Nokia Customer Care
6255/6255i/6256/6256i (RM-19)
Mobile Terminal
Parts Lists and Exploded View
Issue 2 05/2005 Company Confidential ©2005 Nokia Corporation
Page 2
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Contents Page
Exploded View ................................................................................................................................................. 3
Assembly Parts List .....................................................................................................................................4
Parts List — Build 011— Engine Code 0202264..................................................................................... 6
Page 2 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 3
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Exploded View
1
7
2
8
3
9
10
14
15
4
6a
5
6d
6
6f
6h
6b
6c
6e
6g
11
12
13
16
17
18
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 3
Page 4
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Assembly Parts List
Item Qty Description NMP Code
1 1 Headset jack plug 5469271
* 4 Screws 6380145
2 1 D-cover/IHF assembly 0266126
3 1 Volume key 5201001
4 1 Main engine PWB 0202264
5 1 Dome sheet assembly 9795212
6 1 B/C-cover assembly 0266114
6a 1 Speaker 5140067
6b 1 Earpiece gasket 9470703
6c 1 B-cover assembly 9492004
6d 1 Hinge 9590241
6e 1 Hinge flex cable 9855112
6f 1 Adhesive flip detection 9400320
6g 2 Hinge caps 9900053
6h 1 C-cover 9454015
* 4 Screws 6380145
7 1 Inner housing 9517425
8 1 Main display module 4850807
9 1 Upper camera shield 9560316
10 1 VGA camera module 4858023
11 1 U I P W B:
Version A (6255i/6256i)
Version B (6255/6256)
12 1 Secondary display module 4850825
13 1 Lower fold assembly N/A
14 1 Co-label (Carrier dependent)
0210118
0202441
* 1 Screw 6380223
Page 4 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 5
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Qty Description NMP Code
15 1 Keymat assembly:
Latin
Blue
Red
Black
Dark Grey
Chinese
Blue
Red
Black
Thai
Blue
Black
16 1 B, C, and D-cover assembly N/A
17 1 A-cover assembly:
Blue
Red
Black
Silver
9791448
9791435
9797207
9791449
9791450
9791434
9797208
9797387
9797385
9491962
0266331
0266308
9491963
18 1 E-cover 9454017
* Not pictured in the exploded view.
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 5
Page 6
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Parts List — Build 011— Engine Code 0202264
Item Code Side X Y Description
A8000 9517418 Bottom C 6 DUPLEXER SHIELD ASSY DNS08913
A8001 9517420 Bottom G 5 RX SHIELD ASSY DNS08915 HDDA3
A8002 9517419 Bottom H 8 TX SHIELD ASSY DNS08914 HDDA3
A8003 9517416 Bottom M 6 BASEBAND SHIELD ASSY DNS08908
A8004 9517417 Bottom O 2 BLUETOOTH SHIELD ASSY DNS08909
B2200 4510405 Bottom M 3 CRYSTAL 32.768KHZ+-20PPM 12.5PF
C2000 2351009 Top R 3 CHIPCAP X5R 1U K 6V3 0402
C2001 2351009 Top Q 3 CHIPCAP X5R 1U K 6V3 0402
C2002 2320620 Top Q 4 CHIPCAP X7R 10N J 16V 0402
C2004 2320805 Top Q 5 CHIPCAP X5R 100N K 10V 0402
C2008 2320536 Top Q 7 CHIPCAP NP0 10P J 50V 0402
C2009 2320536 Top Q 6 CHIPCAP NP0 10P J 50V 0402
C2010 2320536 Top Q 7 CHIPCAP NP0 10P J 50V 0402
C2011 2320536 Top Q 7 CHIPCAP NP0 10P J 50V 0402
C2012 2320744 Bottom P 3 CHIPCAP X7R 1N0 K 50V 0402
C2013 2320544 Bottom P 2 CHIPCAP NP0 22P J 50V 0402
C2014 2320552 Bottom D 8 CHIPCAP NP0 47P J 50V 0402
C2015 2320552 Bottom D 8 CHIPCAP NP0 47P J 50V 0402
C2016 2351009 Bottom E 8 CHIPCAP X5R 1U K 6V3 0402
C2017 2320596 Top R 8 CHIPCAP X7R 3N3 J 50V 0402
C2018 2320596 Top R 7 CHIPCAP X7R 3N3 J 50V 0402
C2019 2320596 Top Q 6 CHIPCAP X7R 3N3 J 50V 0402
C2020 2320596 Top R 7 CHIPCAP X7R 3N3 J 50V 0402
C2021 2320596 Top Q 6 CHIPCAP X7R 3N3 J 50V 0402
C2022 2320596 Top Q 6 CHIPCAP X7R 3N3 J 50V 0402
C2100 2320805 Top R 8 CHIPCAP X5R 100N K 10V 0402
C2101 2320805 Top R 8 CHIPCAP X5R 100N K 10V 0402
C2102 2320805 Top R 6 CHIPCAP X5R 100N K 10V 0402
C2103 2320805 Top C 3 CHIPCAP X5R 100N K 10V 0402
C2104 2320552 Top B 3 CHIPCAP NP0 47P J 50V 0402
C2105 2320552 Top B 3 CHIPCAP NP0 47P J 50V 0402
