Part no. SD 021_2

Issued 2009-03-25

Part No. Pcs.
Steering damper SD 021 1
Öhlins sticker 00192-01 2
Öhlins Owner’s manual 07261-01 1

Before installing this product, check the
contents of the kit. If anything is missing, please
contact your nearest Öhlins dealer.

Kit Contents

Please note that during storage and
transportation, especially at high ambient
temperature, some of the oil and grease used for
assembling may leak and stain the packaging.
This is in no way detrimental to the product,
wipe off the excessive oil/grease with a cloth.

Warning!

Before installing this product, read the Öhlins
Owner’s Manual. The shock absorber is an
important part of your vehicle and may affect the
stability.

Steering Damper
for Kawasaki ZX6R/ ZX10R

SD 021

Mounting Instructions

1

How to install

Warning!

It is advisable to have an Öhlins dealer install the
steering damper.

When installing, consult your Vehicle Service
Manual.

1

Remove the original steering damper.

2

Install the SD 021 Steering Damper in the
same way as the original unit. Use original
attachment parts.

3

Set the damper to the recommeded set-up in
this folder.

Caution!

Make sure that all screws are tightened to the
correct torque and that nothing fouls or restricts
movement of the steering damper.

Adjustments

Recommended set-up 10 clicks

Set-up Data

Adjuster knob

Warning!

Before riding, always make sure that the
basic settings made by Öhlins are according
to recommended Set-up Data. Read about
adjustments and setting up in the Öhlins
Owner’s Manual before you make any
adjustments. Contact an Öhlins dealer if you
have any questions about setting up the steering
damper.

2
