant up to 50 metres. The chest belt is water-resistant up to 10 metres, but should not be worn for underwater activities, as the heart rate transmission cannot occur under water. Refer to the table for proper use

guidelines.

RAIN SPLASHES, ETC

50m / 165ft

When using the watch for aquatic or outdoor sports activities, observe the following guidelines:

• Rinse with water and mild soap after use.

• Do not use in hot water.

NOTE

• Ensure the buttons and battery compartment are

• Avoid pressing the buttons while in the water or during

OK OK OK NO NO

secured and intact before exposing the watch to

excessive water.

heavy rainstorms, as this may cause water to enter the watch, leading to malfunction.

SHOWERING (WARM / COOL WATER ONLY)

LIGHT SWIMMING / SHALLOW WATER

SHALLOW DIVING / SURFING / WATER SPORTS

SNORKELING / DEEP WATER DIVING

SPECIFICATIONS

TYPE DESCRIPTION

CLOCK

Time format 12 hr / 24 hr

Date format DD / MM or MM / DD

Year format 2001-2050 (auto-calendar)

Alarms Alarms 1 and 2 with daily,

weekday or weekend settings

STOPWATCH

Stopwatch 99:59:59 (HH:MM:SS)

Resolution 1/100sec

Lap counter 99 laps share 99:59:59

(HH:MM:SS)

SMART TRAINING PROGRAM

Warm-up timer Set to 5, 10, 15, or 0 mins

Exercise timer 99:59:00 (HH:MM:SS)

Rest timer 3 mins ﬁxed time

PERFORMANCE TRACKING

Heart rate (HR) alarm Sound / visual

HR measuring range 30-240 bpm

(beats per minute)

Lower HR settable range

Upper HR settable range

Calories calculation 0-9,999 kcal

% fat burning calculation

TRANSMISSION

Range 62.5 cm (25 inches) - may

WATER RESISTANCE

Watch 50 metres (not actuating keys)

Chest belt Splash proof

POWER

Watch 1 x CR2032 3V lithium battery

Chest belt 1 x CR2032 3V lithium battery

OPERATING ENVIRONMENT

Operation temperature -5°C-50°C (23°F-122°F)

Storage temperature -20°C-60°C (-4°F-140°F)

30-220 bpm (beats per minute)

80-240 bpm (beats per minute)

0-99%

decrease with low battery

PRECAUTIONS

To ensure you use your product correctly and safely, read these warnings and the entire user manual before using the product:

• Use a soft, slightly moistened cloth. Do not use abrasive or corrosive cleaning agents, as these may cause

damage. Use luke warm water and mild soap to clean the watch and chest belt thoroughly after each training

session. Never use the products in hot water or store

them when wet.

• Do not bend or stretch the transmitter part of the chest

belt.

• Do not subject the product to excessive force, shock, dust, temperature changes, or humidity. Never expose

the product to direct sunlight for extended periods. Such treatment may result in malfunction.

• Do not tamper with the internal components. Doing

so will terminate the product warranty and may cause

damage. The main unit contains no user-serviceable

parts.

• Do not scratch hard objects against the LCD display as

this may cause damage.

• Take precautions when handling all battery types.

• Remove the batteries whenever you are planning to

store the product for a long period of time.

• When replacing batteries, use new batteries as speciﬁed

in this user manual.

• The product is a precision instrument. Never attempt to take this device apart. Contact the retailer or our customer service department if the product requires servicing.

• Do not touch the exposed electronic circuitry, as there is a danger of electric shock.

• Check all major functions if the device has not been used for a long time. Maintain regular internal testing and cleaning of your device. Have your watch serviced by an approved service center annually.

• When disposing of this product, ensure it is collected separately for special treatment and not as normal household waste.

• Due to printing limitations, the displays shown in this manual may differ from the actual display.

• The contents of this manual may not be reproduced without the permission of the manufacturer.

NOTE The technical speciﬁcations for this product and the contents of the user manual are subject to change without notice.

NOTE Features and accessories will not be available in all countries. For more information, please contact your local retailer.

