Omron NE-C28 User Manual

INSTRUCTION MANUAL

Compressor Nebulizer

MODEL NE-C28

PORTUGUÊS

Caution:

Federal (USA) la order of a ph

ysician or licensed healthcare practitioner

w restricts this de

vice to sale by or on the

FRANÇAIS ESPAÑOL

ENGLISH

CONTENTS

Before Using the Device

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety Information

Operating the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Risk of Electrical Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Maintenance and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Know Your Unit

Main Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Components and Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Operating Instructions

Preparing the Nebulizer for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Attaching the Air Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Using the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Care and Maintenance

Cleaning after Each Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Daily Disinfecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Changing the Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Caring for the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Troubleshooting

Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

The illustrations shown in this instruction manual are image drawings and may differ slightly from the appearance of the actual product.

Before Using the Unit

INTRODUCTION

Thank you for purchasing the OMRON®CompAir®NE-C28 Compressor Nebulizer.

Fill in for future reference.

DATE PURCHASED: __________________

SERIAL NUMBER: ____________________

Staple your purchase receipt here

This product was developed for the successful treatment of asthma, allergies and other respiratory disorders. The compressor forces air to the nebulizer. When the air enters the nebulizer, it converts the prescribed medication into an aerosol of microscopic droplets that can easily be inhaled.

Your NE-C28 CompAir®comes with the following components:

• Compressor (Main Unit)

• Nebulizer Kit

• Mouthpiece

• Child Mask

• Air Tube

• Air Filters (Package of 5)

• Air Filter Cover

• Instruction Manual (English, Spanish, Portuguese, French)

• User Registration Card

The following are optional accessories sold separately:

Adult Inhalation Mask

•

• Nosepiece

The CompAir®is a prescription medical device. Operate this device only

as instructed by your ph

ysician and/or licensed healthcare practitioner

SAVE THESE INSTRUCTIONS

SAFETY INFORMATION

To assure the correct use of the product basic safety measures should always be followed including the warnings and cautions listed in this instruction manual.

SAFETY SYMBOLS USED IN THIS INSTRUCTION MANUAL

WARNING

CAUTION

OPERATING THE DEVICE

For type, dose, and regime of medication follow the instructions of your physician or licensed healthcare practitioner.

Do not block the ventilation slots located on the sides of the device. Do not place the device where the ventilation slots may be obstructed during operation. This could result in the compressor overheating or malfunctioning.

Do not cover the compressor with a blanket, towel, or any other type of cover during use. This could result in the compressor overheating or malfunctioning.

Do not use the device where the device may be exposed to flammable gas or vapors.

Do not use tap or mineral water in the nebulizer for nebulizing purposes.

Clean and disinfect the nebulizer kit, mouthpiece, and optional nosepiece or masks before using them for the first time after purchase.

If the device has not been used for a long period of time clean and disinfect the nebulizer kit, mouthpiece, and optional nosepiece or masks before using them.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the user or patient or damage to the equipment or other property.

Always dispose of any remaining medication in the medication cup after each use. Use fresh medication each time you use the device.

Provide close supervision when this device is used by, on, or near infants, children or compromised indi

Do not insert an

Make sure the air filter is clean. If the air filter has changed color or has not been used for 60 days, replace the f

viduals.

y object into the compressor.

ilter.

SAFETY INFORMATION

OPERATING THE DEVICE (continued)

Make sure the nebulizer kit is correctly assembled, the air filter is properly installed, and the air tube is correctly connected to the compressor and the nebulizer kit. Air may leak from the air tube during use if not securely connected.

Inspect the compressor (main unit) and the nebulizer parts each time before using the device. Make sure no parts are damaged, the nozzle and air tube are not blocked and the compressor operates normally.

Do not use the device if the air tube is bent. Do not block the air filter cover.

Do not alter the baffle, the nozzle in the medication cup or any part of the nebulizer kit.

Do not add more than 7ml of medication to the medication cup.

Do not operate the device at temperatures greater than +104˚F (+40˚C).

Do not tilt the nebulizer kit so the angle of the kit is greater than 45˚. Medication may flow into the mouth.

Do not shake the nebulizer kit while using the device.

Do not subject the compressor or any of the components to strong shocks, such as dropping on the floor.

This device is approved for human use only.

Do not disassemble or attempt to repair the device or components.

Operate the device only as intended. Do not use the device for any other purpose.

Dispose of the device, components and optional accessories according to applicable local regulations. Unlawful disposal may cause environmental pollution.

