Page 1
DIGITAL CAMERA
Instruction Manual
Table of Contents
Quick task index
Preparing the camera and flow of
1.
operations
2. Shooting
3. Viewing photographs and movies
4. Basic operations
5. Using shooting options
6. Menu functions
Connecting the camera to a
7.
smartphone
Connecting the camera to a
8.
computer and a printer
9. Battery, battery charger, and card
10. Interchangeable lenses
11. Using separately sold accessories
12. Information
13. SAFETY PRECAUTIONS
Thank you for purchasing an O lympus digital camera. Before you star t to use your new camera,
please read these instructions caref ully to enj oy optimum performance and a longer servic e life.
Keep this manual in a safe place for future reference.
We recommend that you take test shots to get accustomed to your camera before taking impor tant
photographs.
The screen and camera illustrations shown in this manual were produc ed during the development
stages and may dif fer fro m the actual product.
If there are additions an d/or modific ations of funct ions due to firmware update for the c amera, the
content s will differ. For the latest information, please visit the Olympus website.
Page 2
This notice concerns the supplied fl ash unit and is chiefl y directed to users in
North America.
Information for Your Safety
IMPORTANT SAFETY
INSTRUCTIONS
When using your photographic equipment, basic safety precautions should always be
followed, including the following:
• Read and understand all instructions before using.
• Close supervision is necessary when any fl ash is used by or near children. Do not leave
fl ash unattended while in use.
• Care must be taken as burns can occur from touching hot parts.
• Do not operate if the fl ash has been dropped or damaged - until it has been examined by
qualifi ed service personnel.
• Let fl ash cool completely before putting away.
• To reduce the risk of electric shock, do not immerse this fl ash in water or other liquids.
• To reduce the risk of electric shock, do not disassemble this fl ash, but take it to qualifi ed
service personnel when service or repair work is required. Incorrect reassembly can
cause electric shock when the fl ash is used subsequently.
• The use of an accessory attachment not recommended by the manufacturer may cause a
risk of fi re, electric shock, or injury to persons.
SAVE THESE INSTRUCTIONS
Indications used in this manual
The following symbols are used throughout this manual.
Important information on factors which may lead to a malfunction
or operational problems. Also warns of operations that should be
absolutely avoided.
Points to note when using the camera.
Useful information and hints that will help you get the most out of
your camera.
Reference pages describing details or related information.
2
EN
Cautions
Notes
$
Tips
%
g
Page 3
Table of Contents
Quick task index 7
Unpack the box contents .............9
Preparing the camera and fl ow
of operations 10
Names of parts ...........................10
Charging and inserting the
battery .........................................12
Inserting the card .......................13
Removing the card ...................13
Attaching a lens to the
camera .........................................14
Power on .....................................15
Setting the date/time ..................16
Selecting a shooting mode ........17
Shooting 18
Shooting still pictures................18
Self-portraits .............................19
Recording movies .....................20
Using the touch screen ..............22
Selecting a focusing method ....22
Using the wireless LAN
function .....................................23
Setting shooting functions ........24
Using live guides ......................24
Viewing photographs and
movies 26
Viewing photographs and
movies .........................................26
Index display/Calendar
display ......................................26
Viewing still images ..................27
Watching movies ......................27
Volume......................................27
Protecting images .....................27
Erasing images .........................28
Setting a transfer order on
images ([Share Order]) .............28
Selecting images
([Share Order Selected],
[0], [Erase Selected]) ...........28
Using the touch screen ..............29
Selecting and protecting
images ......................................29
Basic operations 30
Information displays while
shooting ......................................30
Monitor display when
shooting ....................................30
Switching the information
display ......................................31
Using the shooting modes ........32
“Point-and-shoot” photography
(P program mode) ....................32
Choosing aperture
(A aperture-priority mode) .......33
Choosing shutter speed
(S shutter-priority mode) ..........34
Choosing aperture and shutter
speed (M manual mode) ..........35
Comparative bright composites
(live composite photography) ...36
Using movie mode
Adding effects to a movie
[Movie Effect] ............................37
Using PHOTO STORY .............39
Shooting in scene mode ...........42
Using art fi lters..........................44
Commonly used shooting
options ........................................46
Controlling exposure
(exposure compensation) .........46
(n) ............37
Table of Contents
3
EN
Page 4
Changing the brightness of
highlights and shadows ............46
Choosing a focus target
Table of Contents
(AF Area) ..................................47
Setting the AF target .................47
Face priority AF/
pupil detection AF .....................48
Zoom frame AF/zoom AF..........49
Information display during
playback ......................................50
Playback image information .....50
Switching the information
display ......................................51
Changing the playback
information display method.......52
Manipulating playback
images ......................................53
Using shooting options 56
Adjusting settings while
shooting ......................................56
Reducing camera shake
(image stabilizer) ......................57
Adjusting color
(white balance) .........................58
Processing options
(picture mode) ..........................60
Sequential shooting/
using the self timer ...................61
Setting the image aspect ..........62
Adding effects to a movie .........62
Image quality (record mode).....63
Using a fl ash
(fl ash photography)...................65
Adjusting fl ash output
(fl ash intensity control)..............68
Choosing how the camera
measures brightness
(metering) .................................68
Choosing a focus mode
(AF mode).................................69
ISO sensitivity ...........................70
4
EN
Movie sound options
(recording sound with movies)..70
Menu functions 71
Basic menu operations ..............71
Using Shooting Menu 1/
Shooting Menu 2 ........................72
Formatting the card
(Card Setup) .............................72
Deleting all images
(Card Setup) .............................72
Returning to default settings
(Reset) ......................................73
Registering Favorites settings
(Myset)......................................73
Processing options
(Picture Mode) ..........................74
Image quality (K) ...................75
Setting the self timer
(j/Y) .....................................75
Varying settings over a series of
photographs (bracketing)..........76
Taking HDR (High Dynamic
Range) images .........................78
Recording multiple exposures
in a single image
(multiple exposure) ...................79
Shooting automatically with a
fi xed interval
(time lapse shooting) ................80
Wireless remote control fl ash
photography..............................81
Digital Zoom
(Digital Tele-converter) .............81
Using the playback menu ..........81
Displaying images rotated
(R) ..........................................81
Editing still images ....................82
Canceling all protections ..........83
Using the setup menu ................84
X (Date/time setting) ...............84
W (Changing the display
language)..................................84
Page 5
i (Monitor brightness
adjustment) ...............................84
Rec View ..................................84
Wi-Fi Settings ...........................84
c/#
Menu Display ..................84
Firmware...................................84
Using the custom menus ...........85
R AF/MF ..................................85
S Button/Dial ...........................86
T Release/j .........................86
U Disp/8/PC ..........................87
V Exp/p/ISO ..........................88
W # Custom ............................89
X K/Color/WB .......................90
Y Record/Erase .......................91
Z Movie ...................................92
b
K Utility .............................. 92
AEL/AFL ...................................93
MF Assist ..................................93
Button Function ........................94
Viewing camera images on
TV .............................................96
Choosing the control panel
displays.....................................97
Adding information displays......99
Shutter speeds when the fl ash
fi res automatically ...................100
Accessory Port Menu ...............101
Using OLYMPUS PENPAL .....101
A OLYMPUS PENPAL
Share ......................................102
B OLYMPUS PENPAL
Album .....................................103
C Electronic Viewfi nder .........103
Connecting the camera to a
smartphone 104
Connecting to a smartphone ...105
Transferring images to a
smartphone ...............................105
Shooting remotely with a
smartphone ...............................106
Adding position information to
images .......................................106
Setting up your camera for
wireless LAN connection
(Wi-Fi settings) .........................107
Connecting the camera to a
computer and a printer 108
Installing OLYMPUS Viewer 3 ..108
Copying pictures to a computer
without OLYMPUS Viewer 3 .....110
Direct printing (PictBridge) .....111
Easy printing ........................... 111
Custom printing ......................112
Print reservation (DPOF) .........113
Creating a print order.............. 113
Removing all or selected pictures
from the print order .................114
Battery, battery charger, and
card 115
Battery and charger .................115
Using your charger abroad .....115
Usable cards .............................116
Record mode and fi le size/number
of storable still pictures ........... 117
Interchangeable lenses 118
M.ZUIKO DIGITAL lens
specifi cations ..........................118
Using separately sold
accessories 122
Electronic Viewfi nder (VF-4) ....122
External fl ash units designated
for use with this camera ..........124
Wireless remote control fl ash
photography............................124
Table of Contents
5
EN
Page 6
Other external fl ash units ........126
Principal Accessories ..............127
Table of Contents
System chart .............................128
Information 130
Shooting tips and
information ................................130
Error codes ...............................132
Cleaning and storing the
camera .......................................134
Cleaning the camera ..............134
Storage ...................................134
Cleaning and checking the
image pickup device ...............134
Pixel Mapping - Checking the
image processing functions ....135
Menu directory ..........................136
Specifi cations ...........................141
SAFETY PRECAUTIONS 144
SAFETY PRECAUTIONS ..........144
Index 154
6
EN
Page 7
Quick task index
Shooting
Taking pictures with automatic settings
Easy photography with special effects
Choosing an aspect ratio
Quickly matching settings to the scene
Pro-level photography made simple
Adjusting the brightness of a photograph
Taking pictures with a blurred background
Taking pictures that stop the subject in
motion or convey a sense of motion
Taking pictures with the correct color
Processing pictures to match the subject/
Taking monotone pictures
When the camera will not focus on your
subject/Focusing on one area
Focusing on a small spot in the frame/
confi rming focus before shooting
Recomposing photographs after focusing
Taking photos without the fl ash
Reducing camera shake
Taking pictures of a subject against
backlight
Photographing fi reworks
Taking pictures without white subjects
appearing too white or black subjects
appearing too dark
Reducing image noise (mottling)
Optimizing the monitor/
adjusting monitor hue
g
iAUTO (A)
Art fi lter (ART)44
Aspect ratio 62
Scene mode (SCN)42
Live Guide 24
Exposure compensation 46
Live Guide 24
Aperture priority shooting 33
Live Guide 24
Shutter priority shooting 34
Scene mode (SCN)42
White balance 58
One-touch white balance 59
Picture Mode 60
Art fi lter (ART)44
Using the touch screen 22
AF Area 47
Zoom frame AF/zoom AF 49
Zoom frame AF/zoom AF 49
C-AF+TR (AF tracking) 69
DIS Mode/ISO 42/70
Image Stabilizer/Anti-Shock z
Self-timer 61
Remote cable 127
Flash shooting 65
Gradation (Picture Mode) 74
Bulb/time photography 35
Live composite photography 36
Scene mode (SCN)42
Gradation (Picture Mode) 74
Histogram/
Exposure compensation
Highlight & Shadow Control 46
Noise Reduct. 88
Monitor brightness
adjustment/Live View Boost
17
57/89
31/46
84/87
Quick task index
EN
7
Page 8
Checking set effect before taking a
Checking horizontal or vertical orientation
Quick task index
before shooting
Shooting with deliberate composition
Zooming in on photos to check focus
Self-portraits
Sequential shooting Sequential shooting 61
Extending the useful life of the battery
Increasing the number of pictures that
can be taken
Shooting remotely with a smartphone
(wireless LAN function)
Preview function 94
Test Picture 94
Level gauge 31
Displayed Grid 87
Autoq (Rec View)
mode2 (q Close Up Mode)
Self-timer 61
Scene mode (SCN)42
Sleep 88
Record mode 63
Shooting remotely with a
smartphone
84
88
106
Playback/Retouch
Viewing images on a TV
Viewing slideshows with background
music
Brightening shadows
Dealing with red-eye
Printing made easy
Commercial prints
Sharing images easily
Transferring images to a smartphone
(wireless LAN function)
Adding location data to images (wireless
LAN function)
HDMI/Video Out 87
Playback on TV 96
Slideshow 55
Shadow Adj (JPEG Edit) 82
Redeye Fix (JPEG Edit) 82
Direct printing 111
Creating a print order 113
OLYMPUS PENPAL 101
Transferring images to a
smartphone
Adding location data to images
Camera Settings
Synchronizing the date and time Setting the date/time 16
Restoring default settings
Saving the settings
Changing the menu display language
Turning off the auto focus sound
8
EN
Reset 73
Myset 73
W
8 (Beep sound)
g
105
106
g
84
88
Page 9
Unpack the box contents
The following items are included with the camera.
If anything is missing or damaged, contact the dealer from whom you purchased the
camera.
Unpack the box contents
Camera Body cap Strap USB cable
• Flash case
• Computer software CD-ROM
• Instruction manual
• Warranty card
Attaching the strap
1
3
Flash
FL-LM1
Lithium ion battery
BLS-50
2
CB-USB6
Lithium ion charger
BCS-5
• Attach the strap on the other side in the same way.
• Lastly, pull the strap fi rmly, making sure that it is fastened securely.
EN
9
Page 10
1
Preparing the camera and fl ow of
operations
1
Preparing the camera and fl ow of operations
Names of parts
1
2
3
4
5
6
7
f
c
d
e
1 Mode dial ........................................P. 17
2 Shutter button .................................P. 18
3 ON/OFF button ..............................P. 15
4 Control dial* P ...............................P. 26
5 Strap eyelet.......................................P. 9
6 Lens attachment mark ....................P. 14
7 Mount (Remove the body cap before
attaching the lens.)
8 Hot shoe cover
9 Stereo microphone .............P. 54, 70, 83
0 Self-timer lamp/AF illuminator
...............................................P. 61/P. 85
* In this manual, the P icon represent operations performed using the control dial.
a Lens release button ........................P. 14
b Lens lock pin
c Tripod socket
d Battery/card compartment lock .......P. 12
e Battery/card compartment cover.....P. 12
f Connector cover
g Multi-connector ............... P. 96, 108, 111
h HDMI connector (Type D) ...............P. 96
i Card slot .........................................P. 13
8
9
0
5
a
b
g
h
i
10
EN
Page 11
1
2
3
4
5
6
7
8
9
0
b
c
a
1
Preparing the camera and fl ow of operations
F (Up) / F (Exposure compensation)
H (Left) / P (AF
target) button (P. 47)
Q button (P. 56, 71)
1 Speaker
2 Monitor ....................P. 15, 22, 29, 31, 50
3 Accessory port ......................P. 101, 140
4 Hot shoe .......................................P. 124
5 G/Fn button ..................................P. 24
6 U button ...................................P. 38, 49
7 R (Movie)/H button ...........P. 20, 28, 37
* In this manual, the FGHI icons represent operations performed using the arrow
pad.
button (P. 46)
I (Right) /# (Flash)
button (P. 65)
G (Down) / jY
(Sequential shooting/Self-timer)
button (P. 61)
8 MENU button .................................P. 71
9 INFO (Information display) button
........................................................P. 31
0 Q button ..................................P. 56, 71
a Arrow pad* ......................................P. 26
b q (Playback) button ................P. 26, 52
c D (Erase) button ............................P. 28
EN
11
Page 12
Charging and inserting the battery
Charging the battery.
1
1
Preparing the camera and fl ow of operations
Charging indicator
Charging in
progress
Charging
complete
Charging error
(Charging time: Up to
approximately 3 hours 30 minutes)
Cautions
• Unplug the charger when
charging is complete.
Opening the battery/card
2
compartment cover.
Loading the battery.
3
Lights orange
Off
Blinks orange
Charging
indicator
3
Lithium ion
charger
Battery/card
compartment lock
1
AC cable
Direction indicating
mark (S)
Lithium ion battery
AC wall outlet
2
Battery/card
compartment cover
2
1
Direction indicating
Removing the battery
Turn off the camera before opening or closing the
battery/card compartment cover. To remove the battery,
fi rst push the battery lock knob in the direction of the
arrow and then remove.
Cautions
• Contact an authorized distributor or service center if you are unable to remove the
battery. Do not use force.
mark
$ Notes
• It is recommended to set aside a backup battery for prolonged shooting in case the
battery in use drains.
• Also read “Battery, battery charger, and card” (P. 115).
12
EN
Page 13
Inserting the card
Loading the card.
1
• Open the battery/card compartment
cover.
• Slide the card in until it is locked into
place.
g “Usable cards” (P. 116)
Eye-Fi Cards
Read “Usable cards” (P. 116) before use.
Cautions
• Turn off the camera before loading or
removing the battery or card.
Closing the battery/card
2
compartment cover.
• Close the cover and slide the battery/
card compartment lock in the direction
shown by the arrow.
Cautions
• Be sure the battery/card compartment cover is closed before using the camera.
Removing the card
Press the inserted card lightly and it will be ejected. Pull
out the card.
Cautions
• Do not remove the battery or card while the card
write indicator (P. 30) is displayed.
1
1
Preparing the camera and fl ow of operations
2
EN
13
Page 14
Attaching a lens to the camera
Attach a lens to the camera.
1
1
Preparing the camera and fl ow of operations
1
3
Rear cap
2
2
1
2
1
4
2
Lens release button
2
1
• Remove the rear cap of the lens and the body cap of the camera.
• Align the lens attachment mark (red) on the camera with the alignment mark (red) on
the lens, then insert the lens into the camera’s body.
• Rotate the lens clockwise until you hear it click (direction indicated by arrow 3).
Cautions
• Make sure the camera is turned off when attaching or removing the lens.
• Do not press the lens release button.
• Do not touch internal portions of the camera.
Remove the lens cap.
2
Using lenses with an UNLOCK switch
Retractable lenses with an UNLOCK switch cannot
be used while retracted. Turn the zoom ring in the
direction of arrow (1) to extend the lens (2).
To store, turn the zoom ring in the direction of arrow
(4) while sliding the UNLOCK switch (3).
Removing the lens from the camera
Make sure the camera is turned off when removing
the lens.
While pressing the lens release button, rotate the
lens in the direction of the arrow.
1
3
Interchangeable lenses
Read “Interchangeable lenses” (P. 118).
14
EN
1
Page 15
Power on
Press the ON/OFF button to turn on the camera.
1
• When the camera is turned on, the monitor will turn on.
• To turn off the camera, press the ON/OFF button again.
ON/OFF button
Monitor
Battery level
; (green): Camera ready to shoot.
: (green): Low battery
] (blinks red): Charge the battery.
Wi-Fi
ISO-A
200
1
Preparing the camera and fl ow of operations
250250 F5.6
01:02:0301:02:03
3838
Using the monitor
1 Press the monitor down.
2 Adjust the angle of the monitor according to the hinge axis.
Lower angle Self portraitUpper angle
1
1
2
1
1
2
For information on self portraits, read “Self-portraits” (P. 19).
Camera sleep operation
If no operations are performed for a minute, the camera enters “sleep” (stand-by) mode to
turn off the monitor and to cancel all actions. The camera activates again when you touch
any button (the shutter button, q button, etc.). The camera will turn off automatically if
left in sleep mode for 5 minutes. Turn the camera on again before use.
EN
15
Page 16
Setting the date/time
Date and time information is recorded on the card together with the images. The fi le
name is also included with the date and time information. Be sure to set the correct
date and time before using the camera. Some functions cannot be used if the date and
1
time have not been set.
Preparing the camera and fl ow of operations
Display the menus.
1
• Press the MENU button to display the menus.
Shooting Menu 1
Card Setup
1
Reset/Myset
Picture Mode
2
MENU button
Select [X] in the [d] (setup) tab.
