NCP1117, NCV1117

1.0 A Low−Dropout Positive Fixed and Adjustable Voltage Regulators

The NCP1117 series are low dropout positive voltage regulators that are capable of providing an output current that is in excess of 1.0 A with a maximum dropout voltage of 1.2 V at 800 mA over temperature. This series contains eight fixed output voltages of 1.5 V,

1.8 V, 2.0 V, 2.5 V, 2.85 V, 3.3 V, 5.0 V, and 12 V that have no minimum load requirement to maintain regulation. Also included is an adjustable output version that can be programmed from 1.25 V to

18.8 V with two external resistors. On chip trimming adjusts the reference/output voltage to within ±1.0% accuracy. Internal protection features consist of output current limiting, safe operating area compensation, and thermal shutdown. The NCP1117 series can operate with up to 20 V input. Devices are available in SOT−223 and DPAK packages.

Features

• Output Current in Excess of 1.0 A

• 1.2 V Maximum Dropout Voltage at 800 mA Over Temperature

• Fixed Output Voltages of 1.5 V, 1.8 V, 2.0 V, 2.5 V, 2.85 V, 3.3 V,

5.0 V, and 12 V

• Adjustable Output Voltage Option

• No Minimum Load Requirement for Fixed Voltage Output Devices

• Reference/Output Voltage Trimmed to ±1.0%

• Current Limit, Safe Operating and Thermal Shutdown Protection

• Operation to 20 V Input

• NCV Prefix for Automotive and Other Applications Requiring Site

and Control Changes

• Pb−Free Packages are Available

Applications

• Consumer and Industrial Equipment Point of Regulation

• Active SCSI Termination for 2.85 V Version

• Switching Power Supply Post Regulation

• Hard Drive Controllers

• Battery Chargers

http://onsemi.com

Tab

1

3

Heatsink tab is connected to Pin 2.

1

3

ORDERING INFORMATION

See detailed ordering and shipping information in the package dimensions section on pages 11 and 12 of this data sheet.

DEVICE MARKING INFORMATION

See general marking information in the device marking section on page 13 of this data sheet.

1 23

(Top View)

Pin: 1. Adjust/Ground

2. Output

3. Input

Tab

123

(Top View)

SOT−223

ST SUFFIX

CASE 318H

DPAK

DT SUFFIX

CASE 369C

Input

10

F

 Semiconductor Components Industries, LLC, 2004

July, 2004 − Rev. 11

NCP1117

3

XTXX

++

Figure 1. Fixed

Output Regulator

1

2

Output

10 F

TYPICAL APPLICATIONS

Input

3

NCP1117

XTA

++

10 F

Figure 2. Adjustable

Output Regulator

1

Output

2

10 F

1 Publication Order Number:

4.75 V to

5.25 V

110 

22 F

110 

3

NCP1117

XT285

++

10 F

+

Figure 3. Active SCSI Bus Terminator

2

1

18 to 27

Lines

NCP1117/D

NCP1117, NCV1117

MAXIMUM RATINGS

Rating Symbol Value Unit

Input Voltage (Note 1) V

in

Output Short Circuit Duration (Notes 2 and 3) − Infinite − Power Dissipation and Thermal Characteristics

Case 318H (SOT−223)

Power Dissipation (Note 2) Thermal Resistance, Junction−to−Ambient, Minimum Size Pad Thermal Resistance, Junction−to−Case

P

D

R



JA

R



JC

Case 369A (DPAK)

Power Dissipation (Note 2) Thermal Resistance, Junction−to−Ambient, Minimum Size Pad

Thermal Resistance, Junction−to−Case Maximum Die Junction Temperature Range T Storage Temperature Range T Operating Ambient Temperature Range

NCP1117

P

D

R



JA

R



JC

J

stg

T

A

NCV1117

Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit values (not normal operating conditions) and are not valid simultaneously . If these limits are exceeded, device functional operation is not implied, damage may occur and reliability may be affected.

1. This device series contains ESD protection and exceeds the following tests: Human Body Model 2000 V per MIL−STD−883, Method 3015. Machine Model Method 200 V.

2. Internal thermal shutdown protection limits the die temperature to approximately 175°C. Proper heatsinking is required to prevent activation. The maximum package power dissipation is:

3. The regulator output current must not exceed 1.0 A with Vin greater than 12 V.

T

P



D

J(max)

R

JA

 T

A

20 V

Internally Limited

160

15

Internally Limited

67

6.0

−55 to 150 °C

−65 to 150 °C

0 to +125

−40 to +125

W

°C/W °C/W

W

°C/W °C/W

°C

http://onsemi.com

2

NCP1117, NCV1117

ELECTRICAL CHARACTERISTICS (C

= 10 F, C

in

= 10 F, for typical value TA = 25°C, for min and max values TA is the

out

operating ambient temperature range that applies unless otherwise noted. (Note 6)

