Omron NE1A-SCPU01 - 2006, NE1A-SCPU02 - 2006, NE1A-SCPU01, NE1A-SCPU01-V1, NE1A-SCPU02 Operation Manual

OPERATION MANUAL

Safety Network Controller

DeviceNet Safety
NE1A Series:
NE1A-SCPU01(-V1)/-SCPU02

Cat. No. Z906-E2-03

NE1A Series Safety Network Controller:
NE1A-SCPU01(-V1)/-SCPU02
Operation Manual

Revised September 2006

iv

v

Notice:

OMRON products are manufactured for use according to proper procedures by a qualified operator
and only for the purposes described in this manual.

The following conventions are used to indicate and classify precautions in this manual. Always heed
the information provided with them. Failure to heed precautions can

result in injury to people or damage to property.

!WARNING Indicates a potentially hazardous situation which, if not avoided, will result in minor or

moderate injury, or may result in serious injury or death. Additionally, there may be signifi-

cant property damage.

OMRON Product References

All OMRON products are capitalized in this manual. The word "Unit" is also capitalized when it refers to
an OMRON product, regardless of whether or not it appears in the proper name of the product.

The abbreviation "PLC" means Programmable Controller. "PC" is used, however, in some Program­ming Device displays to mean Programmable Controller.

Visual Aids

The following headings appear in the left column of the manual to help you locate dif-ferent types of
information.

IMPORTANT Indicates important information on what to do or not to do to prevent failure to

op-eration, malfunction, or undesirable effects on product performance.

Note Indicates information of particular interest for efficient and convenient opera-

tionof the product.

1,2,3... 1. Indicates lists of one sort or another, such as procedures, checklists, etc.

Indicates general prohibitions for which there is no specific symbol.

Indicates general mandatory actions for which there is no specific symbol.

vi

Trademarks and Copyrights

DeviceNet and DeviceNet Safety are registered trademarks of the Open DeviceNet Vendors Associa­tion.

Other product names and company names in this manual are trademarks or regis-tered trademarks of
their respective companies.

 OMRON, 2005

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form, o

r

by any means, mechanical, electronic, photo-copying, recording, or otherwise, without the prior written permission o

f

OMRON.
No patent liability is assumed with respect to the use of th e information contained herein. Moreo v er, because OMRON is con-

stantly striving to improve its high-quality products, the information contained in this manual is subject to change without
notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no responsibility
for errors or omissions. Neither is any liability as-sumed for damages resulting from the use of the information contained in
this publica-tion.

vii

TABLE OF CONTENTS

PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

1 Intended Audience. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

2 General Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

3 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

4 Precautions for Safe Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

5 Additional Precautions According to UL 1604. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiii

6 Regulations and Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiv

7 Unit Versions of NE1A-series Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxv

SECTION 1
Overview of the NE1A-series Safety Network Controllers. 1

1-1 About NE1A-series Safety Network Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1-2 System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1-3 System Setup Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

SECTION 2

Specifications and Nomenclature . . . . . . . . . . . . . . . . . . . . . 17

2-1 Nomenclature and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2-2 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

SECTION 3

Installation and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3-1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

3-2 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

SECTION 4

DeviceNet Communications Functions. . . . . . . . . . . . . . . . . 51

4-1 Initial Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

4-2 Network Status Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

4-3 Remote I/O Allocations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

4-4 Safety Master Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

4-5 Safety Slave Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

4-6 Standard Slave Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 9

4-7 Explicit Message Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

SECTION 5

I/O Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

5-1 Common Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

5-2 Safety Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

5-3 Test Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 02

5-4 Safety Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

viii

TABLE OF CONTENTS

SECTION 6

Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

6-1 Outline of Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108

6-2 Function Block Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111

6-3 Function Block Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

6-4 Command Reference: Logic Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 17

6-5 Command Reference: Function Blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

SECTION 7

Other Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

7-1 Configuration Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

7-2 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

7-3 Access Control with Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

SECTION 8

Operating Modes and Power Supply Interruptions . . . . . . 181

8-1 NE1A-series Controller Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

8-2 Behavior for Power Supply Interruptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

