JBL PowerUp Wireless Charging Speaker for Nokia, MD-100W
Issue 1.1
2
Contents
About your speaker3
About Qi3
About Bluetooth connectivity4
Keys and parts5
Switch the speaker on6
Pair your device6
Pair and connect6
Pair the speaker using NFC7
Pair the speaker manually7
Clear the pairings8
Play music8
Charge another device wirelessly10
Connect to another device on the
go10
Support11
Product and safety information11
About your speaker
With the Nokia MD-100W wireless speaker, you can listen to music in high audio quality
from your phone or other compatible device, such as a music player. You can connect
to another device without stopping the music. You can also use a standard audio cable
(3.5 mm) to connect your device to the audio connector in the speaker. The product
comes with an audio cable.
The Nokia MD-100W wireless speaker can also be used as a wireless charger. To
charge a Qi compatible device, place it on the wireless charging area, on top of the
speaker.
Warning:
This product may contain small parts. Keep them out of the reach of small children.
Parts of the product are magnetic. Metallic materials may be attracted to the product.
Do not place credit cards or other magnetic storage media near the product, because
info stored on them may be erased.
The surface of this product is nickel-free.
About Qi
Qi is a global standard that makes wireless charging possible for your device. With a
Qi-compatible device, you don't need to connect any cables. You just place your
device on the charging surface.
3
Qi works using magnetic induction, and is currently designed for devices that use 5
watts of power or less, such as mobile phones. Qi chargers and devices use the same
4
frequency, so as long as their active areas are touching, all Qi products are
compatible, regardless of manufacturer or brand. For more details, see the user
guides of both devices.
About Bluetooth connectivity
You can use Bluetooth to make a wireless connection to other compatible devices,
such as mobile phones.
Devices do not need to be in direct line-of-sight, but they must be within 10 meters
(33 feet) of each other. The connection may be affected by obstructions such as walls
or other electronic devices.
This device is compliant with Bluetooth Specification 2.1 + EDR supporting the
following profiles: A2DP and AVRCP . Check with the manufacturers of other devices
to determine their compatibility with this device.
Keys and parts
1 Volume down key
2 Volume up key
3 NFC area
4 Skip to previous track
5 Play or pause key
6 Skip to next track
7 Power and Bluetooth status indicator
8 Bluetooth key
5
9 Wireless charging area
10 Wireless charging status indicators
6
11 Power key
12 Connector for power supply
13 Service connector
14 Audio connector (3.5 mm)
Switch the speaker on
Connect the power supply cable to the connector on the speaker.
1
2 Connect a suitable plug to the AC-adapter of the power supply.
3 Plug the power supply into a wall outlet.
4 Press the power key.
If you've never paired your speaker with a device, or you've cleared the pairings, the
speaker goes into pairing mode automatically when it is switched on, and the
Bluetooth indicator light starts to flash slowly.
If you've already paired the speaker with one or more devices, the speaker connects
to the last device it was used with.
If the speaker is not connected to another device, or has no audio connection or other
activity for 30 minutes, it switches to standby mode, and all the indicator lights switch
off.
Pair your device
Pair and connect
Before using your speaker with a phone or other compatible device for the first time,
you must pair and connect it to the device.
You can only connect the speaker to one device at a time, but you can connect to
another device on the go.
When the speaker is connected, the Bluetooth status indicator light is blue.
If the connected device goes out of Bluetooth range, the speaker tries to reconnect
for 3 minutes. When the device comes back into range, the speaker reconnects
automatically.
You can also use a standard audio cable (3.5 mm) to connect your device to the audio
connector in the speaker. When you connect your speaker and device using a wired
connection, Bluetooth is switched off automatically, and the Bluetooth indicator light
turns white.
Pair the speaker using NFC
With Near Field Communication (NFC), you can easily pair and connect your speaker
to your compatible device.
If your device supports NFC, switch NFC on, and touch the NFC area of the speaker
with the NFC area of your device. The speaker connects to your device automatically.
Some devices may ask for confirmation on connection. For details on NFC, see your
device user guide.
If your device doesn't support NFC, pair the speaker manually.
7
Pair the speaker manually
You can pair your speaker manually with Bluetooth.
8
1 Switch on your speaker and phone or other compatible device.
2 If you've previously paired your speaker with another device, press and hold for
2 seconds to switch Bluetooth on.
3 Within 3 minutes, switch Bluetooth on in your phone, and search for Bluetooth
devices. For details, see your phone user guide.
4 On your phone, select the speaker from the list of found devices.
5 If asked, type in the passcode 0000.
Clear the pairings
You can clear the paired devices list on your speaker.
Switch the speaker off, then press and hold and the power key for 5 seconds.
The white and red indicator lights alternate.
