Page 1
RFID System
V680 Series
Hand-held Reader Writer
User's Manual
Hand-held Reader Writer
V680-CHUD
V680-CH1D
V680-CH1D-PSI
ID Tags
V680/V680S Series
Man. No.: Z272-E1-07
Page 2
Introduction
Thank you for purchasing a V680/V680S-series RFID System. This manual describes the functions,
performance, and application methods needed for optimum use of the V680/V680S-series RFID System.
Please observe the following items when using the V680-series RFID System.
• Allow the V680/V680S-series RFID System to be installed and operated only by qualified specialist with a
sufficient knowledge of electrical systems.
• Read and understand this manual before attempting to use the V680/V680S-series RFID System and use
the V680/V680S-series RFID System correctly.
• Keep this manual in a safe and accessible location so that it is available for reference when required.
Page 3
Introduction
Section 1
Section 2
Section 3
Section 4
Section 5
Section 6
READ AND UNDERSTAND THIS DOCUMENT
Product Overview
Communications Preparations
Commands
Functions
Troubleshooting
ÇÕǹÇflÇëÊ 1 èÕ ëÊ 2 èÕ ëÊ 3 èÕ ëÊ 4 èÕ
Introduction
Section 1 Section 2 Section 3 Section 4 Section 5 Section 6
Appendices
RFID System
V680-CHUD Hand-held Reader/Writer
V680-CH1D Hand-held Reader/Writer
V680-CH1D-PSI Hand-held Reader/Writer
V680 Series RF Tags
V680S Series RF Tags
User’s Manual
Page 4
Introduction
Introduction
READ AND UNDERSTAND THIS DOCUMENT
Please read and understand this document before using the products. Please consult your OMRON representative if you have any questions or comments.
WARRANTY
OMRON’s exclusive warranty is that the products are free from defects in materials and workmanship for a period of one year (or other period if specified)
from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE. OMRON DISCLAIMS ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR COMMERCIAL LOSS IN
ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY.
In no event shall responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE PRODUCTS UNLESS OMRON’S
ANALYSIS CONFIRMS THAT THE PRODUCTS WERE PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.
SUITABILITY FOR USE
THE PRODUCTS CONTAINED IN THIS DOCUMENT ARE NOT SAFETY RATED. THEY ARE NOT DESIGNED OR RATED FOR ENSURING SAFETY OF
PERSONS, AND SHOULD NOT BE RELIED UPON AS A SAFETY COMPONENT OR PROTECTIVE DEVICE FOR SUCH PURPOSES. Please refer to separate catalogs for OMRON's safety rated products.
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the combination of products in the customer’s application or use of the product.
At the customer’s request, OMRON will provide applicable third party certification documents identifying ratings and limitations of use that apply to the products. This information by itself is not sufficient for a complete determination of the suitability of the products in combination with the end product, machine,
system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not intended to be an exhaustive list of all possible uses
of the products, nor is it intended to imply that the uses listed may be suitable for the products:
Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or uses not described in this document.
•
Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical equipment, amusement machines, vehicles, safety
•
equipment, and installations subject to separate industry or government regulations.
Systems, machines, and equipment that could present a risk to life or property.
•
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR PROPERTY WITHOUT ENSURING THAT THE SYSTEM
AS A WHOLE HAS BEEN DESIGNED TO ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT IS PROPERLY RATED AND INSTALLED FOR THE
INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PERFORMANCE DATA
Performance data given in this document is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the
result of OMRON’s test conditions, and the users must correlate it to actual application requirements. Actual performance is subject to the OMRON Warranty
and Limitations of Liability.
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other reasons.
It is our practice to change model numbers when published ratings or features are changed, or when significant construction changes are made. However,
some specifications of the product may be changed without any notice. When in doubt, special model numbers may be assigned to fix or establish key specifications for your application on your request. Please consult with your OMRON representative at any time to confirm actual specifications of purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when tolerances are shown.
ERRORS AND OMISSIONS
The information in this document has been carefully checked and is believed to be accurate; however, no responsibility is assumed for clerical, typographical,
or proofreading errors, or omissions.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user’s programming of a programmable product, or any consequence thereof.
COPYRIGHT AND COPY PERMISSION
This document shall not be copied for sales or promotions without permission. This document is protected by copyright and is intended solely for use in conjunction with the product. Please notify us before copying or reproducing this document in any manner, for any other purpose. If copying or transmitting this
document to another, please copy or transmit it in its entirety.
RFID System
2
User's Manual
Page 5
Introduction
Safety Precautions
Signal Words Used in This Manual
The following symbols are used in this manual to indicate precautions that must be observed to ensure safe
use of the V680/V680S-series RFID System. The precautions provided here contain important safety
information. Be sure to observe these precautions.
The following signal words are used in this manual.
Indicates a potentially hazardous situation which, if not avoided, will result in minor or
WARNING
Meanings of Alert Symbols
moderate injury, or may result in serious injury or death. Additionally, there may be significant property damage.
Introduction
Indicates the possibility of explosion under specific conditions.
Indicates general prohibitions for which there is no specific symbol.
Warning
WARNING
This Product is not designed or rated for ensuring safety of persons. Do not use it for such
purposes.
RFID System
User's Manual
3
Page 6
Introduction
Introduction
Precautions for Safe Use
Observe the following precautions to ensure safe use of the Product.
1. Do not use the Product in environments with flammable, explosive, or corrosive gasses.
2. Do not attempt to disassemble, repair, or modify the Product.
3. The USB driver must be installed in the personal computer before connecting the V680-CHUD to a
personal computer.
4. Do not subject cables to excessive loads.
5. Observe all warnings and precautions given in the body of this manual.
6. Discontinue usage and turn OFF the power supply immediately if you notice any unusual odors, if the
Product is abnormally hot, or if the Product starts smoking.
7. Dispose of the Product as industrial waste.
RFID System
4
User's Manual
Page 7
Introduction
Precautions for Correct Use
Always observe the following precautions to prevent operation failures, malfunctions, and adverse effects on
performance and equipment.
1. Installation and Storage Environment
Do not use or store the Product in the following locations.
• Locations exposed to corrosive gases, dust, metallic powder, or salts
• Locations not within the specified operating temperature range
• Locations subject to rapid changes in temperature or condensation
• Locations not within the specified operating humidity range
• Locations subject to direct vibration or shock outside the specified ranges
• Locations subject to spray of water, oil, or chemicals
2. Environment
• This Product uses a frequency band of 13.56 MHz to communicate with RF Tags. Some motors,
inverters, switching power supplies, and other devices generate electrical noise that will affect communications with the RF Tags. If any of these devices are located in the vicinity of the Product, they
may affect communications with RF Tags, and may possibly damage the RF Tags. Prior to using the
Product in the vicinity of any of these devices, perform a test to determine whether the Product can
be used under the resulting influence.
• Observe the following precautions to minimize the effects of normal noise.
(1) Ground all metal objects in the vicinity of the Product to 100 Ω or less.
(2) Do not use the Product near high-voltage or high-current lines.
• Connectors are not waterproof. Do not use the Product where mists are present.
• Do not use chemicals that would affect the materials used in the product.
• Be sure the USB connector is properly inserted when using the USB port on the V680-CHUD.
• Always use the specified AC Adaptor (V600-A22) when using the V680-CH1D.
• The communications range is adversely affected if there is any metal material around the RF Tag.
•Transmission will not be possible if the front and back panels are mistakenly reversed and the Unit is
mounted to a metallic surface.
V680-D1KP66MT
V680-D8KF67M
V680S-D2KF67M
V680S-D2KF68M
V680S-D8KF67M
V680S-D8KF68M
Introduction
•The communications range will be reduced when the Unit is not mounted to a metallic surface.
mounted to a metallic surface.
V680-D1KP66MT
V680-D8KF67M
V680S-D2KF67M
V680S-D2KF68M
V680S-D8KF67M
V680S-D8KF68M
•The maximum communications range can be obtained when the Antenna faces the RF tag directly.
When the RF tag is installed at a tilt, the communications range is reduced. Consider the effect of
the RF tag at tilt when installing the RF Tag.
•Provide the mounting distances between plural RF tags to prevent them from malfunctions due to
mutual interference
RFID System
User's Manual
5
Page 8
Introduction
Introduction
•If the central axis of an antenna and RF tag shifts, a communications range will fall.
•Do not touch the product immediately after usage at high temperatures. Doing so may occasionally
result in burning.
3. Host Communications
Always confirm that the Product has been started before attempting to communicate with it from the
host. Also, when the Product is started, unstable signals may be output from the host interface. When
starting operation, clear the reception buffers in the host or take other suitable countermeasures.
4. Cleaning
• Do not clean the product with thinners, benzene, or other organic solvents. These will dissolve the
resin parts and coating on the case.
RFID System
6
User's Manual
Page 9
How to Read this Manual
Meanings of Symbols
Indicates particularly important points related to a function, including precautions and application advice.
Indicates page numbers containing relevant information.
Indicates reference to helpful information and explanations for difficult terminology.
Introduction
Introduction
RFID System
User's Manual
7
Page 10
Introduction
Introduction
MEMO
RFID System
8
User's Manual
Page 11
Introduction
Table of Contents
Introduction
Safety Precautions 3
Precautions for Safe Use 4
Precautions for Correct Use 5
How to Read this Manual 7
Section 1 Product Overview 11
Features 12
Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT) 14
Introduction
Names and Functions of Components 19
System Configuration 22
Operation Flowchart 25
Section 2 Communications Preparations 29
V680-CHUD Communications Preparations 30
V680-CH1D Communications Preparations 45
V680-CH1D-PSI Communications Preparations 48
Setting the Hand-held Reader/Writer 49
Communications Test 53
Section 3 Commands 55
Communicating with RF Tags 56
V600 and V680 Command Comparison 57
V680 Commands 59
V600 Commands 83
Section 4 Functions 119
Hand-held Reader/Writer Functions 120
Write Protection Function 121
RF Tag Service Life Detection 123
Memory Check Function in RF Tag 125
RF Tag Memory Error Correction 126
RFID System
User's Manual
9
Page 12
Introduction
Introduction
Section 5 Troubleshooting 127
Error Tables 128
Troubleshooting Flowchart 129
Section 6 Appendices 131
Specifications and Dimensions 132
RF Tag Memory Map 149
RF Tag Memory Capacities and Memory Types (V680 Series) 150
List of ASCII Characters 151
Degree of Protection 152
Revision History 154
10
RFID System
User's Manual
Page 13
Section 1 Product Overview
Features 12
Using Heat-resistive Tags
(V680-D1KP58HTN and V680-D1KP58HT) 14
Names and Functions of Components 19
System Configuration 22
Operation Flowchart 25
Section 1
Product Overview
RFID System
User's Manual
11
Page 14
Section 1
Personal computer
RF Tags
Hand-held Reader/Writers
Hand-held Terminal
manufactured by Zebra Technologies Inc.
Hand-held Terminal Recommended
for the V680-CH1D-PSI: Work About Pro
Product Overview
Features
Section 1
Features
The V680-series Hand-held Reader/Writer incorporates a V680-series Antenna and Controller into a compact
design. Data can be read from or written to the RF Tag simply by approaching or touching the RF Tag with the
Hand-held Reader/Writer.
12
V680-CHUD
This Hand-held Reader/Writer provides a USB connector that conforms to the USB 1.1 standard. Connecting the Hand-held Reader/Writer to a personal computer or Hand-held Terminal gives it superior
portability, and operability.
V680-CH1D
A built-in RS-232C interface allows this Hand-held Reader/Writer to be connected to a personal computer or programmable controller.
V680-CH1D-PSI
A built-in RS-232C interface allows this Hand-held Reader/Writer to be connected to a Hand-held Terminal, giving it superior portability, and operability.
RFID System
User's Manual
Page 15
Section 1
PresentNothing
Version 1.0
Version 1.1
Product Overview
Differences between Version 1.0 and 1.1
The following functions have been added to version 1.1 in comparison to version 1.0. Functions are
upwardly compatible, so version 1.0 can be replaced with version 1.1.
CA1D Mode Setting Added for Tag Memory
Setting the Tag memory setting to CA1D Mode enables reading and writing Heat-resistant Tags that
were written by the V680-CA1D/-CA2D.
Parameter Added to PARAMETER SET (SP) Command
A parameter to set the Tag memory setting was added to the PARAMETER SET (SP) command.
The Tag memory setting is made in the Hand-held Reader/Writer. A different memory map may be used when reading
or writing Heat-resistant Tags that were written by the V680-CA1D/-CA2D from a Reader/Writer that is manufactured by
a company other than OMRON. Refer to Operation When Tag Memory Setting Is Set to Standard Mode in this section.
p.17
Section 1
Features
Checking the Version
RFID System
User's Manual
13
Page 16
Section 1
Product Overview
Using Heat-resistive Tags (V680-D1KP58HTN and
Section 1
Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT)
V680-D1KP58HT)
This section provides information for using Heat-resistive Tags (V680-D1KP58HTN or V680-D1KP58HT).
If you are not using a Heat-resistive Tag, set the Tag memory setting to Standard Mode.
