nordictrack.com
Model No. 24890.0
Serial No.
Write the serial number in the space above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and activate your warranty today, go to my.nordictrack.com.
CUSTOMER CARE
For service at any time, go to nordictrackservice.com.
Or call 1-800-TO-BE-FIT (1-800-862-3348) Mon.–Fri. 6 a.m.–6 p.m. MT Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference.
USER’S MANUAL
TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 IMPORTANT PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 THE CHEST HEART RATE MONITOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 HOW TO USE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 FCC INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 MAINTENANCE AND TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
WARNING DECAL PLACEMENT
This drawing shows the locations of the warning decals. If a decal is missing or illegible, call the telephone number on the front cover of this manual and request a free replacement decal. Apply the decal in the location shown.
Note: The decals may not be shown at actual size.
NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. App store is a trademark of Apple Inc., registered in the U.S. and other countries. IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license. Wi-Fi is a registered trademark of Wi-Fi Alliance. WPA
and WPA2 are trademarks of Wi-Fi Alliance. The BLUETOOTH® word mark and logos are registered trademarks of Bluetooth SIG, Inc. and are used under license. Android, Google Play, and Google Maps are trademarks of Google Inc.
2
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
1.It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions.
2.Before beginning any exercise program, consult your physician. This is especially important for persons over age 35 or persons with pre-existing health problems.
3.The treadmill is not intended for use by persons with reduced physical, sensory, or mental capabilities or lack of experience
and knowledge unless they have been given supervision or instruction concerning use of the treadmill by someone responsible for their safety.
4.Use the treadmill only as described in this manual.
5.The treadmill is intended for home use only. Do not use the treadmill in any commercial, rental, or institutional setting.
6.Keep the treadmill indoors, away from moisture and dust. Do not put the treadmill in a garage or covered patio, or near water.
7.Place the treadmill on a level surface, with at least 8 ft. (2.4 m) of clearance behind it and 2 ft. (0.6 m) on each side. Do not place the treadmill on any surface that blocks air openings. To protect the floor or carpet from damage, place a mat under the treadmill.
8.Do not operate the treadmill where aerosol products are used or where oxygen is being administered.
9.Keep children under age 13 and pets away from the treadmill at all times.
10.The treadmill should be used only by persons weighing 300 lbs. (136 kg) or less.
11.Never allow more than one person on the treadmill at a time.
12.Wear appropriate exercise clothes while using the treadmill. Do not wear loose clothes that could become caught in the treadmill. Athletic support clothes are recommended for both men and women. Always wear athletic shoes. Never use the treadmill with bare feet, wearing only stockings, or in sandals.
13.Plug the power cord into a surge suppressor (not included), and plug the surge suppressor into an appropriate outlet (see page 20). To avoid overloading the circuit, do not plug other electrical devices, except for low-power devices such as cell phone chargers, into the surge suppressor or into an outlet on the same circuit.
14.Use only a surge suppressor that meets all of the specifications described on page 20. To purchase a surge suppressor, see your local NORDICTRACK dealer, call the telephone number on the front cover of this manual, or see your local electronics store.
15.Failure to use a properly functioning surge suppressor could result in damage to the control system of the treadmill. If the control system is damaged, the walking belt may slow, accelerate, or stop unexpectedly, which may result in a fall and serious injury.
16.Keep the power cord and the surge suppressor away from heated surfaces.
17.Never move the walking belt while the power is turned off. Do not operate the treadmill
if the power cord or plug is damaged, or if the treadmill is not working properly. (See MAINTENANCE AND TROUBLESHOOTING on page 37 if the treadmill is not working properly.)
18.Read, understand, and test the emergency stop procedure before using the treadmill (see HOW TO TURN ON THE POWER on page 22). Always wear the clip while using the treadmill.
3
19.Always stand on the foot rails when starting or stopping the walking belt. Always hold the handrails while using the treadmill.
20.When a person is walking on the treadmill, the noise level of the treadmill will increase.
21.Keep fingers, hair, and clothing away from the moving walking belt.
