Compact Disc Player
C-705X
Instruction Manual
English
Before using
Connections
STANDBY/ON
STANDBY
COMPACT DISC PLAYER
DISPLAY
DUAL OPTICAL OUTPUT
TR-1
C-705X
Operations Other Information
Before using
Thank you for purchasing ...
Thank you for purchasing Onkyo C-705X CD player.
Please read this manual thoroughly before making connections and plugging in the unit.
Following the instructions in this manual will enable you to obtain optimum performance and listening
enjoyment from your new C-705X.
Please retain this manual for future reference.
Main Features
• High-Quality Separate Component
• Dual-Channel Optical Digital Outputs
• Linear Single-bit D/A Converter
• TR-1 Play Mode (for playing only the first song)
WARNING:
TO REDUCE THE RISK OF FIRE OR
WARNING
RISK OF ELECTRIC SHOCK
ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
This unit contains a semiconductor laser system and is
classified as a “CLASS 1 LASER PRODUCT”. So, to use
this model properly, read this Instruction Manual
carefully. In case of any trouble, please contact the store
where you purchased the unit. To prevent being exposed
to the laser beam, do not try to open the enclosure.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
DANGER:
INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCK FAILED OR DEFEATED. AVOID DIRECT
EXPOSURE TO BEAM.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
AVIS
DO NOT OPEN
This label on the rear panel states that:
1.
2.
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
“CLA SS 1 LASE R
PRODUCT”
This unit is a CLASS 1 LASER PRODUCT
and employs a laser inside the cabinet.
To prevent the laser from being
exposed, do not remove the cover.
Refer servicing to qualified personnel.
2
Important Safeguards
1. Read Instructions – All the safety and
operating instructions should be read before
the appliance is operated.
2. Retain Instructions – The safety and
operating instructions should be retained for
future reference.
3. Heed Warnings – All warnings on the
appliance and in the operating instructions
should be adhered to.
4. Follow Instructions – All operating and use
instructions should be followed.
5. Water and Moisture – The appliance should
not be used near water – for example, near a
bathtub, washbowl, kitchen sink, laundry tub,
in a wet basement, or near a swimming pool,
and the like.
6. Carts and Stands – The appliance should be
used only with a cart or stand that is
recommended by the manufacturer.
6A. An appliance and cart
combination should be
moved with care. Quick
stops, excessive force, and
uneven surfaces may cause
the appliance and cart
combination to overturn.
7. Wall or Ceiling Mounting – The appliance
should be mounted to a wall or ceiling only
as recommended by the manufacturer.
8. Ventilation – The appliance should be
situated so that its location or position does
not interfere with its proper ventilation. For
example, the appliance should not be situated
on a bed, sofa, rug, or similar surface that
may block the ventilation openings; or if
placed in a built-in installation, such as a
bookcase or cabinet that may impede the flow
of air through the ventilation openings, there
should be free space of at least 5 cm (2 in.)
and an opening behind the appliance.
9. Heat – The appliance should be situated away
from heat sources such as radiators, heat
registers, stoves, or other appliances (including
amplifiers) that produce heat.
PORTABLE CART WARNING
S3125A
10. Power Sources – The appliance should be
connected to a power supply only of the type
described in the operating instructions or as
marked on the appliance.
11. Polarization – If the appliance is provided with a
polarized plug having one blade wider than the
other , please read the following information:
The polarization of the plug is a safety feature.
The polarized plug will only fit the outlet one
way . If the plug does not fit fully into the outlet,
try reversing it. If there is still trouble, the user
should seek the services of a qualified electrician.
Under no circumstances should the user attempt
to defeat the polarization of the plug.
12. Power-Cord Protection – Power-supply
cords should be routed so that they are not
likely to be walked on or pinched by items
placed upon or against them, especially near
plugs, convenience receptacles, and the point
where they exit from the appliance.
13. Cleaning – The appliance should be cleaned
only as recommended by the manufacturer.
14. Nonuse Periods – The power cord of the
appliance should be unplugged from the outlet
when left unused for a long period of time.
15. Object and Liquid Entry – Care should be taken
so that objects do not fall and liquids are not spilled
into the enclosure through openings.
16. Damage Requiring Service – The appliance
should be serviced by qualified service
personnel when:
A. The power-supply cord or the plug has
been damaged; or
B. Objects have fallen, or liquid has been
spilled into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate
normally or exhibits a marked change in
performance; or
E. The appliance has been dropped, or the
enclosure damaged.
17. Servicing – The user should not attempt to
service the appliance beyond that described in
the operating instructions. All other servicing
should be referred to qualified service personnel.
Before Using
Connections
Operations
Other Information
3
Precautions
1. Warranty Claim
You can find the serial number on the rear panel
of this unit. In case of warranty claim, please report this number.
2. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE FIRST
TIME, READ THE FOLLOWING SECTION CAREFULLY.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., AC
230 V, 50 Hz or AC 120 V, 60 Hz) written on the
rear panel.
Setting the STANDBY button to standby does not
shut off the power completely. So the power cord
should be removed from the AC outlet when the
unit is not used for a prolonged time.