Use only Omron authorized parts and accessories. Parts and accessories not approved for use with the device may damage the unit.

Changes or modification not approved by Omron Healthcare will void the user warranty.

SAFETY INFORMATION

RISK OF ELECTRICAL SHOCK

Do not plug or unplug the power cord into the electrical outlet with wet hands.

Do not immerse the compressor (main unit) in water or other liquid.

Do not spill water or other liquids on the compressor and power cord. The compressor and power cord are not waterproof. If liquid spills on these parts, immediately unplug the power cord and wipe off the liquid with gauze or other soft absorbent material.

Do not use or store the device in humid locations, such as a bathroom. Use the device within the operating temperature and humidity.

Do not use a cellular phone near the device. It may result in an operational failure.

Do not overload power outlets. Plug the device into an outlet with voltage.

Do not use extension cords. Plug the power cord directly into the electrical outlet.

Unplug the power cord from the electrical outlet after using the device.

Unplug the power cord from the electrical outlet before cleaning the device.

MAINTENANCE AND STORAGE

Keep the device out of the reach of unsupervised infants and children. The device may contain small parts that can be swallowed.

Do not leave the cleaning solution in the nebulizer parts. Rinse the nebulizer parts

with clean hot tap water after disinfecting.

Wash the nebulizer parts after each use. Dry the parts immediately after washing.

Do not store the air tube with moisture or medication remaining in the air tube. This could result in infection as a result of bacteria.

Store the device and the components in a clean, safe location.

Do not carry or leave the nebulizer with medication in the medication cup.

Do not place or attempt to dry the device, components, or any of the nebulizer parts in a microwave oven.

Do not wrap the power cord around the compressor (main unit).

Main Unit:

Compressor

Power Switch

Front View

MAIN UNIT

Back View

Nebulizing Kit

Air Plug

Air Connect

Components:

Nebulizer Kit

Air Filter Cover

Cap

Inhalation Air Inlet

Inhalation Top

Baf

Ventilation Slots

Nebulizer Kit Holder

(*Air Filter Inside)

Air Plug

Ventilation Slots

Power Plug

Power Cord

Mouthpiece

Child Mask

Nozzle

Medication Cup

ube Connector

Air T

Components:

KNOW YOUR UNIT

Air Tube

with attached Air Plugs

Instruction Manual

Nébuliseur à compresseur

MODÈLE N

E-C28

Mise en garde En vertu de la loi américaine,

Optional Accessories:

Adult Mask

Air Filters

Package of 5

Registration

Nosepiece

User

Card

Air Filter Cover

Carrying Bag

Accessories and Replacement Parts

Model No.

Adult Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C920

Air Filters (Package of 5) . . . . . . . . . . . . . . . . . . . . . . . . . . .C28FL

ube with attached Air Plugs . . . . . . . . . . . . . . . . . . . .C915

Air T

Carrying Bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C28BAG

Child Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C922

Nebulizer Kit Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C900-1

Includes Neb

ulizer Kit, Mouthpiece and

Nosepiece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C911

Mouthpiece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C910

Air Tube

PREPARING THE NEBULIZER FOR USE

WARNING

Clean and disinfect the nebulizer kit, mouthpiece, and optional nosepiece or masks before using them for the first time after purchase.

WARNING

If the device has not been used for a long period of time clean and disinfect the nebulizer kit, mouthpiece, and optional nosepiece or masks before using them.

For directions on cleaning and disinfecting refer to page 16 and page 17.

CAUTION

Make sure the air filter is clean. If the air filter has changed color or has not been used for 60 days, replace the filter.

For directions on changing the air filter refer to page 19.

1. Turn the power switch off. Make sure the power switch is in the O position.

2. Plug the power plug into the electrical outlet.

WARNING

Do not plug or unplug the power cord into the electrical outlet with wet hands.

CAUTION

Do not overload power outlets. Plug the device into the

appropriate voltage outlet.

CAUTION

Do not use extension cords. Plug the power cord directly into the electrical outlet.

3. Lift up the mouthpiece and the cap to remove them from the nebulizer kit.

4. Rotate the inhalation top counterclockwise (A) and lift (B) to remove the inhalation top from the medication cup.

Operating Instructions

max

5 3

PREPARING THE NEBULIZER FOR USE

5. Lift up the baffle and remove the baffle from the medication cup.

CAUTION

Do not alter the baffle, the nozzle in the medication cup or any part of the nebulizer kit.

6. Add the correct amount of prescribed medication to the medication cup.

WARNING

For type, dose, and regime of medication follow the instructions of your physician or licensed healthcare practitioner.

