Nokia N73 User Guide

DECLARATION OF CONFORMITY
0434
provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/
The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of-life. This applies to your device but also to any enhancements marked with this symbol. Do not dispose of these products as unsorted municipal
waste. For more information, see product Eco-Declaration or country specific information at www.nokia.com. © 2008 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Pop-Port, Nseries, N73 and Visual Radio are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.
This product includes software licensed from Symbian Software Ltd © 1998-
2008. Symbian and Symbian OS are trademarks of Symbian Ltd.
Java™ and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
US Patent No 5818437 and other pending patents. T9 text input software Copyright ©1997-2008. Tegic Communications, Inc. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with
Hereby, NOKIA CORPORATION declares that this RM-133 product is in compliance with the essential requirements and other relevant
MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
Export controls The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details, and
availability of language options. This device may contain commodities, technology or software subject to export
laws and regulations from the US and other countries. Diversion contrary to law is prohibited. FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support,
related to
functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party applications. BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
Issue 4 EN, 9252070

Contents

For your safety...........................................7
Get connected..........................................10
Your Nokia N73.......................................11
Charge the battery..............................................................11
Settings.................................................................................. 11
Transfer content from another device.......................... 11
Essential indicators.............................................................12
Volume and loudspeaker control....................................13
Multimedia key (Nokia N73 (original edition))........... 14
Headset.................................................................................. 14
Memory card tool ............................................................... 14
File manager.........................................................................15
Download!.............................................................................16
Support .....................................................17
Nokia support and contact information....................... 17
Software updates................................................................17
Help.........................................................................................17
Tutorial................................................................................... 18
Camera......................................................19
Take pictures ........................................................................19
Take pictures in a sequence.............................................24
You in the picture—self-timer.........................................24
Record videos....................................................................... 25
Gallery.......................................................28
View and browse files........................................................28
Albums ...................................................................................30
Edit images ...........................................................................31
Edit video clips..................................................................... 32
Slide show............................................................................. 33
Presentations........................................................................33
Image print ...........................................................................34
Print online ...........................................................................35
Share online..........................................................................36
Media applications ..................................39
Music access key (Nokia N73 Music Edition) ............. 39
Music player.........................................................................39
Flash Player...........................................................................48
Visual Radio..........................................................................49
RealPlayer..............................................................................51
Movie director......................................................................52
Time management .................................. 55
Clock........................................................................................55
Calendar.................................................................................56
Web browsers...........................................87
Services ..................................................................................87
Web.........................................................................................90
Messaging................................................ 58
Write text ..............................................................................59
Write and send messages..................................................60
Inbox—receive messages...................................................62
Mailbox...................................................................................64
View messages on a SIM card .........................................66
Messaging settings .............................................................66
IM—instant messaging.......................................................70
Contacts (Phonebook) ............................ 74
Save and edit names and numbers ................................74
Copy contacts.......................................................................75
Add ringing tones for contacts........................................76
Create contact groups........................................................76
Make calls ............................................... 77
Voice calls..............................................................................77
Video calls..............................................................................79
Video sharing........................................................................80
Answer or decline a call ....................................................83
Log ...........................................................................................85
Connections..............................................93
Bluetooth connectivity......................................................93
Infrared connection............................................................96
Data cable .............................................................................97
PC connections ....................................................................97
Connection manager..........................................................98
Synchronization...................................................................99
Device manager...................................................................99
Office..................................................... 102
Calculator............................................................................102
Converter.............................................................................102
Notes.....................................................................................102
Recorder...............................................................................103
Quickoffice..........................................................................103
Adobe Reader .....................................................................104
Personalize your device........................ 107
Profiles—set tones.............................................................107
3-D tones.............................................................................108
Change the look of your device ....................................109
Active standby mode........................................................110
Tools....................................................... 111
Voice commands ...............................................................111
Application manager........................................................111
Digital Rights Management...........................................114
Settings.................................................. 115
Phone....................................................................................115
Call ........................................................................................116
Connection..........................................................................117
Date and time ....................................................................119
Security................................................................................120
Call divert............................................................................123
Call barring ........................................................................123
Network ...............................................................................123
Enhancement .....................................................................124
Troubleshooting: Q&A ......................... 125
Battery information ............................. 128
Charging and discharging...............................................128
Nokia battery authentication guidelines ...................128
Care and maintenance ......................... 131
Additional safety information............. 132
Index ...................................................... 135