3. Do not touch this unit with wet hands
Do not handle this unit or power cord when your
hands are wet or damp. If water or any other liquid enters the case, take this unit to an authorized
service center for inspection.
4. Location of this unit
Place this unit in a well-ventilated location.
Take special care to provide plenty of ventilation
on all sides of this unit especially when it is placed
in an audio rack. If ventilation is blocked, this unit
may overheat and malfunction.
Do not expose this unit to direct sunlight or heating units as this unit’s internal temperature may
rise and shorten the life of the pickup.
Avoid damp and dusty places and places directly
affected by vibrations from the speakers. In particular, avoid placing the unit on or above one of
the speakers.
Be sure this unit is placed in a horizontal position.
Never place it on its side or on a slanted surface as
it may malfunction.
Do not place near tuners or TV sets.
If placed next to a TV or tuner , it may cause r eception interference resulting in some noise in the TV
or tuner output.
5. Care
From time to time you should wipe the front and
rear panels and the cabinet with a soft cloth. For
heavier dirt, dampen a soft cloth in a weak solution of mild detergent and water , wring it out dry,
and wipe off the dirt. Following this, dry immediately with a clean cloth.
Do not use rough material, thinners, alcohol or
other chemical solvents or cloths since these could
damage the finish or remove the panel lettering.
6. Points to remember
If this unit is brought from a cold environment to
a warm one or is in a cold room that is quickly
heated, condensation may form on the pickup,
preventing proper operation. In this case, remove
the disc and leave the power ON for about one
hour to remove the condensation.
When transporting this unit, be careful not to
bump it.
4
For U.S. model
The laser is covered by a housing which prevents
exposure during operation or maintenance. However, this product is classified as a Laser Product
by CDRH (Center for Devices and Radiological
Health) which is a department of the Food and
Drug Administration. According to their regulations 21 CFR section 1002.30, all manufactures
who sell Laser Products must maintain records of
written communications between the manufacturer, dealers and customers concerning radiation
safety. If you have any complaints about instructions or explanations affecting the use of this product, please feel free to write to the address on the
back page of this manual. When you write us,
please include the model number and serial number of your unit.
In compliance with Federal Regulations, the certification, identification and the period of manufacture are indicated on the rear panel.
FCC INFORMATION FOR USER
CAUTION:
The user changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Before Using
Connections
Operations
Other Information
5
Precautions
For Canadian model
CAUTION: THIS DIGIT AL APPARA TUS DOES NOT
EXCEED THE CLASS B LIMITS FOR RADIO NOISE
EMISSION FROM DIGITAL APPARA TUS SET OUT IN
THE RADIO INTERFERENCE REGULATIONS OF THE
CANADIAN DEPARTMENT OF COMMUNICATIONS.
For models having a power cord with a polarized
plug:
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
Modele pour les Canadien
ATTENTION: L’INTERFÉRENCE RADIO
ÉLECTRIQUE GÉNÉRÉE PAR CET APPAREIL
NUMÉRIQUE DE TYPE B NE DÉPASSE PAS LES
LIMITES ÉNONCÉES DANS LE RÈGLEMENT SUR LES
PERTURBATIONS RADIO ÉLECTRIQUES, SECTION
APPAREIL NUMÉRIQUE, DU MINISTÈRE DES COMMUNICATIONS.
Sur les modèles dont la fiche est polarisée:
ATTENTION: POUR ÉVITER LES CHOCS
ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQU’AU FOND.
For British model
Replacement and mounting of an AC plug on the
power supply cord of this unit should be performed
only by qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of
this apparatus may not correspond with the
coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured blue must be connected
to the terminal which is marked with the letter N
or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the
letter L or coloured red.
IMPORTANT
A 5 amp fuse is fitted in this plug. Should the fuse
need to be replaced, please ensure that the replacement fuse has a rating of 5 amps and that it
is approved by ASTA or BSI to BS1362. Check for
the ASTA mark or the BSI mark on the body of the
fuse.
IF THE FITTED MOULDED PLUG IS UNSUIT ABLE FOR
THE SOCKET OUTLET IN YOUR HOME, THEN THE
FUSE SHOULD BE REMOVED AND THE PLUG CUT
OFF AND DISPOSED OF SAFELY. THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT
OFF PLUG IS INSERTED INTO ANY 13 AMP SOCKET .
If in any doubt, please consult a qualified electrician.
Declaration of Conformity
We,
ONKYO EUROPE
ELECTRONICS GmbH
INDUSTRIESTRASSE 20
82110 GERMERING,
GERMANY
declare in own responsibility, that the ONKYO product described
in this instruction manual is in compliance with the corresponding
technical standards such as EN60065, EN55013, EN55020 and
EN61000-3-2, -3-3 (or EN60555-2, -3)
GERMERING, GERMANY
6
ONKYO EUROPE ELECTRONICS GmbH
K.OTSU
Table of contents
Connections
Connecting to Onkyo Separate Collection series components ......................... 8
Connecting to the other components ........................................................... 10
Operations
Playing CDs................................................................................................... 13
Other Information
Handling CDs................................................................................................ 19
Troubleshooting ............................................................................................ 20
Indexed to parts and controls........................................................................ 21
Specifications................................................................................................ 24
Before Using
Before Using
Connections
Supplied accessories
Check that the following accessories are supplied with this unit.
remote control cable × 1
Note
This C-705X Compact Disc Player can be operated using an optional RC-289C remote controller. To
obtain an RC-289C, contact the dealer where you purchased the C-705X, or contact Onkyo directly,
at the address on the back cover page.