Page 6 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 7
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Code Side X Y Description
C2106 2320805 Top C 3 CHIPCAP X5R 100N K 10V 0402
C2107 2320805 Top B 3 CHIPCAP X5R 100N K 10V 0402
C2108 2320505 Top B 3 CHIPCAP X5R 4U7 K 6.3V 0603
C2109 2320548 Top Q 6 CHIPCAP NP0 33P J 50V 0402
C2110 2320505 Top B 3 CHIPCAP X5R 4U7 K 6.3V 0603
C2111 2320805 Bottom N 4 CHIPCAP X5R 100N K 10V 0402
C2112 2320805 Top B 2 CHIPCAP X5R 100N K 10V 0402
C2113 2320805 Top Q 8 CHIPCAP X5R 100N K 10V 0402
C2114 2320805 Top Q 8 CHIPCAP X5R 100N K 10V 0402
C2115 2320805 Top Q 8 CHIPCAP X5R 100N K 10V 0402
C2116 2320805 Top C 3 CHIPCAP X5R 100N K 10V 0402
C2117 2320566 Top Q 3 CHIPCAP X7R 180P J 50V 0402
C2118 2320620 Top Q 3 CHIPCAP X7R 10N J 16V 0402
C2119 2351009 Top Q 3 CHIPCAP X5R 1U K 6V3 0402
C2120 2351009 Top Q 3 CHIPCAP X5R 1U K 6V3 0402
C2200 2310037 Bottom J 2 CHIPCAP X5R 10U M 6V3 0805
C2201 2320778 Bottom K 3 CHIPCAP X7R 10N K 16V 0402
C2202 2315269 Bottom M 3 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2203 2315269 Bottom M 5 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2204 2315269 Bottom M 4 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2205 2351009 Bottom K 3 CHIPCAP X5R 1U K 6V3 0402
C2209 2315269 Bottom M 3 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2210 2315269 Bottom M 4 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2211 2320778 Bottom N 4 CHIPCAP X7R 10N K 16V 0402
C2214 2315269 Bottom N 4 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2215 2320805 Bottom M 5 CHIPCAP X5R 100N K 10V 0402
C2216 2320805 Bottom J 5 CHIPCAP X5R 100N K 10V 0402
C2217 2320805 Bottom J 4 CHIPCAP X5R 100N K 10V 0402
C2218 2320805 Bottom J 4 CHIPCAP X5R 100N K 10V 0402
C2224 2320778 Bottom O 4 CHIPCAP X7R 10N K 16V 0402
C2226 2320778 Bottom O 4 CHIPCAP X7R 10N K 16V 0402
C2227 2320778 Bottom O 6 CHIPCAP X7R 10N K 16V 0402
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 7
Page 8
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Item Code Side X Y Description
C2228 2315269 Bottom J 4 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2229 2315269 Bottom J 3 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2230 2315269 Bottom J 4 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2233 2315269 Bottom J 4 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2270 2320143 Bottom K 3 CHIPCAP X5R 220N K 6.3V 0402
C2272 2315269 Bottom J 3 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2273 2315269 Bottom J 4 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2274 2315269 Bottom J 3 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2277 2315269 Bottom J 3 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2300 2320505 Bottom N 9 CHIPCAP X5R 4U7 K 6.3V 0603
C2301 2320505 Bottom N 9 CHIPCAP X5R 4U7 K 6.3V 0603
C2302 2320805 Bottom L 9 CHIPCAP X5R 100N K 10V 0402
C2303 2320505 Bottom M 9 CHIPCAP X5R 4U7 K 6.3V 0603
C2304 2320505 Bottom M 9 CHIPCAP X5R 4U7 K 6.3V 0603
C2400 2320552 Bottom B 6 CHIPCAP NP0 47P J 50V 0402
C2401 2320536 Bottom B 6 CHIPCAP NP0 10P J 50V 0402
C2402 1825133 Bottom B 6 CHIP VARISTOR VWM14V VC50V 0402
C2403 1825133 Bottom F 2 CHIP VARISTOR VWM14V VC50V 0402
C2404 1825133 Bottom H 2 CHIP VARISTOR VWM14V VC50V 0402
C2405 2320481 Bottom F 2 CHIPCAP X5R 1U K 6V3 0603
C2406 2320554 Bottom F 2 CHIPCAP NP0 56P J 50V 0402
C2407 2320764 Bottom F 2 CHIPCAP X7R 6N8 K 25V 0402
C2408 2320805 Bottom I 2 CHIPCAP X5R 100N K 10V 0402
C2409 2320552 Bottom B 5 CHIPCAP NP0 47P J 50V 0402
C2450 2320552 Bottom C 1 CHIPCAP NP0 47P J 50V 0402
C2600 2320805 Bottom E 9 CHIPCAP X5R 100N K 10V 0402
C2601 2320805 Bottom E 9 CHIPCAP X5R 100N K 10V 0402
C2602 2320505 Bottom E 9 CHIPCAP X5R 4U7 K 6.3V 0603
C2700 2320805 Bottom J 7 CHIPCAP X5R 100N K 10V 0402
C2800 2320778 Bottom O 6 CHIPCAP X7R 10N K 16V 0402
C2801 2320778 Bottom J 6 CHIPCAP X7R 10N K 16V 0402
C2802 2320778 Bottom M 7 CHIPCAP X7R 10N K 16V 0402
Page 8 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 9