Pressing and holding and power also restores factory settings in your speaker.
After you've cleared the pairings, you must pair the speaker before you can use it
again. When you switch the speaker on, it goes into pairing mode automatically.
If the paired devices list on your speaker is cleared, also clear that pairing in your
device before pairing again.
Play music
While playing music on your phone, you can control the music with your speaker as
well.
Play a song
Select a song in the music player list, and press to play, pause, or resume playing.
If you receive or make a call while listening to music, the music is paused.
Play the next song
Press .
Play the previous song
Press
Adjust the volume
Press or .
Mute the music
Press and at the same time.
Unmute the music
Press either or , or both at the same time.
9
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a
moderate level.
10
Charge another device wirelessly
Place your phone or other compatible device on the wireless charging area on top of
the speaker. The charging indicator lights turn white and flash on and off while
charging. Adjust the position of your phone if the charging indicator lights blink
quickly. When your phone is fully charged, the charging indicator lights go off
immediately.
You can listen to music while charging, but make sure the music isn't too loud —
vibrations may cause your phone to fall from the speaker.
It's normal for your speaker and phone to get warm, and they may get even warmer
if you use your phone to, for example, stream music while charging. The speaker
switches off automatically if it gets too warm. Wait for 5 minutes and try again.
Keep the speaker free of clutter. If there is something besides your phone on the
speaker, the speaker doesn't charge, and the charging indicator lights blink quickly.
Connect to another device on the go
Take turns with your friends in playing your music. You can change the connected
device on the go, without pausing the music.
1 While playing music from your connected device, press and hold for 2 seconds.
11
2 Pair and connect to another device. The music continues playing until pairing is
complete.
3 Play music on the device just connected.
Support
When you want to learn more about how to use your device, or if you're unsure how
your device should work, read the user guide thoroughly.
If you have an issue, restore the original factory settings.
If your issue remains unsolved, contact Nokia for repair options.
Product and safety information
Take care of your device
Handle your device, charger and accessories with care. The following suggestions help you protect your warranty coverage.
•Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode
electronic circuits. If your device gets wet, allow the device to dry.
•Use the charger for intended purposes only. Improper use, or use of incompatible chargers may present a risk of fire,
explosion, or other hazard. Never use a damaged charger. Only use the charger indoors.
•Do not attempt to charge a device having a damaged, cracked or open battery case or a device that is not compatible
with Qi.
•Do not store the device in high temperatures. High temperatures can shorten the life of the device, and warp or melt
plastics.
•Do not attempt to open the device.
•Unauthorized modifications may damage the device and violate regulations governing radio devices.
•Do not drop, knock, or shake the device.
•Only use a soft, clean, dry cloth to clean the surface of the device.
Recycle
Always return your used electronic products, batteries, and packaging materials to dedicated collection points. This way
you help prevent uncontrolled garbage disposal and promote the recycling of materials.
Additional safety information
Implanted medical devices
Manufacturers of medical devices recommend a minimum separation of 15.3 centimeters (6 inches) between a wireless
device and an implanted medical device, such as a pacemaker or implanted cardioverter defibrillator, to avoid potential
interference with the medical device. Persons who have such devices should:
•Always keep the wireless device more than 15.3 centimeters (6 inches) from the medical device.
•Not carry the wireless device in a breast pocket.
•Turn the wireless device off if there is any reason to suspect that interference is taking place.
•Follow the manufacturer directions for the implanted medical device.
If you have any questions about using your wireless device with an implanted medical device, consult your health care
provider.
12
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this MD-100W product is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://
www.nokia.com/global/declaration/declaration-of-conformity.
Nokia, Nokia Connecting People, and the Nokia Original Accessories logo are trademarks or registered trademarks of Nokia
Corporation.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior
written permission of Nokia is prohibited. Nokia operates a policy of continuous development. Nokia reserves the right to
make changes and improvements to any of the products described in this document without prior notice.
The ‘Qi’ symbol is a trademark of the Wireless Power Consortium
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Nokia is under license.
To the maximum extent permitted by applicable law, under no circumstances shall Nokia or any of its licensors be responsible
for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is." Except as required by applicable law, no warranties of any kind, either
express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular
purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise
this document or withdraw it at any time without prior notice.
The availability of some features may vary by region. Please contact your operator for more details.
The availability of products may vary by region. For more info, contact your Nokia dealer. This device may contain
commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion
contrary to law is prohibited.
FCC/INDUSTRY CANADA/MEXICO NOTICE
This device complies with part 15 of the FCC rules and Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. Any changes or modifications not
expressly approved by Nokia could void the user's authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
13
•Consult the dealer or an experienced radio/TV technician for help.
NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
/Issue 1.1 EN-US
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