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY Do not switch the device
on when wireless phone use is prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST Obey all local
laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE All wireless devices may be
susceptible to interference, which could affect performance.
SWITCH OFF IN HOSPITALS Follow any
restrictions. Switch the device off near medical equipment.
SWITCH OFF IN AIRCRAFT Follow any
restrictions. Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELING Do not use
the device at a refueling point. Do not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING Follow any
restrictions. Do not use the device where blasting is in progress.
USE SENSIBLY Use only in the positions as
explained in the product documentation. Do not touch the antenna areas unnecessarily.
QUALIFIED SERVICE Only qualified personnel
may install or repair this product.
ENHANCEMENTS AND BATTERIES Use only
approved enhancements and batteries. Do not connect incompatible products.
WATER-RESISTANCE Your device is not
water-resistant. Keep it dry.
BACK-UP COPIES Remember to make back-
up copies or keep a written record of all important information.
CONNECTING TO OTHER DEVICES When
connecting to any other device, read its user
7
guide for detailed safety instructions. Do not connect incompatible products.
EMERGENCY CALLS Ensure the phone
function of the device is switched on and in service. Press the end key as many times as needed to clear the display and return to the standby mode. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.
About your device
The wireless device described in this guide is approved for use on the EGSM 850/900/1800/1900 and UMTS 2100 networks. Contact your service provider for more information about networks.
Your device supports Internet connections and other methods of connectivity. Like computers, your device may be exposed to viruses, malicious messages and applications, and other harmful content. Exercise caution and open messages, accept connectivity requests, download content, and accept installations only from trustworthy sources. To increase the security of your devices, consider installing, using, and regularly updating anti-virus software, firewall, and other related software on your device and any connected computer.
When using the features in this device, obey all laws, and respect local customs, privacy and legitimate rights of others, including copyrights.
Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred or forwarded.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.
The office applications support common features of Microsoft Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and 2003). Not all file formats can be viewed or modified.
Your device may have preinstalled bookmarks and links for third-party internet sites. You may also access other third­party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.
Network services
To use the phone you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all
8
networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as MMS, browsing, e-mail, and content downloading using the browser or over MMS, require network support for these technologies.
For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider or other vendor.
Enhancements, batteries, and chargers
Always switch the device off and disconnect the charger before removing the battery.
Check the model number of any charger before use with this device. This device is intended for use when supplied with power from a DC-4, AC-3, or AC-4 charger and from an AC-1, ACP-7, ACP-8, ACP-9, ACP-12, LCH-9, or LCH-12 charger when used with the CA-44 charger adapter.
The battery intended for use with this device is BP-6M.
Warning: Use only batteries, chargers, and
enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.
9
Get connected
Get connected
10
Use your device on the 2G and 3G networks. See ‘About your device’, p. 8.
Use Bluetooth technology to transfer files and connect to compatible enhancements. See ‘Bluetooth connectivity’, p.
93.
Use infrared to transfer and synchronize data between compatible devices. See ‘Infrared connection’, p. 96.
Use a compatible USB data cable, for instance the Nokia Connectivity Cable CA-53, to connect to compatible devices, such as printers and PCs. See ‘Data cable’, p. 97.
Use a compatible miniSD card to transfer data or back up information. See ‘Memory card tool’, p. 14.

Your Nokia N73

Model number: Nokia N73-1.
Hereinafter referred to as Nokia N73. If a function described in this guide is available only in the original edition of the Nokia N73 or Nokia N73 Music Edition, this is indicated in the section describing that function by referring to the Nokia N73 (original edition) or Nokia N73 Music Edition. Check the sales box of your device to see if your device is the original Nokia N73 or Nokia N73 Music Edition.

Charge the battery

1 Connect a compatible charger to a wall outlet. 2 Connect the power cord to the device. If the battery is
completely discharged, it may take a while before the charging indicator starts scrolling.
3 When the battery is fully charged, disconnect the
charger from the device, then from the wall outlet.

Settings

Your Nokia N73 normally has MMS, GPRS, streaming, and mobile Internet settings automatically configured in the device, based upon your wireless service provider
information. You may have settings from your service providers already installed in your device, or you may receive the settings from the service providers as a special text message.
To change the general settings in your device, such as language, the standby mode, and display settings, see ‘Phone’, p. 115.