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Code Side X Y Description
C2803 2320778 Bottom J 5 CHIPCAP X7R 10N K 16V 0402
C2804 2320778 Bottom J 5 CHIPCAP X7R 10N K 16V 0402
C2805 2320778 Bottom J 7 CHIPCAP X7R 10N K 16V 0402
C2806 2320778 Bottom M 7 CHIPCAP X7R 10N K 16V 0402
C2807 2320778 Bottom M 7 CHIPCAP X7R 10N K 16V 0402
C2808 2320778 Bottom M 5 CHIPCAP X7R 10N K 16V 0402
C2809 2320778 Bottom M 6 CHIPCAP X7R 10N K 16V 0402
C2810 2320778 Bottom M 7 CHIPCAP X7R 10N K 16V 0402
C2811 2315269 Bottom M 7 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C2900 2320778 Bottom J 5 CHIPCAP X7R 10N K 16V 0402
C2901 2320778 Bottom I 3 CHIPCAP X7R 10N K 16V 0402
C2902 2320620 Bottom J 5 CHIPCAP X7R 10N J 16V 0402
C2903 2320744 Bottom J 5 CHIPCAP X7R 1N0 K 50V 0402
C2904 2320783 Bottom J 8 CHIPCAP X7R 33N K 10V 0402
C2905 2320620 Bottom J 6 CHIPCAP X7R 10N J 16V 0402
C2906 2320744 Bottom J 6 CHIPCAP X7R 1N0 K 50V 0402
C3000 2320778 Bottom M 7 CHIPCAP X7R 10N K 16V 0402
C3001 2320805 Bottom M 7 CHIPCAP X5R 100N K 10V 0402
C3002 2320778 Bottom O 5 CHIPCAP X7R 10N K 16V 0402
C3003 2320805 Bottom O 6 CHIPCAP X5R 100N K 10V 0402
C3004 2320778 Bottom O 6 CHIPCAP X7R 10N K 16V 0402
C3200 2320481 Bottom J 2 CHIPCAP X5R 1U K 6V3 0603
C3201 2320505 Bottom J 2 CHIPCAP X5R 4U7 K 6.3V 0603
C3202 2320805 Bottom J 2 CHIPCAP X5R 100N K 10V 0402
C6000 2320514 Bottom O 2 CHIPCAP NP0 1P2 C 50V 0402
C6001 2320540 Bottom P 2 CHIPCAP NP0 15P J 50V 0402
C6002 2320520 Bottom N 3 CHIPCAP NP0 2P2 C 50V 0402
C6003 2320778 Bottom N 2 CHIPCAP X7R 10N K 16V 0402
C6004 2320778 Bottom N 3 CHIPCAP X7R 10N K 16V 0402
C6005 2320524 Bottom O 2 CHIPCAP NP0 3P3 C 50V 0402
C6006 2316001 Bottom N 3 CHIPCAP X5R 2U2 K 6V3 0603
C6007 2320778 Bottom O 3 CHIPCAP X7R 10N K 16V 0402
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 9
Page 10
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Item Code Side X Y Description
C6008 2320778 Bottom P 2 CHIPCAP X7R 10N K 16V 0402
C6009 2320540 Bottom P 2 CHIPCAP NP0 15P J 50V 0402
C6010 2320778 Bottom P 2 CHIPCAP X7R 10N K 16V 0402
C6011 2315269 Bottom O 1 CHIP ARRAY X5R 2X1U (2x1U2) K 6V3 0405
C6100 2320785 Bottom L 9 CHIPCAP X7R 47N K 10V 0402
C6101 2320778 Bottom L 8 CHIPCAP X7R 10N K 16V 0402
C6102 2320778 Bottom L 9 CHIPCAP X7R 10N K 16V 0402
C6103 2320805 Bottom K 8 CHIPCAP X5R 100N K 10V 0402
C6104 2320560 Top K 9 CHIPCAP NP0 100P J 50V 0402
C6105 2320744 Bottom K 8 CHIPCAP X7R 1N0 K 50V 0402
C6106 2315209 Bottom J 8 CHIP ARRAY X5R 2X33N M 10V 0405
C6107 2320744 Bottom K 8 CHIPCAP X7R 1N0 K 50V 0402
C6108 2321007 Bottom K 8 CHIPCAP X7R 22N K 16V 0402
C6109 2320546 Bottom K 9 CHIPCAP NP0 27P J 50V 0402
C6110 2321007 Bottom J 8 CHIPCAP X7R 22N K 16V 0402
C6111 2315261 Bottom J 9 CHIP ARRAY X5R 2X47N K 10V 0405
C6112 2320785 Bottom J 8 CHIPCAP X7R 47N K 10V 0402
C6113 2320752 Bottom K 8 CHIPCAP X7R 2N2 K 50V 0402
C6114 2320760 Bottom K 9 CHIPCAP X7R 4N7 K 25V 0402
C6115 2320552 Bottom K 9 CHIPCAP NP0 47P J 50V 0402
C6116 2351009 Bottom J 9 CHIPCAP X5R 1U K 6V3 0402
C6117 2320778 Bottom J 9 CHIPCAP X7R 10N K 16V 0402
C6180 2320805 Bottom N 4 CHIPCAP X5R 100N K 10V 0402
C6182 2320805 Bottom O 4 CHIPCAP X5R 100N K 10V 0402
C7000 2320620 Bottom H 9 CHIPCAP X7R 10N J 16V 0402
C7001 2320805 Bottom H 7 CHIPCAP X5R 100N K 10V 0402
C7003 2320620 Bottom I 9 CHIPCAP X7R 10N J 16V 0402
C7004 2320552 Bottom H 9 CHIPCAP NP0 47P J 50V 0402
C7005 2320524 Bottom H 9 CHIPCAP NP0 3P3 C 50V 0402
C7006 2320633 Bottom H 9 CHIPCAP NP0 220P J 25V 0402
C7007 2320620 Bottom H 7 CHIPCAP X7R 10N J 16V 0402
C7008 2320552 Bottom H 8 CHIPCAP NP0 47P J 50V 0402
Page 10 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 11
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Code Side X Y Description
C7009 2320536 Bottom H 9 CHIPCAP NP0 10P J 50V 0402
C7010 2320536 Bottom H 8 CHIPCAP NP0 10P J 50V 0402
C7011 2320508 Bottom H 8 CHIPCAP NP0 1P0 C 50V 0402
C7012 2320532 Bottom I 9 CHIPCAP NP0 6P8 C 50V 0402
C7014 2320604 Bottom H 9 CHIPCAP NP0 18P J 50V 0402
