Onkyo BR925 User Manual
CD/HDD Receiver
BR-925
Instruction Manual
Contents
Getting Started ..............................2
Connections ................................15
Turning On & First Time Setup ..22
Basic Operation...........................24
Playing & Listening
Playing CDs..............................28
Listening to the Radio...............32
USB Device Playback...............41
Playing External Components ..45
Thank you for purchasing an Onkyo CD/HDD
receiver.
Please read this manual thoroughly before making
any connections and plugging it in.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new CD/HDD receiver.
Please retain this manual for future reference.
Recording (Transferring Data) ...46
Playing the HDD ..........................54
Clock and Timer ..........................62
Advanced Setup ..........................68
Others...........................................70
E
n
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Important Safety Instructions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
AVIS
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand,
PORTABLE CART WARNING
tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to
S3125A
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
2
15. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is dam-
aged,
B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or
water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper adjustment of
other controls may result in damage and will
often require extensive work by a qualified technician to restore the apparatus to its normal
operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry
Never push objects of any kind into the apparatus
through openings as they may touch dangerous voltage points or short-out parts that could result in a
fire or electric shock.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases shall be placed on the apparatus.
Don’t put candles or other burning objects on top of
this unit.
17. Batteries
Always consider the environmental issues and follow local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation,
such as a bookcase or rack, ensure that there is adequate ventilation.
Leave 20 cm (8") of free space at the top and sides
and 10 cm (4") at the rear. The rear edge of the shelf
or board above the apparatus shall be set 10 cm (4")
away from the rear panel or wall, creating a fluelike gap for warm air to escape.
Precautions
1. Recording Copyright—Unless it’s for personal use
only, recording copyrighted material is illegal without the permission of the copyright holder.
2. AC Fuse—The AC fuse inside the unit is not user-
serviceable. If you cannot turn on the unit, contact
your Onkyo dealer.
3. Care—Occasionally you should dust the unit all
over with a soft cloth. For stubborn stains, use a soft
cloth dampened with a weak solution of mild detergent and water. Dry the unit immediately afterwards
with a clean cloth. Don’t use abrasive cloths, thinners, alcohol, or other chemical solvents, because
they may damage the finish or remove the panel lettering.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the unit’s rear panel
(e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).
The power cord plug is used to disconnect this unit
from the AC power source. Make sure that the plug
is readily operable (easily accessible) at all times.
5. Preventing Hearing Loss
Caution
Excessive sound pressure from earphones and headphones can cause hearing loss.
6. Batteries and Heat Exposure
War nin g
Batteries (battery pack or batteries installed) shall
not be exposed to excessive heat as sunshine, fire or
the like.
7. Never Touch this Unit with Wet Hands—Never
handle this unit or its power cord while your hands
are wet or damp. If water or any other liquid gets
inside this unit, have it checked by your Onkyo
dealer.
8. Handling Notes
• If you need to transport this unit, use the original
packaging to pack it how it was when you originally bought it.
• Do not leave rubber or plastic items on this unit
for a long time, because they may leave marks on
the case.
• This unit’s top and rear panels may get warm
after prolonged use. This is normal.
• If you do not use this unit for a long time, it may
not work properly the next time you turn it on, so
be sure to use it occasionally.
• When you’ve finished using this unit, remove all
discs and turn off the power.
9. Installing this Unit
• Install this unit in a well-ventilated location.
• Ensure that there’s adequate ventilation all
around this unit, especially if it’s installed in an
audio rack. If the ventilation is inadequate, the
unit may overheat, leading to malfunction.
• Do not expose this unit to direct sunlight or heat
sources, because its internal temperature may
rise, shortening the life of the optical pickup.
• Avoid damp and dusty places, and places subject
to vibrations from loudspeakers. Never put the
unit on top of, or directly above a loudspeaker.
• Install this unit horizontally. Never use it on its
side or on a sloping surface, because it may cause
a malfunction.
• If you install this unit near a TV, radio, or VCR,
the picture and sound quality may be affected. If
this occurs, move this unit away from the TV,
radio, or VCR.
10. Moisture Condensation
Moisture condensation may damage this unit.
Read the following carefully:
Moisture may condense on the lens of the optical
pickup, one of the most important parts inside this
unit.
• Moisture condensation can occur in the following
situations:
– The unit is moved from a cold place to a warm
place.
– A heater is turned on, or cold air from an air
conditioner is hitting the unit.
– In the summer, when this unit is moved from
an air conditioned room to a hot and humid
place.
– The unit is used in a humid place.
• Do not use this unit when there’s the possibility
of moisture condensation occurring. Doing so
may damage your discs and certain parts inside
this unit.
If condensation does occur, remove all discs and
leave this unit turned on for two to three hours. By
this time, the unit will have warmed up and any condensation will have evaporated.
3
Precautions—Continued
This unit contains a semiconductor laser system and is
classified as a “CLASS 1 LASER PRODUCT”. So, to
use this model properly, read this Instruction Manual
carefully. In case of any trouble, please contact the store
where you purchased the unit.
To prevent being exposed to the laser beam, do not try to
open the enclosure.
CAUTION:
CLASS 1M VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. DO NOT VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
The label on the right is
applied on the rear panel.
1. This unit is a CLASS 1 LASER PRODUCT and
employs a laser inside the cabinet.
2. To prevent the laser from being exposed, do not
remove the cover. Refer servicing to qualified personnel.
For British models
Replacement and mounting of an AC plug on the power
supply cord of this unit should be performed only by
qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance
with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to
the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or
coloured red.
IMPORTANT
The plug is fitted with an appropriate fuse. If the fuse
needs to be replaced, the replacement fuse must
approved by ASTA or BSI to BS1362 and have the same
ampere rating as that indicated on the plug. Check for the
ASTA mark or the BSI mark on the body of the fuse.
If the power cord’s plug is not suitable for your socket
outlets, cut it off and fit a suitable plug. Fit a suitable fuse
in the plug.
For European Models
Declaration of Conformity
We,
ONKYO EUROPE
ELECTRONICS GmbH
LIEGNITZERSTRASSE 6,
82194 GROEBENZELL,
GERMANY
declare in own responsibility, that the ONKYO product
described in this instruction manual is in compliance with the
corresponding technical standards such as EN60065,
EN55013, EN55020 and EN61000-3-2, -3-3.