SECTION 9
Remote I/O Communications Performance and

Local I/O Response Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

9-1 Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

9-2 Operational Flow and Cycle Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

9-3 I/O Refresh Cycle Time and Network Reaction Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

9-4 Reaction Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

SECTION 10

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

10-1 Error Categories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

10-2 Confirmation of Error State. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

10-3 Indicator/Display Status and Corrective Actions for Errors . . . . . . . . . . . . . . . . . . . . . . . . . 202

10-4 Error History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

10-5 Errors When Downloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212

10-6 Errors When Resetting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215

10-7 Errors When Changing Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216

10-8 Connection Status Tables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217

ix

TABLE OF CONTENTS

SECTION 11

Maintenance and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . 223

11-1 Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

11-2 NE1A-series Controller Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225

Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

x

TABLE OF CONTENTS

xi

About this Manual:

This manual describes the installation and operation of the NE1A-series Safety

Network Controllers.

Please read this manual carefully and be sure you understand the information provided before
attempting to install or operate the NE1A-series Controller. Be sure to read the precautions provided in
the following section.

Definition of NE1A-series Controllers

In this manual, the term "NE1A-series Controllers" refers to the NE1A-SCPU01 and NE1A-SCPU02
Safety Network Controllers.

The following manuals provide information on the DeviceNet and DeviceNet Safety.

DeviceNet Safety NE1A Series Safety Network Controller Operation Manual (this manual) (Z906)

This manual describes the specifications, functions, and usage of the NE1A-SCPU01 and NE1A­SCPU02.

DeviceNet Safety System Configuration Manual (Z905)

This manual explains how to configure the DeviceNet Safety system using the

Network Configurator.

DeviceNet Operation Manual (W267)

This manual describes the construction and connection of a DeviceNet network. It provides detailed
information on the installation and specifications of cables, connec-tors, and other peripheral equip­ment used in the network, and on the supply of com-munications power. Obtain this manual and gain a
firm understanding of its contents before using a DeviceNet system.

!WARNING Failure to read and understand the information provided in this manual may result in per-

sonal injury or death, damage to the product, or prod-uct failure. Please read each section
in its entirety and be sure you un-derstand the information provided in the section and
related sections before attempting any of the procedures or operations given.

xii

xiii

Read and Understand this Manual

Please read and understand this manual before using the product. Please consult your OMRON repre­sentative if you have any questions or comments.

Warranty and Limitations of Liability

WARRANTY

OMRON's exclusive warranty is that the products are free from defects in materials and workmanship for a
period of one year (or other period if specified) from date of sale by OMRON.

OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON­INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE
PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR
INTENDED USE. OMRON DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.

LIMITATIONS OF LIABILITY

OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAM-AGES,
LOSS OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS,
WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT
LIABILITY.

In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which
liability is asserted.

IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS
REGARDING THE PRODUCTS UNLESS OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS
WERE PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO
CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.

xiv

Application Considerations

SUITABILITY FOR USE

OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the
combination of products in the customer's application or use of the products.

At the customer's request, OMRON will provide applicable third party certification documents identify-ing
ratings and limitations of use that apply to the products. This information by itself is not sufficient for a
complete determination of the suitability of the products in combination with the end product, ma-chine,
system, or other application or use.

The following are some examples of applications for which particular attention must be given. This is not
intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses
listed may be suitable for the products:

• Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or
uses not described in this manual.

• Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical
equipment, amusement machines, vehicles, safety equipment, and installations subject to separate
industry or government regulations.

• Systems, machines, and equipment that could present a risk to life or property.

Please know and observe all prohibitions of use applicable to the products.

NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCTS ARE PROPERLY RATED AND IN­STALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.

PROGRAMMABLE PRODUCTS

OMRON shall not be responsible for the user's programming of a programmable product, or any con­sequence thereof.

xv

Disclaimers

CHANGE IN SPECIFICATIONS

Product specifications and accessories may be changed at any time based on improvements and other
reasons.