Audio connection cable × 1
Operations
Other Information
7
Connections
Connecting to Onkyo Separate Collection series components
This section introduces you to the other Separate Collection Series system components and their convenient system functions, followed by instruction on how to connect the system.
The following Separate Collection Series components are available:
• A-905X....... Integrated Stereo Amplifier
• T-405X........ Stereo tuner
• K-505X ....... Stereo Cassette Tape Deck
• MD-105X ... Minidisc (MD) Recorder (Not available in U.S. and Canada)
Note that the available components may vary according to the area.
Combining the C-705X Compact Disc player with the above system components enables you to operate the following convenient functions:
• Auto Power On
– You can turn on the power to the amplifier by pressing the STANDBY/ON button on one of the
system components. (The amplifier’s POWER switch must be set to ON.)
– When the amplifier's POWER switch is set to ON, you can turn on the power to all the system
components simultaneously by pressing the STANDBY/ON button on the amplifier.
Afterwards, you can turn off the power to the individual components that are not in use.
• Direct Change
Press the following button on the component you want to operate. The amplifier will automatically
select the input from the corresponding component:
– The play button on the CD player, MD recorder, or stereo cassette tape deck; or
– The PRESET √/® buttons on the tuner.
• Remote Control Operation
You can operate all the system components using the remote controller supplied with the amplifier
A-905X.
• Program Timer
You can operate the timer playback and recording functions using the T-405X. (Refer to the T-405X
instruction manual for more information.)
• Sleep Timer
Y ou can fall asleep to a music/radio pr ogram using the timer. (Refer to the T-405X instruction manual
for more information.)
• CD Dubbing
Simple CD dubbing using a stereo cassette tape deck or MD recorder is possible with the pr essing of
a single button. (Refer to the K-505X or MD-105X Instruction Manual for more information).
• CD/MD Synchro Recording
When using a stereo cassette tape deck or MD recorder to r ecor d fr om the CD player or when using
a stereo cassette tape deck to record from an MD recorder, you can record with simply starting on a
CD player or MD recorder. (Refer to the K-505X or MD-105X instruction manual for more information.)
• Dubbing a specific track from CD
Y ou can specify a track on a CD and easily dub it to a connected MD r ecorder. (Refer to the MD-105X
instruction manual for more information.)
8
Using the remote controller
The unit is not shipped with a remote controller.
However, you can use a remote controller (RC398S) that is shipped with the A-905X amplifier
or an optional remote controller (RC-289C).
Remote controller RC-398S
When the remote controller RC-398S supplied with
the amplifier A-905X is used, operate the remote
controller pointing towards the amplifier’s remote
sensor.
Be sure to make the
the connection is incomplete, you cannot use the
remote controller to operate the unit.
A-905X
Remote control
sensor
30°
30°
RC-398S
Note
The DISC button on the RC-398S remote controller cannot be used.
Remote controller RC-289C
When the optional remote controller RC-289C is
used, operate the remote controller pointing towards the CD player’s remote sensor.
connection securely. If
5m
C-705X
Notes
• Place the unit away from strong light such as
direct sunlight or inverted fluorescent light which
can prevent proper operation of the remote
controller.
• Using another remote controller of the same
type in the same room or using the unit near
equipment which uses infrared rays may cause
operational interference.
• Do not put any object such as a book on the
remote controller. The buttons of the remote
controller may be pressed by mistake and drain
the batteries.
• Make sure the audio rack doors do not have
colored glass. Placing the unit behind such doors
may prevent proper remote controller operation.
• If there is any obstacle between the remote controller and the remote control sensor, the remote controller will not operate.
Before Using
Connections
Operations
C-705X
Remote control
sensor
30°
30°
RC-289C
5m
Note
The DISC 1 to DISC 6 buttons and the NEXT SELECTION button on the RC-289C remote controller cannot be used.
Other Information
9
Connecting to the other components
Before connecting
• Do not connect the unit’s AC power cord to a wall outlet until you have completed all the other
connections.
• On each pair of connectors, a red connector (marked R) corresponds to the right channel, and a
white connector (marked L) to the left channel. Connect white plugs of audio connection cables to
L connectors and connect red plugs of audio connection cables to R connectors.
Audio connection cable
To L connectors
To R connectors (Red)
• Insert the plug securely. If the connection is incomplete, noise or malfunction may result.
Improper connection
Insert completely
• When you use a digital audio optical cable, do not bend it sharply nor coil it tightly.
