Page 1
CDC-3.4
SERVICE MANUAL
Ref. No. 3783
SERVICE MANUAL
COMPACT DISC CHANGER
MODEL CDC-3.4
Oct, 2003
RC-553C
Black model
120V AC, 60HzBMDD
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
Page 2
SPECIFICATION
CDC-3.4 (Compact Disc Changer)
Signal readout system
Frequency response
SN ratio
Audio Dynamic range
THD (Total harmonic distortion)
Audio output (Digital/Optical)
Audio output/Impedance (Digital/Coaxial)
.................................................................
......................
...................................
...........................................
Optical non-contact
......
0.005% (at 1 kHz)
......................
5 Hz-20 kHz
98 dB
96 dB
-22.5 dBm
.....
0.5 V (p-p) / 75 ohm
CDC-3.4
Audio output/Impedance (Analog)
Power supply rating
Power consumption
Standby power consumption
Dimensions (W
.................................................
Weight
Operating conditions Temperature/Humidity
Disc compatibility CD, CD-R, CD-RW
RC-553C (Remote Controller)
Transmitter
Signal range
Power supply
Specifications and features are subject to change without notice.
..............................
................................................
.......
xHxD)
...........................
.........................................................
..............................
............
Two (AA/R6) batteries (1.5 V x 2)
.................
....................................
17-1/8" x 5-3/16" x 17-3/16"
Approx. 16 ft., 5 meters
2.0 V (rms) / 470 ohm
AC 120 V 60 Hz
10 W
4 W
15.0 lbs. (6.8 kg)
........
41-95 F (5 -35 C) / 25-80%
Infrared
(435 x 131 x 436 mm)
Page 3
SERVICE PROCEDURES
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
CDC-3.4
This set employs a laser. Therefore, be sure to follow
carefully the instructions below when servicing.
WARNING!!
SERVICE WARNING : DO NOT APPROACH THE
LASER EXIT WITH THE EYE TOO CLOSELY.
IN CASE IT IS NECESSARY TO CONFIRM LASER
BEAM EMISSION, BE SURE TO OBSERVE FROM
A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE
OPTICAL PICKUP BLOCK.
LASER WARNING LABEL
The labels shown below are affixed.
Warning label
Laser Diode Properties
Material: GaAS/GaAlAs
Wavelength: 780nm
Laser output: max. 0.5mW*
Emission Duration: continuous
*This output is the value measured at a distance about 1.8mm
from the objective lens surface on the Optical Pickup Block.
DANGER:
INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCK FAILED OR DEFEATED. AVOID DIRECT
EXPOSURE TO BEAM.
CAUTION:
HAZARDOUS LASER AND ELECTROMAGNETIC
RADIATION WHEN OPEN AND INTERLOCK DEFEATED.
ATTENTION:
RAYONNEMENT LASER ET ELECTROMAGNETIQUE
DANGEREUX SI OUVERT AVEC L'ECLENCHEMENT
DE SECURITE ANNULE.
Safety check out
After correcting the original service problem perform
the following safety check before releasing the set
to the customer.
Connect the insulating-resistance tester between the
plug of power supply cord and terminal GND on the
back panel.
Specifications: More than 10 M ohm at 500V.
Initializing the unit
Press "STOP" key and "STANDBY" key at same time.
Displayed "INITIALIZE" on the FL display.
(Only U.S.A. model)
Page 4
PANEL VIEW-1
FRONT PANEL
CDC-3.4
1 2 3 4 5 6 7 8 9
1
Standby/On button
This button is used to set the CDC-3.4 to On or
Standby.
2
Standby indicator
This indicator lights up when the CDC-3.4 is
in Standby mode.
3
Repeat button
This button is used with the Repeat function.
4
Random button
This button is used with the Random function.
5
Dimmer button
This button is used to adjust the display brightness.
6
Display button
This button is used to display elapsed, remaining,
and total time information about the current disc or
track and various information about MP3 tracks.
7
Remote control sensor
This sensor receives control signals from the remote
controller.
Display
10
Disc tray
8
Open/Close button
1112131415
This button is used to open and close the disc tray.
9
Disc Select buttons
These buttons are used to select discs. Playback
starts automatically when a disc is selected with one
of these buttons.
10
Play/pause button
This button is used to start and pause playback.
11
Stop button
This button is used to stop playback.
[ ]/[ ] & Folder []/[] buttons
12
These buttons are used to select the previous and
next tracks and to navigate folders on MP3 discs.
[ ]/[ ] & Folder
13
[]/[] buttons
These buttons are used for fast reverse and fast
forward and to navigate folders on MP3 discs.
14
Disc Skip button
This button is used to turn the disc tray when
loading or removing discs and to select discs for playback.