22.The treadmill is capable of high speeds. Adjust the speed in small increments to avoid sudden jumps in speed.
23.The heart rate monitor is not a medical device. Various factors, including the user’s movement, may affect the accuracy of heart rate readings. The heart rate monitor is intended only as an exercise aid in determining heart rate trends in general.
24.Never leave the treadmill unattended while it is running. Always remove the key, press the power switch into the off position (see the drawing on page 7 for the location of the power switch), and unplug the power cord when the treadmill is not in use.
25.Do not attempt to move the treadmill until it is properly assembled. (See ASSEMBLY on page 9 and HOW TO FOLD AND MOVE THE TREADMILL on page 36.) You must be
able to safely lift 45 lbs. (20 kg) to move the treadmill.
26.When folding or moving the treadmill, make sure that the storage latch is holding the frame securely in the storage position. Do not operate the treadmill while it is folded.
27.Do not change the incline of the treadmill by placing objects under the treadmill.
28.Never insert any object into any opening on the treadmill.
29.Inspect and properly tighten all parts each time the treadmill is used.
30.DANGER: Always unplug the power cord immediately after use, before cleaning the treadmill, and before performing the maintenance and adjustment procedures described in this manual. Never remove the motor hood unless instructed to do so by an authorized service representative. Servicing other than the procedures in this manual should be performed by an authorized service representative only.
31.Over exercising may result in serious injury or death. If you feel faint, if you become short of breath, or if you experience pain while exercising, stop immediately and cool down.
SAVE THESE INSTRUCTIONS
4
5
STANDARD SERVICE PLANS
all
6
BEFORE YOU BEGIN
Thank you for selecting the revolutionary NORDICTRACK® ELITE 5800 treadmill. The ELITE 5800 treadmill offers an impressive selection of features designed to make your workouts at home more effective and enjoyable. And when you’re not exercising, the unique treadmill can be folded up, requiring less than half the floor space of other treadmills.
For your benefit, read this manual carefully before using the treadmill. If you have questions after
reading this manual, please see the front cover of this manual. To help us assist you, please note the product model number and serial number before contacting us. The model number and the location of the serial number decal are shown on the front cover of this manual.
Before reading further, please review the drawing below and familiarize yourself with the labeled parts.
Length: 6 ft. (183 cm) |
Tablet Holder |
|
|
Width: 2 ft. 10 in. (86 cm) |
Console |
|
|
|
Tray |
Heart Rate Monitor |
|
Handrail |
Key/Clip |
|
|
Upright |
|
Walking Belt |
Power Switch |
Foot Rail |
|
|
Power Cord |
|
Platform Cushion |
Idler Roller |
|
Adjustment Screws |
|
|
7 |
PART IDENTIFICATION CHART
Use the drawings below to identify small parts used for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see whether it is preattached. Extra parts may be included.
|
5/16" Star |
3/8" Star |
|
Washer (8)–10 |
Washer (25)–8 |
||
|
|
|
|
|
|
|
|
M4 x 16mm |
#8 x 1/2" Ground |
|
#8 x 3/4" |
#10 x 3/4" |
||
Screw (108)–4 |
Screw (7)–1 |
|
Truss Head |
Screw (6)–2 |
||
|
|
|
Screw (24)–20 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5/16" x 3/4" |
3/8" x 1 1/4" |
5/16" x 2" |
||
Screw (1)–4 |
Screw (20)–4 |
Screw (2)–4 |
||
|
|
|
|
|
|
|
|
|
|
3/8" x 2 3/4" Screw (23)–4
8
ASSEMBLY
•Assembly requires two persons.
•Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing materials until you finish all assembly steps.
•After shipping, there may be an oily substance on the exterior of the treadmill. This is normal. If there is an oily substance on the treadmill, wipe it off with a soft cloth and a mild, non-abrasive cleaner.
•To identify small parts, see page 8.
•Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.”
•Assembly requires the following tools:
the included hex key
one adjustable wrench
one Phillips screwdriver
To avoid damaging parts, do not use power tools.
