Nokia X6-00 User guide

Issue 1

Page 2

2Contents

Safety 5

About your device 6 Network services 7

Get started 8

Keys and parts 8 Insert the SIM card and battery 9 Charge the battery 11 Switch the device on 12 Lock the keys and touch screen 12 Home screen 13 Media key 14 Access the menu 14 Touch screen actions 14 Change the ringing tone 16 Support 16 Open Ovi with your device 16

Find help 17

In-device help 17 Accessibility solutions 17 Update software using your PC 17 Settings 18 Access codes 18 Prolong battery life 18 Increase available memory 19

Your device 21

Phone setup 21 Transfer content for the first time 21 Display indicators 21 Volume and loudspeaker control 22 Shortcuts 23 Antenna locations 23 Contacts bar 24 Offline profile 24 Sensor settings and display rotation 25 Headset 25 Remove the SIM card 26

Attach a wrist strap 27 Remote lock 27

Make calls 28

Touch screen during calls 28 Voice calls 28 During a call 28 Voice mailbox 29 Answer or reject a call 30 Make a conference call 30 Speed dial a phone number 31 Call waiting 31 Voice dialing 32 Make a video call 32 During a video call 33 Answer or reject a video call 34 Video sharing 34 Log 37

Write text 39

Automatic input modes 39 Virtual keyboard 39 Alphanumeric keypad 40 Touch input settings 42

Contacts 43

Save and edit names and numbers 43 Contacts toolbar 43 Manage names and numbers 43 Assign default numbers and addresses 44 Ringing tones, images, and call text for contacts 44 Copy contacts 45 SIM services 45

Messaging 47

Messaging main view 47 Write and send messages 47 Messaging inbox 48 Set up your e-mail 50 Nokia Messaging 50

Page 3

Contents 3

Mailbox 51 Mail for Exchange 53 View messages on a SIM card 54 Cell broadcast messages 54 Service commands 54 Messaging settings 54 Instant messaging 56

Personalize your device 57

Change the look of your device 57 Profiles 57

Music folder 58

Music player 58 Nokia Music Store 61 Nokia Podcasting 61 Radio 63

Gallery 65

View and organize files 65 View images and videos 65 Organize images and videos 66 TV-out mode 66

Camera 68

Activate the camera 68 Image capture 68 Video recording 73

Positioning (GPS) 75

About GPS 75 Assisted GPS (A-GPS) 75 Hold your device correctly 76 Tips on creating a GPS connection 76 Position requests 77 Landmarks 77 GPS data 78 Positioning settings 78

Maps 80

About Maps 80 Network positioning 80

Move on a map 80 Display indicators 81 Find locations 81 Plan routes 82 Save and send locations 82 View your saved items 83 Synchronize your favourite locations with Ovi Maps 83 Your search history 84 Walk to your destination 84 Drive to your destination 85 Traffic and safety 86 Maps settings 87 Internet settings 87 Navigation settings 87 Route settings 88 Map settings 89 Synchronization settings 89 Update maps 89

Connectivity 91

Data connections and access points 91 Network settings 91 Wi-Fi/WLAN connection 92 Access points 94 View your active data connections 98 Synchronization 99 Bluetooth connectivity 99 Transfer data using a USB cable 103 PC connections 104 Administrative settings 104

Share online 106

About Share online 106 Subscribe to services 106 Manage your accounts 106 Create a post 107 Post files from Gallery 107

Nokia Video Center 108

View and download video clips 108 Video feeds 109

Page 4

4Contents

My videos 109 Transfer videos from your PC 110 Video center settings 110

Web browser 112

Browse the web 112 Browser toolbar 113 Navigate pages 113 Web feeds and blogs 114 Widgets 114 Content search 114 Download and purchase items 114 Bookmarks 115 Empty the cache 116 Connection security 116

Search 117

About Search 117 Start a search 117

About Ovi Store 118

Other applications 119

Clock 119 Calendar 120 File manager 121 Application manager 121 Software updates over the air 124 RealPlayer 125 Recorder 126 Write a note 127 Make a calculation 127 Converter 127 Dictionary 127

Battery 141

Battery and charger information 141 Nokia battery authentication guidelines 141

Taking care of your device 142

Recycle 142

Additional safety information 142

Small children 142 Operating environment 142 Medical devices 143 Vehicles 143 Potentially explosive environments 143 Emergency calls 143 Certification information (SAR) 144

Index 145

Settings 129

Phone settings 129 Call settings 135

Troubleshooting 138

Accessories 141

Page 5

Safety 5

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

Page 6

6Safety

GLASS PARTS

The front cover of the device is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel.

About your device

The wireless device described in this guide is approved for use on the UMTS 850, 1900, 2100 networks and GSM 850, 900, 1800, 1900 networks. Contact your service provider for more information about networks.

Your device supports several connectivity methods and like computers may be exposed to viruses and other harmful content. Exercise caution with messages, connectivity requests, browsing, and downloads. Only install and use services and software from trustworthy sources that offer adequate security and protection, such as applications that are Symbian Signed or have passed the Java Verified™ testing. Consider installing antivirus and other security software on your device and any connected computer.

Your device may have preinstalled bookmarks and links for third-party internet sites and may allow you to access third-party sites. These are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you access such sites, take precautions for security or content.

Warning:

To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

When using this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights. Copyright protection may prevent some images, music, and other content from being copied, modified, or transferred.

Make back-up copies or keep a written record of all important information stored in your device.

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

The images in this guide may differ from your device display.

Refer to the user guide for other important information about your device.

Page 7

Safety 7

Network services

To use the device you must have service from a wireless service provider. Some features are not available on all networks; other features may require that you make specific arrangements with your service provider to use them. Network services involve transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can explain what charges will apply. Some networks may have limitations that affect how you can use some features of this device requiring network support such as support for specific technologies like WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols and language-dependent characters.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have customized items such as menu names, menu order, and icons.

Page 8

8Get started

Get started

Keys and parts

1 – Earpiece 2 – Touch screen 3 – Menu key 4 – Call key 5 – Light sensor 6 – Secondary camera 7 – Media key 8 – Proximity sensor 9 – End key

10 – Power key 11 – Charger connector 12 – Nokia AV Connector (3.5 mm) 13 – Micro USB connector 14 – Volume/Zoom key 15 – Camera lens 16 – Lock switch 17 – Capture key 18 – Microphone 19 – Camera flash 20 – Loudspeakers 21 – SIM card slot cover

During extended operation such as an active video call and high speed data connection, the device may feel warm. In most cases, this condition is normal. If you

Page 9

Get started 9

suspect the device is not working properly, take it to the nearest authorized service facility.

Do not cover the area above the touch screen with, for example, protective film or tape.

Insert the SIM card and battery Insert the SIM card. Important: To prevent damage to the SIM card, always remove the battery before you

insert or remove the card.

1 Remove the back cover. 2 If the battery is inserted, remove the battery.

Always switch the device off and disconnect the charger before removing the battery.

3 Open the cover of the SIM card slot.

Page 10

10 Get started

4 Insert a SIM card in the slot. Ensure that the contact area on the card is facing up

and the bevelled corner is facing toward the device. Push the card in.

5 Close the cover of the SIM card slot. Ensure that the cover is properly closed.

If the SIM card is not properly in place, the device can only be used in the Offline profile.

Insert the battery

1 Insert the battery.

Page 11

Get started 11

2 To replace the cover, direct the top locking catches toward their slots, and press

down until the cover locks into place.

See "Remove the SIM card," p. 26.

Charge the battery

Your battery has been partially charged at the factory. If the device indicates a low charge, do the following:

1 Connect the charger to a wall outlet. 2 Connect the charger to the device.

3 When the device indicates a full charge, disconnect the charger from the device,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely without charge, it may take

Page 12

12 Get started

several minutes before the charging indicator appears on the display or before any calls can be made.

Tip: Disconnect the charger from the wall outlet when the charger is not in use. A charger that is connected to the outlet consumes power even when it is not connected to the device.

Switch the device on

1 Press and hold the power key. 2 If the device asks for a PIN code or lock code, enter it, and select OK. To delete a

number, select

. The factory setting for the lock code is 12345. 3 Select your location. If you accidentally select the wrong location, select Back. 4 Enter the date and time. When using the 12-hour time format, to switch between

a.m. and p.m., select any number.

Lock the keys and touch screen

To lock or unlock the touch screen and the keys, slide the lock switch on the side of the device.

When the touch screen and keys are locked, the touch screen is switched off and the keys are inactive.

To change settings for automatic screen and key locking, select Menu > Settings and

Phone > Phone mgmt. > Auto. keyguard > Keypad autolock period.

Page 13

Get started 13

Home screen

The home screen is your starting point where you can collect all your important contacts or application shortcuts.

Interactive display elements

To open the clock application, select the clock (1).

To open the calendar, or to change the profile, select the date or the profile name (2).

To view or modify connectivity settings (

), to view the available wireless LANs ( WL AN ) i f WL AN sc a nn in g i s e n ab le d, o r t o view missed events, select th e top right corner (3).

To make a phone call, select Telephone or

To open the contacts list, select Contacts or

(4).

(5).

To open the main menu, press the menu key (6).

Start using the contacts bar

To start using the contacts bar, and to add your contacts to the home screen, select

> Options > New contact, and follow the instructions.

Page 14

14 Get started

Change the home screen theme

To change the home screen theme or the shortcuts, select Menu > Settings and

Personal > Home screen.

Music keys

When music or the radio is playing in the background, music keys (play/pause, skip backward, and skip forward) are displayed in the home screen.

Media key

To access applications such as the music player or browser, select the media key ( ) to open the media bar, and select the application.

Access the menu

To access the menu, press the menu key.

To open an application or folder in the menu, tap it.

Touch screen actions Tap and double-tap

To open an application or other element on the touch screen, you normally tap it with your finger. However, to open the following items, you must tap them twice.

• List items in an application, such as the Drafts folder in the folder list in Messaging

Page 15

Get started 15

Tip: When you open a list view, the first item is already highlighted. To open the

highlighted item, tap it once.

• Applications and folders in the menu when using the list view type

• Files in a file list, for example, an image in the images and videos view in Gallery.

If you tap a file or similar item once, it is not opened, but becomes highlighted. To view the options available for the item, select Options or, if available, select an icon from a toolbar.

Select .

In this user documentation, opening applications or items by tapping them once or twice is called "selecting". If you need to select several items in a sequence, the display texts to select are separated by arrows.

Example: To select Options > Help, tap Options, and then tap Help.

Drag

To drag, place your finger on the screen, and slide it across the screen.

Example: To scroll up or down on a web page, drag the page with your finger.

Swipe

To swipe, slide your finger quickly left or right on the screen.

Scroll

To scroll up or down in lists that have a scroll bar, drag the slider of the scroll bar.

To scroll longer lists, flick the list. The faster you flick, the faster the list moves. If you flick up, the list continues the movement and moves down.

Page 16

16 Get started

To select an item from a spinning list and to stop the movement, tap the item.

Tip: To view a brief description of an icon, place your finger on the icon. Descriptions are not available for all icons.

Touch screen light

To turn the screen light on, tap it.

If the touch screen and keys are locked, tapping the screen does not turn the screen light on. To unlock the screen and keys, slide the lock switch.

Change the ringing tone

Select Menu > Settings and Personal > Profiles.

To personalize a profile, scroll to the profile, and select Options > Customize.

Support

When you want to learn more about how to use your product or you are unsure how your device should function, see the support pages at www.nokia.com/support or your local Nokia website, www.nokia.mobi/support (with a mobile device), the Help application in the device, or the user guide.

If this does not resolve your issue, do one of the following:

• Restart the device: switch off the device, and remove the battery. After about a minute, replace the battery, and switch on the device.

• Restore the original factory settings as explained in the user guide. Your documents and files will be deleted in the reset, so back up your data first.

• Update your device software regularly for optimum performance and possible new features, as explained in the user guide.

If your issue remains unsolved, contact Nokia for repair options. See www.nokia.com/ repair, or in Latin America, www.nokia-latinoamerica.com/centrosdeservicio. Before sending your device for repair, always back up the data in your device.

Open Ovi with your device

Ovi is your door to different Nokia services. For a tour and more information, see www.ovi.com.

Page 17

Find help 17

Find help

For local services and warranty information, see the separate booklet.

In-device help

Your device contains instructions to help to use the applications in your device.

To open help texts from the main menu, select Menu > Help and the application for which you want to read instructions.

When an application is open, to access the help text for the current view, select

Options > Help.

When you are reading the instructions, to change the size of the help text, select

Options > Decrease font size or Increase font size.

You may find links to related topics at the end of the help text. If you select an underlined word, a short explanation is displayed.

Help texts use the following indicators:

Link to a related help topic. Link to the application being discussed.

When you are reading the instructions, to switch between help texts and the application that is open in the background, select Options > Show open apps. and the desired application.

Accessibility solutions

Nokia is committed to making mobile phones easy to use for all individuals, including those with disabilities. For more information, visit the Nokia website at www.nokiaaccessibility.com.

Update software using your PC

Nokia Software Updater is a PC application that enables you to update your device software. To update your device software, you need a compatible PC, broadband internet access, and a compatible USB data cable to connect your device to the PC.

To get more information and to download the Nokia Software Updater application, go to www.nokia.com/softwareupdate, or in Latin America, www.nokialatinoamerica.com/nsu.

Page 18

18 Find help

Settings

Your device normally has MMS, GPRS, streaming, and mobile internet settings automatically configured in the device, based on your network service provider information. You may have settings from your service providers already installed in your device, or you may receive or request the settings from the network service providers as a special message.

Access codes

If you forget any of the access codes, contact your service provider.

Personal identification number (PIN) code — Protect your device and SIM card against unauthorized use. The PIN code (4 - 8 digits) is usually supplied with the SIM card. After three consecutive incorrect PIN code entries, the code is blocked, and you need the PUK code to unblock it.