Precautions for Saving Data at High Temperatures
If you are using a Heat-resistive Tag, write the data again after saving the data at a high temperature
even if it is not necessary to change the data. A " high temperature" is one between 110°C and 200°C.
Using the V680-CA1D/-CA2D
If you are using Heat-resistive Tags (V680-D1KP58HTN or V680-D1KP58HT) and also using the
V680-CA1D/-CA2D, set the Tag memory setting of the V680-CH@D (version 1.1 or newer) to CA1D
Mode.
If you are not using the V680-CA1D/-CA2D, the Tag memory setting does not need to be changed.
Refer to information in Names and Functions of Components.
Combining the V680-CA1D/-CA2D with Other Models
When using other models of Controller with the V680-CA1D/-CA2D, make sure that the version allows
setting the Tag memory setting to CA1D Mode.
To use the V680-CA5D01-V2/-CA5D02-V2, it must be version 2.3 or newer.
To use the V680-CH@D, it must be version 1.1 or newer.
To use the CS/CJ1W-V680C1@, it must be version 1.2 or newer.
Refer to Checking the Version for information on product versions.
p.13
14
RFID System
User's Manual
Page 17
Section 1
V680-CA1D/-CA2D
V680-CH@D
Reading/writing
OK
V680-CH@D
Reading/writing
OK
Address maps
reversed.
Standard model:
V680-CH@D (Ver.1.0)
(Version 1.1 or newer:
Tag memory setting set
to Standard Mode.)
(Version 1.1 or newer:
Tag memory setting set to
CA1D Mode.)
Product Overview
Introduction
The address maps in the RF Tags for the V680-D1KP@@ (except for the V680-D1KP58HT) are
reversed between the V680-CA1D/-CA2D ID Controllers and V680-CH@D Hand-held Reader/Writer
(with Tag memory setting set to CA1D Mode for version 1.1 or newer), and the V680-CH@D (version
1.0) and V680-CH@D (with Tag memory setting set to Standard Mode for version 1.1 or newer) Handheld Reader/Writers. Therefore, when you use RF Tags with a V680-CA1D/-CA2D ID Controller,
always set the Tag memory setting to CA1D Mode in any other models of ID Controller or Hand-held
Reader/Writers that are used for the same RF Tags.
Section 1
Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT)
RFID System
User's Manual
15
Page 18
Section 1
Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT)
Section 1
Product Overview
Applicable RF Tags
Only the V680-D1KP@@ RF Tags can be used when the Tag memory setting is set to CA1D Mode.
V680-D@KF@@ RF Tags cannot be used.
RF Tags That Can Be Used RF Tags That Cannot Be Used
Models Models
V680-D1KP58HT V680-D2KF52M
V680-D1KP58HTN V680-D8KF67
V680-D1KP52MT V680-D8KF67M
V680-D1KP53M V680-D8KF68
V680-D1KP66T V680-D32KF68
V680-D1KP66MT V680S-D2KF67
V680S-D2KF67M
V680S-D2KF68
V680S-D2KF68M
V680S-D8KF67
V680S-D8KF67M
V680S-D8KF68
V680S-D8KF68M
CA1D Mode Setting for Tag Memory and Write Protection
When setting the Tag memory setting to CA1D Mode, always disable write protection.
Setting the Tag Memory Setting to CA1D Mode
When changing an existing system to use the V680-CA1D/-CA2D, there are restrictions in the command system and write protection function.
The following settings are required if the Tag memory setting is set to CA1D Mode.
1.Process code J in PARAMETER SET (SP) command: Set the command system setting to 0 to set
the command system to V600 commands.
2.Process code H in PARAMETER SET (SP) command: Set the write protection function setting to 1 to
disable write protection.
3.Process code L in PARAMETER SET (SP) command: Set the Tag memory setting to 1 to set CA1D
Mode.
Standard Mode is the default Tag memory setting.
For details on the PARAMETER SET (SP) command, refer to PARAMETER SET (SP) under V680 Commands or V600
Commands in Section 3 Commands.
p.78, p.116
16
RFID System
User's Manual
Page 19
Section 1
0000 hex
0001 hex
0002 hex
0003 hex
0004 hex
0005 hex
0006 hex
0007 hex
:
:
03E0 hex
03E1 hex
03E2 hex
03E3 hex
03E4 hex
03E5 hex
03E6 hex
03E7 hex
Data written with
V680-CA1D/-CA2D
Address
01 hex
23 hex
45 hex
67 hex
89 hex
AB hex
CD hex
EF hex
:
:
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
:
:
01 hex
23 hex
45 hex
67 hex
89 hex
AB hex
CD hex
EF hex
Addresses are
reversed by block.
Data read with V680-CH@D (version
1.0) or V680-CH@D (version 1.1 or
newer with Tag memory setting set to
Standard Mode)
Product Overview
Operation When Tag Memory Setting Is Set to Standard Mode
When data that was written to a V680-D1KP58HTN RF Tag with the V680-CA1D/-CA2D ID Controller
is read from a V680-CH@D Hand-held Reader/Writer, the data from addresses that are reversed in
one-block (eight-byte) units is read.
If you are going to use a V680-CH@D Reader/Writer in the same line as a V680-CA1D/-CA2D ID Controller, use a V680-CH@D Reader/Writer with version 1.1 or newer and set the Tag memory setting to
CA1D Mode.
Section 1
Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT)
RFID System
User's Manual
17
Page 20
Section 1
0000 hex
0001 hex
0002 hex
0003 hex
0004 hex
0005 hex
0006 hex
0007 hex
:
:
03E0 hex
03E1 hex
03E2 hex
03E3 hex
03E4 hex
03E5 hex
03E6 hex
03E7 hex
Data written with
V680-CA1D/-CA2D
Address
01 hex
23 hex
45 hex
67 hex
89 hex
AB hex
CD hex
EF hex
:
:
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
01 hex
23 hex
45 hex
67 hex
89 hex
AB hex
CD hex
EF hex
:
:
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
00 hex
Same as data read with
V680-CA1D/-CA2D.
Data read with V680-CH@D (version
1.1 or newer with Tag memory setting
set to CA1D Mode)
Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT)
Section 1
Product Overview
Operation When Tag Memory Setting Is Set to CA1D Mode
If the Tag memory setting for the V680-CH@D (version 1.1 or newer) is set to CA1D Mode, data is read
from or written to addresses that are reversed in block units for the V680-D1KP@@ (except for the
V680-D1KP58HT) in the same way as for the V680-CA1D/-CA2D. Therefore, data can be read from
the same addresses as those to which data was written by the V680-CA1D/-CA2D.
18
Canceling CA1D Mode
To cancel CA1D Mode, use the PARAMETER SET (SP) command to set the Tag memory setting to
Standard Mode.
Process code L: Set the Tag memory setting to Standard Mode. For the V600 protocol, set the tag
memory setting to 0. For the V680 protocol, set the tag memory setting to 00.
For details on the PARAMETER SET (SP) command, refer to PARAMETER SET (SP) under V680 Commands or V600
Commands in Section 3 Commands.
p.78, p.116
When CA1D Mode is canceled, the address mapping with the RF Tags will be different from the ones written in CA1D
Mode. This may cause unexpected addresses to be read or written. When canceling CA1D Mode, initialize the data in
the RF Tags before using them.
RFID System
User's Manual
Page 21
Names and Functions of Components
Antenna
Operation indicator (LED)
Activate switch
Interface connector
Section 1
Product Overview
V680-CHUD
Operation Indicator (LED)
Display Meaning
A command has been received from the host device.
Communications with the RF Tag have completed normally.
Lit green
When the power is turned ON, after initialization of the Hand-held
Reader/Writer is completed.
Communications with the RF Tag are in progress.
Flashing green
A communications error with the RF Tag has occurred.
A CPU error has occurred.
Lit red
An RF Tag non-existent error has occurred.
A communications error with the host device has occurred.
Flashing red
After the operation indicator is lit or flashing for a certain time, it will turn OFF.
Section 1
Names and Functions of Components
Activate Switch
When button commands or commands with button communications specifications (button trigger or button auto) are used and the activate switch is
pressed, communications with the RF Tag will start. (For details on button
communications specifications, refer to Section 3 Commands.)
Interface Connector
This is a USB interface with an A-series plug based on USB 1.1.
Antenna
To communicate with the RF Tag, move the antenna close to it.
V680-CH1D
RFID System
User's Manual
19
Page 22
Section 1
Antenna
Operation indicator (LED)
Activate switch
Serial interface
connector
AC Adaptor
connection jack
Reset button
Product Overview
Operation Indicator (LED)
Section 1
Names and Functions of Components
Display Meaning
A command has been received from the host device.
Communications with the RF Tag have completed normally.
Lit green
•When the power is turned ON, after initialization of the Hand-held
Reader/Writer is completed
•When the power is turned ON and the reset button is pressed for
two seconds or more (initialization stand-by mode).
Flashing green
Lit red
Flashing red
After the operation indicator is lit or flashing for a certain time, it will turn OFF.
Communications with the RF Tag are in progress.
A communications error with the RF Tag has occurred.
A CPU error has occurred.
An RF Tag non-existent error has occurred.
A communications error with the host device has occurred.
Activate Switch
When button commands or commands with button communications specifications (button trigger or button auto) are used and the activate switch is
pressed, communications with the RF Tag will start. (For details on button
communications specifications, refer to Section 3 Commands.)
If the activate switch is pressed with the Hand-held Reader/Writer in the initialization stand-by mode (with the green indicator flashing), the function
settings will be initialized.
Reset Button
Press this button for two seconds or more when the power is first turned
ON to put the Hand-held Reader/Writer into the initialization stand-by
mode.
AC Adaptor Connection Jack
This is a connection jack for the V600-A22 AC Adaptor.
Serial Interface Connector
This is a serial interface with an RS-232C-compliant D-Sub 9-pin connector.
20
RFID System
User's Manual
Antenna
To communicate with the RF Tag, move the antenna closer to it.
V680-CH1D-PSI
Page 23
Operation Indicator (LED)
Antenna
Operation indicator (LED)
Activate switch
Serial interface
connector
Reset button
Section 1
Product Overview
Display Meaning
A command has been received from the host device.
Communications with the RF Tag have completed normally.
Lit green
•When the power is turned ON, after initialization of the Hand-held
Reader/Writer is completed.
•When the power is turned ON and the reset button is pressed for
two seconds or more (initialization stand-by mode).
Flashing green
Lit red
Flashing red
After the operation indicator is lit or flashing for a certain time, it will turn OFF.
Communications with the RF Tag are in progress.
A communications error with the RF Tag has occurred.
A CPU error has occurred.
An RF Tag non-existent error has occurred.
A communications error with the host device has occurred.
Section 1
Names and Functions of Components
Activate Switch
When button commands or commands with button communications specifications (button trigger or button auto) are used and the activate switch is
pressed, communications with the RF Tag will start. (For details on button
communications specifications, refer to Section 3 Commands.)
If the activate switch is pressed with the Hand-held Reader/Writer in the initialization stand-by mode (with the green indicator flashing), the function
settings will be initialized.
Reset Button
Press this button for two seconds or more when the power is first turned ON
to put the Hand-held Reader/Writer into the initialization stand-by mode.
Serial Interface Connector
This is a serial interface with an RS-232C-compliant D-Sub 9-pin connector.
Antenna
To communicate with the RF Tag, move the antenna closer to it.
RFID System
User's Manual
21
Page 24
Section 1
Host Devices
Hand-held Reader/Writer
RF Tags
Personal computer
Product Overview
System Configuration
Section 1
System Configuration
V680-CHUD
The V680-CHUD Hand-held Reader/Writer can communicate with host devices that have a USB interface,
such as personal computers.
The V680-CHUD Hand-held Reader/Writer can be used with any RF Tag in the V680/V680S Series.
For details on Hand-held Reader/Writer and RF Tag models, refer to Section 6 Appendices.
p.132, p.150
22
When using a V680-D8KF@@, to use the V680-CHUD of production after October 2014.
RFID System
User's Manual
Page 25
Host Devices
Hand-held Reader/Writer
RF Tags
V680-CH1D
Personal computer
Programmable controller
(Some models require a conversion connector.)
V600-A22 (option)
Section 1
Product Overview
V680-CH1D
A built-in RS-232C serial interface in the V680-CH1D Hand-held Reader/Writer allows communication with
personal computers and programmable controllers that are equipped with an RS-232C interface.
Section 1
System Configuration
The V680-CH1D Hand-held Reader/Writer can be used with any RF Tag in the V680/V680S Series.
For details on Hand-held Reader/Writer and RF Tag models, refer to Section 6 Appendices.
p.132, p.150
When using a V680-D8KF@@, to use the V680-CH1D of production after October 2014.
RFID System
User's Manual
23
Page 26
Section 1
Host Devices
Hand-held Reader/Writer
RF Tags
Recommended Hand-held Terminal:
Work About Pro manufactured by Zebra Technologies Inc.
V680-CH1D-PSI
System Configuration
Section 1
Product Overview
V680-CH1D-PSI
A built-in RS-232C serial interface in the V680-CH1D-PSI Hand-held Reader/Writer allows communications
with personal computers and programmable controllers that are equipped with an RS-232C interface
The V680-CH1D-PSI Hand-held Reader/Writer can be used with any RF Tag in the V680/V680S Series.