2
• Use FG on the arrow pad to select
[d] and press I.
• Select [X] and press I.
[d] tab
Image Aspect
Digital Tele-converter
Back Set
1
2
Rec View
Wi-Fi Settings
Menu Display
Firmware
Setup Menu
’--.--.-- --:--
English
0.5sec
SetBack
h
4:3
Off
Set the date and time.
3
• Use HI to select items.
• Use FG to change the selected item.
• Use FG to select the date format.
Save settings and exit.
4
YMD Time
2014
Cancel
The time is displayed using a
24-hour clock.
• Press Q to set the camera clock and exit to the main menu.
• Press the MENU button to exit the menus.
Cautions
• If the battery is removed from the camera and the camera is left for a while, the date and
time may reset to the factory default setting.
$ Notes
• You can synchronize the time correctly by pressing Q at a time signal of 0 seconds while
setting [min].
16
EN
X
Y/M/D
Page 17
Selecting a shooting mode
Use the mode dial to select the shooting mode.
A full auto mode in which the camera automatically optimizes settings for the
A
current scene. The camera does all the work, which is convenient for beginners.
Aperture and shutter speed are automatically adjusted for optimal results.
P
You control aperture. You can sharpen or soften background details.
A
You control shutter speed. You can express the motion of moving subjects, or
S
freeze motion without any blur.
You control aperture and shutter speed. You can shoot with long exposures for
M
fi reworks or other dark scenes.
Shoot movies using shutter speed and aperture effects and movie special effects.
n
You can shoot a PHOTO STORY. Shoot with selected PHOTO STORY type.
J
Select a scene according to the subject.
SCN
Select an art fi lter.
ART
Indicator
First, try taking photographs in full auto mode.
Set the mode dial to A.
1
Mode icon
1
Preparing the camera and fl ow of operations
Monitor
ISO
sensitivity
Shutter speed Aperture value
Wi-Fi
ISO-A
200
250250 F5.6
01:02:0301:02:03
3838
Available
recording
time
Number of
storable still
pictures
EN
17
Page 18
2
Shooting
Shooting still pictures
Set up the camera and decide
1
2
Shooting
on the composition.
• Be careful that your fi ngers or
the camera strap do not obstruct
the lens or AF illuminator.
Adjust the focus.
2
• Display the subject in the center of the monitor, and lightly press the shutter button
down to the fi rst position (press the shutter button halfway).
The AF confi rmation mark (() will be displayed, and a green frame (AF target) will
be displayed in the focus location.
• The ISO sensitivity, shutter speed and aperture value that have been set
automatically by the camera are displayed.
• If the AF confi rmation mark blinks, the subject is not in focus. (P. 130)
Release the shutter.
3
• Press the shutter button all the way (fully).
• The shutter sounds and the picture is taken.
• The shot image will be displayed on the monitor.
Landscape position Portrait position
Wi-Fi
ISO-A
Press the shutter
button halfway.
200
250250 F5.6
AF confi rmation mark
28
mm
01:02:0301:02:03
AF target
3838
Pressing the shutter button halfway and all the way down
The shutter button has two positions. The act of lightly pressing the shutter button to the
fi rst position and holding it there is called “pressing the shutter button halfway,” that of
pressing it all the way
down to the second
position “pressing the
shutter button all (or the
rest of) the way down.”
Press halfway
$ Notes
• You can also take photographs using the touch screen. g “Using the touch screen”
(P. 22)
18
EN
Press the rest of
the way down
Page 19
Self-portraits
Inverting the monitor allows you to take pictures of yourself while you preview the
frame.
Lower the monitor slightly and invert it.
1
1
• If a power zoom lens is attached, the camera
automatically switches to wide angle.
• The self portrait menu is displayed in the
monitor.
• The monitor displays a mirror image (fl ipped
horizontally).
1
2
45:67:8945:67:89
23412341
4:3
L
N
FullHD
F
2
Shooting
One Touch
A
e-Portrait
Shutter Touch
C
One Touch
D
Custom Self Timer
Frame the shot.
2
• Be careful that your fi ngers or the camera strap do not obstruct the lens.
Touch C and shoot.
3
• The shot image will be displayed on the monitor.
• You can also shoot by touching the subject displayed in the monitor, or by pressing
the shutter button.
Turning this on makes skin look smooth and
translucent.
Valid only during iAUTO mode (A).
When the icon is touched, the shutter is released
about 1 second later.
Shoot 3 frames using the self timer. You can set
the number of times the shutter is released and the
interval between each release using Custom Self
Timer (P.61).
$ Notes
You can shoot by operating the camera with a smartphone. g “Shooting remotely with a
smartphone” (P. 106)
EN
19
Page 20
Recording movies
You can record movies when the mode dial is on any mode except J (PHOTO
STORY). Try recording in full auto mode fi rst.
Set the mode dial to A.
1
Press the R button to begin recording.
2
2
Shooting
• You can change the focus location by touching
the screen while recording (P. 22).
Press the R button again to end recording.
3
Displayed during
recording
Cautions
• When using a camera with a CMOS image sensor, moving objects may appear distorted
due to the rolling shutter phenomenon. This is a physical phenomenon whereby distortion
occurs in the fi lmed image when shooting a fast-moving subject or due to camera shaking.
In particular, this phenomenon becomes more noticeable when using a long focal length.
• If the camera is used for extended periods, the temperature of the image pickup device
will rise and noise and colored fog may appear in images. Turn off the camera for a short
time. Noise and colored fog may also appear in images recorded at high ISO sensitivity
settings. If the temperature rises further, the camera will turn off automatically.
• When using a Four Thirds system lens, the AF will not operate while recording movies.
• The R button cannot be used to record movies in the following instances:
Multiple exposure (still photography also ends.)/shutter button pressed halfway/during
bulb, time or composite photography/sequential shooting/Panorama/SCN mode
(e-Portrait, Hand-Held Starlight, 3D)/time lapse shooting
R button
Recording time
42
mm
00:02:1800:02:18
20
EN
Page 21
Taking photographs during movie recording (Movie+Photo Mode)
• Press the shutter button during movie recording to record one of the frames of the movie
as a photograph (mode1). To end movie recording, press the R button. The photograph
and movie fi les will be recorded separately to the memory card. The record mode of the
photographs will be XN (16:9).
• There is also a way of recording a photograph of a higher quality (mode2). In mode2, the
movie footage from before and after the photograph is recorded in separate fi les.
g [Movie+Photo Mode] (P. 92)
Cautions
• In mode2 and certain shooting modes, it is only possible to capture a single-frame as a
picture during recording. Other shooting functions may also be limited.
• The autofocus and metering used in movie mode may differ from that used to take
photographs.
• If the record mode for the movie is Motion JPEG (H or I), the camera is set to mode2.
2
Shooting
EN
21
Page 22
Using the touch screen
You can use the touch screen during playback or when framing pictures in the monitor.
Cautions
• The situations in which touch screen operations are not available include the following.
Panorama/3D/e-portrait/multiple exposure/during bulb, time or live composite
2
Shooting
photography/one-touch white balance dialog/when buttons or dials are in use
• Do not touch the display with your fi ngernails or other sharp objects.
• Gloves or monitor covers may interfere with touch screen operation.
• Also available in the ART, SCN or J menu screens. Tap an icon to select it.
Selecting a focusing method
You can focus and shoot by tapping the monitor.
Ta p
to cycle through touch screen settings.
T
Tap a subject to focus and automatically
T
release the shutter. This function is not
available in n mode.
Touch screen operations disabled.
U
Tap to display an AF target and focus on the
V
subject in the selected area. You can use the
touch screen to choose the position and size of
the focus frame. Photographs can be taken by
pressing the shutter button.
Wi-Fi
ISO-A
200
250250 F5.6
01:02:0301:02:03
3030
Previewing Your Subject ( V )
Tap the subject in the display.
1
• An AF target will be displayed.
• Use the slider to choose the size of the frame.
• Touch S to turn off the display of the AF target.
Use the slider to adjust the size of the AF
2
target, and then tap Y to zoom in at the
frame position.
• Use your fi nger to scroll the display when the picture
is zoomed in.
• Tap Z to cancel the zoom display.
22
EN
S-IS AUTOS-IS AUTO
1414
ISO-A
200
Off
250250 F5.6
1010
7
7
5x5x
Page 23
Using the wireless LAN function
You can connect the camera to a smartphone and
control the camera over Wi-Fi. You must have the
specifi ed app installed on the smartphone in advance.
g “Connecting the camera to a smartphone” (P. 104)
Wi-Fi
Wi-Fi
ISO-A
200
250250 F5.6
01:02:0301:02:03
3030
2
Shooting
EN
23
Page 24
Setting shooting functions
Using live guides
Live guides are available in iAUTO (A) mode. While iAUTO is a full auto mode, live
guides make it easy to access a variety of advanced photographic techniques.
2
Shooting
Set the mode dial to A.
1
Touch the tab or press the Fn button to display live guides.
2
• Touch a guide item and press Q after selecting to display the slider of the level bar.
Wi-Fi
ISO-A
200
Ta b
Change Color Saturation
Guide item
250250 F5.6
Use your fi nger to position the sliders.
3
• Tap a to enter the setting.
• To cancel the live guide setting, tap k on the
screen.
• When [Shooting Tips] is selected, select an item and
touch a to display a description.
• The effect of the selected level is visible in the
display. If [Blur Background] or [Express Motions]
is selected, the display will return to normal, but the
selected effect will be visible in the fi nal photograph.
To set multiple live guides, repeat Steps 2 and 3.
4
• A check is displayed on the guide item for live
guides that are already set.
Shoot.
5
• To clear the live guide from the display, press the MENU button.
01:02:0301:02:03
3838
Level bar/selection
Clear & Vivid
0
Flat & Muted
Change Color Saturation
24
EN
Page 25
Cautions
• [Blur Background] and [Express Motions] cannot be set at the same time.
• If [RAW] is currently selected for image quality, image quality will automatically be set to
[YN+RAW].
• Live guide settings are not applied to the RAW copy.
• Pictures may appear grainy at some live guide setting levels.
• Changes to live guide setting levels may not be visible in the monitor.
• Frame rates drop when [Blurred Motion] is selected.
• The fl ash cannot be used with the live guide.
• Choosing live guide settings that exceed the limits of the camera exposure meters may
result in pictures that are over or underexposed.
2
Shooting
EN
25
Page 26
Viewing photographs and movies
3
Viewing photographs and movies
Press the q button.
1
• Your most recent photograph or movie will be displayed.
3
Viewing photographs and movies
• Select the desired photograph or movie using the control dial (P) or arrow pad.
control dial
Wi-Fi
Displays the
previous
frame
Displays the
next frame
2014.07.01 12:30 20
Still image
Wi-Fi
q button
2014.07.01 12:30 4
Movie
Index display/Calendar display
• To view multiple frames, press G during single-frame playback. To start calendar
playback, press the G button repeatedly.
• Press the Q button to view the currently selected picture full frame.
Wi-Fi
100-0020
L
2014.07.01 12:30 20
N
GG
UU
2014.07.01 12:30 21
Index display
2014.7
Sun Mon Tue Wed Thu Fri Sat
29 30 1 2 3 4 5
29 30 1 2 3 4 5
6 7 8 9 10 11 12
6 7 8 9 10 11 12
13 14 15 16 17 18 19
13 14 15 16 17 18 19
20 21 22 23 24 25 26
20 21 22 23 24 25 26
27 28 29 30 31 1 2
27 28 29 30 31 1 2
3 4 5 6 7
3 4 5 6 7
Calendar display
Q
100-0020
L
N
WB
WBWBWB
P
AUTO
AUTOAUTOAUTO
HD
100-0004
26
EN
Page 27
Viewing still images
Close-up playback
In single-frame playback, press U to zoom in; press G to return to single-frame playback.
Wi-Fi
100-0020
L
2014.07.01 12:30 20
N
2x
Watching movies
Select a movie and press the Q button to display the
playback menu. Select [Movie Play] and press the Q
button to begin playback. Press it again to pause playback.
Press the MENU button to end playback.
Back
Movie
Movie Play
Share Order
m
Erase
Set
Volume
Volume can be adjusted by pressing F or G during singleframe and movie playback.
00:00:02/00:00:14
Protecting images
Wi-Fi
0 (protect) icon
4:3
100-0020
L
N
Protect images from accidental deletion. Display an image
you wish to protect and press Q to display the playback
menu. Select [0] and press Q, and then press F or G
to protect the image. Protected images are shown by a 0
(protect) icon. Press F or G to remove protection.
You can also protect multiple selected images.
g “Selecting images ([Share Order Selected], [0],
[Erase Selected])” (P. 28)
2014.07.01 12:30 20
3
Viewing photographs and movies
Cautions
• Formatting the card erases all images even if they have been protected.
EN
27
Page 28
Erasing images
Display an image you want to delete and press the D button. Select [Yes] and press
the Q button.
You can erase images without the confi rmation step by changing the button settings.
g [Quick Erase] (P. 91)
Erase
3
Viewing photographs and movies
D button
Setting a transfer order on images ([Share Order])
You can select images you want to transfer to a smartphone in advance. When playing
back images you want to transfer, press Q to display the playback menu. After
selecting [Share Order] and pressing Q, press F or G to set a share order on an
image and display h.
To cancel a share order, press F or G. You can select images you want to transfer in
advance and set a share order all at once.
g Selecting images ([Share Order Selected], [0], [Erase Selected])
Cautions
• You can set a share order on 200 frames.
• Share orders cannot include RAW images or Motion JPEG (H or I) movies.
Selecting images ([Share Order Selected], [0], [Erase Selected])
You can select multiple images for [Share Order Selected],
[0], or [Erase Selected].
Press the H button in the index display screen (P. 29) to
select an image; a v icon will appear on the image. Press
the H button again to cancel the selection.
Press Q to display the menu, and then select from [Share
Order Selected], [0], or [Erase Selected].
Back
2014.07.01 12:30 21
Yes
No
Set
28
EN
Page 29
Using the touch screen
You can use the touch panel to manipulate images.
Full-frame playback
Viewing additional images
• Slide your fi nger to the left to view later frames, right to
scroll view earlier frames.
Playback zoom
• Lightly touch the screen to display the slider and P.
• Slide the bar up or down to zoom in or out.
• Use your fi nger to scroll the display when the picture is
zoomed in.
• Tap P to display index playback.
Tap Q again for calendar playback.
Index/Calendar Playback
Page ahead/Page back
• Slide your fi nger up to view the next page, down to view
the previous page.
• Use Q or R to choose the number of images
displayed.
• Tap R several times to return to single-frame
playback.
Viewing images
• Tap an image to view it full frame.
Selecting and protecting images
In single-frame playback, lightly touch the screen to display the touch menu. You can
then perform the desired operation by touching the icons in the touch menu.
H
h
0
Select an image. You can select multiple images and delete them
collectively.
Images you want to share with a smartphone can be set.
g “Setting a transfer order on images ([Share Order])” (P. 28)
Protects an image.
S
3
Viewing photographs and movies
Cautions
• Do not touch the display with your fi ngernails or other sharp objects.
• Gloves and monitor covers may interfere with touch screen operation.
EN
29
Page 30
Basic operations
B
4
Information displays while shooting
Monitor display when shooting
1
32 654 97 0a b
8
dc
D
4
Basic operations
C
B
A
z
y
S-AFS-AF
ISO-A
400
-
2.0-2.0
Wi-Fi
x
w
v
1 Card write indicator .........................P. 13
2 Wireless LAN connection........P. 23, 107
3 Super FP fl ash ..............................P. 124
4 RC mode.......................................P. 124
5 Auto bracket/HDR ..................P. 76/P. 78
6 Multiple exposure............................P. 79
7 High frame rate ...............................P. 87
8 Digital Tele-converter ......................P. 81
9 Time lapse shooting ........................P. 80
0 Face priority/Eye priority .................P. 48
a Movie sound ...................................P. 70
b Zoom operation direction/
Focal length/Internal temperature
warning m ................P. 121/P. 133
c Flash ...............................................P. 65
(blinks: charging in progress,
lights up: charging completed)
d AF confi rmation mark......................P. 18
e Image stabilizer...............................P. 57
f Art fi lter ...........................................P. 44
Scene mode....................................P. 42
Picture mode...................................P. 60
AEL
P
u
t
RC
BKT
FP
FPS
250250 F5.6
qp o
r
s
off
28
mm
S-IS AUTOS-IS AUTO
e
f
WB
WBWBWB
g
AUTO
AUTOAUTOAUTO
h
4:3
i
L
N
j
FullHD
+7+7
+
2.0+2.0
-3-3
01:02:0301:02:03
F
10231023
k
l
m
n
g White balance .................................P. 58
h Sequential shooting/self-timer/Anti-
Shock ........................................P. 61, 89
i Aspect ratio .....................................P. 62
j Record mode (still images) .............P. 63
k Record mode (movies) ...................P. 64
l Available recording time
m Number of storable still pictures ...P. 117
n Highlight and shadow control..........P. 46
o Top: Flash intensity control ......P. 68
Bottom: Exposure compensation
indicator............................P. 46
p Exposure compensation value........P. 46
q Aperture value .........................P. 32 – 35
r Shutter speed ..........................P. 32 – 35
s Histogram .......................................P. 31
t Preview ...........................................P. 94
u AE Lock ..........................................P. 93
v Shooting mode...................P. 17, 32 – 44
w Myset ..............................................P. 73
x Shooting using touch screen
operations .......................................P. 22
1
TO
TO
OOO
O
3
N
E
30
EN
Page 31
y Flash intensity control .....................P. 68
z ISO sensitivity .................................P. 70
A AF mode .........................................P. 69
B Metering mode ................................P. 68
C Flash mode .....................................P. 65
D Battery check
; Lit up (green): Ready for use.
(Displayed for
about ten seconds
after the camera is
turned on.)
: Lit up (green): Battery is running
low.
] Blinks (red): Charging required.
E Live guide recall ..............................P. 24
Switching the information display
You can switch the information displayed in the monitor during shooting using the
INFO button.
INFO INFO
Wi-Fi
ISO-A
200
250250 F5.6
S-IS AUTO S-IS AUTO
L
FullHD
01:02:0301:02:03
0.00.0
Information display on
0.00.0
P
250250 F5.6
INFO
N
F
3838
INFO
Level gauge display
Histogram display
Display a histogram showing the distribution of brightness
in the image. The horizontal axis gives the brightness,
the vertical axis the number of pixels of each brightness
in the image. Areas above the upper limit at shooting are
displayed in red, those below the lower limit in blue, and
the area metered using spot metering in green.
Level gauge display
Indicate the orientation of the camera. The “tilt” direction is indicated on the vertical bar and
the “horizon” direction on the horizontal bar. Use the indicators on the level gauge as a guide.
Wi-Fi
ISO-A
200
0.00.0
P
250250 F5.6
Histogram display
Image only
More
Less
Dark Bright
01:02:0301:02:03
S-IS AUTO S-IS AUTO
L
N
FullHDFullHD
3838
4
Basic operations
EN
31
Page 32
Using the shooting modes
60"
F2.8
4000
F22
“Point-and-shoot” photography (P program mode)
P mode is a shooting mode where the camera automatically sets the optimal aperture
and shutter speed according to subject brightness. Set the mode dial to P.