U PI N co d e — T hi s c o de m ay b e s u pp li e d w i th t he U SI M ca rd . Th e US I M c a rd i s a n en ha n ce d version of the SIM card and is supported by 3G cellular phones.

PIN2 code — This code (4 - 8 digits) is supplied with some SIM cards, and is required to access some functions in your device.

Lock code (also known as security code) — The lock code helps you to protect your device against unauthorized use. The preset code is 12345. You can create and change the code, and set the device to request the code. Keep the new code secret and in a safe place separate from your device. If you forget the code and your device is locked, your device will require service and additional charges may apply. Additional charges may apply, and all the personal data in your device may be deleted. For more information, contact a Nokia Care point or your device dealer.

Personal unblocking key (PUK) code and PUK2 code — These codes (8 digits) are required to change a blocked PIN code or PIN2 code, respectively. If the codes are not supplied with the SIM card, contact the network service provider whose SIM card is in your device.

UPUK code — This code (8 digits) is required to change a blocked UPIN code. If the code is not supplied with the USIM card, contact the network service provider whose USIM card is in your device.

Prolong battery life

Many features in your device increase the demand on battery power and reduce the battery lifetime. To save battery power, note the following:

• Features that use Bluetooth technology, or allowing such features to run in the background while using other features, increase the demand on battery power. Turn Bluetooth technology off when you do not need it.

• Features that use wireless LAN (WLAN), or allowing such features to run in the background while using other features, increase the demand on battery power. WLAN on your Nokia device switches off when you are not trying to connect, not connected to an access point, or not scanning for available networks. To further

Page 19

Find help 19

reduce battery consumption, you can specify that your device does not scan, or scans less often, for available networks in the background.

• If you have set Packet data connection to When available in connection settings, and there is no packet data coverage (GPRS), the device periodically tries to establish a packet data connection. To prolong the operating time of your device, select

Packet data connection > When needed.

• The Maps application downloads new map information when you move to new areas on the map, which increases the demand on battery power. You can prevent the automatic download of new maps.

• If the signal strength of the cellular network varies much in your area, your device must scan for the available network repeatedly. This increases the demand on battery power.

If the network mode is set to dual mode in the network settings, the device searches for the UMTS network. You can set the device to use only the GSM network. To only use the GSM network, select Menu > Settings and Connectivity > Network >

Network mode > GSM.

• The backlight of the display increases the demand on battery power. In the display settings, you can change the time-out after which the backlight is switched off, and adjust the light sensor that observes lighting conditions and adjusts the display brightness. Select Menu > Settings and Phone > Display > Light time-out or

Light sensor.

• Leaving applications running in the background increases the demand on battery power. To close the applications you do not use, press and hold the menu key, select

Options > Show open apps., and navigate to the application with the menu key.

Press and hold the menu key, and select Exit.

Increase available memory

Do you need more available device memory for new applications and content?

View how much space is available for different data types

Select Menu > Applications > Office > File mgr..

Many features of the device use memory to store data. The device notifies you if the memory in different memory locations is low.

Increase available memory

Transfer data to the mass memory or to a compatible computer.

To remove data you no longer need, use File manager or open the respective application. You can remove the following:

• Messages in the folders in Messaging and retrieved e-mail messages in the mailbox

Page 20

20 Find help

• Saved web pages

• Contact information

• Calendar notes

• Applications shown in Application manager that you do not need

• Installation files (.sis or .sisx) of applications you have installed. Transfer the

installation files to a compatible computer.

• Images and video clips in Gallery. Back up the files to a compatible computer.

Page 21

Your device 21

Your device

Phone setup

When you switch on your device for the first time, the Phone setup application opens.

To access the Phone setup application later, select Menu > Applications > Phone

setup.

To set up the device connections, select Sett. wizard.

To transfer data to your device from a compatible Nokia device, select Switch.

The available options may vary.

Transfer content for the first time

1 Select Menu > Settings > Switch. 2 Select the connection type you want to use to transfer the data, and connect the

devices. Both devices must support the selected connection type. If you select Bluetooth connectivity as the connection type, you may need to pair

the devices.

3 On your device, select the content you want to transfer from the other device.

When the transfer has started, you can cancel it and continue later.

Content is transferred from the memory of the other device to the corresponding location in your device. The transfer time depends on the amount of data to be transferred.

Display indicators

The device is being used in a GSM network (network service). The device is being used in a UMTS network (network service). You have one or more unread messages in the Inbox folder in Messaging. You have received new e-mail in the remote mailbox. There are messages waiting to be sent in the Outbox folder. You have missed calls. The ringing type is set to Silent, and the message and e-mail alert tones are

turned off. A timed profile is active.

The touch screen and keys are locked. A clock alarm is active. The second phone line is being used (network service).

Page 22

22 Your device

All calls to the device are diverted to another number (network service). If you have two phone lines, a number indicates the active line. A compatible headset is connected to the device.

A compatible TV out cable is connected to the device. A compatible text phone is connected to the device. A data call is active (network service).

A GPRS packet data connection is active (network service). indicates that the connection is on hold and

that a connection is available. A packet data connection is active in a part of the network that supports EGPRS (network service).

indicates that the connection is on hold and that a connection is available. The icons indicate that EGPRS is available in the network, but your device is not necessarily using an EGPRS connection to transfer data. A UMTS packet data connection is active (network service). indicates that the connection is suspended and

that a connection is being established. High-speed downlink packet access (HSDPA) is supported and active (network service).

indicates that the connection is suspended and that a connection is being established. You have set the device to scan for wireless LANs, and a wireless LAN is available (network service). A wireless LAN connection is active in a network that uses encryption. A wireless LAN connection is active in a network that does not use encryption. Bluetooth connectivity is activated. Data is being transmitted using Bluetooth connectivity. When the indicator is blinking, your device is trying to connect with another device. A USB connection is active.

Synchronization is in progress. GPS is active.

Volume and loudspeaker control

Adjust the volume of a phone call or sound clip

Use the volume keys.

Page 23

Your device 23

The built-in loudspeaker allows you to speak and listen from a short distance without having to hold the device to your ear.

Use the loudspeaker during a call

Select Activate loudsp..

Turn off the loudspeaker.

Select Activate handset.

Warning:

Continuous exposure to high volume may damage your hearing. Listen to music at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Shortcuts

To switch between open applications, press and hold the menu key. Leaving applications running in the background increases the demand on battery power

and reduces the battery life.

To start a web connection (network service), in the dialer, tap and hold 0.

To access applications available in the media bar, such as the music player and web browser, in any view, press the media key.

To change the profile, press the power key, and select a profile.

To call your voice mailbox (network service), in the dialer, tap and hold 1.

To open a list of last dialed numbers, in the home screen, press the call key.

To use voice commands, in the home screen, press and hold the call key.

Antenna locations

Your device may have internal and external antennas. Avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with antennas affects the communication quality and may cause a higher power level during operation and may reduce the battery life.

Page 24

24 Your device

Cellular antenna

Bluetooth and WLAN

antenna

GPS antenna

Contacts bar

To start using the contacts bar and add your contacts to the home screen, select

Options > New contact, and follow the instructions.

To communicate with your contact, select the contact and from the following:

— Make a phone call.

— Send a message.

— Add a new feed.

— Refresh feeds.

— Modify settings.

To view the latest call event and other past communication events with a contact, select a contact. To call the contact, press the call key. To view details of other events, select a communication event.

To close the view, select

Offline profile

The offline profile lets you use the device without connecting to the wireless cellular network. When the offline profile is active, you can use your device without a SIM card.

Activate the offline profile

Press the power key briefly, and select Offline.

Page 25

Your device 25

When you activate the offline profile, the connection to the cellular network is closed. All radio frequency signals to and from the device to the cellular network are prevented. If you try to send messages using the cellular network, they are placed in the Outbox folder to be sent later.

Important: In the Offline profile you cannot make or receive any calls, or use other features that require cellular network coverage. Calls may still be possible to the official emergency number programed into your device. To make calls, you must first activate the phone function by changing profiles. If the device has been locked, enter the lock code.

When you have activated the offline profile, you can still use a wireless LAN (WLAN), for example, to read your e-mail or browse on the internet. You can also use Bluetooth connectivity while in the offline profile. Remember to comply with any applicable safety requirements when establishing and using WLAN or Bluetooth connections.

Sensor settings and display rotation

When you activate the sensors in your device, you can control certain functions by turning the device.

Select Menu > Settings and Phone > Sensor settings.

Select from the following:

Sensors — Activate the sensors. Turning control — Select Silencing calls and Snoozing alarms to mute calls and

snooze alarms by turning your device so that the display faces down. SelectAuto-rotate

display to rotate the display content automatically when you turn the device on its left

side or back to a vertical position. Some applications and features may not support rotating the display content.

Headset

You can connect a compatible headset or compatible headphones to your device. You may need to select the cable mode.

Page 26

26 Your device

Warning:

When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Remove the SIM card

1 Remove the back cover by lifting it from the bottom end of the device. 2 Remove the battery.

Page 27

Your device 27

3 Open the cover of the SIM card slot. In the opening under the battery, push the lip

sideways to slide the SIM card out of the slot. Pull the SIM card out.

4 Replace the battery and back cover.

Attach a wrist strap

Remote lock

You can lock your device remotely using a predefined text message.

Enable remote locking

1 Select Menu > Settings and Phone > Phon e mgmt. > Security > Phone and SIM

card > Remote phone locking > Enabled.

2 Enter the text message content (5-20 characters), verify it, and enter the lock code.

Lock your device remotely

Write the predefined text message, and send it to your device. To unlock your device, you need the lock code.

Page 28

28 Make calls

Make calls

Touch screen during calls

Your device has a proximity sensor. To extend battery life and prevent accidental selections, the touch screen is disabled automatically during calls, when you place the device next to your ear.

Do not cover the proximity sensor, for example, with protective film or tape.

Voice calls

1 In the home screen, select Telephone to open the dialler, and enter the phone

number, including the area code. To remove a number, press C. For international calls, select * twice for the + character (which replaces the

international access code), and enter the country code, area code (omit the leading zero if necessary), and phone number. The + character as a replacement for the international access code may not work in all regions. In this case, enter the

international access code directly. 2 To make the call, press the call key. 3 To end the call (or to cancel the call attempt), press the end key.

Pressing the end key always ends a call, even if another application is active.

To make a call from the contacts list, select Menu > Contacts.

Go to the desired name. Or, select the search field, enter the first letters or characters of the name, and go to the name.

To call the contact, press the call key. If you have saved several numbers for a contact, select the desired number from the list, and press the call key.

During a call

Mute or unmute the microphone

Select

Put an active voice call on hold

Select

or .

Page 29

Make calls 29

Activate the loudspeaker

Select

. If you have attached a compatible headset with Bluetooth connectivity, to

route the sound to the headset, select Options > Activate BT handsfree.

Switch back to the handset

Select

End a call

Select

Switch between active and held calls

Select Options > Swap.

Tip: To put an active call on hold, press the call key. To activate the held call, press the call key again.

Send Touch tone strings

1 Select Options > Send touch tones. 2 Enter the Touch tone string or search for it in the contacts list. 3 To enter a wait character (w) or a pause character (p), press * repeatedly. 4 To send the tone, select OK. You can add touch tones to the phone number or touch

tone field in contact details.

End an active call and replace it with another incoming call

Select Options > Replace.

End all calls

Select Options > End all calls.

Many of the options that you can use during a voice call are network services.

Voice mailbox

To call your voice mailbox (network service), in the home screen, select Telephone, and select and hold 1.

1 To change the phone number of your voice mailbox, select Menu > Settings and

Calling > Call mailbox, a mailbox, and Options > Change number.

2 Enter the number (obtained from your network service provider), and select OK.

Page 30

30 Make calls

Answer or reject a call

To answer a call when the touch screen is locked, swipe the screen. Follow the visual cues.

To answer a call when the touch screen is unlocked, press the call key.

To mute the ringing tone of an incoming call when the touch screen is locked, swipe to unlock the screen.

To mute the ringing tone of an incoming call when the touch screen is unlocked, select

You can send a text message without rejecting the call, informing the caller that you cannot answer the call. To activate the text message option and write a standard reply message, select Menu > Settings and Calling > Call > Decline call with msg., and

Message text. To send the reply message, select Send msg., edit the message text, and

press the call key.

If you do not want to answer a call, when the touch screen is unlocked, press the end key. If you activate the Call forwarding > Voice calls > If busy function in phone settings, rejecting an incoming call also diverts the call.

To reject a call when the touch screen is locked, swipe to unlock the screen, and select

Options > Reject.

Make a conference call

Your device supports conference calls between a maximum of six participants, including yourself.

1 Make a call to the first participant. 2 To make a call to another participant, select Options > New call. The first call is

put on hold. 3 When the new call is answered, to add the first participant to the conference call,

select

Add a new participant to a conference call

Make a call to another participant, and add the new call to the conference call.

Have a private conversation with a conference call participant

Select Go to the participant, and select

. The conference call is put on hold on your device.

The other participants can still continue the conference call.

Page 31

Make calls 31

To return to the conference call, select .

Drop a participant from a conference call

Select

, go to the participant, and select .

End an active conference call

Press the end key.

Speed dial a phone number

To activate 1-touch dialing, select Menu > Settings and Calling > Call > 1-touch

dialing.

1 To assign a phone number to one of the number keys, select Menu > Settings and

Calling > 1-touch dialing.

2 Go to the key to which you want to assign the phone number, and select

Options > Assign.

1 is reserved for the voice mailbox.

To call in the home screen, select Telephone and the assigned key, and press the call key.

To call in the home screen when speed dialling is active, select Telephone, and select and hold the assigned key.

Call waiting

With call waiting (network service), you can answer a call when you have another call in progress.

