Additional applications Aplicaciones adicionales

Nokia N70-5

Nokia N70 Additional Applications

9248033

ISSUE 1 EN

ABOUT ADD-ON APPLICATIONS FOR YOUR NOKIA N70 In the sales package you will find a Reduced-Size Dual Voltage MultiMediaCard

(RS-MMC) that contains additional applications from Nokia and third-party developers. The content of the RS-MMC and the availability of applications and services may vary by country, retailer and/or network operator. The applications and further information about the use of the applications at

www.nokiausa.com/support are available in selected languages only.

Some operations and features are SIM card and/or network dependent, MMS dependent, or dependent on the compatibility of devices and the content formats supported. Some services are subject to a separate charge.

NO WARRANTY The third party applications provided on the Reduc ed-Size MultiMediaCard have bee n

created and are owned by persons or entities that are not affiliated with or related to Nokia. Nokia does not own the copyrights and/or intellectual property rights to these third party applications. As such, Nokia does not take responsibility for any end user support or the functionality of these third party applications, nor the information presented in the applications or these materials. Nokia does not provide any warranty for these applications.

YOU ACKNOWLEDGE THE SOFTWARE AND/OR APPLICATIONS (COLLECTIVELY, THE "SOFTWARE") ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND EXPRESS OR IMPLIED AND TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR THAT THE SOFTWARE WILL NOT INFRINGE ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADEMARKS OR OTHER RIGHTS. THERE IS NO WARRANTY BY NOKIA OR BY ITS AFFILIATES THAT ANY ASPECT OF THE SOFTWARE WILL MEET YOUR REQUIREMENTS OR THAT THE OPERATION OF THE SOFTWARE WILL BE UNINTERRUPTED OR ERRORFREE. YOU ASSUME ALL RESPONSIBILITY AND RISK FOR THE SELECTION OF THE SOFTWARE TO ACHIEVE YOUR INTENDED RESULTS AND FOR THE INSTALLATION, USE AND RESULTS OBTAINED FROM IT. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL NOKIA, ITS EMPLOYEES OR AFFILIATES BE LIABLE FOR ANY LOST PROFITS, REVENUE, SALES, DATA, IN FORMATION OR COSTS OF PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, PROPERTY DAMAGE, PERSONAL INJURY, INTERRUPTION OF BUSINESS, OR FOR ANY DIRECT, INDIRECT, INCIDENTAL, ECONOMIC, COVER, P UNITIVE, SPECIAL OR CONSEQUENTIAL DAM AGES,

HOWEVER CAUSED AND WHETHER ARISING UNDER CONTRACT, TORT, NEGLIGENCE, OR OTHER THEORY OF LIABILITY ARISING OUT OF THE INSTALLATION OR USE OF OR INABILITY TO USE THE SOFTWARE, EVEN IF NOKIA OR ITS AFFILIATES ARE ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME COUNTRIES/STATES/ JURISDICTIONS DO NOT ALLOW THE ABOVE EXCLUSION OR LIMITATION OF LIABILITY, BUT MAY ALLOW LIABILITY TO BE LIMITED, IN SUCH CASES, NOKIA, ITS EMPLOYEES' OR AFFILIAT ES' LIABILITY SHALL BE LIMITED TO 50 DOLLARS. NOTHING CONTAINED IN THIS DISCLAIMER SHALL PREJUDICE THE STATUTORY RIGHTS OF ANY PARTY DEALING AS A CONSUMER.

Other product and company names mentioned herein may be trademarks or trade names of their respective owners.

Changes and improvements to the products described in this document are possible without prior notice. Availability may vary by country and region.

NOKIA CORPORATION NOKIA MULTIMEDIA MARKETING WWW.NOKIA.COM

ISSUE 1 EN, 9248033

Introduction............................................... 4

Network services ....................................................................4

Support .....................................................................................4

Imaging ...................................................... 5

KODAK Mobile Service..........................................................5

Office ......................................................... 7

Symantec Mobile Security ..................................................7

Quickword................................................................................7

Quicksheet ...............................................................................9

Quickpoint............................................................................. 10

Adobe Reader....................................................................... 11

Info Print ............................................................................... 13

Connectivity............................................. 14

Wireless Keyboard .............................................................. 14

My own .................................................... 15

Catalogs..................................................................................15

Opera browser ......................................................................16

Tools ......................................................... 18

SettingWizard.......................................................................18

Mobile search.......................................... 19

Mobile Search.......................................................................19

Yahoo! Go ................................................ 20

Yahoo! Go ..............................................................................20

For your PC.............................................. 22

Lifeblog...................................................................................22

PC Suite..................................................................................25

Adobe Photoshop Album Starter Edition ......................27

Introduction

Model number: Nokia N70-5

Hereinafter referred to as Nokia N70.

Introduction

Your Nokia N70 is a powerful, intelligent multimedia device. There are various applications provided by Nokia and different third-party software developers to help you do more with your Nokia N70.

Some of the applications provided are on the Reduced-Size MultiMediaCard (memory card), and some are on the CD-ROM supplied with the device.

Availability of the applications may vary according to your country or sales area.

To use some applications, you must accept the applicable licence terms.

Throughout this document, icons indicate if the application is available on the memory card ( ) or CD-ROM ( ).

Note: If you rem ove the memory card, the applications installed on the memory card cannot be used. Reinsert the memory card to access the applications.

Note: You must install the applications on the CD-ROM to a compatible PC before using them.

Network services

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize network services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Support

Applications provided by third-party software developers are supported by these developers. If you experience problems with an application, obtain support from the relevant Web site. See the Web links at the end of each application in this guide.

Imaging

KODAK Mobile Service

KODAK Mobile allows you to save images and videos at

www.kodakmobile.com

delivery or share images using the browser in your device.

