Oregon Scientific MP200 256MB User Manual

Model: MP 200

User Manual

Manuale d'Uso

Manuel d'Utilisation

MP200 Eng Manul R2(V1.1) F OP 11/15/04, 10:34 AM1

¶´ƒ

CONTENTS

DIGITAL MP3 PLAYER (MP200)

USER MANUAL

Introduction ................................................................................. 1

Main Features ........................................................................ 1

Accessories ............................................................................ 1

Product Overview ....................................................................... 2

Front ....................................................................................... 2

Back ....................................................................................... 2

Getting Started ............................................................................ 3

Driver Software Installation (Win 98SE Users Only) .............. 3

Connecting the Player to Your Computer /

Charging the Battery .............................................................. 3

File Transfer ................................................................................. 4

Disconnecting Player from Computer .................................... 5

Power On / Off ............................................................................. 5

Power On ............................................................................... 5

Power Off ............................................................................... 5

Playing Back Music Files ........................................................... 6

Play ........................................................................................ 6

Stop / Pause ........................................................................... 6

Skip / Fast Forward / Rewind ................................................. 6

Volume Control....................................................................... 7

Menu Navigation ......................................................................... 7

RPT (Repeat) ............................................................................... 8

EQ (Equalizer) ............................................................................. 9

Delete ........................................................................................... 9

Delete One ........................................................................... 10

Delete All .............................................................................. 10

Display ....................................................................................... 10

Backlit ................................................................................... 10

Contrast (LCD Contrast) ...................................................... 10

MP200 Eng Manul R2(V1.1) C OP 11/16/04, 11:25 AM1

¶´ƒ

Scroll (Scroll Speed) ............................................................ 11

Memory and Firmware .............................................................. 11

Settings ...................................................................................... 11

Lang (Language) .................................................................. 11

Time ..................................................................................... 11

Tag (Tag Information) ........................................................... 12

Button Hold ............................................................................... 12

Reset .......................................................................................... 12

Upgrading Firmware (Windows Users Only) .......................... 12

Formatting Your Player (Windows Users Only) ..................... 13

Safety and Care ......................................................................... 13

Troubleshooting ........................................................................ 14

Hardware .............................................................................. 14

Software ............................................................................... 15

Caution ....................................................................................... 16

Technical Specifications .......................................................... 16

About Oregon Scientific ........................................................... 17

FCC Statement .......................................................................... 17

Ver.1.1

MP200 Eng Manul R2(V1.1) C OP 11/16/04, 11:25 AM2

¶´ƒ

INTRODUCTION

Congratulations on your selection of the Oregon ScientificTM MP200. This full-featured Digital MP3 Player offers a variety of features including multi-format data storage support, support for multiple audio standards, enhanced playback and audio features, all in a slim, credit card-sized design.

MAIN FEATURES

• World's first see-through display MP3 player with LED light

• Support for MP3 and WMA / WMA DRM audio file formats

• Multi-format support for mass data storage

• 128MB, 256MB or 512MB built-in flash memory (please refer to indication on the packing)

• 5 preset equalizer settings

• Upgradeable firmware for future audio format support

• Multilanguage menu support

• ID3 Tag information display

• USB 2.0 for fast file transfer (USB flash drive)

• Built-in rechargeable battery

ACCESSORIES

• CD-ROM

• Strap with stereo earphones

• USB cable

• USB power adaptor (optional)

• Carrying pouch

MP200 Eng Manul R2(V1.1) OP 11/15/04, 10:33 AM1

¶´ƒ

PRODUCT OVERVIEW

FRONT

1. Earphone connection

2. Strap connector: Use this to attach the supplied strap

3. LCD screen

4. USB connector

BACK

1. JOG button:

Skip to the next track or

next option;

Review the current or

previous track / back to the previous option;

Start and pause playback / stop

playback / confirm selection

2. MENU button: Press and hold to turn the power on or off; Enter or exit menu settings

3. RESET: Resets the unit

4. VOL + / -: Press to change the volume; toggle between different font displays in STOP status

5. BUTTON HOLD: Lock button controls to prevent activation

MP200 Eng Manul R2(V1.1) OP 11/15/04, 10:33 AM2

¶´ƒ

GETTING STARTED

Before you begin, please check to make sure your computer meets the following minimum system requirements:

• Intel® Pentium® 133MHz or faster

• CD-ROM Drive

• USB 1.1 port or USB 2.0 port

• 10MB free hard disk space

• Microsoft® Windows® 98SE, Me, 2000, or XP

• Mac OS 9.0 or above

DRIVER SOFTWARE INSTALLATION (WIN 98SE USERS ONLY)

WINDOWS 98SE

Installing the MP200 driver software will allow your computer to recognize your MP3 player each time it is connected to the computer.

1. Insert the MP200 CD-ROM into your computer. If the installer does not automatically begin, please refer to the troubleshooting section for help.

2. Follow the onscreen instructions.

3. Restart your computer.

WINDOWS ME, 2000, XP

When you connect your MP3 player to your PC, it will appear as a removable drive (i.e., Removable Disk (H:)).

MACINTOSH OS 9.0 OR ABOVE

When you connect your MP3 player to your Macintosh, it will appear as one drive icon on the desktop (i.e., Untitled).

CONNECTING THE PLAYER TO YOUR COMPUTER / CHARGING THE BATTERY

To connect the player to your computer using the supplied USB cable:

MP200 Eng Manul R2(V1.1) OP 11/15/04, 10:33 AM3

¶´ƒ

NOTE: Make sure you turn off the player before connecting to the PC.

Once connected the player's built-in battery will automatically begin charging. "READY" will show on the LCD. When the battery is fully charged after approximately 2-3 hours on a continuous charge, the battery icon shows

. Disconnect the player when charging is finished

unless you are transferring files.

The battery status indicators are as follows:

NOTE: When the low battery indicator shows

, recharge the battery

as soon as possible. When the battery icon shows

, this indicates

the battery is about to run out of power within a few seconds.

NOTE: Charging time may very depending on the computer's USB usage status. If the player overheats or cools during charging, the battery icon

appears on the LCD and the unit stops charging. The player will automatically restart charging after re-adjusting its internal temperature.

TIP: You can charge your player with the supplied USB adaptor (optional accessory). AC cable and plugs differ from region to region.

FILE TRANSFER

After connecting your MP3 player to the computer, the computer will detect and identify the device as a removable storage drive, allowing you to drag and drop all forms of files between your computer and your player.

1. Double click the My Computer icon.

2. Double click the drive letter (i.e. Removable Disk (H:) or Untitled on the Mac) of your player assigned by the computer.

3. Drag and drop the file(s) you wish to copy from your computer onto your player.

NOTE: You will not be able to view or play any of the stored data unless it is one of the supported MP3 (MPEG-1, Audio Layer 3) or WMA (Windows Media Audio) / WMA DRM audio formats.

Medium

Low Full

MP200 Eng Manul R2(V1.1) OP 11/15/04, 10:33 AM4

¶´ƒ