• Bundling an audio connection cable with the power cord or speaker cord may degrade the sound
quality.
• To use the unit with the other Onkyo Separate Collection series components, follow the connection
diagram in the A-905X instruction manual to connect the unit to the system.
(White)
(White)
(Red)
To L connectors
To R connectors
Note:
The 230 V model is shown in the following illustrations.
10
Connections
Audio
connection
cable
L
R
ANALOG
OUTPUT
REMOTE
CONTROL
COMPACT DISC PLAYER
MODEL NO.
C-705X
DIGITAL OUTPUT
OPTICAL
12
AC OUTLET
AC230V 50Hz
UNSWITCHED
100W MAX.
"CLASS 1 LASER
PRODUCT"
To wall outlet
Before Using
1
LR
CD
Amplifier without
digital input terminal
cable
connector
2
DIGITAL IN
MD recorder, CD-R recorder,
DAT deck, etc.
Optional Optical
fiber cable
1 Connection with the Amplifier
3
Connect the ANALOG OUTPUT connectors on the rear panel of C-705X and the amplifier’s CD
input connectors using the audio connection cable. Refer to the amplifier’s instruction manual for
connections.
2 Connection to DIGITAL OUTPUT connector
Using the DIGITAL OUTPUT connector, you can recor d on digital audio equipment, such as an MD,
CD-R, DAT, etc. For digital r ecor ding, connect the equipment to either DIGITAL OUTPUT OPTICAL 1
or 2 connector using the optical cable (option). These connectors can also be used for connecting
an amplifier which is equipped with a digital input connector.
A connector protection cap is attached to the digital output connector. Remove this cap to connect the unit to other digital equipment. When you are
not using the digital output connector, replace this cap.
3 AC OUTLET (UNSWITCHED)
The AC power cord of another component can be connected to this AC OUTLET connector.
This means that if the C-705X is plugged
into an AC outlet, AC power is available
to this AC OUTLET even if the C-705X is
off.
The shape and capacity of the AC outlet
may differ depending on the area of purchase. Make sure that the capacity of other
components connected to this unit does
not exceed the capacity that is printed on
the rear panel.
ANALOG
OUTPUT
L
R
REMOTE
CONTROL
COMPACT DISC PLAYER
MODEL NO. C-705X
DIGITAL OUTPUT
OPTICAL
12
AC OUTLET
AC230V 50Hz
UNSWITCHED
100W MAX.
"CLASS 1 LASER
PRODUCT"
120 V, 60 Hz models230 V, 50 Hz models
Capacity is
100 watts.
Capacity is
120 watts.
Connections
Operations
Other Information
11
Connecting to the other components
Connecting the connector
If you are using other ONKYO components equipped
with
ponents using the amplifier‘s remote controller.
Before connecting
• The amplifier must be connected in the
• Each component has two
• The components may be connected in any order .
• Remote control operation is not possible if only
The illustration below is the
With these hookups, you can operate the CD Synchro Recording (see “CD/MD synchro recording”
on page 8).
connectors, you can control these com-
system hookups for control operations.
connectors. There
is no difference between those connectors.
the
the
remote control cable is connected to
connectors. Connect the audio connec-
tion cables correctly.
hookup example.
Tuner
Amplifier
Cassette Tape Deck
cable
cable
Connecting the power cord
Insert the AC power cord into a wall
outlet. The STANDBY indicator lights.
To wall outlet
STANDBY/ON
STANDBY
Light
• To use the unit with the other Onkyo Separate Collection series components, follow the
connection diagram in the A-905X instruction manual to connect the unit to the system.
• If you press the
the unit is in the STANDBY mode, the power
will turn on and the display will light up automatically .
(OPEN/CLOSE) button while
C-705X
REMOTE
CONTROL
Note
An
remote control cable equipped with a 1/
8 in. (3.5mm) diameter miniature two-conductor
phone plug is included with this unit and with every tuner and cassette deck that bears the
mark.
12
Supplied
cable
Operations
REMOTE CONTROL RC-289C
RANDOMNEXT SELECTION
DISC 1 DISC 2 DISC 3
DISC 4 DISC 5 DISC 6
REPEAT
MEMORY
CLEAR
123
456
789
+10 0
RC-289C
RC 398S
Playing CDs
Disc tray
STANDBY/ON
COMPACT DISC PLAYER
STANDBY/ON
STANDBY
DISPLAY
DUAL OPTICAL OUTPUT
POWER
TR-1
C-705X
Normal play
• When you are using the C-705X with the A905X Onkyo Separate Collection series component, turn the A-905X’s POWER switch ON.
1 Press STANDBY/ON button or
POWER button on the remote controller RC-398S to turn on the unit.
The STANDBY indicator goes of f, and the display will light up.
STANDBY/ON
STANDBY
(RC-398S)
POWER
2 Press the (OPEN/CLOSE) button
to open the disc tray.
(RC-289C)
Label side
3 Put the disc in the
disc tray, with its
label side facing up.
