Professional Disc Jockey Products
DM905 BLUE DOG
PROFESSIONAL DJ MIXER
USER’S MANUAL
©1999 Industries http://www.numark.com
DM905 Blue Dog
Safety Information
SAFETY INSTRUCTIONS
a) Read Instructions - All the safety and operating
instructions should be read before this product is connected
and used.
b) Retain Instructions - The safety and operating instructions
should be kept for future reference.
c) Heed Warnings - All warnings on this product and in these
operating instructions should be followed.
d) Follow Instructions - All operating and other instructions
should be followed.
e) Water and Moisture - This
product should be kept
away from direct contact
with liquids.
f) Heat - Avoid placing this
product to close to any high heat sources such as radiators.
g) Ventilation - The appliance should be situated so that it’s
location or position does not interfere with it’s proper
ventilation. For example, the appliance should not be
situated on a bed, sofa, rug,
or similar surface that may
block the ventilation
opening; or, placed in a builtinstallation, such as bookcase
or cabinet that may impede
the flow of air through the ventilation openings.
h) Power Sources - This product should be connected to a
power supply only of the type described in these operating
instructions, or as marked on the unit.
i) Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked upon or
pinched by items placed on or against them. When
removing the cord from a power outlet be sure to remove
it by holding the
plug attachment
and not by pulling
on the cord.
j) Object and Liquid Entry - Take care that objects do not fall
into and that liquids are not spilled into the inside of the
mixer.
k) Cleaning – The appliance should be cleaned only as
recommended by the manufacturer.
l)
Non-use Periods – The power cord of the appliance should
be unplugged from the outlet when left unused for long
periods of time.
m) Damage Requiring Service -
Only qualified personnel
should service this product.
If you have any questions
about service please contact
Numark at the number(s)
shown on the back cover of
this manual.
n) Grounding or Polarization - Precautions should be taken
so that the grounding or polarization means built into the
CD player is not defeated.
o) Internal/External Voltage Selectors - Internal or external
voltage selector switches, if any, should only be reset and
re-equipped with a proper plug for alternative voltage by a
qualified service technician. Do not attempt to alter this
yourself.
WARNING: To reduce the risk of fire or electrical shock, do
not expose this appliance to rain or moisture. Electrical
equipment should NEVER be kept or stored in damp
environments.
©1999 Numark Industries - 2 - http://www.numark.com
- The Leader in DJ Technology
DM905 Blue Dog
VERY IMPORTANT
Please read this entire manual before connecting this unit to your system
For optimum performance:
• The crossfader is a user replaceable item and subject to wear. Excessive force can wear out the fader quickly. This is not a
warranted item.
•
Never use spray cleaners on the slide controls . Residues cause excessive dirt build-up and this will void your warranty. In normal
use slide controls can last for many years. If they malfunction (usually because of a dirty or dusty environment) consult a
professional technician.
• Always make sure that AC power is OFF while making any connections.
• Use appropriate cables throughout your system. Do not use excessively long cables (i.e. over 50ft/14m) Be sure plugs and jacks
are tightly mated. Loose connections can cause hum, noise or intermittents that could easily damage your speakers. Make the
input and output connections with readily available low-capacitance stereo cables. Quality cable makes a big difference in audio
fidelity and punch. See your Numark dealer or an electronics or audio specialist store if you are not sure which cables to get.
• Never attempt to make any adjustments or repairs other than those described in this manual. Take the unit to your dealer or to an
authorized Numark Service Center.
• ALWAYS remember: “TURN AMPS ON LAST AND OFF FIRST”. Begin with master faders or volume controls on minimum
and the amplifier gain/input control(s) down. Wait 8 to 10 seconds before turning up the volume. This prevents transients which
may cause severe speaker damage.
• Use restraint when operating controls. Try to move them slowly. Rapid adjustments could damage speakers due to amplifier
clipping.