Activate call waiting

Select Menu > Settings and Calling > Call > Call waiting.

Answer a waiting call

Press the call key. The first call is put on hold.

Swap between an active call and a call on hold

Select Options > Swap.

Connect the call on hold to the active call

Select Options > Transfer. You disconnect yourself from the calls.

Page 32

32 Make calls

End an active call

Press the end key.

End both calls

Select Options > End all calls.

Voice dialing

Your device automatically creates a voice tag for the contacts.

Listen to a voice tag for a contact

1 Select a contact and Options > Voice tag details. 2 Scroll to a contact detail, and select Options > Play voice tag.

Make a call with a voice tag Note: Using voice tags may be difficult in a noisy environment or during an emergency,

so you should not rely solely upon voice dialing in all circumstances.

When you use voice dialing, the loudspeaker is in use. Hold the device at a short distance away when you say the voice tag.

1 To start voice dialling, in the home screen, press and hold the call key. If a compatible

headset with the headset key is attached, press and hold the headset key to start

voice dialing. 2 A short tone sounds, and Speak now is displayed. Say clearly the name that is saved

for the contact. 3 The device plays a synthesized voice tag for the recognized contact in the selected

device language, and displays the name and number. To cancel the voice dialing,

select Quit.

If several numbers are saved for a name, you can say also the name and the number type, such as mobile or telephone.

Make a video call

When you make a video call (network service), you can see a real-time, two-way video between you and the recipient of the call. The live video image, or video image captured by the camera in your device is shown to the video call recipient.

To be able to make a video call, you must have a USIM card and be in the coverage of a UMTS network. For availability, pricing and subscription to video call services, contact your network service provider.

A video call can only be made between two parties. The video call can be made to a compatible mobile device or an ISDN client. Video calls cannot be made while another voice, video, or data call is active.

Page 33

Make calls 33

Icons

You are not receiving video (the recipient is not sending video or the network is not transmitting it). You have denied video sending from your device. To send a still image instead, select Menu > Settings and Calling > Call > Image in video call.

Even if you denied video sending during a video call, the call is still charged as a video call. Check the pricing with your service provider.

1 In the home screen, select

or Telephone to open the dialler, and enter the phone

number.

2 Select Options > Call > Video call.

By default, the secondary camera on the front is used for video calls. Starting a video call may take a while. If the call is not successful (for example, video calls are not supported by the network, or the receiving device is not compatible), you are asked if you want to try a normal call or send a message instead.

The video call is active when you see two video images, and hear the sound through the loudspeaker. The call recipient may deny video sending (indicated with you only hear the voice of the caller and may see a still image or a grey screen.

3 To end the video call, press the end key.

During a video call

View live video or listen to the caller only

or .

Select

Mute or unmute the microphone

Select

or .

), and

Activate the loudspeaker

Select

. If you have attached a compatible headset with Bluetooth connectivity, to

route the sound to the headset, select Options > Activate BT handsfree.

Switch back to the handset

Select

Use the main camera to send video

Select Options > Use secondary camera.

Switch back to using the secondary camera to send video

Select Options > Use main camera.

Page 34

34 Make calls

Take a snapshot of the video you are sending

Select Options > Send snapshot. Video sending is paused and the snapshot is shown to the recipient. The snapshot is not saved.

Zoom your image

Select Options > Zoom.

Set the video quality

Select Options > Adjust > Video preference > Normal quality, Clearer detail or

Smoother motion.

Answer or reject a video call

When a video call arrives,

is displayed.

Answer a video call

Press the call key.

To start sending live video, select Yes.

If you do not activate the video sending, you only hear the voice of the caller. A grey screen replaces your own video.

Start sending video during a video call

Select Options > Enable > Sending video.

Replace the grey screen with an image captured by the camera

Select Menu > Settings and Calling > Call > Image in video call.

Reject a video call

Press the end key.

Video sharing

Use video sharing (network service) to send live video or a video clip from your mobile device to another compatible mobile device during a voice call.

The loudspeaker is active when you activate video sharing. If you do not want to use the loudspeaker for the voice call while you share video, you can also use a compatible headset.

Page 35

Make calls 35

Warning:

Continuous exposure to high volume may damage your hearing. Listen to music at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Video sharing requirements

Video sharing requires a 3G connection. Your ability to use video sharing depends on the availability of the 3G network. For more information on the service, 3G network availability, and fees associated with using this service, contact your service provider.

To use video sharing, ensure the following:

• Your device is set up for person-to-person connections.

• You have an active 3G connection and are within 3G network coverage. If you move

outside the 3G network during a video sharing session, the sharing stops, while your voice call continues.

• Both the sender and recipient are registered to the 3G network. If you invite someone to a sharing session and the recipient’s device is not within 3G network coverage or does not have video sharing installed or person-to-person connections set up, the recipient does not receive invitations. You receive an error message that indicates that the recipient cannot accept the invitation.

Video sharing settings

To set up video sharing, you need person-to-person and 3G connection settings.

A person-to-person connection is also known as a Session Initiation Protocol (SIP) connection. The SIP profile settings must be configured in your device before you can use video sharing. Ask your service provider for the SIP profile settings, and save them to your device. Your service provider may send you the settings or give you a list of the needed parameters.

Add a SIP address to a contact

1 Select Menu > Contacts. 2 Select a contact or create a new contact. 3 Select Options > Edit. 4 Select Options > Add detail > Share video. 5 Enter the SIP address in the format username@domainname (you can use an IP

address instead of a domain name). If you do not know the SIP address for the contact, you can use the phone number

of the recipient, including the country code, to share video (if supported by the network service provider).

Page 36

36 Make calls

Set up your 3G connection

Contact your service provider to establish an agreement for you to use the 3G network.

Ensure that the 3G access point connection settings for your device are configured properly. For more information about the settings, contact your service provider.

Share live video or video clips

During an active voice call, select Options > Share video.

1 To share live video during the call, select Live video.

To share a video, select Video clip. A list of videos saved in the device memory or the mass memory opens. Select the clip you want to share.

You may need to convert the video clip into a suitable format to be able to share it. If your device notifies you that the video clip must be converted, select OK. Your device must have a video editor for the conversion to work.

2 If the recipient has several SIP addresses or phone numbers including the country

code saved in Contacts, select the desired address or number. If the SIP address or phone number of the recipient is not available, enter the address or number of the recipient including the country code, and select OK to send the invitation. Your device sends the invitation to the SIP address.

Sharing begins automatically when the recipient accepts the invitation.

Options during video sharing

Mute or unmute the microphone.

Turn the loudspeaker on and off.

Pause and resume video sharing.

to switch to full screen mode (available for receiver only)

3 To end the sharing session, select Stop. To end the voice call, press the end key.

When you end the call, video sharing also ends.

To save the live video you shared, select Yes when prompted. The device notifies you of the location of the saved video.

If you access other applications while you are sharing a video clip, the sharing is paused. To return to the video sharing view and to continue sharing, in the home screen, select

Options > Resume video sharing.

Accept a video sharing invitation

When someone sends you a video sharing invitation, the invitation message displays the sender’s name or SIP address.

Page 37

Make calls 37

If someone sends you a sharing invitation and you are not within 3G network coverage, you will not know that you received an invitation.

Accept the received invitation

Select Yes. The sharing session is activated.

Reject the received invitation

Select No. The sender receives a message that you rejected the invitation. You can also press the end key to reject the invitation and end the voice call.

End the sharing session

Select Stop or end the voice call. When you end the call, video sharing also ends.

Log

The Log application stores information about the communication history of the device. The device registers missed and received calls only if the network supports these functions, and the device is switched on and within the network service area.

Recent calls

You can view information about your recent calls.

Select Menu > Log and Recent calls.

View missed, received, and dialed calls

Select Missed calls, Received calls, or Dialed numbers.

Tip: To open the dialed numbers list in the home screen, press the call key.

Select Options and from the following:

Save to Contacts — Save a phone number from a recent calls list to your contacts. Clear list — Clear the selected recent calls list. Delete — Clear an event in the selected list. Settings — Select Log duration and the length of time that the communication

information is saved in the log. If you select No log, no information is saved in the log.

Packet data

Select Menu > Log.

You may be charged for your packet data connections by the amount of data sent and received.

Page 38

38 Make calls

Check the amount of data sent or received during GPRS connections

Select Packet data > All sent data or All received data.

Clear both sent and received information

Select Packet data > Options > Clear counters. You need the lock code to clear the information.

Call duration

You can view the approximate duration of your last call, dialled and received calls, and all calls.

Select Menu > Log and Call timers.

Monitor all communication events

In the general log, you can view information on communication events, such as voice calls, text messages, or data and wireless LAN (WLAN) connections registered by your device.

Select Menu > Log.

Open the general log

Open the general log tab

Subevents, such as a text message sent in more than one part and packet data connections, are logged as one communication event. Connections to your mailbox, multimedia messaging center or web pages are shown as packet data connections.

View the GPRS connection details

Go to an incoming or outgoing GPRS connection event indicated with GPRS, and select

Options > View.

Copy a phone number from the log

Select Options > Use number > Copy. You can, for example, paste the phone number to a text message.

Filter the log

Select Options > Filter and a filter.

Define the log duration

Select Options > Settings > Log duration. If you select No log, all the log contents, recent calls register, and messaging delivery reports are permanently deleted.

Page 39

Write text 39

Write text

Tap any text input field to enter letters, numbers, and special characters.

Your device can complete words based on the built-in dictionary for the selected text input language. The device also learns new words from your input.

Automatic input modes

When the sensors and display rotation in your device are activated, the input mode is automatically switched to full-screen keyboard in landscape mode and to alphanumeric keypad in portrait mode.

To activate the sensors and display rotation, do the following:

1 Select Menu > Settings and Phone > Sensor settings > Sensors > On. 2 Select Turning control > Auto-rotate display.

Virtual keyboard

You can use the virtual keyboard in landscape mode.

To activate the virtual keyboard, select available, if the automatic input mode switch is in use (sensors are activated).

1 Close - Close the virtual keyboard. 2 Input menu - Open the touch input options menu to access commands such as

Writing language.

3 Virtual keyboard 4 Shift and caps lock - To enter an uppercase character when writing in lowercase, or

vice versa, select the key before entering the character. To activate the caps lock, select the key twice. A line under the key indicates that the caps lock is activated.

5 Letters 6 Numbers and special characters 7 Character accents 8 Space bar 9 Move the cursor after inputting characters. 10 Backspace

> Full screen QWERTY. This function is not

Page 40

40 Write text

11 Enter – Move the cursor to the next row or text input field. Additional functions are

based on the current context.

12 Input mode - Select the input method. When you tap an item, the current input

method view closes, and the selected one opens. The availability of input modes may vary depending on whether the automatic input modes are activated or not.

Alphanumeric keypad Virtual keypad

With the virtual keypad (Alphanumeric keypad), you can enter characters like you would with a traditional physical keypad with numbers on the keys.

1 Close - Closes the virtual keypad (Alphanumeric keypad). 2 Input menu - Opens the touch input menu, which includes commands such as

Activate predictive text and Writing language.

3 Text input indicator - Opens a pop-up window, in which you can activate or

deactivate predictive text input modes, change the character case, and switch between letter and number modes.

4 Input mode - Opens a pop-up window, in which you can select the input mode.

When you tap an item, the current input method view closes, and the selected one opens. The availability of input modes may vary depending on whether the automatic input mode (sensor settings) is activated or not.

5 Arrow keys - Scroll left or right. 6 Backspace 7 Numbers 8 Star - Opens a special characters table.

Page 41

Write text 41

9 Shift - Changes the character case, activates or deactivates predictive text input

modes, and switches between letter and number modes.

Traditional text input

Tap a number key (1-9) repeatedly until the desired character appears. There are more characters available for a number key than are visible on the key.

If the next letter is located on the same key as the present one, wait until the cursor appears (or move the cursor forward to end the time-out period), and enter the letter.

To insert a space, tap 0. To move the cursor to the next line, tap 0 three times.

Predictive text input

With predictive text input, you can enter any word with a single key selection. Predictive text input is based on a built-in dictionary to which you can add new words. The predictive text dictionary is not available for all languages.

1 To activate predictive text input for all editors on the device, select

prediction. You can also select

> Activate predictive text.

> Activate

2 To write the desired word, use the keys 2-9. Select each key only once for one letter.

For example, to write "Nokia" when the English dictionary is selected, select 6 for N, 6 for o, 5 for k, 4 for i, and 2 for a.

The word suggestion changes after each key selection.

3 When you finish writing the word correctly, move the cursor right to confirm it, or

select 0 to add a space. If the word is not correct, select * repeatedly to view the matching words the

dictionary has found one by one. If the ? character is displayed after the word, the word is not in the dictionary. To

add a word to the dictionary, select Spell, enter the word using traditional text input, and select OK. The word is added to the dictionary. When the dictionary is full, a new word replaces the oldest added word.

4 Start writing the next word.

Switch between text modes

To deactivate predictive text input for all editors in your device, press

Deactivate prediction, or quickly double-tap #. You can also press

> Predictive

text > Off.

Page 42

42 Write text

Touch input settings

Select Menu > Settings and Phone > Touch input.

Select from the following: Writing language — Change the writing language and the language of the dictionary

in predictive text input. Adaptive search — Filter the contents of a list in an application according to the

characters written in the search field.

Page 43

Contacts 43

Contacts

You can save and update contact information, such as phone numbers, home addresses, or e-mail addresses of your contacts. You can add a personal ringing tone or a th umbnail image to a contact. You can also create contact groups, which allow you to send text messages or e-mail to many recipients at the same time.

To open the contacts list, in the home screen, depending on the home screen theme, select Contacts or

Save and edit names and numbers

Select Menu > Contacts.

Add a new contact to the contacts list

1 Select 2 Tap a field to enter information. To close the text input, select

appropriate fields, and select Done.

Edit contacts

Select a contact and Options > Edit.