C7015 2320620 Bottom H 9 CHIPCAP X7R 10N J 16V 0402
C7016 2320508 Bottom H 8 CHIPCAP NP0 1P0 C 50V 0402
C7017 2320560 Bottom I 9 CHIPCAP NP0 100P J 50V 0402
C7018 2322023 Bottom I 9 CHIPCAP NP0 2N2 J 16V 0603
C7019 2320560 Bottom I 9 CHIPCAP NP0 100P J 50V 0402
C7020 2320554 Bottom J 4 CHIPCAP NP0 56P J 50V 0402
C7021 2351009 Bottom I 9 CHIPCAP X5R 1U K 6V3 0402
C7022 2320604 Bottom I 8 CHIPCAP NP0 18P J 50V 0402
C7023 2320620 Bottom I 8 CHIPCAP X7R 10N J 16V 0402
C7024 2320548 Bottom I 8 CHIPCAP NP0 33P J 50V 0402
C7025 2320604 Bottom I 8 CHIPCAP NP0 18P J 50V 0402
C7026 2320548 Bottom H 8 CHIPCAP NP0 33P J 50V 0402
C7027 2320536 Bottom I 8 CHIPCAP NP0 10P J 50V 0402
C7028 2320532 Bottom I 8 CHIPCAP NP0 6P8 C 50V 0402
C7029 2320552 Bottom G 9 CHIPCAP NP0 47P J 50V 0402
C7100 2320620 Bottom I 5 CHIPCAP X7R 10N J 16V 0402
C7101 2360001 Bottom I 5 CHIPCAP X5R 330N K 10V 0603
C7102 2320783 Bottom I 5 CHIPCAP X7R 33N K 10V 0402
C7103 2320548 Bottom H 5 CHIPCAP NP0 33P J 50V 0402
C7104 2320584 Bottom H 5 CHIPCAP X7R 1N0 J 50V 0402
C7105 2320778 Bottom I 3 CHIPCAP X7R 10N K 16V 0402
C7106 2320778 Bottom I 4 CHIPCAP X7R 10N K 16V 0402
C7107 2320778 Bottom I 3 CHIPCAP X7R 10N K 16V 0402
C7108 2320778 Bottom H 4 CHIPCAP X7R 10N K 16V 0402
C7109 2320778 Bottom H 4 CHIPCAP X7R 10N K 16V 0402
C7110 2320778 Bottom I 3 CHIPCAP X7R 10N K 16V 0402
C7111 2320778 Bottom I 4 CHIPCAP X7R 10N K 16V 0402
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 11
Page 12
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Item Code Side X Y Description
C7112 2320778 Bottom H 4 CHIPCAP X7R 10N K 16V 0402
C7113 2320778 Bottom H 4 CHIPCAP X7R 10N K 16V 0402
C7160 2320554 Bottom D 4 CHIPCAP NP0 56P J 50V 0402
C7161 2320516 Bottom D 5 CHIPCAP NP0 1P5 C 50V 0402
C7162 2320805 Bottom D 3 CHIPCAP X5R 100N K 10V 0402
C7163 2320538 Bottom D 3 CHIPCAP NP0 12P J 50V 0402
C7165 2320508 Bottom E 3 CHIPCAP NP0 1P0 C 50V 0402
C7166 2320560 Bottom E 5 CHIPCAP NP0 100P J 50V 0402
C7168 2320602 Bottom E 5 CHIPCAP NP0 4P7 C 50V 0402
C7169 2320532 Bottom G 4 CHIPCAP NP0 6P8 C 50V 0402
C7170 2320584 Bottom F 4 CHIPCAP X7R 1N0 J 50V 0402
C7171 2320536 Bottom G 4 CHIPCAP NP0 10P J 50V 0402
C7172 2320526 Bottom F 5 CHIPCAP NP0 3P9 C 50V 0402
C7173 2320602 Bottom F 4 CHIPCAP NP0 4P7 C 50V 0402
C7174 2320532 Bottom G 4 CHIPCAP NP0 6P8 C 50V 0402
C7175 2320560 Bottom F 3 CHIPCAP NP0 100P J 50V 0402
C7176 2320596 Bottom F 3 CHIPCAP X7R 3N3 J 50V 0402
C7177 2320596 Bottom F 3 CHIPCAP X7R 3N3 J 50V 0402
C7178 2320805 Bottom F 4 CHIPCAP X5R 100N K 10V 0402
C7179 2320544 Bottom F 3 CHIPCAP NP0 22P J 50V 0402
C7180 2320508 Bottom F 3 CHIPCAP NP0 1P0 C 50V 0402
C7181 2320560 Bottom F 3 CHIPCAP NP0 100P J 50V 0402
C7182 2320534 Bottom I 3 CHIPCAP NP0 8P2 C 50V 0402
C7183 2320560 Bottom F 4 CHIPCAP NP0 100P J 50V 0402
C7184 2320785 Bottom E 4 CHIPCAP X7R 47N K 10V 0402
C7185 2320538 Bottom E 3 CHIPCAP NP0 12P J 50V 0402
C7186 2320560 Bottom F 3 CHIPCAP NP0 100P J 50V 0402
C7188 2320534 Bottom H 3 CHIPCAP NP0 8P2 C 50V 0402
C7200 2351009 Bottom G 5 CHIPCAP X5R 1U K 6V3 0402
C7202 2314001 Bottom F 5 CHIPCAP NP0 470P J 6V3 0402
C7203 2320620 Bottom G 5 CHIPCAP X7R 10N J 16V 0402
C7204 2314001 Bottom F 5 CHIPCAP NP0 470P J 6V3 0402
Page 12 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 13
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Code Side X Y Description
C7206 2314001 Bottom F 5 CHIPCAP NP0 470P J 6V3 0402
C7207 2320584 Bottom G 5 CHIPCAP X7R 1N0 J 50V 0402
C7209 2314001 Bottom F 5 CHIPCAP NP0 470P J 6V3 0402
C7210 2314001 Bottom F 5 CHIPCAP NP0 470P J 6V3 0402
C7211 2320576 Bottom F 5 CHIPCAP X7R 470P J 50V 0402
C7212 2320620 Bottom E 6 CHIPCAP X7R 10N J 16V 0402
C7213 2320805 Bottom E 6 CHIPCAP X5R 100N K 10V 0402
C7214 2320552 Bottom E 5 CHIPCAP NP0 47P J 50V 0402
C7215 2351009 Bottom F 7 CHIPCAP X5R 1U K 6V3 0402
C7216 2320620 Bottom F 7 CHIPCAP X7R 10N J 16V 0402
C7218 2320596 Bottom E 6 CHIPCAP X7R 3N3 J 50V 0402
C7219 2320584 Bottom F 6 CHIPCAP X7R 1N0 J 50V 0402
C7220 2320584 Bottom F 6 CHIPCAP X7R 1N0 J 50V 0402
