NXP BAT 86 NXP Datasheet

DISCRETE SEMICONDUCTORS
DATA SH EET
halfpage
BAT86
Schottky barrier diode
Product specification Supersedes data of 1996 Mar 20
2000 May 25
Philips Semiconductors Product specification
Schottky barrier diode BAT86
FEATURES
Low forward voltage
Guard ring protected
Hermetically-sealed leaded glass
DESCRIPTION
Planar Schottky barrier diode with an integrated protection ring against static discharges, encapsulated in a hermetically-sealed subminiature SOD68 (DO-34) package. The diodeissuitable for mounting on a 2 E (5.08 mm) pitch.
package.
APPLICATIONS
handbook, halfpage
k
a
Ultra high-speed switching
Voltage clamping
MAM193
Protection circuits
Blocking diodes.
Fig.1 Simplified outline (SOD68; DO-34) and symbol.
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 60134).
SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
V
R
I
F
I
F(AV)
I
FRM
I
FSM
T
stg
T
j
T
amb
continuous reverse voltage 50 V continuous forward current 200 mA average forward current PCBmounting,leadlength = 4 mm;
V
= 25 V; a = 1.57; δ = 0.5;
RWM
T
=50°C; see Fig.2
amb
200 mA
repetitive peak forward current tp≤ 1s;δ≤0.5 500 mA non-repetitive peak forward current tp≤ 10 ms 5A storage temperature 65 +150 °C junction temperature 125 °C operating ambient temperature 65 +125 °C
2000 May 25 2
Philips Semiconductors Product specification
Schottky barrier diode BAT86
ELECTRICAL CHARACTERISTICS
T
=25°C; unless otherwise specified.
amb
SYMBOL PARAMETER CONDITIONS MAX. UNIT
V
F
I
R
t
rr
C
d
Note
1. Pulsed test: t
forward voltage see Fig.3
I
= 0.1 mA 300 mV
F
I
= 1 mA 380 mV
F
= 10 mA 450 mV
I
F
I
= 30 mA 600 mV
F
= 100 mA 900 mV
I
F
reverse current VR= 40V; see Fig.4; note 1 5 µA reverse recovery time when switched from IF= 10 mA to
4ns IR= 10 mA; RL= 100 ; measured at I
= 1 mA; see Fig.6
R
diode capacitance f = 1 MHz; VR= 1 V; see Fig.5 8 pF
= 300 µs; δ = 0.02.
p
THERMAL CHARACTERISTICS
SYMBOL PARAMETER CONDITIONS VALUE UNIT
R
th j-a
thermal resistance from junction to ambient note 1 320 K/W
Note
1. Refer to SOD68 standard mounting conditions.
2000 May 25 3
Philips Semiconductors Product specification
Schottky barrier diode BAT86
GRAPHICAL DATA
250
handbook, halfpage
I
F(AV) (mA)
200
150
100
50
0
0 50 100 150
Fig.2 Derating curve.
MRA540
o
T ( C)
amb
3
10
handbook, halfpage
I
F
(1) (2) (3)
(mA)
2
10
10
(1) (2) (3)
1
1
10
VF (V)
(1) T (2) T (3) T
amb amb amb
= 125 °C. =85°C. =25°C.
Fig.3 Forward current as a function of forward
voltage; typical values.
1.20.80.40
5
10
handbook, halfpage
I
R
(nA)
4
10
3
10
2
10
MGC686
(1)
(2)
10
(3)
1
1
10
(1) T (2) T (3) T
amb amb amb
10 20 30 40
=85°C. =25°C. = 40 °C.
VR (V)
Fig.4 Reverse current as a function of reverse
voltage; typical values.
12
handbook, halfpage
C
d
MGC687
(pF)
8
4
500
0
050
10 20 30 40
VR (V)
f = 1 MHz.
Fig.5 Diode capacitance as a function of reverse
voltage; typical values.
2000 May 25 4
Philips Semiconductors Product specification
Schottky barrier diode BAT86
andbook, halfpage
I
F
dI
F
dt
t
10%
Q
r
90%
I
R
t
f
MRC129 - 1
Fig.6 Reverse recovery definitions.
2000 May 25 5
Philips Semiconductors Product specification
Schottky barrier diode BAT86
PACKAGE OUTLINE
Hermetically sealed glass package; axial leaded; 2 leads
LD L
DIMENSIONS (mm are the original dimensions)
G
UNIT
mm
Note
1. The marking band indicates the cathode.
b
max.
0.55
OUTLINE VERSION
SOD68 DO-34
D
max.
max.
IEC JEDEC EIAJ
L
1
min.
25.43.041.6
REFERENCES
SOD68
(1)
b
G
1
0 2 4 mm
scale
EUROPEAN
PROJECTION
ISSUE DATE
97-06-09
2000 May 25 6
Philips Semiconductors Product specification
Schottky barrier diode BAT86
DATA SHEET STATUS
DATA SHEET STATUS
Objective specification Development This data sheet contains the design target or goal specifications for
Preliminary specification Qualification Thisdata sheet contains preliminary data, and supplementary data will be
Product specification Production This data sheet contains final specifications. Philips Semiconductors
Note
1. Please consult the most recently issued data sheet before initiating or completing a design.
DEFINITIONS Short-form specification The data in a short-form
specification is extracted from a full data sheet with the same type number and title. For detailed information see the relevant data sheet or data handbook.
Limiting values definition  Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 60134). Stress above one or more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation of the device attheseorat any other conditions above those given in the Characteristics sections of the specification is not implied. Exposure to limiting values for extended periods may affect device reliability.
Application information  Applications that are described herein for any of these products are for illustrative purposes only. Philips Semiconductors make norepresentationorwarrantythatsuchapplicationswillbe suitable for the specified use without further testing or modification.
PRODUCT
STATUS
DEFINITIONS
product development. Specification may change in any manner without notice.
published at a later date. Philips Semiconductors reserves the right to make changes at any time without notice in order to improve design and supply the best possible product.
reserves the right to make changes at any time without notice in order to improve design and supply the best possible product.
DISCLAIMERS Life support applications These products are not
designed for use in life support appliances, devices, or systems where malfunction of these products can reasonably be expected to result in personal injury.Philips Semiconductorscustomersusingorsellingtheseproducts for use in such applications do so at their own risk and agree to fully indemnify Philips Semiconductors for any damages resulting from such application.
Right to make changes  Philips Semiconductors reserves the right to make changes, without notice, in the products, including circuits, standard cells, and/or software, described or contained herein in order to improve design and/or performance. Philips Semiconductors assumes no responsibility or liability for theuseofanyoftheseproducts,conveysnolicenceortitle under any patent, copyright, or mask work right to these products,andmakes no representations or warranties that these products are free from patent, copyright, or mask work right infringement, unless otherwise specified.