WARNING

Do not use tap or mineral water in the nebulizer for nebulizing purposes.

CAUTION

Do not add more than 7ml of medication to the medication cup.

7. Place the baffle back into the medication cup. Make sure the baffle is correctly positioned over the nozzle in the medication cup.

8. Place the inhalation top on the medication cup over the baffle. The top of the baffle should be centered in the inhalation top.

Align the protrusion on the inhalation top with the indentation on the medication cup as illustrated (A).

Turn the inhalation top clockwise until securely closed (B).

PREPARING THE NEBULIZER FOR USE

9. Attach the desired inhalation accessory.

NOTE: Mouthpiece and Nosepiece

Place the cap on the medication cup when using the mouthpiece or nosepiece. Using the cap with the mouthpiece or the nosepiece will reduce the amount of medication that is discharged into the air.

USING THE MOUTHPIECE

Place the cap on the medication cup over the inhalation air inlet (A).

Attach the mouthpiece (B).

USING THE NOSEPIECE

Place the cap on the medication cup over the inhalation air inlet (A).

Attach the nosepiece (B).

NOTE: Child Mask and Adult Mask

Do not place the cap on the medication cup when using the Child Mask or the Adult Inhalation Mask.

USING THE CHILD MASK

Attach the mask to the inhalation top.

USING THE ADULT MASK

Attach the mask to the inhalation top.

ATTACHING THE AIR TUBE

1. Push the Air Plug on one end of the Air Tube onto the Air Connector on the front side of the compressor (A).

2. Push the Air Plug on the other end of the Air Tube onto the Air Tube Connector on the bottom of the Nebulizer Kit (B).

NOTE: Keep the nebulizer kit upright when attaching the air tube. Medication may

spill out of the medication cup.

CAUTION

UTION

Do not use the device if the air tube is bent.

3. Use the Nebulizer Kit Holder as a temporary holder for the nebulizer kit.

USING THE DEVICE

ax 5 3

max

5 3

max

5 3

WARNING

Do not use the device where the device may be exposed to flammable gas or vapors.

WARNING

Do not use or store the device in humid locations, such as a bathroom. Use the device within the operating temperature and humidity.

CAUTION

Provide close supervision when this device is used by, on, or near infants, children or compromised individuals.

CAUTION

Do not use a cellular phone near the device. It may result in an operational failure.

CAUTION

1. Hold the nebulizer kit as illustrated on the right.

CAUTION

Do not tilt the nebulizer kit so the angle of the kit is greater than 45˚. Medication may flow into the mouth.

CAUTION

Do not shake the nebulizer kit while using the device.

2. Turn the power switch on. The power switch is in the (l) position.

NOTE: The compressor starts. Nebulization begins

and aerosol is generated.

Turn the power switch to the off (O) position to stop nebulization.

USING THE DEVICE

x 5 3

5 3

max 5 3

WARNING

Do not cover the compressor with a blanket, towel, or any other type of cover during use. This could result in the compressor overheating or malfunctioning.

CAUTION

Do not block the air filter cover.

3. Inhale medication as instructed by your physician or licensed healthcare practitioner.

USING THE MOUTHPIECE

Insert the mouthpiece into your mouth. Inhale medication breathing normally. Exhale normally through the mouthpiece.

USING THE NOSEPIECE

Inhale the medication through the nosepiece as illustrated. Exhale through the mouth.

NOTE: Child Mask and Adult Mask

If the amount of aerosol is too much, place the cap on the medication cup over the inhalation air inlet.

USING THE CHILD MASK or the ADULT MASK

Place the mask over the nose and mouth. Pull the elastic strap over the head. Gently pull on the strap to securely hold the mask o

ver the nose and mouth. Inhale the

medication. Exhale normally through the mask.

4. Complete the treatment.

ARNING

or type, dose, and regime of medication follow the instructions of your

F physician or licensed healthcare practitioner.

USING THE DEVICE

5. Turn the power switch off. The power switch is in the position. The

compressor turns off and nebulization stops.

6. Disconnect the Air Tube from the Nebulizer Kit. Hold the Air Plug and

gently pull down to disconnect the Air Plug from the Air Tube

Connector on the bottom of the nebulizer kit.

7. Check the Air Tube. No condensation or moisture should remain in the Air Tube.

WARNING

Do not store the air tube with moisture or medication remaining in the air tube. This could result in infection as a result of bacteria.