C7221 2320783 Bottom F 6 CHIPCAP X7R 33N K 10V 0402
C7222 2320764 Bottom F 6 CHIPCAP X7R 6N8 K 25V 0402
C7223 2320518 Bottom G 6 CHIPCAP NP0 1P8 C 50V 0402
C7224 2320805 Bottom I 3 CHIPCAP X5R 100N K 10V 0402
C7225 2320620 Bottom D 5 CHIPCAP X7R 10N J 16V 0402
C7226 2320805 Bottom D 6 CHIPCAP X5R 100N K 10V 0402
C7300 2320536 Bottom G 8 CHIPCAP NP0 10P J 50V 0402
C7301 2320536 Bottom F 8 CHIPCAP NP0 10P J 50V 0402
C7303 2320943 Bottom D 6 CHIPCAP NP0 HQ 1P0 B 16V 0402
C7304 2320501 Bottom C 9 CHIPCAP NP0 1P2 B 50V 0402
C7305 2320584 Bottom G 7 CHIPCAP X7R 1N0 J 50V 0402
C7306 2320620 Bottom G 8 CHIPCAP X7R 10N J 16V 0402
C7307 2320540 Bottom F 7 CHIPCAP NP0 15P J 50V 0402
C7308 2320530 Bottom F 8 CHIPCAP NP0 5P6 C 50V 0402
C7309 2320536 Bottom F 8 CHIPCAP NP0 10P J 50V 0402
C7311 2320620 Top B 7 CHIPCAP X7R 10N J 16V 0402
C7312 2320560 Top B 7 CHIPCAP NP0 100P J 50V 0402
C7313 2320596 Top B 7 CHIPCAP X7R 3N3 J 50V 0402
C7314 2312255 Bottom E 8 CHIPCAP X5R 10U K 10V 1206
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 13
Page 14
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Item Code Side X Y Description
C7315 2320560 Bottom G 9 CHIPCAP NP0 100P J 50V 0402
C7316 2320532 Bottom F 9 CHIPCAP NP0 6P8 C 50V 0402
C7317 2320943 Bottom D 7 CHIPCAP NP0 HQ 1P0 B 16V 0402
C7318 2320584 Bottom G 9 CHIPCAP X7R 1N0 J 50V 0402
C7319 2320560 Bottom G 8 CHIPCAP NP0 100P J 50V 0402
C7320 2320584 Bottom F 9 CHIPCAP X7R 1N0 J 50V 0402
C7321 2320584 Bottom F 9 CHIPCAP X7R 1N0 J 50V 0402
C7322 2320532 Bottom G 9 CHIPCAP NP0 6P8 C 50V 0402
C7323 2320524 Bottom P 9 CHIPCAP NP0 3P3 C 50V 0402
C7325 2320552 Bottom C 2 CHIPCAP NP0 47P J 50V 0402
C7326 2320552 Bottom C 2 CHIPCAP NP0 47P J 50V 0402
C7327 2320552 Bottom E 1 CHIPCAP NP0 47P J 50V 0402
C7328 2320552 Bottom D 1 CHIPCAP NP0 47P J 50V 0402
C7329 2320544 Bottom C 2 CHIPCAP NP0 22P J 50V 0402
C7330 2320544 Bottom C 2 CHIPCAP NP0 22P J 50V 0402
C7399 2320532 Bottom G 7 CHIPCAP NP0 6P8 C 50V 0402
D2200 4376371 Bottom L 4 UEMEK2v0 LF WDENA TFBGA244
D2800 4375107 Bottom K 6 TIKUEDGE1.1 F751728A C035 288UBGA
D3000 4347215 Bottom M 8 SDRAM 4MX16 1.8V/1.8V WBGA60 PBFREE
D3001 4347041 Bottom N 5 FLASH 8MX16 1.8/1.8V FBGA44
D3002 4347157 Bottom N 8 COMBO ADAPTER + 64M NAND TBGA44 PBFREE
D6000 4349855 Bottom N 2 SINGLE INV 74LX1G04
F2000 5119039 Bottom P 4 SM FUSE F 2.0A 32V 0603
G7200 4520005 Bottom G 5 VCTCXO 19.2MHZ 2.78V
G7201 4520013 Bottom G 6 UHF VCO 986-1034MHz/2040-2140MHz
L2000 3203755 Top Q 5 FERRITE BEAD 0.6R 600R/100MZ 0402
L2001 3203755 Top R 5 FERRITE BEAD 0.6R 600R/100MZ 0402
L2002 3203755 Top Q 5 FERRITE BEAD 0.6R 600R/100MZ 0402
L2003 3203803 Top Q 6 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2004 3203803 Top Q 7 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2005 3203803 Top Q 7 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2006 3203743 Bottom P 3 FERR.BEAD 0R03 42R/100MHZ 3A 0805
Page 14 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 15
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Code Side X Y Description
L2100 3203803 Top Q 6 CHIP BEAD ARRAY 2X1000R 0R75 0405
L2151 3203807 Bottom C 4 CHIP BEAD ARRAY 2X220R 0405
L2300 3203723 Bottom M 9 FERRITE BEAD 0R35 68R/100MHZ 0603
L2301 3648941 Bottom N 9 CHOKE 6.8UH M 1A 0R31 3.6X3.6X1.2
L2400 3648955 Bottom H 2 COIL 0.47MH 50MA 3.3X3.4X1.4MM
L6000 3646051 Bottom O 2 CHIP COIL 3N9 +-0N3 Q28/800M 0402
L6001 3646051 Bottom O 2 CHIP COIL 3N9 +-0N3 Q28/800M 0402
L6003 3646063 Bottom O 2 CHIP COIL 22N J Q28/800MHZ 0402
L6004 3646063 Bottom O 2 CHIP COIL 22N J Q28/800MHZ 0402
L6100 3648975 Bottom L 8 CHIP COIL 33N G Q20/500MHZ 0402
L6101 3648975 Bottom L 8 CHIP COIL 33N G Q20/500MHZ 0402
L6102 3646081 Top K 9 CHIP COIL 68N J Q17/300MHZ 0402
L6103 3646139 Bottom K 9 CHIP COIL 120NH J Q8/100MHZ 0402
L7000 3646235 Bottom G 8 CHIP COIL 15N J Q7/100MHZ 0402
L7001 3646235 Bottom G 8 CHIP COIL 15N J Q7/100MHZ 0402
L7002 3646217 Bottom H 8 CHIP COIL 3N9 +-0N3 Q7/100M 0402
L7003 3646217 Bottom H 8 CHIP COIL 3N9 +-0N3 Q7/100M 0402