RC-398S
POWER
CLOCK CALL
TUNER
PRESET
FM AM
REPEAT SCROLL
PLAY MODE
REPEAT RANDOM
MEMORY CLEAR
TIMER
UP/DOWN
ENTER
ACOUSTIC
SLEEP
PRESENCE
DVD
MD
CLEAR
REC
CD
DISC
CD/MD
12
456
789
- - / - - - 10/0
INPUT SELECTOR
G.EQUALIZER
EFFECT
MODE
TAPE
PAUSE/STEP
3
VOLUME
MUTING
RC-398SREMOTE CONTROLLER
(Supplied
with A-905X)
(Optional)
5 Press the button.
The CD player starts playing the first track
(track 1).
• If the
button is pressed when the unit is in
STANDBY mode, it turns on automatically then
starts playing the CD, if one is loaded in the
disc tray. Your amplifier also turns on if it is an
Onkyo A-905X (refer to page 8).
If the CD player does not start playing when
the
button is pressed
• The disc may be upside down in the tray. Press
the
button to open the disc tray. If you cannot see the label on the disc, turn the disc over ,
label side up.
• Moisture may have formed inside the CD player .
Remove the CD from the disc tray and leave
the power on for about one hour to evaporate
the moisture.
To stop playing
Press the
button.
Remote controller
Remote controller
Before Using
Connections
Operations
Other Information
4 Press the button to close the disc
tray.
Note
Y ou can skip this step by pressing the
ton instead of the
disc tray closes automatically and Track 1
starts playing.
(RC-289C)
but-
button. In this case, the
To pause playing
Press the
button. (The PAUSE indicator lights.)
To resume play, press the
or button.
Remote controller
13
5
1
2
- -
/ - - -
10 / 0
Playing CDs
STANDBY/ON
COMPACT DISC PLAYER
DUAL OPTICAL OUTPUT
STANDBY
DISPLAY
TR-1
C-705X
,
Starting playback from a given track
1 Select the track you wish to play
using the
tons (or the
the remote controller).
and but-
and buttons on
Remote controller
2 Press the button.
The CD player starts playing the selected track.
Remote controller
RC-398S
POWER
ACOUSTIC
CLOCK CALL
SLEEP
PRESENCE
TUNER
PRESET
FM AM
DVD
REPEAT SCROLL
PLAY MODE
CLEAR
REPEAT RANDOM
MEMORY CLEAR
DISC
CD/MD
TIMER
12
456
UP/DOWN
789
- - / - - - 10/0
ENTER
INPUT SELECTOR
G.EQUALIZER
EFFECT
MODE
TAPE
PAUSE/STEP
MD
REC
CD
3
VOLUME
MUTING
RC-398SREMOTE CONTROLLER
(Supplied
with A-905X)
,
Number
buttons
,,
DISC 1 DISC 2 DISC 3
DISC 4 DISC 5 DISC 6
REMOTE CONTROL RC-289C
RC-289C
123
456
789
+10 0
(Optional)
RANDOMNEXT SELECTION
REPEAT
MEMORY
CLEAR
Search play
1 Hold down the or
button (or the or button on
the remote controller RC-289C) dur ing play.
(RC-289C)
2 Release your finger when the mu-
sic you would like to listen to is
reached.
The music starts playing from that point.
Number
buttons
Using the remote controller
With the RC-398S remote controller (supplied with
the A-905X) or the RC-289C remote controller
(sold separately), you can select the track to play
using the number buttons. In either case, selecting a track automatically starts play of that track.
How to enter track numbers
Skip play
Each time the button (or the button on the remote controller) is pressed when a
disc is playing, the pickup will advance one track;
and each time the
button on the remote controller) is pressed when
a disc is playing, the pickup will go back one track.
Press these buttons until the desired track num-
button (or the
ber is selected.
RC-398S RC-289C
5
Remote controller
To enter track #5 :
To enter track #10 :
To enter track #21 :
14
0
+10
2
1
Display information
Before starting playback after you
have inserted a disc
a
The total number of tracks on the disc.
b
A number appears on the display for every
track on the disc.
a
b
5
4321
9876
• When the number of tracks exceeds 15, the >15
indicator lights.
After you have started playback
c
Shows how long the current track has been
playing.
d
Tracks that have finished playing do not have
numbers displayed.
c
d
Checking the elapsed or remaining
time
The display changes each time you press the DISPLAY button during play.
a
SINGLE ELAPSED: Shows how long the current track has been playing.
b
SINGLE REMAIN: Shows how much time is
left for the track currently playing.
For T rack 21 or later tracks, the display shows
“_ _: _ _”.
c
TOTAL REMAIN: Shows how much playing
time is left for the entire disc.
During Memory play, this display shows the
playing time remaining for the entire sequence
of tracks programmed into memory.
d
Shows the track numbers.
a
SINGLE ELAPSED
DISPLAY
5
4321
9876
Before Using
Connections
SINGLE ELAPSED
5
4321
9876
Checking the playing time of each
track
Press the DISPLAY button when the unit is
stopped.
• Each time you press the
button, the display shows the playing time of
the previous or next track, following the order of the tracks on the CD.