It is our practice to change model numbers when published ratings or features are changed, or when
significant construction changes are made. However, some specifications of the products may be changed
without any notice. When in doubt, special model numbers may be assigned to fix or estab-lish key
specifications for your application on your request. Please consult with your OMRON repre-sentative at any
time to confirm actual specifications of purchased products.

DIMENSIONS AND WEIGHTS

Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when
tolerances are shown.

PERFORMANCE DATA

Performance data given in this manual is provided as a guide for the user in determining suitability and does
not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must
correlate it to actual application requirements. Actual performance is subject to the OMRON War-ranty and
Limitations of Liability.

ERRORS AND OMISSIONS

The information in this manual has been carefully checked and is believed to be accurate; however, no
responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.

xvi

xvii

PRECAUTIONS

1 Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

2 General Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

3 Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

4 Precautions for Safe Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

5 Additional Precautions According to UL 1604. . . . . . . . . . . . . . . . . . . . . . . . xxiii

6 Regulations and Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiv

7 Unit Versions of NE1A-series Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . xxv

xviii

Intended Audience 1

1 Intended Audience

This manual is intended for the following personnel, who must have knowl­edge of electrical systems (an electrical engineer or the equivalent).

• Personnel in charge of introducing FA and safety systems into production
facilities

• Personnel in charge of designing FA and safety systems

• Personnel in charge of managing FA facilities

• Personnel who have the qualifications, authority, and obligation to provide
safety during each of the following product phases: mechanical design,
installation, opera-tion, maintenance, and disposal

2 General Precautions

The user must operate the product according to the performance specifica­tions de-scribed in the operation manuals.

Before using the product under conditions which are not described in the

manual or applying the product to nuclear control systems, railroad systems,

aviation systems, vehicles, combustion systems, medical equipment, amuse­ment machines, safety equipment, and other systems, machines, and equip­ment that may have a serious influence on lives and property if used
improperly, consult your OMRON representative.

Make sure that the ratings and performance characteristics of the product are

sufficient for the systems, machines, and equipment, and be sure to provide

the systems, machines, and equipment with double safety mechanisms.

This manual provides information for programming and operating the Unit. Be

sure to read this manual before attempting to use the Unit and keep this man­ual close at hand for reference during operation.

!WARNING It is extremely important that a PLC and all PLC Units be used for the speci-

fied purpose and under the specified conditions, especially in applications that
can directly or indirectly affect human life. You must consult with your OMRON
representative before applying a PLC System to the above-mentioned appli­cations

!WARNING This is the Operation Manual for the NE1A-series Safety Network Controllers.

Heed the following items during system construction to ensure that safety­related components are configured in a manner that allows the system func­tions to sufficiently operate.

• Risk Assessment

The proper use of the safety device described in this Operation Manual as
it relates to installation conditions and mechanical performance and func­tions is a prerequisite for its use. When selecting or using this safety de­vice, risk assessment must be conducted with the aim of identifying
potential danger factors in equipment or facilities in which the safety device
is to be applied, during the devel-opment stage of the equipment or facili­ties. Suitable safety devices must be selected under the guid-ance of a suf­ficient risk assessment system. An insufficient risk assessment system
may lead to the selection of unsuitable safety devices.

xix

General Precautions 2

• Typical related international standards: ISO 14121, Safety of Machin­ery -- Princi-ples of Risk Assessment

• Safety Measures

When using this safety device to build systems containing safety-related
components for equipment or facilities, the system must be designed with
the full understanding of and conformance to international standards, such
as those listed below, and/or standards in related industries.

• Typical related international standards: ISO/DIS 12100, Safety of Ma­chinery -- Basic Concepts and General Principles for DesignIEC
61508, Safety Standard for Safety Instrumented Systems (Functional
Safety of Electrical/Electronic/Programmable Electronic Safety-related
Systems)

• Role of Safety Device

This safety device is provided with safety functions and mechanisms as
stipulated in relevant standards, but suitable designs must be used to allow
these functions and mechanisms to operate prop-erly inside system con­structions containing safety-related components. Build systems that en­able these functions and mechanisms to perform properly, based on a full
understanding of their opera-tion.