GROEBENZELL, GERMANY
K. MIYAGI
ONKYO EUROPE ELECTRONICS GmbH
4
Features
Supplied Accessories
HDD/Amplifier
• 80 GB Hard Disk Capacity for Storing Audio Files
(Copies from CDs or a USB Mass Storage Device)
• Discrete Output Stage Circuitry
• Optimum Gain Volume Circuitry
• Dynamic Range Control
• Super Bass (On/Off) and Tone Control
Processing and Connection
•VLSC (Vector Linear Shaping Circuitry)
• Gracenote Database Capability
• Wolfson 2ch Audio D/A Converter
• Audyssey EQ
• Audyssey Dynamic EQ
• USB Port for iPod
™
to Correct Room Acoustic Problems
™*2
®*3
Loudness Correction
or USB Mass Storage Device
• Optical Digital Input
• 3 Audio Inputs and 2 Outputs
• Subwoofer Pre Out
*1
Others
• Plays Audio CDs, MP3s and WMA*4(via USB, CDR, CD-RW
• 4-Mode Timer (Play or Rec/Once or Every)
• Headphone Jack
• Aluminium Top Panel and Volume Knob
• RI-Dock Compatible Remote Control (iPod Control
Capable)
*5
); AAC*6 and WAV Files (via USB)
Make sure you have the following accessories:
Remote controller and two batteries (R6/AA)
Indoor FM antenna
(Connector type varies from country to country.)
AM loop antenna
* In catalogs and on packaging, the letter at the end of the product
name indicates the color. Specifications and operations are the
same regardless of color.
*1 VLSC and the VLSC logo are registered trademarks of Onkyo
Corporation.
*2
Manufactured under license from Audyssey Laboratories. U.S.
and foreign patents pending. Audyssey Dynamic EQ
Audyssey EQ™ are trademarks of Audyssey Laboratories.
*3 iPod is a trademark of Apple Inc., registered in the U.S. and
other countries.
*4 Windows Media, and the Windows logo are trademarks, or reg-
istered trademarks of Micro soft Corporation in the United States
and/or other countries.
*5 Make sure to use discs that have been finalized.
*6 The “AAC” logo is trademark of Dolby Laboratories.
™
and
5
Before Using the CD/HDD Receiver
Installing the Batteries
Detach the battery cover by pressing the
1
tab and pulling up the cover.
Insert two batteries (R6/AA) into the bat-
2
tery compartment.
Carefully follow the polarity diagram (positive
(+) and negative (–) symbols) inside the battery
compartment.
After the batteries are installed and
3
seated correctly, attach the compartment
cover.
Using the Remote Controller
When you operate the remote controller, point it at the
CD/HDD receiver’s remote control sensor, as shown
below.
Remote control sensor
m
5
.
x
o
r
p
p
A
CD/HDD receiver
Notes:
• The remote controller may not work reliably if the CD/
HDD receiver is subjected to bright light, such as direct
sunlight or inverter-type fluorescent lights. Keep this in
mind when installing.
• If another remote controller of the same type is used in
the same room, or the CD/HDD receiver is installed close
to equipment that uses infrared rays, the remote controller may not work reliably.
• Don’t put anything, such as a book, on the remote controller because the buttons may be pressed inadvertently,
thereby draining the batteries.
• The remote controller may not work reliably if the CD/
HDD receiver is installed in a rack behind colored glass
doors. Keep this in mind when installing.
• The remote controller will not work if there’s an obstacle
between it and the CD/HDD receiver’s remote control
sensor.
Notes:
• If the remote controller doesn’t work reliably, try replacing the batteries.
• Don’t mix new and old batteries or different types of batteries.
• If you intend not to use the remote controller for a long
time, remove the batteries to prevent damage from leakage or corrosion.
• Expired batteries should be removed as soon as possible
to prevent damage from leakage or corrosion.
• When replacing the batteries, use R6/AA batteries.
Onkyo recommend that you use manganese dry batteries.
• If rechargeable batteries are used, the remote controller
may be inoperable.
6
What You Can Do with the CD/HDD Receiver
CDs
Playing CDs (page 28)
Recording CDs (page 48)
Playing iPod®
thru USB port
(page 42)
Connected
Components
Playing an external component (page 45)
Recording from an external component (page 50)
Transferring the data (page 51)
USB mass
HDD
(Hard Disk Drive)
Digital audio
player
storage device
*1
Radio
Listening to the radio (page 32)
Recording the radio (page 50)
*1
Accessing
from PC
*2
(page 52)
Playing music from USB device (page 42)
Transferring the data (page 51)
*1 Only for USB devices supporting the USB mass storage class.
*2 Only for personal computers with Microsoft Windows XP Service Pack 2, Service Pack 3, or Microsoft Windows Vista installed.
7
What You Can Do with the CD/HDD Receiver—Continued
Handling the Hard Disk Drive (HDD)
The HDD is very sensitive to physical shock, vibration, and dust.
The CD/HDD receiver is designed to protect the data safely from physical shock, vibration, and dust. However, pay
particular attention to the following points to prevent the recorded data from being lost.
• Do not apply physical shock.
• Do not move the CD/HDD receiver with power cord plugged.
• Do not use the CD/HDD receiver in vibratory or unstable place.
• Do not unplug or move the CD/HDD receiver during recording or playback.
• Do not attempt to replace the HDD or to add another one by yourself. A failure may occur.
• Do not install the CD/HDD receiver in a dusty place.
• Do not block any ventilation openings on the CD/HDD receiver. Heat may be built up, causing a failure.
• Do not use in a place with rapid temperature change (a change over 10°C per hour).
When there is the possibility of moisture condensation occurring, Onkyo recommend that you wait for approx.
one hour after turning the power on before using the CD/HDD receiver.
Advice on data backup
The HDD may fail even in normal use, for example, a sudden data loss or failure caused by electrical service interruption. If the HDD fails for some reason, the data cannot be restored. Onkyo recommend that you backup the data stored
in the CD/HDD receiver to your personal computer or commercially available USB hard disk drive periodically.
When getting repaired
When the HDD gets repaired, the data in the HDD of the CD/HDD receiver, including music data, setting data, cannot
sometimes be reproduced. Before it gets repaired, note down the setting details preset in the CD/HDD receiver on paper.