4
Basic operations
Shooting
mode
• The shutter speed and aperture selected by the camera are displayed.
• The shutter speed and aperture displays will blink if the camera is unable to achieve
correct exposure.
Warning display
example (blinking)
60"
4000
F2.8
F22
The subject is too
dark.
The subject is too
bright.
• The aperture value at the moment when its indication blinks varies with the lens type and
focal length of the lens.
• When using a fi xed [ISO] setting, change the setting. g [ISO] (P. 70)
Wi-Fi
ISO-A
200
P
250250 F5.6
0.00.0
S-IS AUTO S-IS AUTO
01:02:0301:02:03
L
N
FullHD
F
3838
Shutter speed
Aperture value
Status Action
• Use the fl ash.
• The metered range of the camera is
exceeded. A commercially available ND
fi lter (for adjusting the amount of light) is
required.
Program shift (%)
In P and ART modes, you can choose different
combinations of aperture and shutter speed without altering
exposure. Change the combination by pressing the F
button (F), and then using the control dial (P) or FG.
An “s” appears next to the shooting mode during program
shift. To cancel program shift, press FG until “s” is no
longer displayed.
Cautions
• Program shift is not available when you are using a
fl ash.
32
EN
Wi-Fi
ISO-A
200
P
s
250250 F5.6
Program shift
S-IS AUTO S-IS AUTO
L
N
FullHD
F
0.00.0
01:02:0301:02:03
3838
Page 33
Choosing aperture (A aperture-priority mode)
60"
F5.6
4000
F5.6
Mode A is a shooting mode where you choose the aperture and let the camera
automatically adjust to the appropriate shutter speed. Rotale the mode dial to A.
• You can adjust the aperture by rotating the control dial
(P).
• After pressing the F button (F), you can also use
FG to choose the aperture.
• Larger apertures (lower F-numbers) decrease depth of
fi eld (the area in front of or behind the focus point that
appears to be in focus), softening background details.
Smaller apertures (higher F-numbers) increase depth
of fi eld.
Setting the aperture value
Decreasing aperture value IJ Increasing aperture value
F2.8I F4.0I F5.6 JF8.0 JF11
• The shutter speed display will blink if the camera is unable to achieve correct
exposure.
Warning display
example (blinking)
60"
F5.6
Status Action
The subject is
underexposed.
• Decrease the aperture value.
• Increase the aperture value.
• If the warning display does not disappear,
4000
F5.6
The subject is
overexposed.
the metered range of the camera is
exceeded. A commercially available ND
fi lter (for adjusting the amount of light) is
required.
• The aperture value at the moment when its indication blinks varies with the lens type and
focal length of the lens.
• When using a fi xed [ISO] setting, change the setting. g [ISO] (P. 70)
Wi-Fi
ISO
400
A
250250 F5.6
Aperture value
0.00.0
S-IS AUTO S-IS AUTO
01:02:0301:02:03
L
N
FullHD
F
3838
4
Basic operations
EN
33
Page 34
Choosing shutter speed (S shutter-priority mode)
2000
F2.8
125
F22
Mode S is a shooting mode where you choose the shutter speed and let the camera
automatically adjust to the appropriate aperture. Rotate the mode dial to S.
• Rotate the control dial (P) to set the shutter speed.
• After pressing the F button (F), you can also use
FG to choose the shutter speed.
• A fast shutter speed can freeze a fast action scene
without any blur. A slow shutter speed will blur a fast
action scene. This blurring will give the impression of
dynamic motion.
4
Basic operations
Setting the shutter speed
Slower shutter speed IJ Faster shutter speed
60" I 15 I 30I 60 J125 J250 J4000
• The aperture value display will blink if the camera is unable to achieve correct exposure.
Warning display
example (blinking)
2000
F2.8
125
F22
• The aperture value at the moment when its indication blinks varies with the lens type and
focal length of the lens.
• When using a fi xed [ISO] setting, change the setting. g [ISO] (P. 70)
Status Action
The subject is
underexposed.
• Set the shutter speed slower.
• Set the shutter speed faster.
The subject is
overexposed.
• If the warning display does not disappear,
the metered range of the camera is
exceeded. A commercially available ND fi lter
(for adjusting the amount of light) is required.
Wi-Fi
ISO
400
S
Shutter speed
250250 F5.6
S-IS AUTO S-IS AUTO
L
N
FullHD
F
0.00.0
01:02:0301:02:03
3838
34
EN
Page 35
Choosing aperture and shutter speed (M manual mode)
Mode M is a shooting mode where you choose both the aperture and shutter speed. They
can be set even in bulb, time, and live composite photography, where the shutter remains
open while the shutter button is pressed. Set the mode dial to M, rotate the control dial (P)
to adjust the shutter speed, and after presssing the F button (F), rotate the control dial (P)
to adjust the aperture.
• You can adjust the aperture value and shutter speed
using the difference from a correct exposure (measured
by the camera) as guidance.
• When the difference from the correct exposure is
negative (underexposure) reduce the aperture value or
slow the shutter speed.
• When the difference from the correct exposure is
positive (overexposure), increase the aperture value or
increase the shutter speed.
• Shutter speed can be set to values between 1/4000
and 60 seconds or to [BULB] or [LIVE TIME], or
[LIVECOMP].
Cautions
• Even when you have set [Noise Reduct.], noise and/or light spots may still be noticeable
in the image displayed on the monitor and shot images under certain environmental
conditions (temperature etc.) and camera settings.
Noise in images
While shooting at slow shutter speeds, noise may appear on screen. These phenomena
occur when the temperature rises in the image pickup device or image pickup device
internal drive circuit, causing current to be generated in those sections of the image pickup
device that are not normally exposed to light. This can also occur when shooting with a
high ISO setting in a high-temperature environment. To reduce this noise, the camera
activates the noise reduction function. g [Noise Reduct.] (P. 88)
Choosing long exposures (bulb/time photography)
Use for night landscapes and fi reworks. In M mode, set the shutter speed to [BULB] or
[LIVE TIME].
Bulb photography (BULB): The shutter remains open while the shutter button is pressed.
The exposure ends when the shutter button is released.
Time photography (TIME): The exposure begins when the shutter button is pressed all
the way down. To end the exposure, press the shutter button
all the way down again.
• During bulb, time, or live composite photography, the screen brightness changes
automatically. g “BULB/TIME Monitor” (P. 89)
• When using [LIVE TIME], the progress of the exposure will be displayed in the monitor
during shooting. The display can also be refreshed by pressing the shutter button halfway.
• [Live BULB] (P. 89) can be used to display the image exposure during bulb photography.
Wi-Fi
ISO
400
250250 F5.6
exposure
0.00.0
M
Difference from correct
S-IS AUTO S-IS AUTO
01:02:0301:02:03
L
FullHD
3838
N
F
4
Basic operations
EN
35
Page 36
Cautions
• There are limits on the available ISO sensitivity settings.
• To reduce camera blur, mount the camera on a sturdy tripod and use a remote cable (P. 127).
• During shooting, there are limits on the settings for the following functions.
Sequential shooting/self-timer shooting/interval shooting/AE bracket shooting/image
stabilizer/fl ash bracketing/multiple exposure* etc.
*When an option other than [Off] is selected for [Live BULB] or [Live TIME] (P. 89)
Comparative bright composites (live composite photography)
You can record a composite image from multiple shots while observing changes in
bright fl ashes of light, such as fi reworks and stars, without changing the brightness of
the background.
4
Basic operations
Set an exposure time to be the reference in [Composite Settings] (P. 89).
1
In M mode, set the shutter speed to [LIVECOMP].
2
• When the shutter speed is set to [LIVECOMP], you can display the [Composite
Settings] by pressing the MENU button.
Press the shutter button once to prepare for shooting.
3
• You can shoot when a message that indicates preparations are complete is displayed
in the monitor.
Press the shutter button.
4
• Live composite shooting begins. A composite image is displayed after each reference
exposure time, allowing you to observe changes in light.
• During composite shooting, the screen brightness changes automatically.
Press the shutter button to end shooting.
5
• The maximum length of composite shooting is 3 hours. However, the available
shooting time will vary depending on shooting conditions, and charging state of the
camera.
Cautions
• There are limits on the available ISO sensitivity settings.
• To reduce camera blur, mount the camera on a sturdy tripod and use a remote cable (P. 127).
• During shooting, there are limits on the settings for the following functions.
Sequential shooting/self-timer shooting/interval shooting/AE bracket shooting/image
stabilizer/fl ash bracketing etc.
36
EN
Page 37
Using movie mode
Movie mode
You can create movies that take advantage of the effects available in still photography
mode. Use live control to select the settings. g “Adding effects to a movie” (P. 62)
You can also apply an after-image effect or zoom in on an area of the image during
movie recording.
(n)
(n)
can be used to fi lm movies with special effects.
Adding effects to a movie [Movie Effect]
Rotate the mode dial to n.
1
Press the R button to begin recording.
2
• Press the R button again to end recording.
Touch the on-screen icon of the effect you wish to use.
3
Art Fade
W
Old Film
M
Multi Echo
U
One Shot Echo
T
Movie Tele-
X
converter
Art Fade
Touch the icon. The effect will be applied gradually when you release your fi nger.
Old Film
Touch the icon for the effect to be applied. Touch again to cancel the effect.
Multi Echo
Touch the icon to apply the effect. Touch again to cancel the effect.
One Shot Echo
Each touch of the icon adds to the effect.
Film with the selected picture mode effect. The fade
effect is applied to the transition between scenes.
Randomly apply damage and dust-like noise similar to
old movies.
Apply an after-image effect. After-images will appear
behind moving objects.
An after-image will appear for a short time after you press
the button. The after-image will disappear automatically
after a while.
Zoom in on an area of the image without using the lens
zoom. Zoom in on the selected position of the image
even while the camera is kept fi xed.
4
Basic operations
EN
37
Page 38
Movie Tele-converter
Touch the icon to display the zoom frame.
1
• You can change the position of the zoom frame by touching the screen or using
FGHI.
• Press and hold Q to return the zoom frame to a central position.
Touch M or press the U button to zoom in on the area in the zoom frame.
2
• Touch N or press the U button to return to the zoom frame display.
Touch O or press Q to cancel the zoom frame and exit Movie tele-
3
converter mode.
Cautions
4
• The frame rate will drop slightly during recording.
• The 2 effects cannot be applied simultaneously.
Basic operations
• Use a memory card with an SD speed class of 6 or better. Movie recording may end
unexpectedly if a slower card is used.
• When mode1 has been set for taking photographs during movie recording (P. 21, 92), you
cannot take photographs while using movie effects.
• [e-Portrait] and [Diorama] cannot be used at the same time as Art Fade.
• The sound of touch operations and button operations may be recorded.
38
EN
Page 39
Using PHOTO STORY
Rotate the mode dial to J.
1
• A PHOTO STORY menu will be displayed.
A
B
C
D
F
Q
Use FG to choose the theme of the PHOTO STORY.
2
Standard
Speed
Zoom In/Out
Layout
Fun Frames
Works in progress
1
2
3
4
Standard1
• You can display a detailed screen where you choose the variation or number of
frames by using I.
• You can choose different effects, number of frames and aspect ratios for each theme.
You can also change the aspect ratio, the division pattern and the frame effect of
individual images.
Changing between variations
After pressing I, use FG to change the variation.
E
Original PHOTO STORY
PHOTO STORY with effects and aspect ratios changed from the original
F G H
PHOTO STORY.
The number of images and arrangement of image regions can be altered for
each theme of the PHOTO STORY.
• You can change the frame color and frame surrounding effect in each variation.
• Every theme and variation provides a different PHOTO STORY.
After fi nishing the settings, press Q.
3
• The monitor switches to PHOTO STORY display.
• The subject of current frame is displayed.
• Touch any of the frames not containing an image to set that frame as the current frame.
• Press the MENU button to change the theme.
Shoot an image for the fi rst frame.
4
• The image you have shot is displayed in the fi rst
frame.
ISO-A
200
4
Basic operations
1
10231023
0.0
0.0
F5.0
250250
• To end shooting before taking all the frames, press the MENU button, and select an
image saving method.
[Save]: Save images to an SD card and end shooting.
[Finish later]: Save images to an SD card and temporarily end shooting. Saved data
can be called and shooting can be resumed later. (P. 41)
[Discard]: End shooting without saving images.
EN
39
Page 40
Shoot an image for the next frame.
5
• View and shoot the subject for the next frame.
• Press D to cancel the image in the directly preceding
frame and retake the shot.
ISO-A
200
• Touch any frame to cancel the image in it and retake
the shot. Touch the frame, and then touch O.
Once you have shot all the frames, press Q to save the image.
6
$ Notes
4
• During the shooting of a PHOTO STORY, the following operations are available.
Basic operations
Exposure compensation/Program shift/Flash shooting (except when the theme is
1
Shot image Next frame
[Speed])/Live control settings
Cautions
• If the camera is turned off during shooting, all the data for images up to that point is
cancelled and nothing is recorded on the memory card.
• If [RAW] is currently selected for image quality, image quality will automatically be set to
[YN+RAW]. The PHOTO STORY image is saved as JPEG and the images in the frames
as RAW. RAW images are saved in [4:3].
• From among the [AF Mode], [S-AF], [MF] and [S-AF+MF] can be set.
Also, the AF target is fi xed to a single central point.
• The metering mode is fi xed to digital ESP metering.
• The following operations are not available in PHOTO STORY mode.
Movie/Sequential shooting (except when the theme is [Speed])/Self timer/INFO display/
Face priority AF/Digital Tele-converter/Picture mode
• The following button operations are disabled.
Fn/INFO etc.
• During the shooting of a PHOTO STORY, the camera will not go into sleep mode.
If you temporarily saved partway through shooting, recording space for frames not yet
taken is reserved on the SD card.
250250
F5.0
0.0
0.0
10231023
40
EN
Page 41
Resuming shooting of works in progress
Set the mode dial to J.
1
Use FG to select Works in progress Q.
2
• Partially saved data is displayed in the index.
• Q appears on partially saved data.
Select the data with which you want to resume
3
shooting using the arrow pad, and press the Q
button.
• Shooting resumes from the previous session.
2014.07.01 12:30
4
Basic operations
EN
41
Page 42
Shooting in scene mode
Rotate the mode dial to SCN.
1
• A menu of scene menu will be displayed. Select a scene
using FG.
• On the scene menu screen, press I to display details
of the scene mode on the camera monitor.
• Press Q or press the shutter button halfway to select
the highlighted item and exit the scene menu.
Types of scene modes
4
Basic operations
O Portrait
P e-Portrait
L Landscape q DIS Mode fn Fisheye Effect
K Landscape+Portrait
J
Sport r Nature Macro mn Macro
i
Hand-Held Starlight Q Candle T 3D Photo
G Night Scene R Sunset J Panning
U Night+Portrait T Documents
G
Children s Panorama (P. 43)
Shoot.
2
• To choose a different setting, press Q to display the scene menu.
Cautions
• To maximize the benefi ts of the scene modes, some of the shooting function settings are
disabled.
• In [e-Portrait] mode, two images are recorded: an unmodifi ed image and a second
image to which [e-Portrait] effects have been applied. Recording may take some time. In
addition, when the image quality mode is [RAW], the image is recorded in RAW+JPEG.
• [n Fisheye Effect], [n Wide-Angle], and [n Macro] are for use with optional converter
lenses.
• Movies cannot be recorded in [e-Portrait], [Hand-Held Starlight], [Panorama], or [3D
Photo] mode.
• In [Hand-Held Starlight], 8 frames are shot at one time and then combined. When the
image quality mode is [RAW], a JPEG image is combined with the fi rst RAW image and
recorded in RAW+JPEG.
• [3D Photo] is subject to the following limitations.
[3D Photo] can be used only with a 3D lens.
The camera monitor cannot be used to playback images in 3D. Use a device that
supports 3D display.
Focus is locked. In addition, fl ash and self-timer also cannot be used.
Image size is fi xed at 1824 × 1024.
RAW photography is not available.
Frame coverage is not 100%.
H
High Key
I
Low Key g Beach & Snow
J
Macro wn Wide-Angle
(
Fireworks
Portrait
1
42
EN
Page 43
• In [Panning], camera movement is detected and the optimal shutter speed is controlled
when moving the camera to track a moving subject. It is convenient for shooting moving
subjects as if the background is fl owing.
In [Panning], J is displayed during panning detection, and I is displayed when
nothing is detected.
When using a lens with an image stabilizer switch in [Panning], turn the image stabilizer
switch off.
Suffi cient panning effects may not be obtained in bright conditions. Use a commercially
available ND fi lter to obtain effects more easily.
Taking panoramas
If you have installed the supplied computer software, you can use it to join pictures together
to form a panorama. g “Connecting the camera to a computer and a printer” (P. 108)
Rotate the mode dial to SCN.
1
Select [Panorama] and press Q.
2
Use FGHI to choose a pan direction.
3
Take a picture, using the guides to frame the shot.
4
• Focus, exposure, and other settings are fi xed at the
values for the fi rst shot.
M
250250 F5.6 38
Take the remaining images, framing each shot so that the guides overlap with
5
the previous picture.
4
Basic operations
M
250250 F5.6 38
• A panorama may include up to 10 images. A warning indicator (g) is displayed after
the tenth shot.
After taking the last shot, press Q to end the series.
6
[ 2 ]
Exit Exit
[ 3 ]
Cautions
• During panorama shooting, the image previously taken for position alignment will not be
displayed. With the frames or other markers for display in the images as a guide, set the
composition such that the edges of the overlapping images overlap within the frames.
$ Notes
• Pressing Q before shooting the fi rst frame returns to the scene mode selection menu.
Pressing Q in the midst of shooting ends the sequence of panorama shooting, and allows
you to continue with the next one.
EN
43
Page 44
Using art fi lters
Rotate the mode dial to ART.
1
• A menu of art fi lters will be displayed. Select a fi lter
using FG.
• Press Q or press the shutter button halfway to select
the highlighted item and exit the art fi lter menu.
Types of art fi lters
4
Basic operations
Pop Art
j
Soft Focus
k
Pale&Light Color
l
Light Tone
m
Grainy Film
n
Pin Hole
o
Diorama
s
Cross Process
t
Gentle Sepia
u
Dramatic Tone
v
Key Line
Y
Watercolor
Z
Vintage
G
Partial Color
H
ART BKT
(Art Filter
u
Bracket)
Pop Art
1
Creates an image that emphasizes the beauty of color.
Creates an image that expresses a soft tone atmosphere.
Creates an image that expresses warm light by scattering
overall light and slightly overexposing the image.
Creates a high-quality image by softening both shadows and
highlights.
Creates an image that expresses the roughness of black and
white images.
Creates an image that looks as if it was taken using an old or
toy camera by dimming the image perimeter.
Creates a miniature-like image by emphasizing saturation and
contrast, and blurring unfocused areas.
Creates an image that expresses a surreal atmosphere.
Cross Process II creates an image that emphasizes magenta.
Creates a high-quality image by drawing out shadows and
softening the overall image.
Creates an image that emphasizes the difference between
brightness and darkness by partially increasing contrast.
Creates an image that emphasizes edges and adds an
illustrative style.