• Typical related international standards: ISO 14119, Safety of Machin­ery -- Inter-locking Devices Associated with Guards -- Principles of De­sign and Selection

• Installation of Safety Device

The construction and installation of systems with safety-related compo­nents for equipment or facilities must be performed by technicians who
have received suitable training.

• Typical related international standards: ISO/DIS 12100, Safety of Ma­chinery -- Basic Concepts and General Principles for DesignIEC
61508, Safety Standard for Safety Instrumented Systems (Functional
Safety of Electrical/Electronic/Programmable Electronic Safety-related
Systems)

• Complying with Laws and Regulations

This safety device conforms to the relevant regulations and standards, but
make sure that it is used in compliance with local regulations and stan­dards for the equipment or facilities in which it is applied.

• Typical related international standards: IEC 60204, Safety of Machin­ery -- Electrical Equipment of Machines

• Observing Precautions for Use

When putting the selected safety device to actual use, heed the specifica­tions and precautions in this Operation Manual and those in the Instruction
Manual that comes with the product. Using the product in a manner that
deviates from these specifications and precautions will lead to unexpected
failures in equipment or devices, and to damages that result from such fail­ures, due to insufficient operating functions in safety-related components.

• Moving or Transferring Devices or Equipment

When moving or transferring devices or equipment, be sure to include this
Operation Manual to en-sure that the person to whom the device or equip­ment is being moved or transferred will be able to operate it properly.

xx

General Precautions 2

• Typical related international standards: ISO/DIS 12100 ISO, Safety of
Machinery -- Basic Concepts and General Principles for Design IEC
61508, Safety Standard for Safety Instrumented Systems (Functional
Safety of Electrical/ Electronic/ Pro-grammable Electronic Safety-relat­ed Systems)

xxi

Safety Precautions 3

3 Safety Precautions

!WARNING

Serious injury may possibly occur due to loss of required safety functions. Do
not use the NE1A-series Controller's test outputs as safety outputs.

Serious injury may possibly occur due to loss of required safety functions. Do
not use DeviceNet standard I/O data or explicit message data as safety data.

Serious injury may possibly occur due to loss of required safety functions. Do
not use indicators or 7-segment displa y on the NE1A-series Contr oller for safety
op-erations.

Serious injury may possibly occur due to breakdown of safety outputs or test
outputs. Do not connect loads beyond the rated value to the safety outputs and
test outputs.

Serious injury may possibly occur due to loss of required safety funct ions. Wire
the NE1A-series Controller pr op erly so that t he 24-VDC li ne does NOT touch the
out-puts accidentally or unintentionally.

Serious injury may possibly occur due to loss of required safety functions.
Ground the 0-V line of the power supply for external output devices so that the
devices do NOT turn ON when the safety output line or the test output line is
grounded.

Serious injury may possibly occur due to loss of required safety functions.
Clear previous configuration data before connecting the devices to the netw ork .

Serious injury may possibly occur due to loss of required safety functions. Set
suitable node addresses and a suitable baud rate before con necting the devices
to the network.

Serious injury may possibly occur due to loss of required safety functions. Per­form user testing and confirm that all of the device configuration data and oper­ation is correct before starting system operation.

Serious injury may possibly occur due to loss of required safety functions.
When replacing a device, configure the replacement devi ce suitabl y and confirm
that it operate correctly.

Serious injury may possibly occur due to loss of required safety functions. Use
appropriate components or devices according to the requirements given in the
following table.

Control device Requirements

Emergency stop switch Use approved devices with a direct opening mechanism compliant with IEC/

EN 60947-5-1.