1. Go to my.nordictrack.com on your computer |
|
|
|
|
1 |
|
|
and register your product. |
|
|
|
|
|
|
•documents your ownership
•activates your warranty
•ensures priority customer support if assistance is ever needed
Note: If you do not have internet access, call Customer Care (see the front cover of this manual) and register your product.
9
2. Make sure that the power cord is unplugged. |
2 |
|
|
|
|
Remove the tie securing the Upright Wire (83) to |
A |
83 |
|
|
|
the front of the Base (93). |
|
|
Next, identify the Right Upright (84). Have a sec- |
|
83 |
ond person hold the Right Upright near the Base |
|
|
(93). |
|
|
See the inset drawing. Tie the wire tie (A) in |
|
84 |
|
|
|
the Right Upright (84) securely around the end |
|
|
of the Upright Wire (83). Then, insert the Upright |
|
|
Wire into the lower end of the Right Upright as |
|
|
you pull the other end of the wire tie through the |
|
|
Right Upright. |
|
A |
|
|
|
|
|
84 |
|
|
93 |
3. Lay the Right Upright (84) near the Base (93). |
3 |
|
Press the Upright Grommet (86) into the square |
|
|
|
|
|
hole (B) in the Right Upright. Make sure not to |
|
|
pinch the ground wire (C). |
|
|
If there is a screw (D) preattached to the Right |
|
|
Upright (84), remove and discard it. |
|
|
Then, attach the ground wire (C) to the Right |
|
93 |
Upright (84) with a #8 x 1/2" Ground Screw (7). |
|
|
|
|
|
|
|
7 |
|
|
86 |
|
|
C |
|
|
D |
|
|
B |
|
|
84 |
|
10 |
|
4.Hold the Right Upright (84) against the Base (93). Make sure not to pinch the Upright Wire
(83).
Attach the Right Upright (84) with two 3/8" x 2 3/4" Screws (23), two 3/8" x 1 1/4" Screws
(20), and four 3/8" Star Washers (25) as shown; do not fully tighten the Screws yet.
Attach the Left Upright (not shown) in the same way. Note: There are no wires on the left side.
5. Identify the Left and Right Base Covers (89, 90).
Slide the Left Base Cover (89) onto the Left Upright (91), and slide the Right Base Cover (90) onto the Right Upright (84). Press the Base Covers downward, but do not snap the Base
Covers into place yet.
Then, remove and save the four indicated 5/16" x 2" Screws (2).
If there is a film (E) covering the decal on each Upright (84, 91), carefully remove the film.
4 |
|
|
23 |
|
25 |
23 |
|
25 |
83 |
|
|
|
93 |
|
25 |
20 |
84 |
|
25 |
|
20 |
5 |
E |
|
|
2 |
|
|
91 |
|
2 |
|
84 |
|
89 |
|
E |
|
90 |
11
6.Carefully slide the Upright Crossbar (76) between the Right and Left Uprights (84, 91). Attach the Upright Crossbar with four 5/16" x 3/4" Screws (1); start all four Screws, and then tighten them.
7.Hold the Tray (79) near the Right Upright (84). Wrap the tie (F) in the indicated hole (G) in the right Upright around the end of the fan wire (H). Next, pull the fan wire into the hole and out of the top of the right Upright. Then, remove the tie.
Attach the Tray (79) to the Upright Crossbar (76) with four #8 x 3/4" Truss Head Screws (24); start all four Truss Head Screws, and then tighten them.