L7101 3645009 Bottom H 5 CHIP COIL 33NH J Q12/100MHZ 0603
L7160 3646061 Bottom D 4 CHIP COIL 15N J Q30/800MHZ 0402
L7161 3646099 Bottom D 3 CHIP COIL 2N7 +-0N3 Q29/800M 0402
L7162 3646405 Bottom D 4 CHIP COIL 6N2 J Q20/250MHZ 0402
L7163 3646415 Bottom D 4 CHIP COIL 19N J Q24/250MHZ 0402
L7164 3645351 Bottom E 5 CHIP COIL 220N J Q8/50MHZ 0603
L7165 3645095 Bottom G 4 CHIP COIL 120N J Q16/100MHZ 0603
L7166 3646065 Bottom E 3 CHIP COIL 12N J Q31/800MHZ 0402
L7167 3645301 Bottom F 4 CHIP COIL 180N J Q13/100MHZ 0603
L7168 3645351 Bottom G 4 CHIP COIL 220N J Q8/50MHZ 0603
L7169 3645095 Bottom G 5 CHIP COIL 120N J Q16/100MHZ 0603
L7170 3646135 Bottom F 4 CHIP COIL 82N +-0N3 Q17/300M 0402
L7171 3646067 Bottom E 3 CHIP COIL 18N J Q29/800MHZ 0402
L7172 3646047 Bottom G 6 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7173 3646135 Bottom E 4 CHIP COIL 82N +-0N3 Q17/300M 0402
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 15
Page 16
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Item Code Side X Y Description
L7174 3645161 Bottom F 4 CHIP COIL 150N J Q14/100MHZ 0603
L7175 3646061 Bottom E 4 CHIP COIL 15N J Q30/800MHZ 0402
L7176 3645095 Bottom I 3 CHIP COIL 120N J Q16/100MHZ 0603
L7177 3645095 Bottom H 3 CHIP COIL 120N J Q16/100MHZ 0603
L7178 3645351 Bottom G 5 CHIP COIL 220N J Q8/50MHZ 0603
L7179 3645195 Bottom H 3 CHIP COIL 82N J Q12/100MHZ 0603
L7200 3646047 Bottom G 7 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7301 3646081 Bottom C 8 CHIP COIL 68N J Q17/300MHZ 0402
L7302 4550283 Bottom C 8 DIR.COUPLER 824-849MHZ 1.6X0.8MM
L7303 3646009 Top C 7 CHIP COIL 10N J Q30/800MHZ 0402
L7305 3646051 Bottom D 7 CHIP COIL 3N9 +-0N3 Q28/800M 0402
L7307 4550287 Bottom B 8 DIR.COUPLER 1850-1910MHZ 1.6X0.8
L7308 3646421 Bottom D 6 CHIP COIL 1N0 K Q16/250MHZ 0402
L7309 3646047 Bottom F 8 CHIP COIL 3N3 +-0N3 Q28/800M 0402
L7310 3646417 Bottom C 9 CHIP COIL 5N6 J Q20/250MHZ 0402
L7311 3648967 Bottom C 9 CHIP COIL 27N C Q25/250MHz 0402
L7312 3646107 Bottom P 9 CHIP COIL 1N5 +-0N1 Q45/1GHZ 0402
N2000 4370961 Top Q 4 NUT/CP2137 ASIC HBCC16++
N2002 4341705 Bottom E 9 CURRNT SENS LM3820 USMD10 PB-FREE
N2100 4342429 Top Q 3 AF AMP 0.4W LM4890/NCP2890 PBFREE
N2301 4341635 Bottom N 9 DC/DC BUCK REG(NCP1510)USMD9
N2400 4346027 Bottom G 2 EL DRIVER D381A 2-7V MSOP-10
N2600 4865403 Bottom E 9 IRDA 1.15Mbps 2.2mm RoHS
N3200 4341561 Bottom I 2 VREG 2.85/150MA(LP3987-2.85)USMD5
N6000 4376355 Bottom O 3 TJA4 BLUETOOTH DEVICE
N6001 4341561 Bottom N 1 VREG 2.85/150MA(LP3987-2.85)USMD5
N6100 4341427 Bottom K 9 FM RECEIVER(TEA5767HN) LQFP40
N7000 4380021 Bottom I 8 JUPITER D4 PMB3365G VQFN-40
N7100 4380033 Bottom I 4 BATMAN RF RX ASIC STB7102FTR
N7160 4375161 Bottom E 4 LNA/MIXER/DOWNCNTR ALFRED VQFN-24
N7200 4341395 Bottom E 5 1XPLL/SYNTH 2.5GHZ(LMX2310U)MLF20
N7300 4129091 Top B 7 ASIP STPAC01F2 CDMA PWR DET BGA-8
Page 16 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 17
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Code Side X Y Description
N7301 4355671 Bottom F 9 PW AMP SKY77402 CDMA800 CENTAURUS
N7302 4355655 Bottom F 8 PW AMP RF3448 CDMA1900
R2000 1430115 Bottom E 8 CHIPRES 0W06 2K2 F 200PPM 0402
R2001 1430115 Bottom D 8 CHIPRES 0W06 2K2 F 200PPM 0402
R2002 1820039 Bottom I 2 NTC RES 0W1 47K J B 4050+-3% 0402
R2006 1825033 Top Q 4 CHIP VARISTOR VWM14V VC46V 0402
R2007 1430714 Top Q 4 CHIPRES 0W06 33R J 0402
R2008 1430804 Top Q 5 CHIPRES 0W06 100K J 0402
R2009 4129265 Top Q 4 ASIP USB2 FILTER BGA10 PBFREE
R2010 1430812 Top Q 4 CHIPRES 0W06 220K J 0402
R2011 1430812 Top R 3 CHIPRES 0W06 220K J 0402
R2012 1825033 Top R 8 CHIP VARISTOR VWM14V VC46V 0402
R2013 1825033 Top R 7 CHIP VARISTOR VWM14V VC46V 0402
R2014 1825033 Top Q 7 CHIP VARISTOR VWM14V VC46V 0402
R2015 1825033 Top R 7 CHIP VARISTOR VWM14V VC46V 0402
R2050 1430812 Bottom L 3 CHIPRES 0W06 220K J 0402
R2100 1430804 Top C 3 CHIPRES 0W06 100K J 0402
R2101 1430754 Top B 3 CHIPRES 0W06 1K0 J 0402
R2102 1430700 Top B 3 CHIPRES 0W06 10R J 0402
R2103 1430742 Top B 3 CHIPRES 0W06 390R J 0402