Creates a soft, bright image by removing dark areas, blending
pale colors on a white canvas, and further softening contours.
Expresses an everyday shot in a nostalgic, vintage tone using
printed fi lm discoloration and fading.
Impressively expresses a subject by extracting colors you
want to emphasize and keeping everything else monotone.
Each time the shutter is released, the camera creates copies
for all selected art fi lters.
44
EN
Page 45
Shoot.
2
• To choose a different setting, press Q to display the art fi lter menu.
ART bracketing
When one shot is taken, images are recorded for each selected art fi lter. Press I to
choose fi lters.
Art effects
Art fi lters can be modifi ed and effects can be added. Pressing I in the art fi lter menu
displays additional options.
Modifying fi lters
Option I is the original fi lter, while options II and on add effects that modify the original
fi lter.
Adding effects*
Soft focus, pin-hole, frames, white edges, starlight, fi lter, tone, blur, shade effect
* The effects available vary with the selected fi lter.
Cautions
• To maximize the benefi ts of the art fi lters, some of the shooting function settings are
disabled.
• If [RAW] is currently selected for image quality, image quality will automatically be set to
[YN+RAW]. The art fi lter will be applied to the JPEG copy only.
• Depending on the subject, tone transitions may be ragged, the effect may be less
noticeable, or the image may become more “grainy.”
• Some effects may not be visible in live view or during movie recording.
• Playback may differ according to the fi lters, effects, or movie quality settings applied.
Setting and taking partial color images
You can create images that extract only the colors that you
selected using the color ring. Rotate the control dial (P)
COLOR
to select a color to extract. The effects will be displayed in
live view.
4
Basic operations
EN
45
Page 46
Commonly used shooting options
Controlling exposure (exposure compensation)
After pressing the F button (F), use the control dial (P) or HI to adjust the
exposure compensation. Choose positive (“+”) values to make pictures brighter,
negative (“–”) values to make pictures darker. Exposure can be adjusted by ±5.0 EV.
4
Basic operations
Cautions
• Exposure compensation is not available in A, M, or SCN mode.
• The monitor display changes only up to ±3.0 EV. If the exposure exceeds ±3.0 EV, the
• Movies can be corrected in a range up to ±3.0 EV.
Changing the brightness of highlights and shadows
Press the F button (F) and press the INFO button to
display the Highlight & Shadow Control menu. Use HI to
choose a tone level. Choose “low” to darken shadows or
“high” to brighten highlights.
Negative (–) No compensation (0) Positive (+)
exposure bar will begin fl ashing.
INFOINFO INFO
00
00
ISO
200
P
250250 F5.6
S-ISS-IS
L
N
HD
00
01:02:0301:02:03
+
2.0+2.0
12341234
Exposure
compensation
46
EN
Low tone High tone
Page 47
Choosing a focus target (AF Area)
Choose which of the 81 autofocus targets will be used for autofocus.
Press the P button (H) to display the AF target.
1
Use FGHI to change to single target display and select the AF position.
2
• “All targets” mode is restored if you move the cursor off the screen.
All Targets
Single Target
All Targets
The camera automatically
chooses from the full set of
focus targets.
Cautions
• When using a Four Thirds system lens, the camera automatically switches to single target
mode.
• The size and number of the AF target changes depending on the [Digital Tele-converter],
[Image Aspect], and group target settings.
Select the focus target
manually.
Setting the AF target
You can change the target selection method and target size. You can also select Face
priority AF (P. 48).
Press the P button (H) to display the AF target.
1
Press the INFO button during AF target selection and choose a selection
2
method using FG.
INFO
ii
o
(All Targets)
o
(Single Target)
I
(Small Target)
K
(Group Target)
J
Cautions
• When shooting movies, the camera automatically switches to single target mode.
• When using a Four Thirds system lens, the camera automatically switches to single target
mode.
The camera selects automatically from among all the AF
targets.
You select a single AF target.
The AF target can be reduced in size.
The camera automatically chooses from the targets in the
selected group.
FG
ii
4
Basic operations
EN
47
Page 48
Face priority AF/pupil detection AF
The camera detects faces and adjusts focus and digital ESP.
Press H to display the AF target.
1
Press the INFO button.
2
• You can change the AF target selection method.
Use HI to select an option and press Q.
3
Face Priority Off Face priority off.
4
Basic operations
J
Face Priority On Face priority on.
I
Face & Eye Priority On
K
Face & R. Eye Priority On
L
Face & L. Eye Priority On
M
The autofocus system selects the pupil of the eye
closest to the camera for face-priority AF.
The autofocus system selects the pupil of the eye on
the right for face-priority AF.
The autofocus system selects the pupil of the eye on
the left for face-priority AF.
ii
o
Selection method
Point the camera at your subject.
4
• If a face is detected, it will be indicated by a white
border.
Press the shutter button halfway to focus.
5
• When the camera focuses on the face in the white
border, the border will turn green.
• If the camera is able to detect the subject’s eyes, it will
display a green frame over the selected eye.
Wi-Fi
ISO-A
200
P
250250 F5.6
Wi-Fi
(pupil detection AF)
ISO-A
Press the shutter button the rest of the way down to
6
shoot.
200
P
250250 F5.6
Cautions
• Face priority applies only to the fi rst shot in each sequence taken during sequential
shooting.
• Pupil detection is not available in [C-AF].
• Depending on the subject and the art fi lter setting, the camera may not be able to correctly
detect the face.
• When set to [p (Digital ESP metering)], metering is performed with priority given to
faces.
$ Notes
• Face priority is also available in [MF]. Faces detected by the camera are indicated by
white frames.
48
EN
S-IS AUTO S-IS AUTO
L
N
FullHD
F
0.00.0
01:02:0301:02:03
10231023
S-IS AUTO S-IS AUTO
L
N
FullHD
F
0.00.0
01:02:0301:02:03
10231023
Page 49
Zoom frame AF/zoom AF
U
U
U
You can zoom in on a portion of the frame when adjusting focus. Choosing a high
zoom ratio allows you to use autofocus to focus on a smaller area than is normally
covered by the AF target. You can also position the focus target more precisely.
U
Wi-Fi
ISO-A
200
Off
0.0
0.0
250250 F5.6
Zoom frame AF Zoom AF
Q / U
U
S-IS AUTO S-IS AUTO
L
N
FullHD
F
01:02:0301:02:03
3030
U
(Press and hold)
Wi-Fi
ISO-A
200
250250 F5.6
S-IS AUTO S-IS AUTO
L
N
FullHD
F
01:02:0301:02:03
0.00.0
3030
Shooting display
Press the U button to display the zoom frame.
1
• If the camera was focused using autofocus just before the button was pressed, the
zoom frame will be displayed at the current focus position.
• Use FGHI to position the zoom frame.
• Press the INFO button and use FG to choose the zoom ratio.
5×
7×
10×
14×
Comparison of AF and zoom frames
Press the U button again to zoom in on the zoom frame.
2
• Use FGHI to position the zoom frame.
• You can change the zoom ratio by rotating the control dial (P).
Press the shutter button halfway to initiate autofocus.
3
• The camera will focus using the subject in the frame at the center of the screen. To
change the focus position, move it by touching the screen.
$ Notes
• You can also display and move the zoom frame using touch screen operations.
Cautions
• Zoom is visible only in the monitor and has no effect on the resulting photographs.
• When you are using a Four Thirds system lens, the AF will not operate with during zoom
display.
• While zoomed in, a sound is made by the IS (Image Stabilizer).
4
Basic operations
EN
49
Page 50
Information display during playback
Playback image information
Simplifi ed display
157 89
2 3 6
4
4
Basic operations
Wi-Fi
2014.07.01 12:30 15
f
3D3D
×10×10
4:3
L
cde
Overall display
hg i
Wi-Fi
2014.07.01 12:30 15
j
×10×10
P
+2.0+2.0 45mm45mm
WB
AUTO
ISO 400ISO 400
4:3
3D3D
L
N
k
250250
100-0015
N
100-0015
b
F5.6F5.6
+1.0+1.0
G+4G+4A+4A+4
AdobeAdobe
NaturalNatural
1/84608×3456
SD
0
a
l
m
n
o
p
q
r
stuw
v
50
EN
Page 51
1 Battery check ..................................P. 15
2 Wireless LAN connection........P. 23, 104
3 Including GPS information ............P. 106
4 Eye-Fi upload complete ..................P. 92
5 Print reservation
Number of prints ...........................P. 113
6 Share order .....................................P. 28
7 Sound record ..................................P. 54
8 Protect ............................................P. 54
9 Image selected ...............................P. 28
0 File number .....................................P. 91
a Frame number
b Storage device
c Record mode ..................................P. 63
d Aspect ratio .....................................P. 62
e 3D image ........................................P. 42
Temporarily saved image for PHOTO
STORY............................................P. 41
f Date and time .................................P. 16
g Aspect border .................................P. 62
h AF target .........................................P. 47
i Shooting mode...................P. 17, 32 – 44
j Exposure compensation .................P. 46
k Shutter speed ..........................P. 32 – 35
l Aperture value .........................P. 32 – 35
m Focal length ..................................P. 121
n Flash intensity control .....................P. 68
o White balance compensation
p Color space.....................................P. 90
q Picture mode...................................P. 60
r Compression rate ...........................P. 63
s Pixel count ......................................P. 63
t ISO sensitivity .................................P. 70
u White balance .................................P. 58
v Metering mode ................................P. 68
w Histogram .......................................P. 31
Switching the information display
You can switch the information displayed during playback by pressing the INFO
button.
×10×10
4:3
100-0015
L
Image only
INFO
2014.07.0112:30 15
N
Simplifi ed display
INFO
INFO
×10×10
250250
P
+2.0+2.0 45mm45mm
WB
AUTO
ISO 400ISO 400
4:3
100-0015
L
2014.07.0112:30 15
N
Overall display
NaturalNatural
F5.6F5.6
±0.0±0.0
G±10G±10A±10A±10
AdobeAdobe
1/84032×3024
4
Basic operations
EN
51
Page 52
Changing the playback information display method
Press the q button to view pictures full frame. Press the shutter button halfway to
return to shooting mode.
Index display/calendar display
Wi-Fi
2014.07.0112:30 20
Single-frame
4
playback
Basic operations
Playback zoom (close-up playback)
Wi-Fi
2014.07.0112:30 20
Single-frame
playback
Control dial (P)
Arrow pad
(FGHI)
INFO View image info
H
D
Q
G
100-0020
L
N
U
2014.07.0112:30 21
25 frames
Index display
U
100-0020
L
N
G
Single-frame playback: Previous t/Next s
Close-up playback: You can display the next frame or the
Index display: Highlight image
Single-frame playback: Next (I)/previous (H)/playback volume
(FG)
Close-up playback: Scroll image
Index/calendar playback: Highlight image
Select picture (P. 28)
Delete picture (P. 28)
View menus (in calendar playback, press this button to exit to
single-frame playback)
2x
2× zoom
previous frame during close-up playback.
You can display the next frame (I) or the
previous frame (H) during close-up playback
by pressing the INFO button.
G
U
U
G
close-up playback
Q
Sun Mon Tue Wed Thu Fri Sat
29 30 1 2 3 4 5
29 30 1 2 3 4 5
6 7 8 9 10 11 12
6 7 8 9 10 11 12
13 14 15 16 17 18 19
13 14 15 16 17 18 19
20 21 22 23 24 25 26
20 21 22 23 24 25 26
27 28 29 30 31 1 2
27 28 29 30 31 1 2
3 4 5 6 7
3 4 5 6 7
Calendar display
14x
14× zoom
2014.7
Q
52
EN
Page 53
Manipulating playback images
Press Q during playback to display a menu of simple options that can be used in
playback mode.
JPEG
JPEG Edit
Share Order
R
Rotate
m
Back
JPEG Edit, RAW Data Edit g P. 82
Image Overlay g P. 83
Movie Play —
Share Order gP. 28
0 (Protect)
R (Audio recording)
Rotate
m (Slideshow)
Erase
* Not available for H or I movies.
Performing operations on a movie frame (Movie Play)
Pause or resume playback.
• You can perform the following operations while playback is paused.
Q
H/I
F/G
HIor Control dial (P)
F
G
Advance or rewind a movie.
Adjust volume.
Previous/Next
Press and hold HI to continue the operation.
Display the fi rst frame.
Display the last frame.
Set
Still image frame Movie frame
D
D
—
—
D
D
D*
DD
D
D
—
—
DD
DD
4
Basic operations
Cautions
• We recommend using the supplied PC software to play movies on a computer. Before
launching the software for the fi rst time, connect the camera to the computer.
EN
53
Page 54
Protecting images
Protect images from accidental deletion. Display an image you
wish to protect and press Q to display the playback menu.
Select [0] and press Q, and then press F to protect the
image. Protected images are shown by a 0 (protect) icon.
Press G to remove protection. Press Q to save settings and
exit.
You can also protect multiple selected images. g “Selecting
images ([Share Order Selected], [0], [Erase Selected])” (P. 28)
Cautions
• Formatting the card erases all images even if they have been protected.
4
Audio recording
Basic operations
Add an audio recording (up to 30 sec. long) to the current photograph.
Display the image to which you want to add an
1
audio recording and press Q.
• Audio recording is not available with protected images.
• Audio recording is also available in the playback menu.
Select [R] and press Q.
2
• To exit without adding a recording, select [No].
Select [R Start] and press Q to begin recording.
3
• To stop recording part-way through, press Q.
Press Q to end recording.
4
• Images with audio recordings are indicated by a H icon.
• To delete a recording, select [Erase] in Step 2.
Rotate
Choose whether to rotate photographs.
Play the photograph back and press Q.
1
Select [Rotate] and press Q.
2
Press F to rotate the image counterclockwise, G to rotate it clockwise; the
3
image rotates each time the button is pressed.
• Press Q to save settings and exit.
• The rotated image is saved in its current orientation.
• Movies, 3D photos, and protected images cannot be rotated.
0 (protect) icon
Wi-Fi
4:3
100-0020
L
JPEG
R
N
JPEG Edit
Share Order
R
Rotate
m
Set
No
R
Start
Erase
2014.07.01 12:30 20
Back
Back Set
54
EN
Page 55
Slideshow
This function displays images stored on the card one after another.
Press Q during playback and select [m].
1
Back
Adjust settings.
2
Start Start the slideshow. Images are displayed in order, starting with the
BGM Set [Joy] or turn BGM [Off].
Slide Set type of slideshow to execute.
Slide Interval Choose the length of time each slide is displayed from 2 to 10
Movie Interval Select [Full] to include full-length movie clips in the slideshow,
Select [Start] and press Q.
3
• The slideshow will start.
• Press Q to stop the slideshow.
current picture.
seconds.
[Short] to include only the opening portion of each clip.
JPEG
JPEG Edit
Share Order
R
Rotate
m
Volume
Press FG during the slideshow to adjust the overall volume of the camera speaker.
Press HI while the volume adjustment indicator is displayed to adjust the balance
between the sound recorded with the image or movie and background music.
$ Notes
• You can change [Joy] to different BGM. Record the data downloaded from the Olympus
website onto the card, select [Joy] from [BGM] in step 2, and press I. Visit the following
website for the download.
http://support.olympus-imaging.com/bgmdownload/
Set
4
Basic operations
EN
55
Page 56
5
Using shooting options
Adjusting settings while shooting
The live control allows you to preview the effects of different settings in the monitor in
P, A, S, M, n, and J modes.
When the controls in KControl Settings is set to [Live Control], you can use live
control even in ART and SCN. (P. 97)
Live control screen
S-IS AUTOS-IS AUTO
WB
WBWBWB
WB
WBWBWB
AUTO
AUTOAUTOAUTO
AUTO
AUTOAUTOAUTO
4:3
L
N
FullHD
F
Cursor
Functions
Settings
AUTOAUTO
AUTOAUTO
P
Control dial (P) or HI
5
Using shooting options
P
Available settings
Image stabilizer ....................................P. 57
Picture mode ........................................P. 60
Scene mode .........................................P. 42
Art fi lter mode .......................................P. 44
White balance .......................................P. 58
Sequential shooting/self-timer ..............P. 61
Aspect ratio...........................................P. 62
Record mode ........................................P. 63
Press Q to display the live control.
1
• To hide the live control, press Q again.
Use FG to select the settings,
2
use HI to change the selected
setting.
Press the Q button.
3
• The selected settings take effect
automatically if no operations are
performed for about 8 seconds.
AUTOAUTO
AUTOAUTO
WB Auto
n mode ...............................................P. 62
Flash mode ...........................................P. 65
Flash intensity control ...........................P. 68
Metering mode......................................P. 68
AF mode ...............................................P. 69
ISO sensitivity .......................................P. 70
Face priority ..........................................P. 48
Movie sound record ..............................P. 70
Displays
the selected
function
name
WB Auto
Cursor
S-IS AUTOS-IS AUTO
WB
WBWBWB
WB
WBWBWB
AUTO
AUTOAUTOAUTO
AUTO
AUTOAUTOAUTO
4:3
L
N
FullHD
F
F
G
Cautions
• Some items are not available in some shooting modes.
56
EN
Page 57
Reducing camera shake (image stabilizer)
You can reduce the amount of camera shake that can occur when shooting in low light
situations or shooting with high magnifi cation. The image stabilizer starts when you
press the shutter button halfway.
Display the live control and select
1
the image stabilizer item using
FG.
Focal Length
Auto I.S.
OFFOFF
S-ISS-IS
S-ISS-IS S-ISS-IS
Select an option with HI and press Q.
2
OFF Still-I.S. Off
S-IS1
S-IS2
Still
S-IS3
All Direction
Shake I.S.
Vertical Shake
I.S.
Horizontal
Shake I.S.
P
Image stabilizer is off.
Image stabilizer is on.
Image stabilization applies only to vertical
(Y) camera shake.
Image stabilization applies only to horizontal
(Z) camera shake. Use when panning the
camera horizontally with the camera held in
portrait orientation.
The camera detects the panning direction and
applies the appropriate image stabilization.
Image stabilizer is off.
In addition to applying image stabilization in
all directions, the camera compensates for the
Movie
S-IS AUTO Auto I.S.
OFF Movie-I.S. Off
ON Movie-I.S. On
camera shake that occurs when you walk.
Choosing a focal length (Micro Four Thirds/Four Thirds System lenses excluded)
Use focal length information to reduce camera shake when shooting with lenses that are not
Micro Four Thirds or Four Thirds system lenses.
• Select [Image Stabilizer], press the INFO button, use HI to select a focal length, and
press Q.
• Choose a focal length between 8 mm and 1000 mm.
• Choose the value that most closely matches to the one that is printed on the lens.
Cautions
• The image stabilizer cannot correct excessive camera shake or camera shake that occurs
when the shutter speed is set to the slowest speed. In these cases, it is recommended
that you use a tripod.
• When using a tripod, set [Image Stabilizer] to [OFF].
• When using a lens with an image stabilization function switch, priority is given to the lens
side setting.
• When priority is being given to the lens side image stabilization and the camera side is set
to [S-IS AUTO], [S-IS1] is used instead of [S-IS AUTO].
• You may notice an operating sound or vibration when the image stabilizer is activated.