Also be sure to backup the data stored in the CD/HDD receiver. Please note that Onkyo will not be responsible for
anything if the data should be erased or changed during the repair and normal use.
8
Contents
Getting Started
Important Safety Instructions .................................... 2
Precautions ............................................................... 3
Features.................................................................... 5
Supplied Accessories................................................ 5
Before Using the CD/HDD Receiver ......................... 6
Installing the Batteries........................................... 6
Using the Remote Controller................................. 6
What You Can Do with the CD/HDD Receiver.......... 7
Handling the Hard Disk Drive (HDD)..................... 8
Getting to Know the CD/HDD Receiver .................. 10
Front Panel.......................................................... 10
Display................................................................. 11
Rear Panel .......................................................... 12
Remote Controller ............................................... 13
Connections
Connections ............................................................ 15
About Connections.............................................. 15
Connecting Speakers.......................................... 16
Connecting Antennas.......................................... 17
Connecting Other Components........................... 19
Connecting a Subwoofer..................................... 20
Connecting a Component with a Digital Audio
Output............................................................... 20
Connecting a TV.................................................. 20
Hooking Up to the Internet .................................. 21
Turning On & First Time Setup
Turning On the CD/HDD Receiver .......................... 22
First Time Setup...................................................... 23
Setting the Clock with the AccuClock Function... 23
Basic Operation
Basic Operations..................................................... 24
Selecting the Input Source .................................. 24
Adjusting the Volume .......................................... 24
Using Headphones.............................................. 24
Adjusting the Tone .................................................. 25
Adjusting the Bass and Treble ............................ 25
Using the Super Bass Function........................... 25
Using the Direct Function.................................... 25
Muting the Sound ................................................ 25
Using Audyssey EQ™
and Audyssey Dynamic EQ™ .............................. 26
Operation of Music Data ......................................... 27
USB Device......................................................... 27
HDD..................................................................... 27
USB Device Playback ............................................. 41
Compatible USB Devices ....................................41
USB Device Folders and Files............................. 41
Basic Operations of Playback.............................. 42
Playing Selected Tracks...................................... 43
Switching the Display .......................................... 43
Repeat/Random Playback................................... 44
Playing External Components................................. 45
Playing External Components .............................45
Making an u Connection with Onkyo
Components...................................................... 45
Recording (Transferring Data)
Recording (Transferring Data)................................. 46
Compatible USB Devices ....................................46
Preparation for Recording and Transferring ........ 46
Setting for Recording........................................... 47
Recording CDs .................................................... 48
Recording from Tuner.......................................... 50
Recording from Line Input ................................... 50
Transferring Data................................................. 51
Erasing Data from USB Device ...........................53
Playing the HDD
Playing the HDD...................................................... 54
Basic Operations of Playback.............................. 54
Playing Selected Tracks...................................... 55
Switching the Display .......................................... 56
Various Playback Modes..................................... 57
Editing Tracks and Playlists in the HDD.................. 58
Erasing Music Track or Album............................. 58
Editing Track Information..................................... 58
Removing Tracks from the Playlist...................... 60
Editing a Playlist Name........................................ 61
Clock and Timer
Setting the Clock ..................................................... 62
Setting AccuClock to Use a Specific Station .......62
Setting the Clock Manually.................................. 63
Using the Timers ..................................................... 64
Using the Sleep Timer ......................................... 64
Using the Play Timer ...........................................65
Using the Record Timer....................................... 66
Advanced Setup
Advanced Setup...................................................... 68
Network Configuration......................................... 68
Playing & Listening
Playing CDs ............................................................ 28
Basic Operations of Playback ............................. 28
Playing Selected Tracks...................................... 29
Switching the Display .......................................... 29
Retrieving Audio CD Information......................... 30
Random Playback ............................................... 31
Repeat Playback ................................................. 31
Listening to the Radio ............................................. 32
Tuning into AM/FM Radio Stations...................... 32
Displaying Radio Information .............................. 33
Receiving RDS.................................................... 33
Presetting FM Stations Automatically (Auto Preset)
Presetting AM/FM Stations Manually .................. 35
Selecting Preset Stations .................................... 36
Editing Presets .................................................... 37
.... 34
Others
Disc Notes............................................................... 70
Playable Formats .................................................... 72
Controlling External Components............................ 73
Troubleshooting....................................................... 74
Specifications .......................................................... 79
Trademark and Other Proprietary Notices .............. 80
To reset the CD/HDD receiver, see page 74.
9
Getting to Know the CD/HDD Receiver
Front Panel
brbs
1
2
3
4
5
67bn
The page numbers in parentheses show where you can find the main explanation for each item.
a Remote control sensor (6)
Receives control signals from the remote controller.
b CD r HDD DUBBING button (48)
Used to record a CD into HDD. When pressed,
immediately starts recording all tracks.
c CD r USB DUBBING button (48)
Used to record a CD into a digital audio player or
USB storage device. When pressed, immediately
starts recording all tracks.
d ON/STANDBY button (22)
Sets the CD/HDD receiver to On or Standby.
e STANDBY indicator (22)
Lights off when the power is on, and lights up in red
in Standby mode.
f PHONES jack (24)
This stereo minijack is for connecting a pair of stereo headphones for private listening.
g CD tray (28)
The CD is loaded here.
h Stop [2] button (28)
Stops CD playback.
i USB port (42)
A USB mass storage device, such as a USB flash
drive or MP3 music player, containing music files
can be plugged in here and the music files can be
selected and played through the CD/HDD receiver.
j Play/Pause [1/3] button (28)
Starts CD playback. Pressing it during playback
pauses playback.
k LIBRARY button (28)
Displays the list of tracks.
l RETURN button
Returns to the previous menu level.
m y REC button (49)
Pressed to record into HDD, digital audio player, or
USB storage device.
n MULTI JOG dial (24, 28, 36)
Selects a preset radio station or tracks of CD to be
played.
Selects an item for editing or setting. Pressed to
confirm each setting.
o INPUT SELECTOR button (24)
Used to select the input source.
p VOLUME control (24)
This control is used to adjust the volume of the
CD/HDD receiver to “Min”, “1” through “41”,
“Max”.
q Open/Close [0] button (28)
Used to open and close the disc tray.
r Display
See “Display” on page 11.