Contacts toolbar

Select Menu > Contacts.

Call a contact

Go to a contact, and select

Send a message to a contact

Go to a contact, and select

Create a new contact

Select

New contact.

. Fill in the

Call.

Create message.

Manage names and numbers

Select Menu > Contacts.

Delete contacts

Select a contact and Options > Delete. To delete several contacts at the same time, select Options > Mark/Unmark to mark

the desired contacts, and to delete, select Options > Delete.

Page 44

44 Contacts

Copy contacts

Select the contact, Options > Copy, and the desired location.

Add contacts to favorites

Tap and hold a contact, and select Add to favorites.

Listen to the voice tag assigned to a contact

Select the contact and Options > Voice tag details > Options > Play voice tag.

Before using voice tags, note the following:

• Voice tags are not language-dependent. They are dependent on the speaker's voice.

• You must say the name exactly as you said it when you recorded it.

• Voice tags are sensitive to background noise. Record voice tags and use them in a

quiet environment.

• Very short names are not accepted. Use long names, and avoid similar names for different numbers.

Note: Using voice tags may be difficult in a noisy environment or during an emergency, so you should not rely solely upon voice dialing in all circumstances.

Assign default numbers and addresses

If a contact has several numbers or addresses, a default number or address makes it easier for you to call or send a message to the contact. The default number is also used in voice dialling.

1 Select Menu > Contacts. 2 Select a contact and Options > Defaults. 3 Select a default to which you want to add a number or an address, and select

Assign.

4 Select a number or an address you want to set as a default. 5 To exit the Defaults view and save the changes, tap outside the view.

Ringing tones, images, and call text for contacts

You can define a ringing tone for a contact or contact group, and an image and call text for a contact. When the contact calls you, the device plays the selected ringing tone and shows the call text or image (if the caller’s phone number is sent with the call and your device recognizes it).

Select Menu > Contacts.

Page 45

Contacts 45

Add more fields to a contact details view

Select the contact and Options > Edit > Options > Add detail.

Define a ringing tone for a contact or contact group

Select the contact or contact group and Options > Ringing tone, and select a ringing tone.

Remove the ringing tone from a contact

Select Default tone from the list of ringing tones.

Add an image for a contact

Select a contact saved in the device memory and Options > Edit > Add image, and select an image from Gallery.

Define a call text for a contact

Select the contact and Options > Edit > Add call alert text. Enter the call text, and select

View, change or remove the image from a contact

1 Select a contact and Options > Edit. 2Go to Image, and select Options and the desired option.

Copy contacts

Select Menu > Contacts.

When you open the contacts list for the first time, the device asks if you want to copy names and numbers from the SIM card to your device.

Start copying

Select OK.

Cancel copying

Select Cancel. The device asks if you want to view the SIM card contacts in the contacts list. To view

the contacts, select OK. The contacts list opens, and the names stored on your SIM card are indicated with

SIM services

For availability and information on using SIM card services, contact your SIM card vendor. This may be the network service provider or other vendor.

Page 46

46 Contacts

SIM contacts

The number of contacts that can be stored on the SIM card is limited.

Display contacts stored on the SIM card in the contacts list

Select Options > Settings > Contacts to display > SIM memory.

The numbers you save in the contacts list may not be automatically saved to your SIM card.

Copy contacts to the SIM card

Go to a contact, and select Options > Copy > SIM memory.

Select the default memory where to save the new contacts

Select Options > Settings > Default saving memory > Phone memory or SIM

memory.

Contacts stored in the device memory can contain more than one phone number and an image.

Fixed dialing

With the fixed dialing service, you can restrict calls from your device to certain phone numbers. Not all SIM cards support the fixed dialing service. For more information, contact your service provider.

Select Menu > Contacts and Options > SIM numbers > Fixed dial contacts.

When security features that restrict calls are in use (such as call barring, closed user group, and fixed dialing), calls may be possible to the official emergency number programmed into your device. Call restrictions and call forwarding cannot be active at the same time.

You need your PIN2 code to activate and deactivate fixed dialing or edit your fixed dialing contacts. Contact your service provider for your PIN2 code.

Select Options and from the following: Activate fixed dialing or Deactivate fixed dialing — Activate or deactivate fixed

dialling. New SIM contact — Enter the contact name and phone number to which calls are

allowed. Add from Contacts — Copy a contact from the contacts list to the fixed dialling list.

To send text messages to the SIM contacts while the fixed dialing service is active, you need to add the text message centre number to the fixed dialing list.

Page 47

Messaging 47

Messaging

Messaging main view

Select Menu > Messaging (network service).

Create a new message

Select New message.

Tip: To avoid rewriting messages that you send often, use saved messages in the Templates folder in My folders. You can also create and save your own templates.

Messaging contains the following folders:

Inbox — Received messages, except e-mail and cell broadcast messages. My folders — Organize your messages into folders.

Mailbox — Connect to your remote mailbox to retrieve your new e-mail messages,

or view your previously retrieved e-mail messages offline.

Drafts — Draft messages that have not been sent.

Sent — The last messages that have been sent, excluding messages sent using Bluetooth connectivity or infrared. You can define the number of messages that can be saved in this folder.

Outbox — Messages waiting to be sent are temporarily stored in the Outbox, for

example, when your device is outside network coverage.

Delivery reports — Request the network to send you a delivery report of the text

messages and multimedia messages you have sent (network service).

Write and send messages

Select Menu > Messaging.

Important: Exercise caution when opening messages. Messages may contain malicious software or otherwise be harmful to your device or PC.

Before you can create a multimedia message or write an e-mail, you must have the correct connection settings defined.

The wireless network may limit the size of MM S messages. If the inserted picture exceeds this limit, the device may make it smaller so that it can be sent by MMS.

Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.

Page 48

48 Messaging

Check the size limit of e-mail messages with your service provider. If you attempt to send an e-mail message that exceeds the size limit of the e-mail server, the message is left in the Outbox folder, and the device will attempt to resend it periodically. Sending an e-mail requires a data connection, and continuous attempts to resend the e-mail may incur charges from your service provider. In the Outbox folder, you can delete such message, or move it to the Drafts folder.

Messaging requires network services.

Send a text or multimedia message

Select New message.

Send an audio or e-mail message

Select Options > Create message, and the relevant option.

Select recipients or groups from the contacts list

Select

from the toolbar.

Enter the number or e-mail address manually

Tap the To field.

Enter the subject of the e-mail or multimedia message

Enter it in the Subject field, . If the Subject field is not visible, select Options > Message

header fields to change the fields that are visible.

Write the message

Tap the message field.

Add an object to a message or e-mail

Select

and the relevant type of content.

The message type may change to multimedia message based on the inserted content.

Send the message or e-mail

Select

, or press the call key.

Your device supports text messages beyond the limit for a single message. Longer messages are sent as two or more messages. Your service provider may charge accordingly. Characters with accents, other marks, or some language options take more space, and limit the number of characters that can be sent in a single message.

Messaging inbox Receive messages

Select Menu > Messaging and Inbox.

Page 49

An unread text message An unread multimedia message An unread audio message Data received through Bluetooth connectivity

Messaging 49

When you receive a message,

and 1 new message are displayed in the home screen.

Open a message from the home screen

Select Show.

Open a message in the Inbox folder

Select the message.

Reply to a received message

Select Options > Reply.

Multimedia messages

Select Menu > Messaging.

Important: Exercise caution when opening messages. Messages may contain malicious software or otherwise be harmful to your device or PC.

Retrieve multimedia messages

Select Options > Retrieve. A GPRS connection is opened to retrieve the message to your device. You may receive a notification that a multimedia message is waiting in the multimedia message center.

When you open a multimedia message (

), you may see an image and a message.

indicates that a sound clip is included. indicates that a video is included.

Play the sound or video

Select the indicator.

View the media objects that have been included in a multimedia message

Select Options > Objects.

If the message includes a multimedia presentation,

is displayed.

Play the presentation

Select the indicator.

Page 50

50 Messaging

Data, settings, and web service messages

Your device can receive many kinds of messages that contain data, such as business cards, ringing tones, operator logos, calendar entries, and e-mail notifications. You may also receive settings from your service provider in a configuration message.

Save the data in a message

Select Options and the corresponding option.

Web service messages are notifications (for example, news headlines), and may contain a text message or a link. For availability and subscription, contact your service provider.

Set up your e-mail

To set up your e-mail, select Menu > Messaging and Mailbox.

You can set up several e-mail accounts, for example, a personal e-mail account and a corporate e-mail account.

To se t up e- mail from y our h ome sc reen , select the rele vant plu g-in. Al ternati vely, to set up an e-mail account, select Menu > Settings > Sett. wizard.

Nokia Messaging

The Nokia Messaging service automatically sends e-mail from your existing e-mail address to your device. You can read, respond to, and organize your e-mails on the go. The Nokia Messaging service works with a number of internet e-mail providers that are often used for personal e-mail, such as Google e-mail services.

The Nokia Messaging service may be chargeable. For information on possible costs, contact your service provider or the Nokia Messaging service.

The Nokia Messaging service must be supported by your network and may not be available in all regions.

Nokia Messaging is currently provided on a trial basis.

Install the Nokia messaging application

1 Select Menu > Settings > Sett. wizard. 2 When the Settings wizard is opened for the first time, you are asked to define the

e-mail settings after the operator settings. If you have used the Settings wizard before, select E-mail setup.

3 In the e-mail setup, read the information on the display, and select Start > Nokia

E-mail.

4 Accept the installation of the Nokia Messaging application. 5 Enter your e-mail account details.

Page 51

Messaging 51

The Nokia Messaging application is installed in Menu > Applications.

For more information, see www.email.nokia.com.

Mailbox Define e-mail settings

Select Menu > Messaging and Mailbox.

To use e-mail, you must have defined a valid internet access point (IAP) in your device and have correctly defined your e-mail settings.

You must have a separate e-mail account. Follow the instructions given by your remote mailbox and internet service provider (ISP).

If you select Messaging > Mailbox, and have not set up your e-mail account, you are prompted to do so. To start defining the e-mail settings with the mailbox guide, select

Start.

When you create a new mailbox, the name you give to the mailbox replaces Mailbox in the Messaging main view. You can have up to six mailboxes.

Open the mailbox

Select Menu > Messaging and a mailbox.

When you open the mailbox, the device asks if you want to connect to the mailbox.

Connect to your mailbox and retrieve new e-mail headers or messages

Select Yes. When you view messages onlin e, you are continuously connected to a remote mailbox using a data connection.

View previously retrieved e-mail messages offline

Select No.

Create a new e-mail message.

Select Options > Create message > E-mail.

Close the data connection to the remote mailbox

Select Options > Disconnect.

Retrieve e-mail messages

Select Menu > Messaging and a mailbox.

If you are offline, select Options > Connect to open a connection to the remote mailbox.

Page 52

52 Messaging

Important: Exercise caution when opening messages. Messages may contain malicious

software or otherwise be harmful to your device or PC.

Retrieve messages when you have an open connection to a remote mailbox

Select Options > Retrieve e-mail > New to retrieve all new messages, Selected to retrieve only selected messages, or All to retrieve all messages from the mailbox.

To stop retrieving messages, select Cancel.

Close the connection and view the e-mail messages offline

Select Options > Disconnect.

Open an e-mail message offline

To open an e-mail message, select the message. If the e-mail message has not been retrieved and you are offline, you are asked if you want to retrieve this message from the mailbox.

View e-mail attachments

Open the message, and select the attachment field indicated with

. If the attachment

has not been retrieved to the device, select Options > Retrieve.

Retrieve e-mail messages automatically

Select Options > E-mail settings > Automatic retrieval.

Setting the device to retrieve e-mail automatically may involve the transmission of large amounts of data through your service provider's network. Contact your service provider for information about data transmission charges.

Delete e-mail messages

Select Menu > Messaging and a mailbox.

Delete the content of an e-mail from the device only

Select Options > Delete > Phone only. The e-mail is not deleted from the remote mailbox.

The device mirrors the e-mail headers in the remote mailbox. If you delete the message content, the e-mail header stays in your device. If you want to remove the header as well, you must be connected to the server when deleting the message from your device and the remote mailbox. It there is no connection to the server, the header is deleted when you make a connection from your device to the remote mailbox again to update the status.

Page 53

Messaging 53

Delete an e-mail from the device and the remote mailbox

Select Options > Delete > Phone and server.

Cancel deleting an e-mail that has been marked to be deleted from the device and server

Select Options > Restore.

Disconnect from the mailbox

When you are online, to end the data connection to the remote mailbox, select

Options > Disconnect.

Mail for Exchange

With Mail for Exchange, you can receive your work e-mail to your device. You can read and reply to your e-mails, view and edit compatible attachments, view calendar information, receive and reply to meeting requests, schedule meetings, and view, add, and edit contact information.

ActiveSync

Use of the Mail for Exchange is limited to over-the-air synchronization of PIM information between the Nokia device and the authorized Microsoft Exchange server.

Mail for Exchange can be set up only if your company has Microsoft Exchange Server. In addition, your company's IT administrator must have activated Mail for Exchange for your account.

Before starting to set up Mail for Exchange, ensure that you have the following:

• A corporate e-mail ID

• Your office network user name

• Your office network password

• Your network domain name (contact your company's IT department)

• Your Mail for Exchange server name (contact your company's IT department)

Depending on your company's Mail for Exchange server configuration, you may need to enter other information in addition to those listed. If you do not know the correct information, contact your company's IT department.

With Mail for Exchange, the use of the lock code may be mandatory. The default lock code of your device is 12345, but your company's IT administrator may have set a different one for you to use.

Page 54

54 Messaging

You can access and modify the Mail for Exchange profile and settings in the Messaging settings.

View messages on a SIM card

You can view messages that are stored on a SIM card.

Select Menu > Messaging and Options > SIM messages.

