One for All URC-7532 User Manual
URC-7532
702077
Universal remote
F
D
UK
I
NL
P
E
2 WWW.ONEFORALL.COM
PICTURE OF ONE FOR ALL 3 REMOTE
3
INSTALLING THE BATTERIES
4
THE KEYPAD
4
INSTALLATION
Setting up your devices 6
The Search Method 7
USING THE AUX KEY
8
CHANGING A DEVICE KEY
8
QUICK CODE REFERENCE
8
ADVANCED FEATURES
Colour and Brightness 9
Volume Punch-Through 9
Auto Scan 9
Device Sleeptimer 10
The ONE FOR ALL Sleeptimer 10
TROUBLE-SHOOTING
Helpful Hints 11
Customer Service 12
SET-UP CODES
Televisions 73
Video Recorders 78
Table of Contents
Your ONE FOR ALL 3 Package contains:
• Your ONE FOR ALL 3 Remote
• Your ONE FOR ALL 3 Manual
Your manual is divided into two parts: set-up instructions and device
codes. You may need this guide again in the future, so please be
sure to keep it.
Your ONE FOR ALL 3 needs 2 new “AA/LR6” alkaline batteries.
Your ONE FOR ALL 3 can operate three devices: a Television,
a Video Recorder and a second Television or Video Recorder.
UK
About Your ONE FOR ALL 3
WWW.ONEFORALL.COM 3
4
8
6
1
5
9/10
7
3
2
Installing the Batteries
Your ONE FOR ALL 3 needs 2 new “AA/LR6” alkaline batteries.
1 Remove the battery cover from the back of your ONE FOR ALL 3 by
pressing down on the tab.
2 Match the batteries to the + and - marks inside the battery case,
then insert the batteries.
3 Press the battery cover back into place.
See picture of ONE FOR ALL 3 remote on page 3
1
LED
The LED (Light Emitting Diode) flashes red to show the remote is
working.
2 MAGIC Key
The MAGIC key is used to set up your ONE FOR ALL 3 and to access
special functions.
3 POWER Key
The Power key controls the same function as it did on your original
remote.
4 Device Keys
The TV, VCR and AUX keys select the home entertainment device to
be controlled. For example pressing the TV key allows the remote to
control the functions of your Television, after pressing VCR you can
operate your Video Cassette Recorder and the AUX key operates a
second television or video recorder.
5 Number Keys
The Number keys (0-9, 10, 20) provide functions just like your original remote, such as direct access programme selection. If your original
remote uses one/two digit input switching (-/-- symbol), this function
can be obtained by pressing the -/-- key, which is the same as the 10
key.
6 Programme (Channel) +/- Keys
These keys operate in the same way as the keys on your original
remote.
7 Mute
The Mute key operates the same function it did on your orginal
remote control. It is also used to activate the Scan feature (see page
9).
8 Volume +/- Keys
These keys operate in the same way as the keys on your original
remote.
The Keypad
Important notes:
- In order to avoid having to reprogram your ONE FOR ALL 3 after
you remove the batteries, you will need to insert new batteries
within 5 minutes. Also it is best that you do not use rechargable
batteries.
- On the inside of the battery compartment door you will find a
label on which to write your Set-Up codes after your ONE FOR
ALL 3 is set up for your device. Please write down your codes for
easy, future reference.
WWW.ONEFORALL.COM 4
WWW.ONEFORALL.COM 5
9
Video Recorder Keys
After pressing the VCR key, the Video Recorder keys operate the
functions of your Video Recorder. To prevent accidental recording,
the Record key must be pressed twice to start recording.
10 Teletext and Fastext Keys
After pressing the TV key, the top row of the VCR keys is used to
operate the main Teletext functions. The symbols below the keys are
for Teletext. The text keys are used to access the Teletext functions
of your television. Of course, your television must have Teletext
capability.
TEXT ON: Puts the television in the Teletext mode.
TEXT OFF: Switches the television back to regular viewing mode. On
some televisions, this may be done by pressing the TEXT ON key
several times.
EXPAND: Shows the top half of the Teletext page in larger letters.
By pressing again, you can see the bottom half of the Teletext page
enlarged. To return to regular Teletext viewing, press the EXPAND
key again, or press the TEXT ON key, depending on your television.
HOLD/STOP: Stops changing pages.
After pressing the TV key and accessing the text mode, the bottom
row of the Video Recorder keys marked red, green, yellow and
blue, allow you to access the Fastext functions of your television.
Important note: For a more detailed explanation of Teletext and Fastext,
please refer to the manual of your television. Remember, different televisions
control Teletext and Fastext features in different ways. Not all of the Teletext
functions may be available for your particular model.