• Avoid amplifier “clipping” at all costs: this occurs when the red LEDs (usually on the front panel of most professional power
amplifiers) start flashing. “Clipping” is when the power amplifier is distorting and working beyond it’s limits. Amplifier
distortion is THE major cause of speaker failure.
• To prevent fire or shock hazard, do not expose the unit to rain or moisture. Never place cans of beer, soda, glasses of water or
anything wet on top of the unit!
Please record the serial number of your unit as shown on the back of the chassis as well as the name of the
dealer from whom you purchased the unit. Retain this information and your original purchase receipt for your
records. Please return the enclosed warranty card to register your unit with us.
MODEL: __________________________ PURCHASED FROM:_________________________
SERIAL NUMBER:__________________ DATE OF PURCHASE:________________________
©1999 Numark Industries - 3 - http://www.numark.com
Product Registration
- The Leader in DJ Technology
DM905 Blue Dog
DM905
“BLUE DOG”
PROFESSIONAL DJ MIXER
CONGRATULATIONS!
You have purchased the DM905 “Blue Dog” Stereo Mixer by Numark. This equipment features all new
circuitry and the latest in manufacturing and design technology to give you greater quality and better reliability than
ever before. The DM905 brings to you the finest quality of DJ equipment available today.
Thank you for buying Numark DJ products!
FEATURES...
• Compact design
• User replaceable ALPs™ crossfader
• 2 phono inputs
• 2 line inputs
• 1 microphone input
• Tape Out for direct recording
• Powerful stereo headphone output
• Selectable slider cueing
• High-end performance audio signal
©1999 Numark Industries - 4 - http://www.numark.com
- The Leader in DJ Technology
TABLE OF CONTENTS
Safety Measures 2
Important Information 3
Registration 3
Introduction 4
DM905 Blue Dog
Description of the Features 6
Specifications and Setup Diagram 7
Warranty 8
©1999 Numark Industries - 5 - http://www.numark.com
- The Leader in DJ Technology
DM905 Blue Dog
45678109
MIXER FEATURES
3
2
1
13
8. Channel Cue Slider - Used to route channel audio to
your headphones.
9. Headphone Level – Adjusts cue volume.
10. Master Fader - Controls the overall output level.
11. Mic Input – Plug your 1/4” Microphone plug in here.
12. Headphone Input – Plug in the 1/4” plug for your
headphones here.
13. Power Button – turns unit of and on.
REAR PANEL FEATURES
11 12
1. Input fader - Controls individual source levels in the
mix.
2. Input toggle switch - Selects which source will be
live to that channel based on what you have connected to
the rear panel input section.
3. Channel Gain Control – Adjusts the pre-fader
volume for cleaner sound.
4. Replaceable Crossfader - Achieves clean segues
between the two input channels. "Hard left" selects
Channel 1. "Hard right" selects Channel 2. With the
crossfader centered, both assigned channels are live. Use
the crossfader for fast and seamless segues from one
selected channel to the other.
Note: The crossfader is user replaceable in case of failure.
Simply unscrew the two large screws which hold it in
place, lift it out and disconnect it’s cable. Re-attach the
new crossfader and screw the mounting plate back onto the
unit - you’re back in business!
5. Mic Input Gain – Adjusts microphone level.
6. Mic Off/On/Talk Over Toggle – Activates
microphone and talk over mode. Talk over lowers channel
volume so the microphone can be clearly heard.
7. LED Meter - Indicates the Master output level.
14. Phono Inputs – Plug your turntables in here. When
these connectors are used, your signal is fed directly to the
high-quality RIAA phono pre-amplifiers. Use this
position only for turntables . Line level sources will
overload the sensitive phono pre-amps and will cause
distortion.
15. GND - Grounding lug for turntable connection. Always
use this connection when using turntables. (your turntable
cable should have a grounding wire)
16. Line Inputs - Unbalanced RCA jacks for connecting
stereo audio from line level sources such as CD players,
HiFi VCRs, cassette and reel-to-reel tape decks, DAT
machines, laser discs, tuners, even synthesizers or other
mixing consoles.