Transfer content from another device

You can transfer content, such as contacts, free of charge from a compatible Nokia device to your Nokia N73 using Bluetooth connectivity or infrared. The type of content that can be transferred depends on the phone model. If the other device supports synchronization, you can also synchronize data between the other device and your Nokia N73.
You can insert your SIM card in the other device. When Nokia N73 is switched on without a SIM card, the offline profile is automatically activated.
Your Nokia N73
11
Transfer content
1 To use the application for the first time, press , and
select Tools > Transfer. If you have used the application before and want to start a new transfer, select Transfer data. In the information view, select Continue.
2 Select whether you want to use Bluetooth
Your Nokia N73
connectivity or infrared to transfer the data. Both devices must support the selected connection type.
3 If you select Bluetooth connectivity:
To have Nokia N73 search for devices with Bluetooth connectivity, select Continue. Select your other device from the list. You are asked to enter a code on your Nokia N73. Enter a code (1-16 digits), and select OK. Enter the same code on the other device, and select
OK. The devices are now paired. See ‘Pair devices’,
p. 95. For some phone models, the Data transfer application is sent to th e oth er de vice a s a me ssag e. To inst all Data
transfer on the other device, open the message, and
follow the instructions on the display. If you select infrared, connect the two devices. See ‘Infrared connection’, p. 96.
4 From your Nokia N73, select the content you want to
transfer from the other device.
Content is transferred from the memory of the other device to the corresponding location in your Nokia N73.
Transferring time depends on the amount of data to be transferred. You can cancel transferring and continue later.
If the other device supports synchronization, you can keep the data up-to-date in both devices. To start a synchronization with a compatible Nokia device, select
Phones, scroll to the device, and select Options > Synchronise. Follow the instructions on the display.
To view the log of a previous transfer, select Transfer log.

Essential indicators

The device is being used in a GSM network.
The device is being used in a UMTS network (network
service).
You have one or more unread messages in the Inbox
folder in Messaging.
You have received new e-mail in the remote mailbox.
There are messages waiting to be sent in the Outbox
folder.
You have missed calls.
Shown if Ringing type is set to Silent and Message
alert tone, IM alert tone, and E-mail alert tone are set
to Off.
12
The device keypad is locked.
A clock alarm is active.
The second phone line is being used (network service).
All calls to the device are diverted to another number. If you have two phone lines (network service), the indicator for the first line is and for the second
.
A compatible headset is connected to the device.
The connection to a compatible headset with
Bluetooth connectivity has been lost.
A compatible loopset is connected to the device.
A compatible Text phone is connected to the device.
A data call is active.
A GPRS packet data connection is available.
A GPRS packet data connection is active.
A GPRS packet data connection is on hold
A packet data connection is active in a part of the network that supports EDGE. indicates the connection is on hold and that a connection is available. The icons indicate that EDGE is available in the network, but your device is not necessarily using EDGE in the data transfer.
A UMTS packet data connection is available.
A UMTS packet data connection is active.
A UMTS packet data connection is on hold.
Bluetooth connectivity is on.
Data is being transmitted using Bluetooth
connectivity.
A USB connection is active.
An infrared connection is active. If the indicator is blinking, the device is trying to connect to the other device or the connection has been lost.

Volume and loudspeaker control

To increase or decrease the volume level when you have an active call or are listening to a sound, press the volume key on the side of the device.
The built-in loudspeaker allows you to speak and listen from a short distance without having to hold the device to your ear.
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume may be extremely loud.
To use the loudspeaker during a call, select Options >
Activate loudsp..
Your Nokia N73
13
To turn off the loudspeaker, select Options > Activate
handset.

Multimedia key (Nokia N73 (original edition))

This section describes the multimedia key in your Nokia
Your Nokia N73
N73 (original edition) device.
With the multimedia key, you have a quick access to multimedia content and predefined applications.
To open the shortcut assigned to the multimedia key, press and hold . To open a list of multimedia applications, press . To open the desired application, use the scroll key. To exit the list without selecting an application, press .
To change the shortcuts, press , and . To change the applications that are shown when you press , select
Top, Left, Middle, and Right and the application.
Some shortcuts may be fixed, and you are not able to change them.

Headset

Connect a compatible headset to the Pop-Port connector of your device.
Warning: When
you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.
TM

Memory card tool

Use only compatible miniSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.
Press , and select Tools > Memory. You can use a compatible miniSD card as extra storage space and for backing up the information in the device memory.
To back up information from the device memory to a compatible memory card, select Options > Backup phone
mem.
14
To restore information from the compatible memory card to the device memory, select Options > Restore from
card.
To eject the memory card, press , and select Remove
mem. card.
Important: Do not remove the memory card in the
middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

Set a password

To set a password to protect your memory card, select
Options > Set password. You can use up to 8 characters
in the password.
To change the password, select Options > Change
password.
To remove the password, select Options > Remove
password.

