USER GUIDE

TABLE OF CONTENTS

WELCOME ........................................................... 3

In The Box .......................................................... 4

Overview ............................................................ 5

System Requirements ........................................5

Charging The Internal Battery ...........................5

Status Indicator .................................................5

Radar Pace App .................................................5

Pairing With Phone And External Sensors ........ 5

Power Button ..................................................... 6

Touch Pad ........................................................... 7

Changing The Lens ............................................7

Attaching The Aero Clip ....................................7

INTERACT WITH RADAR PACE .......................8

COACHING PHILOSOPHY ................................. 9

TRAINING PROGRAMS ...................................12

TROUBLESHOOTING .......................................12

Sensor Pairing ..................................................12

Resetting Radar Pace ......................................13

MAINTENANCE ................................................ 13

Storing Radar Pace .......................................... 13

Charging ...........................................................14

Cleaning And Maintenance ............................. 14

TECHNICAL SPECIFICATIONS ....................... 15

SUPPORT ........................................................... 15

Oakley Limited Warranty ................................. 16

2 | OAKLEY RADAR PACE USER GUIDE

WELCOME

Say hello to your new personal coach.

RADAR PACE is a real-time voice activated coaching
system. It’s like having a trainer with you whenever
you’re running or cycling, a mentor that gives you the
help and motivation you need to take performance to a
whole new level.

There isn’t much motivation in raw numbers, so instead
of dumping data for a coach to analyze after your
session, RADAR PACE becomes your personal coach
in the here and now. It interprets your information and
communicates with you during your running or cycling
session, providing feedback in real time. All the vital
information is stored for later, but you don’t have to wait
to take advantage of it.

There’s a lot of technology packed into RADAR PACE.
An integrated gyroscope, accelerometer and proximity
sensor combined with a mobile phone app, monitor
what you’re doing and how you move. A pressure sensor
gauges the environment and adjusts your workout plan
as things change. And RADAR PACE lets you interface
with all that technology in the best possible way — by
eliminating the interface. You simply talk to it.

Speak freely. With RADAR PACE, communication is
intuitive and natural. Ask it workout-related questions
in different ways, as though you’re speaking to an
actual coach who’s right there with you and knows how
hard you’re pushing yourself on rides and runs. It even
understands the context of your questions, so go ahead
and ask follow-up questions.

Whether you’re taking on a hill or stopping to rest,
RADAR PACE will know where you are and what you’re
doing, and it gives you relevant information in the right
moment. And just like a real coach, it learns about you
and uses that knowledge to provide dynamic, custom
training that continually adapts to help you improve.

™

With ANT+

and Bluetooth® connectivity, RADAR PACE

can link wirelessly to most added external sensors to

enhance the experience. Forget about slowing down and
reaching for something to see a readout. Simply say,
“Okay Radar...” to get its attention, then the information
you need can be accessed with a simple question. When
your heart rate sensor is wirelessly linked, all you have
to do is ask, “What’s my heart rate?” or just say, “heart
rate.”

To use this smart eyewear, connect it wirelessly to your
smartphone. A handy app makes setup easy and lets
you tell RADAR PACE your training goals and access
performance metrics. Let it know about an upcoming
event and it will develop a training plan that assesses
your level of preparation and dynamically adapts your
ongoing training.

An indicator light tells you the status of remaining
battery power and helps you with wireless pairing, and
a touch pad on the frame lets you control even more
functions with simple taps and swipes. You can adjust
volume, control music, answer calls, and more from your
paired phone.

The water-resistant design is a showcase of Oakley’s
best performance eyewear technologies including

™

comfortably lightweight O Matter

®

and pure Plutonite

for the lens. RADAR PACE uses an

frame material,

interchangeable lens design so you can adapt quickly

™

and easily to the environment. Oakley’s Prizm

Road lens
helps endurance athletes spot subtle changes in the
texture of road surfaces, and see hazards more easily
so they can react faster and perform at their best. The
unrivaled optics maintain razor-sharp clarity at all angles
of view — even at the sides of sweeping contours
that extend peripheral vision while maximizing side
protection against sun, wind and impact.

The power of technology meets the power of possibility.
We put the best of everything into the world’s first real­time voice activated coaching system. With your new
personal trainer for running and cycling, it’s time to reach
for the next level and beyond. Possibility is waiting.

3 | OAKLEY RADAR PACE USER GUIDE

IN THE BOX

The following items are included in the box:

8

2

1

7

5

3

4

1. Eyewear Case

™

2. RADAR PACE with PRIZM

3. 2 Ear Booms

4. Clear Lens for Low Light Conditions

5. RADAR PACE Large Nose Pad

6. Aero Clip

7. RADAR PACE Micro USB Cable

8. Micro Bag

9. Quick Start Guide*

10. Warranty Card*

Road Lens with Small Nose Pad

6

*Not pictured above

4 | OAKLEY RADAR PACE USER GUIDE

OVERVIEW

SYSTEM REQUIREMENTS

™

To use RADAR PACE, you need an Android
(iOS 9 or later).

CHARGING THE BATTERY

Remove either earpiece by pulling it straight down. Plug the RADAR PACE Micro USB cable into the exposed port.
Plug the other end of the cable into any available adapter rated for 5V output. The indicator light on RADAR PACE
will glow green when charging is complete. A full charge requires approximately three hours.

IMPORTANT: Oakley RADAR PACE comes with a specially designed Micro USB cable. Before charging RADAR PACE,
always make sure the USB ports are clean and sweat-free.