ABOUT OREGON SCIENTIFIC

Visit our website (www.oregonscientiﬁc.com) to learn more about Oregon Scientiﬁc products. If you’re in the US and would like to contact our Customer Care department directly, please visit: www2.oregonscientiﬁc.com/service/support.asp

For international inquiries, please visit: www2.oregonscientiﬁc.com/about/international.asp

EU-DECLARATION OF CONFORMITY

Hereby, Oregon Scientiﬁc, declares that this Tap On Pro Heart Rate Monitor (Model: SE188) is in compliance with EMC directive 2004/108/EC. A copy of the signed and dated Declaration of Conformity is available on request via our Oregon Scientiﬁc Customer Service.

Tap On Pro

Pulsómetro

Model: SE188

MANUAL DE USUARIO

ÍNDICE

Introducción .................................................................... 2

Prestaciones Principales .............................................. 3

Reloj ........................................................................... 3

Visualizador LCD ........................................................ 3

Preparación Inicial ......................................................... 4

Desembalaje del Reloj ................................................. 4

Encender el Reloj (Sólo para la Primera Utilización) ... 5 Conﬁguración de Teclas Sonoras / Modo de Luz /

Pantalla Táctil .............................................................. 5

Activación de la Retroiluminación ................................ 5

Activación del bloqueo de los botones ........................ 6

Pantalla Táctil .............................................................. 6

Cambio de Modos de Funcionamiento ....................... 6

Utilización del Reloj ....................................................... 7

Utilización de la(s) Alarma(s) ........................................ 7

Conﬁguración de la(s) Alarma(s) ................................ 7

Apagar el Sonido de la Alarma .................................... 8

Activar / Desactivar la Alarma ..................................... 8

Perﬁl del Ejercicio Físico ............................................... 8

Actividad Indicada ....................................................... 9

Límite Máximo / Inferior / Superior del Ritmo Cardíaco .. 10

Alarma para el Ritmo Cardíaco ................................. 10

Perﬁl del Usuario .......................................................... 10

Nivel de Actividad ...................................................... 12

Acerca del Índice de Salud / Masa Corporal ............. 12

Índice de Salud .......................................................... 12

Índice de Masa Corporal .............................................. 13

Visualizar El índice de Salud / Masa Corporal ......... 14

Colocación de la banda pectoral y el Reloj ............... 14

Señal de Transmisión ................................................ 15

Búsqueda de la Señal ............................................... 17

Acerca del PROGRAMA INTELIGENTE DE

ENTRENAMIENTO ........................................................ 17

Utilización del PROGRAMA INTELIGENTE DE

ENTRENAMIENTO ................................................... 17

Visualizar la Infomación mientras funciona el

PROGRAMA INTELIGENTE DE ENTRENAMIENTO

Visualizar el Registro de Memoria del PROGRAMA

INTELIGENTE DE ENTRENAMIENTO ..................... 19

Ritmo Cardíaco de Recuperación ............................. 19

Cronómetro ................................................................... 19

Visualizar la Información mientras funciona el

Cronómetro / Intervalo .............................................. 20

Visualizar los Registros de Memoria del Cronómetro o Intervalo

Pilas ............................................................................... 21

Información acerca del Entrenamiento ...................... 21

Cómo Puede Ayudarle el Monitor del Ritmo Cardíaco .. 21

Consejos acerca del Entrenamiento ......................... 22

Actividades Acuáticas y Exteriores ........................... 22

Especiﬁcaciones ........................................................ 23

Precauciones ............................................................... 24

Sobre Oregon Scientiﬁc ............................................. 25

EU-Declaración de Conformidad ............................... 25

......... 18

.. 20

INTRODUCCIÓN

Le agradecemos que haya seleccionado el reloj Tap On

Pro Pulsómetro (SE188) de Oregon Scientiﬁc

producto para cuidar su salud deportiva. Este aparato de precisión incluye las siguientes prestaciones:

• Control del ritmo cardíaco con transmisión inalámbrica entre el reloj y banda pectoral.