6 |
|
|
|
|
|
76 |
|
|
1 |
|
1 |
|
|
|
|
|
84 |
|
91 |
7 |
H |
|
|
|
79 |
|
|
|
|
|
|
|
G |
|
|
F |
24 |
76 |
24 |
|
|||
|
84 |
|
|
12
8. Attach the two Handrails (74) to the Right |
8 |
|
|
and Left Uprights (84, 91) with two 5/16" x 2" |
|
|
|
|
|
|
|
Screws (2) that you removed in step 5 and two |
2 |
|
|
5/16" Star Washers (8); do not fully tighten |
8 |
|
|
the Screws yet. Be careful not to pinch the |
74 |
|
|
J |
|
||
Upright Wire (83) or the fan wire (H) on the |
|
||
|
|
||
|
|
|
|
right side. Position the wires in the notch (I) |
|
|
|
as shown. |
|
|
74 |
|
|
|
2 |
Then, remove and discard the two indicated |
|
H |
83 |
screws (J). |
|
||
|
|
8 |
|
|
|
|
|
|
|
|
J |
|
|
91 |
I |
|
|
|
|
|
|
|
84 |
9. Set the console assembly (K) face down on |
9 |
|
|
a soft surface to avoid scratching the console |
|
|
|
|
|
|
|
assembly. |
L |
|
K |
|
|
||
Remove and discard the four indicated screws |
|
|
|
(L). Then, remove the Pulse Crossbar (80). |
|
|
|
|
|
80 |
|
|
|
L |
|
|
|
L |
|
13
10. |
IMPORTANT: To avoid damaging the Pulse |
10 |
|
|
Crossbar (80), do not use power tools, and do |
|
|
|
2 |
6 |
|
|
not overtighten the #10 x 3/4" Screws (6) or |
||
|
|
|
|
|
the 5/16" x 2" Screws (2). |
8 |
80 |
|
Orient the Pulse Crossbar (80) as shown. Attach |
|
2 |
|
the Pulse Crossbar with two of the 5/16" x 2" |
|
|
|
|
2 |
|
|
Screws (2) that you removed in step 5, two 5/16" |
|
|
|
Star Washers (8), and two #10 x 3/4" Screws (6); |
|
6 |
|
|
8 |
|
|
start all four Screws, and then tighten them. |
|
|
|
Then, tighten the other two 5/16" x 2" |
|
|
|
Screws (2). |
|
|
|
|
|
2 |
11. |
With the help of a second person, hold the con- |
11 |
|
|
sole assembly (K) near the Handrails (74). |
|
|
|
|
|
See the inset drawing. Connect the Upright |
|
|
|
Wire (83) to the console wire (M). The connec- |
|
|
|
tors should slide together easily and snap |
|
|
|
into place. If they do not, turn one connector |
|
|
|
and try again. IF YOU DO NOT CONNECT THE |
|
|
|
CONNECTORS PROPERLY, THE CONSOLE |
|
|
|
MAY BECOME DAMAGED WHEN YOU TURN |
|
|
|
ON THE POWER. |
|
|
|
Next, connect the two fan wires (H, N). Then, |
K |
|
|
|
|
|
|
remove any wire ties from the Upright Wire (83) |
|
M |
|
and the fan wires, and insert the excess fan wire |
|
|
|
|
|
|
|
into the Right Upright (84). |
|
|
N |
|
83 |
H |
|
|
|
|
|
|
74 |
|
|
|
|
84 |
M |
|
|
|
83
14
12. Attach the console assembly (K) to the Handrails |
12 |
|
(74) with four 5/16" x 2" Screws (2) and four |
|
|
|
|
|
5/16" Star Washers (8); start all four Screws, |
|
K |
and then tighten them. Be careful not to |
|
|
|
|
|
pinch the wires (M). |
|
|
|
|
74 |
|
74 |
|
|
M |
8 |
|
8 |
2 |
|
2 |
|
|
|
|
13. Insert the wires (M) into the top of the Right |
13 |
|
Upright (84). |
|
|
|
|
|
Locate the Wire Tie (27) included with the hard- |
|
|
ware. Insert the Wire Tie through the small hole |
|
|
in the side of the Right Upright (84). Tighten the |
|
|
Wire Tie around the wires (M) and cut off the end |
|
|
of the Wire Tie. |
|
|
|
|
M |
|
84 |
27 |
14. Start eight #8 x 3/4" Truss Head Screws (24) into |
14 |
|
the Pulse Crossbar (80), and then tighten them; |
|
|
|
|
|
do not overtighten the Truss Head Screws. |
|
|
|
|
80 |
|
24 |
24 |
|
24 |
24 |
|
|
|
|
15 |
|