Note: This application is only available in a limited number of languages.

Press , and select Imaging > KODAK Mobile.

To use the KODAK Mobile Service, you must have an access point that allows you to connect to the Internet configured in your device. For more information on access points, see the user guide of your device.

Save images and videos

Scroll through the list, and press to mark the currently selected image or video. To unmark an item, press on a marked item.

When all the images and videos you want to save are marked, select Options > Save. The items are uploaded to the KODAK Mobile Service; see "Create a KODAK Mobile Service account‚" p 5.

, and order prints for home

Files saved in the KODAK Mobile Service are automatically placed in an album that you can view at

www.kodakmobile.com

your device or on a compatible PC.

Images and videos that are successfully saved are marked with the Kodak “K” in the list.

using the Web browser in

Create a KODAK Mobile Service account

To make a connection to the KODAK Mobile Service, you are asked to select an access point to connect to the Internet. To change the access point later, select Options > Settings.

When you have connected to the Internet, you are asked to sign-in to the service using an existing KODAK Mobile Service, Kodak EasyShare Gallery, or Ofoto.com account. If you do not have an account, you may register for a new one.

1 Enter your phone number (including your international

country code) and a password. If you are signing in to an existing account, you are also asked to enter your e-mail address.

2 Select your mobile network operator from the list.

Your images and videos are saved to the KODAK Mobile Service. On subsequent connections you are automatically connected to your account.

Imaging

Order prints

Mark the images you want to print. When all images you want are marked, select Options > Order prints.

Imaging

The items are saved to the KODAK Mobile Service at

www.kodakmobile.com

print order, connect to the KODAK Mobile Service using the browser in your device. For security reasons, you may be asked to enter the phone number (including your international country code) and password you provided when you created your account.

Prints ordered through the KODAK Mobile Service are printed on Kodak paper and delivered to your home.

. To complete the details of your

Mark the images you want to share with your friends and family, and select Options > Share. Enter e-mail addresses or select e-mail addresses saved in contacts. The photos are saved to the KODAK Mobile Service, and an e-mail invitation to view the items in the service is sent to the e-mail addresses you entered.

Troubleshooting

Remember to provide your international country code when signing in to the KODAK Mobile Service.

If you fail to save your images or videos, check your account information on the KODAK Mobile Service Web site at www.kodakmobile.com Ensure your mobile phone number, e-mail, and password are correct. Save again, and attempt to correct any errors you may have found.

If you still are not able to connect to the KODAK Mobile Service, confirm with your operator that your mobile device data services work properly. You must have a data subscription that allows you to access the Internet.

using your PC Web browser.

More information

You can change how and where items are automatically saved on the KODAK Mobile Service Web site. To make a change, visit www.kodakmobile.com browser, and select the Mobile Upload Albums section of My Account.

You can find more information on the KODAK Mobile Service online Web site. Visit www.kodakmobile.com using your compatible PC or device.

If you experience problems with the KODAK Mobile Service, visit www.nokia.kodakmobile.com/PSHelp.jsp

Support is also available by sending an e-mail to

support@kodakmobile.com

using your PC Web

Office

Symantec Mobile Security

Symantec Mobile Security is a security solution for mobile devices that combines antivirus and firewall protection and is designed to protect your device against harmful content and malicious attacks

Note: This application is only available in a limited number of languages.

To install the application, press , and select Office and the Symantec Mobile Security installation file. Follow the instructions on the screen to complete the installation. The application is installed in the Office folder.

The application is a trial version. The trial period begins when you install Symantec Mobile Security. To continue using the application after the trial period, use the

LiveUpdate service to buy a product update, and follow

the instructions on the screen.

The application runs in the background while you use your device, and automatically scans files for viruses when they are received. To manually scan your device, select Options >

Scan. If an infected file is found, a note is displayed, and

you can select what to do with the file.

The firewall tracks connections from and to the device and logs unauthorized connections. To view the log, select

Options > Activity log.

Update your device with the latest virus definition files and product updates by selecting Options > LiveUpdate. To update manually, select the desired items and Options >

Search. To schedule automatic updates and reminders,

select Options > Settings. To use the update service, you need an Internet access

point configured in your device. For more information on access points, see the user guide of your device.

More information

To open the help of the application, select Options > Help.

For more information, visit www.symantec.com/techsupp

Quickword

Quickword for your Nokia N70 supports the most common

features of Microsoft Word 97, 2000, and XP, and Palm eBooks in .doc format. With Quickword you can read native Microsoft Word documents on the display of your device.

Office

Quickword supports colours, bold, italics, underline, and

full screen view mode.

Office

Quickword supports documents saved in .doc format in

Microsoft Word 97, 2000, and XP, and Palm eBooks in .doc format.

Note: Not all variations or features of the mentioned file formats are supported.

Quickword has the following features:

• Interoperability with compatible PCs and other Palm devices

• Storage of documents on the memory card for instant access

Access and open documents in the following ways:

• Press , and select Office > Quickword. Select

Options > Browse to browse and open documents

stored in the device memory and on the memory card.

• Open an e-mail attachment from received e-mail messages (network service).

• Send a document using Bluetooth connectivity to your

Inbox in Messaging.

•Use File mgr. to browse and open documents stored in the device memory and on the memory card.

• Browse Web pages. Ensure your device is set up with an Internet access point before browsing.

Manage Word files

Press , and select Office > Quickword. To open a document file, scroll to it, and press .

You can also select Options and one of the following:

Files > Sort—To sort the currently displayed files by their

name, size, date, or file extension.

Files > Search—To search for files in Mailbox only, or in all

folders in the device memory and on the memory card.

Details—To see the size of the current file, and when it was

last modified.

View Word documents

To open a Word document for viewing, press , and select

Office > Quickword. Select the document, and press .