• Sistema de codiﬁcación digital para reducir las

interferencias del entorno.

• Sistema de control del ritmo cardíaco cuando éste alcanza el valor del límite superior o el límite inferior.

• Alarma visual o acústica para distintos estados de ritmos cardíacos durante el entrenamiento.

• Memoria que almacena los registros del ritmo cardíaco

durante el ejercicio.

• PROGRAMA INTELIGENTE DE ENTRENAMIENTO

que le permite completar ciclos de ejercicio de modo efectivo.

• Lente táctil para ver cómodamente los datos de

ejercicios.

• Visualización del consumo de calorías y porcentaje de grasa quemada durante y después del ejercicio.

• Perﬁl de ejercicio físico - para calcular su límite personal de ritmo cardíaco para el entrenamiento.

• Perﬁl del usuario – para calcular su índice de salud y su índice de masa corporal (BMI).

• Cronómetro.

• Memorización de 99 intervalos para mostrar el ritmo cardíaco medio y el ritmo cardíaco máximo.

• Dos alarmas con opción de ajuste de la alarma diaria,

como el

de lunes a viernes o ﬁn de semana.

• Soporte para bicicleta, banda pectoral y funda de

transporte incluidos.

• Reloj - water resistant 50m.

• Banda pectoral - resistente a salpicaduras.

IMPORTANTE El reloj SE188 debe destinarse únicamente al uso deportivo y no debe utilizarse como sustituto de ningún consejo médico.

PRESTACIONES PRINCIPALES

RELOJ

1. MEM / LAP / -: Mostrar los registros del entrenamiento;

disminuir el valor de conﬁguración; señalar un

intervalo.

2. MODE: Cambiar a otro modo de visualización.

3. ST / SP / +: Iniciar / detener el cronómetro; incrementar

el valor de conﬁguración.

/ : Encender la retroiluminación durante 3

segundos; bloquear / desbloquear las teclas.

5. SET: Activar el Modo de Conﬁguración; seleccionar

otra opción de conﬁguración; visualizar información

distinta durante el entrenamiento; Resetear el timer y el

cronómetro y visualizar información distinta durante el

entrenamiento.

VISUALIZADOR LCD

1. Zona 1

2. Zona 2

3. Zona 3

Zona 1

1. TIMER: El PROGRAMA INTELIGENTE DE

ENTRENAMIENTO aparece mostrado o está activado.

2. TTL: El tiempo total de ejercicio aparece mostrado.

4. LAP: Muestra el tiempo del intervalo actual o el tiempo

5. SPLIT: Aparece mostrado y calcula el tiempo partido.

6. WARM: El temporizador de calentamiento aparece

: El bloqueo del teclado está activado.

del intervalo de la memoria.

mostrado o está activado.

7. STW: El cronómetro aparece mostrado o está activado.

: La señal sonora de las teclas está desactivada.

9. REST: El tiempo de recuperación aparece mostrado o está activado.

Zona 2

1. MM:DD o DD:MM y día de la semana; tiempo del cronómetro.

4. kcal: Unidades de calorias.

Zona 3

/ : La hora de la alarma 1 y 2; las ondas muestran

cuándo está activada la alarma.

: El cursor indica la alarma seleccionada en el Modo

de Alarma.

: El Modo de Luz está activado.

: Función táctil activada.

1. Hora - HH:MM.

2. AM/PM: Aparece cuando se utiliza el formato de 12-

horas para el reloj / alarma.

3. AVG: El ritmo cardíaco medio aparece mostrado.

4. MAX: Muestra el ritmo cardíaco máximo.

7. kglbs: Unidades de peso corporal.

8. % FAT: Porcentaje de quema de grasa.

9. CM Yr: Unidades de altura; Año de nacimiento del

10. LAP: Medición de un intervalo; número de intervalo.

11. MEM: La memoria del cronómetro o temporizador

12.

: Si el ritmo cardíaco es superior o inferior al límite,

se activará la alarma.

: Parpadea cuando recibe la señal de ritmo

cardíaco.

usuario.

aparece mostrada.