Door interlocking switch or
limit switch

Use approved devices with a direct opening mechanism compliant with IEC/
EN 60947-5-1 and capable of switching micro-loads of 4 mA at 24 VDC.

Safety sensor Use approved devices compliant with the relevant product standards, regula-

tions, and rules in the country where they are used.

Relay with forcibly guided
contacts

Use approved devices with forcibly guided contacts compliant with EN

50205. For feedback signals, use devices with contacts capable of switching
micro-loads of 4 mA at 24 VDC.

xxii

Precautions for Safe Use 4

4 Precautions for Safe Use

■Handling with Care

Do not drop the NE1A-series Controller or subject it to excessive vibration or
me-chanical shock. The NE1A-series Controller may be damaged and may
not function properly.

■Installation and Storage Environment

Do not use or store the NE1A-series Controller in any of the following loca­tions:

• Locations subject to direct sunlight

• Locations subject to temperatures or humidity outside the range specified
in the specifications

• Locations subject to condensation as the result of severe changes in tem­perature

• Locations subject to corrosive or flammable gases

• Locations subject to dust (especially iron dust) or salts

• Locations subject to water, oil, or chemicals

• Locations subject to shock or vibration

Take appropriate and sufficient measures when installing systems in the fol­lowing locations. Inappropriate and insufficient measures may result in mal­function.

• Locations subject to static electricity or other forms of noise

• Locations subject to strong electromagnetic fields

• Locations subject to possible exposure to radioactivity

• Locations close to power supplies

■Installation and Mounting

• Use the NE1A-series Controller within an enclosure with IP54 protection
or higher according to IEC/EN 60529.

• Use DIN rail (TH35-7.5/TH35-15 according to IEC 60715) to install the
NE1A-series Controller into the control panel. Mount the NE1A-Series
Controller to the DIN rail using PFP-M End Plates (not included with the
NE1A-series Controller) to prevent it falling off the DIN rail because of
vibration.

• Space must be provided around the NE1A-series Controller, at least 5
mm from its side and at least 50 mm from its top and bottom surfaces, for
ventilation and wiring.

Contactor Use contactors with a forcibly guided mechanism and monitor the auxiliary

NC contact to detect contactor failures. For feedback signals, use devices
with contacts capable of switching micro-loads of 4 mA at 24 VDC.

Other devices Evaluate whether devices used are appropriate to satisfy the requirements of

the safety category level.

Control device Requirements

xxiii

Additional Precautions According to UL 1604 5

■Installation and Wiring

• Use the following to wire external I/O devices to the NE1A-series Control­ler.

• Disconnect the NE1A-series Controller from the power supply before
starting wiring. Devices connected to the NE1A-series Controller may
operate unexpectedly.

• Properly apply the specified voltage to the NE1A-series Controller inputs.
Applying an inappropriate DC voltage or any AC voltage will cause the
NE1A-series Control-ler to fail.

• Be sure to separate the communications cables and I/O cables from near
high-voltage/high-current lines.

• Be cautious not to get your fingers caught when attaching connectors to
the plugs on the NE1A-series Controller.

• Tighten the DeviceNet connector screws correctly (0.25 to 0.3 N·m).

• Incorrect wiring may lead to loss of safety functions. Wire conductors cor­rectly and verify the operation of the NE1A-series Controller before using
the system in which the NE1A-series Controller is incorporated.

• After wiring is completed, be sure to remove label for wire clipping preven­tion on the NE1A-series Controller to enable heat to escape or proper
cooling.

■Power Supply Selection

Use a DC power supply satisfying the following requirements.

• The secondary circuits of the DC power supply must be isolated from the
primary circuit by double insulation or reinforced insulation.

• The DC power supply must satisfy the requirements for class 2 circuits or
limited voltage/current circuits given in UL 508.

• The output hold time must be 20 ms or longer.

■Periodic Inspections and Maintenance

• Disconnect the NE1A-series Controller from the power supply before
replacing the Controller. Devices connected to the NE1A-series Controller
may operate unex-pectedly.