For details on Hand-held Reader/Writer and RF Tag models, refer to Section 6 Appendices.
24
When using a V680-D8KF@@, to use the V680-CH1D-PSI of production after October 2014.
RFID System
User's Manual
p.132, p.150
Page 27
Operation Flowchart
p.31 to p.34
p.54
p.54
p.132
p.55
Preparation
Test
Transmission
Connect the V680-CHUD to the host device.
When connecting for the first time, the USB driver must be installed.
Perform the communications test between the host device and
Hand-held Reader/Writer.
Perform the communications test between the RF Tag and
Hand-held Reader/Writer.
Check the ambient environment.
Operate the system using real commands.
Section 1
Product Overview
V680-CHUD
Section 1
Operation Flowchart
RFID System
User's Manual
25
Page 28
Section 1
p.46
p.54
p.54
p.132
p.55
p.49
Preparation
Test
Transmission
Communications preparation
Connect the V680-CH1D to the host device.
Perform the communications test between the host device and
Hand-held Reader/Writer.
Perform the communications test between the RF Tag and
Hand-held Reader/Writer.
Check the ambient environment.
Operate the system using real commands.
Set the communications parameters between the host device and
Hand-held Reader/Writer.
Operation Flowchart
Section 1
Product Overview
V680-CH1D
26
RFID System
User's Manual
Page 29
V680-CH1D-PSI
p.48
p.54
p.54
p.132
p.55
p.49
Preparation
Test
Transmission
Communications preparation
Connect the V680-CH1D-PSI to the host device.
Perform the communications test between the host device and
Hand-held Reader/Writer.
Perform the communications test between the RF Tag and
Hand-held Reader/Writer.
Check the ambient environment.
Operate the system using real commands.
Set the communications parameters between the host device and
Hand-held Reader/Writer.
Section 1
Product Overview
Section 1
Operation Flowchart
RFID System
User's Manual
27
Page 30
Section 1
Operation Flowchart
Section 1
Product Overview
MEMO
28
RFID System
User's Manual
Page 31
Section 2 Communications Preparations
V680-CHUD Communications Preparations 30
V680-CH1D Communications Preparations 45
V680-CH1D-PSI Communications Preparations 48
Setting the Hand-held Reader/Writer 49
Communications Test 53
Section 2
Communications Preparations
RFID System
User's Manual
29
Page 32
Section 2
Communications Preparations
V680-CHUD Communications Preparations
Connections
Connecting the Cable
Section 2
1. Connect the cable connector to the USB connector on the host
V680-CHUD Communications Preparations
device, making sure that the connector is oriented correctly
and not inserted at an angle.
Removing the Cable
1. Remove the cable.
Close the software application at the host device and then pull out the connector in a straight line, not at an angle.
If the connector is removed while the software is running at the host
device, operation may stop due to a software malfunction error.
Restart the software if operation becomes impossible.
30
RFID System
User's Manual
Page 33
Section 2
Communications Preparations
Installing the USB Driver (V680-CHUD)
When connecting the Hand-held Reader/Writer to the host device for the first time, the USB driver must
be installed at the host device.
Downloading the USB Driver
Download the USB Driver for the V680-CHUD from the web site.
For details, ask your OMRON sales representative.
Section 2
Installing the USB Driver
The V680-CHUD supports the Windows XP, Windows 7 or Windows 10 operating system. Install the
driver in the host personal computer using the following procedure.
Operation on other operating systems is not supported.
Windows XP
1. Turn ON the power to the personal computer and start Windows XP.
2. Connect the Hand-held Reader/Writer to the personal computer.
For details on connection methods, refer to Connections.
p.30
Wait for the following window to be displayed.
3. When the following dialog box is displayed, select the Install from a list or specific location (Advanced)
Option and click the Next Button.
V680-CHUD Communications Preparations
RFID System
User's Manual
31
Page 34
Section 2
Communications Preparations
4. Click the Browse Button when the Found New Hardware Wizard Dialog Box appears, select the folder
in which the downloaded file V680-CHUD_100.inf was saved, and click the Next button.
Section 2
V680-CHUD Communications Preparations
5. Click the Continue Anyway Button.
32
RFID System
User's Manual
Page 35
Communications Preparations
6. The USB Driver installation will begin.
7. When the following window is displayed, installation has been completed.
Section 2
Section 2
V680-CHUD Communications Preparations
8. Click the Finish Button.
RFID System
User's Manual
33
Page 36
Section 2
Communications Preparations
Checking Installation
Check that the driver is correctly installed.
1. Connect the Hand-held Reader/Writer to the personal computer.
Section 2
2. On the Start Menu, select Control Panel - System.
V680-CHUD Communications Preparations
3. Click the Device Manager Button in the Hardware Tab Page.
34
4. Select Ports (COM & LPT), and check that OMRON RFID USB COM is displayed.
The driver is correctly installed if this port is displayed.
Communications with the Hand-held Reader/Writer can be performed with the COM number displayed in parentheses after
OMRON RFID USB COM.
RFID System
User's Manual
Page 37
Windows 7
1. Turn ON the power to the personal computer and start Windows 7.
Section 2
Communications Preparations
2. Connect the ID Controller to the computer via USB.
Refer to Connections for information on the connection method.
p.30
3. Select Settings - Control Panel - System and Security from the Windows Start Menu.
4. Click the Device Manager Button.
Section 2
V680-CHUD Communications Preparations
RFID System
User's Manual
35
Page 38
Section 2
Communications Preparations
5. Right-click the Other devices - V680-CHUD and click the Properties.
Section 2
V680-CHUD Communications Preparations
6. Click the Update Driver Button.
7. Once the following dialog box has been displayed, click the Browse my computer for driver software
Button.
36
RFID System
User's Manual
Page 39
Section 2
Communications Preparations
8. Click the Browse Button and select the folder where the downloaded V680-CHUD_100_win7_@@.inf
is to be saved. Then click the Next Button.
9. Click the Install this driver software anyway Button.
Section 2
V680-CHUD Communications Preparations
The following dialog box will be displayed when the software installation has been completed.
10. Click the Close Button.
RFID System
User's Manual
37
Page 40
Section 2
Communications Preparations
Checking Installation
Use the following procedure to confirm that the driver has been correctly installed.
1. Turn ON the power to the personal computer and start Windows 7.
Section 2
2. Connect the ID Controller to the computer via USB.
V680-CHUD Communications Preparations
3. Select Settings - Control Panel - System and Security from the Windows Start Menu.
Refer to Connections for information on the connection method.
p.30
4. Click the Device Manager Button.
38
RFID System
User's Manual
Page 41
Communications Preparations
5. Right-click the Other devices - V680-CHUD and click the Properties.
6. Select Ports (COM & LPT), and check that OMRON RFID USB COM is displayed.
If the driver is correctly installed, the property window for the V680-CHUD will be displayed as follows:
Section 2
Section 2
V680-CHUD Communications Preparations
Communications with the ID Controller can be performed with the COM number displayed in parentheses after OMRON RFID
USB COM.
RFID System
User's Manual
39
Page 42
Section 2
Communications Preparations
Windows 10
1. Turn ON the power to the personal computer and start Windows 10.
Section 2
V680-CHUD Communications Preparations
2. Connect the ID Controller to the computer via USB.
3. Select Settings - Windows System - Control Panel - System and Security from the Windows Start
Menu.
Refer to Connections for information on the connection method.
p.30
4. Click the System Button.
40
RFID System
User's Manual
Page 43
Communications Preparations
5. Click the Device Manager Button.
6. Right-click the Ports - USB Serial Device (COM) and click the Update driver.
Section 2
Section 2
V680-CHUD Communications Preparations
7. Once the following dialog box has been displayed, click the Browse my computer for driver software
Button.
RFID System
User's Manual
41
Page 44
Section 2
Communications Preparations
8.
Click the
is to be saved. Then click the Next Button.
Section 2
V680-CHUD Communications Preparations
9. The USB Driver installation will begin.
Browse
Button and select the folder where the downloaded V680-CHUD_100_win10_@@.bat
The following dialog box will be displayed when the software installation has been completed.
10. Click the Close Button.
42
RFID System
User's Manual
Page 45
Communications Preparations
Checking Installation
Use the following procedure to confirm that the driver has been correctly installed.
Section 2
1. Turn ON the power to the personal computer and start Windows 10.
2. Connect the ID Controller to the computer via USB.
Refer to Connections for information on the connection method.
p.30
3. Select Settings - Windows System - Control Panel - System and Security from the Windows Start
Menu.
Section 2
V680-CHUD Communications Preparations
4. Click the System Button.
RFID System
User's Manual
43
Page 46
Section 2
Communications Preparations
5. Click the Device Manager Button.
Section 2
V680-CHUD Communications Preparations
6. Right-click the Ports - OMRON RFID USB (COM), and check the Update driver.
If the driver is correctly installed, the property window for the V680-CHUD will be displayed as follows:
Communications with the ID Controller can be performed with the COM number displayed in parentheses after OMRON RFID
USB COM.
44
RFID System
User's Manual
Page 47
Communications Preparations
Connector from Mating Side
51
96
V680-CH1D Communications Preparations
Pin Arrangement of the Host Device Interface Connector
V680-CH1D
Section 2
Pin No.
1 --- ---
2 Receive data RD
3 Send data SD
4 --- --- ---
5 Signal ground SG ---
6 (Reserved) --- ---
7 Request send RS
8 Enable send CS
9 --- --- ---
Signal
(See note.)
Code
(See note.)
Signal direction
Hand-held Reader/Writer to host
device
Host device to Hand-held Reader/
Writer
Loops inside connector
Note: The names of signals at the host device are abbreviated with codes.
Note: For conversion to a 25-pin connector, the SGC-X9P/25P-2 manufactured by Sunhayato, or an
equivalent, is recommended.
Section 2
V680-CH1D Communications Preparations
RFID System
User's Manual
45
Page 48
Section 2
SGC-X9P25P-2
V600-A22
V680-CH1D Communications Preparations
Section 2
Communications Preparations
Connection with the Host Device
Use the following procedure to connect the V680-CH1D to the host device.
1. Connect the V680-CH1D to the RS-232C interface of the host device.
• When connecting to an IBM PC/AT or compatible:
• When connecting to a PC9801-series computer (D-Sub 25-pin connector):
To convert from a 9-pin connector to a 25-pin connector, use an SGC-X9P25P-2 conversion connec-
tor manufactured by Sunhayato, or an equivalent product.
2. Connect the V600-A22 AC Adaptor to the V680-CH1D.
46
3. Plug the V600-A22 AC Adaptor into a 100- to 120-VAC power outlet.
RFID System
User's Manual
• Do not use any AC adaptor other than the specified one (V600-A22).
• Using any AC adaptor other than the specified one may cause a malfunction, damage, or fire in the V600-CH1D.
• Some host devices require a conversion connector.
Page 49
Section 2
V680-CH1D
Pin No. Signal
1---
2RD
3SD
4---
5SG
6---
7RS
8CS
9---
CQM1/CJ1/CS1
Pin No. Signal
1---
2SD
3RD
4RS
5CS
6---
7---
8---
9SG
Loop
Communications Preparations
When connecting to a CQM1, CJ1, CS1, etc.
Prepare a connection cable as shown in the connection examples below.
Note: Because both the V680-CH1D interface connector and the interface connector of the CQM1,
CJ1, and CS1 are sockets, a conversion connector is necessary to connect them. Also, the pin
arrangement of the CQM1, CJ1, and CS1 interface connector is different from the RS-232C pin
arrangement of a personal computer.
Section 2
V680-CH1D Communications Preparations
RFID System
User's Manual
47
Page 50
Section 2
Connector from Mating Side
51
96
Communications Preparations
V680-CH1D-PSI Communications Preparations
Pin Arrangement of the Host Device Interface Connector
V680-CH1D-PSI
Section 2
V680-CH1D-PSI Communications Preparations
Pin No.
1 --- ---
2 Receive data RD
3 Send data SD
4 --- --- ---
5 Signal ground SG ---
6 Reserved --- ---
7 Request send RS
8 Enable send CS
95 VDC ---
Signal
(See note.)
Code
(See note.)
Note: The names of signals at the host device are abbreviated with codes.
Connection with the Host Device
Use the following procedure to connect the V680-CH1D-PSI to the host device.
Signal direction
Hand-held Reader/Writer to host
device
Host device to Hand-held Reader/
Writer
Loops inside connector
Host device to Hand-held Reader/
Writer
1. Connect the V680-CH1D-PSI to the RS-232C interface of the host device.
RFID System
48
User's Manual
Page 51
Setting the Hand-held Reader/Writer
Settings
The following settings are used to operate the Hand-held Reader/Writer.
• Serial communications parameters (baud rate, transmission code, parity check, stop bits)
• Basic function settings (Auto Command OFF)
These settings can be changed by sending a setting command from the host device. To operate the
Hand-held Reader/Writer with the new setting, the power must be turned OFF then ON again, or the
ABORT command must be used.
Serial Communications Parameters
The following settings are related to serial communications. Use the COMMUNICATIONS CONDITIONS SETTING (TR) command.