98bkblbm
bq
bp
bo
10
Getting to Know the CD/HDD Receiver—Continued
Display
12 43567
9bk blbm bn bo
8
a Play, pause and Rec 1/3/y REC
indicators
Displays the playback and recording status.
b Input source indicators
Displays the input source for playback. During
recording, the indicator of the destination flashes.
HDD: Hard disk drive.
CD: Audio CD or data CD.
USB: USB device.
TUNER: FM or AM.
LINE 1 to LINE3:
Connected components.
DIGITAL: Components connected via optical digi-
tal audio.
Lights up when the input signal is PCM.
The indicator flashes if the input signal
is digital but not PCM, or the CD/HDD
receiver is in “unlocked” state (the cable
is disconnected or the component is not
turned on).
c S.BASS indicator
Lights up when the Super Bass function is on.
d Message area
Various information is displayed here, including
radio preset numbers, tuning frequency, current time,
volume level, sleep time, mode settings, and so on.
e Playback mode indicators
RANDOM:
REPEAT:
REPEAT 1:
BGM: Lights up when BGM mode play-
f Jump mode indicators
:
Lights up when random playback
is selected.
Lights up when repeat playback
is selected for all tracks.
Lights up when repeat playback
is selected for one track.
back is selected (see page 57).
Lights up when jump mode is
selected (see page 55).
g Tuning indicators
AUTO:
Lights up when Auto Tuning is selected, and disappears when Manual Tuning is selected.
:
Lights up when the CD/HDD receiver is tuned to a
radio station.
FM STEREO:
Lights up when the CD/HDD receiver is tuned to a
stereo FM station.
RDS:
Lights up when the CD/HDD receiver is tuned to a
radio station that supports RDS (Radio Data System).
h DIRECT indicator
Lights up when the Direct function is on.
i REMAIN indicator
Lights up when the remaining track time is being
displayed.
j TIMER indicators
Show the status of the timers.
TIMER:
Lights up when a timer has been programmed.
1, 2, 3, 4:
Light up when a timer has been programmed.
:
Lights up when a timer has been programmed for
recording.
k SLEEP indicator
Lights up when the Sleep function has been set.
l MUTING indicator
Flashes while the CD/HDD receiver is muted.
m Dynamic EQ indicator
Lights up when the Audyssey Dynamic EQ™ has
been set.
n File format indicators
Displays the format of playback and recording data.
11
Getting to Know the CD/HDD Receiver—Continued
Rear Panel
123 5
7
The page numbers in parentheses show where you can find the main explanation for each item.
a ETHERNET (21)
This socket is for connecting a broadband router
using a commercially available LAN cable.
b LINE 1 IN (20)
These terminals are for connecting audio output of
external devices such as TV or turntable with a
built-in phono equalizer.
c MD/TAPE (LINE 2) IN/OUT (19)
These analog audio inputs and outputs are for connecting a recorder with an analog input and output,
such as a MiniDisc recorder or cassette deck.
d DOCK/CDR (LINE 3) IN/OUT (19)
This analog audio input and output are for connecting an Onkyo RI Dock. The input and output can
also be connected to a CD recorder or recording
device.
e SPEAKERS (16)
These terminal posts are for connecting speakers.
f SUBWOOFER PRE OUT (20)
This jack is for connecting a powered active subwoofer.
g OPTICAL DIGITAL IN (20)
This optical digital audio input can be used to connect a component with an optical digital output,
such as a CD recorder, MD recorder, games console, satellite tuner, or personal computer. Use a
commercially available optical digital audio cable
(square) to make the connection.
4
8 9 bk bl
Heat sink
h u REMOTE CONTROL (19)
This u (Remote Interactive) jack can be connected to an u jack on another Onkyo component.
The CD/HDD receiver’s remote controller can then
be used to control that component. To use u, you
must make an analog audio connection (RCA)
between the CD/HDD receiver and the other component.
i FM ANTENNA (17)
This jack is for connecting an FM antenna.
j AM ANTENNA (17)
These push terminals are for connecting an AM
antenna.
k Power cord (22)
The power cord should be connected to a suitable
power source (plug type varies from country to
country).
See pages 15–21 for connection information.
Caution:
The heat sink is a device designed to disperse heat from
within the CD/HDD receiver. Do not to place objects
around the CD/HDD receiver and ensure that there is adequate ventilation all around the CD/HDD receiver. If the
ventilation is inadequate, the CD/HDD receiver may overheat, leading to malfunction.
6
12
Getting to Know the CD/HDD Receiver—Continued
Remote Controller
The page numbers in parentheses show where you can
find the main explanation for each item.
1
2
3
4
5
6
7
8
9
bk
bl
bm
bn
bo
bp
bq
br
bs
bt
ck
cl
cm
cn
co
cp
cq
cr
cs
a ON/STANDBY button (22)
This button is used to set the CD/HDD receiver to
On or Standby.
b SLEEP button (64)
Used to set the Sleep timer, which turns off the
CD/HDD receiver after a specified time.
c Alphabetic letters/Symbol ( )/Number (0
to >10) buttons (39, 58, 61)
Used to enter the name of the playlist, album, artist,
track or radio presets.
Numeric: Used to select the track you want to play.
Also used to set the clock manually and set the timers.
d PLAYLIST REG button (57)
Used to register music files in HDD to the playlist.
e Source selection buttons (24)
INPUT [q]/[w] buttons:
Used to switch the input source.
HDD 1 button*:
Switches to HDD for playback.
CD 1 button*:
Switches to CD for playback.
USB 1 button*:
Switches to USB for playback.
* These buttons also work in the Standby mode.
f BGM MODE 1 button (57)
Used to play tracks in HDD* in BGM mode. This
button also works in the Standby mode.
* Except for music files recorded from the FM/AM or
external components.
g LIBRARY button (28)
Displays the list of tracks.
h RETURN button
Returns to the previous display.
i Operation buttons (28, 32, 36, 73)
3: Pauses playback.
1: Starts playback.
2: Stops playback.
Fast Reverse/Fast Forward [5]/[4] and
TUNING [e]/[r] buttons:
Used to fast reverse or fast forward CD playback.