6 WWW.ONEFORALL.COM
Setting Up Your Devices
Example: To set up the ONE FOR ALL 3 for your television:
1 Find the code for your device in the Code list.
Codes are listed by device type and brand name.
The most popular code is listed first. Make sure your
device is switched on (not on standby).
2 Press the TV key on the ONE FOR ALL 3 for the device
you wish to set up.
3 Press and hold down MAGIC until the red light blinks
twice. (The red light will blink once and then twice.)
4 Enter your (four-digit device code) using the number
keys. The red light will blink twice.
5 Now, aim the ONE FOR ALL 3 at your device and
press POWER. If your device switches off, the ONE FOR
ALL 3 is ready to operate your device.
6 Turn your device back on and try all the remote’s functions to ensure
they are working properly. If the functions do not work properly,
repeat steps 1-5 using another code listed under your brand.
7 If your device does not respond, follow steps 1 to 5 with
each code listed for your brand. If none of the codes listed
for your brand operate your device, or if your brand is not
listed at all, try the search method described on page 7.
8 Write your code in the four boxes provided in the battery
compartment and on page 8 for easy future reference.
Installation
Before you start, please read these instructions carefully
Important notes:
- Some codes are quite similar. If your device does not respond or is not
functioning properly with one of the codes, try another code listed under
your brand.
- If your VCR’s original remote control does not have a POWER key, press
PLAY instead of POWER during step 5, when setting up your device.
- Remember to press the correct device key before operating your device.
Only one device can be assigned to a device key. If your original remote
operates more than one device, you need to set up each device separately.
ONE FOR A
Adyson
Agazi
AGB
Agef
0
0
0
9
0
0
8
7
, 0
0
9
3
, 0
3
6
3
, 0
4
1
0
2
1
7
, 0
2
1
6
0
2
6
4
0
5
1
6
0
0
8
7
0
2
1
6
, 0
0
0
9
, 0
0
3
7
, 0
0
0
3
7
, 0
2
7
4
, 0
2
0
8
, 0
3
7
1
____
6 WWW.ONEFORALL.COM
To set up a second TV or VCR (see page 8).
(*) To use the AUX key (see page 8).
Devices can be found under the following keys:
Television
Video Recorder
(*) Television /
(*) Video Recorder /
The Search Method
If your device does not respond to the ONE FOR ALL 3 after you have tried
all the codes listed for your brand, try searching for your code. The Search
Method allows you to find the code for your device by scanning through all
the codes contained in the memory of the ONE FOR ALL 3. The Search
Method may also work if your brand is not listed at all.
Example: To search for your TV code:
1 Switch your television on (not on standby) and aim your
ONE FOR ALL at your TV.
2 Press the TV key on your ONE FOR ALL 3.
3 Press and hold down MAGIC until the ONE FOR ALL 3’s
red light blinks twice (The red light will blink once and
then twice).
4 Press 9 9 1. The red light will blink twice.
5 Now slowly, alternate between TV and POWER, over and
over, until your television turns off. You may have to
press these keys many times (up to 200!), so please
be patient. Remember to keep pointing the ONE FOR
ALL 3 at your television when you press these keys.
6 As soon as your television turns off, press MAGIC.
The ONE FOR ALL remote should now be ready to operate your device.
Turn your device back on and try all the remote’s functions to ensure they
are working properly. If some of the ONE FOR ALL’s commands are not
operating correctly, try the search method again. You may be using the
wrong code.
Once you have Set-Up your ONE FOR ALL 3, you can blink back your
SET-UP CODE for future reference.
Example: To blink out your Television code:
1 Press TV once.
2 Press and hold MAGIC until the ONE FOR ALL 3’s TV key
blinks twice (The red light will blink once and then twice).
3 Press 9 9 0. The red light will blink twice.
4 For the first digit of your four-digit code, press 1 and
count all the red blinks. If there are no blinks, the digit is
"0".
5 For the second digit, press 2 and count all the red blinks.
If there are no blinks, the digit is "0".
6 For the third digit, press 3 and count all the red blinks.
If there are no blinks, the digit is "0".
7 For the fourth digit, press 4 and count
all the red blinks. If there are no blinks, the digit is "0".
Now you have your four-digit code.
Make sure you write your Television code in the boxes provided in
the battery compartment and on page 8 for easy future reference.
Important notes:
- To search for the code for another device follow the instructions above
only press the appropriate device key instead of TV during steps 2 and 5.
- If the original remote control of your VCR does not have a POWER key,
press PLAY instead of POWER during step 5.
Important note: To blink back the code for your other devices press the
appropriate device key during step 1.
WWW.ONEFORALL.COM 7