Characteristic

Reference Voltage, Adjustable Output Devices

(V (V

= 2.0 V, I

in–Vout

= 1.4 V to 10 V, I

in–Vout

= 10 mA, TA = 25°C)

out

= 10 mA to 800 mA) (Note 6)

out

Output Voltage, Fixed Output Devices

1.5 V (V

1.8 V (V

2.0 V (V

2.5 V (V

2.85 V (V

3.3 V (V

5.0 V (V

= 3.5 V, I

in

= 2.9 V to 11.5 V, I

(V

in

= 3.8 V, I

in

= 3.2 V to 11.8 V, I

(V

in

= 4.0 V, I

in

= 3.4 V to 12 V, I

(V

in

= 4.5 V, I

in

(V

= 3.9 V to 10 V, I

in

= 4.85 V, I

in

= 4.25 V to 10 V, I

(V

in

= 4.0 V, I

(V

in

= 5.3 V, I

in

= 4.75 V to 10 V, I

(V

in

= 7.0 V, I

in

(V

= 6.5 V to 12 V, I

in

= 10 mA, TA = 25 °C)

out

= 10 mA, TA = 25 °C)

out

= 10 mA, TA = 25 °C)

out

= 10 mA, TA = 25 °C)

out

= 0 mA to 500 mA) (Note 6)

out

= 10 mA, TA = 25 °C)

out

= 10 mA, TA = 25 °C)

out

= 0 mA to 800 mA) (Note 6)

out

= 0 mA to 800 mA) (Note 6)

out

= 0 mA to 800 mA) (Note 6)

out

= 0 mA to 800 mA,) (Note 6)

out

= 10 mA, TA = 25 °C)

= 0 mA to 800 mA) (Note 6)

out

= 0 mA to 800 mA) (Note 6)

out

= 0 mA to 800 mA) (Note 6)

out

Symbol Min Typ Max Unit

V

ref

V

out

1.238

1.225

1.485

1.470

1.782

1.755

1.970

1.960

2.475

2.450

2.821

2.790

3.267

3.235

4.950

4.900

1.25−1.262

1.270

1.500

1.800

2.000

2.500

2.850

3.300

5.000

1.515

−

1.530

1.818

−

1.845

2.030

−

2.040

2.525

−

2.550

2.879

−

2.910

−

2.910

3.333

−

3.365

5.050

−

5.100

V

12 V (V

= 14 V, I

in

(V

= 13.5 V to 20 V, I

in

Line Regulation (Note 4)

Adjustable (V

in

1.5 V (Vin = 2.9 V to 11.5 V, I

1.8 V (V

2.0 V (V

2.5 V (V

2.85 V (V

3.3 V (V

5.0 V (V 12 V (V

= 3.2 V to 11.8 V, I

in

= 3.4 V to 12 V, I

in

= 3.9 V to 10 V, I

in

= 4.25 V to 10 V, I

in

= 4.75 V to 15 V, I

in

= 6.5 V to 15 V, I

in

= 13.5 V to 20 V, I

in

Load Regulation (Note 4)

Adjustable (I

1.5 V (I

1.8 V (I

2.0 V (I

2.5 V (I

2.85 V (I

3.3 V (I

5.0 V (I 12 V (I

out

= 0 mA to 800 mA, Vin = 2.9 V)

out

= 0 mA to 800 mA, Vin = 3.2 V)

out

= 0 mA to 800 mA, Vin = 3.4 V)

out

= 0 mA to 800 mA, Vin = 3.9 V)

out

= 0 mA to 800 mA, Vin = 4.25 V)

out

= 0 mA to 800 mA, Vin = 4.75 V)

out

= 0 mA to 800 mA, Vin = 6.5 V)

out

= 0 mA to 800 mA, Vin = 13.5 V)

out

Dropout Voltage (Measured at V

= 100 mA)

(I

out

(I

= 500 mA)

out

= 800 mA)

(I

out

Output Current Limit (Vin−V

= 10 mA, TA = 25 °C)

out

= 2.75 V to 16.25 V, I

= 0 mA to 800 mA) (Note 6)

out

= 10 mA)

out

= 0 mA)

out

= 0 mA)

out

= 0 mA)

out

= 0 mA)

out

= 0 mA)

out

= 0 mA)

out

= 0 mA)

out

= 0 mA)

out

= 10 mA to 800 mA, Vin = 4.25 V)

− 100 mV)

out

= 5.0 V, TA = 25°C, Note 5) I

out

Reg

Vin−V

out

11.880

11.760

line

12.000

−

− 0.04 0.1

−

line

0.3

0.4

0.5

0.8

0.9

1.0

− 0.2 0.4

−

out

−

2.3

2.6

3.0

3.3

3.8

4.3

6.7 16

0.95

1.01

1.07

1000 1500 2200 mA

12.120

12.240

1.0

2.5

3.0

4.5

6.0

7.5

5.5

6.0

7.5

8.0 10 15 28

1.10

1.15

1.20

4. Low duty cycle pulse techniques are used during testing to maintain the junction temperature as close to ambient as possible.