Use the scroll key to move around in the document.

To search the document for text, select Options >

Find > Options.

You can also select Options and one of the following:

Go to—To move to the start, selected position within, or

end of the document.

Zoom—To zoom in or out.

Autoscroll—To start automatic scrolling through the

document, press to stop scrolling.

Press to slow down, or to speed up the automatic scrolling.

More information

If you experience problems with Quickword, visit

www.quickoffice.com

Support is also available by sending an e-mail to

supportS60@quickoffice.com

for more information.

Quicksheet

Quicksheet for your Nokia N70 supports the most common

features of Microsoft Excel 97, 2000, 2003, and XP. With

Quicksheet you can receive Excel files and read them on

the display of your device.

Quicksheet supports spreadsheet files saved in .xls format

in Microsoft Excel 97, 2000, 2003, and XP.

Note: Not all variations or features of the mentioned file formats are supported.

Quicksheet has the following features:

• Switch between worksheets with just 2 clicks.

• Search the spreadsheet for a text within a value or formula.

• Resize columns, and freeze rows and columns.

• Store spreadsheets on the memory card for instant access.

Access and open files in the following ways:

• Press , and select Office > Quicksheet. Select

Options > Browse to browse and open documents

stored in the device memory and on the memory card.

• Open an e-mail attachment from received e-mail messages (network service).

• Send a document using Bluetooth connectivity to your

Inbox in Messaging.

•Use File mgr. to browse and open documents stored in the device memory and on the memory card.

• Browse Web pages. Ensure your device is set up with an Internet access point before browsing.

Manage spreadsheets

Press , and select Office > Quicksheet. To open a spreadsheet file, scroll to it, and press .

You can also select Options and one of the following:

Files > Sort—To sort the currently displayed files by their

name, size, date, or file extension.

Files > Search—To search for files in Mailbox only, or in all

folders in the device memory and on the memory card.

Details—To see the size of the current file, and when it was

last modified.

Office

View spreadsheets

To open a spreadsheet for viewing, press , and select

Office

Office > Quicksheet. Select the spreadsheet file, and

press . Use the scroll key to move around in the spreadsheet. To switch between worksheets, select Options > Go to,

scroll to the worksheet, and select OK. To search the spreadsheet for a text within a value or

formula, select Options > Find > Options. To change how the spreadsheet is displayed, select Options

and any of the following:

Change screen size—To toggle between full screen and

partial screen mode.

Zoom level—To zoom in or out. Freeze—To keep the highlighted row, column, or both

visible while you move in the spreadsheet.

Adjust column width—Press or to make a column

narrower or wider. When the column is the desired width, press .

More information

If you experience problems with Quicksheet, visit

www.quickoffice.com for more information.

Support is also available by sending an e-mail to

supportS60@quickoffice.com

Quickpoint

Quickpoint for your Nokia N70 supports the most common

features of Microsoft PowerPoint 97, 2000, and XP. With

Quickpoint you can receive PowerPoint presentations and

read them on the display of your device.

Quickpoint supports presentations created in .ppt format

in Microsoft PowerPoint 97, 2000, and XP.

Note: Not all variations or features of the mentioned file formats are supported.

Quickpoint has the following features:

• Advanced viewing with four views: outline, speaker notes, slide, and thumbnails (four-up).

• Storage of presentations on the memory card for instant access

Access and open files in the following ways:

• Press , and select Office > Quickpoint. Select

Options > Browse to browse and open documents

stored in the device memory and on the memory card.

• Open an e-mail attachment from received e-mail messages (network service).

• Send a document using Bluetooth connectivity to your

Inbox in Messaging.

•Use the File mgr. to browse and open documents stored in the device memory and on the memory card.

• Browse Web pages. Ensure your device is set up with an Internet access point before browsing.

Manage presentations

Press , and select Office > Quickpoint.

You can also select Options and one of the following:

Files > Sort—To sort the currently displayed files by their

name, size, date, or file extension.

Files > Search—To search for files in Mailbox only, or in all

folders in the device memory and on the memory card.

Details—To see the size of the current file, and when it was

last modified.

To expand or collapse items in the presentation outline in the outline view, select Options > Outline.

In the slide view in full screen mode, press:

• 1—to zoom out

• 2—to zoom in

• 3—to fit the slide to the screen

More information

If you experience problems with Quickpoint, visit

www.quickoffice.com

Support is also available by sending an e-mail to

supportS60@quickoffice.com

for more information.

Adobe Reader

Office

View presentations

To open a presentation for viewing, press , and select

Office > Quickpoint. Scroll to a presentation, and press .

To move between the Outline, Notes, Slide, and Thumbnail views, press or .

Press or to move to the next or previous slide in the presentation.

To toggle between full screen and partial screen mode, select Options > Change screen size.

With Adobe Reader you can read PDF documents on the display of your device.

Note: This application has been optimized for PDF document content on handsets and other mobile devices, and provides only a limited set of features compared with PC versions.

Note: This application is only available in a limited number of languages.

Access and open documents in the following ways:

• Press , and select Office > Adobe PDF. Select

Office

Options > Browse for file to browse and open

documents stored in the device memory and on the memory card.

• Open an e-mail attachment from received e-mail messages (network service).

• Send a document using Bluetooth connectivity to your

Inbox in Messaging.

•Use File mgr. to browse and open documents stored in the device memory and on the memory card.

• Browse Web pages. Ensure your device is set up with an Internet access point before browsing.

Manage PDF files

To browse and manage PDF files, press , and select

Office > Adobe PDF. Your recent files are listed in the file

view. To open a document, scroll to it, and press .

You can also select Options and from the following:

Browse for file—To browse for PDF files in the device

memory or on a memory card.

Settings—To modify default zoom level and viewing mode

of PDF documents.

