UNIQUE” – BEING WITHOUT A LIKE OR EQUAL.

THE DTR-10.5’S CUTTING EDGE TECHNOLOGY,

CARD-BASED ARCHITECTURE, AND UPGRADEABLE

HARDWARE & SOFTWARE GIVE YOU A HOME THEATER

CENTERPIECE THAT OUTPERFORMS ALL OTHERS.

CARD-BASED THX Ultra 2 A/V Receiver

Customization

0.5 is the world’s first home theater receiver built

TR-1

The D
around a modular, card-based architecture. Integra will
work with your professional installer or retailer to configure
the receiver’s various connections and features to suit the
specific needs of your home theater
flagship status with a family of plug and play card options,
upgradeable software, and P
This truly is a home theater receiver for the next generation.

. It lives up to its

C configuration program.

Designed

to intergra

Ease of Use

Integra has always been recognized for building products
that are easy-to-use and integrate flawlessly into home
control systems. The DTR-10.5 is no exception. Therefore
while it contains the latest technologies and features, a host
of control options allow for seamless operation through
touchpanels, keypads, and other user interfaces. The end
result is a power
remains simple to enjoy.

te. Built to stimulate.

ful, advanced home theater system that

DTR-10.5

THX Ultra2 Certification

For more than a decade, THX Certification has set the highest

standard for home theater equipment. Besides being able to

produce exceptional mo

quality through Ultra2 Cinema and

to create truly uplifting music with

Music Mode, it also features Game

Mode, a post-processing technology

and listening mode that

game experience by immersing the player into the action.

To complete the package, Boundary Gain Compensation

(BGC) reduces “boomy” bass from listening positions

adjacent to walls and other obstructions.

vie sound

revolutionizes the home video

Audiophile-Grade Components

The power supply is arguably one of

the most critical components in a

high-end amplifier. The DTR-10.5

employs a massive toroidal power

transformer to ensure that there is

plenty of current on-demand to beautifully reproduce

the dynamics of music and movies. Custom high capacity

filter capacitors give you greater power delivery at low

frequencies, plus tremendous continuous

power reserves. For hi-fi purists, discrete,

precision matched output transistors pro-

vide faster switching speed, which trans-

lates into a wider dynamic range.

Wolfson®192 kHz/24-Bit DACs for All Channels

Widely recognized as one of the industry’s best, these

sophisticated digital-to-analog converters from Wolfson

process more information faster, deliver an impressive

dynamic range, and are virtually jitter-free. If you want

the best performance possible from

DVD-Audio, Super Audio CD and other

high-resolution formats, you’ll appreciate

these ultra-precise converters.

394)

EEE-1

K (I

N

i.LI

The promise of D

was an elation to music lovers around the world.

Their jubilance was short lived with the realization

that analog cables (up to six of them) would be

needed to connect

soon recognized that these sophisticated multi-channel

VD-Audio and Super Audio CD

VD player to the receiver. It was

the D

recordings, with quality of sound never realized before,

would require a new type of connection to bring out their

true potential. Enter i.LINK – it simplifies and at the same time

expands your audio experience through a high-bandwidth,

high-resolution connection o

carries high-resolution multi-channel audio in the digital

domain to provide the blissful experience you’ve been

waiting for, without the hassle. i.LINK — the new standard

for digital audio.

High-Definition Multimedia Int

HDMI adds digital video to round out the system, creating

a completely digital home

theater experience. While the

name may be imposing, HDMI simplifies wiring by doing

away with the myriad cables required for a state-of-the-art

home entertainment system. By keeping everything in the

digital realm, unnecessary digital to analog conversions

are eliminated. Conventional composite, S-video, and 480i

component sources are upconverted to 480p for reduced

“jaggies” and flicker. With technology shifting to digital

displays such as plasma and LCD, a lossless digital signal

guarantees the crystal-clear images and pristine music your

home theater deserves. HDMI is backwards compatible

with DVI displays by using an adapter cable.

ver a single cable. One wire

erface (HDMI)

Video Upconversion

For those customers with analog displays, the DTR-10.5 also

features high quality conversion of composite and S-video

signals up to component video,

including time-base correction for

increased compatibility. While the

0.5 is one of the most

TR-1

D

advanced home theater

components on the face of the

th, you’re still likely to have

ear

some composite or S-Video only

components in your system.

Connect your VCR, cable box, or

satellite receiver to the DTR-10.5 and each signal will flow

to your compatible TV or projector via one component cable.

This simplifies connection to your display and makes the

system easier to operate since the television can always

remain on the same video input.