5. The regulator output current must not exceed 1.0 A with V

6. NCP1117: T NCV1117: T

= 0°C , T

low

= −40°C, T

low

high high

= 125°C = 125°C

greater than 12 V.

in

%

mV

%

mV

V

http://onsemi.com

3

NCP1117, NCV1117

ELECTRICAL CHARACTERISTICS (C

= 10 F, C

in

= 10 F, for typical value TA = 25°C, for min and max values TA is the

out

operating ambient temperature range that applies unless otherwise noted. (Note 7)

Characteristic

Minimum Required Load Current for Regulation, Adjustable Output Devices

(V

= 15 V)

in

Quiescent Current

1.5 V (V

1.8 V (V

2.0 V (V

2.5 V (V

2.85 V (V

3.3 V (V

5.0 V (V 12 V (V

= 11.5 V)

in

= 11.8 V)

in

= 12 V)

in

= 10 V)

in

= 10 V)

in

= 15 V)

in

= 15 V)

in

= 20 V)

in

Symbol Min Typ Max Unit

I

L(min)

I

Q

− 0.8 5.0 mA

−

3.6

4.2

4.5

5.2

5.5

6.0

10 10 10 10 10 10 10

10 Thermal Regulation (TA = 25°C, 30 ms Pulse) − 0.01 0.1 %/W Ripple Rejection (Vin−V

Adjustable

1.5 V

1.8 V

2.0 V

2.5 V

2.85 V

3.3 V

5.0 V

12 V Adjustment Pin Current (Vin = 11.25 V, I Adjust Pin Current Change

(V

= 1.4 V to 10 V, I

in−Vout

Temperature Stability S Long Term Stability (TA = 25°C, 1000 Hrs End Point Measurement) S

= 6.4 V, I

out

= 10 mA to 800 mA)

out

= 500 mA, 10 Vpp 120 Hz Sinewave)

out

= 800 mA) I

out

I

RR

adj

67 66 64 64 62 62 60 57 50

73 72 70 70 68 68 64 61 54

−

− 52 120 A

adj

T

t

− 0.4 5.0 A

− 0.5 − %

− 0.3 − %

RMS Output Noise (f = 10 Hz to 10 kHz) N − 0.003 − %V

7. NCP1117: T NCV1117: T

= 0°C , T

low

= −40°C, T

low

high high

= 125°C = 125°C

mA

dB

out

http://onsemi.com

4

NCP1117, NCV1117

2.0

1.5

1.0

Vin = V I

out

+ 3.0 V

out

= 10 mA

Adj, 1.5 V,

1.8 V, 2.0 V,

2.5 V

0.5 0

−0.5

−1.0

−1.5

, OUTPUT VOLTAGE CHANGE (%)

out

V

−2.0

−50 −25 0 25 50 75 100 125 , AMBIENT TEMPERATURE (°C)

T

A

2.85 V, 3.3 V,

5.0 V, 12.0 V

Figure 4. Output Voltage Change

vs. Temperature

2.0

1.5

1.0

TJ = 25°C

150

1.4 TJ = 25°C

1.2

TJ = −40°C

1.0

0.8

TJ = 125°C

0.6

, DROPOUT VOLTAGE (V)

0.4

out

0.2

− V

in

V

0

0 200 400 600 800 1000

I

out

Load pulsed at 1.0% duty cycle

, OUTPUT CURRENT (mA)

Figure 5. Dropout Voltage

vs. Output Current

2.0

1.8

1.6

1.4

0.5

, OUTPUT CURRENT (A)

out

I

Load pulsed at 1.0% duty cycle

0

0 2 4 6 8 101214161820

− V

V

, VOLTAGE DIFFERENTIAL (V)

in

out

Figure 6. Output Short Circuit Current

vs. Differential Voltage

100

80

60

40

20

, ADJUST PIN CURRENT (A)

adj

I

0

−50 −25 0 25 50 75 100 125 150 TA, AMBIENT TEMPERATURE (°C)

I

= 10 mA

out

, OUTPUT CURRENT (A)

1.2

out

I

Vin = 5.0 V Load pulsed at 1.0% duty cycle

1.0

−50 −25 0 25 50 75 100 125 150 TA, AMBIENT TEMPERATURE (°C)

Figure 7. Output Short Circuit Current

vs. Temperature

10

5.0

0

−5.0

−10

−15

QUIESCENT CURRENT CHANGE (%)

Q,

−20

I

−50 −25 0 25 50 75 100 125 150

T

, AMBIENT TEMPERATURE (°C)

A

Figure 8. Adjust Pin Current

vs. Temperature

Figure 9. Quiescent Current Change

vs. Temperature

http://onsemi.com

5

NCP1117, NCV1117

100

f

= 120 Hz

ripple

V

 3.0 V

80

60

40

V

= 5.0 V

out

V

− V

= 3.0 V

in

out

= 10 F

C

out

20

C

= 25 F

RR, RIPPLE REJECTION (dB)

adj

T

= 25°C

A

f

ripple

V

ripple

= 20 kHz

 0.5 V

P−P

0

0 200 400 600 800 1000

I

, OUTPUT CURRENT (mA)

out

Figure 10. NCP1117XTA Ripple Rejection

vs. Output Current

Cin = 1.0 F C I

5.25

INPUT

4.25

VOLTAGE (V)