Format a memory card

When a memory card is reformatted, all data on the card is permanently lost.
Some memory cards are supplied preformatted and others require formatting. Consult your retailer to find out if you must format the memory card before you can use it.
To format a memory card, select Options > Format mem.
card. Select Yes to confirm.

File manager

Many features of the device, such as contacts, messages, images, videos, ringing tones, calendar notes, documents, and downloaded applications, use memory to store data. The free memory available depends on how much data is already saved in the device memory.
You can use a compatible memory card as extra storage space. Memory cards are rewritable, so you can delete old information and save new data on a memory card.
To browse files and folders in the device memory or on a memory card (if inserted), press , and select Tools > File
mgr.. The device memory view ( ) opens. Press to
open the memory card view ( ), if available.
To move or copy files to a folder, press and at the same time to mark a file, and select Options > Move to
folder or Copy to folder.
Your Nokia N73
15
To find a file, select Options > Find and the memory from which to search, and enter a search text that matches the file name.

View memory consumption

To view what types of data you have in the device and how much memory the different data types consume,
Your Nokia N73
select Options > Memory details. The amount of available free memory is shown in Free memory.

Memory low—free memory

The device notifies you if the device or the memory card memory is low.
To free device memory, transfer data to a compatible memory card, if you have one. Mark files to be moved, and select Options > Move to folder > Memory card, and a folder.
Tip! You can use Nokia Phone Browser available in
Nokia PC Suite to view the different memories in your device and transfer data.
To remove data to free memory, use File manager, or go to the respective application. For example, you can remove the following:
• Messages from Inbox, Drafts, and Sent folders in
Messaging
• Retrieved e-mail messages from the device memory
• Saved Web pages
• Saved images, videos, or sound files
• Contact information
•Calendar notes
• Downloaded applications. See also ‘Application manager’, p. 111.
• Installation files (.sis) of applications you have installed to a compatible miniSD card; first back up the installation files to a compatible PC using Nokia PC Suite.
• Any other data that you no longer need

Download!

Download! (network service) is a mobile content shop
available on your device. You can browse, download, and install items, such as applications and media files, to your device from the Internet.
The items are categorized under catalogs and folders provided by different service providers. Some items may be chargeable, but you can usually preview them free of charge.
Press , and select Internet > Download!
For details, see the Additional applications leaflet.
16

Support

Nokia support and contact information

Check www.nokia.com/support or your local Nokia Web site for the latest version of this guide, additional information, downloads, and services related to your Nokia product.
On the Web site, you can get information on the use of Nokia products and services. If you need to contact customer service, check the list of local Nokia contact centers at www.nokia.com/customerservice.
For maintenance services, check your nearest Nokia service center at www.nokia.com/repair.

Software updates

Nokia may produce software updates that may offer new features, enhanced functions, or improved performance. You may be able to request these updates through the Nokia Software Updater PC application. To update the device software, you need the Nokia Software Updater application and a compatible PC with Microsoft Windows 2000 or XP operating system, broadband internet access,
and a compatible data cable to connect your device to the PC.
To get more information and to download the Nokia Software Updater application, visit www.nokia.com/softwareupdate or your local Nokia web site.
If software updates over the air are supported by your network, you may also be able to request updates through the device. See ‘Device manager’, ‘Software updates’, p.
99.

Help

Your device has context-sensitive help. When an application is open, select Options > Help to access help for the current view.
When you are reading the instructions, to switch between help and the application that is open in the background, press and hold .
To open help from the main menu, select Tools > Help. Select the desired application to view its help topics.
Support
17

Tutorial

Support
The tutorial gives you information about some of the features of your device. To access the tutorial in the menu, press , and select Applications > Tutorial and the section you want to view.
18

Camera

Your Nokia N73 has two cameras, a high resolution camera on the back of the device (the main camera) and a lower resolution camera on the front (the secondary camera). You can use both cameras to take still pictures and record videos. The secondary camera on the front is used in portrait mode, and the main camera on the back in landscape mode.
The Nokia N73 device supports an image capture resolution of 2048x1536 pixels using the main camera. The image resolution in these materials may appear different.
The images and video clips are automatically saved in the Images & video folder in
Gallery. The cameras produce
.jpeg images. Video clips are recorded in the .mp4 file format, or in the 3GPP file format with the .3gp file extension (Sharing quality). See ‘Video settings’, p. 26.
You can send images and video clips in a multimedia message, as an e-mail attachment, or by using Bluetooth connectivity. You can also upload them to a compatible online album. See ‘Share online’, p. 36.