Can also be used with an Onkyo RI Dock, CD
recorder or MD recorder. Also used to tune the
radio frequency.
13
Getting to Know the CD/HDD Receiver—Continued
Previous/Next [7]/[6] and PRESET
[e]/[r] buttons
Used to select the previous or next track or radio
preset. Can also be used with an Onkyo RI Dock,
CD recorder or MD recorder. With an Onkyo cassette deck, they work as fast reverse and fast forward buttons.
j PLAYLIST [q]/[w] buttons (57)
Plays the tracks on the playlist. Each time the button
is pressed, the selected playlist is switched and
playback starts.
k USB REC [y3] button (49)
Used to record to your USB storage device.
l HDD REC [y3] button (49)
Used to record to HDD.
m CLOCK CALL button (63)
Calls up the clock to display the day and time.
This button also works in the Standby mode.
n TIMER button (63, 64)
Used to set the timers and clock.
o CAPS button (39)
Used to select the character group.
p DIRECT button (25)
Used to switch to the Direct mode.
q TONE button (25)
Used to adjust the bass and treble.
r S.BASS button (25)
Sets the Super Bass function.
s CLEAR button (40)
Used to delete the input letters.
t MUTING button (25)
Mutes the output of the CD/HDD receiver.
u VOL [q]/[w] button (24)
Adjust the volume level.
v TUNER (BAND) button (36)
Selects AM or FM radio as the input source.
w TOOLS button
Used to display setting items.
x Cursor q/w/e/r and ENTER buttons
Cursor:
Selects items by moving the cursor.
ENTER:
Used to confirm settings. Also used to start playback of the selected track.
y DISPLAY button (29, 73)
Used to change the information shown on the display. With an Onkyo RI Dock, it works as a backlight button.
z REPEAT button (31, 73)
Sets repeat playback. Can also be used with an
Onkyo RI Dock. With an Onkyo cassette deck, it
works as a reverse mode button.
cr OPEN/CLOSE [0] button (28)
Used to open and close the disc tray.
cs RANDOM button (31)
Used to select random playback.
14
Connections
About Connections
• Before making any connections, read the manuals
supplied with your other components.
• Don’t connect the power cord until you’ve completed
and double-checked all connections.
Connection Color Coding
RCA-type audio connections are usually color-coded:
red and white. Use red plugs to connect right-channel
audio inputs and outputs (typically labeled “R”). Use
white plugs to connect left-channel audio inputs and outputs (typically labeled “L”).
Left (white)
Right (red) Right (red)
• Push plugs in all the way to make
good connections (loose connections can cause noise or malfunctions).
Analog audio
cable
Left (white)
Right!
Wrong!
• To prevent interference, keep audio cables away from
power cords and speaker cables.
• If the TV picture is distorted, or noise is heard in the
output sound of the CD/HDD receiver, install the
CD/HDD receiver as far as possible from the TV.
Optical Digital Input Terminal
The optical digital input terminal of the CD/HDD
receiver is a type of terminal with cover. Insert the optical digital cable while pushing the cover inwards.
Notes:
• Plug or unplug the optical digital cable in straight direction.
• If you plug or unplug the cable slantingly, the cover may
be damaged.
• Do not put anything on top of the CD/HDD receiver, as it
may interfere with proper ventilation, leading to malfunction.
See the related pages for connection.
Antennas
page 17
Internet
page 21
Digital device
with an optical
digital output
such as a game
console, a personal computer,
or a satellite tuner
page 20
Recording device such as an MD recorder, a
cassette deck or a CD recorder, or an Onkyo
RI dock
page 19
Speakers
page 16
Powered active
subwoofer
page 20
Power cord
(Plug type varies from country to
country.)
page 22
Don't connect the power cord
until you've completed and double-checked all connections.
15
Connections—Continued
Connecting Speakers
• Connect the right speaker to the CD/HDD receiver’s right (R) SPEAKERS terminals. Connect the left speaker to the
left (L) SPEAKERS terminals.
• Connect the positive (+) terminal on each speaker to the corresponding positive (+) terminal on the CD/HDD receiver.
Connect the negative (–) terminal on each speaker to the corresponding negative (–) terminal on the CD/HDD
receiver. Use the red wires to connect the positive (+) terminals.
• Up to two speakers can be connected to the CD/HDD receiver.
Right speaker
Red wires
• Connect only speakers with an impedance of between
4 and 16 ohms. Connecting a speaker with a lower
impedance may damage the speaker.
• Be careful not to short the positive and negative wires.
Doing so may damage the CD/HDD receiver. Also, be
careful not to touch the rear panel.
Left speaker
Speaker cable
—Terminal posts—
Strip about 15 mm of insulation from the ends of the speaker
cables, and twist the bare wires tightly. Unscrew the terminal.
Fully insert the bare wire, making sure that it’s touching the
threaded shaft in the center. Screw the terminal tight.
• Be careful not to confuse the positive and negative terminals, or L and R speakers during the connection.
Doing so may result in unnatural sound.
• Do not connect both speaker cables to the same L or R
terminals (Fig. 1). Do not connect more than two
speaker terminals to each speaker (Fig. 2).
• Twist the speaker cord sufficiently.
The contact between bare wire and rear panel may
cause a short circuit.
16
Fig. 1 Fig. 2
Connections—Continued
Connecting Antennas
This section explains how to connect the supplied indoor
FM antenna and AM loop antenna, and how to connect
commercially available outdoor FM and AM antennas.
The CD/HDD receiver won’t pick up any radio signals
without an antenna connected, so you must connect the
antenna to use the tuner.
AM ANTENNA push terminals
FM ANTENNA jack
Connecting the Indoor FM Antenna
The supplied indoor FM antenna is for indoor use only.
Attach the FM antenna, as shown.
1
Connecting the AM Loop Antenna
The supplied indoor AM loop antenna is for indoor use
only.
Assemble the AM loop antenna, inserting
1
the tabs into the base, as shown.
Connect both wires of the AM loop
2
antenna to the AM ANTENNA push terminals, as shown.
(The antenna’s wires are not polarity sensitive, so
they can be connected either way around.)
Make sure that the wires are attached securely and
that the push terminals are gripping the bare
wires, not the insulation.
Insert the plug fully
into the jack.