20

0

out

T

A

= 10 F

out

= 0.1 A

= 25°C

100

P−P

V

ripple

Vin − V

 0.5 V

out

80

V

ripple

 3.0 V

60

V

= 5.0 V

out

V

− V

= 3.0 V

in

out

I

40

20

RR, RIPPLE REJECTION (dB)

= 0.5 A

out

C

= 10 F

out

C

= 25 F, f > 60 Hz

adj

C

= 200 F, f  60 Hz

adj

T

= 25°C

A

Vin − V

out

 V

dropout

0

10 100 1.0 k 10 k 100 k

, RIPPLE FREQUENCY (Hz)

f

ripple

Figure 11. NCP1117XTA Ripple Rejection

vs. Frequency

0.1 0

−0.1

DEVIATION (V)

OUTPUT VOLTAGE

0.5

Cin = 10 F C

= 10 F

out

V

= 4.5 V

in

Preload = 0.1 A T

= 25°C

A

P−P

 3.0 V

−20

DEVIATION (mV)

OUTPUT VOLTAGE

0 40 80 120 160

t, TIME (s)

Figure 12. NCP1117XT285

Line Transient Response

7.5

INPUT

6.5

VOLTAGE (V)

20

0

−20

DEVIATION (mV)

OUTPUT VOLTAGE

0 40 80 120 160

t, TIME (s)

Figure 14. NCP1117XT50

Line Transient Response

Cin = 1.0 F C

= 10 F

out

I

= 0.1 A

out

T

= 25°C

A

CHANGE (A)

LOAD CURRENT

200

−0.1

DEVIATION (V)

OUTPUT VOLTAGE

CHANGE (A)

LOAD CURRENT

200

0

0 40 80 120 160

t, TIME (s)

Figure 13. NCP1117XT285 Load Transient Response

0.1 0

Cin = 10 F C V Preload = 0.1 A T

0.5 0

0 40 80 120 160

t, TIME (s)

Figure 15. NCP1117XT50

Load Transient Response

= 10 F

out

= 6.5 V

in

= 25°C

A

200

http://onsemi.com

6

NCP1117, NCV1117

14.5

INPUT

13.5

VOLTAGE (V)

20

0

−20

DEVIATION (mV)

OUTPUT VOLTAGE

0 40 80 120 160

t, TIME (s)

Figure 16. NCP1117XT12 Line

Transient Response

180

160

140

120

100

, THERMAL RESISTANCE,

80

JA

JUNCTION−TO−AIR (°CW)



R

60

Minimum Size Pad

010203025155.0

Cin = 1.0 F C

out

I

out

T

= 25°C

A

= 10 F

= 0.1 A

0.1

−0.1

DEVIATION (V)

OUTPUT VOLTAGE

0.5

CHANGE (A)

LOAD CURRENT

200

P

for TA = 50°C

D(max)

R



JA

L, LENGTH OF COPPER (mm)

0

Cin = 10 F C

= 10 F

out

V

= 13.5 V

in

Preload = 0.1 A T

= 25°C

A

0

0 40 80 120 160 200

t, TIME (s)

Figure 17. NCP1117XT12 Load

Transient Response

1.6

1.4

2.0 oz. Copper L

L

1.2

1.0

0.8

0.6

0.4

, MAXIMUM POWER DISSIPATION (W)

D

P

Figure 18. SOT−223 Thermal Resistance and Maximum

Power Dissipation vs. P.C.B. Copper Length

100

90

80

70

60

, THERMAL RESISTANCE,

50

JA

JUNCTION−TO−AIR (°CW)



R

40

Minimum Size Pad

010203025155.0

P

for TA = 50°C

D(max)

2.0 oz. Copper

L

R



JA

L, LENGTH OF COPPER (mm)

L

Figure 19. DPAK Thermal Resistance and Maximum

Power Dissipation vs. P.C.B. Copper Length

http://onsemi.com

7

1.6

1.4

1.2

1.0

0.8

0.6

0.4

, MAXIMUM POWER DISSIPATION (W)

D

P

NCP1117, NCV1117

APPLICATIONS INFORMATION

Introduction

The NCP1117 features a significant reduction in dropout voltage along with enhanced output voltage accuracy and temperature stability when compared to older industry standard three−terminal adjustable regulators. These devices contain output current limiting, safe operating area compensation and thermal shutdown protection making them designer friendly for powering numerous consumer and industrial products. The NCP1117 series is pin compatible with the older LM317 and its derivative device types.