DISPLAY
SINGLE
SINGLE
REMAIN
REMAIN
Note:
Press twice the DISPLAY button when the unit is
stopped, the display shows the total remaining
time.
or
5
4321
9876
5
4321
9876
SINGLE
DISPLAY
TOTAL REMAIN
DISPLAY
DISPLAY
REMAIN
b
5
4321
9876
Operations
c
5
4321
9876
d
5
4321
9876
Other Information
15
Playing CDs
RC 398S
REMOTE CONTROL RC-289C
RANDOMNEXT SELECTION
DISC 1 DISC 2 DISC 3
DISC 4 DISC 5 DISC 6
REPEAT
MEMORY
CLEAR
123
456
789
+10 0
RC-289C
RANDOM
STANDBY/ON
COMPACT DISC PLAYER
DUAL OPTICAL OUTPUT
STANDBY
DISPLAY
TR-1
TR-1
C-705X
Playing the first track only (TR-1
Play)
In this mode, the unit plays only the first track of
the disc then stops. The TR-1 Play mode is useful
for playing disc singles. You cannot use the remote controller for this operation.
1 Press the TR-1 button.
The TR-1 indicator appears.
TR-1
TR
-1
2 Press the button.
The unit starts playing the first track of the
disc.
RC-398S
POWER
ACOUSTIC
SLEEP
CLOCK CALL
PRESENCE
TUNER
PRESET
FM AM
REPEAT SCROLL
PLAY MODE
CLEAR
REPEAT RANDOM
MEMORY CLEAR
DISC
CD/MD
TIMER
12
456
UP/DOWN
789
- - / - - - 10/0
ENTER
INPUT SELECTOR
G.EQUALIZER
EFFECT
MODE
TAPE
DVD
PAUSE/STEP
MD
REC
CD
3
VOLUME
MUTING
RC-398SREMOTE CONTROLLER
(Supplied
with A-905X)
RANDOM
(Optional)
• To perform Random, Memory or Repeat play,
you need either of the following remote controllers:
RC-398S (supplied with A-905X amplifier)
RC-289C (optionally available)
Playing tracks in random order
(Random play)
1 Press the RANDOM button to enter
Random play mode.
The CD player plays the tracks in a random
order.
RANDOM
5
4321
109876
RANDOM
1211
16
To quit TR-1 play
Press the TR-1 button again.
TR-1
• Random play will be canceled when the RANDOM,
(OPEN/CLOSE) or button is pressed,
or when all tracks on disc have been played.
• Random play can be performed in conjunction
with Memory and Repeat modes.
RC 398S
CLEAR
REMOTE CONTROL RC-289C
RANDOMNEXT SELECTION
DISC 1 DISC 2 DISC 3
DISC 4 DISC 5 DISC 6
REPEAT
MEMORY
CLEAR
123
456
789
+10 0
RC-289C
MEMORY
Number
buttons
CLEAR
5
1
2
- -
/ - - -
10 / 0
CLEAR
MEMORY
RC-398S
POWER
SLEEP
CLOCK CALL
TUNER
PRESET
FM AM
REPEAT SCROLL
PLAY MODE
CLEAR
REPEAT RANDOM
MEMORY CLEAR
TIMER
12
456
UP/DOWN
789
ENTER
- - / - - - 10/0
INPUT SELECTOR
G.EQUALIZER
ACOUSTIC
EFFECT
PRESENCE
TAPE
DVD
PAUSE/STEP
MD
REC
CD
DISC
CD/MD
3
MUTING
(Supplied
with A-905X)
MODE
Number
VOLUME
buttons
RC-398SREMOTE CONTROLLER
(Optional)
Before Using
Memory play
• Up to 25 tracks can be stored in memory.
1 Press the MEMORY button to enter
Memory play mode.
MEMORY
MEMORY
2 Press the number button(s) to se-
lect your desired track.
To enter further track numbers into memory ,
repeat this step.
3 Press the button.
The track in memory are played in the order
you specified.
Note
• If more than 25 tracks are already in memory,
“FULL” will light on the time display to indicate
that the memory is full.
• If the MEMORY button is pressed during play,
the currently playing track is stored into memory .
To stop Memory play
Press the button.
How to enter track numbers
RC-398S RC-289C
To enter track #5 :
5
To enter track #10 :
To enter track #21 :
0
+10
2
1
Display information
Example: Tracks 2, 7, 10, 11 and 5 are stored in
memory
(Before starting Memory play)
a
The last track number stored in memory is
shown on the display.
b
Track numbers in memory are shown.
c
MEMORY indicator appears to indicate that
you are in Memory play mode.
abc
MEMORY
11
5
2
107
To clear the last track stored
Press the CLEAR button.
The last track you stored into memory is cleared.