S-IS AUTOS-IS AUTO
S-IS AUTO
S-IS AUTO
AUTO
AUTOAUTOAUTO
AUTO
AUTOAUTOAUTO
L
FullHD
mmmm5050
j
WB
WBWBWB
WB
WBWBWB
4:3
N
F
stabilizer
5
Using shooting options
EN
57
Page 58
Adjusting color (white balance)
White balance (WB) ensures that white objects in images recorded by the camera
appear white. [AUTO] is suitable in most circumstances, but other values can be
selected according to the light source when [AUTO] fails to produce the desired results
or you wish to introduce a deliberate color cast into your images.
Display the live control and select the white balance item using FG.
1
S-IS AUTOS-IS AUTO
WB
WBWBWB
WB
WBWBWB
AUTO
AUTOAUTOAUTO
White balance
AUTO
AUTOAUTOAUTO
4:3
L
N
FullHD
F
Light conditions
5
Using shooting options
Select an option with HI and press Q.
2
WB mode
Auto white
balance
AUTO
5
N
Preset white
balance
O
1
>
U
n
One-touch
white balance
(P. 59)
Custom white
balance
P/Q/
W/X
CWB
WB Auto
AUTOAUTO
AUTOAUTO
P
Color
temperature
Used for most light conditions (when there is a
k
white portion framed on the monitor). Use this
mode for general use.
For shooting outdoors on a clear day, or to
5300K
capture the reds in a sunset or the colors in a
fi reworks display
7500K
For shooting outdoors in the shadows on a clear
day
6000K For shooting outdoors on a cloudy day
3000K For shooting under a tungsten light
4000K For subjects lit by fl uorescent lights
k
For underwater photography
5500K For fl ash shooting
Color
temperature
set by one-
touch WB.
2000K –
14000K
Choose when a white or gray subject can be
used to measure white balance and the subject
is under mixed lighting or lit by an unknown type
of fl ash or other light source.
After pressing the INFO button, use HI
buttons to select a color temperature and then
press Q.
58
EN
Page 59
One-touch white balance
Measure white balance by framing a piece of paper or other white object under the lighting
that will be used in the fi nal photograph. This is useful when shooting a subject under natural
light, as well as under various light sources with different color temperatures.
Select [P], [Q], [W] or [X] (one-touch white balance 1, 2, 3 or 4) and
1
press the INFO button.
Photograph a piece of colorless (white or gray) paper.
2
• Frame the object so that it fi lls the display and no shadows fall it.
• The one-touch white balance screen appears.
Select [Yes] and press Q.
3
• The new value is saved as a preset white balance option.
• The new value is stored until one-touch white balance is measured again. Turning the
power off does not erase the data.
% Tips
• If the subject is too bright or too dark or visibly tinted, the message [WB NG Retry] will be
displayed and no value will be recorded. Correct the problem and repeat the process from
Step 1.
5
Using shooting options
EN
59
Page 60
Processing options (picture mode)
Select a picture mode and make individual adjustments to contrast, sharpness, and
other parameters (P. 74). Changes to each picture mode are stored separately.
Display the live control and select picture mode.
1
S-IS AUTOS-IS AUTO
jj
Picture mode
WB
WBWBWB
AUTO
AUTOAUTOAUTO
4:3
L
N
Natural
h
i
jj
j44j
Select an option with HI and press Q.
2
i-Enhance Produces more impressive-looking results suited to the scene.
5
Using shooting options
h
Vivid Produces vivid colors.
i
Natural Produces natural colors.
j
Muted Produces fl at tones.
Z
Portrait Produces beautiful skin tones.
a
Monotone Produces black and white tone.
J
Custom
K
e-Portrait
v
Pop Art
j
Soft Focus
k
Pale&Light Color
l
Light Tone
m
Grainy Film
n
Pin Hole
o
Diorama
s
Cross Process
t
Gentle Sepia
u
Dramatic Tone
v
Key Line
Y
Watercolor
Z
Vintage
G
Partial Color*
H
P
Select one picture mode, set the parameters, and register the
setting.
Produces smooth skin textures. Cannot be used with bracket
photography or when shooting movies.
Choose an art fi lter and select the desired effect.
g “Types of art fi lters” (P. 44)
* After choosing Partial Color using HI, press the INFO button to display the color ring.
FullHD
F
M C
55
60
EN
Page 61
Sequential shooting/using the self timer
Keep the shutter button pressed all the way down to take a series of photos.
Alternatively, you can take pictures using the self timer.
Display the live control and select sequential shooting/self timer using FG.
1
S-IS AUTOS-IS AUTO
WB
WBWBWB
AUTO
AUTOAUTOAUTO
Sequential
4:3
shooting/
L
N
FullHD
P
Select an option using HI and press Q.
2
o
T
Single-frame
shooting
Sequential H
Shoots 1 frame at a time when the shutter button is pressed
(normal shooting mode, single-frame shooting).
Photographs are taken at about 8 frames per second (fps) while the
shutter button is pressed all the way down. Focus, exposure, and
white balance are fi xed at the values for the fi rst shot in each series.
Photographs are taken at about 3.5 frames per second (fps)
S
Sequential L
while the shutter button is pressed all the way down. Focus and
exposure are fi xed according to the options selected for [AF
Mode] (P. 69) and [AEL/AFL] (P. 93).
Press the shutter button halfway to focus, the rest of the way
Y12s
Self-timer
12 SEC
down to start the timer. First, the self-timer lamp lights up for
approximately 10 seconds, then it blinks for approximately 2
seconds and the picture is taken.
Y2s
Self-timer
2 SEC
Press the shutter button halfway to focus, the rest of the
way down to start the timer. The self-timer lamp blinks for
approximately 2 seconds, and then the picture is taken.
Press the INFO button to set [Y Timer], [Frame], [Interval Time],
and [Every Frame AF].
Select a setting using HI, and adjust the setting by using the
control dial (P).
YC
Custom Selftimer
If [Every Frame AF] is set to [ON], each frame is automatically
focused before shooting.
Single
Y
oo
TT
12sY12sY2sY2sYcYc
S
S
F
self timer
5
Using shooting options
$ Notes
• To cancel the activated self-timer, press G.
Cautions
• When you are using S, no confi rmation image is displayed during shooting. The
image is displayed again after shooting ends. When you are using T, the image shot
immediately before is displayed.
• The speed of sequential shooting varies depending on the lens you are using and the
focus of the zoom lens.
• During sequential shooting, if the battery check blinks due to low battery, the camera
stops shooting and starts saving the pictures you have taken on the card. The camera
may not save all of the pictures depending on how much battery power remains.
• Fix the camera securely on a tripod for self-timer shooting.
• If you stand in front of the camera to press the shutter button halfway when using the selftimer, the photograph may be out of focus.
EN
61
Page 62
Setting the image aspect
You can change the aspect ratio (horizontal-to-vertical ratio) when taking pictures.
Depending on your preference, you can set the aspect ratio to [4:3] (standard), [16:9],
[3:2], [1:1], or [3:4].
Display the live control and select the aspect ratio item using FG.
1
Use HI to select an aspect ratio and press Q.
2
Cautions
• JPEG images are cropped to the selected aspect ratio; RAW images, however, are not
cropped but are instead saved with information on the selected aspect ratio.
• When RAW images are played back, the selected aspect ratio is shown by a frame.
Adding effects to a movie
You can create movies that take advantage of the effects available in still photography
5
mode. Set the mode dial to n to enable the settings.
Using shooting options
62
After selecting n mode, display the live control and
1
use FG to highlight the shooting mode.
n
PP
Use HI to choose a shooting mode and press the Q button.
2
Optimal aperture is set automatically according to the brightness of the subject. You
P
can adjust the exposure by using the control dial (P).
After pressing the F button, you can also set it by using HI.
Depiction of background is changed by setting the aperture. You can set the
aperture by using the control dial (P).
A
After pressing the F button, you can also set it by using FG.
After pressing the F button, you can adjust the exposure by using HI.
Shutter speed affects how the subject appears. You can set the shutter speed by
using the control dial (P).
S
After pressing the F button, you can also set it by using FG.
After pressing the F button, you can adjust the exposure by using HI.
The shutter speed can be set to values between 1/30 s and 1/4000 s.
You control both aperture and shutter speed. You can set the shutter speed by using
the control dial (P). After pressing the F button, you can also set it by using FG.
After pressing the F button, you can set the aperture by using the control dial (P)
M
or HI.
The shutter speed can be set to values between 1/30 s and 1/4000 s.
The sensitivity can only be set manually to values between ISO 200 and 3200.
Cautions
• When recording a movie, you cannot change the settings for exposure compensation,
aperture value, and shutter speed.
• If [Image Stabilizer] is activated while recording a movie, the recorded image is enlarged slightly.
• Stabilization is not possible when the camera shake is excessive.
• When the inside of the camera becomes hot, shooting is automatically stopped to protect
the camera.
• With some art fi lters, [C-AF] operation is limited.
• Cards with an SD speed class of 6 or above are recommended for movie recording.
EN
Program Auto
AA SS MM
PP
Shooting mode
M-IS ONM-IS ON
j
P
P
WB
WBWBWB
AUTO
AUTOAUTOAUTO
S-AFS-AF
PP
FullHD
F
Page 63
Image quality (record mode)
Select an image quality for photographs and movies according their intended use, for
example retouching on a computer or display on the web.
Display the live control and use FG to choose a record mode for
1
photographs or movies.
S-IS AUTOS-IS AUTO
WB
WBWBWB
AUTO
AUTOAUTOAUTO
4:3
NN
4608x3456
L
L MNS
F
RAWRAW
P
N
Record mode
Select an option using HI and press Q.
2
Record modes (still images)
Choose from JPEG (YF, YN, XN, and WN) and RAW modes. Choose a JPEG+RAW option
to record both a JPEG and a RAW image with each shot. JPEG modes combine image size
(Y, X, and W) and compression ratio (SF, F, N, and B).
When you want to select a combination other than YF/YN/XN/WN, change the [K Set]
(P. 90) settings in Custom Menu.
Image size Compression rate
Name Pixel count
Y (Large)
4608×3456*
SF
(Super
Fine)
YSF YF* YN* YB
F
(Fine)N(Normal)B (Basic)
3200×2400*
X (Middle)
2560×1920
1920×1440
XSF XF XN* XB
1600×1200
1280×960*
W (Small)
1024×768
WSF WF WN* WB
640×480
* Default
FullHD
F
L
F+
F+F+F+
N
RAW
RAWRAWRAW
3838
Application
Select for the
print size
For small prints
and use on a
website
5
Using shooting options
RAW image data
This format (extension “.ORF”) stores unprocessed image data for later processing. RAW
image data cannot be viewed using other cameras or software, and RAW images cannot
be selected for printing. JPEG copies of RAW images can be created using this camera.
g “Editing still images” (P. 82)
EN
63
Page 64
Record modes (movies)
Record mode Pixel count File format Application
Full HD Fine 1920×1080
Full HD Normal 1920×1080
HD Fine 1280×720
HD Normal 1280×720
H
I
• Depending on the type of card used, recording may end before the maximum length is
5
Using shooting options
reached.
*1 Individual movies can be up to 29 minutes long.
*2 Files may be up to 2GB in size.
1280×720
640×480
MPEG-4 AVC/
1
H.264*
Motion JPEG*
Display on TVs and other
devices
For computer playback or
2
editing
64
EN
Page 65
Using a fl ash (fl ash photography)
The fl ash can be set manually as required. The fl ash can be used for fl ash
photography in a variety of shooting conditions.
Remove the terminal cover from the fl ash unit and attach the fl ash to the
1
camera.
• Slide the fl ash unit all the way in, stopping when it contacts the back of the shoe and
is securely in place.
UNLOCK switchHot shoe cover
1
2
Connector cover
5
Using shooting options
Removing the fl ash unit
Press the UNLOCK switch while removing the fl ash unit.
Raise the fl ash head.
2
• Lower the fl ash head when the fl ash is not in use.
Display the live control and use FG to choose a fl ash mode.
3
Flash mode
WB
WBWBWB
AUTO
AUTOAUTOAUTO
S-AFS-AF
ISO
ISOISOISO
AUTO
AUTOAUTOAUTO
ii
Flash Auto
AUTOAUTO
AUTOAUTO
P
RR
UNLOCK switch
2
1
EN
65
Page 66
Use HI to choose a fl ash mode and press Q.
4
• The options available and the order in which they are displayed vary depending on
the shooting mode. g “Flash modes that can be set by shooting mode” (P. 67)
AUTO Auto fl ash
Fill-in fl ash The fl ash fi res regardless of the light conditions.
#
Flash off The fl ash does not fi re.
$
Red-eye reduction fl ash
#!
!/
#SLOW
5
!SLOW
Using shooting options
#SLOW2/
Curtain
#FULL,
#1/4 etc.
Slow synchronization
(1st curtain)
Slow synchronization
(1st curtain)/Red-eye
reduction fl ash
Slow synchronization
2nd
(2nd curtain)
Manual
The fl ash fi res automatically in low light or
backlight conditions.
This function allows you to reduce the red-eye
phenomenon. In S and M modes, the fl ash
always fi res.
Slow shutter speeds are used to brighten dimly-lit
backgrounds.
Combines slow synchronization with red-eye
reduction.
The fl ash fi res just before the
shutter closes to create trails
of light behind moving light
sources.
For users who prefer manual operation. If you
press the INFO button, you can use the dial to
adjust the fl ash level.
Cautions
• In [!/#!(Red-eye reduction fl ash)], after the pre-fl ashes, it takes about 1 second
before the shutter is released. Do not move the camera until shooting is complete.
• [!/#!(Red-eye reduction fl ash)] may not work effectively under some shooting
conditions.
• When the fl ash fi res, the shutter speed is set to 1/250 sec. or slower. When shooting
a subject against a bright background with the fi ll-in fl ash, the background may be
overexposed.
66
EN
Page 67
Flash modes that can be set by shooting mode
Shooting
mode
P/A
S/M
• #AUTO, $ can be set in A mode.
* 1/200 sec. or 1/180 sec. (FL-50R only) when using a separately sold external fl ash unit
Minimum range
The lens may cast shadows over objects close to
the camera, causing vignetting, or be too bright
even at minimum output.
• External fl ash units can be used to prevent vignetting. To prevent photographs from being
overexposed, select mode A or M and choose a high f-number, or reduce ISO sensitivity.
LV super
control
panel
#AUTO
!
#
$
!
SLOW
#SLOW
#
SLOW2
#
#!
$
#
2nd-C
Flash mode
Auto fl ash
Auto fl ash
(red-eye reduction)
Fill-in fl ash Always fi res
Flash off
Slow synchronization
(red-eye reduction)
Slow synchronization
(1st curtain)
Slow synchronization
(2nd curtain)
Fill-in fl ash
Fill-in fl ash
(red-eye reduction)
Flash off
Fill-in fl ash/Slow
synchronization
(2nd curtain)
Flash
timing
curtain
curtain
curtain
curtain
curtain
Conditions for
fi ring the fl ash
Fires automatically
1st
kk k
1st
Fires automatically
2nd
1st
kk k
2nd
Lens
17mm f1.8 0.25 m
25mm f1.8 0.25m
45mm f1.8 0.5m
14 – 42mm IIR 0.55m
14 – 42mm EZ 0.25m
40 – 150mm 0.9m
in dark/backlit
conditions
in dark/backlit
conditions
Always fi res
Always fi res
Approximate distance at
which vignetting occurs
Shutter
speed
limit
1/30 sec. –
1/250 sec.*
30 sec. –
1/250 sec.*
60 sec. –
1/250 sec.*
60 sec. –
1/250 sec.*
60 sec. –
1/250 sec.*
5
Using shooting options
EN
67
Page 68
Adjusting fl ash output (fl ash intensity control)
Flash output can be adjusted if you fi nd that your subject to appears overexposed, or is
underexposed even though the exposure in the rest of the frame is just right.
Display the live control and select
1
the Flash intensity control item
using FG.
P
Select a fl ash compensation value using HI and press Q.
2
Cautions
• This setting has no effect when the fl ash control mode for the external fl ash unit is set to
5
Using shooting options
MANUAL.
• Changes to fl ash intensity made with the external fl ash unit are added to those made with
the camera.
Choosing how the camera measures brightness (metering)
Choose how the camera meters subject brightness.
Display the live control and select
1
the metering item using FG.
P
Select an option with HI and press Q.
2
Digital ESP
p
metering
Center weighted
averaging
H
metering
Spot metering
I
Spot metering -
IHI
highlight
Spot metering -
ISH
shadow
Press the shutter button halfway.
3
• Normally, the camera will start metering when the shutter button is pressed halfway
and lock exposure while the shutter button is held in this position.
68
EN
The camera meters exposure in 324 areas of the frame and
optimizes exposure for the current scene or (if an option other
than [OFF] is selected for [I Face Priority]) portrait subject.
This mode is recommended for general use.
This metering mode provides the average
metering between the subject and the
background lighting, placing more weight on
the subject at the center.
Choose this option to meter a small area (about
2% of the frame) with the camera pointed at
the object you wish to meter. Exposure will be
adjusted according to the brightness at the
metered point.
Increases spot metering exposure. Ensures bright subjects
appear bright.
Lowers spot metering exposure. Ensures dark subjects appear
dark.
Flash compensation
0.0
00
Metering
S-AFS-AF
AUTO
AUTOAUTOAUTO
ESP
HIHI SHSH
AUTOAUTOAUTOAUTO
WB
WBWBWB
AUTO
AUTOAUTOAUTO
S-AFS-AF
ISO
ISOISOISO
AUTO
AUTOAUTOAUTO
ii
RR
AUTOAUTOAUTOAUTO
ISO
ISOISOISO
ii
RR
Page 69
Choosing a focus mode (AF mode)
Select a focusing method (focus mode).
You can choose separate focusing methods for still photography mode and n mode.
Display the live control and select the AF mode item using FG.
1
AUTOAUTOAUTOAUTO
S-AFS-AF
Single AF
C-AFC-AF
MFMF
S-AFS-AF
P
Select an option with HI and press Q.
2
• The selected AF mode is displayed on the monitor.
The camera focuses once when the shutter button is pressed
halfway. When the focus is locked, a beep sounds, and the AF
S-AF (single AF)
confi rmation mark and the AF target mark light up. This mode is
suitable for taking pictures of still subjects or subjects with limited
movement.
The camera repeats focusing while the shutter button remains
pressed halfway. When the subject is in focus, the AF confi rmation
C-AF
(continuous AF)
mark lights up on the monitor and the beep sounds when the focus
is locked at the fi rst and second time.
Even if the subject moves or you change the composition of the
picture, the camera continues trying to focus.
• When using a Four Thirds system lens, this setting will change to
[S-AF].
This function allows you to
manually focus on any position
MF
(manual focus)
S-AF+MF
(simultaneous use of
by operating the focus ring on
the lens.
After pressing the shutter button halfway to focus in [S-AF] mode,
you can turn the focus ring to fi ne-adjust focus manually.
S-AF mode and MF
mode)
Press the shutter button halfway to focus; the camera then tracks
and maintains focus on the current subject while the shutter button
C-AF+TR
(AF tracking)
is held in this position.
• The AF target is displayed in red if the camera can no longer track
the subject. Release the shutter button and then frame the subject
again and press the shutter button halfway.
• When using a Four Thirds system lens, this setting will change to
[S-AF].