Net-Tune

Internet

Radio

Router

Kitchen Home Theater

(

Living Room

)

Broadband
Modem

PC

Ethernet

Zone 2
Speakers

Ethernet

Audio Client

DTR-10.5

The DTR-10.5 is part of the only line-up of home theater

components on the market

to feature networking

capability. With Integra’s exclusive Net-Tune system, at the

push of a button your home theater is transformed from

home entertainment to home network. By connecting the

receiver into your home’s wired or wireless computer

network, the musical possibilities are nearly endless. You

can liberate music files locked inside your computer from

the limitation of underperforming desktop speakers. Turn

your computer into a hard disk server with the Net-Tune

Central media distribution software, and stream M

WAV or WMA files into the DTR-10.5 and out of your home

theater speakers. Plus enjo

new music source using the DTR-10.5’s built-in surround

processing for a full multi-channel experience. Second, bring

a world of music into your home with Internet radio. With a

broadband Internet connection, you’ll have radio stations

from around the world at your fingertips. For songs stored

on your computer you may access the artists, genres,

albums, and playlists, and also sort Internet radio stations

by location, language, and genre – all through the receiver’s

on-screen display on your television. Don’t worry if you don’t

have the TV turned on – you may also utilize the large

display on the DTR-10.5’s front panel. By adding Integra’s

dedicated music server and audio clients, you can increase

the system’s capabilities and enjoy music in up to 12

different rooms at the same time. Now you can listen to the

kind of music you want, when you want, where you want!

Programmable A/B Speaker Outputs

Movies vs. Music

To properly configure your home theater for both 7.1

channel movies and 5.1 music formats, such as DVD-Audio

D, you need to have the rear speakers located in

C

and SA

their optimum location for each format. Seem impossible? It

isn’t. The D

to be used specifically for multi-channel music, setting the

stage for an unparalleled theater and concert experience.

TR-10.5 allows an additional pair of rear speakers

y the ability to listen to this

P3,

Two-Channel Aficionados

Are you thinking of turning your high-end two-channel

listening room into a theater? Wouldn’t it be convenient

if you could keep those tower speakers for two-channel

listening, while still being able to set up a matched

7.1 theater system? By connecting the 7.1 theater system

to the “A” speaker outputs and the towers to the “B”

terminals, you can enjoy the best of both. When listening

to a stereo source, the DTR-10.5 will automatically switch

to the “B” terminals. You may even bridge the left and right

outputs to provide the high current, clean power that you

and your speakers crave!

Web-Based “Configurator”

If you’ve purchased a computer online recently, you’ve

probably gone through the process of selecting the specific

components you desired. To guide you in customizing your

home theater receiver, our web site features a similar

“configurator,” which allows you to select from the available

card options, see a rear panel sketch including all

connections, and even save your configuration for later

review with your Integra dealer.

System Integration Features

Professional installation specialists are praising the

DTR-10.5’s robust offering of installation features. It is

able to deliver different music to the home theater plus two

additional rooms in your home, simultaneously! Dedicated

infrared inputs for each zone allow discrete source and

volume control from each room. For sophisticated home

control systems, an RS-232 control port allows full two-way

communication to touchpanel displays and keypads. For

controlling peripheral devices such as lights, screens and

motorized shades, there are five programmable 12V trigger

outputs. Given its modular configuration, we recommend that

you visit your local authorized Integra dealer to assist in

0.5 for your system. Integra low voltage

tailoring the D

professionals are experts in the various disciplines required

to maximize your home theater investment. Our web site

vides contact information for your local Integra specialist.

pro

TR-1

A Unique Modular Design Sets

E

REMOTE
CONTROL

MAIN

ZONE

3

ZONE

2

IN

AC INLET

A

L

R

FRONT SURR SURR

BACK

CENTER

SUB
WOOFER

SUB
WOOFER

FRONT

L

CENTERFRONT

R

SURR BACK L (ASSIGNABLE

)

SURR

R

SURR L

FRONT

R

(BTL

)

FRONT L (BTL

)

IR

12V
TRIGGER
OUT

RS

232

PRE OUT A

(

SINGLE

)

PRE
OUT B

C

E

200mA MAX.

100mA MAX.

100mA MAX.

100

mA MAX.

100mA MAX.

AC 120V 60Hz

SWITCHED

120W 1A MAX.

AC OUTLET

UDC/UDT

SPEAKERS A

SPEAKERS B

22

1

66

55

44

33

22

11

OPTICAL COAXIAL

AUDIO IN

1

3

2

1

PH

2

3

9

8

7

6

5

4

4

5

RL

LR

L

R

R L

G

IN

1

IN

2

HDMI, the HDMI logo
is a trademark
or registered
trademarks of HDMI
Licensing LLC.