Section 2
Communications Preparations
Section 2
Setting the Hand-held Reader/Writer
Item Contents
Baud rate (bps) 2,400, 4,800, 9,600*, 19,200, 38,400
Transmission code 7-unit ASCII 7* or 8-unit JIS 8
Parity check Even parity*/odd parity/none
Stop bits 2*/1
Note: Items marked by an asterisk (*) are set as the default when shipped from the factory.
Basic Function Settings
The Auto Command OFF function can be set. Use the BASIC FUNCTIONS SETTING (FN) command.
Item Contents
Auto Command OFF function Yes (1 minute)*, No
Note: Items marked by an asterisk (*) are set as the default when shipped from the factory.
Reading the Settings
Use the SET INFORMATION READ (UL) command to read the settings of the Hand-held Reader/
Writer. The information read by the SET INFORMATION READ command is set in the backup memory
of the Hand-held Reader/Writer. For this reason, care must be taken when the power is first turned ON
after the settings have been changed because the operational settings of the Hand-held Reader/Writer
will be different.
RFID System
User's Manual
49
Page 52
Section 2
External input
1 2 4 … End code
No additional data
Inter-character monitoring time
Response
3
Error code: 14
Host device to Hand-held
Reader/Writer
Hand-held Reader/Writer
to host device
External input
Command
Response delay time
Response
Host device to
Hand-held
Reader/Writer
Hand-held
Reader/Writer to host
Internal
processing time
Setting the Hand-held Reader/Writer
Section 2
Communications Preparations
Setting the Operating Parameters
To optimize Hand-held Reader/Writer performance and reliability, operating parameters can be set to
match the application. The following parameters can be set: the inter-character monitoring time,
response delay time, auto command cancel time, write protection setting, and protocol.
Usually there will be no problem if the default settings are used, but the system can be optimized by
setting following parameters.
These parameters are stored in the internal memory of the Hand-held Reader/Writer and are saved
even if the power is turned OFF. When the internal settings are changed with the PARAMETER SET
command (SP), it is not necessary to reset the Hand-held Reader/Writer. The changes will be effective
immediately after the PARAMETER SET command is executed.
The PARAMETER SET command is also used to read the parameter settings. For details on the PARAMETER SET
command, refer to PARAMETER SET (SP) in Section 3.
p.78, p.116
Inter-character Monitoring Time
The Hand-held Reader/Writer recognizes a command when it receives the end code of a command
string that is sent from the host device. However, if for some reason the command is only partially
received, the Hand-held Reader/Writer will monitor for a fixed period of time after the last character in
the command string is received. If the complete command string is not received after the fixed period of
time has expired, a format error (end code: 14) will be returned.
Setting range
0 to 9,999 (ms)
Note: Default value: 99 (ms)
Response Delay Time
The start of returning a response can be changed by setting the response delay time.
The actual time from when sending the command has been completed until returning the response is started is the
Hand-held Reader/Writer's internal processing time (minimum: 0 ms) plus the response delay time (a set value).
Setting range
0 to 99 (ms)
Note: Default value: 20 (ms)
50
RFID System
User's Manual
Page 53
Section 2
External input
Command
Auto command
cancel time
Response
Error code: 72
Host device to
Hand-held
Reader/Writer
Hand-held
Reader/Writer to host
device
Communications Preparations
Auto Command Cancel Time
The auto command cancel time is used to set the amount of time from after an auto command is sent
until the command processing will be aborted.
After waiting for the tag for a fixed period of time, an " RF Tag non-existent" error (error code: 72) will be
returned to the host device.
Setting range
0 to 99 (s)
Note: Default value: 60 (s)
Write Protection Enable Setting
The write protection enable setting can be used to enable or disable write protection.
00: Write protection function disabled
01: Write protection function enabled default value
Section 2
Setting the Hand-held Reader/Writer
For details on write protection settings, refer to Write Protection Function in Section 4.
p.121
Protocol Switch
The protocol switch is used to set whether the Hand-held Reader/Writer will use the V680 command
format or the V600 command format.
0: V600 commands (default value)
1: V680 commands
For details, refer to Section 3 Commands.
p.55
Tag Memory Setting
The CA1D Mode in the Tag memory setting is used only when using the V680-CA1D/-CA2D.
If you are using the V680-CA1D/-CA2D, set the Tag memory setting to CA1D Mode.
If you are not using the V680-CA1D/-CA2D, set the Tag memory setting to Standard Mode.
0: Standard Mode (default value)
1: CA1D Mode
Refer to Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT) in Section 1 Product Overview for information on using Using Heat-resistive Tags (V680-D1KP58HTN or V680-D1KP58HT).
p.14
CA1D Mode can be used with version 1.1 or newer.
Use the VERSION READ (VS) command to read the product version. For details on the VERSION READ (VS) command, refer to VERSION READ (VS) under V680 Commands or V600 Commands in Section 3 Commands.
p.80, p.111
RFID System
User's Manual
51
Page 54
Section 2
Setting the Hand-held Reader/Writer
Section 2
Communications Preparations
Initializing the Settings
A setting command is used to set the Hand-held Reader/Writer but if the communications parameters
are not known or if the setting contents are damaged, it is possible that communications will no longer
be possible with the host device. If this occurs, press both the reset button and the activate switch
when turning ON the power. This will return all settings to the defaults set when the Hand-held Reader/
Writer was shipped from the factory, allowing communications with the host device again.
Reset Procedure
1. Turn ON the power while pressing the reset button.
2. Keep the reset button depressed for two seconds or more. The green operation indicator will start
flashing.
3. With the green operation indicator flashing, remove your finger from the reset button and press the acti-
vate switch.
4. When the activate switch is pressed, the operation indicator will stop flashing green. This indicates that
all of the settings have been initialized.
Note: If the activate switch is not pressed within 30 seconds from the time that the operation indicator
starts flashing green, the settings will not be initialized.
The V680-CHUD does not have a reset button. To reset the V680-CHUD, shut down the software on the host device,
and disconnect and reconnect the connector.
52
RFID System
User's Manual
Page 55
Communications Test
Connect the Hand-held Reader/Writer
to the host device.
Visually check the indicator display.
Execute the online test from the host
device.
Test run the system.
Finish
Check communications between the host device and Hand-held
Reader/Writer using the test command.
Check operation using real commands.
Test Run Procedure
Section 2
Communications Preparations
Section 2
Communications Test
RFID System
User's Manual
53
Page 56
Section 2
Section 2
Communications Preparations
Communications Test between Host Device and Hand-held
Reader/Writer
Use the test command to test communications between the Hand-held Reader/Writer and host device.
Before performing communications with the RF Tag, check the Hand-held Reader/Writer connections
and communications.
1. Send the test command from the host device.
Communications Test
For detail on the test command, refer to TEST (TS).
p.79, p.110
2. If communications is normal, the Hand-held Reader/Writer will return the received data.
If a response is not returned, refer to Troubleshooting.
p.127
Communications Test between RF Tags and Hand-held Reader/
Writer
Use actual commands to test communications between the RF Tags and the Hand-held Reader/Writer.
1. Send the READ command (RD) with an SA communications specification from the host device.
For details on the READ command, refer to READ (RD).
If using V600 commands, refer to the Auto Read command (AR).
, p.92
p.65
The Hand-held Reader/Writer will communicate with the RF Tag and the operation indicator will flash green.
2. Move the antenna of the Hand-held Reader/Writer close to the RF Tag.
The Hand-held Reader/Writer will read the data in the RF Tag when the Hand-held Reader/Writer moves within the interrogation
zone. As a result, the operation indicator will light green and then turn OFF.
54
RFID System
User's Manual
Page 57
Section 3 Commands
Communicating with RF Tags 56
V600 and V680 Command Comparison 57
V680 Commands 59
V600 Commands 83
Section 3
Commands
RFID System
User's Manual
55
Page 58
Section 3
Address (hex)
0010
0011
0012
0013
0014
“O”
“M”
“R”
“O”
“N”
4
5
4
4
4
D
2
F
F
E
1 byte
• RF Tag
WT 1 0A00 ROOM1 CRN
WT 1 0A00 ROOM1 CRNST
Command code
Start address
Write data
ASCII
setting
Processing
area number
setting
Terminator
Command code
Start address
Write data
ASCII
setting
Processing
area number
setting
Terminator
Communications
specification
• Examples for Specifying ASCII Text
V600 Commands
V680 Commands
0010
0011
9
1
9
6
Address (hex)
1 byte
• RF Tag
WT 1 0H1 00 9619 CR
WT 1 0H1 00 9619 CRST
Start address Write data Terminator
Command
code
Hexa-
decimal
code
setting
Process-
ing area
number
setting
Start address Write data Terminator
Command
code
Hexa-
decimal
code
setting
Processing area
number
setting
• Examples for Specifying Hexadecimal
V600 Commands
V680 Commands
Communicating with RF Tags
Section 3
Commands
Communicating with RF Tags
Specifying Data Code
Whether the read or write data is treated as an ASCII (or JIS 8) or hexadecimal is specified in each
command.
ASCII (JIS 8 Code)
• One character of ASCII or JIS 8 code data occupies 1 byte
(1 address) of the RF Tag memory.
Hexadecimal
• One character is treated as a hexadecimal number. Therefore,
only numerals 0 through 9 and A to F can be accepted.
• Two characters of data occupy 1 byte (1 address) of the RF Tag
memory. Therefore, specify data in 2-character units (in even
numbers) when using a WRITE command. If an odd number of
characters is specified by mistake, an error will occur.
56
RFID System
User's Manual
Page 59
Section 3
Commands
V600 and V680 Command Comparison
The V680-series Hand-held Reader/Writer can use commands in either the V600 command format or the
V680 command format. By using V600 commands, production lines that previously used a V600-series
Reader/Writer can use the same application with the V680-series Hand-held Reader/Writer. New functionality
can be used by using V680 commands.
The PARAMETER SET (SP) command is used to switch between the two command formats. V680 and V600
commands are handled as shown in the following tables.
Communications Commands
V680 commands V600 commands
Command name
READ
WRITE
DATA FILL
DATA CHECK MD ST C/K DATA CHECK MD C/K
OVERWRITE COUNT CONTROL MD ST S/L OVERWRITE COUNT CONTROL MD S
CALCULATION WRITE --- --- --- CALCULATION WRITE CW A/S
ID CODE READ ID ST H ID CODE READ ID H
READ WITH ERROR CORRECTION QR ST A/H --- --- ---
WRITE WITH ERROR CORRECTION QW ST A/H --- --- ---
Command
code
RD
WT
DF
Communications
specification
ST A/H READ RD A/H
SA A/H AUTO READ AR A/H
BT A/H BUTTON READ BR A/H
BA A/H BUTTON AUTO READ UR A/H
ST A/H WRITE WT A/H
SA A/H AUTO WRITE AW A/H
BT A/H BUTTON WRITE BW A/H
BA A/H BUTTON AUTO WRITE UW A/H
ST A/H DATA FILL FL A/H
SA A/H AUTO DATA FILL AF A/H
Data
specifica-
tion
Command name
Command
code
specifica-
Data
tion
Section 3
V600 and V680 Command Comparison
Communications Subcommands
V680 commands V600 commands
Command name
COMMAND PROCESSING TERMINATE AA --- COMMAND PROCESSING TERMINATE AA ---
ABORT (reset) XZ --- ABORT (reset) XZ ---
Command
code
Data
specifi-
cation
Command name
Command
code
specifi-
Controller Control Commands
V680 commands V600 commands
Command name
COMMUNICATIONS CONDITIONS SETTING TR COMMUNICATIONS CONDITIONS SETTING TR
BASIC FUNCTIONS SETTING FN BASIC FUNCTIONS SETTING FN
SET INFORMATION READ UL SET INFORMATION READ UL
PARAMETER SET SP PARAMETER SET SP
Command
code
Command name
Command
code
RFID System
User's Manual
Data
cation
57
Page 60
Section 3
V600 and V680 Command Comparison
Section 3
Commands
Host Commands
V680 commands V600 commands
Com-
Command name
TEST TS TEST TS
VERSION READ VS VERSION READ VS
mand
code
Command name
Command
code
58
RFID System
User's Manual
Page 61
V680 Commands
A
C
B
D
Communications
with RF Tag
Response
Command
Host devic
e
Hand-held Read
er/Writer
RF Tag
Communications with the RF Tag
There are four types of communications specifications for communicating with RF Tags using the
Hand-held Reader/Writer.
Name
Single trigger ST
Single auto SA
Button trigger BT
Button auto BA
Depending on the command, there are limitations on the communications specification that can be used.
For communication specifications that can be used, refer to V600 and V680 Command Comparison in this chapter.
Communications
specification
p.57
Section 3
Commands
Description
When the Hand-held Reader/Writer receives a command, it communicates with an RF Tag and then
returns a response.
When the Hand-held Reader/Writer receives a command, it waits to detect an RF Tag in the
Antenna's communication area. When the Hand-held Reader/Writer detects an RF Tag, it communicates with the RF Tag and then returns a response.
When the Hand-held Reader/Writer receives a command, it communicates with the RF Tag when
the activate switch is pressed, and then returns a response.
When the Hand-held Reader/Writer receives a command, it waits to detect an RF Tag in the
Antenna's communication area after the activate switch is pressed. When the Hand-held Reader/
Writer detects an RF Tag, it communicates with the RF Tag and then returns a response.