Take pictures

When taking a picture, note the following:
• Use both hands to keep the camera still.
• The quality of a digitally zoomed picture is lower than that of a nonzoomed picture.
• The camera goes into the battery saving mode if there are no keypresses for a moment. To continue taking pictures, press .
To take a picture, do the following:
1 To activate the main camera, open the slide. If the
camera is in Video mode, select Switch to image
mode from the active toolbar.
2 To lock the focus on an object, press the capture key
halfway down (main camera only). The green locked focus indicator appears on the display. If the focus was not locked, the red focus indicator appears. Release the capture key, and press it halfway down again. You can, however, take the picture without locking the focus.
3 To take a picture, in the main camera, press the
capture key. Do not move the device before the image is saved.
To zoom in or out, use the zoom key on the side of your device.
Camera
19
You can make lighting and color adjustments before taking a picture by using the scroll key to scroll through the active toolbar. See ‘Setup settings—Adjust color and lighting’, p. 23.
Camera
Saving the captured image may take longer if you change the zoom, lighting, or color settings.
To free memory before taking a picture, select Options >
Go to free memory (only available if you have backed up
images or video clips). See ‘Free memory’, p. 30.
To activate the front camera, select Options > Use
secondary camera.
To close the main camera, close the slide.

Still image camera indicators

The still image camera viewfinder displays the following:
• The current capture mode indicator (1).
• The active toolbar (2), which you can scroll through before capturing the image to activate the self-timer or sequence mode, or select the capturing mode, scene, flash mode, white balance, exposure compensation, color tone, and light sensitivity (the active toolbar is not displayed during focus and image capture). See ‘Active toolbar’, p. 21.
•The image resolution indicator (3) indicates whether the quality of the image is Print
3M - Large
(2048x1536 resolution), Print
2M - Medium (1600x1200 resolution), Print/e-mail
0.8M - Small (1024x768 resolution), or Multimedia message 0.3M (640x480 resolution).
• The image counter (4) displays the estimated number of images you can capture using the current image quality setting and memory in use (the counter is not displayed during focus and image capture).
• The device memory ( ) and memory card ( ) indicators (5) show where images are saved.
To display all viewfinder indicators, select Options > Show
icons. To display only the camera status indicators, select Hide icons.
20

Active toolbar

In the camera, you can use active toolbar as a shortcut to select items and adjust different settings before and after taking a picture or recording a video. In the active toolbar, scroll to different items, and select them by pressing the scroll key. The available options vary depending on the capture mode and state you are in. You can also define whether the active toolbar is always visible on the display or activated by a key press.
If you want the active toolbar to be visible on the display before and after taking a picture or recording a video, select Options > Show icons.
If you want the active toolbar to be visible only a while when you need it, select Options > Hide icons. You can activate the active toolbar by pressing the scroll key.
Before taking a picture or recording a video, in the active toolbar, select from the following:
to switch between the video and image modes
to select the scene
to select the flash mode
to activate the self-timer (images only). See ‘You in
the picture—self-timer’, p. 24.
to activate the sequence mode (images only). See
‘Take pictures in a sequence’, p. 24.
to adjust the exposure compensation (images only)
to adjust white balance
to select a color effect
to adjust light sensitivity (images only)
The icons change to reflect the current status of the setting.
The available options may vary depending on the view you are in.
See also active toolbar options in ‘After taking a picture’, p. 21, ‘After recording a video’, p. 26, and ‘Active toolbar’, p. 29 in Gallery.

After taking a picture

After you take the picture, select the following from the active toolbar (available only if Show captured image is set to On in Still image camera settings):
• If you do not want to keep the image, select Delete.
Camera
21
• To send the image using multimedia, e-mail, Bluetooth connectivity, or infrared, or upload it to a compatible online album, press the call key, or select Send. For
Camera
more information, see ‘Messaging’, p. 58, ‘Bluetooth connectivity’, p. 93, and ‘Share online’, p. 36. This option is not available during an active call. You can also send the image to a call recipient during an active call. Select Send to caller (only available during an active call).
• To tag images to the Print Basket for later printing, select Add to Print Basket.
• To print the picture, select Print. See ‘Image print’, p. 34.
• To capture a new image, select New image.
To rename the image, select Options > Rename image.
To use the picture as wallpaper in the active standby, select Options > Set as wallpaper.