View PDF files

When a PDF file is open, select Options and one of the following:

Zoom—To zoom in, out, or to a selected percentage.

You can also resize the document to the screen width, or fit the whole PDF page to the screen.

Find—To search the document for a text.

View—To view the document in a full screen mode.

You can also rotate the PDF document by 90 degrees in either direction.

Go to—To move to a selected page, next page, previous

page, first page, or last page.

Save—To save the file to device memory or memory card.

Settings—To modify default zoom level and default

viewing mode.

Details—To display the properties of the PDF document.

More information

For more information, visit www.adobe.com.

To share questions, suggestions, and information about the application, visit the Adobe Reader for Symbian OS user forum at http://adobe.com/support/forums/main.html

Info Print

Note: This application is only available in a limited

number of languages.

Press , and select Office > Info print. The Info print application enables you to print directly and wirelessly from your device. You can print a variety of contents from your device to a Basic Print Profile (BPP) equipped printer with Bluetooth connectivity (for example, HP Deskjet 450 Mobile Printer and HP Photosmart 8150). This includes multimedia and text messages, e-mail text, contacts, calendar, and notes.

For contacts, the application supports printing of the following contact fields: phone, fax, mobile, e-mail, URL, and address.

More information

For more information, visit www.hp.com/united-states/

camphone/mobile_print.html.

Office

Connectivity

Wireless Keyboard

To set up a Nokia Wireless Keyboard or other compatible

Connectivity

wireless keyboard supporting the Bluetooth Human Interface Devices (HID) profile for use with your device, use the Wireless Keyboard application. The keyboard enables you to enter text in comfort, using the full QWERTY layout, for text messages, e-mail, and calendar entries.

Note: This application is only available in a limited number of languages.

1 Activate Bluetooth connectivity on your device.

2 Switch on the keyboard.

3 Press , and select Connect. > Wireless Keyboard

4 Select Options > Find keyboards to start searching for

devices with Bluetooth connectivity.

5 Select the keyboard from the list.

6 To pair the keyboard with your device, enter a passcode

of your choice (1 to 9 digits) on the device, enter the same passcode on your keyboard within 30 seconds, and press the enter key on the keyboard. You do not need to write down the passcode because you can use a different passcode if you need to pair the keyboard with your device again.

To enter the digits of the passcode, you may need to press the Fn key first.

7 If you are asked for a keyboard layout, select it from a

list on your device.

8 When the name of the keyboard appears, its status

changes to Keyboard connected, and the green indicator of your keyboard blinks slowly, the keyboard is ready for use.

For details on the operation and maintenance of your keyboard, see its user guide.

My own

Catalogs

Catalogs (network service) is a mobile content shop

available on your device.

Use Catalogs to discover, download, and enjoy content, services, and applications that work with your Nokia N70. Games, ringing tones, wallpapers, applications, and much more are right at hand. The available content depends on your network operator and service provider.

Note: This application is only available in a limited number of languages.

Set up catalogs

Press , and select My own > Catalogs. Select OK if you accept the disclaimer.

When you open Catalogs for the first time, you are asked to define the settings.

1 On the Network tab, select which access point is used

to connect to the catalog server and how download progress is displayed.

2 To set your preferences, press to open the General

tab. Select where temporary files are stored, whether content is opened automatically after it is downloaded, and whether the device asks for your confirmation before you preview or download content.

3 After you complete the settings, select Done.

The application updates your device with the most recent catalogs available from your network operator or service provider and other available channels. If you want to change the settings later, select Options > Settings.

Catalogs uses your network services to access the most

updated catalog content. For information on additional items available through Catalogs, contact your network operator or service provider.

Use catalogs

In the main view, you can browse the catalogs available in your device. With Catalogs, you can:

• Discover new content that is available for your Nokia N70.

• Preview new items and read their descriptions, and download trial versions (if available).

My own

• Buy the easy way. Catalogs offers the payment methods available to you. Catalogs supports background downloads, downloads from multiple

My own

sources, and automatic installation.

• Upgrade when needed. Your device knows when upgrades are available for the applications you have installed.

Catalogs receives ongoing updates, bringing you the latest

content your network operator or service provider offers for your device. To update the catalogs manually, select

Options > Actions > Refresh.

Opera browser

To access the Web, press , and select My own > www. With the Opera browser, you can access pages that use the extensible hypertext markup language (XHTML), hypertext markup language (HTML), extensible markup language (XML), or wireless markup language (WML).

Note: This application is only available in a limited number of languages.

Check the availability of services, pricing, and tariffs with your network operator or service provider. Service providers will also give you instructions on how to use their services.

To access the Web, you must have an Internet access point configured in your device. For more information on access points, see the user guide of your device.

Browse the Web

Important: Use only services that you trust and that offer adequate security and protection against harmful software.

When you have the required connection settings in your device, you can access the Web. Press , and select My

own > www. To open a Web page, press 1 to open a field

for entering a URL address, or press 2 to view bookmarks.

The Opera browser formats Web pages intended for browsing with a PC to fit the width of the device display (fit to screen mode). To move on the page, scroll up or down. To select elements on the page, such as links, buttons, or form fields, scroll left or right to move to the element, and press . On some pages tailored for mobile phones, scrolling in any direction selects elements.

To view pages in their original layout, press #. To move on the page, use the scroll key. To select elements on the page, select Focus, scroll to the element, and press . To scroll on the page again, select Scroll. To return to fit to screen mode, press #.

To browse pages in full screen, press *. To return to the normal view, press * again.

To go to the previous page while browsing, select Back. To save a bookmark for the current page, press 7.

You can download files that cannot be shown on the browser page, such as themes and video clips. To download an item, move to the link, and press .

Important: Only install and use applications and other software from sources that offer adequate security and protection against harmful software.

Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred or forwarded.

To change display, general, or advanced settings, select

Options > Settings.

End the connection

To end the connection and close the browser, select

Options > Exit.

Empty the cache

A cache is a memory location that is used to store data temporarily. If you have tried to access or have accessed confidential information requiring passwords, empty the cache after each use. The information or services you have accessed are stored in the cache. To empty the cache, select

Options > Tools > Delete private data > Delete cache.

More information

For additional help on the program functions, select

Options > Tools > Help.

Visit www.opera.com/support/tutorials/s60/ more information.

for

My own

Tools

SettingWizard

SettingWizard configures your device for e-mail and

operator (MMS, GPRS, and Internet) settings based on your network operator information.

Note: To use these services, you may have to contact your network operator or service provider to activate a data connection or other services.

Press , and select Tools > SettingWizard.

Select the item from the menu that you want to configure your device for, and press .

E-mail

1 When you choose to configure your e-mail settings,

SettingWizard detects your available network

operator, and asks you to confirm it. Select OK, or scroll to another network operator, and select OK.

2 Select your e-mail service provider from the list.

3 Select the outgoing mail server. Use the default server

if you are not sure.

4 SettingWizard prompts you to enter the details of your

e-mail address, user name, and password. Select each in turn, and select Options > Change. Enter the details, and select OK.

5 Select Options > OK when you are finished.

6 Select OK to confirm that you want to set up the

mailbox for the specified operator.

7 Select OK.

Operator

1 When you choose to configure your operator settings,

SettingWizard detects your available network operator

and asks you to confirm it. Select OK, or scroll to another network operator, and select OK.

2 Select OK to confirm that you want to set up your

device for the specified operator.

More information

If you experience any problems with SettingWizard, visit the Nokia phone settings Web site at

www.nokiausa.com/phonesettings

Mobile search

Mobile Search

Use Mobile Search to give you access to leading search engines. Simple, convenient, and fast way to find and connect to local services, websites, images, and mobile content. You can find and call local restaurants and shops, and use the advanced mapping technology to guide you to their location.

Use Mobile Search

Press and select Search.

Note: The availability of this service may vary according to your country or sales area.

When you open Mobile Search, a list of categories are displayed. Select a category (for example, Images) and enter your text into the search field. Select Search and your results are displayed.

More information

For additional help on the program functions, select

Options > Help.

Visit www.mobilesearch.nokia.com

/ for more information.

Mobile search

Yahoo! Go

Access your e-mail, photo albums, instant messenger and more - wherever you are. Keep it easy, keep it safe, and keep your complete peace of mind. With Yahoo! Go, you can stay out and stay connected with your Yahoo! account.

Yahoo! Go enables you to access services including Yahoo! Mail, Yahoo! Messenger, Yahoo! Photos, Yahoo! Search, as well as, view news and download games and ringtones.

Yahoo! Go uses a single sign-in feature, which means that you only have to sign-in once during setup.

Yahoo! Go is comprised of the following four main features:

• Yahoo! Mail

• Yahoo! Messenger

• Yahoo! Connections

• Yahoo! Photos

Yahoo! Go

Note: Some applications are only available in a

limited number of languages.

Yahoo! Mail

Yahoo! Mail enables you to get your e-mails on the move. The automatic synchronization with your Yahoo! Mail account ensures everything you do on your device (for example, sending e-mails, marking as read or deleting e-mails) is immediately reflected on your online Yahoo! account.

Yahoo! Messenger

Yahoo! Messenger enables you to chat with your contacts using your device. You can send and receive text Instant Messages (IMs), emoticons, audibles, voice IMs, attach images to IMs, and manage your Yahoo! Messenger account.

To appear online to your contacts you need to sign-in to Yahoo! Messenger with one click. Your device saves your log in information so you do not need to re-enter this each time you want to instant message. The default setting is to be signed in to Messenger for a maximum of 10 minutes any time your device is detected as being inactive. Lengthening the time of this setting will reduce the standby time of your device.

Some networks do not support simultaneous use of Yahoo! Messenger and the reception of Video Calls and multimedia messages (MMS).

Yahoo! Connections

Yahoo! Connections synchronizes your device and Yahoo! account.

Yahoo! Connections starts automatically every time you switch on your device. You do not have to open the browser to check e-mails and other Yahoo! data. You can also send e-mail from your Yahoo! Mail account and view, create, edit, and delete contacts, calendar events and tasks using the messaging, contacts, and calendar applications on your device. The changes you make are reflected in your Yahoo! account.

Yahoo! Connections displays the status of the last connection, whether it was successful or not, and if a data exchange is presently being performed. It also displays the times of the last and next scheduled data exchanges.

Yahoo! Photos

Yahoo! Photos helps you manage and share yours photos. Yahoo! Photos on your device enables you to view and upload images from your device, as well as link to Yahoo! Photos and view your albums on the web. The feature works in conjunction with Yahoo! Connections.

Each time you take a photo with your device, Yahoo! Photos asks if you want to add it to your album. Photos that you upload to Yahoo! Photos appear:

• In your album on the Yahoo! Photos web site (in their original size).

• In the Yahoo! Photos application on your device (in a reduced size).

• In the device Gallery (in the original size)

More information

To find out more about Yahoo! Go, how it works, information on costs and additional help, please visit:

www.yahoo.com/

Yahoo! Go

For your PC

Lifeblog

For your PC

Nokia Lifeblog is a combination of software for mobile phone and PC that keeps a multimedia diary of the items that you collect with your device. Lifeblog automatically organizes your photos, videos, text messages, multimedia messages, and weblog posts into a chronology that you can browse, search, share, publish, and back up. Both Lifeblog for PC and Lifeblog for mobile phone let you send or blog your items for others to see.