HDMI

S VIDEO VIDEO

IN IN

IN

1

IN 2

3

2

1

Y

P

B

P

R

COMPONENT
VIDEO

IN

3

6

5

4

Y

P

B

P

R

214

3

Y

P

B

P

R

Y

P

B

P

R

COMPONENT VIDEO

IN 4

ANTENNA

FM
75

B

SURR BACK R (ASSIGNABLE

)

A

B

D

DIGITAL IN DIGITAL IN

L

R

S VIDEOS VIDEO VIDEOVIDEO

OUT

CD F

G

HI JK L

MODEL NO.

DTR-10.5

CD

OUT

OUT

F

L

OUT

IH

OUT OUT

J

K

AB

OUT

1

OUT

2

AM

GND

1

“Net-Tune”
is a trademark of
Onkyo Corporation.

ETHERNET

(

Net-Tune

)

A UDIO

The i.LINK logo is a
trademarks of Sony
Corporation, registered
in the U.S. and other
countries.

S400

SBR SBL

SR SL

SUB C

FR

FL

SBR SBL

SR SL

SUB C

FR

FL

MULTI

­CH

IN 1

MULTI

­CH

IN 2

The New Benchmark in Audio Engineering

A truly great home theater receiver will sport a design
and features that set it apart from the rest. The DTR-10.5
earns its place at the top with a unique modular design
which features a vast array of the latest digital
and analog inputs and outputs.

NCLUDED MODULES

I

Module

Digital Audio

C-DGTL

Features six optical and
coaxial inputs, and two
optical and coaxial outputs.
Dual Texas Instruments
DSPs handle signal
processing. Superb DACs
from Wolfson Electronics
feature signal-to-noise
ratios much better than
typically found in an
integrated receiver.

Module

Analog Audio

C-ANLG

Features nine two-channel
analog inputs for conventional
sources, as well as a dedicated
phono input. Five outputs
are configurable for
Main/Zone2/Zone3, both
fixed and variable outputs
are supported.

DC

®

GF

IH

A B C D E F G H I J K L

Module

Video

C-VIDEO

Features six composite
and S-video inputs plus
four assignable outputs.
Component video switching
includes three HD compatible
inputs and one output. All
composite and S-video inputs
are upconverted to 480i
component.

K

Module

uner

M T

AM/F

M

F

C-AM

eatures 4

F
Discrete tuning and preset
station recall are supported
via IR and RS-232.

0 AM/FM presets.

OPTIONAL MODULES

A

Module

i.Link

C-iLINK

All audio formats, including
high-resolution multi-channel
D

VD-Audio and SACD, are
sent in digital form from the
source device to the receiver.
This allows bass management
and other processing to be
per

formed digitally in the

receiver.

B

Module

Net-Tune Ethernet

C-NET-A

Net-Tune is a revolutionary
new technology that allows
your A/V receiver to plug
into your home’s wired or
wireless network to access
music stored on your PC or
dedicated server, as well as
Internet radio.

L

Module

HDMI

C-HDMI

High Definition Multimedia
Interface (HDMI) is the latest
in digital transmission and
connectivity. This format
allows high definition video
to be sent in the digital
domain.

Module

J

BNC Component

C-CPNT-BNC

Adds one BNC component
input and output. BNC
connectors offer a positive
locking connection and
are commonly found on
plasma displays.

E

Module

Multi-channel Input

C-MULTI

Features two multi-channel
inputs for connection to
DVD-Audio and SACD
players. Digital bass
management is possible
and may be bypassed for
“pure” listening.

or

or

J

Module

RCA Component

C-CPNT-RCA

Provides one additional
RCA component input
and output. Passes
high-definition video
without loss or signal
degradation.

E

Module

Multi-channel
& AES/EBU

C-AES

Features one multi-channel
input and one AES/EBU
input. The latter is a high
quality digital format used
in professional equipment
and high-end DVD/CD
transports. Digital bass
management is possible
and may be bypassed for
“pure” listening.