: Condición de la pila.

PREPARACIÓN INICIAL

DESEMBALAJE DEL RELOJ

Cuando desembale su reloj SE188, asegúrese de conservar todo el material de embalaje en un lugar seguro, por si posteriormente fuera necesario transportar o devolver el producto para su reparación.

En esta caja encontrará:

• Reloj

• Banda pectoral

• Soporte para bicicleta

• Funda de transporte

• 2 pilas CR2032 de litio - ya instaladas

ENCENDER EL RELOJ (SÓLO PARA LA PRIMERA UTILIZACIÓN)

Pulse cualquier tecla durante 2 segundos para activar el visualizador LCD.

• El Pantalla Táctil ACTIVADO o DESACTIVADO consulte la sección “Pantalla Táctil”.

CONFIGURACIÓN DE TECLAS SONORAS / MODO DE LUZ / PANTALLA TÁCTIL

Podrá conﬁgurar el reloj para que tenga:

• La señal sonora de las teclas ACTIVADA o DESACTIVADA.

• El Modo de Luz ACTIVADO o DESACTIVADO - consulte la sección “Activación de la Retroiluminación”.

Para activar estas prestaciones:

1. Pulse MODE para navegar al Modo de Reloj de Tiempo

Real.

2. Pulse SET hasta alcanzar la prestación que desea

cambiar.

3. Pulse ST / SP / + o MEM / LAP / - para cambiar la

conﬁguración.

4. Pulse SET para conﬁrmar la conﬁguración y desplazarse

a la siguiente.

ACTIVACIÓN DE LA RETROILUMINACIÓN

Cuando el Modo de Luz esté DESACTIVADO:

• Pulse para encender la retroiluminación durante 3 segundos. Pulse cualquier otra tecla mientras la luz esté encendida y el tiempo de la luz se prolongará durante 3 segundos más.

Cuando el Modo de Luz esté ACTIVADO:

• Pulse cualquier tecla para ENCENDERLA o prolongar la retroiluminación durante 3 segundos.

Para ahorrar consumo, la conﬁguración del Modo de Luz ACTIVADO se APAGARÁ automáticamente después de 2 horas.

NOTA La retroiluminación no funciona cuando el icono de baja energía de la pila aparece mostrado y se recuperará cuando se sustituyan las pilas por nuevas.

ACTIVACIÓN DEL BLOQUEO DE BOTONES

Para activar o desactivar el bloqueo de los botones:

• Pulse y mantenga pulsado

aparecerá en el display, cuando la función de

bloqueo o desbloqueo esté activada.

durante dos segundos.

PANTALLA TÁCTIL

La función de pantalla táctil le ofrece fácil acceso a 6 modos predeterminados:

• Ritmo cardíaco (HR)

• Cronómetro (STW)

• PROGRAMA INTELIGENTE DE ENTRENAMIENTO (SMART)

• Calorías quemadas (CAL)

• Intervalo (LAP)

• Reloj

Para conﬁgurar la función de lente táctil:

1. En el Modo de hora, pulse SET hasta alcanzar la pantalla de pantalla táctil “TOUCH ON”.

2. Pulse SET y manténgalo pulsado.

3. Pulse ST / SP / + o MEM / LAP / - para seleccionar 1 de

los 6 modos.

4. Pulse SET para conﬁrmar.

Para utilizar la función de lente táctil:

Simplemente toque la pantalla y su modo predeterminado se mostrará durante 10 segundos antes de volver a la pantalla previa.

aparece cuando se active la función de pantalla táctil, y

parpadea cuando se muestra la pantalla predeterminada.

CAMBIO DE MODOS DE FUNCIONAMIENTO

Pulse MODE para cambiar entre 5 modos de funcionamiento:

• Reloj de Tiempo Real

• Reloj Alarma

• Perﬁl del Usuario / Perﬁl del Ejercicio Físico

• Temporizador-PROGRAMA INTELIGENTE DE ENTRENAMIENTO

• Cronómetro

Los modos se describen en las siguientes secciones.

+ 167 hidden pages