If any condensation or moisture remains in the air tube, remove the moisture from the air tube. Follow the directions below:

1. Make sure the Air Tube is still connected to the Air connector on the front side of the compressor.

2. Turn the power switch on. The power switch is in the (l)

position. The compressor will start and pump air through the air

tube to expel the moisture.

3. Turn the power switch off.

8. Disconnect the Air Tube from the compressor. Hold the Air Plug and gently pull the Air Plug off the Air Connector on the front side of the compressor.

9. Unplug the device from the electrical outlet.

CAUTION

Unplug the po using the device.

wer cord from the electrical outlet after

CLEANING AFTER EACH USE

Following the cleaning instructions after each use will prevent any remaining medication in the bottle from drying resulting in the device not nebulizing effectively and will help prevent infections.

WARNING

Wash the nebulizer parts after each use. Dry the parts immediately after washing.

1. Remove the inhalation accessory (mouthpiece, mask, or nosepiece) from the nebulizer kit.

2. Disconnect the air tubing from the nebulizer.

3. Gently twist the inhalation top counterclockwise and lift to separate the nebulizer into two sections.

4. Remove the baffle.

5. Discard remaining medication in the medication cup.

WARNING

Always dispose of any remaining medication in the medication cup after each use. Use fresh medication each time you use the device.

6. Rinse all the parts of the nebulizer kit and the mouthpiece or nosepiece with hot tap water. You may also wash these parts in a dishwasher. Remove the parts after the wash and rinse cycle is completed. DO NOT wash the mask in a dishwasher.

CAUTION

Place the nebulizer pieces in a basket recommended for dishwasher use. Place the basket on the top shelf to avoid any damage to the nebulizer kit.

7. Rinse the mask with hot tap water.

8. Hand dry or air dry in a clean environment using a soft, clean, lint-free cloth.

9. Assemble the nebulizer and store the nebulizer kit in a dry, sealed bag.

UTION

The nebulizer kit should be replaced every 6 months.

DAILY DISINFECTING

You can disinfect daily by soaking the parts in a vinegar solution or using a commercially available medical disinfectant. If your physician or respiratory therapist specifies a different cleaning procedure follow their instructions.

Disinfect the nebulizer kit and the mask, nosepiece or mouthpiece after the last treatment of the day.

VINEGAR METHOD

1. Make a solution of 1 part white vinegar and 3 parts distilled water.

Make enough solution to submerge the parts.

2. Remove the inhalation accessory (mouthpiece, mask, or nosepiece)

from the nebulizer kit.

3. Disconnect the air tubing from the nebulizer.

4. Gently twist the inhalation top counterclockwise and lift to separate

the nebulizer into two sections.

5. Remove the baffle.

6. Wash all the parts of the nebulizer kit, the mouthpiece, nosepiece

or mask in warm water and a mild detergent. Rinse in hot tap water. You may also wash the nebulizer kit, mouthpiece or nosepiece in a dishwasher. DO NOT wash the mask in a dishwasher.

CAUTION

Place the nebulizer pieces in a basket recommended for dishwasher use. Place the basket on the top shelf to avoid any damage to the nebulizer kit.

7. Submerge the parts in the white vinegar and distilled water solution

for 30 minutes.

8. Remove the parts and discard the solution. Rinse the parts with hot

tap water.

DAILY DISINFECTING

9. Hand dry or air dry in a clean environment using a soft, clean,

lint-free cloth.

10. Assemble the nebulizer and store the nebulizer kit in a dry, sealed bag.

WARNING

Store the device and the components in a clean, safe location.

MEDICAL DISINFECTANT METHOD

Consult your physician or respiratory therapist regarding the use of medical disinfectant cleaners. Carefully follow the instructions supplied by the manufacturer of the medical disinfectant.

CHANGING THE AIR FILTER

Change the air filter every 60 days even if the air filter does not appear dirty. If the air filter appears dirty, or if water or medication has spilled on the air filter replace with a new air filter immediately.

1. Pull the air filter cover to remove from the front side of the compressor.

2. Remove the dirty filter with a small pointed object.

CAUTION

Do not attempt to wash or clean the air filter. Damp air filters can cause blockages. Do not substitute cotton or any other material for the air filter.

CAUTION

Wash the air filter cover regularly to prevent any blockage in the cover. Do not boil. Make sure the cover is dry before inserting the new air filter.

3. Insert a new air filter into the air filter cover.

CAUTION

Before inserting the new air filter make sure the air filter is clean and free of dust. Do not operate the device without the air filter. Use only the Omron air filter designed for this device.