Connections
Operations
Other Information
17
RC 398S
Playing CDs
ACOUSTIC
SLEEP
PRESENCE
DVD
MD
CLEAR
REC
CD
DISC
CD/MD
12
456
789
- - / - - - 10/0
(Supplied
with A-905X)
INPUT SELECTOR
G.EQUALIZER
EFFECT
MODE
TAPE
PAUSE/STEP
3
VOLUME
MUTING
RC-398SREMOTE CONTROLLER
REPEAT
MEMORY
RC-398S
POWER
CLOCK CALL
TUNER
PRESET
FM AM
REPEAT SCROLL
PLAY MODE
REPEAT RANDOM
MEMORY CLEAR
TIMER
UP/DOWN
ENTER
To quit Memory play
Press the MEMORY or (OPEN/CLOSE) button.
The MEMORY indicator disappears to indicate that
you are in Normal play mode.
The contents of the memory are completely
cleared.
MEMORY
To check tracks stored in memory
Stop the Memory play.
1. The last program number stored in memory is
shown on the display.
MEMORY
5
21
RC-289C
DISC 1 DISC 2 DISC 3
DISC 4 DISC 5 DISC 6
123
456
789
+10 0
REMOTE CONTROL RC-289C
RANDOMNEXT SELECTION
REPEAT
MEMORY
CLEAR
(Optional)
,
REPEAT
MEMORY
Playing all tracks on disc (Repeat
play)
1 Press the REPEAT button to enter
Repeat play mode.
The REPEAT indicator lights.
REPEAT
5
4321
REPEAT
109876
1211
2 Press the button to start Repeat
play.
2. Each time you press the or button on
the remote controller RC-289C, the track numbers stored in memory are shown on the display one by one.
MEMORY
21
18
• When the last track is completed, the CD
player returns to the beginning of the disc
5
and plays all the tracks on the disc again.
• Repeat play can be performed in conjunction with Normal, Memory, Random, and
TR-1 play modes. The REPEAT button can
be pressed even when a track is playing.
Play mode Repeated tracks
TR-1 1st track only
Normal All tracks on disc
Memory Tracks in memory (in stored order)
Random Repeats random play of all tracks
on disc.
To quit Repeat play
Press the REPEAT or button.
The REPEAT indicator disappears to indicate that
you are in Normal play mode.
Other Information
Handling CDs
Playable discs
This unit can play back the following discs.
Disc
Contents
mark
Audio
CDs
Y ou cannot play back discs other than those listed
above.
Avoid using heart-shaped or octagonal discs. Playing irregularly shaped discs may damage the internal mechanism of the unit.
Do not use discs on which adhesive from adhesive
tape or a disc label (if it is a rental disc) remains.
Otherwise, you may not be able to eject the discs
or the unit may become inoperative.
Audio
Disc
size
12 cm
8 cm
(CD single)
Maximum
playback time
74 minutes
20 minutes
Taking the CD out of the disc
case
1 Hold the disc case in the palm of
one hand and pull the cover upward with the other hand to open
the disc case.
2 While pushing on the center grip
of the disc case with your finger,
take out the disc by holding its
edges.
Important notes on handling CDs
• Carefully lift the disc from the disc case, making sure to only hold the disc by its edges or the
hole in the middle.
Before Using
Connections
Operations
• A dry, soft cloth may be used to wipe dust and
fingerprints off the surface of CDs.
• Do not use volatile agents on discs, such as thinner or benzine. Also, do not use conventional
record cleaner or antistatic agents.
• Do not place a CD in direct sunlight or locations
subject to high humidity or low temperature.
• Do not store a CD in the CD player tray for long
periods of time.
Other Information
19
Troubleshooting
If you have any problems with the unit, please check the troubleshooting table below first.
For any problems not covered in the table, please consult your nearest Onkyo authorized service center.
Symptom
STANDBY/ON button is pr essed,
but power does not come on.
Disc is loaded in the disc tray ,
but playback will not begin.
No sound
Disc skipping
Search time (when moving to
a specific track) is extremely
long.
Track numbers cannot be
stored in the memory.
Noise during play
Remote controller does not
function.
Cause
• Power cord plug is not properly
connected to AC outlet.
• Disc is in the disc tray upside down.
• Disc is dirty.
• Moisture has accumulated inside
the CD player.
• Incomplete or incorrect connections.
• Improper input selector switch setting on amplifier .
• Disc is dirty.
• Disc is scratched.
• CD player has been bumped.
• Disc is dirty.
• Disc is scratched.
• No disc in the tray.
• A track number not on the disc is
being input.
• Interference from TV
• Battery level is low.
• Your position is too far from the
unit’s remote control sensor or out
of the sensor’s detection angle.
• An obstacle exists between you and
the unit’s remote control sensor.
• The system components are not
connected properly.
Remedy
• Insert the plug firmly.
• Load the disc with the label facing
upward.
• Clean the disc.
• Remove the disc from the disc tray,
place the CD player in a warm place
and leave the power on for about
one hour.
• Check all cable connections. (See
pages 10-12)
• Insert all plugs firmly into jacks.
• Set switch to proper position. See
your amplifiers operating instructions for more information.
• Clean the disc. (See page 19)
• Replace the disc.
• Place the CD player in a more stable
location.
• Clean the disc. (See page 19)
• Replace the disc.