Output Voltage

The typical application circuits for the fixed and adjustable output regulators are shown in Figures 20 and 21. The adjustable devices are floating voltage regulators. They develop and maintain the nominal 1.25 V reference voltage between the output and adjust pins. The reference voltage is programmed to a constant current source by resistor R1, and this current flows through R2 to ground to set the output voltage. The programmed current level is usually selected to be greater than the specified 5.0 mA minimum that is required for regulation. Since the adjust pin current, I

adj

, is significantly lower and constant with respect to the programmed load current, it generates a small output voltage error that can usually be ignored. For the fixed output devices R1 and R2 are included within the device and the ground current I

, ranges from 3.0 mA to 5.0 mA

gnd

depending upon the output voltage.

External Capacitors

Input bypass capacitor Cin may be required for regulator stability if the device is located more than a few inches from the power source. This capacitor will reduce the circuit’s sensitivity when powered from a complex source impedance and significantly enhance the output transient response. The input bypass capacitor should be mounted with the shortest possible track length directly across the regulator’s input and ground terminals. A 10 F ceramic or tantalum capacitor should be adequate for most applications.

Input

Figure 20. Fixed Output Regulator

3

NCP1117

XTXX

++

C

in

1

I

gnd

Output

2

C

out

Frequency compensation for the regulator is provided by

capacitor C

and its use is mandatory to ensure output

out

stability. A minimum capacitance value of 4.7 F with an equivalent series resistance (ESR) that is within the limits of

0.25  to 2.2  is required. The capacitor type can be ceramic, tantalum, or aluminum electrolytic as long as it meets the minimum capacitance value and ESR limits over the circuit’s entire operating temperature range. Higher values of output capacitance can be used to enhance loop stability and transient response with the additional benefit of reducing output noise.

R1

R2

Output

C

out

C

adj

Input

Figure 21. Adjustable Output Regulator

3

NCP1117

XTA

++

C

in

I

adj

V

 V

out

ref



1

R2

1 

R2 R1

2

V

ref

+



 I

adj

The output ripple will increase linearly for fixed and adjustable devices as the ratio of output voltage to the reference voltage increases. For example, with a 12 V regulator, the output ripple will increase by 12 V/1.25 V or

9.6 and the ripple rejection will decrease by 20 log of this ratio or 19.6 dB. The loss of ripple rejection can be restored to the values shown with the addition of bypass capacitor C

, shown in Figure 21. The reactance of C

adj

at the ripple

adj

frequency must be less than the resistance of R1. The value of R1 can be selected to provide the minimum required load current to maintain regulation and is usually in the range of 100  to 200 .

C



adj

2  f

1

ripple

R1

The minimum required capacitance can be calculated from the above formula. When using the device in an application that is powered from the AC line via a transformer and a full wave bridge, the value for C

f

ripple 

The value for C

120 Hz, R1  120 , then C

is significantly reduced in applications

adj

 11.1 F

adj

is:

where the input ripple frequency is high. If used as a post regulator in a switching converter under the following conditions:

f

 50 kHz, R1  120 , then C

ripple

 0.027 F

adj

Figures 10 and 11 shows the level of ripple rejection that is obtainable with the adjust pin properly bypassed.

http://onsemi.com

8

NCP1117, NCV1117

Protection Diodes

The NCP1117 family has two internal low impedance diode paths that normally do not require protection when used in the typical regulator applications. The first path connects between V

and Vin, and it can withstand a peak

out

surge current of about 15 A. Normal cycling of Vin cannot generate a current surge of this magnitude. Only when V is shorted or crowbarred to ground and C

is greater than

out

50 F, it becomes possible for device damage to occur. Under these conditions, diode D1 is required to protect the device. The second path connects between C

adj

and V

out

, and it can withstand a peak surge current of about 150 mA. Protection diode D2 is required if the output is shorted or crowbarred to ground and C

D1

1N4001

Input

C

in

Figure 22. Protection Diode Placement

NCP1117

3

++

XTA

1

R2

is greater than 1.0 F.

adj

2

D2

R1

1N4001

+

C

adj

Output

C

out

A combination of protection diodes D1 and D2 may be

required in the event that Vin is shorted to ground and C

adj

is greater than 50 F. The peak current capability stated for the internal diodes are for a time of 100 s with a junction temperature of 25°C. These values may vary and are to be used as a general guide.

Load Regulation

The NCP1117 series is capable of providing excellent load regulation; but since these are three terminal devices, only partial remote load sensing is possible. There are two conditions that must be met to achieve the maximum available load regulation performance. The first is that the top side of programming resistor R1 should be connected as close to the regulator case as practicable. This will minimize the voltage drop caused by wiring resistance RW + from appearing in series with reference voltage that is across R1.

The second condition is that the ground end of R2 should be connected directly to the load. This allows true Kelvin sensing where the regulator compensates for the voltage drop caused by wiring resistance RW −.