R2104 1825033 Bottom D 4 CHIP VARISTOR VWM14V VC46V 0402
R2105 1430693 Top R 7 CHIPRES 0W06 5R6 J 0402
R2106 1430693 Top Q 7 CHIPRES 0W06 5R6 J 0402
R2107 1430693 Top R 6 CHIPRES 0W06 5R6 J 0402
R2108 1430693 Top R 6 CHIPRES 0W06 5R6 J 0402
R2109 1430796 Top B 2 CHIPRES 0W06 47K J 0402
R2110 1430804 Top C 2 CHIPRES 0W06 100K J 0402
R2111 1430778 Top B 2 CHIPRES 0W06 10K J 0402
R2112 1430804 Top C 2 CHIPRES 0W06 100K J 0402
R2115 1430808 Top Q 3 CHIPRES 0W06 150K J 0402
R2116 1430121 Top Q 3 CHIPRES 0W06 22K F 200PPM 0402
R2117 1430137 Top R 3 CHIPRES 0W06 1K0 F 200PPM 0402
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 17
Page 18
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Item Code Side X Y Description
R2118 1430137 Top R 3 CHIPRES 0W06 1K0 F 200PPM 0402
R2119 1430778 Top R 3 CHIPRES 0W06 10K J 0402
R2120 1825031 Bottom C 4 VARISTOR ARRAY 2XVWM16V VC50 0405
R2200 1414605 Bottom K 2 CHIPRES 0W25 0R22 J 0805
R2201 1430778 Bottom J 7 CHIPRES 0W06 10K J 0402
R2202 1430770 Bottom O 5 CHIPRES 0W06 4K7 J 0402
R2203 1430770 Bottom O 5 CHIPRES 0W06 4K7 J 0402
R2204 1430804 Bottom O 5 CHIPRES 0W06 100K J 0402
R2205 1430804 Bottom O 6 CHIPRES 0W06 100K J 0402
R2206 1430804 Bottom O 4 CHIPRES 0W06 100K J 0402
R2207 1430804 Bottom O 4 CHIPRES 0W06 100K J 0402
R2400 1430778 Bottom B 6 CHIPRES 0W06 10K J 0402
R2401 1430770 Bottom F 2 CHIPRES 0W06 4K7 J 0402
R2402 1430770 Bottom H 2 CHIPRES 0W06 4K7 J 0402
R2403 1430770 Bottom H 2 CHIPRES 0W06 4K7 J 0402
R2404 1430798 Bottom I 2 CHIPRES 0W06 56K J 0402
R2406 1430690 Bottom H 2 CHIPRES JUMPER 0R0 0402
R2407 1430804 Bottom I 2 CHIPRES 0W06 100K J 0402
R2408 1430812 Bottom H 2 CHIPRES 0W06 220K J 0402
R2600 1413850 Bottom D 9 CHIPRES 0W125 4R7 J 0805
R2700 4129071 Bottom J 7 ASIP SIM INTERFACE ** PB-FREE **
R2800 1430770 Bottom M 6 CHIPRES 0W06 4K7 J 0402
R2801 1430770 Bottom M 7 CHIPRES 0W06 4K7 J 0402
R2802 1430117 Bottom M 6 CHIPRES 0W06 100R F 200PPM 0402
R2803 1430117 Bottom M 6 CHIPRES 0W06 100R F 200PPM 0402
R2804 1430784 Bottom M 5 CHIPRES 0W06 15K J 0402
R2805 1430710 Bottom M 5 CHIPRES 0W06 22R J 0402
R2806 1430778 Bottom M 7 CHIPRES 0W06 10K J 0402
R2807 1430700 Bottom M 7 CHIPRES 0W06 10R J 0402
R2808 1430778 Bottom O 5 CHIPRES 0W06 10K J 0402
R2821 1430804 Bottom C 2 CHIPRES 0W06 100K J 0402
R2900 1430770 Bottom J 5 CHIPRES 0W06 4K7 J 0402
Page 18 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 19
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Code Side X Y Description
R2901 1430754 Bottom J 6 CHIPRES 0W06 1K0 J 0402
R2902 1430770 Bottom J 5 CHIPRES 0W06 4K7 J 0402
R2903 1430754 Bottom J 6 CHIPRES 0W06 1K0 J 0402
R2904 1430770 Bottom J 6 CHIPRES 0W06 4K7 J 0402
R2905 1430770 Bottom J 8 CHIPRES 0W06 4K7 J 0402
R3000 1430722 Bottom M 7 CHIPRES 0W06 68R J 0402
R3001 1430804 Bottom O 5 CHIPRES 0W06 100K J 0402
R3002 1430770 Bottom J 7 CHIPRES 0W06 4K7 J 0402
R3200 1430690 Bottom J 2 CHIPRES JUMPER 0R0 0402
R3201 1430804 Bottom I 2 CHIPRES 0W06 100K J 0402
R3202 4129101 Bottom K 2 ASIP MMC FILTER *** PB-FREE ***
R6000 1430830 Bottom N 2 CHIPRES 0W06 1M0 J 0402
R6001 1430778 Bottom N 3 CHIPRES 0W06 10K J 0402
R6002 1430778 Bottom O 3 CHIPRES 0W06 10K J 0402
R6003 1430832 Bottom N 3 CHIPRES 0W06 2K7 J 0402
R6005 1430691 Bottom O 3 CHIPRES 0W06 2R2 J 0402
R6007 1430690 Bottom N 4 CHIPRES JUMPER 0R0 0402
R6100 1430778 Bottom L 8 CHIPRES 0W06 10K J 0402
R6101 1430778 Bottom L 9 CHIPRES 0W06 10K J 0402
R6102 1430792 Bottom L 8 CHIPRES 0W06 33K J 0402
R6103 1430804 Bottom L 9 CHIPRES 0W06 100K J 0402
R6104 1430792 Bottom K 8 CHIPRES 0W06 33K J 0402
R6105 1430786 Bottom J 9 CHIPRES 0W06 18K J 0402
R7000 1430780 Bottom I 7 CHIPRES 0W06 12K J 0402
R7001 1430778 Bottom I 9 CHIPRES 0W06 10K J 0402
R7002 1430790 Bottom I 9 CHIPRES 0W06 27K J 0402
R7003 1430778 Bottom J 4 CHIPRES 0W06 10K J 0402
R7004 1430730 Bottom I 8 CHIPRES 0W06 150R J 0402
R7005 1430734 Bottom I 8 CHIPRES 0W06 220R J 0402
R7006 1430690 Bottom I 7 CHIPRES JUMPER 0R0 0402
R7007 1430794 Bottom I 7 CHIPRES 0W06 39K J 0402
R7008 1430794 Bottom I 8 CHIPRES 0W06 39K J 0402