Still image camera settings

There are two kinds of settings for the still image camera:
Image setup and main settings. To adjust Image setup,
see ‘Setup settings—Adjust color and lighting’, p. 23. The setup settings return to the default settings after you close the camera, but the main settings remain the same until you change them again. To change the main settings, select Options > Settings and from the following:
Image qualityPrint 3M - Large-Large (2048x1536
resolution), Print 2M - Medium (1600x1200 resolution),
Print/e-mail 0.8M - Small (1024x768 resolution), or Multimedia message 0.3M (640x480 resolution). The
better the image quality, the more memory the image consumes. If you want to print the image, select Print 3M
- Large, Print 2M - Medium, or Print/e-mail 0.8M ­Small. If you want to send it through e-mail, select Print/ e-mail 0.8M - Small. To send the image through MMS,
select Multimedia message 0.3M.
These resolutions are only available in the main camera.
Add to album—Select whether you want to save the image
to a certain album in the gallery. If you select Yes, a list of available albums opens.
Show captured image—Select On if you want to see the
captured image after it is taken, or Off if you want to continue taking pictures immediately.
Default image name—Define the default name for the
captured images.
Extended digital zoom (main camera only)—Select On to
allow the zoom increments to be smooth and continuous between digital and extended digital zoom. If you want to limit the zoom to where the selected image quality is maintained, select Off.
Capture tone—Select the tone you want to hear when you
take a picture.
22
Memory in use—Select where to store your images.
Restore camera settings—Select OK to return the default
values to the camera settings.

Flash

The flash is available only in the main camera.
Keep a safe distance when using the flash. Do not use the flash on people or animals at close range. Do not cover the flash while taking a picture.
The camera has an LED flash for low light conditions. The following flash modes are available for the still image camera: Automatic (), Red eye reduct. (), On (), and Off ().
To change the flash mode, in the active toolbar, select the desired flash mode.

Setup settings—Adjust color and lighting

To enable the camera to reproduce colors and lighting more accurately, or to add effects to your pictures or videos, use the scroll key to scroll through the active toolbar, and select from the following options:
White balance—Select the current lighting condition
from the list. This allows the camera to reproduce colors more accurately.
Exposure compensation (images only)—Adjust the
exposure time of the camera.
Colour tone—Select a color effect from the list.
Light sensitivity (images only)—Select the light sensitivity
of the camera. The darker the environment, the higher the light sensitivity should be.
The screen display changes to match any settings you make, so that you see how the change affects the pictures or videos.
The available settings vary depending on the selected camera.
The setup settings affect both the cameras; if you change the settings in the secondary camera, the settings in the main camera change too. The setup settings return to the default settings when you close the camera.
If you select a new scene, the color and lighting settings are replaced by the selected scene. See ‘Scenes’, p. 24. You can change the setup settings after selecting a scene if needed.
Camera
23

Scenes

A scene helps you to find the right color and lighting settings for the current environment. Select a proper
Camera
scene for taking pictures or recording video clips from the scene list. The settings of each scene have been set according to a certain style or environment.
Scenes are only available in the main camera.
Use the scroll key to scroll through the active toolbar, and select from the following options:
Video scenes
Automatic ( )(default) and Night ().
Image scenes
Auto () (default), User defined (), Close-up mode(), Portrait (), Landscape (), Sports (), Night (), and Night portrait ().
When you take pictures, the default scene is Auto. You can select the User defined scene as the default scene.
To make your own scene suitable for a certain environment, scroll to User defined, and select Options >
Change. In the user defined scene you can adjust different
lighting and color settings. To copy the settings of another scene, select Based on scene mode and the desired scene.

Take pictures in a sequence

The sequence mode is available only in the main camera.
To set the camera to take six pictures or more in a sequence (if enough memory is available), in the active toolbar, select Switch to sequence mode.
To take six pictures, press the capture key. To take more than six pictures, press and hold the capture key. To stop taking pictures, release the capture key. You can capture up to 100 images, depending on the available memory.
After you take the pictures, they are shown in a grid on the display. To view a picture, press to open it.
You can also use the sequence mode with the self-timer. When using the self-timer, the maximum number of pictures is six.
To return to the sequence mode viewfinder, press the capture key.

You in the picture—self-timer

The self-timer is available only in the main camera.
Use the self-timer to delay the capture so that you can include yourself in the picture. To set the self-timer delay, in the active toolbar, select Self timer > 2 seconds, 10
seconds, or 20 seconds. To activate the self-timer, select
24
Activate. The device beeps when the timer is running. The
camera takes the picture after the selected delay elapses.
To switch off Self timer, in the active toolbar, select Self
timer > Off.
You can also use the self-timer in the sequence mode.
Tip! In the active toolbar, select Self timer > 2
seconds to keep your hand steady when taking a
picture.