Cautions
• The camera may be unable to focus if the subject is poorly lit, obscured by mist or smoke,
or lacks contrast.
• When using a Four Thirds system lens, AF will not be available during movie recording.
S-AFS-AFMFC-AFC-AF
S-AFS-AF
AF mode
ISO
ISOISOISO
AUTO
AUTOAUTOAUTO
ii
RR
TR
)
Near
Focus ring
5
Using shooting options
EN
69
Page 70
ISO sensitivity
Increasing ISO sensitivity increases noise (graininess) but allows photographs to be
taken when lighting is poor. The setting recommended in most situations is [AUTO],
which starts at ISO 200 — a value that balances noise and dynamic range — and then
adjusts ISO sensitivity according to shooting conditions.
Display the live control and select the ISO sensitivity item using FG.
1
AUTOAUTOAUTOAUTO
ISO-A
5
Using shooting options
Select an option with HI and press Q.
2
AUTO
ISO-AISO-AISO-A
200
200200200
Recommended
250 F5.6 0.0
AUTOAUTO
AUTOAUTO LOWLOW
250250 320320 400400 500500
P
200200
The sensitivity is set automatically according to the shooting
conditions.
S-AFS-AF
ISO
ISOISOISO
AUTO
AUTOAUTOAUTO
RR
ii
ISO
sensitivity
LOW, 200 – 25600 Sensitivity is set to the selected value.
Movie sound options (recording sound with movies)
Display the live control and select a movie sound using FG.
1
ISO
ISOISOISO
AUTO
AUTOAUTOAUTO
RR
RR
ii
Movie sound
Movie R On
OFFOFF
ONON
ONON
Switch ON/OFF using HI and press Q.
2
n
Cautions
• When recording sound in a movie, the sound made by the lens and camera operating
may be recorded. If desired, you can reduce these sounds by shooting with [AF Mode] set
to [S-AF], or by limiting the amount of times you press the buttons.
• No sound is recorded in s (Diorama) mode.
• When recording sound with movies is set to [OFF], O is displayed.
70
EN
Page 71
Menu functions
6
Basic menu operations
The menus contain shooting and playback options that are not displayed by the live
control, and let you customize the camera settings for easier use.
Preliminary and basic shooting options
W
Advanced shooting options
X
Playback and retouch options
q
Customizing camera settings (P. 85)*
c
Accessory port menu options for accessory port devices such as EVF and
#
OLYMPUS PENPAL (P. 101)*
Camera setup (e.g., date and language)
d
* Not displayed at default settings.
Press the MENU button to display the menus.
1
Operation guide
Press the MENU button
to go back one screen
Ta b
Shooting Menu 1
Card Setup
1
Reset/Myset
Picture Mode
2
Image Aspect
Digital Tele-converter
j
4:3
Off
SetBack
Press Q to confi rm the
setting
• A guide is displayed for about 2 seconds after you select an option.
• Press the INFO button to view or hide guides.
Use FG to select a tab and press Q.
2
Select an item using FG and press Q to display options for the
3
selected item.
The current setting is displayed
Shooting Menu 2
1
Function
Use FG to highlight an option and press Q to select.
4
Image Stabilizer
Bracketing
2
HDR
Multiple Exposure
Time Lapse Settings
# RC Mode
Back Set
oj /Y
Off
Q
Off
Off
Off
Off
• Press the MENU button repeatedly to exit the menu.
Shooting Menu 2
j/Y
1
Image Stabilizer
Bracketing
2
HDR
Multiple Exposure
Time Lapse Settings Off
#
RC Mode Off
Back
$ Notes
• For the default settings of each option, refer to “Menu directory” (P. 136).
6
Menu functions (Basic operations)
o
Off
T
S
Off
Y
12s
Off
Y
2
s
Y
C
Set
EN
71
Page 72
Using Shooting Menu 1/Shooting Menu 2
Shooting Menu 1
Card Setup
1
Reset/Myset
Picture Mode
2
Image Aspect
Digital Tele-converter
Shooting Menu 1 Shooting Menu 2
Card Setup (P. 72)
W
Reset/Myset (P. 73)
X j/Y (Sequential shooting/Self-timer)
Picture Mode (P. 74)
K (P. 75)
Image Aspect (P. 62)
Digital Tele-converter (P. 81)
6
Menu functions (Shooting menus)
Formatting the card (Card Setup)
Cards must be formatted with this camera before fi rst use or after being used with
other cameras or computers.
All data stored on the card, including protected images, is erased when the card is
formatted.
When formatting a used card, confi rm there are no images that you still want to keep
on the card. g “Usable cards” (P. 116)
Select [Card Setup] in W Shooting Menu 1.
1
Select [Format] and press Q.
2
j
4:3
Off
SetBack
(P. 61, 75)
Image Stabilizer (P. 57)
Bracketing (P. 76)
HDR (P. 78)
Multiple Exposure (P. 79)
Time Lapse Settings (P. 80)
# RC Mode (P. 81)
Card Setup
All Erase
Format
Select [Yes] and press Q.
3
• Formatting is performed.
Deleting all images (Card Setup)
All images taken are deleted. Protected images are not deleted.
Select [Card Setup] in W Shooting Menu 1.
1
Select [All Erase] and press Q.
2
Select [Yes] and press Q.
3
• All images are deleted.
72
EN
Back
Back
Card Setup
All Erase
Format
Set
Set
Page 73
Returning to default settings (Reset)
Camera settings can be easily restored to default settings.
Select [Reset/Myset] in W Shooting Menu 1.
1
Select [Reset] and press Q.
2
• Highlight [Reset] and press I to choose the reset type.
To reset all settings except the time, date, and a few
others, highlight [Full] and press Q.
g “Menu directory” (P. 136)
Select [Yes] and press Q.
3
Reset/Myset
Reset
Myset1
Myset2
Myset3
Myset4 No Data
Back
Basic
No Data
No Data
No Data
Set
Registering Favorites settings (Myset)
Saving Myset
You can save the current camera settings for modes other than shooting mode. Saved
settings can be called up in P, A, S, and M modes.
Adjust settings in order to save.
1
Select [Reset/Myset] in W Shooting Menu 1.
2
Select the desired destination ([Myset1]–[Myset4]) and press I.
3
• [Set] appears next to destinations ([Myset1]–[Myset4]) to which settings have already
been saved. Selecting [Set] again overwrites the registered setting.
• To cancel the registration, select [Reset].
Select [Set] and press Q.
4
• Settings that can be saved to Myset g “Menu directory” (P. 136)
Using Myset
Sets the camera to the settings selected for Myset.
Select [Reset/Myset] in W Shooting Menu 1.
1
Select the desired settings ([Myset1]–[Myset4]) and
2
press Q.
Select [Yes] and press Q.
3
Reset/Myset
Reset
Myset1
Myset2
Myset3
Myset4 Set
Back
Basic
6
Menu functions (Shooting menus)
Set
Set
Set
Set
EN
73
Page 74
Processing options (Picture Mode)
You can make individual adjustments to contrast, sharpness and other parameters in
[Picture Mode] (P. 60) settings. Changes to each picture mode are stored separately.
Select [Picture Mode] in W Shooting Menu 1.
1
Select an option with FG and press Q.
2
Press I to display settings for the selected option.
3
Contrast Distinction between light and dark
6
Sharpness Sharpness of the image
Menu functions (Shooting menus)
Saturation Vividness of the color
Gradation Adjust tone (gradation).
Divides the image into detailed
regions and adjusts the brightness
Auto
Normal Use [Normal] mode for general uses.
High Key Gradation for a bright subject.
Low Key Gradation for a dark subject.
Effect
(i-Enhance)
B&W Filter
(Monotone)
N:Neutral
Ye:Yellow
Or:Orange
R:Red
G:Green
separately for each region. This is
effective for images with areas of
large contrast in which the whites
appear too bright or the blacks
appear too dark.
Sets the extent that the effect will be
applied.
Creates a black and white image.
The fi lter color is brightened and the
complementary color is darkened.
Creates a normal black and white
image.
Reproduces clearly defi ned white
cloud with natural blue sky.
Slightly emphasizes colors in blue
skies and sunsets.
Strongly emphasizes colors in blue
skies and brightness of crimson
foliage.
Strongly emphasizes colors in red lips
and green leaves.
Card Setup
1
Reset/Myset
Picture Mode
2
Image Aspect
Digital Tele-converter
Back Set
h i-aJ K
DDDD
DDDD
DD
DDDD
D
kk
Shooting Menu 1
k
kk
DD
j
4:3
Off
D
D
74
EN
Page 75
h i-aJ K
Pict. Tone
(Monotone)
N:Neutral
S:Sepia Sepia
Colors the black and white image.
Creates a normal black and white
image.
kk
B:Blue Bluish
P:Purple Purplish
G:Green Greenish
Cautions
• Changes to contrast have no effect at settings other than [Normal].
DD
Image quality (K)
Select an image quality. You can select a separate image quality for photographs and
movies. This is the same as the [K] item in live control.
• You can change the JPEG image size and compression ratio combination, and [X] and
[W] pixel counts. [K Set], [Pixel Count] g “Image quality (record mode)” (P. 63)
Setting the self timer (j/Y)
You can customize the self timer operation.
Select [j/Y] in X Shooting Menu 2.
1
Select [YC] (custom) and press I.
2
Use FG to select the item and press I.
3
• Use FG to select the setting and press Q.
Frame Sets the number of frames to be shot.
Y Timer
Interval Time
Every Frame AF
Sets the time after the shutter button is pressed until the picture
is taken.
Sets the shooting interval for the second and subsequent
frames.
Sets whether or not to perform AF right before a picture is taken
with self timer.
Shooting Menu 2
1
Image Stabilizer
Bracketing
2
HDR
Multiple Exposure
Time Lapse Settings
# RC Mode
Back Set
6
Menu functions (Shooting menus)
oj /Y
Off
Off
Off
Off
Off
EN
75
Page 76
Varying settings over a series of photographs (bracketing)
“Bracketing” refers to the act of varying settings automatically over a series of shots
or a series of images to “bracket” the current value. You can store bracket shooting
settings and turn bracket shooting off.
Select [Bracketing] in X Shooting Menu 2 and
1
press Q.
After selecting [On], press I and select a bracket
2
shooting type.
• When you select bracket shooting, t appears on the
screen.
6
Menu functions (Shooting menus)
Press I, select settings for parameters such as the number of shots, and
3
then press the Q button.
• Continue to press the Q button until you return to the screen in step 1.
• If you select [Off] in step 2, bracket shooting settings will be saved and you can shoot
normally.
Cautions
• Cannot be used during HDR photography.
• Cannot be used at the same time as time lapse shooting.
• You cannot shoot during bracket shooting if there is not enough space on the camera’s
memory card for the selected number of frames.
AE BKT (AE bracketing)
The camera varies the exposure of each shot. The modifi cation amount can be selected from
0.3 EV, 0.7 EV, or 1.0 EV. In single-frame shooting mode, one photograph is taken each time
the shutter button is pressed all the way down, while in sequential shooting mode the camera
continues to take shots in the following order while the shutter button is pressed all the way
down: no modifi cation, negative, positive. Number of shots: 2, 3, 5, or 7
• The t indicator turns green during bracketing.
• The camera modifi es exposure by varying aperture and
shutter speed (mode P), shutter speed (modes A and M),
or aperture (mode S).
• The camera brackets the value currently selected for
exposure compensation.
• The size of the bracketing increment changes with the value
selected for [EV Step]. g “Using the custom menus” (P. 85)
j/Y o
1
Image Stabilizer
Bracketing
2
HDR
Multiple Exposure
Time Lapse Settings
# RC Mode
Back
AE BKT
WB BKT
FL BKT
ISO BKT
ART BKT
Back
AE BKT
WB BKT
FL BKT
ISO BKT
ART BKT
Back
Shooting Menu 2
Bracketing
Bracketing
Off
2f 0.3EV
2f 0.7EV
2f 1.0EV
3f 0.3EV
3f 0.7EV
3f 1.0EV
A-- G--
A-- G--
Off
Off
Off
Off
Off
Set
--
--
--
--
Set
--
--
--
--
--
Set
76
EN
Page 77
WB BKT (WB bracketing)
Three images with different white balances (adjusted in specifi ed color directions) are
automatically created from one shot, starting with the value currently selected for white
balance. WB bracketing is available in P, A, S and M modes.
• White balance can be varied by 2, 4, or 6 steps on each of
WB BKT
the A – B (Amber – Blue) and G – M (Green – Magenta) axes.
• The camera brackets the value currently selected for white
balance compensation.
A-B G-M
3f 4Step 3f 4Step
Back Set
FL BKT (FL bracketing)
The camera varies fl ash level over three shots (no modifi cation on the fi rst shot, negative on
the second, and positive on the third). In single-frame shooting, one shot is taken each time
the shutter button is pressed; in sequential shooting, all shots are taken while the shutter
button is pressed.
• The t indicator turns green during bracketing.
• The size of the bracketing increment changes with the value
selected for [EV Step]. g “Using the custom menus” (P. 85)
AE BKT
WB BKT
FL BKT
ISO BKT
ART BKT
Bracketing
Off
3f 0.3EV
3f 0.7EV
3f 1.0EV
A-- G--
--
--
--
--
6
Menu functions (Shooting menus)
Back
Set
ISO BKT (ISO bracketing)
The camera varies the sensitivity over three shots while keeping the shutter speed and
aperture fi xed. The modifi cation amount can be selected from 0.3 EV, 0.7 EV, or 1.0 EV. Each
time the shutter button is pressed, the camera shoots three frames with the set sensitivity
(or if auto sensitivity is selected, the optimal sensitivity setting) on the fi rst shot, negative
modifi cation on the second shot, and positive modifi cation on the third shot.
• The size of the bracketing increment does not change with
the value selected for [ISO Step]. g “Using the custom
menus” (P. 85)
• Bracketing is performed regardless of the upper limit set with
[ISO-Auto Set]. g “Using the custom menus” (P. 85)
Back
AE BKT
WB BKT
FL BKT
ISO BKT
ART BKT
Bracketing
Off
3f 0.3EV
3f 0.7EV
3f 1.0EV
A-- G--
--
--
--
--
Set
ART BKT (ART bracketing)
Each time the shutter is released, the camera records multiple
images, each with a different art fi lter setting. You can turn art
fi lter bracketing on or off separately for each picture mode.
• Recording may take some time.
• ART BKT cannot be combined with WB BKT or ISO BKT.
Back
ART BKT
Pop Art
Soft Focus
Pale&Light Color
Light Tone
Grainy Film
Pin Hole
Diorama
EN
77
Page 78
Taking HDR (High Dynamic Range) images
The camera shoots several images and automatically combines them into an HDR
image. You can also shoot several images and perform HDR imaging on a computer
(HDR bracketing photography).
Select [HDR] in X Shooting Menu 2 and press Q.
1
Select a type of HDR photography and press the Q button.
2
HDR1
6
HDR2
Menu functions (Shooting menus)
3F 2.0EV
5F 2.0EV
7F 2.0EV
3F 3.0EV
5F 3.0EV
Shoot.
3
• When you press the shutter button, the camera automatically shoots the set number
of images.
• If you assign HDR to a button using the [Button Function] (P. 94), you can press the
button to call up the HDR shooting screen.
Cautions
• In the case of HDR1 and HDR2, exposure compensation is not available.
• If you shoot with a slower shutter speed, there may be more noticeable noise.
• Attach the camera to a tripod or other stabilizing item and then shoot.
• The image displayed on the monitor while shooting will differ from the HDR-processed
image.
• In the case of HDR1 and HDR2, the HDR-processed image will be saved as a JPEG fi le.
When the image quality mode is set to [RAW], the image is recorded in RAW+JPEG. The
only image recorded in RAW is the image with suitable exposure.
• If set to HDR1/HDR2, the picture mode is fi xed to [Natural] and the color setting is fi xed to
[sRGB]. [Full-time AF] does not operate.
• Flash photography, bracketing, multiple exposure and time lapse shooting cannot be used
at the same time as HDR photography.
• You cannot shoot during HDR photography if there is not enough space on the camera’s
memory card for the selected number of frames.
Four shots are taken, each with a different exposure, and the
shots are combined into one HDR image inside the camera.
HDR2 provides a more impressive image than HDR1. ISO
sensitivity is fi xed to 200. Also, the slowest available shutter
speed is 1 second and the longest available exposure is 4
seconds.
HDR bracketing is performed. Select the number of images and
the exposure difference.
HDR imaging processing is not performed.
1
Image Stabilizer
Bracketing
2
HDR
Multiple Exposure
Time Lapse Settings
# RC Mode
Back Set
Shooting Menu 2
oj /Y
Off
Off
Off
Off
Off
78
EN
Page 79
Recording multiple exposures in a single image (multiple exposure)
Record multiple exposures in a single image, using the option currently selected for
image quality.
Select [Multiple Exposure] in X Shooting Menu 2.
1
Adjust settings.
2
Frame Select [2f].
Multiple Exposure
Frame
Auto Gain
Overlay Off
Off
Off
When set to [On], the brightness of each
frame is set to 1/2 and the images are
Auto Gain
overlaid. When set to [Off], the images are
overlaid with the original brightness of each
Back
Set
frame.
When set to [On], a RAW image recorded
Overlay
• a is displayed in the monitor while multiple exposure
Shoot.
3
on a card can be overlaid with multiple
exposures and stored as a separate image.
The number of pictures taken is one.
is in effect.
ISO
400
250 F5.6
0.00.0
P
01:02:0301:02:03
• a is displayed in green when shooting starts.
• Press D to delete the last shot.
• The previous shot is superimposed on the view through the lens as a guide to
framing the next shot.
% Tips
• To overlay 3 or more frames: Select RAW for [K] and use the [Overlay] option to make
repeated multiple exposures.
• For more information on overlaying RAW images: g “Image overlay” (P. 83)
Cautions
• The camera will not go to sleep while multiple exposure is in effect.
• Photographs taken with other cameras cannot be included in a multiple exposure.
• When [Overlay] is set to [On], the images displayed when a RAW image is selected are
developed with the settings at the time of shooting.
• To set the shooting functions, cancel multiple exposure shooting fi rst. Some functions
cannot be set.
• Multiple exposure is cancelled automatically from the fi rst picture in the following
situations.
The camera is turned off/The q button is pressed/The MENU button is pressed/The
shooting mode is set to a mode other than P, A, S, M/The battery power runs out/
Any cable is connected to the camera /You switch between the monitor and electronic
viewfi nder
• When a RAW image is selected using [Overlay], the JPEG image for the image recorded
in RAW+JPEG is displayed.
• When shooting multiple exposures using bracketing, priority is given to multiple exposure
shooting. While the overlay image is being saved, bracketing is reset to the factory default
setting.
6
3838
Menu functions (Shooting menus)
EN
79
Page 80
Shooting automatically with a fi xed interval (time lapse shooting)
You can set the camera to shoot automatically with a set time lapse. The shot frames
can also be recorded as into a single movie. This setting is only available in P/A/S/M
modes.
Perform the following settings under [Time Lapse Settings] in X Shooting
1
Menu 2.
Frame Sets the number of frames to be shot.
Start Waiting Time Sets waiting time before starting to shot.
Interval Time Sets interval between shots after shooting starts.