Lifeblog for mobile phone automatically keeps track of your multimedia items. Use Lifeblog on your device to browse your items, send them to others, or publish them on the Web. Connect your device to a compatible PC using a USB cable or Bluetooth connectivity to transfer and synchronize the items on the device with your PC.

Lifeblog for PC provides easy browsing and searching of the items that you collected with your device. With one-button transfer using a USB cable or Bluetooth connectivity, your favorite photos, videos, text, and multimedia messages are transferred back to your device.

For safekeeping, you can back up your Lifeblog database using your hard disk, CDs, DVDs, removable drive, or

network drive. Additionally, you can post items to your weblog (blog).

Note: This application is only available in a limited number of languages.

Install Lifeblog on your device

To install Lifeblog on your device:

1 Press , and select My own > Lifeblog.

2 Select Options > Open to start the installation program.

3 Select OK to install the Lifeblog phone application.

Lifeblog is installed in the My own folder.

Install Lifeblog on your PC

Before you install Lifeblog on a compatible PC, you need the following:

• 1 GHz Intel® Pentium® or equivalent, 128 MB RAM

• 400 MB of available hard disk space (if Microsoft® DirectX® and Nokia PC Suite must be installed)

• Graphics capability of 1024x768 and 24-bit color

• 16 MB graphics card

• Microsoft® Windows® 2000 or Windows XP

To install Lifeblog on your PC:

1 Insert the CD-ROM supplied with your device. 2 Install Nokia PC Suite (including CA-53 USB

cable drivers).

3 Install Nokia Lifeblog for PC. 4 If Microsoft® DirectX® 9.0 is not already installed on

your PC, it is installed now.

Connect your device and your PC

To connect your device and a compatible PC using the USB cable:

1 Ensure that you have installed Nokia PC Suite and

the CA-53 driver for the USB connection.

2 Connect the USB cable to the device and the PC. 3 Start the Lifeblog PC application.

To connect your device and a compatible PC using Bluetooth wireless technology:

1 Ensure that you have installed Nokia PC Suite on

your PC.

2 Activate Bluetooth connectivity on your device and on

your PC. For details, see the user guide for your device and the documentation for your PC.

Transfer items

When you have connected your device to a compatible PC using a USB cable or Bluetooth connectivity, you are ready to transfer your items.

To transfer items from your device Timeline to the Timeline view on the PC and to synchronize your Timeline:

1 Start the Lifeblog application on your PC. 2 In the Lifeblog PC application, select File >

Transfer items.

The items on the device that were successfully transferred to the PC are deleted from the device. The items are deleted from all item stores on the device (for example, Messaging and Gallery). If you do not want your items to be deleted from the device, add them to Favorites before transferring them to the PC. Favorites and text messages always stay on your device, unless you specify otherwise.

Post to the Web

To share your best Lifeblog items, send them to your weblog on the Internet for others to see.

You must first create an account with a weblog service, create one or more weblogs that you use as the destination of your posts, and add the weblog account to Lifeblog. The recommended weblog service for Lifeblog is Six Apart's

www.typepad.com

On your device, add the weblog account in Lifeblog in the weblog settings. On your PC, edit accounts in the Edit

weblog accounts window.

To post items to the Web from your device: 1 In Timeline or Favorites, select the items that you want

to post to the Web.

For your PC

2 Select Options > Post to Web. 3 If you use the feature for the first time, Lifeblog

retrieves a weblog list from the weblog server.

4 The weblog post dialog opens. Select the weblog you

For your PC

want to use from the Post to: list. If you have created new weblogs, to update the weblog list, select Options >

Refresh weblog list.

5 Enter a title and a caption for the post. You can also

write a longer story or description in the body text field.

6 When everything is ready, select Options > Send.

To post items to the Web from your PC: 1 In Timeline or Favorites, select the items (a maximum

of 50) that you want to post to the Web.

2 Select File > Post to Web..., or click the Post to the Web

button. The Post to Web window opens.

3 Enter a title and a caption for the post. You can also

write a longer story or description in the body text field.

4 Select the weblog that you want to use from the Post

to: list.

5 When everything is ready, click the Send button.

Import items from hard disk, CD, or DVD

In addition to the .jpg images of your imaging device, you can also import .jpg images and .3gp and .mp4 video clips from other sources (such as a CD or folders on your hard disk) into Lifeblog.

To import images or videos from a PC to Lifeblog for PC:

1 In the Timeline or Favorites view, select File > Import

from PC.... The Import images or videos from your PC

window opens.

2 Browse the list to find the image or video file from the

list, or navigate to other folders to find the file that you want to import. Use the Look in list to browse other drives or appliances.

3 Select a folder, file, or several files. You can view their

content in the Preview: pane.

4 Click Import to import the folder (including subfolders)

or selected files.

Browse in the Timeline and Favorites views on your PC

When you start Lifeblog on your PC, you have several ways to move around in the Timeline and Favorites views. The fastest way is to grab the slider handle and move it forward or backward, fast or slow. Alternatively, click the time bar to select a date, use the Go to date... feature, or use the arrow keys.

More information

For more information on weblog services and their compatibility with Lifeblog, visit www.nokia.com/lifeblog or press F1 in the Lifeblog PC application to open Lifeblog Help.

To get your free licence code for all Nokia Nseries device owners, go to www.nokia.com/nseries/lifeblog

PC Suite

Nokia PC Suite is a set of PC applications developed for use with your Nokia N70.

To install and use Nokia PC Suite, you need a PC that runs on Microsoft® Windows® 2000 or XP and is compatible with the provided USB cable, or with Bluetooth connectivity.

Before using Nokia PC Suite, you need to install it on your PC. See the CD–ROM for more information.

A full user guide for Nokia PC Suite is available in electronic format on the CD-ROM.