Before you can view SIM messages, you must copy them to a folder in your device.

1 Mark the messages. Select Options > Mark/Unmark > Mark or Mark all. 2 Open a list of folders. Select Options > Copy. 3 Select a folder to copy. 4 To view the messages, open the folder .

Cell broadcast messages

Cell broadcast (network service) allows you to receive messages on various topics, such as weather or traffic conditions, from your service provider. For available topics and relevant topic numbers, contact your service provider. This service may not be available for all regions.Cell broadcast messages cannot be received in 3G networks. A GPRS connection may prevent cell broadcast reception.

Select Menu > Messaging and Options > Cell broadcast.

Service commands

With service commands (network service) you can enter and send service requests (also known as USSD commands), such as activation commands for network services, to your service provider. This service may not be available for all regions.

Select Menu > Messaging and Options > Service commands.

Messaging settings

The settings may be preconfigured in your device, or you may receive them in a message. To enter settings manually, fill in all fields marked with Must be defined or an asterisk.

Some or all message centers or access points may be preset for your device by your service provider, and you may not be able to change, create, edit, or remove them.

Text message settings

Select Menu > Messaging and Options > Settings > Text message.

Select from the following:

Message centers — View a list of all text message centers that have been defined. Message center in use — Select which message center to use to deliver text messages.

Page 55

Messaging 55

Character encoding — To use character conversion to another encoding system when

available, select Reduced support. Receive report — Request the network to send you a delivery report of the text

messages you have sent (network service). Message validity — Select for how long the message center resends your message if

the first attempt fails (network service). If the message cannot be sent within this time period, the message is deleted from the message center.

Message sent as — T o find out if yo ur messa ge cente r is able to con vert text mes sages into these other formats, contact your service provider.

Preferred connection — Select the connection to use. Reply via same center — Reply to messages using the same text message center

number (network service).

Multimedia message settings

Select Menu > Messaging and Options > Settings > Multimedia message.

Select from the following:

Image size — Define the size of the image in a multimedia message. MMS creation mode — If you select Guided, the device informs you if you try to send

a message that may not be supported by the recipient. If you select Restricted, the device prevents you from sending messages that may not be supported. To include content in your messages without notifications, select Free.

Access point in use — Select which access point is used as the preferred connection. Multimedia retrieval — Select how you want to receive messages, if available. To

receive messages automatically in your home network, select Auto in home netw.. Outside your home network, you receive a notification that there is a message to retrieve in the multimedia message center. If you select Always automatic, your device automatically makes an active GPRS connection to retrieve the message both in and outside your home network. Select Manual to retrieve multimedia messages from the message center manually, or Off to prevent receipt of any multimedia messages. Automatic retrieval may not be supported in all regions.

Allow anonymous msgs. — Reject messages from anonymous senders. Receive ads — Receive multimedia message advertisements (network service). Receive reports — Display the status of sent messages in the log (network service). Deny report sending — Prevent your device from sending delivery reports of received

messages. Message validity — Select for how long the message center resends your message if

the first attempt fails (network service). If the message cannot be sent within this time period, the message is deleted from the message center.

Page 56

56 Messaging

The device requires network support to indicate that a sent message has been received or read. Depending on the network and other circumstances, this information may not always be reliable.

E-mail settings Manage mailboxes

Select Menu > Messaging and Options > Settings > E-mail.

Select which mailbox you want to use to send and receive e-mail

Select Mailbox in useand a mailbox.

Remove a mailbox and its messages from your device

Select Mailboxes, go to the desired mailbox, and select Options > Delete.

Create a new mailbox

Select Mailboxes > Options > New mailbox. The name you give to the new mailbox replaces Mailbox in the Messaging main view. You can have up to six mailboxes.

Change the connection settings, user settings, retrieval settings, and automatic retrieval settings

Select Mailboxesand a mailbox.

Instant messaging

Select Menu > Applications > IM.

Note: IM service involves the transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can explain what charges will apply. The availability of IM service depends on the offer of your service provider. Check with your service provider for the availability of IM service.

Instant messaging (IM) (network service) allows you to chat with other people using instant messages and join discussion forums (IM groups) with specific topics. Various service providers maintain compatible IM servers that you can log in to after you register to an IM service. Service providers may differ in their support of features.

Before you can use Instant messaging, you must save the settings to access the service that you want to use. The settings may be preconfigured in your device, or you may receive the settings as a configuration message from the service provider that offers the IM service. You can also enter the settings manually.

Page 57

Personalize your device 57

Personalize your device

You can personalize your device by changing the home screen, tones, or themes.

Change the look of your device

You can use themes to change the look of the display, such as background image

and main menu layout.

Select Menu > Settings and Personal > Themes.

Preview a theme

Select General, go to the theme, and wait for a few seconds.

Activate the theme

Select Options > Set.

Change the layout of the main menu

Select Menu.

Change the look of the home screen

Select Home scr. theme.

Set an image or a slideshow as the background in the home screen

Select Wallpaper > Image or Slide show.

Change the image displayed in the home screen when a call is received

Select Call image.

Profiles

You can use profiles to set and customize the ringing tones, message alert tones, and other tones for different events, environments, or caller groups. The name of the selected profile is displayed in the home screen. If the general profile is in use, only the date is displayed.

Select Menu > Settings and Personal > Profiles.

Page 58

58 Music folder

Music folder

Music player

Music player supports file formats such as AAC, AAC+, eAAC+, MP3, and WMA. Music player does not necessarily support all features of a file format or all the variations of file formats.

You can also use Music player to listen to podcasts. Podcasting is a method for delivering audio or video content over the internet using either RSS or Atom technologies for playback on mobile devices and computers.

Play a song or a podcast

To open Music player, select

You may have to refresh the music and podcast libraries after you have updated the song or podcast selection in your device. To add all available items to the library, select

Options > Refresh library.

To play a song or a podcast:

1 Select categories to navigate to the song or podcasts you want to hear. 2 To play an item, select the item from the list.

> .

To pause playback, tap

; to resume, tap .

To fast-forward or rewind, tap and hold

or .

Page 59

Music folder 59

To go to the next item, tap . To return to the beginning of the item, tap . To skip to the previous item, tap

again within 2 seconds after a song or podcast has started.

To turn random play (

To repeat the current item (

) on or off, select Options > Shuffle play.

), all items ( ), or to turn repeat off, select Options >

Repeat.

If you play podcasts, shuffle and repeat are automatically turned off.

To adjust the volume, press the volume key.

To modify the tone of the music playback, select Options > Equalizer.

To modify the balance and stereo image or to enhance the bass, select Options >

Settings.

To return to the home screen and leave the player playing in the background, press the end key.

To close the player, select Options > Exit.

Playlists

Select

> and Playlists.

To view details of the playlist, select Options > Playlist details.

Create a playlist

1 Select Options > New playlist. 2 Enter a name for the playlist, and select OK. 3 To add songs now, select Yes; or to add the songs later, select No. 4 If you select Yes, select artists to find the songs you want to add to the playlist.

Select Add to add items. To show the song list under an artist title, select Expand. To hide the song list, select

Collapse.

5 When you have made your selections, select Done.

The playlist is saved to the mass memory of your device.

To add more songs later, when viewing the playlist, select Options > Add songs.

Page 60

60 Music folder

To add songs, albums, artists, genres, and composers to a playlist from the different views of the music menu, select an item and Options > Add to playlist > Saved

playlist or New playlist.

To remove a song from a playlist, select Options > Remove. This does not delete the song from the device; it only removes it from the playlist.

To reorder songs in a playlist, select the song you want to move, and Options > Reorder

playlist.

To grab a song and drop it to a new position, select the song in the desired position and

Drop.

To finish reordering the playlist, select Done.

Podcasts

Select

> and Podcasts.

Podcast episodes have three states: never played, partially played, and completely played. If the state is partially played, the episode plays from the last playback position the next time it is played. If the state is never played or completely played, the episode plays from the beginning.

Transfer music from a computer

You can use the following methods to transfer music:

• To install Nokia Music to manage and organize your music files, download the PC software from www.music.nokia.com/download, and follow the instructions.

• To view your device on a computer as a mass memory device where you can transfer any data files, make the connection with a compatible USB data cable or Bluetooth connectivity. If you are using a USB data cable, select Mass storage as the connection mode.

• To synchronize music with Windows Media Player, connect a compatible USB data cable, and select Media transfer as the connection mode.

To change the default USB connection mode, select Menu > Settings and

Connectivity > USB > USB connection mode.

Nokia Music

With the Nokia Music PC software, you can transfer music to your device from your computer, and manage and organize your music files.

You need an internet connection to buy music.

Page 61

Music folder 61

Manage your music in Nokia Music

Open the Nokia Music software on your PC, and register or sign in to Nokia Music Store.

Connect your device to the PC with a compatible USB data cable. Do not disconnect the cable until the installation of the software has finished.

To select the connection mode on your device, select Media transfer.

Nokia Music Store

With Nokia Music Store (network service), you can search, browse, and purchase music to download to your device. To purchase music, you first need to register for the service.

Select Menu > Music > Music store.

To access Nokia Music Store, you must have a valid internet access point in the device.

The availability and appearance of Nokia Music Store settings may vary. The settings may also be predefined and you may not be able to modify them.

Select the access point

You may be asked to select the access point to use when connecting to Nokia Music Store. Select Default access point.

Modify Nokia Music Store settings

When browsing Nokia Music Store, you may be able to modify the settings by selecting

Options > Settings.

Nokia Music Store is not available for all countries or regions.

Nokia Podcasting

With the Nokia Podcasting application (network service), you can search, discover, subscribe to, and download podcasts over the air, and play, manage, and share audio and video podcasts with your device.

Podcasting settings

Select Menu > Music > Podcasting.

To start using Podcasting, define your connection and download settings.

Connection settings

Select Options > Settings > Connection and from the following:

Page 62

62 Music folder

Default access point — Select the access point to use to connect to the internet. Search service URL — Define the podcast search service web address, to use to search

for podcasts.

Download settings

Select Options > Settings > Download and from the following: Save to — Define where to save podcasts. For optimal use of storage space, mass

memory is recommended.

Update interval — Define how often podcasts are updated. Next update time — Define the time of the next automatic update.

Automatic updates only occur if a specific default access point is selected and the Podcasting application is open.

Download limit (%) — Define the percentage of memory that is reserved for podcast downloads.

If limit exceeds — Define what to do if the download limit is exceeded.

Setting the application to retrieve podcasts automatically may involve the transmission of large amounts of data through your service provider’s network. For information on data transmission charges, contact your service provider.

Restore default settings

Select Options > Restore default.

Download podcasts

After you have subscribed to a podcast, you can download, play, and manage the podcast episodes.

Select Menu > Music > Podcasting.

View a list of subscribed podcasts

Select Podcasts.

View individual episode titles

Select the podcast title. An episode is a particular media file of a podcast.

Start a download

Select the episode title. You can download multiple episodes at the same time.

Page 63

Music folder 63

Start playing a podcast before the download is complete

Go to a podcast, and select Options > Play preview.

Successfully downloaded podcasts are stored in the Podcasts folder, but may not be displayed immediately.

Radio Listen to the radio

Select Menu > Music > Radio.

The FM radio depends on an antenna other than the wireless device antenna. A compatible headset or accessory needs to be attached to the device for the FM radio to function properly.

When you open the application for the first time, you can choose to have the local stations tuned automatically.

To listen to the next or the previous station, select

To mute the radio, select

or .

Select Options and from the following:

Stations — View saved radio stations. Tune stations — Search for radio stations. Save — Save the radio station. Activate loudspeaker or Deactivate loudspeaker — Turn the loudspeaker on or off. Alternative frequencies — Select whether you want the radio to automatically search

for a better RDS frequency for the station if the frequency level becomes low. Play in background — Return to the home screen with the radio playing in the

background.

Manage radio stations

Select Menu > Music > Radio.

To listen to saved stations, select Options > Stations, and select a station from the list.

To remove or rename a station, select Options > Stations > Options > Delete or

Rename.

To set the desired frequency manually, select Options > Tune stations > Options >

Manual tuning.

Page 64

64 Music folder

Page 65

Gallery 65

Gallery

To store and organise your images, video clips, sound clips, and streaming links, select

> .

Tip: To access the images and video clips view quickly, tap the media key ( the media bar, and select

View and organize files

Select

Select from the following:

Open a file

Select a file from the list. Videos and files with the .ram file extension open and play in Video center, and music and sound clips in Music player.

View images and videos

Select

By default, the images, videos, and folders are organized by date and time.

To open a file, select a file from the list. To zoom in an image, use the volume key.

> .

Images & videos — View images in the image viewer and videos in Video center.

Songs — Open Music player. Sound clips — Listen to sound clips. Other media — View presentations.

> and Images & videos.

) to open

To print your images on a compatible printer, select Options > Print.

To edit a video clip or an image, select Options > Edit.

Select Options > Use file and from the following:

Set as wallpaper — Use the image as wallpaper in the home screen. Set as call image — Set the image as a generic call image. Assign to contact — Set the image as a call image for a contact. As ringing tone — Set the video as a ringing tone. Assign to contact — Assign the video as a ringing tone for a contact.

Page 66

66 Gallery

The toolbar helps you select frequently used functions with images, video clips, and folders.

From the toolbar, select from the following:

Send — Send an image or a video clip.

Edit — Edit an image or a video clip.

Delete — Delete an image or a video clip.

Organize images and videos

Select

> .

Create a new folder

Select Images & videos > Options > New folder.

Move a file

Select the file and Options > Organize > Move to folder.

TV-out mode

You can view your images and videos on a compatible TV.

Select Menu > Settings.

To view your images and videos on a compatible TV, use a Nokia Video-Out Cable.

Before viewing images and videos on the TV, you may need to define the TV system (PAL or NTSC) and the TV aspect ratio (Widescreen or Normal).