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 19
Page 20
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Item Code Side X Y Description
R7100 1430754 Bottom I 5 CHIPRES 0W06 1K0 J 0402
R7101 1430744 Bottom I 4 CHIPRES 0W06 470R J 0402
R7102 1430770 Bottom H 5 CHIPRES 0W06 4K7 J 0402
R7103 1430776 Bottom I 3 CHIPRES 0W06 8K2 J 0402
R7104 1430790 Bottom I 4 CHIPRES 0W06 27K J 0402
R7160 1430681 Bottom D 3 CHIPRES 0W06 4R3 J 0402
R7161 1430796 Bottom F 3 CHIPRES 0W06 47K J 0402
R7162 1430724 Bottom F 3 CHIPRES 0W06 82R J 0402
R7163 1430796 Bottom F 3 CHIPRES 0W06 47K J 0402
R7164 1430681 Bottom E 3 CHIPRES 0W06 4R3 J 0402
R7165 1430796 Bottom F 3 CHIPRES 0W06 47K J 0402
R7200 1430700 Bottom G 6 CHIPRES 0W06 10R J 0402
R7203 1430690 Bottom F 5 CHIPRES JUMPER 0R0 0402
R7204 1430726 Bottom J 7 CHIPRES 0W06 100R J 0402
R7205 1430778 Bottom G 5 CHIPRES 0W06 10K J 0402
R7208 1430700 Bottom E 6 CHIPRES 0W06 10R J 0402
R7209 1430690 Bottom F 6 CHIPRES JUMPER 0R0 0402
R7210 1430730 Bottom G 6 CHIPRES 0W06 150R J 0402
R7211 1430778 Bottom F 6 CHIPRES 0W06 10K J 0402
R7212 1430778 Bottom F 6 CHIPRES 0W06 10K J 0402
R7213 1430766 Bottom F 6 CHIPRES 0W06 3K9 J 0402
R7215 1430762 Bottom I 3 CHIPRES 0W06 2K2 J 0402
R7216 1430700 Bottom D 6 CHIPRES 0W06 10R J 0402
R7300 1430720 Top C 8 CHIPRES 0W06 56R J 0402
R7301 1820039 Bottom E 7 NTC RES 0W1 47K J B 4050+-3% 0402
R7302 1430720 Top B 8 CHIPRES 0W06 56R J 0402
R7304 1430690 Top B 7 CHIPRES JUMPER 0R0 0402
S2401 5409235 Bottom B 7 SM TACT SW TRAV 0.2 4.1X3.55X1.75
S2402 5201001 Bottom F 1 SM VOLUME BUTTON 16VDC 50MA
S2403 5201001 Bottom H 1 SM VOLUME BUTTON 16VDC 50MA
T7000 4550271 Bottom G 9 BALUN 900+/-100MHZ 0.9DB
T7001 4550273 Bottom H 8 TRANSF BALUN 50:100 1900+/-100MHZ
Page 20 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Page 21
6255/6255i/6256/6256i (RM-19)
Nokia Customer Care Parts Lists and Exploded View
Item Code Side X Y Description
V2000 4113721 Bottom P 2 TVS DI 1PMT16AT3 16V 175W PWRMITE
V2101 4210431 Top B 3 TR BC848BL3 N 30V 0A1 0W25 TSLP-3
V2400 4210431 Bottom I 2 TR BC848BL3 N 30V 0A1 0W25 TSLP-3
V2900 4210431 Bottom J 8 TR BC848BL3 N 30V 0A1 0W25 TSLP-3
V6100 4110965 Bottom L 8 CAP.DI BB202 CT 2.5 FM 0R8 SOD523
V6101 4110965 Bottom L 9 CAP.DI BB202 CT 2.5 FM 0R8 SOD523
V7100 4110921 Bottom H 4 CAP.DI BBY57-02W 1/4 16/4P SOD523
X2000 5460061 Bottom Q 6 SM SYSTEM CONNECTOR 14POL
X2002 5409255 Bottom D 7 SM LYNX BATT CONN 3POL 12V 2A H7.
X2100 5469271 Bottom B 3 CONN AUD 3POL SMD 2.5MM DIA
X2450 5469279 Bottom D 2 CONN BTB 2X30 F P0.4
X2700 5434003 Bottom I 6 SM SIM CONN 2X3POL P2.54 H2.2
X3200 5406969 Bottom L 2 SM MMC CONN 6POL P2.5 H1.6
X7071 5409293 Bottom P 9 ANTENNA GROUND CLIP SMD DMD10149
X7300 5429065 Bottom C 8 CONN RF+SW 100V 1W 50R 2.2GHZ
X8000 5409309 Top A 2 MODULE ID COMPONENT 2.8X1.8X0.3
Z2101 4129269 Bottom M 3 ASIP AUDIO OUTPUT STAGE
Z2102 4129269 Bottom M 4 ASIP AUDIO OUTPUT STAGE
Z2103 4129267 Top C 3 ASIP AUDIO MICROPHONE INPUT STAGE
Z2104 4129267 Top R 6 ASIP AUDIO MICROPHONE INPUT STAGE
Z2105 4129267 Top Q 8 ASIP AUDIO MICROPHONE INPUT STAGE
Z2106 4129269 Bottom M 4 ASIP AUDIO OUTPUT STAGE
Z2400 4129031 Top Q 5 ASIP KEYBOARD INTERFACE *PB-FREE*
Z6000 4551041 Bottom O 2 LTCC FILT 2441.75+-41.75MHZ 2.5X2
Z7000 4511427 Bottom G 9 SAW FILT 836.5+-12.5MHZ 2X1.6
Z7001 4513007 Bottom G 8 BAW FILT 1880+-30MHZ 2X1.6X0.6
Z7160 4511441 Bottom E 5 SAW FILT 881.5+-12.5MHZ/2.5 2X1.6
Z7161 4511423 Bottom E 3 SAW FILT 1960+-30MHZ/3.2DB 2X1.6
Z7162 4510439 Bottom F 4 XTAL FILT 128.1MHZ/4DB 3X3X1
Z7163 4511543 Bottom G 3 SAW FILT 128.1MHZ 7X5X1.48
Issue 2 05/2005 ©2005 Nokia Corporation Company Confidential Page 21
Page 22
6255/6255i/6256/6256i (RM-19)
Parts Lists and Exploded View
Item Code Side X Y Description
Z7300 4550295 Bottom C 8 DIPL 859+/-35MHZ-1920+/-70MHZ
Z7301 4512197 Bottom C 6 DUPL 1930-1990/1850-1910MHZ 5X5
Z7302 4512203 Bottom C 7 DUPL 824-849/869-894MHZ 3.8X3.8X1.5
Page 22 ©2005 Nokia Corporation Company Confidential Issue 2 05/2005
Loading...