• Load a disc into the tray.
• Use only the track numbers on the
disc.
• Turn off the TV, or move the unit
farther from the TV.
• Replace the batteries.
• Remote controller is possible within
a distance of approximately 5
meters from the unit’s sensor and a
detection range of 30°.
• Operate from a different position or
remove the obstacle.
• Connect the system components
properly according to the A-905X
instruction manual.
20
Indexed to parts and controls
For operational instructions, refer to the page indicated in parentheses.
Front panel
STANDBY/ON
button [13]
STANDBY
indicator [12]
DISPLAY button [15]
Display
STANDBY/ON
STANDBY
Disc tray [13]
COMPACT DISC PLAYER
DISPLAY
DUAL OPTICAL OUTPUT
Remote control
sensor [9]
button (Pause) [13]
Button
(Open/Close)
[13, 18]
TR-1 button [16]
TR-1
button (Stop)
[13]
button (Play)
[13, 14, 16]
C-705X
, button
(Track down/Fast reverse,
T rack up/Fast forward) [14, 15]
Before Using
Connections
Operations
Elapsed/Remaining
time indicator Memory indicator
SINGLE ELAPSED
TOTAL REMAIN
Pause indicator
REPEAT
RANDOM
Multi-purpose
MEMORY
Music calendar
display
TR-1 indicator
-
1
TR
5
4321
109876
1514131211
15
Over indicator
Other Information
21
Indexed to parts and controls
Remote controller
Remote controller supplied with the A-905X (RC-398S)
To operate the supplied remote controller, make the appropriate connection to the remote connectors.
RC-398S
POWER button [13]
CD player operation buttons
REPEAT : Repeat mode button [18]
RANDOM : Random play button [16]
: Stop button [13, 17]
: Pause button [13]
: Play button [13, 14, 17, 18]
MEMORY : Memory button [17, 18]
CLEAR : Clear button [17]
DISC : Disc button (can not be used.)
: Track down button [14]
: Track up button [14]
POWER
CLOCK CALL
ACOUSTIC
SLEEP
PRESENCE
TUNER
PRESET
FM AM
DVD
PAUSE/STEP
REPEAT SCROLL
PLAY MODE
REPEAT RANDOM
MEMORY CLEAR
TIMER
UP/DOWN
ENTER - - / - - - 10/0 MUTING
MD
CLEAR
REC
CD
DISC
CD/MD
2
1
456
789
INPUT SELECTOR
G.EQUALIZER
EFFECT
TAPE
3
MODE
VOLUME
RC-398SREMOTE CONTROLLER
Number buttons [14, 17]
1~9, 10/0 : Number buttons
--/--- : Ten‘s hold button
22
Optional remote controller for CD (RC-289C)
CD player operation
buttons
: Stop button [13, 17]
: Play button
[13, 14, 17, 18]
: Pause button [13]
: Fast reverse button
[14, 18]
: Fast forward button
[14, 18]
: Track down button
[14]
: Track up button [14]
RC-289C
DISC 1 DISC 2 DISC 3
DISC 4 DISC 5 DISC 6
123
456
789
+10 0
REMOTE CONTROL RC-289C
RANDOMNEXT SELECTION
REPEAT
MEMORY
CLEAR
: Open/Close button [13]
NEXT SELECTION button (Not used.)
DISC 1-6 buttons (Not used.)
RANDOM : Random button [16]
REPEAT : Repeat button [18]
MEMORY : Memory button [17, 18]
CLEAR : Clear button [17]
Number buttons [14, 17]
Before Using
Connections
Operations
Other Information
23
Specifications
Signal readout system : Optical non-contact
Reading rotation : About 500 – 200 r.p.m.
(constant linear velocity)
Linear velocity : 1.2 –1.4 m/s
Error correction system :
Cross Interleave Reed Solomon code
D/A converter : 1 bit D/A converter
Sampling frequency : 352.8 kHz
(Eight-times oversampling)
Number of channels : 2 (stereo)
Frequency response : 5 Hz – 20 kHz
Total harmonic distortion : 0.005% (at 1 kHz)
Dynamic range : 96 dB
Signal to noise ratio : 90 dB
Channel separation : 85 dB (at 1 kHz)
Wow and Flutter:
Below threshold of measurability
Output level : 2 volts r.m.s.
Power consumption :
230 V, 50 Hz model : 8 watts
120 V, 60 Hz model : 9 watts
Power supply rating :
AC 230 V, 50 Hz
AC 120 V, 60 Hz
Dimensions (W x H x D) :
205 x 91 x 275 mm
8-1/16" x 3-9/16" x 10-3/16"
Weight : 2.2 kg, 4.9 lbs.
Specifications and external appearance are subject to
change without notice because of product improvements.
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 0720-31-8111 Fax: 0720-33-5222 http://www.onkyo-intl.com
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.onkyo.net
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: 852 2429 3118 Fax: 852 2428 9039
Printed in Japan
SN 29342739
24
HOMEPAGE
http://www.onkyo.co.jp/
I9905-1
E
Loading...