NOTE: Plug mono audio sources into both Left and
Right inputs using a "Y" cable connector.
17. Record Outputs - Unbalanced RCA jacks used to send
the output of the program to any connected recording
device.
18. Stereo Main Outputs - Unbalanced RCA connectors
controlled by the Master fader.
19. Power Connector - Plug in power adapter here and
check the voltage level to match your country’s standard.
©1999 Numark Industries - 6 - http://www.numark.com
- The Leader in DJ Technology
SPECIFICATIONS
INPUTS:
Line: 10kΩ input impedance
74mV rms sensitivity (for 1.22V output)
Mic: 10kΩ input impedance unbalanced
2.2mV rms sensitivity (for 1.22V output)
80mV rms max input
Phono: 47kΩ input impedance
2.4mV rms sensitivity @ 1 KHz
(for 1.22V output)
OUTPUTS:
Line: 7.2V rms max
Headphone Amp: 0.5 watt into 47Ω
Distortion less than .01%
SIGNAL TO NOISE RATIOS (vs. maximum output):
Line: Better than 100 dB
Mic: Better than 81 dB
Phono: Better than 80 dB
DM905 Blue Dog
FREQUENCY RESPONSE:
Line: 20 Hz- 22k Hz ±0.5 dB
Line: 20 Hz- 20k Hz ±0.5 dB
Phono: ±1 dB except for controlled attenuation of -3 dB
@ 20 Hz to reduce rumble and feedback
POWER CONSUMPTION:
5.5 Watt typical
10 watt with full headphone output
DIMENSIONS:
165mm(W) x 235mm(H) x 110mm(D)
6 1/2” (W) x 9 1/2” (H) x 4 1/2” (D)
WEIGHT:
1.5 kgs
3.4lbs
SETUP DIAGRAM
©1999 Numark Industries - 7 - http://www.numark.com
- The Leader in DJ Technology
Professional Disc Jockey Products
LIMITED PRODUCT WARRANTY
What is covered and for how long?
1. NUMARK INDUSTRIES LCC ("NUMARK") warrants to the original purchaser that NUMARK'S DJ mixers and amplifiers are free from defects in material and workmanship under
normal use and service for the period commencing upon the date of purchase from an authorized NUMARK dealer and continuing for the following period of time after that
date for (2) Years. The warranty is extended to (3) Years with the completion of the warranty card provided that the warranty card is completed and returned within (30)
days from the date of purchase. All other NUMARK products are warranted for (1) Year including but not limited to CD players, CD Mix Stations, turntables, preamplifiers,
beatkeepers, equalizers, microphones, headphones, and all other accessories.
What is not covered? This Limited Warranty is conditioned upon proper use of the product by the purchaser.
2. This Limited Warranty does not cover: (a) defects or damage resulting from accident, misuse, abuse, neglect, unusual physical or electrical stress, modification of any part of
the product, or cosmetic damage; (b) equipment that has the serial number removed or made illegible; (c) all plastic surfaces and other externally exposed parts that are
scratched or damaged due to normal use; (d) defects or damage from improper testing, operation, maintenance, installation, adjustment, or service of the mixers; (e)
crossfaders.
3. What are NUMARK'S obligations? During the applicable warranty period, NUMARK will repair or replace, at NUMARK'S sole discretion, without charge to the purchaser, any
defective component part of the mixer. To obtain service under this Limited Warranty, purchaser must first contact NUMARK and obtain a return authorization number
("RA#"). Purchaser must then return the mixer to NUMARK in an adequate container for shipping, accompanied by purchaser's sales receipt or comparable proof of sale
showing the date of purchase, the serial number of the product, and the seller's name and address. To obtain an RA# and assistance on where to return the mixer, contact
NUMARK customer service at 401-295 9000. Upon receipt, NUMARK will repair or replace the defective products. NUMARK may, at NUMARK'S sole discretion, use rebuilt,
reconditioned, or new parts or components when repairing any product or replace a product with a rebuilt, reconditioned or new product. Repaired mixers will be warranted
for a period equal to the remainder of the original Limited Warranty on the original mixer or for (90) days, whichever is longer. All replaced parts, components, boards and
equipment become the property of NUMARK. If NUMARK determines that any mixer is not covered by this Limited Warranty, purchaser must pay all parts, shipping, and labor
charges for the repair or return of such mixer.