Once the CD/HDD receiver is ready for use,
you’ll need to tune into an FM radio station and
adjust the position of the FM antenna to achieve
the best possible reception.
Use thumbtacks or something similar to
2
fix the FM antenna into position.
Thumbtacks, etc.
Caution:
Be careful that you don’t injure yourself when using
thumbtacks.
If you cannot achieve good reception with the supplied
indoor FM antenna, try a commercially available outdoor FM antenna instead (see page 18).
Push Insert wire Release
Once the CD/HDD receiver is ready for use,
you’ll need to tune into an AM radio station and
adjust the position of the AM antenna to achieve
the best possible reception.
Keep the antenna as far away as possible from the
CD/HDD receiver, TV, speaker cables, and power
cords.
If you cannot achieve good reception with the supplied
indoor AM loop antenna, try using it with a commercially available outdoor AM antenna (see page 18).
17
Connections—Continued
Connecting an Outdoor FM Antenna
If you cannot achieve good reception with the supplied
indoor FM antenna, try a commercially available outdoor FM antenna instead.
Notes:
• Outdoor FM antennas work best outside, but usable
results can sometimes be obtained when installed in an
attic or loft.
• For best results, install the outdoor FM antenna well away
from tall buildings, preferably with a clear line of sight to
your local FM transmitter.
• Outdoor antenna should be located away from possible
noise sources, such as neon signs, busy roads, etc.
• For safety reasons, outdoor antenna should be situated
well away from power lines and other high-voltage
equipment.
• Outdoor antenna must be grounded in accordance with
local regulations to prevent electrical shock hazards.
■ Using a TV/FM Antenna Splitter
It’s best not to use the same antenna for both FM and TV
reception, as this can cause interference problems. If circumstances demand it, use a TV/FM antenna splitter, as
shown.
Connecting an Outdoor AM Antenna
If good reception cannot be achieved using the supplied
AM loop antenna, an outdoor AM antenna can be used
in addition to the loop antenna, as shown.
Outdoor antenna
AM loop antenna
Outdoor AM antennas work best when installed horizontally outside, but good results can sometimes be obtained
indoors by mounting horizontally above a window. Note
that the AM loop antenna should be left connected.
Outdoor antenna must be grounded in accordance with
local regulations to prevent electrical shock hazards.
Insulated antenna cable
18
TV/FM antenna splitter
To CD/HDD receiver To TV (or VCR)
Connections—Continued
Connecting Other Components
The following diagram shows how to connect other components (i.e., a cassette deck, an MD recorder, a CD recorder)
and an Onkyo RI Dock (Remote Interactive Dock). If Audyssey EQ™ is active, you cannot perform recording (except
for timer recording) to an external component. Deactivate Audyssey EQ™ when you want to record to an external
component (see page 26).
Connecting an MD recorder or cassette deck
Connect the CD/HDD receiver’s
Connect the CD/HDD receiver’s MD/TAPE IN jacks to the OUTPUT (PLAY) jacks of the MD recorder or cassette deck.
Connecting a CD recorder or an Onkyo RI Dock
Connect the CD/HDD receiver’s DOCK/CDR OUT jacks to the AUDIO INPUT jacks of the CD recorder or Onkyo RI
Dock.
Connect the CD/HDD receiver’s DOCK/CDR IN jacks to the AUDIO OUTPUT jacks of the CD recorder or Onkyo RI
Dock.
Connecting Onkyo u Components
First connect each Onkyo component to the CD/HDD receiver with an analog audio cable (RCA) as described above.
Next, make the necessary u connections with an u cable (see illustration below). Finally, change the Input Display
to the corresponding component name (see page 45).
MD recorder
MD/TAPE
OUT jacks to the INPUT (REC) jacks of the MD recorder or cassette deck.
Cassette deck
CD recorder
Onkyo RI Dock
R L
CD/HDD receiver’s rear panel
Analog audio
cables (RCA)
u cable supplied with the
Onkyo RI Dock
R L
: Signal flow
u cable supplied with other Onkyo components
What can you do with u?
• Connecting an Onkyo
with the CD/HDD receiver’s remote controller.
ponent
• When playback is started on the
u-capable component to the CD/HDD receiver via u cable allows you to control the com-
component connected via u, the CD/HDD receiver will automatically select it as
the input source.
• When you start playback on the component connected via u, if the CD/HDD receiver is on Standby, it will auto-
matically turn on. Similarly, when the CD/HDD receiver is set to Standby, all components connected via u will also
go on Standby.
Notes:
•No u cable is included with the CD/HDD receiver. Use u cables supplied with other Onkyo components.
•Use u jacks for a combined use with u-capable components.
•Some u-capable components have two u jacks. They’re both the same, so you can use either one. The extra jack is for
connecting additional u-capable components.
19
Connections—Continued
P
Connecting a Subwoofer
The CD/HDD receiver has SUBWOOFER PRE OUT jack for connecting a powered active subwoofer (i.e., a subwoofer
with a built-in amplifier).
CD/HDD receiver’s rear panel
: Signal flow
Connecting a Component with a Digital Audio Output
The following diagram shows how to connect a component with an optical digital audio output, such as a games console,
satellite tuner, or personal computer. Connect the CD/HDD receiver’s DIGITAL OPTICAL IN jack to an optical digital
audio output on the other component.
You can change the Input Display for the OPTICAL DIGITAL IN to DIGITAL, CD-R/dig, GAME/dig, or PC/dig so
that it matches the type of component that you connect (see page 45).
The CD/HDD receiver supports only a 16-bit PCM signal with a sampling rate of between 44.1 kHz and 48 kHz.
Some components require the settings of forced conversion to PCM.
owered active
subwoofer
: Signal flow
Commercially available optical
digital audio cable (square)
Optical digital output
Game console, etc.
DIGITAL
OUTPUT
Connecting a TV
Connect the CD/HDD receiver’s LINE 1 IN jacks to the TV’s audio output jacks.
Red White Red White
Analog audio cable (RCA)
Audio output
LR
20
TV
: Signal flow
Connections—Continued
Hooking Up to the Internet
The CD/HDD receiver is network-ready, which means
you can hook it up to your home network with a standard
Internet and the Gracenote® music recognition service is
available. Gracenote
music CD database service constructed on servers
located on the Internet. See page 80 for details.