RW+

Input

in

C

3

NCP1117

XTA

+

in

2

+

C

1

R1

R2

out

Output

Remote Load

RW−

Figure 23. Load Sensing

Thermal Considerations

This series contains an internal thermal limiting circuit that is designed to protect the regulator in the event that the maximum junction temperature is exceeded. When activated, typically at 175°C, the regulator output switches off and then back on as the die cools. As a result, if the device is continuously operated in an overheated condition, the output will appear to be oscillating. This feature provides protection from a catastrophic device failure due to accidental overheating. It is not intended to be used as a substitute for proper heatsinking. The maximum device power dissipation can be calculated by:

T

P



D

J(max)

R

JA

 T

A

The devices are available in surface mount SOT−223 and DPAK packages. Each package has an exposed metal tab that is specifically designed to reduce the junction to air thermal resistance, R

, by utilizing the printed circuit

JA



board copper as a heat dissipater. Figures 18 and 19 show typical R

values that can be obtained from a square

JA



pattern using economical single sided 2.0 ounce copper board material. The final product thermal limits should be tested and quantified in order to insure acceptable performance and reliability. The actual R

can vary

JA



considerably from the graphs shown. This will be due to any changes made in the copper aspect ratio of the final layout, adjacent heat sources, and air flow.

http://onsemi.com

9

NCP1117, NCV1117

Input

10

F

Figure 24. Constant Current Regulator Figure 25. Slow Turn−On Regulator

Output Control

Off

Constant Current

NCP1117

3

XTA

++

R

2

1

V

I

Input

10 F

ref



out

 I

adj

R

NCP1117

3

XTA

++

1

1.0 k 2N2222

Output

10 F

2

120

Output

10 F

360

On

1.0 k

V

out(Off)

 V

ref

Input

10 F

NCP1117

3

XTA

++

R2

1

2N2907

2

R1

50 k

1N4001

10 F

Input

10 F

NCP1117

3

++

XTA

2

1

R1

R2

2N2222

Output Voltage Control

Resistor R2 sets the maximum output voltage. Each transistor reduces the output voltage when turned on.

Output

10 F

Output

10 F

Figure 26. Regulator with Shutdown Figure 27. Digitally Controlled Regulator

Input

10 F

NCP1117

3

XT50

++

2

1 50 

R

CHG

6.6 V

NCP1117

XT50

+

10

+

F

−

23

1

The 50  resistor that is in series with the ground pin of the upper regulator level shifts its output 300 mV higher than the lower regulator. This keeps the lower regulator off until the input source is removed.

Output

10

F

5.3 V AC Line

5.0 V Battery

Input

3

NCP1117

XT50

++

10

F

2.0 k

2

1

+

10 F

Figure 28. Battery Backed−Up Power Supply Figure 29. Adjusting Output of Fixed

Voltage Regulators

Output

10 F

5.0 V to 12 V

http://onsemi.com

10

NCP1117, NCV1117

ORDERING INFORMATION

Nominal Output

Device

NCP1117DTA Adjustable DPAK 75 Units / Rail NCP1117DTAG Adjustable DPAK

NCP1117DTARK Adjustable DPAK 2500 / Tape & Reel NCP1117DTARKG Adjustable DPAK

NCP1117DTAT5 Adjustable DPAK 2500 / Tape & Reel NCP1117STAT3 Adjustable SOT−223 4000 / Tape & Reel NCP1117STAT3G Adjustable SOT−223

NCP1117DT12 12 DPAK 75 Units / Rail NCP1117DT12RK 12 DPAK 2500 / Tape & Reel NCP1117DT12T3 12 SOT−223 4000 / Tape & Reel NCP1117DT15 1.5 DPAK 75 Units / Rail NCP1117DT15RK 1.5 DPAK 2500 / Tape & Reel NCP1117DT15RKG 1.5 DPAK

NCP1117ST15T3 1.5 SOT−223 4000 / Tape & Reel NCP1117ST15T3G 1.5 SOT−223

NCP1117DT18 1.8 DPAK 75 Units / Rail NCP1117DT18RK 1.8 DPAK 2500 / Tape & Reel NCP1117DT18RKG 1.8 DPAK

NCP1117DT18T5 1.8 DPAK 2500 / Tape & Reel NCP1117DT18T5G 1.8 DPAK

NCP1117ST18T3 1.8 SOT−223 4000 / Tape & Reel NCP1117ST18T3G 1.8 SOT−223

NCP1117DT20 2.0 DPAK 75 Units / Rail NCP1117DT20RK 2.0 DPAK 2500 / Tape & Reel NCP1117ST20T3 2.0 SOT−223 4000 / Tape & Reel NCP1117ST20T3G 2.0 SOT−223

NCP1117DT25 2.5 DPAK 75 Units / Rail NCP1117DT25RK 2.5 DPAK 2500 / Tape & Reel NCP1117DT25RKG 2.5 DPAK

NCP1117DT25T5 2.5 DPAK 2500 / Tape & Reel NCP1117ST25T3 2.5 SOT−223 4000 / Tape & Reel NCP1117ST25T3G 2.5 SOT−223

†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifi-

cations Brochure, BRD8011/D.