4. Put the air filter cover back on the compressor.

CARING FOR THE DEVICE

Mild Detergent

To keep your device in the best condition and protect the unit from damage follow these directions:

CAUTION

Do not subject the compressor or any of the components to strong shocks, such as dropping on the floor.

CAUTION

Use only Omron authorized parts and accessories.

CLEANING THE COMPRESSOR

Clean the casing of the main unit by using a soft cloth moistened with water or a mild detergent. Do not use abrasive cleaners. Dry the casing immediately using a soft clean cloth.

WARNING

Do not immerse the compressor (main unit) in water or other liquid.

CAUTION

Unplug the power cord from the electrical outlet before cleaning the device.

CAUTION

Do not insert any object into the compressor.

STORING THE DEVICE

1. Put the nebulizer kit and the inhalation accessory (mouthpiece, nosepiece or mask) in a dry, sealed bag. Place the bag in the storage pocket of the carrying bag.

2. Coil the air tubing and place in the storage pocket.

3. Place the compressor in the carrying bag.

CAUTION

Do not wrap the power cord around the compressor (main unit).

CARING FOR THE DEVICE

4. Zipper the bag closed.

5. Store the device in a safe, clean location. Do not store the device in extreme hot or cold temperature, high humidity or in direct sunlight.

WARNING

Keep the device out of the reach of unsupervised infants and children. The device may contain small parts that can be swallowed.

CAUTION

Do not carry or leave the nebulizer with medication in the medication cup.

AUTHORIZED SERVICE

Contact Omron Healthcare customer service for warranty and repair services. There are no user serviceable parts. Unauthorized service will void the user warranty.

CAUTION

Do not disassemble or attempt to repair the device or components.

TROUBLESHOOTING TIPS

PROBLEM SOLUTION

No power on unit when the power switch is turned on.

No nebulization or low nebulization rate when the power is on.

The device is abnormally loud.

The device is very hot.

The device is not plugged into an electrical outlet.

No medication in the medication cup. Too much or too little medication in the medication cup.

The baffle is not placed in the medication cup or incorrectly positioned.

The nebulizer kit is not correctly assembled.

The nozzle is blocked.

The nebulizer kit is tilted at an incorrect angle.

The air tube is incorrectly attached.

The air tube is folded or damaged. The air tube is blocked.

The air filter is dirty.

The air filter cover is incorrectly attached.

The ventilation slots are blocked.

CAUSE

Turn the power switch off. Plug the power plug into an

electrical outlet. Turn the device on.

Add the correct amount of medication to the medication cup.

Make sure the baffle is correctly positioned over the nozzle in the medication cup.

Make sure the nebulizer kit is correctly assembled and the inhalation accessory is correctly attached.

Clean and disinfect the nebulizer kit to remove the blockage.

Hold the nebulizer kit correctly. Do not tilt the nebulizer kit so the angle of the kit is greater than 45 degrees.

Make sure the air tube is correctly attached to the compressor and the nebulizer kit.

Make sure the air tube is not folded, kinked or bent. Inspect the air tube for any damage. Replace the air tube if damaged.

Replace the air filter with a new clean air f

Attach the air filter cover correctly.

e sure the air f

Mak not blocked.

Do not block the ventilation slots located on the sides of the compressor. Do not cover the compressor with an cover during use. Place the device where the ventilation slots are not obstructed during use.

ilter.

ilter co

y type of

er is

WARRANTY

LIMITED WARRANTIES

Your Omron NE-C28 COMPAir®Nebulizer Compressor, excluding the nebulizer kit, inhalation accessories, air tube and air filters, is warranted to be free from defects in materials and workmanship appearing within 5 years from the date of purchase, when used in accordance with the instructions provided with your device. The above warranty extends only to the original retail purchaser.

We will, at our option, repair or replace without charge your Omron Nebulizer Compressor. Repair or replacement is our only responsibility and your only remedy under the above warranties.

To obtain warranty service contact Omron Healthcare's Customer Service by calling 1-800-634-4350 for the address of the repair location and the return shipping and handling fee. Information for warranty service is available on our website at www.omronhealthcare.com.

Enclose the Proof of Purchase. Include a letter, with your name, address, phone number, and description of the specific problem. Pack the product carefully to prevent damage in transit. Because of possible loss in transit, we recommend insuring the product with return receipt requested.

ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THE APPLICABLE WRITTEN WARRANTY ABOVE.

limitation may not apply to you.