15
Disc tray light
This light illuminates the disc tray. It comes on
when the CDC-3.4 is turned on and gets brighter
when the disc tray is open.
Page 5
PANEL VIEW-2
FL DISPLAY
1
2 3 4
CDC-3.4
5
6
7
9
8
10
11 12 13
REPEAT
MEMORY
RANDOM
RANDOM indicator
1
2
MEMORY indicator
REPEAT indicator
3
4
DISC indicator
FLDR
The number of the current disc appears here.
5
FLDR (FOLDER) indicator
While stopped, the total number of folders on the
current MP3 disc are displayed. During playback,
the number of the current folder is displayed.
6
NEXT indicator
This indicator appears when using
the Next Selection function.
REAR PANEL
NEXT TOTALDISC
TRACK
NAME
7
REMAIN
TRACK indicator
MP3
3
2
1
6
5
4
While stopped, the total number of tracks on the
current disc are displayed. During playback, the
number of the current track is displayed.
8
NAME indicator
This indicator appears when the current disc is an
MP3 disc and a name (disc, folder, track) is
being displayed.
9
TOTAL indicator
This indicator appears when the total remain
time is displayed.
10
REMAIN indicator
11
Play / Pause indicator
12
MP3 indicator
13
Disc indicators 1-6
456
IR
RS
232
IN
OUT
1 2 3
1
ANALOG AUDIO OUTPUT
These RCA/phono connectors can be connected to
the analog audio inputs on a hi-Þ amp or AV
receiver.
2
COAXIAL & OPTICAL DIGITAL AUDIO
OUTPUT
These connectors can be used to connect a CD-R,
MiniDisc, DAT recorder, digital amp, or other
equipment with digital inputs.
3
REMOTE CONTROL
These (Remote Interactive) connectors can be
connected to the connectors on your other
Integra/Onkyo AV components for interactive control.
To use you must also make analog audio connections (RCA/phono) between the CDC-3.4 and
your other Integra/Onkyo equipment.
COMPACT DISC CHANGER
MODEL NO.
CDC
:
RATING
V 60 Hz 10 W
AC 120
Integra
Division of
ONKYO CORPORATION
2-1
, NISSHIN-CHO, NEYAGAWA-SHI, OSAKA,
MADE IN CHINA
JAPAN
4
AC INLET
-
3.4
AC INLET
The supplied power cord is connected here. The
other end of the power cord should be connected to
a suitable wall outlet.
5
RS 232
This RS-232 port can be connected to an external
controller.
6
IR IN/OUT
The IR IN connector can be used to connect a commercially available IR receiver, which can be used
to pickup signals from the remote controller when
the CDC-3.4 is located in another room, installed in
a rack, or is out of range of the remote controller.
The IR OUT connector can be used to connect a
commercially available IR emitter, which can be
used to pass remote controller signals received by
the IR IN along to other AV components.
Page 6
PANEL VIEW-3
REMOTE CONTROLLER (RC-533C)
1
2
3
4
5
6
7
8
10
11
12
13
14
15
CDC-3.4
On button
1
This button is used to turn on the CDC-3.4.
2
Standby button
This button is used to set the CDC-3.4 to Standby.
3
9
Number buttons
These buttons are used to enter track and MP3
folder numbers.
4
Search (>10) button
This button is used to enter track numbers above 10
and to select MP3 folders.
5
Operation buttons
Pause [ ] button
This button is used to pause playback.
Stop [ ] button
This button is used to stop playback.
Play [ ] button
This button is used to start playback.
6
[ ]/[ ] & Folder [ ]/[ ] buttons
These buttons are used for fast reverse and fast
forward, and to navigate folders on MP3 discs.
7
Next Selection button
This button is used with the Next Selection function
for cuing up the next track.
8
Disc Select buttons
These buttons are used to select discs. Playback
starts automatically when a disc is selected with one
of these buttons.
9
Open/Close
[] button
This button is used to open and close the disc tray.
10
Repeat button
This button is used with the Repeat function.
11
Random button
This button is used with the Random function.
12
Memory button
This button is used with the Memory function.
13
Clear button
This button is used to cancel various functions.
14
[ ]/[ ] & Folder [ ]/[ ] buttons
These buttons are used to select the previous and
next tracks, and to navigate folders on MP3 discs.
15
Disc [+] & [-] buttons
These buttons are used to select discs.
Page 7
M40
1
CDC-3.4
A103
A103
A103
2
3
5
M38
4
A103
A221
M38
6
M36
A12
Cloth tape
M35
M34
Cloth tape
(80)
P702
U25
A12
M30
A12
A12
U28
A12
U21
A51
A12
U29
A12
A12
A103
A2
A7
U20-1
A32
A226
A12
A225
A5
A1
A12
A205
A208
.4
-3
C
D
C
A103
A301
A201
A209
A103
A103
A103
Page 8