Section 3
V680 Commands
Single Trigger (ST) Communications Specifications
After the antenna end of the Hand-held Reader/Writer has been moved close to an RF Tag, a single
trigger (ST) communications specification is sent from the host device to communicate with the RF
Tag.
1. Move the antenna end of the Hand-held Reader/Writer close to the RF Tag.
2. Send the command from the host device to the Hand-held Reader/Writer.
3. The Hand-held Reader/Writer will communicate with the RF Tag.
4. A response will be returned from the Hand-held Reader/Writer to the host device.
If communications end normally, the operation indicator (LED) will light green and then turn OFF.
If an RF Tag is not detected within the Hand-held Reader/Writer's communication area when the command is sent from the host device, an RF Tag Non-existent Error will occur. At this time, the operation
indicator will flash red.
RFID System
User's Manual
59
Page 62
Section 3
C
A
D
Communications
with RF Tag
Response
Command
Host
device
RF T
ag
Hand-held Reader/Writer
B
V680 Commands
Section 3
Commands
Single Auto (SA) Communications Specifications
A single auto (SA) communications specification is used to communicate with an RF Tag when the
antenna end of the Hand-held Reader/Writer is moved close to an RF Tag after the command has
been sent from the host device.
1. Send the command from the host device to the Hand-held Reader/Writer.
2. The Hand-held Reader/Writer will enter the communications stand-by state with the RF Tag, and the
operation indicator (LED) will flash green.
If an RF Tag is not detected within one minute of sending the command, a timeout will occur and an RF Tag Non-existent Error will occur. As a result, the operation indicator will flash red.
3. Communications with the RF Tag will be performed when the antenna end of the Hand-held Reader/
Writer is moved close to the RF Tag.
4. A response is returned from the Hand-held Reader/Writer to the host device.
If communications end normally, the operation indicator (LED) will light green and then turn OFF.
60
RFID System
User's Manual
Page 63
Section 3
D
A
E
Communications
with RF Tag
Response
Command
C
Press
Hand-held Reader/Writer
Host device RF Tag
Commands
Button Trigger (BT) Communications Specifications
A button trigger (BT) communications specification is used to communicate with an RF Tag when the
antenna is moved close to an RF Tag and the activate switch is pressed after the command has been
sent from the host device.
Section 3
V680 Commands
1. Send the command from the host device to the Hand-held Reader/Writer. The operation indicator will
light green.
2. Move the antenna end of the Hand-held Reader/Writer close to the RF Tag.
B
3. Press the Hand-held Reader/Writer activate switch.
4. The Hand-held Reader/Writer will communicate with the RF Tag.
5. A response is returned to the host device from the Hand-held Reader/Writer.
If communications end normally, the operation indicator (LED) will light green and then turn OFF.
If an RF Tag is not detected within the Hand-held Reader/Writer's communication area when the activate switch is pressed, an RF Tag Non-existent Error will occur.
At this time, the operation indicator will flash red.
RFID System
User's Manual
61
Page 64
Section 3
D
A
E
Communications
with RF Tag
Response
Command
B
Press
Hand-held Reader/Writer
Hos
t device
RF T
ag
B
V680 Commands
Section 3
Commands
Button Auto (BA) Communications Specifications
A button auto (BA) communication specification is used to execute auto commands after the command
is sent from the host device and the activate switch of the Hand-held Reader/Writer is pressed.
1. Send the command from the host device to the Hand-held Reader/Writer. The operation indicator will
light green.
2. Press the Hand-held Reader/Writer activate switch.
3. The Hand-held Reader/Writer will enter the communication stand-by state with the RF Tag, and the
operation indicator (LED) will flash green.
If the RF Tag is not detected within one minute of sending the command, a timeout will occur and an RF Tag Non-existent Error will occur. As a result, the operation indicator will flash red.
4. Communications with the RF Tag will be performed when the antenna end of the Hand-held Reader/
Writer is moved close to an RF Tag.
5. A response is returned from the Hand-held Reader/Writer to the host device.
If communications end normally, the operation indicator (LED) will light green and then turn OFF.
62
RFID System
User's Manual
Page 65
Section 3
××
×
2
2
CR
×
…×n×
Communications
specification
××
2
1 frame (maximum frame length: 2,114 characters)
Command
code
Data Terminator
××
×
2
2
CR
×
…×n×
××210
11
Command
code
Data
Terminator
End code
Fixed
value
Resend
flag
Commands
Command and Response Formats
The formats of commands sent from the host device to the Hand-held Reader/Writer and responses
returned from the Hand-held Reader/Writer to the host device are described below.
The command and response both consist of a single frame. Each frame (including the terminator)
consists of up to 2,114 characters. (When specifying hexadecimal for using the WRITE command, the
maximum is 4,218 characters.)
Command Frame
Name Description
Command code Contains the two-character code (see page 88) that indicates command.
Communications specification Contains the two-character code that indicates the method used to communicate with the RF Tag (see page
59.)
Data Contains the parameters or write data used to execute the command.
• Data settings, processing specifications
• Start address
• Write data, number of bytes to be written
• Number of read bytes
• Number of check block bytes, decrement count
• Specified data
• Message data
• Parameter data
• Baud rate, data length, parity, and stop bit specifications
• Auto command OFF specification
• Settings for the TR command, settings for the FN command, and system setting data
Terminator Indicates end of command/response.
Section 3
V680 Commands
Response Frame
Name Description
End code Indicates the execution result for the command.
For information on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
Data The data for the response.
• Read data
•UID
• Processing terminate timing
• Parameter data
• Message data
• Model information
Note: Other than the above items, the same data as the command frame is returned in the response.
RFID System
User's Manual
63
Page 66
Section 3
Commands
Command List
Commands can be classified into four major types.
Communications Commands
The following commands are used for communications with the RF Tag.
Section 3
V680 Commands
Command
code
RD READ A/H Reads memory data from the RF Tag. p.65
WT WRITE A/H Writes data to the memory of the RF Tag. p.66
DF DATA FILL A/H
MD
ID ID CODE READ H Reads the UID in the RF Tag. p.71
QR
QW
Command name
DATA CHECK C/K Calculates or compares memory check codes in the RF Tag. p.70
OVERWRITE COUNT CONTROL
READ WITH ERROR CORRECTION
WRITE WITH ERROR CORRECTION
Processing
specification
S/L
A/H
A/H
Writes the specified data to the specified number of bytes beginning from the specified start address.
Controls the number of overwrites for RF Tags.
Reads memory data from the RF Tag.
Verifies data reliability using the check code.
Writes data to the memory of the RF Tag.
Writes a check code to enable verifying data reliability.
Communications Subcommands
The following commands are used to cancel or reset command execution.
Command
code
AA
XZ ABORT - Resets the Hand-held Reader/Writer. p.74
Command name
COMMAND PROCESSING
TERMINATE
Processing spec-
ification
-
Forcedly ends communications with the RF Tag.
Function Page
p.67
p.69
p.72
p.73
Function Page
p.74
Controller Control Commands
These commands are used to reset the Controller or set serial communications.
Command
code
TR COMMUNICATIONS CONDITIONS SETTING Sets communications parameters for communications with the host device. p.75
FN BASIC FUNCTIONS SETTING Sets the Auto Command OFF function. p.76
UL SET INFORMATION READ Reads the settings data for the Hand-held Reader/Writer. p.77
SP PARAMETER SET Sets, reads, or initializes Hand-held Reader/Writer parameters. p.78
Command name Function Page
Host Commands
These commands are used to test communications between the Hand-held Reader/Writer and host
device.
Command
code
TS TEST Confirms the communications status between the Hand-held Reader/Writer and
VS VERSION READ Reads the Hand-held Reader/Writer's software model, software version, and
Command name Function Page
host device. The data sent from the host device is returned as is.
software creation date.
p.79
p.80
64
RFID System
User's Manual
Page 67
Commands
Command
RD
1
2
2
CR
A/H
××4×
××
2
11
×××××
4
Command
code
Data
setting
Number of bytes
to read
Terminator
Read area
start address
Communica-
tions
specification
Fixed
value
Response
RD
0
2
2
CR
1
00
2
11
×××…×
n
TerminatorRead data
End code
Command
code
Fixed
value
Resend
flag
Communications Commands
Details of communications commands used to communicate with the RF Tag are provided here.
READ (RD)
This command reads up to 2 Kbytes of data from the RF Tag.
Section 3
Section 3
Communications specification
Specifies the method for communicating with the RF Tag.
Refer to Communications with the RF Tag for details on the communications specification.
p.59
Data setting Sets the code format used to send responses for read data.
A: ASCII
H: Hexadecimal
Fixed value Always 1.
Read area start address Specifies the start address of the area to be read from the RF Tag in 4-digit hexadecimal.
Setting range: 0000 to FFFF hex
Number of bytes to read Specifies the number of bytes to be read from the RF Tag in 4-digit hexadecimal.
The maximum number of bytes that can be read at one time is 2 Kbytes, as follows:
Setting range: 0001 to 0800 hex
•ASCII: 2,048 bytes (2,048 characters)
•Hexadecimal: 2,048 bytes (4,096 characters)
V680 Commands
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
Read data Specifies the data read from the RF Tag.
The characters in ASCII indicate the number of read bytes and the characters in hexadecimal indicate the number of read bytes x 2.
RFID System
User's Manual
65
Page 68
Section 3
Command
WT
1
2
2
CR
A/H
×…n×
××
2
11
×××××
4
×
Command
code
Data
setting
Fixed
value
Write data
Write area
start address
Terminator
Communica-
tions
specification
Response
WT
0
2
2
CR
1
00
2
11
Command
code
Fixed
value
Terminator
Resend
flag
End code
Commands
WRITE (WT)
The WRITE command writes up to 2 Kbytes of data to the memory of an RF Tag.
Section 3
V680 Commands
Communications specification
Specifies the method for communicating with the RF Tag.
Refer to Communications with the RF Tag for details on the communications specification.
p.59
Data setting Sets the code format used to send responses for read data.
A: ASCII
H: Hexadecimal
Fixed value Always 1.
Write area start address Specifies the start address of the area in the RF Tag to be written to in 4-digit hexadecimal.
Setting range: 0000 to FFFF hex
Write data Specifies the write data to the RF Tag.
Up to 2 Kbytes of data can be written with one command.
ASCII: 2,048 bytes (2,048 characters)
Hexadecimal: 2,048 bytes (4,096 characters)
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
66
RFID System
User's Manual
Fixed value Always 1.
Resend flag Always 0.
For details on end codes, refer to End Codes.
p.82
Page 69
Section 3
Command
DF
1
2
2
CR
A/H
××4×
××
2
11
×××××
4
××
2 or 4
××
Number of
write bytes
Command
code
Data
setting
Fixed
value
Write data
Write area
start address
Terminator
Communica-
tions
specification
Response
DF
0
2
2
CR
1
00
2
11
Command
code
Fixed
value
Terminator
Resend
flag
End code
Commands
DATA FILL (DF)
The DATA FILL command writes the designated data for the specified number of bytes beginning from
the specified start address.
This command can be used to write data regardless of the write protection setting. Confirm that there is no important
data in the area being written before executing this command.
Section 3
Communications specification
Specifies the method for communicating with the RF Tag.
Refer to Communications with the RF Tag for details on the communications specification.
p.59
Data setting Sets the code format used to send responses for read data.
A: ASCII
H: Hexadecimal
Fixed value Always 1.
Write area start address Specifies the start address of the area in the RF Tag to be written to in 4-digit hexadecimal.
Setting range: 0000 to FFFF hex
Number of write bytes Specifies the number of bytes of data to write to the RF Tag in 4-digit hexadecimal.
Setting range: 0000 to FFFF hex
(0000: The RF Tag will be written up to the end address.)
Write data Specifies the write data to the RF Tag.
ASCII: 2 digits specified.
Hexadecimal: 4 digits specified.
V680 Commands
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
RFID System
User's Manual
67
Page 70
Section 3
Command
DF
1
2
2
CR
H
0046
ST
2
11
00030
4
10410
Number of
write bytes
Command
code
Data
setting
Fixed
value
Write data
Write area
start address
Terminator
Communica-
tions
specification
Response
DF
0
2
2
CR
1
00
2
11
Command
code
Fixed
value
Terminator
Resend
flag
End code
Address (hex)
002F
0030
0031
0032
0033
0034
0035
0036
3
3
2
3
3
0
1
F
2
3
3
3
3
4
5
6
Address (hex)
002F
0030
0031
0032
0033
0034
0035
0036
0
0
2
0
0
1
1
F
1
1
0
0
3
1
1
6
Before Writing
Before Writing
V680 Commands
Section 3
Commands
Example
This examples shows how to write 00101 hex to the memory area with addresses 0030 to 0006 (hex)
for an RF Tag in which the same data and address is written. The communications specification is ST.