*NCV prefix is for automotive and other applications requiring site and control changes.

Voltage

Package Shipping

75 Units / Rail

(Pb−Free)

2500 / Tape & Reel

(Pb−Free)

4000 / Tape & Reel

(Pb−Free)

2500 / Tape & Reel

(Pb−Free)

4000 / Tape & Reel

(Pb−Free)

2500 / Tape & Reel

(Pb−Free)

2500 / Tape & Reel

(Pb−Free)

4000 / Tape & Reel

(Pb−Free)

4000 / Tape & Reel

(Pb−Free)

2500 / Tape & Reel

(Pb−Free)

4000 / Tape & Reel

(Pb−Free)

†

http://onsemi.com

11

NCP1117, NCV1117

ORDERING INFORMATION

Nominal Output

Device Shipping

NCP1117DT285 2.85 DPAK 75 Units / Rail NCP1117DT285RK 2.85 DPAK 2500 / Tape & Reel NCP1117ST285T3 2.85 SOT−223 4000 / Tape & Reel NCP1117DT33 3.3 DPAK 75 Units / Rail NCP1117DT33RK 3.3 DPAK 2500 / Tape & Reel NCP1117DT33RKG 3.3 DPAK

NCP1117DT33T5 3.3 DPAK 2500 /Tape & Reel NCP1117DT33T5G 3.3 DPAK

NCP1117ST33T3 3.3 SOT−223 4000 /Tape & Reel NCP1117ST33T3G 3.3 SOT−223

NCP1117DT50 5.0 DPAK 75 Units/Rail NCP1117DT50RK 5.0 DPAK 2500 / Tape & Reel NCP1117DT50RKG 5.0 DPAK

NCP1117ST50T3 5.0 SOT−223 4000 /Tape & Reel NCV1117DTARK* Adjustable DPAK 2500 / Tape & Reel NCV1117STAT3* Adjustable SOT−223 4000 / Tape & Reel NCV1117STAT3G* Adjustable SOT−223

NCV1117ST12T3* 12 SOT−223 4000 / Tape & Reel NCV1117ST12T3G* 12 SOT−223

NCV1117DT15RK* 1.5 DPAK 2500 / Tape & Reel NCV1117DT15RKG* 1.5 DPAK

NCV1117ST15T3* 1.5 SOT−223 4000 / Tape & Reel NCV1117DT18T5* 1.8 DPAK 2500 / Tape & Reel NCV1117DT25RK* 2.5 DPAK 2500 / Tape & Reel NCV1117ST25T3* 2.5 SOT−223 4000 / Tape & Reel NCV1117DT33T5* 3.3 DPAK 2500 / Tape & Reel NCV1117DT50RK* 5.0 DPAK 2500 / Tape & Reel

†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifi-

cations Brochure, BRD8011/D.

*NCV prefix is for automotive and other applications requiring site and control changes.

Voltage

Package

2500 / Tape & Reel

(Pb−Free)

2500 /Tape & Reel

(Pb−Free)

4000 /Tape & Reel

(Pb−Free)

2500 / Tape & Reel

(Pb−Free)

4000 / Tape & Reel

(Pb−Free)

4000 / Tape & Reel

(Pb−Free)

2500 / Tape & Reel

(Pb−Free)

†

http://onsemi.com

12

NCP1117, NCV1117

MARKING DIAGRAMS

SOT−223

ST SUFFIX

CASE 318H

ALYW 117−A

1

23

Adjustable 1.5 V 1.8 V 2.0 V 2.5 V

ALYW 7−285

1

2.85 V 3.3 V 5.0 V 12 V

117AJ

ALYWW

1

23

ALYW 17−15

23

17−15

ALYWW

ALYW 17−33

1

23

DT SUFFIX

CASE 369C

ALYWW

ALYW 17−18

23

DPAK

17−18

ALYW

117−5

1

23

ALYWW

ALYW 117−2

23

117−2

ALYW 17−12

1

23

17−25

ALYWW

ALYW 17−25

23

2

1

31

Adjustable 1.5 V 1.8 V 2.0 V 2.5 V

17285

ALYWW

2

1

2.85 V 3.3 V 5.0 V 12 V

2

31

17−33

ALYWW

2

31

A = Assembly Location L = Wafer Lot Y = Year WW, W = Work Week

2

31

117−5

ALYWW

2

31

2

31

17−12

ALYWW

2

3

http://onsemi.com

13

3

NCP1117, NCV1117

ÉÉ

PACKAGE DIMENSIONS

SOT−223

ST SUFFIX

CASE 318H−01

ISSUE O

H

D

4

b2

M

0.1 C

SAS

B

A

(b2)

b3

SECTION B−B L

E

M

0.2 C

B

E1

S

B

3

A

e

e1

2

A

1

B



c1

SECTION A−A

SOLDERING FOOTPRINT*

(b)

b1

0.08

C

b

A1

A

c

NOTES:

1. DIMENSIONS ARE IN MILLIMETERS.

2. INTERPRET DIMENSIONS AND TOLERANCES PER ASME Y14.5M, 1994.

S

B

S

A

M

0.1 C

3. DIMENSION E1 DOES NOT INCLUDE INTERLEAD FLASH OR PROTRUSION. INTERLEAD FLASH OR PROTRUSION SHALL NOT EXCEED 0.23 PER SIDE.