Define the TV system and aspect ratio

Select Phone > Accessories > TV-Out.

In TV-out mode, you cannot use the TV as the camera viewfinder.

View images and play videos on a TV

1 Connect a Nokia Video-Out Cable to the video input of a compatible TV. 2 Connect the other end of the cable to the Nokia AV Connector of your device. 3 You may need to select the USB cable mode. 4 Select

> , and an image or a video.

Page 67

Gallery 67

The images are viewed in the image viewer, and the videos are played in RealPlayer.

All audio, including active calls, stereo video audio, key tones, and ringing tones, are played through the TV. You can use the device microphone normally.

The opened image is displayed in full-screen mode on the TV. When you open an image in the thumbnail view while it is displayed on the TV, zooming in is not available.

When you select a video, it is played on the device display and the TV screen.

You can view images as a slide show on the TV. All items in an album or marked images are displayed on the TV in full-screen mode.

The quality of the TV image may vary, depending on the resolution of the connected device.

Wireless radio signals, such as incoming calls, may cause interference in the TV image.

Page 68

68 Camera

Camera

Your phone has two cameras, a high resolution camera on the back of the device, and a lower resolution camera on the front. You can use both cameras to capture images and record videos.

Your device supports an image capture resolution of 2592x1944 pixels. The image resolution in this guide may appear different.

Activate the camera

To activate the camera, press the capture key.

To activate the secondary camera, activate the main camera, and select Options > Use

secondary camera.

Image capture Still image controls and indicators

The still image viewfinder displays the following:

1 Mode indicator 2 Zoom slider. To activate or deactivate the zoom slider, tap the screen. 3 Capture icon. 4 Flash mode. 5 Capture settings 6 Battery charge level indicator 7 Image resolution indicator 8 Image counter (the estimated number of images you can capture using the current

image quality setting and available memory)

9 Memory in use. Depending on the setup of your device, there are the following

options: device memory (

10 GPS signal indicator

) or mass memory ( ).

Page 69

Camera 69

Capture and recording settings

To open the capture and recording settings view before capturing an image or recording a video clip, select Menu > Applications > Camera and

The capture and recording settings view provides you with shortcuts to different items and settings before capturing an image or recording a video clip.

The capture and recording settings return to the default settings after you close the camera.

Select from the following:

Select the scene.

or Switch between video and image mode.

or Show or hide the viewfinder grid (images only).

Activate the self-timer (images only).

Activate sequence mode (images only).

Open Gallery.

Image settings

Select a color effect.

Adjust the white balance. Select the current lighting conditions. This allows the

camera to reproduce colors more accurately.

Adjust the exposure compensation (images only). If you are shooting a dark subject against a very light background, such as snow, adjust the exposure to +1 or +2 to compensate for the background brightness. For light subjects against a dark background, use -1 or -2.

Adjust light sensitivity (images only). Increase the light sensitivity in low light conditions to avoid too dark images and blurry images. Increasing the light sensitivity may also increase the image noise.

Adjust contrast (images only). Adjust the difference between the lightest and darkest

parts of the image.

Adjust sharpness (images only).

The screen display changes to match the settings you define.

Page 70

70 Camera

The capture settings are shooting-mode specific. Switching between the modes does not reset the defined settings.

If you select a new scene, the capture settings are replaced by the selected scene. You can change the capture settings after selecting a scene, if needed.

Saving the captured image may take longer if you change the zoom, lighting, or color settings.

Capture images

When capturing an image, note the following:

• Use both hands to keep the camera still.

• The quality of a digitally zoomed image is lower than that of a non-zoomed image.

• The camera goes into battery saving mode if there are no actions for about a minute.

To continue capturing images, slide the lock switch on the side of the device.

To capture an image:

1 To switch from video mode to image mode, if necessary, select

> .

2 To lock the focus on an object, press the capture key halfway down (not available

in landscape or sport scene modes). A green locked focus indicator is displayed. If the focus was not locked, a yellow focus indicator is displayed. Release the capture key, and press it halfway down again. You can also capture an image without locking the focus.

3 To capture an image, press the capture key. Do not move the device before the

image is saved and the final image displayed.

To zoom in or out when capturing an image, use the zoom key in your device.

To leave the camera open in the background and use other applications, press the menu key. To return to the camera, press and hold the capture key.

After capturing an image

After you capture an image, select from the following options (available only if you have selected Options > Settings > Show captured image > Yes):

— Send the image in a multimedia or e-mail message, or through connection methods such as Bluetooth connectivity. You can also post your image to compatible online sharing services.

To send the image to the person you are talking to, select

during a call.

Page 71

Camera 71

— Post your image to compatible online sharing services.

— Delete the image.

To use the image as wallpaper in the home screen, select Options > Use image > Set

as wallpaper.

To set the image as a default call image to be used for every call situation, select

Options > Use image > Set as call image.

To assign the image to a contact, Options > Use image > Assign to contact.

To return to the viewfinder to capture a new image, press the capture key.

Flash and video light

The camera of your device has a dual LED flash for low light conditions.

To select the desired flash mode, select the current flash mode indicator, which is one of the following:

Automatic, Reduce red, On, and Off.

Avoid touching the flash LEDs when the back cover has been removed. The LEDs may get hot after prolonged usage.

Keep a safe distance when using the flash. Do not use the flash on people or animals at close range. Do not cover the flash while taking a picture.

Increase light levels when recording video in low light

Select

Scenes

A scene helps you to find the right color and lighting settings for the current environment. The settings of each scene have been set according to a certain style or environment.

The default scene in image mode is Automatic, and in video mode Automatic (both indicated with

To change the scene, select

> Scene modes and a scene.

To make your own scene suitable for a certain environment, scroll to User defined and select Change. In the user defined scene you can adjust different lighting and color settings. To copy the settings of another scene, select Based on scene mode and the

Page 72

72 Camera

desired scene. To save the changes and return to the scenes list, select Back. To activate your own scene, select User defined > Select.

Location information

Your device does not have an internal GPS antenna. To use this feature, use a compatible GPS receiver (accessory sold separately).

You can automatically add capture location information to the file details of the captured material.

Select Menu > Applications > Camera.

Add location information to all captured material

Select Options > Settings > Show GPS info > On. The location information is available only for images captured with the main camera.

It may take several minutes to obtain the coordinates of your location. The availability and quality of GPS signals may be affected by your location, buildings, natural obstacles, and weather conditions. If you share a file that includes location information, the location information is shared and your location may be visible to third parties viewing the file. The device requires network services to acquire location information.

Location information indicators:

— Location information unavailable. GPS stays on in the background for several

minutes. If a satellite connection is made and the indicator changes to

within that time, all the images captured and video clips recorded during that time are tagged based on the received GPS positioning information.

— Location information is available. Location information is added to the file details.

Self-timer

Use the self-timer to delay the capture, so that you can include yourself in the image.

Set the self-timer delay

Select

> and the delay desired before the image is captured.

Activate the self-timer

Select Activate. The stopwatch icon on the screen blinks and the remaining time is displayed when the timer is running. The camera captures the image after the selected delay elapses.

Deactivate the self-timer

Select

> > .

Page 73

Camera 73

Tip: To keep your hand steady when capturing an image, try using a delay of 2

seconds.

Capture images in a sequence

Select Menu > Applications > Camera.

The sequence mode is available only in the main camera.

To start capturing images in a quick sequence, select Menu > Applications >

Camera and

> Sequence. To close the settings window, tap the screen above the

window. Press and hold the capture key. The device captures images until you release the key or until the memory runs out. If you press the capture key briefly, the device captures 18 images in a sequence.

The captured images are displayed in a grid. To view an image, select the image. To return to the sequence mode viewfinder, press the capture key.

You can also use sequence mode with the self-timer.

To deactivate sequence mode, select

> Single shot.

Video recording Record a video

1 To switch from image mode to video mode, if necessary, select 2 To start recording, press the capture key or select

. A red record icon is displayed.

> .

3 To pause recording, select Pause. To resume, select Continue. If you pause

recording and do not press any key within one minute, the recording stops. To zoom in or out, use the zoom keys.

4 To start recording, press the capture key. The video clip is automatically saved in

Gallery.

Video recording on-screen controls and indicators

The video viewfinder displays the following:

Page 74

74 Camera

1 Capture mode indicator 2 Audio mute on indicator 3 Capture icon. Tap to record video. 4 Video light on/off. 5 Recording settings. Tap to change settings. 6 Battery charge level indicator 7 Video quality indicator. To change this setting, select Options > Settings > Video

quality.

8 Video clip file type 9 Available recording time. When you are recording, the current video length

indicator also shows the elapsed and remaining time.

10 The location to which the video clip is saved.

After recording a video clip

After you record a video, select from the following options (available only if you have selected Options > Settings > Show last captured video > Yes):

— Play the video clip you just recorded.

— Post your video to compatible online sharing services.

— Delete the video clip.

To send the video to the person you are talking to, select Options > Send to caller during a call.

To return to the viewfinder to record a new video clip, press the capture key.

Page 75

Positioning (GPS) 75

Positioning (GPS)

You can use applications such as GPS data to find out your location, or measure distances and coordinates. These applications require a GPS connection.

About GPS

The Global Positioning System (GPS) is operated by the government of the United States, which is solely responsible for its accuracy and maintenance. The accuracy of location data can be affected by adjustments to GPS satellites made by the United States government and is subject to change with the United States Department of Defense civil GPS policy and the Federal Radionavigation Plan. Accuracy can also be affected by poor satellite geometry. Availability and quality of GPS signals may be affected by your location, buildings, natural obstacles and weather conditions. GPS signals may not be available inside buildings or underground and may be impaired by materials such as concrete and metal.

GPS should not be used for precise location measurement, and you should never rely solely on location data from the GPS receiver and cellular radio networks for positioning or navigation.

The trip meter has limited accuracy, and rounding errors may occur. Accuracy can also be affected by availability and quality of GPS signals.

The coordinates in the GPS are expressed using the international WGS-84 coordinate system. The availability of the coordinates may vary by region.

For the pricing and availability of these services, contact your service provider.

Assisted GPS (A-GPS)

Your device also supports assisted GPS (A-GPS).

A-GPS is a network service.

Assisted GPS (A-GPS) is used to retrieve assistance data over a packet data connection, which assists in calculating the coordinates of your current location when your device is receiving signals from satellites.

When you activate A-GPS, your device receives useful satellite information from an assistance data server over the cellular network. With the help of assisted data, your device can obtain the GPS position faster.

Your device is preconfigured to use the Nokia A-GPS service, if no service providerspecific A-GPS settings are available. The assistance data is retrieved from the Nokia AGPS service server only when needed.

Page 76

76 Positioning (GPS)

You must have an internet access point defined in the device to retrieve assistance data from the Nokia A-GPS service over a packet data connection. To define an access point for A-GPS, select Menu > Applications > Location and Positioning > Positioning

server > Access point. A wireless LAN (WLAN) access point cannot be used for this

service. Only a packet data internet access point can be used. Your device asks for the internet access point when GPS is used for the first time.

Hold your device correctly

When using the GPS receiver, ensure you do not cover the antenna with your hand.

Establishing a GPS connection may take from a couple of seconds to several minutes. Establishing a GPS connection in a vehicle may take longer.

The GPS receiver draws its power from the device battery. Using the GPS receiver may drain the battery faster.

Tips on creating a GPS connection

Check satellite signal status

Select Menu > Applications > Location and GPS data > Options > Satellite status.

If your device has found satellites, a bar for each satellite is shown in the satellite info view. The longer the bar, the stronger the satellite signal. When your device has received enough data from the satellite signal to calculate your location, the bar color changes.

Initially your device must receive signals from at least four satellites to be able to calculate the coordinates of your location. When the initial calculation has been made,

Page 77

Positioning (GPS) 77

it may be possible to continue calculating the coordinates of your location with three satellites. However, the accuracy is generally better when more satellites are found.

To view the positions of found satellites, select Chg. view.

If no satellite signal can be found, consider the following:

• If you are indoors, go outdoors to receive a better signal.

• If you are outdoors, move to a more open space.

• If the weather conditions are bad, the signal strength may be affected.

• Some vehicles have tinted (athermic) windows, which may block the satellite

signals.

Ensure you do not cover the antenna with your hand.

Establishing a GPS connection may take from a couple of seconds to several minutes. Establishing a GPS connection in a vehicle may take longer.

The GPS receiver draws its power from the device battery. Using GPS may drain the battery faster.

Position requests

You may receive a request from a network service to receive your position information. Service providers may offer information about local topics, such as weather or traffic conditions, based on the location of your device.

When you receive a position request, the service that is making the request is displayed. Select Accept to allow your position information to be sent or Reject to deny the request.

Landmarks

With Landmarks, you can save the position information of locations in your device. You can sort the saved locations into different categories, such as business, and add details to them. You can use your saved landmarks in compatible applications.

Page 78

78 Positioning (GPS)

Select Menu > Applications > Location and Landmarks.

Select Options and from the following: New landmark — Create a new landmark. To request position information of your

current location, select Current position. To enter the position information manually, select Enter manually.

Edit — Edit a saved landmark (for example, add a street address). Add to category — Add a landmark to a category. Select each category to which you

want to add the landmark.

Send — Send one or several landmarks to a compatible device.

Create a new landmark category

On the categories tab, select Options > Edit categories.

GPS data

GPS data is designed to provide route guidance information to a selected destination and traveling information, such as the approximate distance to the destination and approximate duration of travel. You can also view position information about your current location.

Select Menu > Applications > Location and GPS data.

Positioning settings

Positioning settings define the methods, server, and notation settings used in positioning.

Select Menu > Applications > Location and Positioning.

Define positioning methods

Use only the integrated GPS receiver of your device

Select Integrated GPS.

Use Assisted GPS (A-GPS) to receive assistance data from a positioning server

Select Assisted GPS.