Record videos

1 To activate the main camera, open the slide. If the
camera is in the Image mode, select Switch to video
mode from the active toolbar.
2 Press the capture key to start recording. In the portrait
mode, use the scroll key for recording. The red record icon is shown and a tone sounds, indicating that recording has started.
3 Select Stop to stop recording. The video clip is
automatically saved to the Images & video folder of
Gallery. See ‘Gallery’, p. 28. The maximum length of the
video is 60 minutes (if enough memory is available).
To pause recording at any time, press Pause. The pause icon ( ) blinks on the display. Video recording automatically stops if recording is set to pause and there
are no keypresses within a minute. Press the capture key again to resume recording.
To zoom in or out of the subject, press the zoom key on the side of the device.
To make lighting and color adjustments before recording a video, use the scroll key to scroll through the active toolbar. See ‘Setup settings—Adjust color and lighting’, p. 23 and ‘Scenes’, p. 24.
To free memory before recording a video, select Options >
Go to free memory (only available if you have backed up
images or video clips). See ‘Free memory’, p. 30.
To activate the front camera, select Options > Use
secondary camera.

Video capture indicators

The video viewfinder displays the following:
• The current capture mode indicator (1).
• The video stabilization indicator (2)
• The audio mute on indicator (3).
• The active toolbar (4), which you can scroll through before recording to select the scene, white balance, and color tone (the toolbar is not displayed during recording).
Camera
25
• The total available video recording time (5). When you are recording, the current video length indicator also shows the elapsed time and time remaining.
•The device
Camera
memory ( ) and memory card ( ) indicators (6) show where videos are saved.
• The video quality indicator (7) indicates whether the quality of the video is High, Normal, or
Sharing.
• The video clip file type (8).
To display all viewfinder indicators, select Options >
Show icons. Select Hide icons to display only the video
status indicators, and during the recording, the available record time, zoom bar when zooming, and the selection keys.
To activate the front camera, select Options > Use
secondary camera.

After recording a video

After you record a video clip, select the following from the active toolbar (available only if Show captured video is set to On in Video settings):
• To immediately play the video clip you just recorded,
select Play.
• If you do not want to keep the video, select Delete.
• To send the video clip in a multimedia message, or using e-mail, Bluetooth connectivity, or infrared, or upload it to a compatible online album, press the call key, or select Send. For more information, see ‘Messaging’, p. 58, ‘Bluetooth connectivity’, p. 93, and ‘Share online’, p. 36. This option is not available during an active call. You cannot send video clips saved in the .mp4 file format in a multimedia message. You can also send the video clip to a call recipient during an active call. Select Send to caller.
• To record a new video clip, select New video.
To rename the video, select Options > Rename video.

Video settings

There are two kinds of settings for the video recorder:
Video setup and main settings. To adjust Video setup
settings, see ‘Setup settings—Adjust color and lighting’, p. 23. The setup settings return to the default settings after you close the camera, but the main settings remain the
26
same until you change them again. To change the main settings, select Options > Settings and from the following:
Video quality—Set the quality of the video clip to High
(best quality for long term usage and playback on a compatible TV or PC and mobile device), Normal (standard quality for playback through your mobile device), or
Sharing (limited video clip size to send in a multimedia
message). If you want to view the video on a compatible TV or PC, select High, which has CIF resolution (352x288) and the .mp4 file format. To send the video clip through MMS, select Sharing (QCIF resolution, .3gp file format). The size of the video clip recorded with Sharing is limited to 300 KB (about 20 seconds in duration) so that it can be conveniently sent as a multimedia message to a compatible device.
Video stabilisation—Select On to reduce camera shake
when recording the video.
Audio recording—Select On if you want to record both
image and sound.
Add to album—Select whether you want to add the
recorded video clip to a certain album in Gallery. Select
Yes to open a list of available albums.
Show captured video—Select whether you want the first
frame of the recorded video clip to be shown on the display after the recording stops. Select Play from the active
toolbar (main camera) or Options > Play (secondary camera) to view the video clip.
Default video name—Define the default name for the
captured video clips.
Memory in use—Define the default memory store: device
memory or memory card (if inserted).
Restore camera settings—Select OK to return the default
values to the camera settings.
Camera
27

Gallery

28
Gallery
To store and organize your images, video clips, sound clips, playlists, and streaming links, press , and select
Gallery.
Tip! If you are in another application, to view the last
stored picture in Gallery, press the review key
on the side of your device. To enter the
Images & video folder main view, press the review key
again.