• Do not disassemble, repair, or modify the NE1A-series Controller. Doing
so may lead to loss of safety functions.

■Disposal

• Be cautions not to injure yourself when dismantling the NE1A-series Con­troller.

5 Additional Precautions According to UL 1604

The NE1A-series Controller is suitable for use in Class I, Div. 2, Group A, B,
C, D or Non-Hazardous Location Only.

WARNING - Explosion Hazard - Substitution of Components May Impair Suit­ability For Class I, Div. 2.

Solid wire

0.2 to 2.5 mm

2

(AWG 24 to AWG 12)

Stranded (flexi­ble) wire

0.34 to 1.5 mm

2

(AWG 22 to AWG 16)
Stranded wires should be prepared by attaching insulated bar
terminals (DIN 46228-4 standard compatible) to the ends before
connecting them.

xxiv

Regulations and Standards 6

WARNING - Explosion Hazard - Do Not Disconnect Equipment Unless Power
Has Been Switched OFF or the Area Is Known To Be Non-Hazardous.

WARNING - Explosion Hazard - Do Not Disconnect USB Connector Unless
Power Has Been Switched OFF or the Area Is Known To Be Non-Hazardous.

6 Regulations and Standards

The NE1A-SCPU01 has been certified as follows:

As of July 2006, applications have been submitted for the following certifica-

tions for the NE1A-SCPU01-V1 and NE1A-SCPU02 and are still pending.

Certifying organization Standards

TUV Rheinland EN954-1:1996, EN60204-1:1997, EN61000-6-2:2001,

EN61000-6-4:2001, EN418:1992, IEC61508 part1-7/12.98-05.00,
IEC61131-2:2003,NFPA 79-2002, ANSI RIA15.06-1999,
ANSI B11.19-2003

UL UL1998, UL508, UL1604, NFPA79, IEC61508, CSA22.2 No142,

CSA22.2 No213

Certifying organization Standards

TUV Rheinland EN954-1:1996, EN60204-1:1997, EN61000-6-2:2001,

EN61000-6-4:2001, EN418:1992, IEC61508 part1-7/12.98-05.00,
IEC61131-2:2003,NFPA 79-2002, ANSI RIA15.06-1999,
ANSI B11.19-2003

UL UL1998, UL508, UL1604, NFPA79, IEC61508, CSA22.2 No142,

CSA22.2 No213

xxv

Unit Versions of NE1A-series Controllers 7

7 Unit Versions of NE1A-series Controllers

Unit Versions

A "unit version" has been introduced to manage NEA1-series Safety Network
Control-lers according to differences in functionality accompanying Unit
upgrades.

1. Notation of Unit Versions on Products

The unit version (Ver. @.@) is listed near the lot number on the nameplate
of the prod-ucts for which unit versions are being managed, as shown be­low.

• Controllers that do not have a unit version listed on the label are called
Pre-Ver. 1.0 Controllers.

Product Nameplate

The unit version is listed here.
(Example: Ver. 1.0)

xxvi

Unit Versions of NE1A-series Controllers 7

2. Checking the Unit Version with Support Software
The following procedure can be used to check the unit version from the
Network Configurator version 1.6 or higher.

a. Upload the configuration information from the system. The device

icons will be dis-played, as shown in the following diagram.

b. Right-click on the Controller's icon to display the popup menu shown

below.
Select Property from the menu.

xxvii

Unit Versions of NE1A-series Controllers 7

c. The Controller's Property Window will be displayed.

The device name and revision are given in the Property Window. The NE1A­series Controllers supported by version 1.6@ are listed in the following table.

3. Checking the Unit Version with the Unit Version Label

The following unit version labels are provided with the Controller.

These labels can be affixed to the front of earlier Controllers to differentiate
between Controllers with different unit versions.