OMRON SHALL NOT BE LIABLE FOR LOSS OF USE OR ANY OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT COSTS, EXPENSES OR DAMAGES.

not allow the exclusion or limitation of incidental or consequential damages, so the above exclusions may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state.

The abo incidental, special, or consequential damages of any nature. (Some countries do not allow the exclusion or limitation of incidental or consequential damages, so the above warranty may not apply to you.

Any implied warranties arising by the operation of law shall be limited in duration to the term of this warranty. (Some countries do not allow limitations on how long an implied warranty lasts, so the abo

This warranty gives you specific legal rights and you may have other rights which vary from country to country.

Some states do not allow limitations on how long an implied warranty lasts, so the above

Some states do

FOR CUSTOMER SERVICE (USA and Canada)

Visit our web site at: www.omronhealthcare.com Call toll free: 1-800-634-4350

LIMITED WARRANTIES (OUTSIDE OF THE USA AND CANADA)

ve warranty is complete and exclusive. The warrantor expressly disclaims liability for

e limitation may not apply to you)

FCC STATEMENT

Note:

POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only) This product has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. The product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the product does cause harmful interference to radio or television reception, which can be determined by turning the product on and off, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the product and the receiver.

• Connect the product into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for Canada only) This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus”, ICES-003 of the Canadian Department of Communications.

Cet appareil numérique respecte les limites de bruits radioeléctriques applicables aux appareils numériques de Clase B prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques”, ICES-003 édictée par le minister des Communications.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

SPECIFICATIONS

Model: NE-C28 Type: Compressor nebulizer Electrical: 120V 60Hz Power Consumption: 180VA Nebulizer Rate: 0.4 ml/min (without cap) Particle Size: *MMD approximately 5 µm (based on EN13544-1) Medication Cup Capacity: 7 ml (cc) max. Appropriate Medication 2 mL - 7 mL (cc)

Quantities: Operating Temperature/ +50°F to +104°F (+10°C to +40°C), 30% to 85% RH

Humidity: Storage Temperature/ –4°F to +140°F (–20°C to +60°C), 10% to 95% RH

Humidity: Weight: Approx. 67oz. (1.9kg) (compressor only) Dimensions: Approx. 6 3/4" (w)

(170 mm × 103mm × 182mm)

Contents: Compressor, Nebulizer Kit, Air Tube, Air Filter Cover,

Mouthpiece, 5 Replacement Filters, Child Mask, Carrying Bag, Instruction Manual printed in English, Spanish, User Registration Card.

UPC Code: 0 73796 45328 2 *MMD = Mass Median Diameter

Tested using malvern laser

NOTES:

• Subject to technical modification without prior notice.

• Please note that specifications may vary with medication type used. = Type B = Class II

• Do not use the device where it may be exposed to flammable gas.

• This unit confirms to EMC Standard IEC60601-1-2:2001. However, if it is used

together with other medical de

vices or electrical equipment, the operations of one of devices. Please follow any instructions in the manuals and use all devices correctly.

× 4 1/8" (h) × 7 1/8" (d)

y may influence the

58JN

COMPRESSOR NEBULIZER

ith respect to electric shock, f

mechanical hazards only in accordance with UL60601-1

ire and

NOTES

Manufactured By Omron Made in China

Distributed by:

Omron Healthcare, Inc.

1200 Lak Bannockburn, Illinois 60015 www.omronhealthcare.com

eside Dri

C28 INST Re

GUIDE DE L’UTILISATEUR

Nébuliseur à compresseur

MODÈLE NE-C28

Mise en g

ertu de la loi américaine, la v

En v

arde

n’est autorisée que sur ordonnance d’un médecin ou d’un praticien de la santé autorisé

ente de cet appareil

FRANÇAIS

TABLES DES MATIÈRES

Avant d’utiliser l’appareil

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Renseignements sur la sécurité

Utilisation de l’appareil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Risque de choc électrique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Entretien et entreposage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Familiarisez-vous avec l’appareil

Unité principale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Composants et pièces de rechange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Mode d’emploi

Préparation du nébuliseur pour l’utilisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Fixation du tube à air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Utilisation de l’appareil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Entretien

Nettoyage après chaque usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Désinfection quotidienne . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Changement du filtre à air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Entretien de l’appareil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Dépannage

Guide de dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Conformité FCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Spécifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Les illustrations montrées dans ce mode d’emploi sont des dessins et pourraient différer quelque peu de l’apparence réelle du produit.

+ 82 hidden pages