Use information from the cellular network (network service)

Select Network based.

Page 79

Positioning (GPS) 79

Define positioning server

Define an access point and positioning server for network-assisted positioning

Select Positioning server. This is used for assisted GPS or network-based positioning. The positioning server may

be preset by your service provider, and you may not be able to edit the settings.

Define notation settings

Select the measurement system to use for speeds and distances

Select Measurement system > Metric or Imperial.

Define in which format the coordinate information is displayed in your device

Select Coordinate format and the desired format.

Page 80

80 Maps

Maps

About Maps

With Maps, you can see your current location on the map, browse maps of different cities and countries, search for places, plan routes from one location to another, save locations, and send them to compatible devices. You can also purchase licenses for traffic information and navigation services, if available for your country or region.

When you use Maps for the first time, you may need to select an Internet access point for downloading maps.

If you browse to an area which is not covered by maps already downloaded in your device, a map for the area is automatically downloaded through the internet. Some maps may be available in your device. You can also use the Nokia Map Loader PC software to download maps. To install Nokia Map Loader to a compatible PC, go to www.nokia.com/maps.

Tip: To avoid data transfer costs, you can also use Maps without an internet connection, and browse the maps that are saved.

Note: Downloading content such as maps, satellite images, voice files, guides or traffic information may involve transmission of large amounts of data (network service).

Almost all digital cartography is inaccurate and incomplete to some extent. Never rely solely on the cartography that you download for use in this device.

Network positioning

You can use the mobile network to find your current location. This is faster but less accurate than with GPS, and you cannot use the location as a starting point for navigation.

Select Menu > Maps.

Use the mobile network for positioning

Select the network-based positioning method from the device settings.

When you start the Maps application and your GPS connection is ready, GPS replaces mobile network as the positioning method.

Move on a map

When the GPS connection is active,

shows your current location on the map.

Page 81

Maps 81

To view your current or last known location, select Options > My position.

To move on the map, drag the map. By default, the map is oriented north.

When you have an active data connection and browse the map on the display, a new map is automatically downloaded if you browse to an area not covered by the maps that have already been downloaded. The maps are automatically saved.

To zoom in and out on the map, select + and -.

To change the map type, select Options > Map mode.

Display indicators

Select Menu > Maps.

The GPS indicator

shows the availability of the satellite signals. One bar is one satellite. When the device tries to find satellite signals, the bar is yellow. When the device receives enough data from the satellites for GPS to calculate your location, the bar turns green. The more green bars, the more reliable the location calculation.

Initially, your device must receive signals from at least four satellites to calculate the coordinates of your location. After the initial calculation, signals from three satellites may be enough.

The data transfer indicator

shows the internet connection used, and the

amount of data transferred since the application started.

Find locations

To search for locations, tap the information area above the map, and select Explore. Start entering the location name in the search field. The device suggests matching nearby locations. Select the location from the list, or enter the location name in the search field, and select Search.

1 To find a specific address, select the search icon and Address. 2 Start entering the required information. The fields marked with an asterisk (*) are

mandatory.

3 Select the address from the list of suggested matches.

To find an address saved in the contacts list, select the search icon and Address >

Options > Select from Contacts.

Page 82

82 Maps

To search for locations by their coordinates, select the search icon and Places.

To search for locations in specific categories, such as restaurants or shopping, tap the information area above the map, and select Explore. Select a category, and enter the search terms in the search field.

Plan routes

You can create routes and view them on the map.

Select Menu > Maps.

Create a route

1 Tap your starting point on the map. To add the destination and more locations to

the route, select Add new route point. If you want to use your current position as

the starting point, add the destination to the route. 2 Tap the information area above the map, and select Add to route. 3 Select Add new route point, and add the destination and more locations to the

route.

Change the order of the locations in the route

Tap a location, and select Move. Tap the place where you want to move the location, and select Select.

Show the route on the map

Select Show route.

Navigate to the destination

Select Show route > Options > Start driving or Start walking. To be able to navigate, you need to purchase a license.

Save the route.

Select Show route > Options > Save route.

Save and send locations

You can save your favourite locations to your device and send them to compatible devices.

Select Menu > Maps.

Save a location to your device

Tap the location, tap the information area above the map, and select Save.

Page 83

Maps 83

View your saved locations.

In the main view, select Options > Favorites.

Send a location to a compatible device

Tap the location, and select Send.

View your saved items

You can sort the locations and routes you have saved to your device, and view them on the map. You can also create collections of your favorite places, such as restaurants and museums.

Select Menu > Maps.

View the saved locations and routes

Select Options > Favorites.

Sort the saved locations

Select Places > Options > Sort.

View the location on the map

Tap the location, and select Show on map.

Add the location to a route

Tap the location, and select Add to route.

Create a collection

Select Options > New collection.

Synchronize your favourite locations with Ovi Maps

The Ovi Web site contains the Internet services that Nokia provides. The Ovi Maps section contains services related to Maps. You can synchronize your saved locations, collections, and routes with Ovi Maps, if you have a Nokia account in Ovi. To create the account, visit www.ovi.com.

Select Menu > Maps.

Synchronize saved items with Ovi Maps

Select Options > Favorites > Synchronize with Ovi.

Page 84

84 Maps

Set the device to synchronize items automatically

Select Options > Tools > Settings > Synchronization > Synchronize with Ovi > At

start-up and shut-d.. The device starts the synchronization when you open and close

the Maps application.

Synchronizing may involve the transmission of large amounts of data through your service provider’s network. Contact your service provider for information about data transmission charges.

Your search history

In the history view, you can quickly return to the locations you have recently searched for.

Select Menu > Maps.

View your search history

Select Options > History.

View the selected location on the map

Tap the location, and select Show on map.

Send the location to a compatible device

Tap the location, and select Send.

Add the location to a route.

Tap the location, and select Add to route.

Walk to your destination

When you purchase a licence for pedestrian navigation, you can create routes that include pedestrian zones and parks, prioritize walkways and smaller roads, and omit motorways.

With the licence, you also get the enhanced search service to your device, if available for your country or region. The enhanced search service enables you to find local events and travelling-related information when you perform searches.

Select Menu > Maps.

Purchase a license for pedestrian navigation

Select Options > Shop & licenses > Options > Shops for other regions > All

regions > City Explorer. You can pay for the license with a credit card or on your phone

bill, if supported by your service provider.

Page 85

Maps 85

Start navigating

Tap a location, tap the information area above the map, and select Walk to.

The distance between the start and end points of a walking route is limited to a maximum of 50 kilometres (31 miles) and the travelling speed to a maximum of 30 kph (18 mph). If the speed limit is exceeded, navigation stops and is resumed once the speed is back within limits.

If the destination is on off-road terrain, the route is displayed as a straight line to indicate the walking direction.

There is no voice guidance available for pedestrian navigation, but the device guides you with a tone or vibration approximately 20 metres (22 yards) before you need to turn or make another manoeuver. The guiding method depends on the settings of the profile currently active in your device.

See an overview of the route

Select Options > Route overview.

Stop navigating.

Select Stop.

Drive to your destination

You can purchase a license for navigating on foot or by car. The license is region-specific and can be used only in the selected area.

To help navigating and driving, you also have lane assistance and speed limit warning services in your device, if available for your country or region.

Select Menu > Maps.

Purchase a license

Select Options > Shop & licenses > Shop > Drive.

Start navigating by car

Select a location, tap the information area above the map, and select Drive to.

When you use car navigation for the first time, you are asked to select the language of the voice guidance and download the related voice guidance files.

Note: Downloading content such as maps, satellite images, voice files, guides or traffic information may involve transmission of large amounts of data (network service).

Page 86

86 Maps

To switch between different views during the navigation, tap the information area above the map, and select 2D view, 3D view, Arrow view, or Route overview.

Find an alternative route.

Select Options > Diff. route.

Repeat voice guidance.

Select Options > Repeat.

Adjust the volume of voice guidance.

Select Options > Volume.

View the trip distance and duration

Select Options > Dashboard.

Stop navigating.

Select Stop.

Your first consideration while using Maps should be road safety. The service should not be used by the driver of a motor vehicle while driving.

Traffic and safety

The real-time traffic information service provides information about traffic events that may affect your travel. You can purchase and download the traffic information service to your device, if available in your country or region.

When you purchase the license, the location of speed cameras is shown on your route during navigation and tracking, if this feature is enabled and available for your country or region. Some jurisdictions prohibit or regulate the use of speed camera location data. Nokia is not responsible for the accuracy, or the consequences of use of speed camera location data.you also get the notification service for speed cameras, if available for your country or region.

Select Menu > Maps.

Note: Downloading content such as maps, satellite images, voice files, guides or traffic information may involve transmission of large amounts of data (network service).

Content such as satellite images, guides, weather and traffic information and related services are generated by third parties independent of Nokia. The content may be inaccurate and incomplete to some extent and is subject to availability. Never rely solely on the aforementioned content and related services.

Page 87

Maps 87

Purchase a license for the traffic information service

Select Options > Shop & licenses > Shop > Traffic & safety.

View information about traffic events

Select Options > Traffic info. The events are shown on the map as triangles and lines.

View the details and possible rerouting options

Select Options > Open.

Update the traffic information

Select Update traffic info.

Set your device to avoid traffic events

In the main view, select Options > Tools > Settings > Navigation > Reroute due to

traffic.

Maps settings

Select Menu > Maps.

Select Options > Tools > Settings and from the following:

Internet — Define the internet settings. Navigation — Define the navigation settings. Route — Define the routing settings. Map — Define the map settings. Synchronization — Define the settings for synchronizing saved items with the Ovi

Maps web service.

Internet settings

Select Menu > Maps.

Select Options > Tools > Settings > Internet and from the following: Go online at start-up — Set the device to open an internet connection when you open

Maps. Default access point or Network destination — Select the access point to be used

when connecting to the internet. Roaming warning — Set the device to notify you when registering to a network other

than your home network.

Navigation settings

Select Menu > Maps.

Page 88

88 Maps

Select Options > Tools > Settings > Navigation and from the following: Voice guidance — Select the language of the voice guidance for navigation. If you

select a language with the text "with street names", also the street names are said aloud. You may need to download the voice files before you can select the language.

Backlight — Define the backlight setting. Automatic zoom — Use automatic zooming. Traffic info update — Update the information about traffic events. Reroute due to traffic — Plan a new route to avoid traffic events. Time indicator — Display the travel time or estimated time of arrival. Speed limit warner — Set the device to notify you when you exceed the speed limit,

if speed limit information is available for your route. Safety spot warner — Set the device to notify you when you approach a speed camera,

if such information is available for your route. Maps improvement — Let Nokia use information from your device to improve the

Maps application. The information is collected periodically while you travel at typical car speeds, and is anonymous and encrypted. The information contains your direction, speed, location, satellite time, and the accuracy of positioning. The information is sent only when you use Maps over a fixed or wireless local area network connection. Once the information is sent, it is deleted from your device.

The available options may vary.

Route settings

You can select the mode of transportation used when you create routes and what characteristics you want the route to prefer.

Select Menu > Maps.

Edit the route settings

Select Options > Tools > Settings > Route.

Select the mode of transportation

Select Transport mode > Walk or Drive. If you select Walk, one-way streets are regarded as normal streets and walkways can be used.

Use the fastest route

Select Route selection > Faster route. This option is available only if you have selected

Drive as the mode of transportation.

Use the shortest route

Select Route selection > Shorter route.

Page 89

Maps 89

To plan routes that combine the advantages of both the shortest and the fastest route, select Route selection > Optimized.

You can also choose to allow or avoid using motorways, tunnels, ferries, and toll roads.

Map settings

Select Menu > Maps.

Select Options > Tools > Settings > Map and from the following: Categories — Select the categories of points of interest you want to display on the

map.

Colors — Optimize the color scheme for day or night usage. Memory to be used — Select where the map files are saved in your device. Maximum memory use — Select how much memory can be used to store maps. When

the memory limit is reached, the oldest maps are removed.

System of measurement — Select the metric or imperial system.

Synchronization settings

Define how you want your device to synchronize with Ovi Maps. If you do not have an account in Ovi, create one at www.ovi.com.

Select Menu > Maps.

Define the synchronization settings.

Select Options > Tools > Settings > Synchronization.

To set the device to synchronize your saved items with your Ovi account automatically when you open and close the Maps application, select Synchronize with Ovi > At start-

up and shut-d..

Synchronize your saved items with Ovi manually

Select Synchronize with Ovi > Manual. To synchronize the items, in the main view, select Options > Favorites > Synchronize with Ovi.

Define your Ovi account details

Select Login information.

Update maps

To update the maps and voice guidance files in your compatible device, download Nokia Maps Updater to your computer from www.nokia.com/maps. Connect your device to the computer, open Nokia Maps Updater, and do the following:

Page 90

90 Maps

1 Select your language from the list. 2 If more than one device is connected to the computer, select your device from the

list. 3 When Nokia Maps Updater has found updates, download them to your device. 4 Accept the download in your device when prompted on the device display.

Page 91

Connectivity 91

Connectivity

Your device offers several options to connect to the internet or to another compatible device or PC.

Data connections and access points

Your device supports packet data connections (network service), such as GPRS in the GSM network. When you use your device in GSM and 3G networks, multiple data connections can be active at the same time, and access points can share a data connection. In 3G networks, data connections remain active during voice calls.

You can also use a Wi-Fi/WLAN data connection. Only one connection in one wireless LAN can be active at a time, but several applications can use the same internet access point.

To establish a data connection, an access point is required. You can define different kinds of access points, such as the following:

• MMS access point to send and receive multimedia messages

• Internet access point (IAP) to send and receive e-mail and connect to the internet

Check the type of access point you need with your service provider for the service you want to access. For availability and subscription to packet data connection services, contact your service provider.

Network settings

Select Menu > Settings and Connectivity > Network.