Model Device name Revision Unit version

NE1A-SCPU01 NE1A-SCPU01 1.01 Pre-Ver. 1.0

NE1A-SCPU01-V1 NE1A-SCPU01-V1 1.01 1.0

NE1A-SCPU02 NE1A-SCPU02 1.01 1.0

xxviii

Unit Versions of NE1A-series Controllers 7

Function Support by Unit Version

Model NE1A-SCPU01 NE1A-

SCPU01-V1

NE1A-SCPU02

Unit version

Function

Pre-Ver. 1.0 Ver. 1.0 Ver. 1.0

Logic operations

Maximum program size
(total number of function blocks)

128 254 254

Added function blocks

• RS Flip-flop

• Multi Connector

•Muting

• Enable Switch

• Pulse Generator

• Counter

•Comparator

--- Supported Supported

Selection of the rising edge of the reset
condition for the Reset and Restart
Function Blocks

--- Supported Supported

Use local I/O status in logic program­ming

--- Supported Supported

Use the Unit's general status in logic
programming

--- Supported Supported

I/O control functions

Contact Operation Counter --- Supported Supported

Total ON Time Monitor --- Supported Supported

DeviceNet communications functions

Number of safety I/O connections at the
Safety Master

16 32 32

Selection of operation of safety I/O
communications after a communica­tions error

--- Supported Supported

Add local output monitoring to send
data during Slave operation.

--- Supported Supported

Add local input monitoring to send data
during Slave operation.

--- Supported Supported

Functions supporting system startup and error recovery

Saving non-fatal error history in non­volatile memory

--- Supported Supported

Added function block errors to error his­tory.

--- Supported Supported

xxix

Unit Versions of NE1A-series Controllers 7

Unit Versions and Programming Devices

Network Configurator version 1.6 or higher must be used when using a Safety
Logic Controller with unit version 1.0. The following table shows the relation­ship between unit versions and Network Configurator versions.

NE1A-series Controller Upgrade Procedure

Functionality has been expanded in various ways for the NE1A-SCPU01-V1
and NE1A-SCPU02 in comparison to the NE1A-SCPU01. When changing
from a NE1A-SCPU01 to a NE1A-SCPU01-V1 or NE1A-SCPU02 in a system
that uses a NE1A-SCPU01, the previous configuration data can be used by
converting it from configura-tion data for the NE1A-SCPU01 to configuration
data for the NE1A-SCPU01-V1 or NE1A-SCPU02.

Use the following procedure to create configuration data for the NE1A­SCPU01-V1 or NE1A-SCPU02 from configuration data for the NE1A­SCPU01.

1. Reading Configuration Data

Use the following procedure to read the configuration data with the Network
Configu-rator (version 1.6).

• Read the saved configuration data.

• Use network uploading to read configuration data from devices on the
network.

The following screen will be displayed when reading has been completed.

Model number Network Configurator

Ver. 1.3@ Ver. 1.5@ Ver. 1.6@

NE1A-SCPU01
Pre-Ver. 1.0

Can be used. Can be used. Can be used.

NE1A-SCPU01-V1 with unit
version 1.0

Cannot be used. Cannot be used. Can be used.

NE1A-SCPU02 with unit
version 1.0

Cannot be used. Cannot be used. Can be used.

xxx

Unit Versions of NE1A-series Controllers 7

2. Converting Configuration Data

In the data read with the Network Configurator, right-click the NE1A-SCPU01
that is to be changed to the NE1A-SCPU01-V1 or NE1A-SCPU02 and select

Change Device Type from the pop-up menu.

Next, select the new device in the New Device and press the OK Button.

After a moment, the model number will change and the configuration data for
the new device will be completed.

xxxi

Unit Versions of NE1A-series Controllers 7

3. Expansion Configuration

When the data configuration is converted, all expanded functionality will be
set to the default values. Set the configuration for all expanded functionality to
be used.

4. Re-registering Safety Slaves in the Safety Master

If the device for which configuration data has been converted is a Safety
Slave, it must be re-registered in the Safety Master. First, select the Slave in
the Safety Connections Tab Page of the Safety Master and unregister it.