In addition, while the PC is accessing the CD/HDD
receiver, you can transfer the music files between the
CD/HDD receiver and your PC via FTP. See page 52 for
details.
The CD/HDD receiver is configured to automatically try
to access the Internet upon completion of the hook up. If
your connection is not successfully established, see
page 68. A contract with an Internet Service Provider
(ISP) is required to connect to the Internet. If you already
have a broadband internet connection there is no need to
take out another contract.
Network Requirements
■ Ethernet Network
The CD/HDD receiver’s Ethernet port supports 10BaseT. For best results, a 100Base-TX switched Ethernet network is recommended. Because wireless connections
may be unreliable, wired connections are recommended.
®
music recognition service is
• The CD/HDD receiver does not support PPPoE settings,
so if you have a PPPoE-type Internet connection, you
must use a PPPoE-compatible router.
• Depending on your ISP, you may need to specify a proxy
server. If your computer is configured to use a proxy
server, use the same settings for the CD/HDD receiver
(
see page 69).
Connecting the CD/HDD receiver
To connect the CD/HDD receiver to your home network,
plug one end of a shielded CAT5 Ethernet cable into the
CD/HDD receiver’s ETHERNET port, and plug the
other end into a LAN port on your router or switch.
The following diagram shows how you can connect the
CD/HDD receiver to your home network. In this example, it’s connected to a LAN port on a router, which has
a 4-port 100Base-TX switch built-in.
CD/HDD receiver
■ Ethernet Router
A router manages the network, routing data and supplying IP addresses. Your router must support the following:
• NAT (Network Address Translation). NAT allows several networked computers to access the Internet simultaneously via a single Internet connection.
• DHCP (Dynamic Host Configuration Protocol).
DHCP supplies IP addresses to network devices,
allowing them to configure themselves automatically.
• A router with a 100Base-TX switch built-in is recommended.
Some routers have a modem built-in, and some ISPs
require you to use specific routers. Please consult your
ISP or computer dealer if you’re unsure.
■ CAT5 Ethernet cable
Use a shielded CAT5 Ethernet cable (straight-type) to
connect the CD/HDD receiver to your home network.
■ Internet Access
A narrowband Internet connection (e.g., 56K modem,
ISDN) will not provide satisfactory results, so a broadband connection is strongly recommended (e.g., cable
modem, xDSL modem, etc). Please consult your ISP or
computer dealer if you’re unsure.
Notes:
• The CD/HDD receiver uses DHCP to configure its network settings automatically. If you want to configure
these settings manually,
see page 69.
Modem
Router
LAN/Ethernet port
Computer
WAN port
LAN port
LAN port
Music recognition technology and related data are provided by Gracenote®. Gracenote is the industry standard
in music recognition technology and related content
delivery. For more information visit www.gracenote.com.
21
Turning On the CD/HDD Receiver
1
2
Plug the power cord into a suitable wall outlet.
The STANDBY indicator lights up after a while (several seconds). The CD/HDD receiver
enters the Standby mode.
Notes:
• Before connecting the power cord, connect all of your speakers and AV components.
• Turning on the CD/HDD receiver may cause a momentary power surge that might interfere with
other electrical equipment on the same circuit. If this is a problem, plug the CD/HDD receiver into
a different branch circuit.
To wall outlet
Power cord
(Plug type varies from country
to country.)
Press the [ON/STANDBY] button on the CD/HDD receiver or remote controller.
ON/STANDBYON/STANDBY
STANDBY indicator
The STANDBY indicator goes off and the following screen appears on the display. Press the
[ON/STANDBY] button again to set the CD/HDD receiver to Standby. The STANDBY indicator lights up.
Tip:
When you start playback on (or turn on) an Onkyo RI Dock, CD recorder, MD recorder, or cassette deck that’s connected to
the CD/HDD receiver with an u cable and analog audio cable, the CD/HDD receiver turns on automatically. Similarly, when
you set the CD/HDD receiver to On or Standby, the other component will also be set to On or Standby.
22
First Time Setup
Setting the Clock with the AccuClock Function
To use the AccuClock function, the CD/HDD receiver must be able to receive RDS radio stations, which means an FM
antenna must be connected. Be sure to connect an FM antenna before attempting to use this function (see page 17).
The very first time you turn on the CD/HDD receiver, the AccuClock function automatically sets the CD/HDD
receiver’s clock based on the CT (Clock Time) information present in an RDS radio broadcast. While the clock is being
set, “Wait…” appears on the display, as shown. Note that it may take up to 5 minutes to set the clock.
When the clock has been set, the message “Clock Adjusted” scrolls across the display, then the day and time are displayed for a while, as shown.
00 : 01
W
ait . . .
The AccuClock function automatically updates the clock daily at 2 A.M., 3 A.M., and 2 P.M.
If for some reason the clock cannot be set automatically, see “Setting AccuClock to Use a Specific Station” on page 62
and “Setting the Clock Manually” on page 63.
Turning Off the AccuClock Function
If you don’t want AccuClock to automatically update the clock each day, you can turn it off as follows.
2008 . 01 . 01
.
1
TIMER
2
/
ENTER
3
4
Press the [TIMER] button.
Clock
Timer 1
Timer 2
Press [ENTER] with “Clock”
selected.
The sub-menu appears and the CD/HDD
receiver enters clock setting mode.
Use the Up and Down [q]/[w] buttons to select “AccuClock”, and
then press [ENTER].
To turn off AccuClock, press the
Up or Down [q]/[w] button until the
asterisks disappear.
C l ock
RDS-CT Station
: FM 87.50MHz
The asterisks indicate that the
AccuClock function is on.
The AccuClock function is off. To turn
AccuClock back on again, press the Up
or Down [q]/[w] button so that the asterisks are displayed.
Note:
The AccuClock function cannot be turned off until the clock
has been set.
23
Basic Operations
Selecting the Input Source
You can select HDD, CD, AM, FM, or a connected component (LINE 1, TAPE, DOCK, USB or DIGITAL) as the input
source.
On the CD/HDD receiver, press the [INPUT
SELECTOR] button repeatedly.
The input sources are selected in the following order.
HDD CD USB FM
DIGITAL*
DOCK* TAPE*
* Input Display can be changed (see page 45).