68
RFID System
User's Manual
Page 71
Section 3
Command
MD
1
2
2
CR
S/L
××
2
××
2
11
××××
4
Command
code
Fixed
value
Terminator
Communica-
tions
specification
Area start address
Decrement
count
Pro-
cessing
specifi-
cation
Response
MD
0
2
2
CR
1
00
2
11
Command
code
Fixed
value
Terminator
Resend
flag
End code
Commands
OVERWRITE COUNT CONTROL (MD S/L)
The OVERWRITE COUNT CONTROL command is used to manage overwrite counts for EEPROM RF
Tags. The specified overwrite count control area data is updated to enable determining when the
EEPROM's write life has expired.
Section 3
Communications specification
Specifies the method for communicating with the RF Tag.
For details on communications specifications, refer to Communications with the RF Tag.
p.59
Processing specification Specifies the check process.
S: Subtraction (Overwrite control count can be set by user. 16,700,000 writes max.) See note.
L: Addition (Overwrite control count fixed at 100,000 writes.)
Fixed value Always 1.
Area start address Specifies the start address of the overwrite count control area in 4-digit hexadecimal.
Setting range: 0000 to FFFD hex
Decrement count Specifies the number of refresh operations in 2-digit hexadecimal.
Setting range: 00 to FF hex (00
Performs overwrite count check only.)
For details, refer to RF Tag Service Life Detection.
p.123
Note: The write life for EEPROM RF Tags is 100,000 at 25°C.
V680 Commands
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
For details on OVERWRITE COUNT CONTROL, refer to RF Tag Service Life Detection.
p.123
RFID System
User's Manual
69
Page 72
Section 3
Command
MD
1
2
2
CR
C/K
××
2
××
2
11
××××
4
Check block
start address
Terminator
Number of check
block bytes
Command
code
Communi-
cations
specification
Fixed
value
Pro-
cessing
specifi-
cation
Response
MD
0
2
2
CR
1
00
2
11
Command
code
Terminator
End code
Fixed
value
Resend
flag
Commands
DATA CHECK (MD C/K)
This command writes or compares the CRC code using the specified check block unit. The CRC code
is calculated from the generated polynomial expression X
16
+ X12 + X5 + 1.
Section 3
V680 Commands
Communications specification
Specifies the method for communicating with the RF Tag.
For details on communications specifications, refer to Communications with the RF Tag.
p.59
Process setting Specifies the check process.
K: Check code calculation
C: Check code comparison
Fixed value Always 1.
Check block start
address
Number of check block
bytes
Specifies the start address of the check block in 4-digit hexadecimal.
Setting range: 0000 to 1FFD hex
Specifies the number of bytes in the check block in 2-digit hexadecimal.
Setting range: 00h, 03 to FF hex (00 = 256 bytes)
The number of check block bytes is the check code calculation area + 2 bytes.
For details, refer to Memory Check Function in RF Tag.
p.125
70
RFID System
User's Manual
End code Indicates the execution result for the command.
An end code of 00 indicates normal completion.
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
For details on the memory check, refer to Memory Check Function in RF Tag.
p.125
Page 73
ID CODE READ (ID)
Command
ID
1
2
2
CR
H
××
2
11
Command
code
Data
setting
Terminator
Communica-
tions
specification
Fixed
value
Response
ID
0
2
2
CR
1
00
2
11
×××…×
0 or 16
UID
TerminatorEnd code
Command
code
Fixed
value
Resend
flag
Reads the ID code from the RF Tag.
Section 3
Commands
Communications specification
Specifies the method for communicating with the RF Tag.
For details on communications specifications, refer to Communications with the RF Tag.
p.59
Data setting Always H.
Fixed value Always 1.
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
UID The UID is an ID that uniquely identifies an RF Tag. (Unique Identifier)
Note: A ID code will not be attached if an error occurs.
Section 3
V680 Commands
The ID READ command is used to write the ID code to the RF Tag's memory, and therefore will be affected by
the ambient temperature. Be careful when using the RF Tag in environments with high ambient temperatures.
RFID System
User's Manual
71
Page 74
Section 3
Command
QR
1
2
2
CR
A/H
××4×
××
2
11
×××××
4
Command
code
Data
setting
Number of bytes
to read
Terminator
Read area
start address
Communica-
tions
specification
Fixed
value
Response
QR
0
2
2
CR
1
00
2
11
×××…×
n
TerminatorRead data
End code
Command
code
Fixed
value
Resend
flag
Section 3
Commands
READ WITH ERROR CORRECTION (QR)
Reads the data in the area written by the WRITE WITH ERROR CORRECTION (QW) command from
the RF Tag. Be sure to read data from the same area written by the WRITE WITH ERROR CORRECTION (QW) command.
Communications specification
V680 Commands
Specifies the method for communicating with the RF Tag.
For details on communications specifications, refer to Communications with the RF Tag.
p.59
Data setting Sets the code format used to send responses for read data.
A: ASCII
H: Hexadecimal
Fixed value Always 1.
Read area start address Specifies the start address of the area to be read from the RF Tag in 4-digit hexadecimal.
Setting range: 0000 to FFFA hex
Number of bytes to read Specifies the number of bytes to be read from the RF Tag in 4-digit hexadecimal. The maximum
number of bytes that can be read at one time is 510 bytes, as follows:
Setting range: 0001 to 01FE hex
• ASCII: 510 bytes (510 characters)
• Hexadecimal: 510 bytes (1,020 characters)
72
RFID System
User's Manual
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
Read data Specifies the data read from the RF Tag.
The characters in ASCII indicate the number of read bytes and the characters in hexadecimal indicate the number of read bytes x 2.
Page 75
Section 3
Command
QW
1
2
2
CR
A/H
×…n×
××
2
11
×××××
4
×
Command
code
Data
setting
Fixed
value
Write data
Write area
start address
Terminator
Communica-
tions
specification
Response
QW
0
2
2
CR
1
00
2
11
Command
code
Fixed
value
Terminator
Resend
flag
End code
Commands
WRITE WITH ERROR CORRECTION (QW)
The WRITE WITH ERROR CORRECTION (QW) command writes data to the RF Tag. The command
also writes the RF Tag memory check and error correction codes as 5 bytes of write data. Do not
change this code, it is required by the READ WITH ERROR CORRECTION (QR) command.
Section 3
Communications specification
Specifies the method for communicating with the RF Tag.
For details on communications specifications, refer to Communications with the RF Tag.
p.59
Data setting Sets the code format used to send responses for write data.
A: ASCII
H: Hexadecimal
Fixed value Always 1.
Write area start address Specifies the start address of the area in the RF Tag to be written to in 4-digit hexadecimal.
Setting range: 0000 to FFFA hex
Write data Specifies the write data to the RF Tag.
The maximum number of bytes that can be read at one time is 510 bytes, as follows:
ASCII: 510 bytes (510 characters)
Hexadecimal: 510 bytes (1,020 characters)
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
V680 Commands
Fixed value Always 1.
Resend flag Always 0.
For details on end codes, refer to End Codes.
p.82
RFID System
User's Manual
73
Page 76
Section 3
Command
AA
1
2
2
CR
0
11
Command
code
Terminator
Fixed
value
Pro-
cessing
specifi-
cation
Response
AA
0
2
2
CR
1
00
2
11
0×
2
Command
code
Terminator
End code
Fixed
value
Resend
flag
Processing
terminate
timing
Command
XZ
2
2
CR
Command
code
Terminator
Response
Section 3
Commands
Communications Subcommands
Communications subcommands are used together with communications commands. Communications
with the RF Tag cannot be performed using only these subcommands.
COMMAND PROCESSING TERMINATE (AA)
Terminates the processing of the communications commands and restores the command wait status.
V680 Commands
Processing specification Always 0.
Fixed value Always 1.
End code Indicates the execution result for the command.
00: Normal completion
15: Command processing not executed.
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
Termination timing Indicates the timing for terminating command processing.
00: Terminate before RF Tag detection.
01: Terminate during RF Tag detection.
74
RFID System
User's Manual
ABORT (XZ)
This command is used to restore the Hand-held Reader/Writer to command wait status when there is
no response from the Hand-held Reader/Writer due to some problem during communications with the
host device or with an RF Tag.
The ABORT (XZ) command can be used only with the V680-CH1D.
Do not use it with the V680-CHUD.
None
Page 77
Section 3
Command
TR
×
211
2
CR
×
××
11
Data
length
Baud
rate
Parity
Stop
bits
Command
code
Terminator
Response
TR
00
22
2
CR
01
11
Command
code
Terminator
End code
Fixed
value
Resend
flag
Commands
COMMUNICATIONS CONDITIONS SETTING (TR)
This command is used to set serial communications parameters. The Hand-held Reader/Writer must
be restarted to make the changes take effect.
The COMMUNICATIONS CONDITIONS SETTING (TR) command can be used only with the V680-CH1D.
Do not use it with the V680-CHUD.
A memory error will occur if the power supply is interrupted while parameters are being changed.
Section 3
V680 Commands
Baud rate Sets the baud rate.
0: 9,600 bps
1: 2,400 bps
2: 4,800 bps
3: 19,200 bps
4: 38,400 bps
Default setting: 9,600 bps
Data length Sets the data length.
0: 7 bits
1: 8 bits
Default setting: 7 bits
Parity Sets the parity.
0: Even parity
1: Odd parity
2: No parity
Default setting: Even parity
Stop bits Sets the number of stop bits.
0: 2 bits
1: 1 bit
Default setting: 2 bits
End code Indicates the execution result for the command.
00: Normal completion
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
RFID System
User's Manual
75
Page 78
Section 3
Command
FN
0
Fixed
value
211
2
CR
×
Command
code
Terminator
Auto
Command
OFF
specification
Response
FN
00
2
2
2
CR
01
11
Command
code
Terminator
End code
Fixed
value
Resend
flag
V680 Commands
Section 3
Commands
BASIC FUNCTIONS SETTING (FN)
This command is used to set the Auto Commands OFF function. The Hand-held Reader/Writer must
be restarted to make the changes take effect.
A memory error will occur if the power supply is interrupted while parameters are being changed.
Auto Command OFF
specifications
Designates whether the Auto Command OFF function is used.
0: Auto Command OFF used.
1: Auto Command OFF not used.
Default setting: Auto Command OFF used.
Fixed value Always 0.
End code Indicates the execution result for the command.
00: Normal completion
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
76
RFID System
User's Manual
Page 79
SET INFORMATION READ (UL)
Command
UL
2
2
CR
Command
code
Terminator
Response
UL
××
00
TR
22
×× :FN
×0:
2
CR
SI8000000
01
11
Hand-held Reader Writer system data
Baud
rate
Data
length
Stop
bits
Parity Auto Command
OFF specification
Command
code
Terminator
End code
Settings for TR command
Settings for
FN command
Resend
flag
Fixed
value
Fixed
value
This command is used to read the settings of the Hand-held Reader/Writer.
Only the Auto Command OFF function is supported by the V680-CHUD.
The settings made with the COMMUNICATIONS CONDITIONS SETTING (TR) command are not valid for the V600CHUD.
Section 3
Commands
Section 3
V680 Commands
End code Indicates the execution result for the command.
00: Normal completion
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
Settings for TR command Baud rate 0: 9,600 bps
1: 2,400 bps
2: 4,800 bps
3: 19,200 bps
4: 38,400 bps
Data length 0: 7 bits
1: 8 bits
Parity 0: Even parity
1: Odd parity
2: No parity
Stop bits 0: 2 bits
1: 1 bit
Settings for FN command Auto Command OFF
Specification
System data SI000000
Fixed value Always 0.
0: Auto Command OFF used.
1: Auto Command OFF not used.
RFID System
User's Manual
77
Page 80
Section 3
Command
SP
××
2
2
CR
××
0 to 4
2
Upper digit Lower digit
××
Parameter data
(for changed
parameters only)
Command
code
Terminator
Process code
Response
S
00
22
2
CR
××
P
××
1
1
0
1
Parameter data
Command
code
Terminator
0 to 4
Fixed
value
Resend flag
End code
V680 Commands
Section 3
Commands
PARAMETER SET (SP)
The PARAMETER SET command is used to set conditions for communicating with RF Tags. The
various parameters are set in the Hand-held Reader/Writer.
The Hand-held Reader/Writer does not need to be reset when internal settings are changed. The new settings are
effective immediately.
A memory error will occur if the power supply is interrupted while parameters are being changed.
Process code (Upper digit) Specifies the process to perform for the parameter.
0: Change the internal setting.
1: Read internal setting.
9: Return internal setting to default value.
Process code (Lower digit) Specifies the parameter.
1: Inter-character monitoring time
2: Response delay time
4: Auto command cancel time
H: Write protection setting
J: Protocol switch
L: Tag memory setting (See note 1.)
Parameter data (for
changed parameters only)
Note 1.: Parameter L is enabled only with version 1.1 or newer.
Note 2.: The data number of the parameter data is the number specified for the lower digit of the process code.
The settable values for the data number are the same as for the parameter specified by the lower digit of the process code.
Data No. (See note 2.) Settable values
1 Specify 4 decimal digits. 0000 to 9999 (ms)
0000: No monitoring, Default value: 0100 (ms)
2 Specify 2 decimal digits. 00 to 99 (ms)
00: No delay, Default value: 20 (ms)
4 Specify 2 decimal digits. 01 to 99 (s)
Default value: 60 (s)
H 00: Write protection OFF
01: Write protection ON (default value)
J 00: V600 protocol (default value)
01: V680 protocol
L 00: Standard Mode (default value)
01: CA1D Mode
78
End code Indicates the execution result for the command.