Connect your device to the PC

The Get Connected wizard helps you to connect your device to a compatible PC. After you complete the wizard steps, you have established a connection between your device and the PC, and you can start using the Nokia PC Suite applications that require PC connectivity.

1 Install Nokia PC Suite. Get Connected opens automatically. 2 Select which connection type to use when connecting

the device to the PC.

3 Follow the instructions on the screen to connect the

device to the PC.

To open Get Connected later (for example, to configure another connection type), select Get Connected in Nokia PC Suite.

Synchronize

Nokia PC Sync allows you to synchronize contacts, calendar, to-do, and note items between your device and a compatible PC personal information manager (PIM), enabling you to keep the information on both the device and the compatible PC up to date.

1 Start Nokia PC Suite.

2 Connect your device to the PC with the USB cable, or

use a Bluetooth connection.

3 Select Synchronize in Nokia PC Suite.

Note: When you first connect, a wizard helps you to set up the synchronization default mode.

You can set the device and PC to automatically synchronize data when the device is connected to the PC, and Nokia PC Suite is active.

Back up and restore

Back up data from your device or restore saved data from the compatible PC to the device.

1 Start Nokia PC Suite.

2 Connect your device to the PC with the USB cable, or

use a Bluetooth connection.

For your PC

3 Select Back up and restore in Nokia PC Suite.

4 On the Select a task page, select Make a backup... or

Restore backup....

5 Follow the instructions on the screen.

It is recommended that you back up your device content at

For your PC

regular intervals to help avoid potential data loss.

Store images and video clips

With Image Store, you can store images and videos from your device to a compatible PC. The application checks the device memory and memory card for new images and videos that have been captured since the last storing session, and stores them on the PC.

Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred or forwarded.

1 Start Nokia PC Suite.

2 Connect your device to the PC with the USB cable, or

use a Bluetooth connection.

3 Select Store images in Nokia PC Suite.

4 When you use Image Store for the first time, a settings

wizard opens. You must complete the settings to be able to store files from your device to the PC. Follow the instructions on the screen.

5 Select Store Now in the Image Store main window.

Image Store searches the device memory and memory card for new images and videos captured since the last storing session. Depending on the file types selected in the settings, all new images or videos are stored on the PC.

Transfer information and pictures

With Nokia Phone Browser you can manage the contents of your device folders through Windows Explorer. Transfer information and pictures from device to device, or device to compatible PC.

Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred or forwarded.

1 Start Nokia PC Suite. 2 Connect your device to the PC with the USB cable, or

use a Bluetooth connection.

3 Select Transfer Files in Nokia PC Suite. 4 In Windows Explorer, select My Computer > Nokia

Phone Browser > Nokia N70.

5 Select the device subfolder you want to view.

To refresh the device contents view, select View > Refresh.

Transfer music

With Nokia Audio Manager, you can create and organize digital music files on a compatible PC and transfer them to a compatible device, or from device to device.

Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred or forwarded.

1 Start Nokia PC Suite. 2 Connect your device to the PC with the USB cable, or

use a Bluetooth connection.

3 Select Transfer Music in Nokia PC Suite.

Connect to the Internet

One Touch Access sets up the modem access automatically based on the network operator or service provider (network service). You can quickly establish a network connection using your device as a modem by means of a UMTS network or GPRS in the GSM network.

Ensure that a data connection is activated on your device. Contact your service provider for more information.

If you want to use a standard Bluetooth wireless technology modem, Bluetooth modem drivers must be installed before you can use One Touch Access.

Set up modem access

One Touch Access includes a settings wizard, which allows you to configure the connection settings. Follow the instructions on the screen.

Establish a modem connection

1 Start Nokia PC Suite.

2 Connect your device to the compatible PC.

3 Select Connect to the Internet in Nokia PC Suite.

4 One Touch Access connects to the Internet after

10 seconds. You can also select Connect to start aconnection.

More information

For further information, and to download the most recent version of Nokia PC Suite, visit www.nokiausa.com/pcsuite

Adobe Photoshop Album Starter Edition

Adobe® Photoshop® Album Starter Edition 3.0 helps you to find, fix, and easily share your photos using a compatible PC. With this version of Starter Edition you can:

• Use tags to organize your photos so that they are easy to find.

• Use a calendar view to view all of your digital photos in one place.

• Fix common photo flaws in a single click.

• Share photos in many ways: send through e-mail, print at home, or send them to mobile devices.

Note: This application is only available in a limited number of languages.

For your PC

Installation

Install the Starter Edition application to your PC from the CD-ROM provided with your device. Starter Edition requires the Microsoft® Windows® 2000 or XP operating system, Nokia PC Suite 6.5 or later for connectivity between your

For your PC

device and PC, and Apple® QuickTime® 6.5.1. or later to view and edit video clips.

Nokia PC Suite is provided for you on CD-ROM with your device. If your system does not have Apple® QuickTime® installed, you can install it from

www.apple.com/quicktime/download

Follow the on-screen installation instructions.

Transfer photos and video clips from your device to PC

There are two ways to transfer your photos from your device to Starter Edition.

To transfer photos and video clips to a compatible PC automatically:

1 Connect your device to a compatible PC with the USB

cable provided with your device. On the PC, the Adobe

Photo Downloader dialog box opens, and the new image

and video files captured since the last transfer are automatically selected.

2 To start the transfer, click Get Photos. All selected files

are imported to Starter Edition. Any albums you created in the phone gallery will be automatically transferred into Starter Edition and identified as tags.

3 You can select to delete files from your device after

they have been transferred to Starter Edition.

To enable or disable the automatic Adobe Photo

Downloader dialog box, right-click the icon on the task bar.

To transfer photos to a compatible PC manually:

1 Connect your device to a compatible PC with the USB

cable or using Bluetooth connectivity.