STATUS INDICATOR

RADAR PACE has an indicator light that lets you check the status of remaining battery power, and tells you when it is

®

pairing with a Bluetooth

-enabled device.

WHILE CHARGING:

GREEN: Remaining power is greater than 99%

YELLOW: Remaining power is between 50% and 99%

RED: Remaining power is less than 50%

WHILE POWERED ON:

LIGHT BLUE FLASHING: Booting up or shutting down

LIGHT BLUE SOLID: Device is ready

®

DARK BLUE FLASHING: Bluetooth

RED FLASHING: Factory reset mode

pairing mode

smartphone (version 4.4 or later) or an Apple® iPhone® 5S or later

RADAR PACE APP

Download the RADAR PACE app on your smartphone from the Apple® App Store® or on Google Play™. Launch the app
and follow the onscreen instructions. Let the app help you pair RADAR PACE with your phone and external sensors.
Use the app to give RADAR PACE the information it needs to build your personal training program.

PAIRING WITH PHONE AND EXTERNAL SENSORS

Pair RADAR PACE with your smartphone by pressing the power button twice quickly. The indicator light will flash dark
blue. If pairing is successful, it will turn solid light blue.

A solid dark blue light indicates pairing was not successful. Ensure RADAR PACE is in pairing mode by pressing the
power button twice quickly. Also note that pairing should be done only via the RADAR PACE app; do not pair via any
other application on your phone.

After pairing with your smartphone is complete, the app will assist you with pairing external sensors such as your
heart rate monitor and speed sensor. Be sure the devices are powered on and ready for pairing. If you are unable to

®

pair RADAR PACE with a sensor, have your phone “forget” all sensor pairing (go into Bluetooth
your phone and unpair all sensors). Note the additional information below, and see the Troubleshooting section
for added help.

5 | OAKLEY RADAR PACE USER GUIDE

settings on

IF YOU HAVE ANY ISSUES WHEN ATTEMPTING TO PAIR RADAR PACE WITH EXTERNAL BLUETOOTH SENSORS,
PLEASE NOTE THE FOLLOWING:

•

Pair only via the RADAR PACE app.

•

Ensure the battery of the sensor device has enough charge to broadcast its signal to RADAR PACE.

•

Some sensors require movement to begin broadcasting to the RADAR PACE app.

•

Ensure the sensor device is not paired with another device; if it is currently paired with your phone, go to phone system

settings and unpair to ensure the device is discoverable.

•

Refer to the owners manual that came with your external sensor for more troubleshooting information.

FOR ISSUES RELATED TO PAIRING WITH EXTERNAL ANT+ SENSORS, PLEASE NOTE THE FOLLOWING:

•

Ensure the battery of the sensor device has enough charge to broadcast its signal to RADAR PACE.

•

Some sensors require movement to begin broadcasting to the RADAR PACE app.

•

Refer to the owners manual that came with your external sensor for more troubleshooting information.

FOR ISSUES RELATED TO CONNECTED SENSORS, PLEASE NOTE THE FOLLOWING:

•

Ensure the sensor device is not currently paired with another device.

•

Most connected sensors require movement to begin broadcasting to the RADAR PACE app.

POWER BUTTON

Located on the inner facing of the temple, the power button has multiple functions:

FOR YOUR SESSION

Power on: HOLD FOR MORE THAN 2 SECONDS. (The indicator light on the outer facing of the temple will show the remaining battery power

by glowing red, yellow or green, then will blink light blue.)

Pair with phone: PRESS TWICE QUICKLY. (The indicator light will flash

dark blue. If pairing is successful, it will turn solid light blue. If unsuccessful,

it will turn solid dark blue; see the Troubleshooting section.)

Power off: HOLD FOR MORE THAN 3 SECONDS. (The indicator light will

blink light blue.)

FOR RESETTING RADAR PACE

Factory reset and reboot: HOLD FOR MORE THAN 12 SECONDS.

(The indicator light will blink red.)

Factory reset and power off: HOLD FOR MORE THAN 18 SECONDS. (The

indicator light will blink red.)

6 | OAKLEY RADAR PACE USER GUIDE

TOUCH PAD

The touch pad on the temple lets you control functions with simple taps and swipes. You can adjust the volume,
control music and calls, and more from your paired phone.

CONTROL VOLUME

Increase volume: SWIPE FORWARD

Decrease volume: SWIPE BACKWARD

CONTROL MUSIC

Pause or play song: SINGLE TAP

Jump to next song: DOUBLE TAP

Return to previous song: TRIPLE TAP

Fast forward: DOUBLE TAP and HOLD

Rewind: TRIPLE TAP and HOLD

CONTROL CALLS

Answer call: SINGLE TAP

End call: SINGLE TAP

Decline call: HOLD then RELEASE (Use this function when you are not on a current call, and the phone is ringing.)

End current call and switch to incoming or on-hold call: HOLD then RELEASE

Switch back and forth between incoming call and current call: SINGLE TAP (A single tap puts the current call on hold and answers the

incoming call. Each single tap after that switches between the two calls, placing one on hold.)

CONTROL SIRI® / GOOGLE NOW

Activate Siri® or Google Now™: HOLD then RELEASE

™

CHANGING THE LENS

To remove a lens from RADAR PACE, follow the instructions below. (To install a lens, simply reverse the procedure.)

1. With two fingers, carefully pinch the two nose bridge tabs inward.

2. Push the nose bridge toward the top of the frame until the lens releases from the top.

3. Pull the lens down and out.

7 | OAKLEY RADAR PACE USER GUIDE