Fixed value Always 1.
Resend flag Always 0.
Parameter data Attached only when parameter data is being obtained.
RFID System
User's Manual
00: Normal completion
For details on end codes, refer to End Codes.
p.82
Page 81
Section 3
Command
TS
××
×…
2
2
CR
×
n
TerminatorMessage data
Command
code
Response
TS
××
×…
2
2
CR
×
n
00
2
01
11
Command
code
TerminatorMessage data
End code
Fixed
value
Resend
flag
Commands
Host Commands
TEST (TS)
This command returns test messages sent from the host device without changing anything.
The TEST command is used for communications tests between the host device and the Hand-held
Reader/Writer.
Message data Any text string for testing communications containing 514 characters max.
Section 3
V680 Commands
End code Indicates the execution result for the command.
00: Normal completion
For details on end codes, refer to End Codes.
p.82
Fixed value Always 1.
Resend flag Always 0.
Message data Any text string for testing communications containing 514 characters max.
RFID System
User's Manual
79
Page 82
Section 3
Command
Command code
VS
2
2
* CR
Terminator
Response
Command code
VS
Software model
2
2
* CR
Terminator
16
End code
00
2
01
11
Resend
flag
Fixed
value
1
Software version
41
Creation date
10
Section 3
Commands
VERSION READ (VS)
The VERSION READ command reads the Hand-held Reader/Writer's software model, software version, and software creation date.
V680 Commands
Software model The software creation date.
For the V680-CHUD: V680-CHUD$000000
For the V680-CH1D: V680-CH1D$000000
For the V680-CH1D-PSI: V680-CH1D$000000
Software version The software version.
*.**
Software creation date The software creation date.
20**/**/**
80
User's Manual
RFID System
Page 83
Section 3
Response
IC
2
2
××
2
CR
01
11
Command
code
Terminator
End code
Fixed
value
Resend
flag
Response
××
××
22
2
CR
01
11
Command
code
Terminator
End code
Fixed
value
Resend
flag
Commands
Other Commands
UNDEFINED COMMAND RESPONSE (IC)
This command is returned as the response when the Hand-held Reader/Writer cannot read the command header.
Error Response
If an error occurs during communications with the host device, or the RF Tag, error notification is provided in the end code.
Section 3
V680 Commands
RFID System
User's Manual
81
Page 84
Section 3
V680 Commands
Section 3
Commands
End Codes
End codes are given in 2-digit hexadecimal.
Status End code Meaning
Normal 00 Normal completion
Host communications error 10 (See note.) Vertical parity error
11 (See note.) Framing error
12 (See note.) Overrun error
14 Format error
15 Execution status error
18 Frame length error
Lower communications error 70 RF Tag communications error
71 Mismatch error
72 RF Tag non-existent error
76 Error end code for the DATA CHECK command or OVERWRITE COUNT CON-
TROL command (verification error or overwrite count exceeded) or error for
READ WITH ERROR CORRECTION or DATA CHECK command
77 Warning for READ WITH ERROR CORRECTION or DATA CHECK command
79 RF Tag error
7A Address error
7C Antenna error
7D Write protection error
Memory error 93 Internal memory error
Note: Vertical parity errors, framing errors, and overrun errors do not occur for the V680-CHUD.
For details on each error, refer to Error Tables.
p.128
82
RFID System
User's Manual
Page 85
Section 3
A
C
B
D
Communications
with RF Tag
Response
Command
Hos
t device
Hand-hel
d Reader/Writer
RF
Tag
Commands
V600 Commands
There are 4 types of commands for communicating with the RF Tag using the Hand-held Reader/Writer.
• Normal commands
• Button commands
• Auto commands
• Button auto commands
Normal Commands
Normal commands are sent from the host device for communications with the RF Tag, after the
antenna end of the Hand-held Reader/Writer has been moved close to the RF Tag.
1. Move the antenna end of the Hand-held Reader/Writer close to the RF Tag.
Section 3
V600 Commands
2. Commands are sent from the host device to the Hand-held Reader/Writer.
3. The Hand-held Reader/Writer communicates with the RF Tag.
4. A response is returned from the Hand-held Reader/Writer to the host device.
If communications end normally, the operation indicator (LED) will light green and then turn OFF.
If the RF Tag is not detected within the Hand-held Reader/Writer's communication area when the command is sent from the host device, an RF Tag Non-existent Error will occur.
At this time, the operation indicator will flash red.
RFID System
User's Manual
83
Page 86
Section 3
D
A
E
Communications
with RF Tag
Response
Command
C
Press
Hand-held Reader/Writer
Host device RF Tag
B
V600 Commands
Section 3
Commands
Button Commands
Button commands used to perform communications with the RF Tag are activated when the activate
switch is pressed after commands are sent from the host device, and the antenna end of the Hand-held
Reader/Writer has been moved close to the RF Tag.
1. A command is sent from the host device to the Hand-held Reader/Writer. As a result, the operation
indicator will light green.
2. Move the antenna end of the Hand-held Reader/Writer close to the RF Tag.
3. Press the Hand-held Reader/Writer activate switch.
4. The Hand-held Reader/Writer communicates with the RF Tag.
5. A response is returned to the host device from the Hand-held Reader/Writer.
If communications end normally, the operation indicator (LED) will light green and then turn OFF.
If the RF Tag is not detected within the Hand-held Reader/Writer's communication area when the activate switch is pressed, an RF Tag Non-existent Error will occur.
At this time, the operation indicator will flash red.
84
RFID System
User's Manual
Page 87
Section 3
C
A
D
Communications
with RF Tag
Response
Command
Host device RF Tag
Hand-held Reader/Writer
B
Commands
Auto Commands
Auto commands can execute communications with the RF Tag when the antenna end of the Hand-held
Reader/Writer has been moved close to the RF Tag after the command is sent from the host device.
1. A command is sent from the host device to the Hand-held Reader/Writer.
2. The Hand-held Reader/Writer enters the communications stand-by state with the RF Tag, and the
operation indicator (LED) flashes green.
Section 3
V600 Commands
If the RF Tag is not detected within one minute of sending the command, a timeout will occur and an RF Tag Non-existent Error will occur. As a result, the operation indicator will flash red.
3. Communications with the RF Tag are performed when the antenna end of the Hand-held Reader/
Writer is moved close to the RF Tag.
4. A response is returned to the host device from the Hand-held Reader/Writer.
If communications end normally, the operation indicator (LED) will light green and then turn OFF.
RFID System
User's Manual
85
Page 88
Section 3
D
A
E
Communications
with RF Tag
Response
Command
B
Press
Hand-held Reader/Writer
Hos
t device
RF T
ag
B
V600 Commands
Section 3
Commands
Button Auto Commands
Button auto commands execute auto commands after a command is sent from the host device and the
activate switch of the Hand-held Reader/Writer is pressed.
1. A command is sent from the host device to the Hand-held Reader/Writer. As a result, the operation
indicator will light green.
2. Press the Hand-held Reader/Writer activate switch.
3. The Hand-held Reader/Writer enters the communications stand-by state with the RF Tag, and the
operation indicator (LED) flashes green.
If the RF Tag is not detected within one minute of sending the command, a timeout will occur and an RF Tag Non-existent Error will occur. As a result, the operation indicator will flash red.
4. Communications with the RF Tag are performed when the antenna end of the Hand-held Reader/
Writer is moved close to the RF Tag.
5. A response is returned to the host device from the Hand-held Reader/Writer.
If communications end normally, the operation indicator (LED) will light green and then turn OFF.
86
RFID System
User's Manual
Page 89
Section 3
××
×
2
2
CR
×
…×n×
1 frame (maximum frame length: 2,114 characters)
Command
code
Data Terminator
××
×
2
2
CR
×
…×n×
××
2
Command
code
Data
Terminator
End code
Commands
Command and Response Formats
The formats of commands sent from the host device to the Hand-held Reader/Writer and responses
returned from the Hand-held Reader/Writer to the host device are described below.
The command and response both consist of a single frame. The frame (including the terminator)
consists of up to, 2,114 characters.
Command Frame
Name Description
Command code Contains the two-character code (see page 88) that indicates the command.
Data Contains the data for the command.
• Data setting, processing specification
• Start address
• Write data, number of bytes to be written
• Number of read bytes
• Number of calculation area bytes, calculation data
• Number of check block bytes, decrement count
• Specified data
• Message data
• Parameter data
• Baud rate, data length, parity, and stop bits specification
• Auto command OFF specification
• Settings for the TR command, settings for the FN command, and system setting data.
Terminator Indicates end of command/response.
Section 3
V600 Commands
Response Frame
Name Description
End code Indicates the execution result for the command.
Fixed value Always 1.
Resend flag Always 0.
Data Contains the data for the response.
Note: Other than the above items, the same data as the command frame is returned in the response.
For information on end codes, refer to End Codes.
p.82
• Read data
•UID
• Processing terminate timing
• Calculation data
• Message data
• Parameter data
• Model information
RFID System
User's Manual
87
Page 90
Section 3
V600 Commands
Section 3
Commands
Command List
Commands can be classified into four major types.
Communications Commands
The following commands are used for communications with the RF Tag.
Command code Command name Function Page
RD READ Reads memory data from the RF Tag. p.89
WT WRITE Writes data to the memory of the RF Tag. p.91
AR AUTO READ Reads data from the RF Tag when the RF Tag enters the interrogation
AW AUTO WRITE Writes data to the memory of the RF Tag when the RF Tag enters the
BR BUTTON READ Reads data from the memory of the RF Tag when the activate switch is
BW BUTTON WRITE Writes data to the memory of the RF Tag when the activate switch is
UR BUTTON AUTO READ Reads data from the RF Tag when the RF Tag enters the interrogation
UW BUTTON AUTO WRITE Writes data to the memory of the RF Tag when the RF Tag enters the
CW CALCULATION WRITE Writes the calculation results for the memory data to the RF Tag. p.102
FL DATA FILL Writes data for the specified number of write bytes beginning from the
AF AUTO DATA FILL Writes the specified data to the specified number of bytes beginning from
MDC/K DATA CHECK Calculates or compares memory check codes in the RF Tag. p.106
MDS OVERWRITE COUNT
CONTROL
ID ID CODE READ Reads the UID in the RF Tag. p.108
zone.
interrogation zone.
pressed.
pressed.
zone after the activate switch is pressed.
interrogation zone after the activate switch is pressed.
write start address specified in the command.
the specified start address when the RF Tag approaches.
Controls the number of overwrites for RF Tags.
p.92
p.94
p.96
p.98
p.99
p.101
p.103
p.104
p.107
Communications Subcommands
These commands are used to cancel command execution.
Command code Command name Function Page
AA COMMAND PROCESS-
ING TERMINATE
XZ ABORT Resets the Hand-held Reader/Writer. p.112
Forcedly ends communications with the RF Tag.
Controller Control Commands
These commands are used to reset the Controller or set serial communications.
Command code Command name Function Page
TR COMMUNICATIONS CON-
DITIONS SETTING
FN BASIC FUNCTIONS SET-
TING
UL SET INFORMATION READ Reads the settings data for the Hand-held Reader/Writer. p.115
SP PARAMETER SET Sets, reads, or initializes Hand-held Reader/Writer parameters. p.116
Sets communications parameters for communications with the host
device.
Sets the Specify Auto Command OFF function.
Host Commands
These commands are used to test communications between the Hand-held Reader/Writer and host
device.
Command code Command name Function Page
TS TEST Confirms the communications status between the Hand-held Reader/Writer
VS VERSION READ Reads the Hand-held Reader/Writer's software model, software version,
and host device. The data sent from the host device is returned as is.
and software creation date.
p.109
p.113
p.114
p.110
p.111
88
RFID System
User's Manual
Page 91
Section 3
Command
××
RD
××
A/H 1
××
211 4 2
2
CR
Command
code
Data
setting
Number of bytes
to read
Terminator
Read area
start address
Pro-
cessing
area
number
setting
××
RD
××
A/H 2
××
211 4 2
2
CRA/H
1
××
××××
42
Command
code
Data
setting
Number of
bytes
to read
Terminator
Read area
start address
Area (1) setting
Area (2) setting
Data
setting
Number of bytes
to read
Read area
start address
Pro-
cessing
area
number
setting
Commands
Communications Commands
Details of communications commands used to communicate with the RF Tag are provided here.
READ (RD)
This command reads data from the RF Tag. If the RF Tag is not in the interrogation zone, an error
response (end code: 72 = RF Tag non-existent) will be returned.
Processing area number: 1
Section 3
V600 Commands
Processing area number: 2
Data setting Sets the code format used to send responses for read data.
A: ASCII
H: Hexadecimal
When multiple processing areas are used, ASCII and hexadecimal can be specified at the same
time within a single command frame.
Processing area number
setting
Read area start address Specifies the start address of the area to be read from the RF Tag in 4-digit hexadecimal.
Number of bytes to read Specifies the number of bytes to be read from the RF Tag in 2-digit hexadecimal. The maximum
Specifies the processing area number.