Sets recording format of frame sequence.
Time Lapse Movie
6
Menu functions (Shooting menus)
• The image quality of the movie is [Motion JPEG (HD)] and the frame rate 10fps.
Shoot.
2
• Frames are shot even if the image is not in focus after AF. If you wish to fi x the focus
position, shoot in MF.
• [Rec View] operates for 0.5 seconds.
• If either of the time before shooting, or shooting interval is set to 1 minute 31 seconds
or longer, the monitor and camera power will turn off after 1 minute. 10 seconds before
shooting, the power will automatically turn on again. When the monitor is off, press the
shutter button to turn it on again.
Cautions
• If the AF mode is set to [C-AF] or [C-AF+TR], it is automatically changed to [S-AF].
• Touch operations are disabled during time lapse shooting.
• Cannot be used with HDR photography.
• It is not possible to combine time lapse shooting with bracketing, multiple exposure, and
bulb, time or composite photography.
• The fl ash will not work if the fl ash charging time is longer than the interval between shots.
• If the camera automatically turns off in interval between shots, it will turn on in time for the
next shot.
• If the any of the still pictures are not recorded correctly, the time lapse movie will not be
generated.
• If there is insuffi cient space on the card, the time lapse movie will not be recorded.
• Time lapse shooting will cancelled if any of the following is operated: Mode dial, MENU
button, q button, lens release button, or connecting the USB cable.
• If you turn off the camera, time lapse shooting will be cancelled.
• If there is not enough charge left on the battery, the shooting may end partway through.
Make sure the battery is suitably charged before starting.
[Off]: Records each frame as a still picture.
[On]: Records each frame as a still picture and generates and
records a single movie from the frame sequence.
80
EN
Page 81
Wireless remote control fl ash photography
The supplied fl ash unit and external fl ash units that offer a remote control mode and
are designated for use with this camera can be used for wireless fl ash photography.
g “Wireless remote control fl ash photography” (P. 124)
Digital Zoom (Digital Tele-converter)
Digital Tele-converter is used to zoom in beyond the current zoom ratio. The camera
saves the center crop. Zoom is increased by about 2×.
Select [On] for [Digital Tele-converter] in W Shooting Menu 1.
1
The view in the monitor will be enlarged by a factor of two.
2
• The subject will be recorded as it appears in the monitor.
Cautions
• Digital zoom is not available with multiple exposures, in J mode, or when T, s, f,
w, or m is selected in SCN mode.
• This function is not available when [Movie Effect] is [On] in n mode.
• When a RAW image is displayed, the area visible in the monitor is indicated by a frame.
• AF target drops.
Using the playback menu
Playback Menu
m (P. 55)
R (P. 81)
Edit (P. 82)
Print Order (P. 113)
Reset Protect (P. 83)
Connection to Smartphone (P. 104)
Playback Menu
m
1
R
Edit
2
Print Order
Reset Protect
Connection to Smartphone
Back Set
6
Menu functions (Shooting menus)
Displaying images rotated (R)
When set to [On], photographs taken with the camera rotated in portrait orientation are
automatically rotated and displayed in portrait orientation.
EN
81
Page 82
Editing still images
Recorded images can be edited and saved as new images.
Select [Edit] in the q Playback Menu and press Q.
1
Use FG to select [Sel. Image] and press Q.
2
Use HI to select the image to be edited and press Q.
3
• [RAW Data Edit] is displayed if the picture is a RAW image, [JPEG Edit] if it is a JPEG
image. If the image was recorded in RAW+JPEG format, both [RAW Data Edit] and
[JPEG Edit] will be displayed. Select the menu for the image to be edited.
Select [RAW Data Edit] or [JPEG Edit] and press Q.
4
Create a JPEG copy of a RAW image edited according to the settings.
[Current]
RAW Data
6
Edit
Menu functions (Playback menus)
[Custom1]
[Custom2]
ART BKT
Choose from the following options:
[Shadow Adj]: Brightens a dark backlit subject.
[Redeye Fix]: Reduces the red-eye phenomenon during fl ash shooting.
[P]: Use the control dial (P) to choose the
size of the crop and FGHI to specify the
crop position.
The JPEG copy is processed using the current camera
settings. Adjust the camera settings before choosing this
option.
Editing can be performed while changing the settings on
the monitor. You can save the settings used.
The image is edited using settings for the selected art
fi lter.
82
JPEG Edit
When the settings are complete, press Q.
5
• The settings will be applied to the image.
Select [Yes] and press Q.
6
• The edited image is stored in the card.
[Aspect]: Changes the aspect ratio of images from 4:3 (standard) to [3:2],
[16:9], [1:1], or [3:4]. After changing the aspect ratio, use FGHI to
specify the trimming position.
[Black & White]: Creates black and white images.
[Sepia]: Creates sepia-toned images.
[Saturation]: Sets the color depth. Adjust the color saturation checking the
picture on the screen.
[Q]: Converts the image fi le size to 1280 × 960, 640 × 480, or 320 × 240.
Images with an aspect ratio other than 4:3 (standard) are converted to the
closest image fi le size.
[e-Portrait]: Makes skin look smooth and translucent.
You may not be able to compensate depending on the image if face
detection fails.
EN
O
Set
Page 83
Cautions
• 3D photos, movies, and temporarily saved fi les for PHOTO STORY cannot be edited.
• Red-eye correction may not work depending on the image.
• Editing of a JPEG image is not possible in the following cases:
When an image is processed on a PC, when there is not enough space in the card
memory, when an image is recorded on another camera
• When resizing ([Q]) an image, you cannot select a larger number of pixels than was
originally recorded.
• [P] and [Aspect] can only be used to edit images with an aspect ratio of 4:3 (standard).
• When [Picture Mode] is set to [ART], [Color Space] is locked to [sRGB].
Image overlay
Up to 3 frames of RAW images taken with the camera can be overlaid and saved as a
separate image.
The image is saved with the record mode set at the time the image is saved. (If [RAW]
is selected, the copy will be saved in [YN+RAW] format.)
Select [Edit] in the q Playback Menu and press Q.
1
Use FG to select [Image Overlay] and press Q.
2
Select the number of images in the overlay and press Q.
3
Use FGHI to select the RAW images that will
4
be used in the overlay.
• When you have selected the number of images
specifi ed in Step 3, the overlay will be displayed.
Adjust gain.
5
• Use HI to select an image and use FG to adjust
gain.
• Gain can be adjusted in the range 0.1 – 2.0. Check the
results in the monitor.
Press Q. A confi rmation dialog will be displayed; select [Yes] and press Q.
6
Image Overlay
RAW RAW RAW
RAW
RAW RAW RAW
Back
Image Overlay
×1.5×1.5×0.3 ×0.5
Back
Set
Set
% Tips
• To overlay 4 or more frames, save the overlay image as a RAW fi le and use
[Image Overlay] repeatedly.
Audio recording
Add an audio recording (up to 30 sec. long) to the current photograph.
This is the same function as [R] during playback. (P. 54)
Canceling all protections
This function lets you cancel the protection of several images at one time.
Select [Reset Protect] in the q Playback Menu.
1
Select [Yes] and press Q.
2
6
Menu functions (Playback menus)
EN
83
Page 84
Using the setup menu
Use the d Setup Menu to set the basic camera functions.
Option Description
X
(Date/time
setting)
W
(Changing
the display
language)
6
i
Menu functions (Setup menus)
(Monitor
brightness
adjustment)
Rec View Choose whether pictures are displayed immediately after shooting
Wi-Fi
Settings
c/#
Display
Firmware Your product’s fi rmware version will be displayed. When you make
Set the camera clock.
You can change the language used for the on-screen display and
error messages from English to another language.
You can adjust the brightness and
color temperature of the monitor. Color
temperature adjustment will affect only
the monitor display during playback.
Use HI to highlight j (color
temperature) or k (brightness) and
FG to adjust the value.
Press the INFO button to switch
Vivid Natural
Back Set
between [Natural] and [Vivid] monitor
color display.
and for how long. This is useful for making a brief check of the
picture you have just taken. Pressing the shutter button halfway
while checking the picture lets you resume shooting immediately.
[0.3sec] – [20sec]: Selects the number of seconds to display each
picture.
[Off]: The picture being recorded to the card is not displayed.
[Autoq]: Displays the image being recorded, and then switches to
playback mode. This is useful for erasing a picture after checking it.
Set up the camera to connect to a smartphone with wireless LAN
connectivity using the wireless function on the camera.
Choose whether to display the custom menus or accessory port
Menu
menu.
inquiries about your camera or accessories or when you want to
download software, you will need to state which version of each of
the products you are using.
Setup Menu
1
2
Rec View
Wi-Fi Settings
Menu Display
Firmware
-
2j+1
’--.--.-- --:--
k
English
0.5sec
SetBack
g
16
—
—
—
104
—
—
84
EN
Page 85
Using the custom menus
Camera settings can be customized using the c Custom Menu.
Custom Menu
AF/MF (P. 85)
R
Button/Dial (P. 86)
S
Release/j (P. 86)
T
U
Disp/8/PC (P. 87)
Exp/p/ISO (P. 88)
V
W
# Custom (P. 89)
K/Color/WB (P. 90)
X
Record/Erase (P. 91)
Y
Movie (P. 92)
Z
b K Utility (P. 92)
R AF/MF
Option Description
AF Mode Choose the AF mode. This is the same as the live control
Full-time AF If [On] is selected, the camera will continue to focus even
AEL/AFL Customize AF and AE lock. 93
Reset Lens When set to [Off], the focus position of the lens is not reset
BULB/TIME
Focusing
Focus Ring You can customize how the lens adjusts to the focal point by
MF Assist When set to [On], you can automatically switch to zoom or
P Set Home
AF Illuminat. Select [Off] to disable the AF illuminator. —
I Face Priority
AF Area Pointer If you select [Off], the AF target frame will not be displayed
setting. You can set separate focusing methods for still
photography mode and n mode.
when the shutter button is not pressed halfway. Cannot be
used when using a Four Thirds system lens.
even when the power is turned off. The focus of power
zoom lenses is also reset.
You can change the focus position during exposure by using
manual focus (MF). When set to [Off], rotation of the focus
ring is disabled.
selecting the rotational direction of the focus ring.
peaking in manual focus mode by rotating the focus ring.
Choose the AF target position that will be saved as the
home position. p appears in the AF target selection
display while you choose a home position.
You can select the face priority or eye priority AF mode. This
is the same as the live control setting.
during confi rmation.
Back
1
2
R
AF/MF
S
Button/Dial
T
Release/
U
Disp/8/PC
V
Exp/
W
#
X
K
MENU
Custom Menu
j
p
/ISO
Custom
/Color/WB
c
Set
R
g
69
—
—
—
—
93
—
48
—
6
Menu functions (Custom menus)
EN
85
Page 86
S Button/Dial
Option Description
Button Function Choose the function assigned to the selected button.
[FnFunction], [UFunction], [RFunction], [IFunction],
[GFunction], [nFunction], [lFunction]
Dial Function
6
Dial Direction
Menu functions (Custom menus)
Mode Dial
Function
You can change the function of the control dial (P).
PF / %
A Aperture value / F
S Shutter speed / F
M Shutter speed / Aperture value
[Prev/Next] / [G / Magnify]
q
In P, A, S, and M modes, the roles played before and after
F button is pressed are reversed.
Choose the direction in which the dial is rotated to adjust
shutter speed or aperture. Change the program shift direction.
You can assign registered Myset settings to any position
on the mode dial. [Myset1] - [Myset4] (P. 73) can be selected
when the settings are registered.
MENU
c
S
g
94
—
—
—
T Release/j
Option Description
Rls Priority S If [On] is selected, the shutter can be released even when
Rls Priority C
j L fps
j H fps
j Image
Stabilization
Half Way Rls
With IS
Lens I.S. Priority
Release Lag-Time If [Short] is selected, the time lag between fully pressing the
* This will shorten the battery life. Also make sure that the camera is not subject to sharp
impacts while in use. Such impacts may cause the monitor to stop displaying subjects. If
this happens, turn the power off and on again.
86
EN
the camera is not in focus. This option can be set separately
for S-AF (P. 69) and C-AF (P. 69) modes.
Choose the frame advance rates for [S] and [T]. Figures
are the approximate maximums.
Activates/deactivates image stabilization for continuous
shooting.
When set to [Off], the IS (Image Stabilization) function while
the shutter button is pressed halfway will not be activated.
If [On] is selected, priority is given to the lens function operation
when using a lens with an image stabilization function.
shutter button and the shot being taken can be shortened.*
MENU c
T
g
—
61
—
—
—
—
Page 87
U Disp/8/PC
Option Description
HDMI [HDMI Out]: Selecting the digital video signal format for
Video Out Choose the video standard ([NTSC] or [PAL]) used in your
KControl
Settings
G/Info Settings
Displayed Grid
Picture Mode
Settings
Histogram
Settings
Mode Guide Choose [Off] to not display help for the selected mode when
Live View Boost If [On] is selected, priority will be given to making images
Frame Rate Select [High] to reduce frame lag. However, the image
Art LV Mode [mode1]: The fi lter effect is always displayed.
LV Close Up Mode [mode1]: Pressing the shutter button halfway cancels zoom.
Flicker reduction Reduce the effects of fl icker under some kinds of lighting,
connecting to a TV via an HDMI cable.
[HDMI Control]: Select [On] to allow the camera to be
operated using remotes for TVs that support HDMI control.
country or region.
Choose the controls displayed in each shooting mode.
Controls
Live Control (P. 56)
Live SCP (P. 98)
Live Guide (P.24)
Art Menu ––
Scene Menu –––
Choose the information displayed when the INFO button is
pressed.
[q Info]: Choose the information displayed in full frame
playback.
[LV-Info]: Choose the information displayed when the
camera is in shooting mode.
[G Settings]: Choose the information displayed in index
and calendar playback.
Select [w], [x], [y], [X] or [x] to display a grid on the
monitor.
Display only the selected picture mode when a picture
mode is selected.
[Highlight]: Choose the lower bound for the highlight display.
[Shadow]: Choose the upper bound for the shadow display.
the mode dial is rotated to a new setting.
clearly visible; the effects exposure compensation and other
settings will not be visible in the monitor.
quality may drop.
[mode2]: Filter effects are not visible in the monitor while
the shutter button is pressed halfway. Choose for a smooth
display.
[mode2]: Zoom is not cancelled when the shutter button is
pressed halfway.
including fl uorescent lamps. When fl icker is not reduced by
the [Auto] setting, set to [50Hz] or [60Hz] in accordance with
the commercial power frequency of the region where the
camera is used.
Shooting mode
P/A/
A
S/M
MENU
ART SCN
–––
–
c
U
g
96
96
97
6
Menu functions (Custom menus)
99,
100
—
—
99
17
—
—
—
49
—
EN
87
Page 88
U Disp/8/PC
Option Description
z lock
q Close Up Mode
Peaking Settings You can switch the edge enhancement color between white
Backlit LCD If no operations are performed for the selected period, the
Sleep The camera will enter sleep (energy saving) mode if no
6
Menu functions (Custom menus)
8 (Beep sound)
USB Mode Choose a mode for connecting the camera to a computer or
If [On] is selected, the preview switches between lock and
release every time the button registered for preview is
pressed.
[mode1]: Press U to zoom in (to a maximum of 14 ×) and
press G to zoom out.
[mode2]: Press U to display the zoom frame for the
specifi ed zoom ratio. Press U again to zoom in.
and black.
backlight will dim to save battery power. The backlight will
not dim if [Hold] is selected.
operations are performed for the selected period. The
camera can be reactivated by pressing the shutter button
halfway.
When set to [Off], you can turn off the beep sound that is
emitted when the focus locks by pressing the shutter button.
printer. Choose [Auto] to display USB mode options every
time the camera is connected.
V Exp/p/ISO
Option Description
EV Step Choose the size of the increments used when selecting
Noise Reduct. This function reduces the noise that is generated during
Noise Filter Choose the amount of noise reduction performed at high
ISO Set ISO sensitivity. 70
ISO Step Select the increments available for choosing ISO sensitivity. —
ISO-Auto Set Choose the upper limit and default value used for ISO
shutter speed, aperture, exposure compensation, and other
exposure parameters.
long exposures.
[Auto]: Noise reduction is performed at slow shutter speeds,
or when the internal temperature of the camera has risen.
[On]: Noise reduction is performed with every shot.
[Off]: Noise reduction off.
• After shooting, processing time takes about the same
amount of time as shooting time.
• Noise reduction turns off automatically during sequential
shooting.
• This function may not work effectively with some shooting
conditions or subjects.
ISO sensitivities.
sensitivity when [Auto] is selected for ISO.
[High Limit]: Choose the upper limit for auto ISO sensitivity
selection.
[Default]: Choose the default value for auto ISO sensitivity
selection.
MENU c
MENU
c
U
g
—
—
—
—
—
—
—
V
g
—
35
—
—
88
EN
Page 89
V Exp/p/ISO
Option Description
ISO-Auto Choose the shooting modes in which [Auto] ISO sensitivity
Metering Choose a metering mode according to the scene. 68
AEL Metering Choose the metering method used for AE lock (P. 93).
BULB/TIME Timer Choose the maximum exposure for bulb and time
BULB/TIME
Monitor
Live BULB Choose the display interval during shooting. Some
Live TIME
Anti-Shock z
Composite
Settings
is available.
[P/A/S]: Auto ISO sensitivity selection is available in all
modes except M. ISO sensitivity is fi xed at ISO200 in mode
M.
[All]: Auto ISO sensitivity selection is available in all modes.
[Auto]: Use the currently selected metering method.
photography.
Set the monitor brightness when [BULB], [TIME], or [COMP]
is used.
restrictions apply. The frequency drops at high ISO
sensitivities. Choose [Off] to disable the display. Tap the
monitor or press the shutter button halfway to refresh the
display.
Choose the delay between the shutter button being
pressed and the shutter being released. This diminishes
camera shake caused by vibrations. This feature is
useful in situations such as microscope photography and
astrophotography.
Choose 0 seconds when you want to reduce slight blurring
due to shutter operation.
It is also useful for sequential shooting (P. 61) and self timer
photography (P. 61). However, sequential shooting is not
available when this setting is set to 0 seconds.
Set an exposure time to be the reference in composite
photography (P. 36).
MENU c
V
g
—
—
—
—
—
—
—
—
6
Menu functions (Custom menus)
W # Custom
Option Description
# X-Sync.
# Slow Limit
w+F
Choose the shutter speed used when the fl ash fi res.
Choose the slowest shutter speed available when a fl ash
is used.
When set to [On], the exposure compensation value is
added to the fl ash compensation value.
MENU
c
46, 68
W
g
100
100
EN
89
Page 90
X K/Color/WB
Option Description
K Set
Pixel Count
6
Menu functions (Custom menus)
You can select the JPEG image quality mode from
combinations of three image sizes and four compression
rates.
1) Use HI to select a
combination ([K1] –
[K4]) and use FG to
change.
2) Press Q.
Choose the pixel count for [X]- and [W]-size images.
1) Select [Xiddle] or
[Wmall] and press I.
2) Choose a pixel count
and press Q.