DTR-10.5

DTR-10.5

(base model shown)

FEATURES

TION

AMPLIFICA

• THX Ultra2 Certified 7 channel amplifier

• 7 x 200 Watts/Channel at 6Ω

• 7 x 150 Watts/Channel at 8Ω

• WRAT — Wide Range Amplifier Technology (5 Hz – 100 kHz)

• Linear Optimum Gain Volume Circuitry

PROCESSING

• THX Surround EX 7.1 Processing

• Dolby Digital EX and Pro Logic IIx

• DTS and DTS-ES, DTS Neo:6, DTS 96/24

• Dolby Headphone and Dolby Virtual Speaker

• Dual 32-Bit DSP chips for main and Zone 2

• Non-scaling configuration

• Wolfson 192 kHz/24-bit D/A converters for all channels

• 39 Exclusive DSP soundfields with Direct/Pure bypass modes

• VLSC — Vector Linear Shaping Circuitry

• A-Form listening mode memory and IntelliVolume input level calibration system

VIDEO

• Conversion of composite and s-video to component and HDMI with time-base correction**

• New 5-line digital comb filter for composite to s-video conversion

• 50 MHz bandwidth, professional grade component video switching (4 in, 2 out)

• 7 Composite / S-Video inputs and 4 outputs

CONNECTIONS

• High Definition Multimedia Interface (2 in, 1 out)**

• 2 i.Link inputs for all audio for

• Ethernet for Net-Tune streaming audio**
ee zone multi-r

• Thr

• Independent IR inputs for all 3 zones w/12VDC for IR r

• Bi-directional RS-232 port

• Five assignable 12VDC trigger outputs

• Programmable speaker A/B for all 7.1 channels

• Bridging capable for FL/FR using SBL/SBR

• 13 Digital inputs (7 optical, 6 coaxial, 12 assignable)

• 4 Assignable digital outputs (2 optical, 2 coaxial)

• Two sets of color-coded 7.1 multi-channel inputs, or one multi-channel input

and one AES/EBU input**

• 7.1 Channel color

• Har

dware & software upgradable for future additions

oom capability (Main, Zone 2 and Zone 3)

-coded pre-outputs

mats**

eceivers

SPECIFICATIONS

AMPLIFIER

Continuous average power output (FTC)
All channels: 150 W per channel min. RMS at 8 ohms,

Dynamic power output (stereo): 2 x 340 W at 3 ohms

Frequency response: 5 Hz to 100 kHz: +1/–3 dB
Signal-to-noise ratio: 110 dB (IHF A, 0.5 V input)
Total harmonic distortion: 0.08% at rated power
IM distortion: 0.08% at rated power
Damping factor: 60 at 8 ohms
Muting: Set by user

INPUT SENSITIVITY AND IMPEDANCE

Line (CD, Tape, etc.): 200 mV, 50 k ohms
Multi-Channel inputs (Front L/C/R, Surround L/R,

OUTPUT LEVEL AND IMPEDANCE

Rec out (Tape, Video 1, 2): 200 mV, 470 ohms
Pre out: 1 V, 470 ohms
Zone 2/3 line output:

TONE CONTROL

Bass:
Mid range: ±12 dB at 1,000 Hz
Treble: ±12 dB at 20,000 Hz

FM

uning range:

T
Usable sensitivity

AM

uning range:

T
Usable sensitivity: 30 µV

Surround Back L/R)**: 200 mV, 50 k ohms
(Subwoofer)**: 36 mV, 50 k ohms

eo:

, ster

2 channels driven from 20 Hz to 20
kHz with no more than 0.08% total
harmonic distortion.

200 W min. RMS at 6 ohms, 2 channels

driven from 1 kHz with no more
than 0.08% total harmonic distortion.

2 x 260 W at 4 ohms
2 x 175 W at 8 ohms

, 470 ohms

100 mV

12 dB at 50 Hz

±

87.5–108.0 MHz (100-kHz steps)

17.2 dBf, 2.0

530–1,710 kHz (10-kHz steps)

µV (75 ohms IHF)

MISCELLANEOUS

• Direct access tuning via IR & RS-232

• Variable subwoofer crossover (40 - 150 Hz, 10 Hz steps)

• PC set-up application available via Ether

*Base model configuration
**Reflects optional cards

net and RS-232

PHONO

Input sensitivity: 2.5 mV, 50 k ohms
Overload:
RIAA Deviation:
Signal-to-noise ratio: 80 dB (IHF A, 0.5 V input)

GENERAL

Power supply: AC 120 V, 60 Hz
Power consumption:
Dimensions (W x H x D):

Weight: 70.8 lbs. (32.1 kg)*

ay, Upper Saddle River, NJ 07458 • Telephone: [phone] • Fax: [phone] • www.intergrahometheater.com

18 Park W

70 mV RMS at 1 kHz, 0.5% THD
20 Hz to 20 kHz:

13.0 A*
17-1/8" x 8-11/16" x 18-15/16"
435 x 175 x 429 mm

0.8 dB

±