4. DIMENSIONS b AND b2 DO NOT INCLUDE DAMBAR PROTRUSION. ALLOWABLE DAMBAR PROTRUSION SHALL BE 0.08 TOTAL IN EXCESS OF THE b AND b2 DIMENSIONS AT MAXIMUM MATERIAL CONDITION.

5. TERMINAL NUMBERS ARE SHOWN FOR REFERENCE ONLY.

6. DIMENSIONS D AND E1 ARE TO BE DETERMINED AT DATUM PLANE H.

MILLIMETERS

DIM MIN MAX

A −−− 1.80

A1 0.02 0.11

b 0.60 0.88 b1 0.60 0.80 b2 2.90 3.10 b3 2.90 3.05

c 0.24 0.35 c1 0.24 0.30

D 6.30 6.70

E 6.70 7.30 E1 3.30 3.70

2.30

e

4.60

e1

L 0.25

 0 10

−−−



3.8

0.15

2.0

0.079

2.3

0.091

2.3

0.091

6.3

0.248

2.0

0.079

mm



1.5

0.059

SCALE 6:1

inches



*For additional information on our Pb−Free strategy and soldering

details, please download the ON Semiconductor Soldering and Mounting Techniques Reference Manual, SOLDERRM/D.

http://onsemi.com

14

NCP1117, NCV1117

PACKAGE DIMENSIONS

DPAK

DT SUFFIX

CASE 369C−01

ISSUE O

SEATING

−T−

PLANE

B

V

S

R

4

A

123

K

F

L

D

2 PL

G

0.13 (0.005) T

C

E

Z

U

J

H

M

NOTES:

1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.

2. CONTROLLING DIMENSION: INCH.

DIM MIN MAX MIN MAX

A 0.235 0.245 5.97 6.22 B 0.250 0.265 6.35 6.73 C 0.086 0.094 2.19 2.38 D 0.027 0.035 0.69 0.88

E 0.018 0.023 0.46 0.58

F 0.037 0.045 0.94 1.14 G 0.180 BSC 4.58 BSC H 0.034 0.040 0.87 1.01

J 0.018 0.023 0.46 0.58 K 0.102 0.114 2.60 2.89

L 0.090 BSC 2.29 BSC R 0.180 0.215 4.57 5.45

S 0.025 0.040 0.63 1.01 U 0.020 −−− 0.51 −−−

V 0.035 0.050 0.89 1.27

Z 0.155 −−− 3.93 −−−

MILLIMETERSINCHES

SOLDERING FOOTPRINT*

6.20

0.244

2.58

0.101

5.80

0.228

3.0

0.118

1.6

0.063

6.172

0.243

mm



SCALE 3:1

inches



*For additional information on our Pb−Free strategy and soldering

details, please download the ON Semiconductor Soldering and Mounting Techniques Reference Manual, SOLDERRM/D.

http://onsemi.com

15

NCP1117, NCV1117

ON Semiconductor and are registered trademarks of Semiconductor Components Industries, LLC (SCILLC). SCILLC reserves the right to make changes without further notice

to any products herein. SCILLC makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does SCILLC assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. “Typical” parameters which may be provided in SCILLC data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. SCILLC does not convey any license under its patent rights nor the rights of others. SCILLC products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the SCILLC product could create a situation where personal injury or death may occur. Should Buyer purchase or use SCILLC products for any such unintended or unauthorized application, Buyer shall indemnify and hold SCILLC and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that SCILLC was negligent regarding the design or manufacture of the part. SCILLC is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.

PUBLICATION ORDERING INFORMATION

LITERATURE FULFILLMENT:

Literature Distribution Center for ON Semiconductor P.O. Box 61312, Phoenix, Arizona 85082−1312 USA

Phone: 480−829−7710 or 800−344−3860 Toll Free USA/Canada Fax: 480−829−7709 or 800−344−3867 Toll Free USA/Canada Email: orderlit@onsemi.com

N. American Technical Support: 800−282−9855 Toll Free

USA/Canada Japan: ON Semiconductor, Japan Customer Focus Center

2−9−1 Kamimeguro, Meguro−ku, Tokyo, Japan 153−0051

Phone: 81−3−5773−3850

http://onsemi.com

ON Semiconductor Website: http://onsemi.com Order Literature: http://www.onsemi.com/litorder

For additional information, please contact your local Sales Representative.

NCP1117/D

16

ON Semiconductor NCP1117, NCV1117 Technical data

Specifications and Main Features

Frequently Asked Questions

User Manual