2 Start the Starter Edition application.

3 In the shortcuts bar, click Get photos > From Camera,

Mobile Phone or Card Reader. The Adobe Photo Downloader dialog box opens.

4 Click Get Photos to start the transfer. All selected files

are imported to Starter Edition. Any albums you created in the phone gallery will be automatically transferred into Starter Edition and identified as tags.

5 You can select to delete files from your device after

they have been transferred to the Starter Edition.

Transfer photos and video clips from PC to your device

To transfer edited photos and video clips back to your device: 1 Connect your device to a compatible PC with the USB

cable or using Bluetooth connectivity.

2 Start the Starter Edition application. 3 Select the photos and videos you want to transfer to

your device.

4 Click Share in the shortcuts bar, and select Send to

Mobile Phone.

5 Click OK.

Browse your photos in full screen

View full screen photos, and rotate, fix, and mark them for printing.

To view photos in full screen:

1 Select the photos. 2 From the File menu, select View > Full Screen Slideshow.

The slide show starts.

3 To rotate, fix, and mark photos for printing, use your

mouse to select the icons at the bottom of the screen.

Share your photos in e-mail

The file size of photos and slide shows is automatically reduced when you send them as e-mail attachments in Starter Edition.

To send your photos and slide shows in e-mail:

1 Select the photos.

2 In the shortcuts bar, select Share > Email.

3 When you send photos or slide shows in e-mail for the

first time, you must select the e-mail client. Starter Edition uses the selected client in all future e-mail correspondence.

4 Select whether you want to send the photos as a slide

show or as individual attachments.

5 Click OK. An e-mail message window opens.

Print your photos

Print high-quality photos in any layout you want.

1 Select the photos.

2 Select Print in the shortcuts bar, and select Print from

the menu.

3 Select layout and size.

4 Click Print.

Organize and find your photos by date

Starter Edition automatically organizes your photos by date so that they are easy to find.

There are two ways to find photos by date: photo well and calendar view.

For your PC

To find photos using the photo well:

1 Select Photo Well in the shortcuts bar.

2 In the timeline below the shortcuts bar, select the

month of the photos you want to view. Photos from

For your PC

that month are shown in the photo well.

To find photos using the calendar view:

1 Select Calendar View in the shortcuts bar.

2 In the calendar view, select a day with a photo to view

all the photos taken that day.

3 Scroll from month to month with the arrow buttons at

the top of the calendar.

Organize and find your photos using tags

Use keyword tags to find photos based on the people in them, place, event, and other characteristics of the photo. When you tag your photos, you do not have to remember the file name, date, or folder for each photo.

Click Organize in the shortcuts bar to open the Tag pane.

To create your own tag:

1 Click New in the Tag pane, and select New Tag.

2 In the Create Tag dialog box, use the Category menu

to choose which subcategory you want to list the tag under.

3 In the Name text box, enter the name you want to give

the tag.

4 In the Note text box, enter any information you want

to add about the tag.

5 Click OK.

The tag appears in the Tag pane under the category or subcategory you selected.

To attach a tag to a photo, drag the tag from the Tag pane onto the photo in the photo well.

To find your photos, double-click a tag in the Tag pane; the search finds all photos that have that particular tag attached.

To narrow the range of photos and jump to a particular month, click the bar in the timeline.

If you create a new album on the device, add photos in it, and transfer the photos to Starter Edition, the album information shows as a new tag under Imported tags.

Fix your photos

Starter Edition provides tools to fix the most common photo problems.

To fix photos:

1 Select a photo in the photo well.

2 Click Fix photo in the shortcuts bar. Starter Edition

makes a copy of the original photo file for editing.

To fix the photo automatically, select Auto Smart Fix.

To fix the photo manually, select Fix Photo Window..., and from the following:

General—Selects auto correction for color, levels,

contrast, or sharpening.

Crop—Crops a photo to improve the composition or add

emphasis to an image.

Red Eye—Corrects the red-eye effect caused by a

camera flash.

Play and edit your videos

To play your videos, double-click the video file, and click

Play under the video window.

To edit, rearrange, and delete scenes in your mobile movies:

1 Right-click a movie file, and select Edit Mobile Movie.

You see the first frame of your video in the video window. The blue marker in the timeline below the video window indicates the frame you are viewing.

2 To play, pause, stop, go to the beginning, or go to the

end, use the control buttons below the video window. Or, to move through the video, drag the blue marker in the timeline.

3 To select a section of the video to crop, rearrange, or

delete, do one of the following:

• Drag the selection handles that are located at the

beginning and end of the timeline.

• To mark the start time of the selection, press and

hold Shift, and click in the timeline. To mark the end time, press and hold Ctrl, and click in the timeline.

After you have selected a section, you can drag the selection bar in the timeline.

4 To delete the selected section of the video, click the

Delete button in the toolbar.

To crop the selection and delete the parts outside it, click the Crop button in the toolbar.

To copy the selection and paste it to another point in time, click the Copy button in the toolbar. Drag the blue marker in the timeline to the desired point, and click the Paste button.

More information

For additional help on the program functions, select Help >

Adobe Photoshop Album Help in the main menu.

For more information on Starter Edition, visit

www.adobe.com/products/photoshopalbum/starter.html

For your PC

Nokia N70

Additional Applications Guide

9248033

Nokia N70 Additional applications

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Introduction

Network services

Support

Imaging

KODAK Mobile Service

Office

Symantec Mobile Security

Quickword

Quicksheet

Quickpoint

Adobe Reader

Info Print

Connectivity

Wireless Keyboard

My own

Catalogs

Opera browser

Tools

SettingWizard

Mobile search

Mobile Search

Yahoo! Go

Yahoo! Go

For your PC

Lifeblog

PC Suite

Adobe Photoshop Album Starter Edition