4. What are the limits on NUMARK'S liabilities? THE WARRANTIES GIVEN IN THIS LIMITED WARRANTY, TOGETHER WITH ANY IMPLIED WARRANTIES COVERING NUMARK
MIXERS, INCLUDING WITHOUT LIMITATION ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION
OF THIS LIMITED WARRANTY. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, NUMARK SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL,
CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES, LOSS OF PROFITS, DAMAGES TO PURCHASER'S PROPERTY, OR INJURY TO PURCHASER OR OTHERS ARISING
OUT OF THE USE, MISUSE OR INABILITY TO USE ANY NUMARK MIXER, BREACH OF WARRANTY, OR NEGLIGENCE, INCLUDING BUT NOT LIMITED TO NUMARK'S
OWN NEGLIGENCE, EVEN IF NUMARK OR ITS AGENT HAS BEEN ADVISED OF SUCH DAMAGES, OR FOR ANY CLAIM BROUGHT AGAINST PURCHASER BY ANY OTHER
PARTY. THIS LIMITED WARRANTY IS THE COMPLETE WARRANTY FOR NUMARK'S MIXERS, AND IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES. THIS
LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT AND STATES PURCHASER'S EXCLUSIVE
REMEDY. IF ANY PORTION OF THIS LIMITED WARRANTY IS ILLEGAL OR UNENFORCEABLE BY REASON OF ANY LAW, SUCH PARTIAL ILLEGALITY OR
UNENFORCEABILTY SHALL NOT AFFECT THE ENFORCEABILITY OF THE REMAINDER OF THIS LIMITED WARRANTY WHICH PURCHASER ACKNOWLEDGES IS AND
WILL ALWAYS BE CONSTRUED TO BE LIMITED BY ITS TERMS OR AS LIMITED AS THE LAW PERMITS.
5. This Limited Warranty allocates risk of product failure between purchaser and NUMARK, and NUMARK'S product pricing reflects this allocation of risk and the limitations of
liability contained in this Limited Warranty. The agents, employees, distributors, and dealers of NUMARK are not authorized to make modifications to this Limited Warranty, or
make additional warranties binding on NUMARK. Accordingly, additional statements such as dealer advertising or presentation, whether oral or written, do not constitute
warranties by NUMARK and should not be relied upon.
6. How does state law apply to this warranty? SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR
HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO PURCHASER.
7. This Limited Warranty gives you specific legal rights. You may also have other rights, which vary from one jurisdiction to another.
RETURN INFORMATION
a) A Return Authorization number must be obtained from Numark through the address or phone numbers below.
b) A copy of the original sales receipt must also be included for the equipment to be repaired under warranty.
c) The faulty equipment must be packed in its original packaging.
d) One additional outer layer of packaging must be included to ensure product safety. Failure to do so may inadequately protect the equipment in transit and,
therefore, jeopardize the customer’s warranty.
e) Numark will not accept COD shipments and no call tags will be issued for merchandise return.
f) Numark will not return repaired merchandise to customers by priority service, unless by written request at the customer’s cost. Requests must be submitted in
writing with merchandise returned.
g) The defective Numark equipment should be sent, FREIGHT PREPAID with Return Authorization number clearly printed on the outer packaging and original sales
receipt enclosed to:
INDUSTRIES
Attention: Service Department
11 Helmsman Avenue
North Kingstown, RI 02852 USA
Phone: +1 (401) 295-9000
Fax:: +1 (401) 295-5200
Web: www.numark.com
Loading...