Your device can automatically switch between GSM and UMTS networks. GSM networks are indicated with

Select from the following:

Network mode — Select which network to use. If you select Dual mode, the device uses the GSM or UMTS network automatically, according to the network parameters and the roaming agreements between the wireless service providers. For details and roaming costs, contact your network service provider. This option is shown only if supported by the wireless service provider.

A roaming agreement is an agreement between two or more service providers to enable the users of one service provider to use the services of other service providers.

Operator selection — Select Automatic to set the device to search for and select one of the available networks, or Manual to manually select the network from a list. If the connection to the manually selected network is lost, the device sounds an error tone

. UMTS networks are indicated with .

Page 92

92 Connectivity

and asks you to reselect a network. The selected network must have a roaming agreement with your home network.

Cell info display — Set the device to indicate when it is used in a cellular network based on microcellular network (MCN) technology and to activate cell info reception.

Wi-Fi/WLAN connection

Your device can detect and connect to wireless local area networks (WLAN). Using a WLAN, you can connect your device to the internet and compatible devices that have WLAN support.

About WLAN

Your device can detect and connect to WLANs. Using a WLAN, you can connect your device to the internet and compatible devices that support WLAN.

To use a WLAN connection, you need the following:

• WLAN must be available in your location.

• Your device must be connected to the WLAN. Some WLANs are protected, and you

need an access key from the service provider to connect to them.

• An internet access point created for WLAN. Use the access point for applications that

need to connect to the internet.

A WLAN connection is established when you create a data connection using a WLAN internet access point. The active WLAN connection ends when you end the data connection.

You can use WLAN during a voice call or when packet data is active. You can only be connected to one WLAN access point device at a time, but several applications can use the same internet access point.

Note: In France, you are only allowed to use Wi-Fi indoors.

Features that use WLAN, or that are allowed to run in the background while using other features, increase the demand on battery power and reduce the battery life.

Your device supports the following WLAN features:

• IEEE 802.11b/g standard

• Operation at 2.4 GHz

• Wired equivalent privacy (WEP), Wi-Fi protected access (WPA/WPA2), and 802.1x

authentication methods. These functions can be used only if they are supported by

the network.

Page 93

Connectivity 93

Important: Always enable one of the available encryption methods to increase the

security of your wireless LAN connection. Using encryption reduces the risk of unauthorized access to your data.

When the device is in the Offline profile, you can still use a WLAN, if available. Remember to comply with any applicable safety requirements when establis hing and using a WLAN connection.

Tip: To check the unique media access control (MAC) address that identifies your device, open the dialler and enter *#62209526#.

Wi-Fi/WLAN wizard

Select Menu > Settings and Connectivity > Wireless LAN.

The Wi-Fi/ WLAN wizard helps you to connect to a wireless LAN (WLAN) and manage your Wi-Fi/ WLAN connections.

If the search finds WLANs, to create an internet access point (IAP) for a connection and start the web browser using this IAP, select the connection and Start web browsing.

If you select a secured WLAN, you are asked to enter the relevant password. To connect to a hidden network, you must enter the correct network name (service set identifier, SSID).

If you already have the web browser running using the currently active Wi-Fi/ WLAN connection, to return to the web browser, select Continue web browsing.

To end the active connection, select the connection and Disconnect WLAN.

WLAN internet access points

Select Menu > Settings and Connectivity > Wireless LAN > Options.

Select from the following:

Filter WLAN networks — Filter out wireless LANs (WLANs) from the list of found networks. The selected networks are not displayed the next time the application searches for WLANs.

Details — View the details of a network shown in the list. If you select an active connection, the connection details are displayed.

Operating modes

There are two operating modes in Wi-Fi WLAN: infrastructure and ad hoc.

Page 94

94 Connectivity

The infrastructure operating mode allows two kinds of communication: wireless devices are connected to each other through a Wi-Fi/WLAN access point device, or wireless devices are connected to a wired LAN through a Wi-Fi/WLAN access point device.

In the ad hoc operating mode, devices can send and receive data directly with each other.

Wireless LAN settings

Select Menu > Settings and Connectivity > Wireless LAN > Options > Settings.

Select from the following:

Show WLAN availability — Select whether

is displayed when a wireless LAN (WLAN)

is available.

Tip: To access the WLAN Wizard application and view the available options, select the WLAN icon, and in the pop-up window, select the highlighted text next to the WLAN icon.

Scan for networks — If you set Show WLAN availability to Yes, you can select how often the device searches for available WLANs and updates the indicator.

Internet connectivity test — Select whether you want the device to test the internet capability of the selected WLAN automatically, to ask for permission every time, or to never perform the connectivity test. If you select Run automatically or allow the test to be performed when the device asks for it, and the connectivity test is performed successfully, the access point is saved to the internet destinations.

To view advanced settings, select Options > Advanced settings. Changing the advanced settings for the WLAN is not recommended.

Access points Create a new access point

Select Menu > Settings and Connectivity > Destinations.

You may receive access point settings in a message from a service provider. Some or all access points may be preset for your device by your service provider, and you may not be able to change, create, edit, or remove them.

1 Select

Access point.

2 The device asks you to check for available connections. After the search, connections

that are already available are shown and can be shared by a new access point. If

you skip this step, you are asked to select a connection method and to define the

settings needed.

Page 95

Connectivity 95

To view access points stored in your device, select an access point group. The different access point groups are the following:

Internet access points Multimedia messaging access points WAP access points Uncategorized access points

The different access point group types are the following:

Protected access point Packet data access point Wireless LAN (Wi-Fi) access point

Manage access point groups

To avoid selecting a single access point every time the device makes a network connection, you can create a group that contains various access points to connect to that network and define the order in which the access points are used. For example, you can add wireless LAN (Wi-Fi) and packet data (GPRS) access points to an internet access point group, and use the group for browsing the web. If you give Wi-Fi the highest priority, the device connects to the internet through Wi-Fi, if available, and through a GPRS connection if not.

Select Menu > Settings and Connectivity > Destinations.

Create a new access point group

Select Options > Manage > New destination.

Add access points to an access point group

Select the group and Options > New access point.

Copy an existing access point from another group

Select the group, go to the access point to copy, and select Options > Organize > Copy

to other dest..

Change the priority of an access point within a group

Select Options > Organize > Change priority.

GPRS access point settings

Select Menu > Settings and Connectivity > Destinations > Access point, and follow the instructions.

Page 96

96 Connectivity

Edit a GPRS access point

Select an access point group and access point marked with

. Follow the instructions

from your service provider.

Select from the following:

Access point name — The access point name is provided by your service provider. User name — The user name may be needed to make a data connection, and is usually

provided by your service provider. Prompt password — If you must enter the password every time you log in to a server,

or if you do not want to save your password in the device, select Yes. Password — A password may be needed to make a data connection and is usually

provided by your service provider. Authentication — To always send your password encrypted, select Secure. To send

your password encrypted when possible, select Normal. Homepage — Depending on the access point you are setting up, enter the web address

or the address of the multimedia message center. Use access point — Set the device to connect to the destination using this access point

after confirmation or automatically.

Modify advanced GPRS access point settings

Select Options > Advanced settings.

Select from the following: Network type — Select the internet protocol type to transfer data to and from your

device. The other settings depend on the selected network type.

Phone IP address (for IPv4 only) — Enter the IP address of your device. DNS addresses — Enter the IP addresses of the primary and secondary DNS servers, if

required by your service provider. To obtain these addresses, contact your internet service provider.

Proxy server address — Enter the address of the proxy server. Proxy port number — Enter the port number of the proxy server.

Wi-Fi access point settings

Select Menu > Settings and Connectivity > Destinations > Access point, and follow the instructions.

Edit a wireless LAN (Wi-Fi) access point

Select an access point group and access point marked with

. Follow the instructions

from your WLAN service provider.

Page 97

Connectivity 97

Select from the following: WLAN network name — Sele ct Enter manually or Search for networks. If you select

an existing network, the Wi-Fi network mode and Wi-Fi security mode are determined by the settings of its access point device.

Network status — Define whether the network name is displayed. WLAN network mode — Select Ad-hoc to create an ad hoc network and to allow

devices to send and receive data directly; a WLAN access point device is not needed. In an ad hoc network, all devices must use the same WLAN network name.

WLAN security mode — Select the encryption used: WEP, 802.1x, orWPA/WPA2 (802.1x and WPA/WPA2 are not available for ad hoc networks). If you select Open

network, no encryption is used. The WEP, 802.1x, and WPA functions can be used only

if the network supports them.

Homepage — Enter the web address of the starting page. Use access point — Set the device to create a connection using this access point

automatically or after confirmation.

The available options may vary.

Security settings for WEP

Define the WEP security settings if you have selected the wired equivalent privacy (WEP) as the WLAN security mode.

1 Select Menu > Settings and Connectivity > Destinations. 2 Select the access point group that has the desired WLAN access point, and select the

access point.

You can also define WEP settings when creating a new WLAN access point. 3 Select WLAN security mode > WEP. 4 Select WLAN security settings, and define the following:

WEP key in use — Select the wired equivalent privacy (WEP) key number. You can

create up to four WEP keys. The same settings must be entered on the WLAN access

point device.

Authentication type — Select Open or Shared for the authentication type

between your device and the WLAN access point device.

WEP key settings — Enter WEP encryption (length of the key), WEP key

format (ASCII or Hexadecimal), and WEP key (the WEP key data in the selected

format).

Security settings for 802.1x and WPA/WPA2

Define the 802.1x or WPA/WPA2 security settings if you have selected either as the WLAN security mode.

Page 98

98 Connectivity

1 Select Menu > Settings and Connectivity > Destinations. 2 Open the access point group that has the desired WLAN access point, and select the

access point. You can also define 802.1x or WPA/WPA2 settings when creating a new WLAN access

point. 3 Select WLAN security mode > WPA/WPA2 or 802.1x. 4 Select WLAN security settings > WPA/WPA2 > EAP to use an extensible

authentication protocol (EAP) plug-in, or Pre-shared key to use a password. The

same password must be entered on the WLAN access point device.

If you selected EAP, define the EAP plug-in settings according to the instructions

from your service provider.

Connections in WPA2 only mode are applicable to WPA2 enabled devices only.

The available options may vary.

Advanced WLAN settings

1 Select Menu > Settings and Connectivity > Destinations. 2 Open the access point group that has the desired WLAN access point, and select the

WLAN access point.

You can also define advanced WLAN settings when creating a new WLAN access

point. 3 Select Options > Advanced settings, and define the following:

IPv4 settings — Enter the IP address of your device, the subnet IP address, the default gateway, and the IP addresses of the primary and secondary DNS servers. For these addresses, contact your internet service provider.

IPv6 settings — Define the type of DNS address. Ad-hoc channel (only for Ad-hoc) — To enter a channel number (1-11) manually, select

User defined.

Proxy server address — Enter the address for the proxy server. Proxy port number — Enter the proxy port number.

The available options may vary.

View your active data connections

Select Menu > Settings and Connectivity > Connection mgr..

In the active data connections view, you can see your data connections:

data calls packet data connections

Page 99

Connectivity 99

WLAN connections

Close a connection

Select Options > Disconnect.

Close all open connections

Select Options > Disconnect all.

View the details of a connection

Select Options > Details.

Synchronization

With the Synchronization application, you can synchronize your notes, messages, browser bookmarks, and contacts with compatible applications on a compatible PC or on the internet.

Select Menu > Settings and Connectivity > Data transfer > Sync.

You may receive synchronization settings in a special message from your service provider.

A synchronization profile contains the necessary settings for synchronization. When you open the application, the default or previously used synchronization profile is displayed.

Create a new synchronization profile

Select Options > New sync profile.

Define the features included in the synchronization profile

Select a synchronization item to include it in the profile or to leave it out.

Manage synchronization profiles

Select Options and the desired option.

Synchronize data

Select Options > Synchronize.

Bluetooth connectivity About Bluetooth connectivity

With Bluetooth connectivity, you can make a wireless connection to other compatible devices, such as mobile phones, computers, headsets, and car kits.

You can use the connection to send items from your device, transfer files from your compatible PC, and print files with a compatible printer.

Page 100

100 Connectivity

Select Menu > Settings and Connectivity > Bluetooth.

Since devices with Bluetooth wireless technology communicate using radio waves, they do not need to be in direct line-of-sight. However, they must be within 10 metres (33 feet) of each other, although the connection may be subject to interference from obstructions such as walls or from other electronic devices.

This device is compliant with Bluetooth Specification 2.0 + EDR supporting the following profiles: generic access, network access, control, hands-free, headset, object push, file transfer, dial-up networking, SIM access, and serial port. To ensure interoperability between other devices supporting Bluetooth technology, use Nokia approved accessories for this model. Check with the manufacturers of other devices to determine their compatibility with this device.

When the device is locked, only connections to authorized devices are possible.

Features using Bluetooth technology increase the demand on battery power and reduce the battery life.

Bluetooth settings

Select Menu > Settings and Connectivity > Bluetooth.

Select from the following:

Bluetooth — Activate Bluetooth connectivity. My phone's visibility — To allow your device to be visible to other Bluetooth devices,

select Shown to all. To set a length of time, after which the visibility is set from shown to hidden, select Set visibility period. To hide your device from other devices, select

Hidden.

My phone's name — Edit the name of your device. The name is shown to other

Bluetooth devices. Remote SIM mode — Allow another device, such as a compatible car kit accessory, to

use the SIM card in your device to connect to the network.

Security tips

Select Menu > Settings and Connectivity > Bluetooth.

When you are not using Bluetooth connectivity, to control who can find your device and connect to it, select Bluetooth > Off or My phone's visibility > Hidden. Deactivating the Bluetooth function does not affect other functions in your device.

Do not pair with or accept connection requests from an unknown device. This helps to protect your device from harmful content. Operating the device in hidden mode is a safer way to avoid malicious software.