AM
LINE
Tip:
You can also use the CD/HDD receiver’s MULTI JOG
dial to switch the input source while any input source is
displayed.
On the remote controller, press the INPUT
[q]/[w] buttons repeatedly.
Each time you press these buttons, you can select the
previous or next input source.
Using other buttons:
HDD 1 button*
Switches to HDD for playback.
CD 1 button*
Switches to CD for playback.
USB 1 button*
Switches to USB for playback.
TUNER (BAND) button
Selects AM or FM as the input source. If you press this
button repeatedly, you can switch the radio band.
* These buttons also work in the Standby mode.
Adjusting the Volume
Turn the [VOLUME] control clockwise to
increase the volume or counterclockwise to
decrease it.
CD/HDD receiver
Remote
controller
You can also use remote controller’s VOL [q]/[w] button.
The default setting is “10”. You can adjust the volume
from MIN, 01 through 41 to MAX.
24
Using Headphones
Turn down the volume, then connect your stereo headphones to the PHONES minijack.
You can adjust the volume and mute the sound, as
explained earlier.
The speakers output no sound while the headphones are
connected.
PHONES jack
Notes:
• Do not connect the audio output jack of any other device
to the PHONES jack, because it may cause a malfunction
of the device.
• When you use headphones, Onkyo recommend that you
deactivate Audyssey EQ™. About Audyssey EQ™, see
page 26.
Adjusting the Tone
You can use the following buttons on the remote controller to adjust the tone.
Using the Direct Function
DIRECT
TONE
S.BASS
MUTING
q/w
ENTER
Adjusting the Bass and Treble
1
Remote
controller
2
Using the Super Bass Function
Press the [TONE] button to select
“BASS:0”.
Muting the Sound
Use the Up and Down [q]/[w] buttons to adjust the bass.
The default setting is “±0”. You can
adjust the bass and treble from –3 to +3.
Press [ENTER], and then use the
Up and Down [q]/[w] buttons to
adjust the treble.
Notes:
• If you press no buttons for 8 seconds, the
previous display will appear automatically.
• If you press the [TONE] button while the
Direct function is on, the Direct function
will be turned off.
Press the [S.BASS] button.
The S.BASS indicator lights up.
To turn off the Super Bass function, press
the [S.BASS] button again.
S.BASS indicator
Press the [DIRECT] button.
When the Direct function is on, the tone
controls are bypassed, so you can enjoy a
pure sound, and the DIRECT indicator
lights up.
To turn off the Direct function, press the
[DIRECT] button again.
When the Direct function is off, the tone
controls can be used to adjust the sound.
DIRECT indicator
DirectOn
Press the [MUTING] button.
The output is muted and the MUTING
indicator flashes on the display.
To unmute the CD/HDD receiver, press
the [MUTING] button again.
MUTING indicator
Muting
Tips:
While the CD/HDD receiver is muted:
• Turning the [VOLUME] control on the
CD/HDD receiver or pressing the VOL
[q]/[w] button on the remote controller
will unmute the CD/HDD receiver.
• If you turn the CD/HDD receiver off, the
next time you turn it on, the CD/HDD
receiver will be unmuted.
S.BassOn
Note:
If you press the [S.BASS] button while the
Direct function is on, the Direct function
will be turned off.
25
Using Audyssey EQ™ and Audyssey Dynamic EQ™
Audyssey EQ™ optimizes the audio quality set for the
recommended Onkyo speakers. The recommended
speakers are D-112E and D-N10BX.
With Audyssey EQ™ enabled,
Audyssey Dynamic EQ™ becomes enabled by default.
You can deactivate Audyssey Dynamic EQ by selecting
“Off” in step 4 below. When Audyssey EQ™ is activated
while the Direct function is on, the Direct function will
be turned off.
Notes:
Audyssey Dynamic EQ™ allows you to maintain the
proper octave-to-octave balance at any volume level in
accordance with the preset speakers.
• In order to record with appropriate sound,
Audyssey EQ™ is automatically deactivated during a
recording. After the recording is finished,
Audyssey EQ™ and Audyssey Dynamic EQ™ will
resume as previously set.
1
2
Press the [TOOLS] button.
Use the Up and Down [q]/[w] buttons to select “Audio”, and then
press [ENTER].
Tool
Record
Audio
Deactivating Audyssey Dynamic EQ™
1
2
3
4
Press the [TOOLS] button.
Use the Up and Down [q]/[w] buttons to select “Audio”, and then
press [ENTER].
Tool
Record
Audio
Use the Up and Down [q]/[w] buttons to select “Dynamic EQ”,
and then press [ENTER].
Audio
Audyssey EQ
Dynamic EQ
Use the Up and Down [q]/[w] buttons to select “Off”, and then
press [ENTER].
3
4
Press [ENTER] with
“Audyssey EQ” selected.
Audio
Audyssey EQ
[Dynamic EQ]
Use the Up and Down [q]/[w] buttons to select the speaker, and
then press [ENTER].
Audio
Audyssey EQ
:D-112E
(The above is an example when D112E is selected.)
“Complete!” will be displayed, and the
setting is completed.
Audyssey Dynamic EQ™ becomes
active and the Dynamic EQ indicator
lights up.
Dynamic EQ indicator
Audio
Dynamic EQ
: Off
“Complete!” will be displayed, and the
setting is completed.
Audyssey Dynamic EQ™ becomes
deactive and the Dynamic EQ indicator
goes off.
When the Direct function is on while
Audyssey Dynamic EQ™ is activated,
Audyssey Dynamic EQ™ will be deactivated. In this
status, when the Direct function is turned off,
Audyssey Dynamic EQ™ will resume.
About Audyssey Dynamic EQ™
Audyssey Dynamic EQ solves the problem of
deteriorating sound quality as volume is decreased by
taking into account human perception and room
acoustics. Dynamic EQ selects the correct frequency
response moment-by-moment at any user-selected
volume setting. The result is bass response and tonal
balance that remains constant despite changes in
volume. Dynamic EQ combines information from
incoming source levels with actual output sound
levels in the room, a prerequisite for delivering a
loudness correction solution. Audyssey Dynamic EQ
works in tandem with Audyssey EQ to provide wellbalanced sound for every listener at any volume level.
26