View and browse files

Select Images & video
, Tracks , Sound
clips , Streaming links
, Presentations ,
or All files , and press
to open it.
You can browse and open folders; and mark, copy, and move items to folders. You can also create albums; and mark, copy, and add items to
albums. See ‘Albums’, p. 30.
Files stored on your compatible memory card (if inserted) are indicated with .
To open a file, press . Video clips, .ram files, and streaming links are opened and played in RealPlayer, and music and sound clips in Music player. See ‘RealPlayer’, p. 51, and ‘Music player’, p. 39.
To copy or move files to the memory card (if inserted) or to device memory, select a file and Options > Move and
copy > Copy to memory card or Move to memory card,
or Copy to phone mem. or Move to phone mem..
To download tracks or sound clips into Gallery using the browser, in the Tracks or Sound clips folders, select Track
downl., or Sound downl.. To download images or videos, in
the Images & video folder, select the download icon. The browser opens, and you can select a bookmark from which the site can download.

Images and video clips

Pictures taken and video clips recorded with the camera are stored in the Images & video folder in Gallery. Images and video clips can also be sent to you in a multimedia
message, as an e-mail attachment, through Bluetooth connectivity, or by using infrared. To be able to view a received image or video clip in Gallery or in RealPlayer, you must save it in the device memory or on a compatible memory card (if inserted).
Open the Images & video folder in Gallery. The images and video clip files are in a loop, and ordered by date. The number of files is displayed. To browse the files one by one, scroll left or right. To browse files in groups, scroll up or down.
When the image is opened, to zoom in on an image, press the zoom key on the side of your device. The zooming ratio is shown on the lower left part of the display. The zooming ratio is not stored permanently.
To rotate the selected image left or right, select Options >
Rotate.
To edit a video clip or a photo, select Options> Edit. An image editor or a video editor opens. See ‘Edit video clips’, p. 32. See ‘Edit images’, p. 31.
To create custom video clips, select a video clip or several clips in the gallery, and select Options > Edit. See ‘Edit video clips’, p. 32.
To print your images on a compatible printer, or to store them on your memory card (if inserted) for printing, select
Options> Print. See ‘Image print’, p. 34. You can also tag
images for later printing to the Print Basket in Gallery. See ‘Print Basket’, p. 30.
To add an image or a video clip to an album in the gallery, select Options > Albums > Add to album. See ‘Albums’, p. 30.
To use the picture as a background image, select the picture and Options > Use image > Set as wallpaper.
To delete an image or video clip, press .

Active toolbar

In the Images & video folder, you can use active toolbar as a shortcut to select different tasks. The active toolbar is available only when you have selected an image or a video clip.
In the active toolbar, scroll up or down to different items, and select them by pressing the scroll key. The available options vary depending on the state you are in and on whether you have selected an image or a video clip. You can also define whether the active toolbar is always visible on the display or activated by a key press.
If you want the active toolbar to be visible on the display, select Options > Show icons.
If you want the active toolbar to be visible only a while when you need it, select Options > Hide icons. To activate the active toolbar, press the scroll key.
Gallery
29
Select from the following:
to play the selected video clip
Gallery
to send the selected image or video clip
/ to add or remove an image from the Print Basket.
See ‘Print Basket’, p. 30.
to view the images in the Print Basket
to start a slide show of the images in the selected
album
to delete the selected image or video clip
to print the viewed image
The available options may vary depending on the view you are in.

Free memory

To reduce the resolution and file size of images saved in
Gallery and free memory for new pictures, select Options > Shrink. To back up the images first, copy them
to a compatible PC or other location. Selecting Shrink reduces the resolution of an image to 640x480.
To increase free memory space after you have copied items to other locations or devices, select Options > Free
memory. You can browse a list of files you have copied. To
remove a copied file from Gallery, select Options>
Delete.

Print Basket

You can tag images to the Print Basket, and print them later with a compatible printer or in a compatible printing kiosk, if available. See ‘Image print’, p. 34. The tagged images are indicated with in the Images & video folder and albums.
To tag an image for later printing, select an image, and
Add to Print Basket from the active toolbar.
To view the images in the Print Basket, select View Print
Basket from the active toolbar, or select the Print Basket
icon from the Images & video folder (available only when you have added pictures to the Print Basket).
To remove an image from the Print Basket, select an image in the Images & video folder or in an album, and Remove
from print from the active toolbar.

Albums

With albums you can conveniently manage your images and video clips. To view the albums list, in the Images &
video folder, select Options > Albums > View albums.
To add a picture or a video clip to an album in the gallery, scroll to a picture or video clip, and select Options >
Albums > Add to album. A list of albums opens. Select the
30
Loading...
+ 110 hidden pages