1
SF
Y
Back
Image size
Xiddle
Wmall
Back
D
2
F
X
Pixel Count
Pixel Count
MENU
Set
3
4
N
W
SF
W
F
Set
Compression
rate
2560×1920
1280×960
Set
c
X
g
63
63
Shading Comp. Choose [On] to correct peripheral illumination according to
the type of lens.
• Compensation is not available for teleconverters or
extension tubes.
• Noise may be visible at the edges of photographs taken at
high ISO sensitivities.
WB Set the white balance. This is the same as the live control
setting. You can also fi ne-tune the white balance for each
mode.
All >
[All Set]: Use the same white balance compensation in all
modes except [CWB].
[All Reset]: Set white balance compensation for all modes
except [CWB] to 0.
W Keep Warm
Color
#+WB
Select [Off] to eliminate “warm” colors from pictures taken
under incandescent lighting.
Adjust white balance for use with a fl ash.
Color Space You can select how colors are reproduced on the monitor
or printer.
90
EN
—
58
—
—
—
—
Page 91
Y Record/Erase
MENU
c
Option Description
Quick Erase
If [On] is selected, pressing the D button in the playback
display will immediately delete the current image.
RAW+JPEG Erase Choose the action performed when a photograph recorded
at a setting of RAW+JPEG is erased in single-frame
playback (P. 28).
[JPEG]: Only the JPEG copy is erased.
[RAW]: Only the RAW copy is erased.
[RAW+JPEG]: Both copies are erased.
• Both the RAW and JPEG copies are deleted when selected
images are deleted or when [All Erase] (P. 72) is selected.
File Name [Auto]: Even when a new card is inserted, the fi le numbers
are retained from the previous card. File numbering
continues from the last number used or from the highest
number available on the card.
[Reset]: When you insert a new card, the folder numbers
starts at 100 and the fi le name starts at 0001. If a card
containing images is inserted, the fi le numbers start at the
number following the highest fi le number on the card.
Edit Filename Choose how image fi les are named by editing the portion of
the fi lename highlighted below in gray.
sRGB: Pmdd0000.jpg Pmdd
Adobe RGB: _mdd0000.jpg mdd
Priority Set Choose the default selection ([Yes] or [No]) for confi rmation
dialogs.
dpi Settings Choose the print resolution. —
Copyright
Settings*
Add the names of the photographer and copyright holder to
new photographs. Names can be up to 63 characters long.
[Copyright Info.]: Select [On] to include the names of the
photographer and copyright holder in the Exif data for new
photographs.
[Artist Name]: Enter the name of the photographer.
[Copyright Name]: Enter the name of the copyright holder.
1) Highlight a character 1 and press Q to add the
highlighted character to the name 2.
2) Repeat Step 1 to complete the name, then highlight
[END] and press Q.
• To delete a character, press the INFO button to
place the cursor in the name area 2, highlight the
character, and press D.
Copyright Name
ABCDE
2
!”#$%&()*+, - . /
01234567’89: ;<=>?
@
ABCDEF GH I J KLMNO
1
PQR S TU VWXY Z
a b c d e f g h i j k l m n END
opqr s tuvwxy z
Cancel Set
Delete
05/63
[]_
{}
Y
g
—
63
—
6
Menu functions (Custom menus)
—
—
—
* OLYMPUS does not accept liability for damages arising from disputes involving the use of
[Copyright Settings]. Use at your own risk.
EN
91
Page 92
Z Movie
Option Description
nMode
Movie R
Movie Effect
Wind Noise
Reduction
Recording Volume Adjust sensitivity separately for each microphone of the
K Volume
Limiter
Movie+Photo
6
Mode
Menu functions (Custom menus)
Choose a movie record mode. This option can also be
selected using the live control.
Choose [Off] to record silent movies. This option can also
be selected using the live control.
Choose [On] to enable movie effects in n mode.
Reduce wind noise during recording.
camera. Adjust the sensitivity using FG while checking
the peak sound level picked up by the microphone over the
previous few seconds.
If [On] is selected, the volume is automatically regulated
when the volume picked up by the microphone is louder
than normal.
Choose the way in which photographs are taken during
movie recording.
[mode1]: Take photographs during movie recording without
stopping recording.
[mode2]: Stop recording to take photographs. Recording will
resume after the photograph is taken.
MENU
c
Z
g
62
70
37
—
—
—
21
b K Utility
Option Description
Pixel Mapping The pixel mapping feature allows the camera to check and
Exposure Shift Adjust correct exposure separately for each metering mode.
: Warning
Level
Level Adjust You can calibrate the angle of the level gauge.
Touch Screen
Settings
Eye-Fi* Enable or disable upload when using an Eye-Fi card. Displayed
Electronic
Zoom Speed
* Use in accordance with local regulations. Onboard airplanes and in other locations in
which the use of wireless devices is prohibited, remove the Eye-Fi card from the camera,
or select [Off] for [Eye-Fi]. The camera does not support the “endless” Eye-Fi mode.
92
EN
adjust the image pickup device and image processing functions.
• This reduces the number of exposure compensation options
available in the selected direction.
• The effects are not visible in the monitor. To make normal
adjustments to the exposure, perform exposure compensation
(P. 46).
Choose the battery level at which the 8 warning is displayed.
[Reset]: Resets adjusted values to the default settings.
[Adjust]: Sets the current camera orientation as the 0 position.
Activate the touch screen. Choose [Off] to disable the touch
screen.
when an Eye-Fi card is inserted.
You can change the zoom speed used when operating the power
zoom lens with the zoom ring.
MENU c
b
g
135
—
15
—
—
—
119
Page 93
AEL/AFL
MENU c R [AEL/AFL]
Autofocus and metering can be performed by pressing the
button to which AEL/AFL has been assigned. Choose a
mode for each focus mode.
AEL/AFL
Shutter button function
Mode
mode1 S-AF Locked – – – Locked
S-AF
mode2 S-AF – – Locked – Locked
mode3 – Locked – – S-AF –
mode1 C-AF start Locked Locked – – Locked
mode2 C-AF start – Locked Locked – Locked
C-AF
mode3 – Locked Locked – C-AF start –
mode4 – – Locked Locked C-AF start –
mode1 – Locked – – – Locked
MF
mode2 – – – Locked – Locked
mode3 – Locked – – S-AF –
Half-press Full press
Focus Exposure Focus Exposure Focus Exposure
S-AF AEL/AFL
mode1
AEL/S-AF
Half Way
ExposureFully
AEL
AEL
AFL
Back Set
AEL/AFL Button
function
When holding down
AEL/AFL
MF Assist
MENU c R [MF Assist]
This is a focus assist function for MF. When the focus ring is rotated, the edge of the
subject is enhanced or a portion of the screen display is magnifi ed. When you stop
operating the focus ring, the screen returns to the original display.
Magnify Magnifi es a portion of the screen. The portion to be magnifi ed
Peaking Displays clearly defi ned outlines with edge enhancement. You
can be set in advance using AF target. g [AF Area] (P.47)
can select the enhancement color. g [Peaking Settings] (P.88)
6
Menu functions (Custom menus)
$ Notes
• [Peaking] can be displayed using button operations. The display is switched every time
the button is pressed. Assign the switching function to one of the buttons in advance using
[Button Function] (P. 94).
Cautions
• When Peaking is in use, the edges of small subjects tend to be enhanced more strongly.
This is no guarantee of accurate focusing.
EN
93
Page 94
Button Function
MENU c S [Button Function]
See the table below for the functions that can be assigned. The options available vary from
button to button.
Button function items
[FnFunction] / [UFunction] / [RFunction]*
([Direct Function]*
*1 Not available in n mode.
*2 Assign the function to each of FGHI.
*3 Choose the AF target.
*4 Choose the function assigned to the button on some lenses.
F
ISO Adjust ISO sensitivity.
WB Adjust white balance.
AEL/AFL AE lock or AF lock. The function changes according to the
6
Menu functions (Custom menus)
R REC
z (Preview)
k (One-touch white
balance)
P (AF area)
P Home
MF Press the button to select manual focus mode. Press the
RAWK
K TEST (Test Picture)
Myset1 – Myset4 Switches among the registered Myset settings when the
u
I/H The button can be used to choose between I and H while
Live Guide Press the button to display live guides.
2
/ [P]*3) / [lFunction]*
Adjust exposure compensation.
[AEL/AFL] setting. When AEL is selected, press the button
once to lock the exposure and display u on the monitor.
Press the button again to cancel the lock.
Press the button to record a movie.
Aperture is stopped down to the selected value while the
button is pressed.
If [On] is selected for [z Lock] in Custom Menu, the aperture
is held at the selected value even when releasing the button.
The camera measures white balance when the button is
pressed (P. 59).
Choose the AF target.
Pressing the button selects the AF target position saved with
[P Set Home] (P. 85). Press the button again to return to
AF target mode. If the camera is turned off when the home
position is selected, the home position will be reset.
button again to restore the previously selected AF mode.
Press the button to toggle between JPEG and RAW+JPEG
record modes.
Pictures taken while the button is pressed are displayed in the
monitor but are not recorded to the memory card.
button is pressed. Press the button again to return.
Turn the monitor backlight on and off.
the underwater case is attached. Press and hold the button
to return to the previous mode. If you assign this function to
a button, switching between I and H while using a lens
with power zoom functionality will automatically set lens to the
WIDE end or TELE end.
1
/ [IFunction] / [GFunction] / [nFunction] /
4
94
EN
Page 95
b (Digital Tele-
converter)
a (Magnify)
Peaking Each press of the button switches the monitor between
AF Stop Stops autofocus.
j/Y
#
HDR Switches to HDR shooting with the saved settings.
BKT Turns on BKT shooting using stored settings.
GLock (Touch panel
lock)
Electronic Zoom When using a lens with a power zoom function, after pressing
Press the button to turn digital zoom on or off.
Press the button to display the zoom frame. Press again to
magnify the image. Press and hold the button to turn off the
zoom frame.
display/non-display. When Peaking is displayed, histogram
and highlight/shadow display are not available.
Choose a sequential shooting or self timer option.
Choose a fl ash mode.
Press and hold the button to enable and disable touch panel
operation.
the button, use the arrow pad for zooming operations.
6
Menu functions (Custom menus)
EN
95
Page 96
Viewing camera images on TV
MENU c U [HDMI], [Video Out]
Use the separately sold cable with the camera to playback recorded images on your
TV. Connect the camera to an HD TV using an HDMI cable to view high-quality images
on a TV screen. When connecting TVs using an AV cable, fi rst set the camera’s [Video
Out] settings (P. 87).
Multi-connector
AV cable (optional: CB-AVC3)
(Connect to the TV video input jack
(yellow) and audio input jack (white).)
6
Type A
Menu functions (Custom menus)
HDMI cable
HDMI connector
(type D)
Connect the TV and camera and switch the input source of the TV.
1
• The camera monitor turns off when the cable is connected.
• Press the q button when connecting via an AV cable.
Cautions
• For details on changing the input source of the TV, refer to the TV’s instruction manual.
• Depending on the TV’s settings, the displayed images and information may become
cropped.
• If the camera is connected using both an AV and HDMI cables, it will assign priority to
HDMI.
• If the camera is connected via an HDMI cable, you will be able to choose the digital video
signal type. Choose a format that matches the input format selected with the TV.
1080i Priority is given to 1080i HDMI output.
720p Priority is given to 720p HDMI output.
480p/576p
• You cannot shoot pictures or movies when the HDMI cable is connected.
• Do not connect the camera to other HDMI output devices. Doing so may damage the
camera.
• HDMI output is not performed while connected via USB to a computer or printer.
480p/576p HDMI output. 576p is used when [PAL] is selected for
[Video Out] (P. 87).
(Connect to the HDMI connector on the TV.)
96
EN
Page 97
Using the TV remote control
The camera can be operated by a TV remote control when connected to a TV that
supports HDMI control. g [HDMI] (P. 87)
$ Notes
• You can operate the camera by following the operation guide displayed on the TV.
• During single-frame playback, you can display or hide the information display by
pressing the “Red” button, and display or hide the index display by pressing the
“Green” button.
• Some televisions may not support all features.
Choosing the control panel displays
MENU c U [ KControl Settings]
Sets whether or not to display control panels for option selection in each shooting
mode.
In each shooting mode, press Q to insert a check in the control panel you want to
display.
How to display control panels
• Press the
button to switch the display.
Q button while the control panel is displayed, then press the INFO
A
P/A/S/M
Q
Q
Change Color Saturation
Live guide
AUTOAUTO
AUTOAUTO
P
Live control
WB Auto
S-IS AUTOS-IS AUTO
WB
WBWBWB
WB
WBWBWB
AUTO
AUTOAUTOAUTO
AUTO
AUTOAUTOAUTO
4:3
L
FullHD
N
F
INFO
INFO
AUTOAUTO
AUTOAUTO
Live control
WB
ISO
AUTO
AUTO
250250 F5.6
LV super control
panel (P. 98)
S-IS AUTOS-IS AUTO
INFO
WB
WBWBWB
WB
WBWBWB
AUTO
AUTOAUTOAUTO
AUTO
AUTOAUTOAUTO
4:3
L
N
FullHD
WB Auto
F
WB
AUTO
NORM
i
4:3
01:02:0301:02:03
10231023
INFO
WB
ISO
WB
AUTO
AUTO
AUTO
LV super control
panel (P. 98)
250250 F5.6
i
4:3
INFO
6
Menu functions (Custom menus)
NORM
01:02:0301:02:03
10231023
ART/SCN
Q
Art fi lter menu
Pop Art
1
Portrait
1
Scene menu
INFO
WB Auto
AUTOAUTO
AUTOAUTO
Live control
S-IS AUTOS-IS AUTO
WB
WBWBWB
WB
WBWBWB
AUTO
AUTOAUTOAUTO
AUTO
AUTOAUTOAUTO
4:3
L
FullHD
N
F
INFO
WB
ISO
WB
AUTO
AUTO
AUTO
LV super control
4:3
250250 F5.6
panel (P. 98)
i
INFO
NORM
01:02:0301:02:03
10231023
97
EN
Page 98
LV super control panel
The LV super control panel displays the current status of the shooting settings. You can
use it to set different options. Select options using the arrow pad or touch operations to
change the settings.
1
Recommended ISO
ISO
AUTO
AUTO
WB
AUTO
250250 F5.6
2
3
4
5
P
Settings that can be modifi ed using LV super control panel
1 Currently selected option
6
2 ISO sensitivity .................................P. 70
3 Flash mode .....................................P. 65
Menu functions (Custom menus)
4 Flash intensity control .....................P. 68
5 Sequential shooting/self-timer ........P. 61
6 White balance .................................P. 58
White balance compensation
7 Picture mode...................................P. 60
8 Sharpness N..................................P. 74
Contrast J .....................................P. 74
Saturation T .................................P. 74
Cautions
• Not displayed in movie record mode.
After displaying the live control, press the
1
INFO button.
• The LV super control panel is displayed.
• Each time you press the INFO button, the
display switches.
Tap the desired item.
2
• The item will be highlighted.
Press the Q button, and select a settings
3
option.
$ Notes
• Also available in the ART or SCN menu screens.
Touch the icon of the function you wish to select.
6
7
8
NORM
4:3
0.00.0
cdfe b
i
a
01:02:0301:02:03
10231023
9
0
Gradation z...................................P. 74
B&W Filter x .................................P. 74
Picture tone y ...............................P. 75
9 Color space.....................................P. 90
0 Button function assignment ............P. 94
a Face priority ....................................P. 48
b Metering mode ................................P. 68
c Aspect ratio .....................................P. 62
d Record mode ..................................P. 63
e AF mode .........................................P. 69
AF target .........................................P. 47
f Image stabilizer...............................P. 57
WB Auto
AUTOAUTO
AUTOAUTO
P
Recommended ISO
ISO
Cursor
WB
AUTO
AUTO
AUTO
250250 F5.6
WB
ISO
WB
AUTO
AUTO
AUTO
250250 F5.6
i
4:3
i
4:3
S-IS AUTOS-IS AUTO
AUTO
AUTOAUTOAUTO
NORM
01:02:0301:02:03
10231023
NORM
01:02:0301:02:03
10231023
WB
WBWBWB
WB
WBWBWB
AUTO
AUTOAUTOAUTO
4:3
L
N
FullHD
F
98
EN
Page 99
Adding information displays
MENU c U [ G/Info Settings]
LV-Info (Shooting information displays)
Use [LV-Info] to add the following shooting information displays. The added displays are
displayed by repeatedly pressing the INFO button during shooting. You can also choose to
not show displays that appear at the default setting.
ISO
200
P
250250 F5.6
Highlight & Shadow
display
Highlight & Shadow display
Areas above the upper limit of brightness for the image are shown in red, those below the
lower limit in blue. g [Histogram Settings] (P. 87)
q Info (Playback information displays)
Use [q Info] to add the following playback information displays. The added displays are
displayed by repeatedly pressing the INFO button during playback. You can also choose to
not show displays that appear at the default setting.
×10×10
L
N
HD
01:02:0301:02:03
0.00.0
3838
6
Menu functions (Custom menus)
Highlight
15
Shadow
15
1615
Highlight & Shadow display Light box displayHistogram display
Light box display
[q Close Up Mode] in the custom menu must be set to [mode2] to show this display.
Compare two images side-by-side. You can move the selected image on the right to the
reference image on the left by pressing Q.
• The base image is displayed on the right. Using the control dial (P) or HI to select an
image and pressing Q moves that image to the left screen. The image to be compared
to the image on the left can be selected on the right. To choose a different base image,
highlight the right frame and press Q.
• To zoom in, choose the image to be zoomed by using the U button, press the INFO
button, and then use FG or the control dial (P) to change the zoom ratio.
• Use FGHI to view other areas of the picture. The image to be zoomed changes each
time U is pressed.
U UU
2x
2x
2x
53 54
EN
99
Page 100
G Settings (Index/calendar display)
Q
You can add an index display with a different number of frames and calendar display
using [G Settings]. The additional screens are displayed by pressing the G button
during playback.
Wi-Fi
2014.07.0112:30 20
Single-frame
playback
Shutter speeds when the fl ash fi res automatically
MENU c W [ # X-Sync.] [# Slow Limit]
6
You can set shutter speed conditions for when the fl ash fi res.
Menu functions (Custom menus)
Shooting
mode
P
A
S
M
G
100-0020
L
N
U
2014.07.0112:30 20
4 frames
Flash timing
(synchronous)
The slower of 1/(lens focal
length×2) and the
[# X-Sync.] settings
The set shutter speed No lower limit
G
2014.07.01 12:30 20
U
2014.07.0112:30 20
9–100 frames
Index display
Upper limit Lower limit
[# X-Sync.] setting*
[# Slow Limit] setting
* 1/200 seconds or 1/180 seconds (FL-50R only) when using a separately sold external
fl ash.
G
U
Calendar display
2014.7
Sun Mon Tue Wed Thu Fri Sat
29 30 1 2 3 4 5
29 30 1 2 3 4 5
6 7 8 9 10 11 12
6 7 8 9 10 11 12
13 14 15 16 17 18 19
13 14 15 16 17 18 19
20 21 22 23 24 25 26
20 21 22 23 24 25 26
27 28 29 30 31 1 2
27 28 29 30 31 1 2
3 4 5 6 7
3 4 5 6 7
Q
100
EN
Loading...