Setting range: 1 to 9, A (A = 10)
Setting range: 0000 to FFFF hex
When multiple processing areas are used, specify the areas in order starting from the smallest
address. The same area cannot be specified twice.
number of bytes that can be read at one time is 256 bytes, as follows:
• ASCII: 256 bytes (256 characters)
• Hexadecimal: 256 bytes (512 characters)
Setting range: 00 to FF hex (00 = 256 bytes)
When multiple processing areas are used, set so that the total number of bytes from all areas to be
read is within 256 bytes, as follows:
Area (1) bytes +...+ Area (N) bytes ≤ 256 bytes
RFID System
User's Manual
89
Page 92
Section 3
Response
RD
…×
00
××
22 n
2
CR
×
TerminatorRead dataEnd code
Command
code
××
RD
…×
00
××
22 n
2
CR×
×…×
n
Command
code
Terminator
Read data
Area (1)
Area (1) setting
Area (2) setting
Read data
Area (2)
End code
V600 Commands
Section 3
Commands
Processing Area Number: 1
Processing Area Number: 2
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
For details on end codes, refer to End code List.
p.118
Read data Specifies the data read from the RF Tag.
The characters in ASCII indicate the number of read bytes and the characters in hexadecimal indicate the number of read bytes x 2.
90
RFID System
User's Manual
Page 93
Section 3
Command
××
WT
××
A/H 1
××
211 4
2
CR
n
××
Command
code
Data
setting
Processing
area
number
setting
Write data
Write area
start address
Terminator
××
WT
××
A/H 2
××
211 4 2
…××
n
2
CRA/H
1
××
××××
42
…××
n
Command
code
Data
setting
Processing
area
number
setting
Number of
write bytes
Write area
start address
Area (1) setting
Write data Terminator
Area (2) setting
Data
setting
Number of
write bytes
Write area
start address
Write data
Response
WT
00
22
2
CR
Command
code
TerminatorEnd code
Commands
WRITE (WT)
This command writes data to the RF Tag. If the RF Tag is not in the interrogation zone, an error
response (end code: 72 = RF Tag non-existent) will be returned.
Processing Area Number: 1
Processing Area Number: 2
Section 3
V600 Commands
Data setting Sets the code format used to send responses for write data.
A: ASCII
H: Hexadecimal
When multiple processing areas are used, ASCII and hexadecimal can be specified at the same
time within a single command frame.
Processing area number
setting
Specifies the processing area number.
Setting range: 1 to 9, A (A = 10)
Write area start address Specifies the start address of the area in the RF Tag to be written to in 4-digit hexadecimal.
Setting range: 0000 to FFFF hex
When multiple processing areas are used, specify the areas in order starting from the smallest
address. The same area cannot be specified twice.
Number of write bytes When multiple processing areas are used, specifies the number of bytes to be written to the RF Tag
in 2-digit hexadecimal. The maximum number of bytes that can be written at one time is 256 bytes,
as follows:
• ASCII: 256 bytes (256 characters)
• Hexadecimal: 256 bytes (512 characters)
Setting range: 01 to FF hex
When multiple processing areas are used, set so that the total number of bytes to be written for all
areas is within 256 bytes, as follows:
Area (1) bytes +...+ Area (N) bytes ≤ 256 bytes
Write data Specifies the write data from the RF Tag.
The characters in ASCII indicate the number of write bytes and the characters in hexadecimal indicate the number of write bytes x 2.
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
For details on end codes, refer to End code List.
p.118
RFID System
User's Manual
91
Page 94
Section 3
Command
××
AR
××
A/H 1
××
211 4 2
2
CR
Command
code
Data
setting
Number of
read bytes
Read area
start address
Processing
area
number
setting
Terminator
××
AR
××
A/H 2
××
211 4 2
2
CRA/H
1
××
××××
42
Command
code
Data
setting
Number of
read bytes
Terminator
Read area
start address
Area (1) setting
Area (2) setting
Data
setting
Number of
read bytes
Read area
start address
Processing
area
number
setting
Section 3
Commands
AUTO READ (AR)
This command reads data from the RF Tag when the RF Tag enters the interrogation zone. The Handheld Reader/Writer responds when the communications between the Hand-held Reader/Writer and RF
Tag have ended.
Processing Area Number: 1
V600 Commands
Processing Area Number: 2
Data setting Specifies the code format used to send responses for write data.
A: ASCII
H: Hexadecimal
When multiple processing areas are used, ASCII and hexadecimal can be specified at the same
time within a single command frame.
Processing area number
setting
Read area start address Specifies the start address of the area in the RF Tag to be read from in 4-digit hexadecimal.
Number of read bytes When multiple processing areas are used, specifies the number of bytes to be read from the RF
Specifies the processing area number.
Setting range: 1 to 9, A (A = 10)
Setting range: 0000 to FFFF hex
When multiple processing areas are used, specify the areas in order starting from the smallest
address. The same area cannot be specified twice.
Tag in 2-digit hexadecimal.
The maximum number of bytes that can be read at one time is 256 bytes.
• ASCII: 256 bytes (256 characters)
• Hexadecimal: 256 bytes (512 characters)
Setting range: 00 to FF hex (00 = 256 bytes)
92
RFID System
User's Manual
When multiple processing areas are used, set so that the total number of bytes to be read for all
areas is within 256 bytes, as follows:
Area (1) bytes +...+ Area (N) bytes ≤ 256 bytes
Page 95
Processing Area Number: 1
Response
×
AR
…×
00
××
22 n
2
CR
Command
code
TerminatorRead dataEnd code
××
AR
…×
00
××
22 n
2
CR×
×…×
n
Command
code
Terminator
Read data
area (1)
Area (1) setting
Area (2) setting
Read data
area (2)
End code
Processing Area Number: 2
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
For details on end codes, refer to End code List.
p.118
Section 3
Commands
Section 3
V600 Commands
Read data Specifies the data read from the RF Tag.
The characters in ASCII indicate the number of read bytes and the characters in hexadecimal indicate the number of read bytes x 2.
RFID System
User's Manual
93
Page 96
Section 3
Command
××
AW
××
A/H 1
××
211 4
2
CR
n
××
Command
code
Write data
Terminator
Data
setting
Processing
area
number
setting
Write area
start address
××
AW
××
A/H 2
××
211 4 2
…××
n
2
CRA/H
1
××
××××
42
…××
n
Number of
write bytes
Write data
Data
setting
Number of
write bytes
Write area
start address
Write data
Command
code
Data
setting
Processing
area
number
setting
Write area
start address
Terminator
Area (1) setting
Area (2) setting
Section 3
Commands
AUTO WRITE (AW)
This command writes data to the RF Tag when the RF Tag enters the interrogation zone. The Handheld Reader/Writer responds when communications between the Hand-held Reader/Writer and RF
Tag have ended.
Processing Area Number: 1
V600 Commands
Processing Area Number: 2
Data setting Sets the code format used to send responses for write data.
A: ASCII
H: Hexadecimal
When multiple processing areas are used, ASCII and hexadecimal can be specified at the same
time within a single command frame.
Processing area number
setting
Write area start address Specifies the start address of the area in the RF Tag to be written to in 4-digit hexadecimal.
Number of write bytes When multiple processing areas are used, specifies the number of bytes to be written to the RF Tag
Specifies the processing area number.
Setting range: 1 to 9, A (A = 10)
Setting range: 0000 to FFFF hex
When multiple processing areas are used, specify the areas in order starting from the smallest
address. The same area cannot be specified twice.
in 2-digit hexadecimal.
The maximum number of bytes that can be written at one time is 256 bytes.
• ASCII: 256 bytes (256 characters)
• Hexadecimal: 256 bytes (512 characters)
Setting range: 01 to FF hex
Write data Indicates the data to be written to the RF Tag.
94
RFID System
User's Manual
When multiple processing areas are used, set so that the total number of bytes to be written for all
areas is within 256 bytes,6 bytes, as follows:
Area (1) bytes +...+ Area (N) bytes ≤ 256 bytes
The characters in ASCII indicate the number of write bytes and the characters in hexadecimal indicate the number of write bytes × 2
Page 97
Section 3
Response
Commands
Command
code
AW
End code Indicates the execution result for the command.
00
22
TerminatorEnd code
CR
2
The end code 00 indicates normal completion.
For details on end codes, refer to End code List.
p.118
Section 3
V600 Commands
RFID System
User's Manual
95
Page 98
Section 3
Command
××
BR
××
A/H 1
××
211 4 2
2
CR
Number of
read bytes
Terminator
Command
code
Data
setting
Processing
area
number
setting
Read area
start address
××
BR
××
A/H 2
××
211 4 2
2
CRA/H
1
××
××××
42
Terminator
Number of
read bytes
Command
code
Data
setting
Processing
area number
setting
Read area
start address
Number of
read bytes
Data
setting
Read area
start address
Area (1) setting
Area (2) setting
Section 3
Commands
BUTTON READ (BR)
After this command is received by the Hand-held Reader/Writer, data is read from the RF Tag by
pressing the activate switch. If the activate switch is pressed and the RF Tag is not in the interrogation
zone, an error response (end code: 72 = RF Tag non-existent) will be returned.
Processing Area Number: 1
V600 Commands
Processing Area Number: 2
Data setting Sets the code format used to send responses for read data.
A: ASCII
H: Hexadecimal
When multiple processing areas are used, ASCII and hexadecimal can be specified at the same
time within a single command frame.
Processing area number
setting
Read area start address Specifies the start address of the area in the RF Tag to be read from in 4-digit hexadecimal.
Number of read bytes Specifies the number of bytes to be read from the RF Tag in 2-digit hexadecimal.
Specifies the processing area number.
Setting range: 1 to 9, A (A = 10)
Setting range: 0000 to FFFF hex
When multiple processing areas are used, specify the areas in order starting from the smallest
address. The same area cannot be specified twice.
The maximum number of bytes that can be read at one time is 256 bytes.
• ASCII: 256 bytes (256 characters)
• Hexadecimal: 256 bytes (512 characters)
Setting range: 00 to FF hex (00 = 256 bytes)
96
RFID System
User's Manual
When multiple processing areas are used, set so that the total number of bytes to be read for all
areas is within 256 bytes, as follows:
Area (1) bytes +...+ Area (N) bytes ≤ 256 bytes
Page 99
Processing Area Number: 1
Response
×
BR
…×
00
××
22 n
2
CR
Command
code
TerminatorRead data
End code
××
BR
…×
00
××
22 n
2
CR×
×…×
n
Command
code
Terminator
Read data
area (1)
Read data
area (2)
End code
Area (1) setting Area (2) setting
Processing Area Number: 2
End code Indicates the execution result for the command.
The end code 00 indicates normal completion.
Section 3
Commands
Section 3
V600 Commands
For details on end codes, refer to End code List.
p.118
Read data Indicates the data read from the RF Tag.
The characters in ASCII indicate the number of read bytes and the characters in hexadecimal indicate the number of read bytes x 2.
RFID System
User's Manual
97
Page 100
Section 3
Command
××
BW
××
A/H 1
××
211 4
2
CR
n
××
Command
code
Write data
Terminator
Data
setting
Processing
area
number
setting
Write area
start address
××
BW
××
A/H 2
××
211 4 2
…××
n
2
CRA/H
1
××
××××
42
…××
n
Area (1) setting
Write data Terminator
Area (2) setting
Data
setting
Number of
write bytes
Write data
Command
code
Data
setting
Processing
area number
setting
Write area
start address
Number of
write bytes
Write area
start address
Response
BW
00
22
2
CR
Command
code
Terminator
End code
V600 Commands
Section 3
Commands
BUTTON WRITE (BW)
After this command is received by the Hand-held Reader/Writer, data is written to the RF Tag by pressing the activate switch. If the activate switch is pressed and the RF Tag is not in the interrogation zone,
an error response (end code: 72 = RF Tag non-existent) will be returned.
Processing Area Number: 1
Processing Area Number: 2
Data setting Sets the code format used to send responses for write data.
A: ASCII
H: Hexadecimal
When multiple processing areas are used, ASCII and hexadecimal can be specified at the same
time within a single command frame.
Processing area number
setting
Specifies the processing area number.
Setting range: 1 to 9, A (A = 10)
Write area start address Specifies the start address of the area in the RF Tag to be written to in 4-digit hexadecimal.
Setting range: 0000 to FFFF hex
When multiple processing areas are used, specify the areas in order starting from the smallest
address. The same area cannot be specified twice.
Number of write bytes When multiple processing areas are used, specifies the number of bytes to be written to the RF Tag
in 2-digit hexadecimal.
The maximum number of bytes that can be written at one time is 256 bytes.
• ASCII: 256 bytes (256 characters)
• Hexadecimal: 256 bytes (512 characters)
Setting range: 01 to FF hex
When multiple processing areas are used, set so that the total number of bytes to be written for all
areas is within 256 bytes, as follows:
Area (1) bytes +...+ Area (N) bytes ≤ 256 bytes
Write data Indicates the data to be written to the RF Tag.
The characters in ASCII indicate the number of write bytes and the characters in hexadecimal indicate the number of write bytes x 2.
End code Indicates the execution result for the command.
98
RFID System
User's Manual
The end code 00 indicates normal completion.
For details on end codes, refer to End code List.
p.118
